Frontgate 27417 Instruction manual

FRONTGATEFRONTGATE
OUTFITTING AMERICA' S FINEST HOMESTM
ASSEMBLY AND INSTALLATION INSTRUCTIONS
ITEM NO.: 27417 & 27418
BLACK LOG RACK W/STAINLESS STEEL HARDWARE
PARTS LIST:
Part Description Q'ty
(per set)
TOOLS NEEDED: SCREW DRIVER, WRENCH
COMPLETE ASSEMBLED
STEP 1
1. Join feet(1) & legs(2) together.
2. Fix them by nuts (8) bolts(7) & washers(6)
Q'ty
(per set)
Description
Part
1
2
3
4
5
6
7
8
9
10
11
12
13
14
2
2
4
2
12
8
4
4
4
4
4
Metal
Feet
Metal
Leg
Metal
Male Tubing
Metal
Female
Tubing
Metal
Screw
Metal
Washer(A)
Metal
Bolt(1/4"-20T) 12
5
24
Including One
Spare Screw
Metal Nut
(1/4"-20T)
Metal
Bolt(3/8"-16T)
Metal
Washer(B)
Metal Nut
(3/8"-16T)
Metal
Brace
Metal Anchor
Metal
Knob

STEP 2
1. Slide male tubings(3) into female tubings(4)
and fix by screws(5) at
the bottom.
2. Screw in the knobs(14)
to the end of tubings.
CARE AND MAINTENANCE: Wipe with a soft, dry cloth only. Avoid cleaners and abrasives as they may
damage the finish.
Please contact one of our Product Specialists for assembly assistance or questions at 1-800-537-8484
or email [email protected].
Specialists are available weekdays 8:00AM to 8:00AM EST or Saturdays 9:30AM to 6:00PM.
STEP 4
STEP 3
1. Attach braces(12) to tubings & fix by nuts(8).
bolts(7) & washers(6).
1. Attach assembled tubings to the legs and fix
by nuts(11),bolts(10) & washers(9).
2. If necessary,use anchors(13) to affix to deck etc.
