FSR HV-T3 User manual

FSR 244 Bergen Boulevard, Woodland Park, NJ 07424, Phone: [phone] - Fax: [phone]
43045 LIT1468A
HV-T3 INSTALLATION INSTRUCTIONS
SLOTS USED FOR 5/8" TO
1-1/8" THICK TABLE TOPS
SLOTS USED FOR 1-1/8" TO
1-9/16" THICK TABLE TOPS
3.50" DIAMETER
(2) MOUNTING
CLAMP
(2) MOUNTING
SCREW
MOUNTING
CLAMP AND
MOUNTING
SCREW
INSTALLED MOUNTING
CLAMP AND
MOUNTING
SCREW
(SEE BELOW)
HV-T3 ASSEMBLY
TABLE
DRILL 3.50" DIAMETER HOLE IN TABLE TOP.
1.
2. INSERT HV-T3 ASSEMBLY AND ORIENT AS REQUIRED.
3. INSTALL MOUNTING CLAMPS TO ASSEMBLY AND SECURE TO TABLE BY
SCREWING MOUNTING SCREWS TO UNDERSIDE OF TABLE.
MAKE ELECTRICAL CONNECTIONS AS REQUIRED. ENSURE HDMI
CONNECTOR CAN BE PULLED OUT 3'-0".
4. CUSTOMER TO PROVIDE
KO SLUG/PENNY/OTHER
HARD FLAT PIECE FOR
SCREW END, WITH SOFT
TABLE WOOD

HV-T3 Table Box Cable Harness Detail
2 - Green
LED - Green +
3 - Red
LED - Red +
4 - Black & Brown
Ground
Function
Pin #/ Wire Color
1 - Blue
Switch - (N.O.)
1 2 3 4
