FRO­NIUS Selectiva 4185 User manual

Fronius prints on elemental chlorine free paper (ECF) sourced from certified sustainable forests (FSC).
/ Perfect Charging / Perfect Welding / Solar Energy
42,0426,0310,EN 007-13052019
Selectiva Li 8 kW
2200 / 4185 / 8090
8110
Selectiva Li 16 kW
8180 / 8210
Selectiva Li 18 kW
2250 / 2320 / 4260
4300 / 4325
Operating Instructions
Battery charging system
EN

2

3
EN
Dear reader,
Introduction Thank you for the trust you have placed in our company and congratulations on buying this
high-quality Fronius product. These instructions will help you familiarise yourself with the
product. Reading the instructions carefully will enable you to learn about the many different
features it has to offer. This will allow you to make full use of its advantages.
Please also note the safety rules to ensure greater safety when using the product. Careful
handling of the product will repay you with years of safe and reliable operation. These are
essential prerequisites for excellent results.
The latest version of the operating instructions can be found on the Fronius website
www.fronius.com.
Explanation of
safety notices DANGER!
Indicates immediate danger.
► If not avoided, death or serious injury will result.
WARNING!
Indicates a potentially hazardous situation.
► If not avoided, death or serious injury may result.
CAUTION!
Indicates a situation where damage or injury could occur.
► If not avoided, minor injury and/or damage to property may result.
NOTE!
Indicates a risk of flawed results and possible damage to the equipment.
IMPORTANT!
Indicates tips for correct operation and other particularly useful information.
This does not indicate a potentially hazardous situation.
If you see any of the symbols depicted in the "Safety rules" chapter, special care is re-
quired.

4

5
EN
Contents
Safety rules ................................................................................................................................................ 7
General ................................................................................................................................................. 7
Proper use ............................................................................................................................................ 7
Environmental conditions...................................................................................................................... 7
Mains connection .................................................................................................................................. 8
Dangers from mains current and charging current ............................................................................... 8
Dangers posed by the battery............................................................................................................... 8
General information regarding the handling of lithium batteries ........................................................... 9
Protecting yourself and others .............................................................................................................. 9
Safety measures in normal operation ................................................................................................... 10
EMC Device Classifications .................................................................................................................. 10
EMC measures ..................................................................................................................................... 10
Data protection...................................................................................................................................... 10
Maintenance and repair ........................................................................................................................ 10
Obligations of the operator.................................................................................................................... 11
Safety inspection................................................................................................................................... 11
Safety symbols...................................................................................................................................... 11
Disposal ................................................................................................................................................ 12
Copyright............................................................................................................................................... 12
General information ................................................................................................................................... 13
Device concept ..................................................................................................................................... 13
Customer-specific information .............................................................................................................. 13
Correct battery configuration................................................................................................................. 13
Mains connection .................................................................................................................................. 13
Correct arrangement of the mains/charging leads................................................................................14
Warning notices on the device.............................................................................................................. 15
Warning notices inside the device ........................................................................................................ 16
Setup regulations .................................................................................................................................. 17
Wall bracket .......................................................................................................................................... 18
Control elements and connections............................................................................................................. 21
Controls and connections ..................................................................................................................... 21
Control panel......................................................................................................................................... 23
Charging the battery .................................................................................................................................. 25
Charging ............................................................................................................................................... 25
Interrupting charging ............................................................................................................................. 27
Stopping charging ................................................................................................................................. 28
Display ....................................................................................................................................................... 29
Overview of modes ............................................................................................................................... 29
Standard mode ..................................................................................................................................... 29
Menu selection...................................................................................................................................... 30
Statistics mode...................................................................................................................................... 30
History mode......................................................................................................................................... 31
Configuration mode............................................................................................................................... 32
Charging settings .................................................................................................................................. 34
Additional functions............................................................................................................................... 37
General options..................................................................................................................................... 39
Reset settings ....................................................................................................................................... 40
USB mode............................................................................................................................................. 40
Status codes ......................................................................................................................................... 42
Options....................................................................................................................................................... 45
Safety.................................................................................................................................................... 45
Charging lights ...................................................................................................................................... 46
Wall bracket .......................................................................................................................................... 46
Floor bracket ......................................................................................................................................... 47
LED strip ............................................................................................................................................... 47
IP 23...................................................................................................................................................... 47
Air filter.................................................................................................................................................. 47
"Mobile" kit ............................................................................................................................................ 47

6
Remote control system ......................................................................................................................... 47
Technical data............................................................................................................................................ 48
Selectiva 8 kW Li-Ion ............................................................................................................................ 48
Selectiva 16 kW Li-Ion .......................................................................................................................... 49
Selectiva 18 kW Li-Ion .......................................................................................................................... 50

7
EN
Safety rules
General The device is manufactured using state-of-the-art technology and according to recognised
safety standards. If used incorrectly or misused, however, it can cause:
- Injury or death to the operator or a third party
- Damage to the device and other material assets belonging to the operator
- Inefficient operation of the device
All persons involved in commissioning, operating, maintaining and servicing the device
must:
- Be suitably qualified
- Read and follow these Operating Instructions carefully
The Operating Instructions must always be at hand wherever the device is being used. In
addition to the Operating Instructions, attention must also be paid to any generally appli-
cable and local regulations regarding accident prevention and environmental protection.
All safety and danger notices on the device:
- Must be in a legible state
- Must not be damaged
- Must not be removed
- Must not be covered, pasted or painted over
For the location of the safety and danger notices on the device, refer to the section headed
"General information" in the Operating Instructions for the device.
Before switching on the device, rectify any faults that could compromise safety.
This is for your personal safety!
Proper use The device is to be used exclusively for its intended purpose. Any use above and beyond
this purpose is deemed improper. The manufacturer is not liable for any damage, or unex-
pected or incorrect results arising out of such misuse.
Proper use includes:
- carefully reading and obeying all operating instructions and safety and danger notices
- performing all stipulated inspection and maintenance work
- following all instructions from the battery and vehicle manufacturers
Proper handling of the device is essential for it to function correctly. The device must never
be pulled around by the cable.
Environmental
conditions
Operation or storage of the device outside the stipulated area will be deemed as not in ac-
cordance with the intended purpose. The manufacturer shall not be held liable for any dam-
age arising from such usage.
For exact information on permitted environmental conditions, please refer to the "Technical
data" section.

8
Mains connection Devices with a higher rating may affect the energy quality of the mains due to their current
consumption.
This may affect a number device types in terms of:
- Connection restrictions
- Criteria with regard to the maximum permissible mains impedance *)
- Criteria with regard to the minimum short-circuit power requirement *)
*) at the interface with the public grid
see "Technical data"
In this case, the plant operator or the person using the device should check whether the
device may be connected, where appropriate by discussing the matter with the power sup-
ply company.
IMPORTANT! Ensure that the mains connection is earthed properly
Dangers from
mains current
and charging cur-
rent
Anyone working with chargers exposes themselves to numerous dangers e.g.:
- Risk of electrocution from mains current and charging current
- Hazardous electromagnetic fields, which can risk the lives of those using cardiac
pacemakers
An electric shock can be fatal. Every electric shock is potentially life threatening. To avoid
electric shocks while using the charger:
- Do not touch any live parts inside or on the outside of the charger.
- Under no circumstances touch the battery poles
- Do not short-circuit the charging lead or charging terminals
All cables and leads must be secured, undamaged, insulated and adequately dimen-
sioned. Loose connections, scorched, damaged or inadequately dimensioned cables and
leads must be immediately repaired by authorised personnel.
Dangers posed
by the battery The substances contained in the battery to be charged can be harmful to the environment
as well as to human and animal health.
If the battery becomes damaged, please observe the following points:
- Make sure that leaking fluids cannot get into the soil or groundwater
- If pollution has already occurred, it must be removed in accordance with relevant na-
tional regulations
The battery can catch fire if overheated. Do not expose the battery to heat
(e.g. a permanent heat source or fire).
If the battery is damaged or subjected to improper use, dangerous vapours may be given
off, which can irritate the airways.
If this happens:
- Ensure an adequate supply of fresh air
- Seek medical attention in case of discomfort
Liquid may emerge from a faulty battery.
- Avoid contact with the liquid
- Take the battery to an authorised service centre for repair
- Clean and check any parts that have come into contact with the liquid
Do not operate or store the device in a potentially explosive atmosphere.
Special regulations apply in rooms at risk of fire or explosion.
Observe relevant national and international regulations.

9
EN
To comply with European Directive 2006/66/EC on batteries and its implementation in na-
tional law, batteries that have reached the end of their life must be collected separately and
returned to an approved recycling facility. Be sure to return any used battery to your dealer,
or find out about the approved collection and recycling facilities in your area. Ignoring this
European Directive may be harmful to the environment and your own health!
As soon as it appears that the battery has been mechanically damaged, dispose of the bat-
tery in accordance with national laws and guidelines at your nearest recycling centre.
If anything is unclear or for any questions concerning disposal, contact an authorised ser-
vice centre.
General informa-
tion regarding the
handling of lithi-
um batteries
- Lithium batteries have a gas-tight seal and are harmless provided the manufacturer's
specifications are adhered to during use and handling
- Never use chargers that are not suitable for the battery type
- Do not short-circuit
- Do not mechanically damage them (tap, deform, dismantle, etc.)
- Never heat them to above the permissible temperature or burn them
- Always store batteries in a cool, dry place
- Lithium batteries are safe to use if they are handled properly within the parameters
specified by the manufacturer
- Mishandling or circumstances that result in improper use can result in the battery con-
tents and decomposition products leaking and related reactions that are extremely
hazardous to health and the environment
- As a wide variety of chemical substances are found inside the battery, in the event of
an accident always follow the manufacturer's specifications regarding emergency re-
sponse actions and first aid
- Lithium batteries must, in all circumstances, be handled according to the manufactur-
er's instructions
- In particular, this applies to observing the limits for maximum current load, charging
and cutoff voltages as well as mechanical and thermal loads
- The charger and battery are designed to work together and must not be modified or
manipulated in any way as this can result in considerable safety risks
- Ideally, lithium batteries should be stored at room temperature in a dry location (details
regarding the storage temperature range can be found in the manufacturer's instruc-
tions)
- Large temperature fluctuations must be avoided (e.g. do not store the batteries near
to heaters, do not expose them to prolonged sunlight)
- Should damage or improper handling result in the leakage of substances, then the
manufacturer's instructions must be followed
- This includes the use of personal protective equipment
- When storing large quantities of lithium batteries, the local authorities should be con-
sulted
- Employees must be trained on how to correctly handle lithium batteries (in the same
way as hazardous substances)
Protecting your-
self and others
While the charger is in operation, keep all persons, especially children, out of the working
area. If, however, there are people in the vicinity,
- warn them about all the dangers (hazardous electrolytes and gases, danger from
mains and charging current, etc.),
- provide suitable protective equipment.

10
Before leaving the work area, ensure that people or property cannot come to any harm in
your absence.
Safety measures
in normal opera-
tion
- Chargers with a ground conductor must only be operated on a mains supply with a
ground conductor and a socket with a ground conductor contact. If the charger is op-
erated on a mains supply without a ground conductor or in a socket without a ground
conductor contact, this will be deemed gross negligence. The manufacturer shall not
be held liable for any damage arising from such usage.
- Only operate the charger in accordance with the degree of protection shown on the
rating plate.
- Never operate the charger if there is any evidence of damage.
- Arrange for the mains cable to be checked regularly by a qualified electrician to ensure
the ground conductor is functioning properly.
- Any safety devices and parts that are not functioning properly or are in imperfect con-
dition must be repaired by a qualified technician before switching on the charger.
- Never bypass or disable protection devices.
- After installation, an accessible mains plug is required.
EMC Device Clas-
sifications
Devices in emission class A:
- Are only designed for use in industrial settings
- Can cause line-bound and radiated interference in other areas
Devices in emission class B:
- Satisfy the emissions criteria for residential and industrial areas. This is also true for
residential areas in which the energy is supplied from the public low-voltage mains.
EMC device classification as per the rating plate or technical data.
EMC measures In certain cases, even though a device complies with the standard limit values for emis-
sions, it may affect the application area for which it was designed (e.g. when there is sen-
sitive equipment at the same location, or if the site where the device is installed is close to
either radio or television receivers).
If this is the case, then the operating company is obliged to take appropriate action to rectify
the situation.
Data protection The user is responsible for the safekeeping of any changes made to the factory settings.
The manufacturer accepts no liability for any deleted personal settings.
Maintenance and
repair
Under normal operating conditions, the device requires only a minimum of care and main-
tenance. However, it is vital to observe some important points to ensure it remains in a us-
able condition for many years.
- Before switching on, always check the mains plug and cable as well as charger leads
and charging terminals for any signs of damage.
- If the surface of the device housing is dirty, clean with a soft cloth and solvent-free
cleaning agent only
Maintenance and repair work must only be carried out by authorised personnel. Use only
original replacement and wearing parts (also applies to standard parts). It is impossible to
guarantee that bought-in parts are designed and manufactured to meet the demands made
on them, or that they satisfy safety requirements.

11
EN
Do not carry out any modifications, alterations, etc. to the device without the manufactur-
er's consent.
Obligations of the
operator
The operator must only allow persons to work with the device who:
- are familiar with the fundamental instructions regarding safety at work and accident
prevention and have been instructed in how to use the device
- have read and understood these operating instructions, especially the section "safety
rules", and have confirmed as much with their signatures
- are trained to produce the required results.
Checks must be carried out at regular intervals to ensure that operators are working in a
safety-conscious manner.
Safety inspection The manufacturer recommends that a safety inspection of the device is performed at least
once every 12 months.
A safety inspection should be carried out by a qualified electrician
- After any changes are made
- After any additional parts are installed, or after any conversions
- After repair, care and maintenance has been carried out
- At least every twelve months
For safety inspections, follow the appropriate national and international standards and di-
rectives.
Further details on safety inspections can be obtained from your service centre. They will
provide you, on request, with any documents you may require.
Safety symbols Devices with the CE mark satisfy the essential requirements of the low-voltage and elec-
tromagnetic compatibility directives.
Devices with the EAC mark of conformity satisfy the requirements of the relevant standards
in Russia, Belarus, Kazakhstan, Armenia and Kyrgyzstan.

12
Disposal Do not dispose of this device with normal domestic waste! To comply with the European
Directive on Waste Electrical and Electronic Equipment and its implementation as national
law, electrical equipment that has reached the end of its life must be collected separately
and returned to an approved recycling facility. Any device that you no longer require must
either be returned to your dealer or given to one of the approved collection and recycling
facilities in your area. Ignoring this European Directive may have potentially adverse af-
fects on the environment and your health!
Copyright Copyright of these operating instructions remains with the manufacturer.
The text and illustrations are all technically correct at the time of printing. We reserve the
right to make changes. The contents of the operating instructions shall not provide the ba-
sis for any claims whatsoever on the part of the purchaser. If you have any suggestions for
improvement, or can point out any mistakes that you have found in the instructions, we will
be most grateful for your comments.

13
EN
General information
Device concept The technology is embedded in a robust industry-standard housing. The exceptionally
compact design complies with all safety standards, requires less installation space and
protects the components to ensure a long service life.
Fitted with a graphical display, an integrated datalogger, new interfaces and additional op-
tions, the device is perfectly equipped for the future.
Customer-specif-
ic information
If customer-specific information is available for the supplied device, supply them with the
device.
Correct battery
configuration WARNING!
Danger due to unsuitable batteries being connected to the charger.
Escaping gas, fire or explosion may result in serious injury and damage to property.
► Never connect a battery to the charger unless it is compatible in terms of its type and
voltage and the charger settings are correct.
► The charger must only be used with lithium-ion batteries approved by Fronius.
WARNING!
Danger due to trailing charging leads.
This could result in injury due to getting caught or tripping on loose cables.
► Lay the charging leads so that no one can trip over or become entangled in them.
WARNING!
Danger due to charging plug being pulled out during charging.
This may result in serious injury and damage to property.
► Before pulling out the charging plug, first stop the charging process using the Stop/
Start key.
► Once the charging process is complete, wind up the charging lead or, if available, place
it on the cable holder.
Mains connection WARNING!
Danger from electric current.
This can result in serious injury or death.
► Before starting work, switch off all the devices and components involved and discon-
nect them from the grid.
► Secure all the devices and components involved to prevent unintentional restarting.
► If required, nothing other than a type B residual current circuit breaker should ever be
used for connecting the device to the mains.

14
WARNING!
Danger due to incorrect operation and incorrectly performed work.
This may result in serious injury and damage to property.
► All the work and functions described in this document must only be carried out by
trained and qualified personnel.
► Read and understand this document.
► Read and understand all the Operating Instructions for the system components, espe-
cially the safety rules.
WARNING!
Danger due to faulty or insufficient power supply.
This may result in serious injury and damage to property.
► The power supply requirements detailed in "Technical data" must be met.
Correct arrange-
ment of the
mains/charging
leads
CAUTION!
Danger due to overheating caused by laying the mains/charging leads incorrectly.
Risk of damage to the components.
► Lay mains/charging lead without loops
► Do not cover mains/charging lead

15
EN
Warning notices
on the device
A number of safety symbols can be seen on the charger's rating plate. The safety symbols
must not be removed or painted over.
An electric shock can be fatal. The housing must never be opened by anyone
other than a service technician trained by the manufacturer. The device must be
disconnected from the mains before starting any work with the housing open. A
suitable measuring instrument must be used to ensure that electrically charged
components (e.g. capacitors) are fully discharged. Ensure that the device re-
mains disconnected from the mains until all work has been completed.
Do not use the functions until you have fully read the Operating Instructions.
Possible sources of ignition, such as fire, sparks and naked flames, must be kept
away from the battery.
The charger can cause DC fault currents in the ground conductor. If a fault cur-
rent protection device (RCD) is used on the mains side to protect against electric
shock, it must conform to Type B.
Do not dispose of used devices with domestic waste. Dispose of them according
to the safety rules.
Ser.No.:
Part No.:
U DC nom.
I DC max.
Protective class I
I AC max.
U AC nom.
P AC max.
Fronius International GmbH
Froniusstraße 1
A-4643 Pettenbach
Austria
IP20
xxV
xxxA
xxA
3~ NPE 400V 50/60Hz
xxxxW
Selectiva xxxx Li xxkW
4,010,xxx,876
xxxxxxxx
xxxxxxxx
xxxx
Ladevorgang immer stoppen bevor das Ladekabel abgezogen wird!
Nur mit zugelassener Lithium Ionen Batterie verwenden!
Always stop charging before you disconnect the charging cable!
Use only with approved lithium ion battery!
Toujours arrêter la charge avant de déconnecter le câble de charge!
Utiliser uniquement avec des batteries lithium-ion agréées!
¡Detener siempre la carga antes de desconectar el cable de carga!
¡Utilizar exclusivamente baterías de iones de litio homologadas!
Interrompere sempre la carica prima di scollegare il cavo di carica!
Utilizzare solo con la batteria agli ioni di litio approvata!
Li
WARNUNG - WARNING - ATTENTION
ADVERTENCIA - AVVISO
42,0409,0420

16
Warning notices
inside the device WARNING!
Danger from electric current.
This can result in serious injury or death.
► The housing must never be opened by anyone other than a trained service technician.
► The device must be disconnected from the mains before starting any work with the
housing open.
► A suitable measuring instrument must be used to ensure that electrically charged com-
ponents (e.g. capacitors) are fully discharged.
► Use an easily legible and understandable warning sign to ensure that the device is not
reconnected to the mains supply before all the work has been completed.
Inside the device:
(A) CAN (B) Signal lamps
(2) External start/stop (+) - black (1) 12 V
(3) External start/stop (-) - black (2) GREEN
(5) Detect - white (3) YELLOW
(6) CAN High - green (4) RED
(7) CAN Low - yellow (5) BLUE
(8) CAN GND - brown (6) External start/stop (+)
(7) External start/stop (-)
(2)
black
white
Ext. Start/Stop (-) black
Detect
42,0409,0411
CAN High green
CAN Low yellow
CAN GND brown
(3)
(5)
(6)
(7)
(8)
Ext. Start/Stop (+)
(A)
(B)
WARNING Hazardous Voltage
(4)
(5)
(1)
(2)
(3)
REMOTE
CONTROL Lights
1
2
3
4
12V
GREEN
YELLOW
RED
BLUE
Ext. Start/Stop (+)
Ext. Start/Stop (-)
(6)
(7)
Kondensator Entladezeit < 2 min.
Capacitor discharge time < 2 min.
Décharge de condensateur < 2 min.
Condensador tiempo de descarga < 2 min.
Condensatore tempo di scaricamento < 2 min.

17
EN
Setup regulations WARNING!
Danger from machines falling or toppling over.
This may result in serious injury and damage to property.
► Make sure that all system components are securely in position when setting them up.
► If using a floor bracket or wall bracket, always make sure that all the fastenings are se-
cure.
► Devices weighing more than 25 kg (55.12 lb.) must be carried by at least two people.
► If mounting on shelves, the shelf must be capable of supporting the weight of the de-
vice.
The device is tested to IP20 protection, meaning:
- Protection against penetration by solid foreign bodies with diameters exceeding 12.5
mm (0.49 in.)
- No protection against water
The device can be set up and operated in dry, closed areas that comply with degree of pro-
tection IP20. Exposure to wet conditions should be avoided.
The device may only be operated in a hori-
zontal position.
Cooling air
The charger must be set up in such a way that the cooling air can flow unimpeded through
the vents in the housing that are provided for that purpose. Ensure that there is always a
minimum clearance of 0.2 m (7.874 in.) around the air inlets and outlets. The surrounding
air must be free from
- Excessive dust
- Electrically conductive particles (carbon black or swarf)
- Heat sources
Cooling air is drawn in and flows out as indicated by the arrows in the following illustrations.
NOTE!
Danger due to partially or fully covered air inlets and outlets.
This can result in damage to property.
► If several chargers are set up one behind the other, they should be offset.

18
If the chargers are arranged in a line one behind the other without being offset, the space
between the chargers must be as follows:
a) Selectiva 8 kW: Minimum distance 30 cm (11.81 in)
b) Selectiva 16-18 kW: Minimum distance 60 cm (1 ft. 11.62 in.)
Wall bracket WARNING!
Danger due to work that has been carried out incorrectly and devices falling over.
This may result in serious injury and damage to property.
► This installation must only be carried out by trained and qualified personnel.
► Take note of the safety rules in the charger Operating Instructions.
► Different wall plugs and screws are required depending on the supporting surface.
► Wall plugs and screws are therefore not included in the scope of supply.
► The installer is responsible for selecting the correct wall plugs and screws.
WARNING!
Danger due to objects falling or toppling over.
This may result in serious injury and damage to property.
► Ensure that all screw connections are secure.
► Only use with a Fronius Selectiva 8/-18 kW charger.
► Ensure the device is level when mounting.
1 2
(a)
(b)
1
3
1
2
32
62
62
2

19
EN
633 (24.92)
mm (in.)
13
(.51)
180 (7.09)
193 (7.6)
595,5 (23.44) 179 (7.05)
453 (17.83) 344 (13.54)
109
(4.29)
8 kW
16 kW
392 (15.43)
502 (19.76)
647 (25.47)
267 (10.51)
247 (9.72)
241 (9.49)
585 (23.03)
20
(.79)
110
(4.33)
mm (in.)

20
Drilling template
342 (13.46)
418 (16.46)
494 (19.45)
500 (19.69)
492 (19.37)
450 (17.72)
400 (15.75)
300 (11.81)
200 (7.87)
20 (.79)
8.3
(.79)
6
(.24)
7 (.28)
8.5
(.33)
6(.24)
25
(.98)
76 (2.99)
60
(2.36)
mm (in.) 8 kW / 16 kW
Weight of wall bracket:
8 kW 1.80 kg (3.97 lb)
16 kW 3.15 kg (6.49 lb)
18 kW 4.30 kg (9.48 lb)
18 kW
392 (15.43)
516 (20.31)
mm (in.)
785 (30.91)
500 (19.69)
570 (22.44) 241 (9.49)
646 (25.43)
723 (28.46)
267 (10.51)
247 (9.72
(.79)
20
76
(2.99)
9
(.35)
24
(.94)
124
(4.88)
