FS NC8200 Series User manual

4-SLOT 2U L3 DATA CENTER SWITCH
CHASSIS AND LINE CARDS
NC8200 Series Switch
V1.0
NC8200-16Q
Status
1F 2F 3F 4F 5F 6F 7F 8F 9F 10F 11F 12F 13F 14F 15F 16F
Status
1F 2F 3F 4F 5F 6F 7F 8F 9F 10F 11F 12F 13F 14F 15F 16F 17F 18F 19F 20F 21F 22F 23F 24F
1 2 3 4
25F
26F
NC8200-24BC
1 2 3 4 1 2 3 4123 4 1 2 3 4
NC8200-8C
1F
2F
3F
4F
5F
6F
7F
8F
Status
Quick Start Guide

NC8200-4TD, NC8200-8C, NC8200-16Q, NC8200-24BC
NC8200-16Q
Status 1F 2F 3F 4F 5F 6F 7F 8F 9F 10F11F12F13F14F15F16FStatus 1F 2F 3F 4F 5F 6F 7F 8F 9F 10F11F12F13F14F15F16F17F18F19F20F21F22F23F24F1 2 3 4
25F
26F
NC8200-24BC
1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4
NC8200-8C
1F
2F
3F
4F
5F
6F
7F
8F
Status
Introduction
Thank you for choosing NC8200-4TD switch chassis and NC8200-8C, NC8200-16Q and NC8200-24BC
line cards. This guide is designed to familiarize you with the layout of the switch and describes how
to deploy the switch in your network.
Accessories
Grounding Cable x1Power Cord x2 Mounting Bracket x2
M4 Screw x18 M6 Screw x8 M6 Nut x8
Inner Rail x2 Slide Rail x2 Blank Plate x4
NOTE: NC8200-8C, NC8200-16Q and NC8200-24BC line cards have dust plugs delivered
with them. Keep the dust plugs properly and use them to protect idle optical ports.

Hardware Overview
Switch Chassis Front Panel
NC8200-4TD
DescriptionParts
Blank PlateInstall a blank panel to the empty slot to prevent dust from entering the switch.
Blank Plate
Back Panel Ports
USB MGMT
CONSOLE USB CONSOLE
AFM-NC4TD-FB Status AFM-NC4TD-FB Status AFM-NC4TD-FB Status MGMT
MGMT
Status
Func
ID
CONSOLE
NC8200-4TD
PWR1
FAN1 FAN2 FAN3
PWR2
Ports Description
USB
CONSOLE
MGMT An Ethernet management port
A USB management port for software and conguration backup and
oine software upgrade
An RJ45 console port for serial management
USB CONSOLE A Mini-USB B serial port for serial management
AFM-NC4TD-FB Status AFM-NC4TD-FB Status AFM-NC4TD-FB Status MGMT
MGMT
Status
Func
ID
CONSOLE
NC8200-4TD
PWR1
FAN1 FAN2 FAN3
PWR2
Back Panel
Fan Slots
ASSET TAG Grounding Point
Dual Power Supplies

AFM-NC4TD-FB Status AFM-NC4TD-FB Status AFM-NC4TD-FB Status MGMT
MGMT
Status
Func
ID
CONSOLE
NC8200-4TD
PWR1
FAN1 FAN2 FAN3
PWR2
Back Panel Button
Button Description
FuncReserved function button
Func
AFM-NC4TD-FB Status AFM-NC4TD-FB Status AFM-NC4TD-FB Status MGMT
MGMT
Status
Func
ID
CONSOLE
NC8200-4TD
PWR1
FAN1 FAN2 FAN3
PWR2
Fan Status MGMT ID
Status
Back Panel LEDs
Power Supply Status
LEDs DescriptionStatus
Status
Solid Red
O
O
Solid Green
Solid Yellow
Blinking Green
1. One of the power supply modules or fan modules fails.
2. Only one fan is in the position.
3. The internaltemperature exceeds the threshold,and the
switching service resets.
The system is powered o.
1. The temperature exceeds the threshold.
2. Only two fans are in the position.
3. One of the dual power supplies is not connected with AC
power cord.
The fan is powered o.
The system is operational.
The systemis initializing.
Fan Status Solid Green
Solid Red
The fan is operational.
The fan fails or stops.

NC8200-16Q
Status 1F 2F 3F 4F 5F 6F 7F 8F 9F 10F11F12F13F14F15F16F
QSFP+
Line Cards Front Panel Ports
NC8200-8C
NC8200-16Q
Ports Description
QSFP+ QSFP+ ports for 40G connection
LEDs DescriptionStatus
O
O
O
Power
Supply Status
Solid Green
There is no power input or the power supplyfails.
Solid Red An error occurs, e.g., overcurrent, overvoltage or fan fault.
Solid Yellow The AC power in redundancy is plugged out.
An alarm is generated but the power module keeps working.
The alarm may be caused by high power, high current, high
temperature, or low fan rotation speed.
Blinking Red
The power inputis normal.
ID
MGMT
Solid Blue
Device location is disabled.
The port is not connected.
Green The port is connected at 1000Mbps.
Yellow The port is connected at 10/100Mbps.
The portis transmitting or receiving data.Blinking
Device location is enabled.
Ports Description
QSFP28QSFP28 ports for 40/100G connection
1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4
NC8200-8C
1F
2F
3F
4F
5F
6F
7F
8F
Status
QSFP28

NC8200-24BC
Ports Description
SFP28SFP28 ports for 10/25G connection
QSFP28QSFP28 ports for 40/100G connection
SFP28
Status 1F 2F 3F 4F 5F 6F 7F 8F 9F 10F11F12F13F14F15F16F17F18F19F20F21F22F23F24F1 2 3 4
25F
26F
NC8200-24BC
QSFP28
NC8200-16Q
Status 1F 2F 3F 4F 5F 6F 7F 8F 9F 10F11F12F13F14F15F16F
1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4
NC8200-8C
1F
2F
3F
4F
5F
6F
7F
8F
Status
Status 1F 2F 3F 4F 5F 6F 7F 8F 9F 10F11F12F13F14F15F16F17F18F19F20F21F22F23F24F1 2 3 4
25F
26F
NC8200-24BC
Status QSFP28
QSFP28
QSFP+Status
SFP28
Front Panel LEDs
NC8200-8C
NC8200-16Q
NC8200-24BC
Status QSFP28

Status
QSFP+
Solid Red
Solid Green
Solid Yellow
Blinking Green
The line card fails or resets.
The temperature exceeds the threshold.
The line card is operational.
Solid Green
Blinking Green
The QSFP+ port is NOTconnected.O
O
The QSFP+ port is transmitting or receiving data at 40G.
The QSFP+ port isconnected at40G.
O
QSFP28
(4*10G/4*25G) Solid Green
Blinking Green
The QSFP28 port is NOTconnected.
The QSFP28 port is transmitting or receiving data at 10/25G.
The QSFP28 portis connected at 10/25G.
The line card is powered o.
The line cardis initializing.
O
QSFP28 Solid Green
Blinking Green
The QSFP28 port is NOTconnected.
The QSFP28 port is transmitting or receiving data at 40/100G.
The QSFP28 portis connected at 40/100G.
NOTE: When the 100G interface of the module is split into four 10G or 25G interfaces, the
four indicators represent the status of the split four ports. Otherwise, only the rst of the
four lights will light up.
SFP28 Solid Green
Blinking Green
The SFP28 port is NOT connected.O
The SFP28 port is connected at 10/25G.
The SFP28 port is transmitting or receiving data at 10/25G.
LEDs DescriptionStatus

Before you begin the installation, make sure that you have the following:
Site Environment:
Do not operate it in an area that exceeds an ambient temperature of 40°C.
Installation Requirements
Phillips screwdriver.
Standard-sized, 19" wide rack with a minimum of 2U height available.
Category 5e or higher RJ45 Ethernet cables, ber optical cables and console cable for connecting
network devices.
Do not install the equipment in a dusty environment.
The installation site must be free from leaking or dripping water, heavy dew, and humidity.
The installation site must be well ventilated. Ensure that there is adequate airow around the
switch.
The switch should be installed at least 2U (88.9mm) away from devices to its sides.
Be sure that the switch is level and stable to avoid any hazardous conditions.
Ensure rack and working platforms are well earthed.

1. Secure the mounting brackets and inner rails to the two sides of the switch chassis with eighteen
M4 screws.
2. Attach the slide rails to the rack using four M6 screws and nuts.
Rack Mounting
Mounting the Switch

3. Align inner rails with the front of the slide rails. Slide the inner rails into the slide rails, keeping the
pressure even on both sides.
4. Attach the switch to the rack using four M6 screws and nuts.

NC8200-16Q
Status
1F 2F 3F 4F 5F 6F 7F 8F 9F 10F 11F 12F 13F 14F 15F 16F
Status
1F 2F 3F 4F 5F 6F 7F 8F 9F 10F 11F 12F 13F 14F 15F 16F 17F 18F 19F 20F 21F 22F 23F 24F
1 2 3 4
25F
26F
NC8200-24BC
1F
2F
3F
4F
5F
6F
7F
8F
1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4
NC8200-8C
Status
1. Take o the blank panel of the line card slot.
2. Pinch the captive screws on line card and rotate the ejector lever outward. Push the line card into
the slot horizontally.
3. Tighten the captive screws with a screwdriver to secure line card in the chassis.
Installing the Line Cards
NOTE: Line cards NC8200-8C, NC8200-16Q and NC8200-24BC are not hot swappable.
Please make sure to power o the switch before installing or removing line cards.

NOTE: 1. Insert the power module steadily. Please pay attention to the direction of the
power panel to avoid wrong insertion. If the position is not proper, pull the power supply
module out slowly and re-insert it.
2. The power supply modules are factory-installed, please take steps above to replace the
modules if necessary.
Replacing the Power Supply Module
2. Take the plane printed with power information as the top panel of the power module. Hold the
handle of the power module with one hand, and support the bottom with the other hand. Horizontally
push the power module into the slot. The power module is completely seated in the slot until a click is
heard.
1. Press and hold the lock of the power module leftward and pull the module out by the handle.
AFM-NC4TD-FB
Status
AFM-NC4TD-FB
Status
AFM-NC4TD-FB
Status
MGMT
MGMT
Status
Func
ID
CONSOLE
NC8200-4TD
PWR1
FAN1 FAN2 FAN3
PWR2
AFM-NC4TD-FB
Status
AFM-NC4TD-FB
Status
AFM-NC4TD-FB
Status
MGMT
MGMT
Status
Func
ID
CONSOLE
NC8200-4TD
PWR1
FAN1 FAN2 FAN3
PWR2

1.Loosen the captive screws of the fan module with a screwdriver.
2. Hold the handle at the end of the fan module, and withdraw the fan module slowly.
Replacing the Fan Module
3. Hold the handle at the end of a new fan module. Insert the fan module to the chassis slowly until it
is fully seated, and make sure that it is in good contact with the slot.
4. Tighten the captive screws with a screwdriver to x the fan module in the switch chassis.
AFM-NC4TD-FB
Status
MGMT
MGMT
Status
Func
ID
CONSOLE
NC8200-4TD
PWR1
FAN3
PWR2
AFM-NC4TD-FB
Status
AFM-NC4TD-FB
Status
AFM-NC4TD-FB
Status
MGMT
MGMT
Status
Func
ID
CONSOLE
NC8200-4TD
PWR1
FAN1 FAN2 FAN3
PWR2
AFM-NC4TD-FB
Status
NOTE: 1. If the screws cannot be tightened, it is probably because the fan module is not
fully inserted. Please check it carefully.
2. The fan modules are factory-installed, please take steps above to replace the modules if
necessary.

Grounding the Switch
Connecting the Power
1. Connect one end of the grounding cable to a proper earth ground, such as the rack in which the
switch is mounted.
2. Secure the grounding lug to the grounding point on the switch back panel with the washers and
screw.
1. Plug the AC power cord into the power port on the back of the switch.
2. Connect the other end of the power cord to an AC power source.
AFM-NC4TD-FB
Status
AFM-NC4TD-FB
Status
AFM-NC4TD-FB
Status
MGMT
MGMT
Status
Func
ID
CONSOLE
NC8200-4TD
PWR1
FAN1 FAN2 FAN3
PWR2
AFM-NC4TD-FB
Status
AFM-NC4TD-FB
Status
AFM-NC4TD-FB
Status
MGMT
MGMT
Status
Func
ID
CONSOLE
NC8200-4TD
PWR1
FAN1 FAN2 FAN3
PWR2
CAUTION: The earth connection must not be removed unless all supply connections have
been disconnected.

First install SFP28 transceivers and then connect ber optic cables to the transceiver ports, or directly
connect DAC cables to the SFP28 slots.
NC8200-16Q
Status
1F 2F 3F 4F 5F 6F 7F 8F 9F 10F 11F 12F 13F 14F 15F 16F
Status
1F 2F 3F 4F 5F 6F 7F 8F 9F 10F 11F 12F 13F 14F 15F 16F 17F 18F 19F 20F 21F 22F 23F 24F
12 3 4
25F
26F
NC8200-24BC
123 4 1 2 341 2 341234
NC8200-8C
1F
2F
3F
4F
5F
6F
7F
8F
Status
Connecting the SFP28 Ports
Connecting the QSFP+ Ports
First install QSFP+ transceivers and then connect ber optic cables to the transceiver ports, or directly
connect DAC cables to the QSFP+ slots.
NC8200-16Q
7F 8F 9F 10F11F12F13F 14F 15F16F
Status
1F 2F 3F 4F 5F 6F 7F 8F 9F 10F11F 12F13F 14F15F 16F 17F 18F19F20F 21F22F23F24F
1 2 3 4
25F
26F
NC8200-24BC
41 2 3 4 1 2 3 4
NC8200-8C
5F
6F
7F
8F
48

NC8200-16Q
Status
1F 2F 3F 4F 5F 6F 7F 8F 9F 10F 11F 12F 13F14F15F16F
Status
1F 2F 3F 4F 5F 6F 7F 8F 9F 10F11F12F13F 14F15F16F17F18F19F 20F 21F22F 23F24F
1 2
25F
26F
NC8200-24BC
1 2 3 4 1 2 3 4 12 3 4 1 2 3 4
NC8200-8C
1F
2F
3F
4F
5F
6F
7F
8F
Status
AFM-NC4TD-FB
Status
AFM-NC4TD-FB
Status
AFM-NC4TD-FB
Status
MGMT
MGMT
Status
Func
ID
CONSOLE
NC8200-4TD
PWR1
FAN2 FAN3
PWR2
Connecting the QSFP28 Ports
Connecting the Console Port
First install QSFP28 transceivers and then connect ber optic cables to the transceiver ports, or
directly connect DAC cables to the QSFP28 slots.
1. Insert the RJ45 connector into the RJ45 CONSOLE port on the rear of the switch.
2. Connect the DB9 female connector of the console cable to the RS-232 serial port on the computer.
WARNING: Laser beams will cause eye damage. Do not look into bores of transceivers or
optical bers without eye protection.

Insert the Universal Serial Bus (USB) ash disk to the USB port for software and conguration backup
and oine software upgrade.
Connecting the MGMT Port
Connecting the USB Port
1. Connect one end of a standard RJ45 Ethernet cable to a computer.
2. Connect the other end of the cable to the MGMT port on the rear of the switch.
AFM-NC4TD-FB
Status
AFM-NC4TD-FB
Status
AFM-NC4TD-FB
Status
MGMT
MGMT
Status
Func
ID
CONSOLE
NC8200-4TD
PWR1
FAN1 FAN2 FAN3
PWR2
AFM-NC4TD-FB
Status
AFM-NC4TD-FB
Status
AFM-NC4TD-FB
Status
MGMT
MGMT
Status
Func
ID
CONSOLE
NC8200-4TD
PWR1
FAN1 FAN2 FAN3
PWR2
USB

Conguring the Switch Using the Console Port
x
Quick Connect
Protocol:
The port may be manually entered or selected from the list.
Serial
Flow Control
DTR/DSR
RTS/CTS
XON/XOFF
Save sessionShow quick connect on startup
Open in a tab
Connect
Cancel
COM3
9600
8
None
1
Port:
Baud rate:
Data bits:
Parity:
Stop bits:
Name of pipe:
Step 1: Connect a computer to the console port of the switch using the console cable.
Step 2: Start the terminal simulation software such as HyperTerminal on the computer.
Step 3: Set the parameters of the HyperTerminal: 9600 bits per second, 8 data bits, no parity, 1 stop
bit and no ow control.
Step 4: After setting the parameters, click Connect to enter.
Troubleshooting
The indicator on the front panel of the host is OFF. The Status indicator of the fan module is OFF, and
the fan does not work. The indicator of the power module is OFF.
Please check the following:
First disconnect the power cord of the power module.
1. Whether the cables of the cabinet have been correctly connected.
2. Whether the cabinet power sockets are loosely connected to power modules.
3. Whether the power modules are installed correctly.
Power System Fault

FS ensures our customers that any damage or faulty items due to our workmanship, we will oer a
free return within 30 Days from the day you receive your goods. This excludes any custom made
items or tailored solutions.
Support and Other Resources
Download
Help Center
Contact Us
https://www.fs.com/download.html
https://www.fs.com/service/help_center.html
https://www.fs.com/contact_us.html
Product Warranty
Warranty: NC8200-4TD switch chassis and NC8200-8C, NC8200-16Q and NC8200-24BC line
cards enjoy 5 years limited warranty against defects in materials or workmanship. For more
details about warranty, please check at
https://www.fs.com/policies/warranty.html
Return: If you want to return item(s), information on how to return can be found at
https://www.fs.com/policies/day_return_policy.html
5
After the system starts, the fan does not work or the Status indicator is OFF.
Please check the following:
Check if the connection between the fan module and the backplane is secure and if the connector
gets loose. If the connection is secure, you need to replace the fan module.
The Fan Does Not Work
1. Check whether serial port cable is connected correctly, whether serial port cable is disconnected,
and whether the connected serial port is identical with that congured on the HyperTerminal.
2. Check that the parameter conguration of the serial port matches that specied in the instructions.
Serial Port Console Has No Output or Outputs Illegible Characters
Copyright © 2020 FS.COM All Rights Reserved.
Q.C. PASSED
