FROST NOVA 2 Install guide

1
Fitting instruction
Montageanleitung
Monteringsvejledning
Monteringsvägledning
Montage hanleiding
Manuel de montage
NOVA2
COAT RACK 1, 2 & 3
N1904-2
N1904-1
COAT RACK 1 COAT RACK 2 COAT RACK 3
N1904-3
2,00 mm
228,00 mm
200,00 mm
50,00 mm
50,00 mm 50,00 mm
50,00 mm
50,00 mm
28,00 mm
40,00 mm
25,00 mm
50,00 mm
50,00 mm
50,00 mm
Ø28,00 mm
40,00 mm
178,00 mm
150,00 mm
2,00 mm
25,00 mm
25,00 25,00 25,00
100,00 mm
116,00 mm
40,00 mm
Ø16,00
25,00 25,00
12,50
2,00 mm
21
N1904-2
150,00 mm
N1904-1
200,00 mm
N1904-3
100,00 mm
O1904-2
O1904-1
O1904-3
Material: Stainless steel, AISI 304
Design: Bønnelycke mdd
Manufacturer: FROST A/S

2x 2x
D7.8 - DB3.5 - L41D6 - H30
AB
2x 1x
CD
M4 - P0.7 - L3 2,5MM
2x 2x
D8.0 - DB4.5 - L50D6 - H30
AB
2x 1x
CD
M5 - P0.8 - L5 2,5MM
2x 2x
D8.0 - DB4.5 - L50D6 - H30
AB
2x 1x
CD
M5 - P0.8 - L5 2,5MM
COAT RACK 1 COAT RACK 2 COAT RACK 3
Cleaning and maintenance
Stainless steel surfaces should be cleaned with
a microbre cloth, glass cleaner or other non
abrasive and gentle agents.
Attention:
Never use solvents or aggressive household
cleaners like bleach, acids (e.g. descalers) or
ammonia-based bathroom cleaner to clean
the product. Steel wool and hard brushes can
permanently damage the surfaceof the steel.
Exclusion of liability
FROST accepts no liability whatsoever for
damage to persons or property that occurs or
has occurred as a result of improper installation
or maintenance, particularly if the safety
instructions and other points to note listed are
not or have not been observed in full.
Warning and hazard notices
Improper mounting or use can lead to
accidents and serious injuries.
