Fuji Electric FVR-E11S-7EN User manual

INSTRUCTION MANUAL
Single-phase 200V input FVR-E11S-7EN
Th ee-phase 400V input FVR-E11S-4EN
Low noise high performance inverter
Caution
Thank you for purchasing our FVR-E11S series inverter.
This product is designed to drive a three-phase induction motor. Read through this
instruction manual and be familiar with the handling method for correct use.
Improper handling blocks correct operation or causes a short life or failure.
Have this manual delivered to the final user of the product. Keep this manual in a
safe place until the inverter is discarded.
For the usage of optional equipment, refer to the manuals for optional equipment.
Fuji Electic Co., Ltd. INR-SI47-0627a-E
Fuji Electric FA Europe GmbH, Germany, Tel [phone], 
Fax [phone], [email protected]

i
Int oduction
Safety p ecautions
Read through this manual before starting installation, connection (wiring), operation, or maintenance
and inspection for correct use. Be familiar with the knowledge about the device, information about
safety, and all the precautions before starting operation.
The safety precautions are classified into the following categories in this manual.
！
！！
！WARNING
Negligence of the description can cause dangers including deaths or
serious injuries.
！
！！
！CAUTION Negligence of the description can cause dangers including intermediate or
slight injuries or material losses.
Negligence of the description under the CAUTION title can cause serious results in certain
circumstances. These safety precautions are important and must be observed at any time.
Pu poses
！
！！
！ WARNING
FVR-E11S is designed to drive a three-phase induction motor. Do not use it for single-phase
motors or for other purposes.
Othe wise fi e could occu .
FVR-E11S may not be used for a life-support system or other purposes directly related to the
human safety.
Though FVR-E11S is manufactured under strict quality control, install safety devices for
applications where serious accidents or material losses are foreseen in relation to the failure of it.
Othe wise an accident could occu .
Installation
！
！！
！ WARNING
Install the inverter on a nonflammable material such as metal.
Othe wise fi e could occu .
Do not place flammable matter nearby.
Othe wise fi e could occu .
！
！！
！ CAUTION
Do not hold the cover during transportation.
Othe wise the inve te may d op and cause inju ies.
Do not allow lint, paper, wood chips, dust, metallic chips or other foreign matter in the inverter or do
not allow them attached to the heat sink.
Othe wise fi e o an accident could occu .
Do not install or operate an inverter which is damaged or lacking parts.
Othe wise fi e, an accident o inju ies could occu .
Wi ing
！
！！
！ WARNING
When connecting the inverter to the power supply, add a circuit breaker for circuit protection and
earth leakage breaker in the path of power supply.
Othe wise fi e could occu .
Be sure to connect the grounding cable without fail.
Othe wise elect ic shock o fi e could occu .
Both screws of grounding terminals of FVR5.5/7.5E11S-4EN has to be tightened up securely even
if one grounding terminal is not used.
Othe wise elect ic shock o fi e could occu .
Qualified electricians should carry out wiring.
Othe wise elect ic shock could occu .
Perform wiring after checking that the power supply is turned off.
Othe wise elect ic shock could occu .
Be sure to perform wiring after installing the main body of the inverter.
Othe wise elect ic shock o inju ies could occu .

ii
！
！！
！ CAUTION
Check that the number of phases and the rated voltage of the product agree with the number of
phases and the voltage of the AC power supply.
Othe wise fi e o an accident could occu .
Do not connect the AC power cables to the output terminals (U, V, W).
Othe wise fi e o an accident could occu .
Do not connect a braking resistor directly to the DC terminals (P (+), N (-)).
Othe wise fi e o an accident could occu .
The inverter, motor and wiring generate electric noise. Take care of malfunction of the nearby
sensors and devices.
Othe wise an accident could occu .
Ope ation
！
！！
！ WARNING
Be sure to install the terminal cover before turning the power on. Do not remove the cover during
power application.
Othe wise elect ic shock could occu .
Do not operate switches with wet hands.
Othe wise elect ic shock could occu .
If the retry function has been selected, the inverter may automatically restart according to some
causes after tripping.
(Design the machine so that human safety is ensured after restarting.)
Othe wise an accident could occu .
If the torque limit function has been selected, the inverter may operate at an
acceleration/deceleration time or speed different from the set ones. Design the machine so that
safety is ensured even in such cases.
Othe wise an accident could occu .
The STOP key is only effective when function setting has been established to make the STOP key
enable. Prepare an emergency stop switch separately.
Othe wise an accident could occu .
If an alarm reset is made with the operation signal turned on, a sudden start will occur. Check that
the operation signal is turned off in advance.
Othe wise an accident could occu .
Do not touch the inverter terminals during power applies to the inverter even if the inverter stops.
Othe wise elect ic shock could occu .
！
！！
！ CAUTION
Do not turn the main circuit power on or off to start or stop inverter operation.
Othe wise failu e could occu .
Do not touch the heat sink and braking resistor because they become very hot.
Othe wise bu ns could occu .
Setting the inverter to high speeds is easy. Check the performance of the motor and machines
before changing the setting.
Othe wise inju ies could occu .
The brake function of the inverter does not provide mechanical holding means.
Inju ies could occu .

iii
Maintenance and inspection and pa ts eplacement
！
！！
！ WARNING
Turn the power off and wait for at least five minutes before starting inspection.
(Further, check that the charge lamp is unlit, and check the DC voltage across the P (+) and N (-)
terminals to be lower than 25Vdc.)
Othe wise elect ic shock could occu .
Maintenance and inspection and parts replacement should be made only by qualified persons.
(Take off the watch, rings and other metallic matter before starting work.)
(Use insulated tools.)
Othe wise elect ic shock o inju ies could occu .
Disposal
！
！！
！ CAUTION
Handle the inverter as an industrial waste when disposing of it.
Othe wise inju ies could occu .
Othe s
！
！！
！ WARNING
Never remodel.
Othe wise elect ic shock o inju ies could occu .
GENERAL PRECAUTIONS
Drawings in this manual may be illustrated without covers or safety shields for explanation of detail
parts. Restore the covers and shields in the original state and observe the description in the manual
before starting operation.

iv
Confo mity to Low Voltage Di ective in EU
[Available only fo the p oducts with CE o TÜV ma k]
！
！！
！ CAUTION
1. Safe separation for control interface of this inverter is provided when this inverter is installed
in overvoltage category II. PELV(Protective Extra Low Voltage) circuit or SELV(Safety Extra
Low Voltage) circuit from external controller is connected to the interface directly.
2. Basic insulation for control interface of this inverter is provided when this inverter is installed
in overvoltage category III. An insulation transformer has to be installed between power
supply mains and this inverter when SELV circuit from external controller is connected to this
inverter directly. Otherwise supplementary insulation between control interface of this inverter
and environment must be provided.
3. The ground terminal G should always be connected to the ground. Don't use only RCD as
the sole method of electric shock protection.
Dimensions of external PE conductor should be same as dimensions of input phase
conductor and capable for possible fault.
4. Use MCCB or MC that conforms to EN or IEC standard.
5. Where RCD (Residual-current-operated protective device) is used for protection in case of
direct or indirect contact, only RCD of type B is allowed on the supply side of this EE
(Electric equipment). Otherwise another protective measure shall be applied such as
separation of the EE from the environment by double or reinforced insulation or isolation of
EE and supply system by the transformer.
6. The inverter has to be installed in environment of pollution degree 2. If the environment is
pollution degree 3 or 4, the inverter has to be installed in a cabinet of IP54 or higher.
7. Use a prescribed wire according to the EN60204 Appendix C.
8. Install the inverter, AC or DC reactor, input or output filter in an enclosure that meets the
following requirement, to prevent a human body from touching directly to these equipment.
1) When a person can touch easily on each connecting terminal or live parts, install the
inverter, AC or DC reactor, output filter in an enclosure with minimum degree of
protection of IP4X.
2) When a person can not touch easily on each connecting terminal or live parts, install
the inverter, AC or DC reactor, output filter in an enclosure with a minimum degree of
protection of IP2X.
9. It is necessary to install the inverter in appropriate method using an appropriate RFI filter to
conform to the EMC directive. It is customer's responsibility to check whether the
equipment ,the inverter is installed in, conforms to EMC directive.
10. Do not connect copper wire to grounding terminal directly. Use cramp terminal with tin or
equivalent plating to reduce electrochemical potential.
11. Do not remove the keypad panel before disconnecting power and do not insert/remove the
extension cable for keypad panel remote operation while power is on. Confirm that the
extension cable is securely latched to keypad panel and inverter before power is on.
A supplementary isolation is required for the extension cable when the inverter is installed in
overvoltage category III.
12. Basic insulation for control interface of this inverter is provided when the inverter is used at
altitude over 2000m. The use at altitude over 3000m is not permitted.
13. The supply mains neutral has to be earthed for FVR-E11S-4EN.

v
Caution fo UL/cUL equi ement [Available only fo the p oducts with UL/cUL ma k]
！
！！
！ CAUTION
1. [WARNING] Take care of electric shock. Be sure to turn the inverter off before starting work.
2. [CAUTION] When the charge lamp is lit, the inverter is still charged at a dangerous voltage.
3. [WARNING] There are two or more live parts inside the inverter.
4. The inverter is approved as a part used inside a panel. Install it inside a panel.
5. Perform wiring to the input, output and control terminals of the inverter, referring to the table
below. Use UL certified round crimp terminal to the input and output terminals with insulation
cover or covered with reduced tube to obtain the insulation distance. Use a crimping tool
recommended by the terminal manufacturer when fabricating crimp terminals.
6. Install a fuse or circuit breaker between the power supply and the inverter, referring to the
table below.
1) Use copper wires of allowable maximum temperature 60 or 75 degree C.
2) Use UL certified AC600V "Class J fuse."
7. The inverters FVR0.1 to 2.2E11S-7 are suitable for use on a circuit capable or delivering not
more than 20,000 rms symmetrical amperes, 240V maximum.
8. The inverters FVR0.4 to 7.5E11S-4 are suitable for use on a circuit capable or delivering not
more than the following symmetrical amperes, 480V maximum.
When the fuse is installed : 20,000A
When the circuit breaker is installed : 5000A
9. FVR-E11S-EN is an open type inverter.
10. A class 2 circuit wired with class 1 wire.
Tightening torque
[N·m]
Applicable wire
diameter
[AWG] (mm2) 1)
Inverter type
L1/R,L2/S,
L3/T
L1/L, L2/N
P1,P(+)
DB,N(-)
U, V, W
Control
section
L1/R,L2/S,
L3/T
L1/L, L2/N
G
P1,P(+)
DB,N(-)
U, V, W
Control
section
Fuse 2) [A]
Breaker [A]
FVR0.1E11S-7EN 6 5
FVR0.2E11S-7EN 6 5
FVR0.4E11S-7EN
1.2
10 10
FVR0.75E11S-7EN
14 (2.1)
15 15
FVR1.5E11S-7EN 12 (3.3) 30 30
FVR2.2E11S-7EN
1.8
0.4
10 (5.3)
20
(0.5)
40 40
FVR0.4E11S-4EN
FVR0.75E11S-4EN 6 5
FVR1.5E11S-4EN 10 10
FVR2.2E11S-4EN 15 15
FVR4.0E11S-4EN
1.8 14 (2.1)
20 20
FVR5.5E11S-4EN 12 (3.3) 30 30
FVR7.5E11S-4EN 3.5
0.4
10 (5.3)
20
(0.5)
40 40

Contents
1. Befo e Using the Inve te ･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･1-1
1-1 Receiving Inspection ･･････････････ 1-1
1-2 Appearance of Product ････････････ 1-1
1-3 Handling the Product ･･････････････ 1-3
1-4 Transportation ････････････････････ 1-6
1-5 Storage･･････････････････････････ 1-6
2. Installation and Connection ･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･2-1
2-1 Operating Environment ････････････ 2-1
2-2 Installation Method ････････････････ 2-1
2-3 Connection･･･････････････････････ 2-2
2-3-1 Basic Connection ･･･････････････ 2-2
2-3-2 Connection of Main Circuit and
Grounding Terminal･････････････ 2-4
2-3-3 Connection of Control Terminal ･･･ 2-6
2-3-4 Terminal Layout ････････････････ 2-9
2-3-5 Applicable Devices and
Cable Sizes for Main Circuit ･･････ 2-11
3. Ope ation ･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･3-1
3-1 Inspection and Preparation
Before Operation･･････････････････ 3-1
3-2 Operation Method ･････････････････ 3-1
3-3 Test Operation････････････････････ 3-1
4. Keypad Panel ･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･4-1
4-1 Appearance of Keypad Panel･･･････ 4-1
4-1-1 Upon an Alarm ･････････････････ 4-3
4-1-2 Digital Frequency Setting Method ･4-3
5. Selecting Functions ･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･5-1
5-1 Function Selection List･････････････ 5-1
5-2 Detail Description of Each Function ･5-11
Fundamental Functions (F Functions) ･･･ 5-11
Extension Terminal Functions (E Functions)
･･････････････････････････････ 5-21
Control Functions of Frequency
(C Functions) ････････････････････････ 5-26
Motor Parameters (P Functions) ････････ 5-29
High Performance Functions (H Functions) 5-31
Alternative Motor Parameters (A Functions)
･･････････････････････････････ 5-39
Optional Functions(O Functions)････････ 5-40
6. P otective Ope ation ･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･6-1
6-1 List of Protective Operations････････ 6-1
6-2 Alarm Reset･･････････････････････ 6-2
7. T oubleshooting･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･7-1
7-1 When Protective Function Goes
Active ･･･････････････････････････ 7-1
7-2 When Motor rotates Incorrectly ･･･････ 7-5
8. Maintenance and Inspection ･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･8-1
8-1 Daily Inspection･･･････････････････ 8-1
8-2 Periodic Inspection ････････････････ 8-1
8-3 Measurement of Electrical Amounts
in Main Circuit ････････････････････ 8-4
8-4 Insulation Test ････････････････････ 8-5
8-5 Replacement Parts ････････････････ 8-5
8-6 Inquiries about Product and
Guarantee ･･･････････････････････ 8-5
9. Specifications ･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･9-1
9-1 Standard Specifications ････････････ 9-1
9-2 Common Specifications ････････････ 9-3
9-3 External Dimensions ･･････････････ 9-7
9-4 RS485 Communication ････････････ 9-11
9-4-1 Connector and Communication
Cable ･･････････････････････････9-12
9-4-2 Recommended RS-232C/RS485
Converter ･･････････････････････9-12
9-4-3 Remove/local changeover ････････9-12
9-4-4 Communication Protocol ･････････9-13
9-4-5 Standard Frame･････････････････9-15
9-4-6 Short Frame ････････････････････9-16
9-4-7 Details of Frame ････････････････9-17
9-4-8 Broadcasting ･･･････････････････9-18
9-4-9 Communication Error Code ･･･････9-19
9-4-10 Data Type ･･････････････････････9-19
9-4-11 Function Code List･･･････････････9-20
9-4-12 Data Format ････････････････････9-24
10. Options ･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･10-1
10-1 External Options ･････････････････ 10-1
11. Applicable Reacto ･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･11-1
12. Elect omagnetic compatibility･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･･
･12-1
12-1General ･･････････････････････････ 12-1
12-2 Recommended Installation Instructions
･････････････････････････････････ 12-1

1-1
1. Before Using the Inverter
1-1 Receiving Inspection
Unpack and check the following items.
If you have any problems with the product, contact the dealer or the nearest branch of Fuji lectric Co.,
Ltd.
(1) Check the ratings nameplate to confirm that the delivered product is the ordered one.
TYPE: Type of inverter
FVR 0.4 11S -7 N
Version
Power voltage system:
7: Single-phase 200V class
4: Three-phase 400V class
Series name: 11S
Nominal applicable motor capacity: 0.4: 0.4 kW
Product type
SOURCE: Nu ber of input phases, input voltage, input frequency, input current
OUTPUT: Nu ber of output phases, rated output capacity, rated output voltage, output
frequency range, rated output current, overload current rating
SER. NO.: Product nu ber
0 1 0113R0001
Serial number of production lot
Production month: 1 to 9: January to September; X,
Y, or Z: October, November, or December
Production year: Last digit of year
(2) Check for breakage, missing parts, and dents or other damage on the cover and the main body
given during transportation.
(3) Instruction manual for inverter body is built-in.
1-2 External view of Product
(1-1) Overall view (4.0kW or below)
Keypad panel
Control terminal block cover
Intermediate cover
Ratings nameplate
Main circuit terminal block cover
Keypad panel mounting screw
FVR0.4E11S-7EN
1PH 200-240V 50/60Hz 6.4A
3PH 0.4kW 200-230V 0.2-400Hz 3.0A
150% 1 in
010113R0001
T

1-2
(1-2) Overall view (5.5,7.5kW)
(2-1) View of wiring part(4.0kW or below)
A barrier is provided in the main circuit terminal block cover for the P1, P (+), DB and N (-) cable port.
Cut the barrier using nippers or the like before wiring.
Keypad panel
Control cable port
Terminal block cover
P1, P (+), DB, N
(-) cable port
Intermediate cover
L1/R, L2/S, L3/T
(L1/L, L2/N), U, V, W
cable port
Ratings nameplate
Grounding cable port
Keypad panel mounting screw

1-3
(2-2) View of wiring part(5.5,7.5kW)
A barrier is provided in the cable cover for the P1, P (+), DB and N (-) cable port. Cut the barrier
using nippers or the like before wiring.
1-3 Handling the Product
(1) Removing the control terminal block cover(4.0kW or below)
While lightly pushing the sides of the control terminal block cover at the catches, lift the cover in the
procedure shown in Fig. 1-3-1 to remove it.
Fig. 1-3-1 Removing the control terminal block cover
Control cable port
P1, P (+), DB, N (
-
) cable port
L1/R, L2/S, L3/T cable port
Grounding cable port
U, V, W cable port
Cable cover
Terminal block cover

1-4
(2) Removing the main circuit terminal block cover(4.0kW or below)
While lightly pushing the sides of the main circuit terminal block cover at the catches, slide toward
you in the procedure shown in Fig. 1-3-2 to remove it.
Fig. 1-3-2 Removing the main circuit terminal block cover
(3) Removing the terminal block cover(5.5,7.5kW )
Loose the screws indicated below and while lightly pushing the sides of the terminal block cover at
the catches, lift the cover in the procedure shown in Fig. 1-3-3 to remove it.
①
①①
① ①
①①
①
②
②②
② ②
②②
②
③
③③
③
Fig. 1-3-3 Removing the terminal block cover
screws

1-5
(4) Removing the keypad panel
Loosen the keypad panel mounting screws and remove the keypad panel in the procedure shown in
Fig. 1-3-4. During the procedure, slowly remove the keypad panel right toward the top. If the keypad
panel is handled abruptly, the connector will be broken.
Mounting screw (M3)
Fig. 1-3-4 Removing the keypad panel
Reverse the procedures to mount the terminal block cover and keypad panel.

1-6
1-4 Transportation
Always hold the main unit when carrying the inverter.
If covers or parts are held, the inverter may be broken or it may drop.
1-5 Storage
Store the inverter in an environment described in Table 1-5-1.
Table 1-5-1 Storage environment
Item Specifications
Ambient temperature -10～+50 degree C
Storage temperature (Note 1)
-25～+65 degree C
Relative humidity 5～95%Note 2
Places not subjected to abrupt temperature changes
or condensation or freezing
Atmosphere
The product must not be exposed to dust, direct sunlight, corrosive or
fl
ammable gases, oil mist, vapor, water drops or vibration. There must be
little salt in the atmosphere.
86～106kPa (During storage)
Atmospheric pressure 70～106kPa (During transportation)
Note 1: The storage temperature is for a short time during transportation or the like.
Note 2: ven if the humidity is within the requirements of the specifications, places with abrupt
temperature changes are subject to condensation or freezing. Avoid storing the inverter in
such places.
(1) Do not place the inverter directly on the floor.
(2) If the ambient atmosphere is adverse, wrap the inverter in a vinyl sheet or the like when storing.
(3) If humidity may give an ill effect, add a drying agent (such as silica gel) in the package prepared
as described in item (2).
The long-term storage method of the inverter varies largely according to the environment of the
storage site. General storage methods are described below.
(1) The storage site must satisfy the requirements of specifications for temporary storage.
However, for storage exceeding three months, the upper limit of the ambient temperature shall
not exceed 30 °C. This is for the prevention of deterioration of electrolytic capacitors left turned
off.
(2) The package must be air tight so that moisture will not enter. Add a drying agent inside the
package to contain the relative humidity inside the package within 70%.
(3) The inverter installed on a unit or control panel and left is likely to be exposed to moisture and
dust. If this is the case, remove the inverter and move it to a preferable environment.
(4) lectrolytic capacitors left turned off for an extended period of time deteriorate. Do not store for
one year or more without turning the power on.
To store temporarily
To store for a long time

2-1
2. Installation and Connection
2-1 Operating Environment
Install the inverter in an environment described in Table 2-1-1.
Table 2-1-1 Operating environment
Item Specifications
Site Indoors
Ambient temperature -10 to + 0 degree C
Relative humidity to 9 % (without condensation)
Atmosphere The inverter must not be exposed to dust,
direct sunlight, corrosive gases, oil mist,
vapor or water drops.
There must be little salt.
No condensation occurs due to abrupt
temperature changes.
Altitude 1,000 m max. (Refer to Table 2-1-2 for
altitudes exceeding 1000 m.)
Atmospheric pressure
86 to 106 kPa
3mm 2 to 9 Hz
9.8m/s2 9 to 20 Hz
2m/s2 20 to Hz
Vibration
1m/s2 to 200 Hz
2-2 Installation Method
(1) Tightly mount the inverter in the upright position on a
rigid structure so that the "FVR-E11" characters face
front. Avoid mounting the inverter upside down or
avoid mounting horizontally.
(2) Allow clearances for cooling wind shown in Fig. 2-2-1
to cool down the inverter which generates heat
during operation. The generated heat is radiated
upward. Do not install the inverter below a heat
sensitive device.
(3) The temperature of the heat sink rises to about 90
degrees C during operation of the inverter. Mount the
inverter on a base made of a material withstanding
the temperature rise.
！
！！
！WARNING Install the inverter on a nonflammable material such as
metal.
Other ise fire could occur.
(4) When installing the inverter inside a control panel or the like, take full consideration for
ventilation so that the ambient temperature of the inverter does not exceed the specification
requirements. Do not install the inverter in a poorly ventilated small enclosure.
( ) When storing multiple inverters inside a single unit or inside a control panel, horizontal
installation is recommended to reduce mutual temperature effects. When an vertical layout is
adopted for an unavoidable reason, install a partition plate or the like between inverters to isolate
the heat of the lower inverter.
！
！！
！
CAUTION
Do not allow lint, paper, wood chips, dust, metallic chips or other foreign matter in
the inverter or do not allow them attached to the heat sink.
Other ise fire or an accident could occur.
Fig. 2-2-1
Table 2-1-2 Output attenuation ratio
in relation to altitude
Altitude Output current
attenuation ratio
1000 m or
less
1.00
1000-1 00m 0.97
1 00-2000m 0.9
2000-2 00m 0.91
2 00
-
3000m
0.88
Above
Main body
FVR-E11S
10mm
100mm
Below
Left
10mm
100mm
Right

2-2
2-3 Connection
Remove the control terminal block cover to connect the control terminal block. Remove the main
circuit terminal block cover to connect the main circuit terminal block. Correctly connect cables
taking care of the following precautions.
2-3-1 Basic Connection
(1) Be sure to connect the power cables to main circuit power terminals L1/R, L2/S and L3/T or
L1/L,L2/N of the inverter. If the power cables are connected to other terminals, the inverter will
be broken. As well, check the source voltage for the allowable voltage range specified on the
nameplate and so on.
(2) Connect the grounding terminal without fail according to national or local electric code to prevent
electric shock, fire or other disasters and to reduce electric noise.
(3) Use reliable crimp terminals for connection of cables to the terminals.
(4) After finishing wiring, check the following.
a. Check if the cables are connected correctly.
b. Check if there is no failure of connection.
c. Check if terminals or cables are short circuited or there is a ground fault.
( ) To change connection of an inverter having been turned on
The smoothing capacitor in the direct current part of the main circuit takes time to be discharged
after it is turned off. To avoid danger, check the DC voltage (across main circuit terminals P (+)
and N (-)) for a safety voltage (2 Vdc or lower) using a multi-meter, after the charge lamp is unlit.
Wait until the residual voltage is discharged before shorting a circuit, to avoid being hit by sparks
caused by the voltage (electric charge).
！
！！
！WARNING
• Be sure to connect the grounding cable without fail.
Other ise electric shock or fire could occur.
• Qualified electricians should carry out wiring.
Other ise electric shock could occur.
• Perform wiring after checking that the power supply is turned off.
Other ise electric shock could occur.

2-3
■
■■
■ Basic connection diagram
U
L2/N
L1/L
Po er supply (*1)
Single-phase
200 to 240 V
50/60 Hz
Molded case
circuit breaker
(MCCB) or earth
leakage circuit
breaker (ELCB)
Po er supply (*1)
Three-phase
380 to 480 V
50/60 Hz
G
EFL-E11-7
FWD
REV
X1
X2
X3
X4
X
CM
13
12
11
C1
FM
V
W
P1 P(+) DB N(-)
M
<Y1E>
<Y2E>
<CMC>
G
Motor
Grounding
terminal
SR
10Vdc
(-)
(+)
22～27Vdc
Pulse output
Control circuit part
Analog frequency meter
0 to 0Hz
FM(*2)
Current input
for setting
4 to 20mAdc
A voltage signal (0 to +10 Vdc
or 0 to + Vdc) can be supplied
to terminals [12] and [11]
instead of a potentiometer.
Potentiometer (*2)
DC reactor
DCR (*2)
External braking resistor (*2)
(*4)
P
DB
2
1
Transistor output
Digital input (*2)
Analog
input
Alarm relay output
30
30A
30B
30C
3
2
1
Grounding
terminal
(P24)
(THR)
(*3)
Digital
frequency meter
(pulse counter)
(*2)
0Hz
22kohm
FM
Analog output
2 0ohm
To change the FM terminal to
pulse outputs, change SW1 on
the control board and change
F29.
(P24) (THR)
(When X assigned to THR)
3
P24
L1/R
L3/T
L2/S
L
N
L'
N'
EFL-E11-4
G
L1'
L2'
L3'
0V
L1
L2
L3
(*3)
Electric cabinet
Armoured
or
screened
cable
EMC compliance filter (*2)
EMC compliance filter (*2)
CM
FVR-E11S-EN
CM
CM
SW1
*1) Supply a source voltage
suitable for the rated
voltage of the inverter.
*2) Optional part. Use when
necessary.
*3) Peripheral equipment.
Use when necessary.
*4) To connect a DC reactor
(DCR) for power factor
correcting, remove the
jumper between the P1
and P (+) terminals.

2-4
2-3-2 Connection of Main Circuit and Grounding Terminal
Table2-3-1 Connection of Main Circuit and Grounding Terminal
Symbol Name of terminal Description
L1/R,L2/S,L3/T Main circuit power
input
Connects a 3-phase power supply.
L1/L,L2/N Main circuit power
input
Connects a 1-phase power supply.
U,V,W Inverter output Connects a 3-phase induction motor.
P1,P(+) For DC reactor Connects an optional DC reactor.
P(+),DB For external braking
resistor
Connects an optional external braking resistor.
P(+),N(-) DC link circuit terminal Connected to DC link circuit.
G grounding Grounding terminal of the inverter chassis (housing).
Connect to the protective ground.
(1) Main circuit power input terminal (L1/R, L2/S, L3/T,L1/L,L2/N)
a. Connect the main circuit power input terminals to the power supply through a circuit breaker
for circuit (wiring) protection or an earth leakage breaker. There is not need to match the
phase sequence.
b. It is recommended to connect a magnetic contactor to disconnect the inverter from the power
supply to prevent a failure or accident from becoming serious upon activation of the
protective function of the inverter.
c. Do not turn the main circuit power supply on or off to start or stop the inverter. Instead, use
control circuit terminals FWD and REV or the RUN and STOP keys on the keypad panel. If it
is unavoidable to turn the main circuit power supply on or off to start or stop the inverter, limit
the frequency to once an hour or fewer.
d. Do not connect to a single-phase power supply for 3-phase input inverter.
(2) Inverter output terminals (U, V, W)
a. Connect these terminals to a 3-phase motor with the correct phase sequence. If the direction
of rotation does not match the operation direction, change arbitrary two cables among the U,
V and W phases.
b. Do not connect a phase advance capacitor or surge absorber to the inverter output.
c. If the wiring length between the inverter and the motor is extremely long, the stray capacity
between cables causes a high frequency current, possibly tripping the inverter due to an
overcurrent, increasing the leakage current, or deteriorating the current detection accuracy to
cause deterioration of the performance or other phenomena. To prevent such trouble, limit
the wiring length of the motor to 0 m for 4.0 kW or a smaller output or to 100 m for a larger
output.
Note: When a thermal relay is installed in the path between the inverter and the motor, or especially
in the case of a 400V system, the thermal relay may malfunction even with a wiring length
shorter than 0 m. In such a case, add an OFL filter or lower the Motor sound adjustment
(carrier frequency) of the inverter. ... Function code F26 Motor sound adjustment.

2-
(3) DC reactor connecting terminals (P1, P (+))
a. Use this terminal to connect a DC reactor (option).
Remove the jumper connected in the factory before
connecting the DC reactor.
b. Do not remove the jumper if no DC reactor is used.
Cut the barrier in the main circuit terminal block cover
for the P1, P (+), DB and N (-) cable port using nippers
or the like when connecting wiring.
(4) External braking resistor connecting terminals (P (+), DB)
E11S is not equipped with a braking resistor. An external
braking resistor (option) is necessary for frequent
operation or heavy duty inertia load operation to
enhance the braking performance.
a. Connect the P (+) and DB terminals of the
external braking resistor to the P (+) and DB
terminals of the inverter.
b. Arrange devices so that the wiring length is within
m and twist or closely (in parallel) place the two
cables.
( ) Inverter grounding terminal ( G )
Ground the grounding terminal G for safety and noise reduction without fail. The metallic frame
of electrical equipment must be grounded in accordance with national or local electric code to
avoid electric shock, fire and other disasters.
！
！！
！
CAUTION
• Check that the number of phases and the rated voltage of the product agrees with
the number of phases and the voltage of the AC power supply.
• Do not connect the AC power cables to the output terminals (U, V, W).
Other ise injuries could occur.
• Do not connect a braking resistor directly to the DC terminals (P (+), N (-)).
Other ise fire could occur.
P1 P(+) DB N(-)
DC reactor
DCR
External braking resistor DB
P DB
2
1
(P24)
(THR)
Fig. 2-3-2 Connection diagram
Fig. 2-3-1 DCR connection diagram

2-6
2-3-3 Connection of Control Terminal
Table 2-3-2 shows the functions of the control circuit terminals. The method of connecting control
function terminals varies according to the function setting. Refer to the connection method for the
function.
Table 2-3-2 Functions of control circuit terminals
Classifica-
tion
Terminal
symbol
Terminal name Description of function
13 Potentiometer power
supply
+10 Vdc power supply for frequency setting POT.
(POT: 1 to kohm).
12 Voltage input (1) The frequency is set according to the external analog
input voltage command.
• 0 to +10 Vdc / 0 to 100%
• Reversible operation using +/- signal: 0 to +/-10 Vdc / 0
to 100%
• Inverse mode operation: +10 to 0 Vdc / 0 to 100%
(2) The PID control feedback signal is input.
* Input resistance: 22 kohm
C1 Current input (1) The frequency is set according to the analog input
current command.
• 4 to 20 mAdc / 0 to 100%
• Inverse mode operation: 20 to 4 mAdc / 0 to 100%
(2) The PID control feedback signal is input.
* Input resistance 2 0 ohm
Analog
input
11 Common Common for analog signals
FWD Forward operation
command
Forward operation with FWD-P24 ON and deceleration
and stop with FWD-P24 OFF.
REV Reverse operation
command
Reverse operation with REV-P24 ON and
deceleration-stop with REV-P24 OFF.
X1 Digital input 1
X2 Digital input 2
X3 Digital input 3
X4 Digital input 4
X Digital input
A coast-to-stop command from an external device,
external alarm, alarm reset, multi-step frequency selection
and other functions can be assigned to the X1 through X
terminals. Refer to the terminal function E01 to 0 setting
method in section -2 Detail Description of Each
Function.
<Digital input circuit specification>
P24 Control unit
power supply
+24V DC power supply for control input.
Maximum output current : 0mA
Digital
input
CM Common Common for digital input
FWD,REV,
X1 to X
CM
4.7kohm
P24
+24
V
Item min.
typ. Max.
Level OFF 0V - 2V Operation
voltage Level ON 22V
24V 27V
Operation current at ON - 4.2mA
6mA
Allowable leakage current at
OFF
- - 0. mA

2-7
Classifica-
tion Terminal
symbol
Terminal name Description of function
Analog monitor The monitor signal for analog DC voltage (0 to +10 Vdc) is
output. The signal description can be selected from the
following.
• Output frequency1 (before slip compensation)
• Output frequency2 (after slip compensation)
• Output current • Output voltage
• Output torque • Load factor
• Input power • PID feedback value
• DC link circuit voltage
* Allowable connection impedance: min. k ohm
Analog
output /
pulse
output
FM (11:
Common
terminal)
Pulse rate monitor The monitor signal is output according to the pulse voltage.
The signal description is the same as the FMA signal.
* Allowable connection impedance: min. k ohm
Use SW1 on the control board and function code F29 to
change between the analog monitor and Pulse rate monitor.
(FMA: analog monitor, FMP: Pulse rate monitor)
Y1E Transistor output 1
Y2E Transistor output 2
The RUN signal, frequency equivalence signal, overload
early warning signal and other signals are output to arbitrary
ports at a transistor output. Refer to terminal function E20 to
21 setting methods in section -2 Detail Description of Each
Function.
<Transistor output circuit specification>
CMC Common
(Transistor output)
Common for transistor output signal. Isolated from terminals
CM and 11.
Transistor
output
P24
(CM:
common
terminal)
DC voltage supply
Power supply for transistor output load. (24 Vdc 0 mAdc
Max.) (When using P24, short the CMC and P24 terminals.) (If
the P24 terminal is overloaded or connected with the CM
terminal, the inverter trips with
Er3 indication. To reset,
remove external causes and, after several minutes, turn the
inverter on again.)
Relay
output
30A,30
B,30C
Alarm relay output When the inverter is stopped with an alarm, a relay contact
output (1C) is issued.
Contact capacity: 48 Vdc 0. A
(When complying with UL/cUL:42Vdc 0. A)
Selection between excitation upon an alarm or excitation
during normal operation is allowed.
Item min. typ. max.
ON level - 1V 2V
Operation
voltage *1 OFF level - 24V
27V
Maximum load current at ON - - 0mA
Leakage current at OFF - - 0.1mA
Current
Operation
Voltage
