BORDEAUX DINING TABLE
F R O N T G A T E

BORDEAUX DINING TABLE
F R O N T G A T E
PART LIST BOX 1: HARDWARE ENCLOSED :
NUMBER OF PEOPLE TO INSTALL :ASSEMBLY TIME
RECOMMENDED 3 PEOPLE OR MORE UNDER 20 MINUTES
PRE ASSEMBLY INSTRUCTIONS :
1. Do not throw away packaging materials until the assembly is complete. Partsmight be
accidentally thrown away.
ASSEMBLY INSTRUCTION: TOOL REQUIRED (INCLUDED):
STEP 1 :
1. Open the table top (A) by unlocking the leaf-lock and pulling the table top open as shown figure 1,in
picture 1.
STEP 2 :
Part # Description QTY Part # Description QTY
A
.
Top
1 pc
C.
Pedestal
1 pc
B.
Extension
Leaf
1 pc
Part # Description QTY
D
.
Wooden Dowels
2 Pcs
Part # Description QTY
E
,F,G
.
4 Set
Picture.
1
Figure1
A
Figure 2
A

BORDEAUX DINING TABLE
F R O N T G A T E
2. Insert wooden dowels (D) into the holes on the pedestal (C).Place the table top (A) to the
pedestal (C), place spring washers (G), followed by flat washers (F) onto the hexagonal bolts
(E), then insert the hexagonal bolts (E,F&G) through the holes of the bridge(A) into the insert
nut in the pedestal (C). Tighten with wrench (H) as shown in fig 4, picture 2.
STEP 3 :
3a. If extension leaf is going to be used, please ensure to unlock the leaf-lock before opening the
table top. Grip both table ends and pull to open.
3b.Insert extension leaf (B) into position, make sure the leaf pins match with the corresponding
holes.
3c.Slide/close both ends simultaneously until leaves are securely in place. Lock the leaf-lock.
Figure
3
Picture.
2
Picture.
3
Figure
5
C
Figure 4

Page 4 of 4
F R O N T G A T E
BORDEAUX DINING TABLE
CARE &MAINTENANCE : Use mild detergent and water to clean. Always use a soft cloth to wipe
down and clean your table. Do not use any abrasive or acidic cleaners as this may mar or
damage the finish. For additional care and cleaning instructions, contact our Product Specialist
teams at 1-800-537-8484.
Please contact one of Our Product Specialists for assembly assistance orquestions at
1-800-537-8484 or email [email protected]. Specialists are available weekdays 8:00 a.m. to
8:00 p.m. EST or Saturday 9:30 a.m. to 6:00 p.m.
