Fuji Xerox DocuPrint M355df User manual

DocuPrint M355df
Service Manual 1st Edition

•This service manual covers the following models.
FUJI XEROX Co. Ltd.
• DocuPrint M355df
•Related Materials
• No other related materials issued other than
this service manual.
•Confidentiality
• This service manual is issued intending use by
maintenance service personnel authorized by FUJI
XEROX Co. Ltd.
Copying, transferring or leasing
this manual without prior consent by FUJI
XEROX Co. Ltd. is prohibited.
• When a page becomes irrelavant (e.g.
superceded by a replacement page), destroy
the page by burning or shredding it.
• Handle with care to avoid loss or damage of the
manual.
•Revision and Modification Information
When design changes or revisions relating to this
service manual occur, the overseas technical
information or overseas service bulletin may be
issued as supplementary information until such
changes are accomodated in the updated version
of this service manual.
Edited by: Fuji Xerox Co., Ltd. CS TSD
Minatomirai Center Bldg. 7F
3-6-1, Minato-mirai, Nishi-ku, Yokohama-shi, Kanagawa, JAPAN 220-0012
[XEROX] is registered trademarks.
DocuPrint M355df
Service Manual 1st Edition Issued: July 2012
Important changes including revi-
sions of spare part numbers and ad-
justment specifications must
immediately be reflected on the re-
spective pages of this service manu-
al upon reception of such
information.

Company Name
Department Name
Telephone No.
Full Name Employee No.

Introduction
Getting to know the Service Manual
How to use the Service Manual
Terms and Symbols
Abbreviations
Chapter 1 Service Call Procedure
Chapter 2 Troubleshooting
Chapter 3 Image Quality Troubleshooting
Chapter 4 Disassembly/Assembly and Adjustment
Chapter 5 Parts List
Chapter 6 General
Chapter 7 Wiring Data
Chapter 8 Accessories(not yet issued)
Chapter 9 Installation / Removal (not yet issued)
Chapter 10 Mechanism & Functions Overview

Preface

Preface
Table of Contents
Table of Contents
1 Getting to Know the Service Manual.............................................................. Preface-1
2 How to Use the Service Manual..................................................................... Preface-1
2.1 Contents of Manual ......................................................................................................Preface-1
2.2 Information on Updating ...............................................................................................Preface-2
3 Terms and Symbols....................................................................................... Preface-3
4 Abbreviations................................................................................................. Preface-4

Introduction
1. Getting to Know the Service Manual
Preface-1
1. Getting to Know the Service Manual
This manual is used as the standard service manual for the DocuPrint M355df.
• Publication Comment Sheet
Enter any comments and/or corrections regarding the DocuPrint M355df service manual into the
Publication Comment Sheet, and send it to FX/TS PSC OSG via OpCo Technical Service
Department
2. How to Use the Service Manual
This manual describes the standard procedures for the servicing of the product. Refer to Chapter 1
Service Call Procedure for efficient and effective servicing during maintenance calls.
2.1 Contents of Manual
• Hardware
This manual summarizes all technical information on the product.
• Chapters
This manual is divided into ten chapters as described below.
Chapter 1 Service Call Procedure
This chapter describes the general work and servicing procedures for the maintenance of the
product.
Chapter 2 Troubleshooting
This chapter describes the troubleshooting procedures other than image quality
troubleshooting of the product. It also describes how to use the diagnostics and some
programs.
Chapter 3 Image Quality Troubleshooting
This chapter describes the image quality troubleshooting procedures of the product.
Chapter 4 Disassembly/Assembly and Adjustment
This chapter describes the disassembly, assembly, adjustment and replacement procedures
for the components of the product.
Chapter 5 Parts List
This chapter contains the spare parts list for the product.
Chapter 6 General
This chapter contains the specification, service modes, and service data of the product.
Chapter 7 Wiring Data
This chapter contains the information about the Wiring Connector List/Locations and the
Wiring Data for the product.
Chapter 8 Accessories (not yet issued)
This chapter contains the information on related products.
Chapter 9 Installation / Removal (not yet issued)
This chapter contains the installation and removal procedures and product-specific options.
Chapter 10 Mechanism & Functions Overview
This chapter gives an overview of the functions of the main components of the product.

Introduction
2. How to Use the Service Manual
Preface-2
2.2 Information on Updating
This manual will be revised and sent to each Service Center as specified below. Revisions must be
incorporated correctly to keep the manual up-to-date.
Updating Procedure
• When the entire manual is revised, "1st Edition" on the front cover will be renewed to 1st Edition,
2nd Edition, 3rd Edition and so on.
• When this manual is partially revised, revisions will be sequentially indicated as Revision A,
Revision B, Revision C, etc. All revised pages will be marked accordingly with "Revision A",
"Revision B", "Revision C" and so on.
Revision Sidebar
When any paragraph, table or figure has been added or amended, a revision sidebar will be
added to indicate where the revision was made.
(Example)
If the same page is changed again due to a subsequent revision, revision sidebars associated
with the previous revision(s) will be deleted.

Introduction
3. Terms and Symbols
Preface-3
3. Terms and Symbols
This section describes the terms and symbols used throughout this manual.
The terms and symbols used at the beginning of a text are defined as follows:
• REP : Indicates the disassembly/assembly procedure for reference.
• ADJ : Indicates the adjustment procedure for reference.
• PL : Indicates the parts list for reference.
• ASSY : Means Assembly.
Safety Critical Components (SCC)
Control of the safety of components that are designated Safety Critical Components shall conform
to Fuji Xerox Co. Ltd-stipulated rules and regulations on Safety Critical Components.
As to replacement of any component designated SCC, the complete component unit must be
replaced. It must never be disassembled or no individual internal parts of it must be replaced.
Installation of any part other than the ones designated by Fuji Xerox Co. Ltd. shall be strictly
prohibited because it cannot be guaranteed in quality and safety.
Important Information Stored Component (ISC)
Important Information Stored Components store customers’ important information they have
entered after machine installation. When replacing Important Information Stored Components, you
must replace and discard them, following the procedure described in Chapter 4 Adjustments. Take
care never to let customer information leak out.
Indicates an imminently hazardous situation, such as death or serious injury if
operators do not handle the machine correctly by disregarding the statement.
DANGER
Indicates a potentially hazardous situation, such as death or serious injury if
operators do not handle the machine correctly by disregarding the statement.
Indicates a potentially hazardous situation, such as injury or property damage
if operators do not handle the machine correctly by disregarding the statement.
Used to emphasize the procedure, servicing, and regulation.
NOTE

Introduction
4. Abbreviations
Preface-4
4. Abbreviations
This manual contains abbreviations that are specific to this manual, as well as general
abbreviations, which include:
ADC Automatic Density Control
AG Analog Ground
APS Auto Paper Select
ARC Auto Registration Control
ASSY Assembly
ATS Auto Tray Switching
BBlack
BCR Bias Charge Roll
Bk Black
BLK Black
BLU Blue
BRN Brown
BTR Bias Transfer Roll
C Cyan
CLN Cleaner
CRU Customer Replaceable Unit
CRUM CRU Monitor
CTRG Cartridge
DET Detoner Roll
DEVE. Developer
DIAG. Diagnostic
DISP Dispense
dpi dots per inch
DTS Detack Saw
DUP Duplex
ESB Electro Static Brush
ESS Electric Subsystem
FFront
FEED, FDR Feeder
FIP Fault Isolation Procedure
GND Ground
GRN Green
GRY Gray
HT Half Tone
HUM Humidity
HVPS High Voltage Power Supply
ICDC ImageCountDispenseControl
ID Image Density, or
Identification
IBT Intermediate Belt Transfer
INTL, INLK Interlock
IOT Image Output Terminal
KBlack
LLeft
L/H Left Hand
LD Laser diode
LDD Lightly Doped Drain
LED Light-emitting diode
LEF Long Edge Feed
LH Left Hand
LV Low Voltage
LVPS Low Voltage Power Supply
M Magenta
MAG Mag. Roll
MCU Machine Control Unit
MOB Marks On Belt
MOT Motor
MSI Multi Sheet Inserter
N/P No Paper
NVM Non Volatile Memory
OEM Original Equipment
Manufacuring
OHP Overhead Project
OP Operation
OPC Organic Photo Conductor
ORN ORANGE
PC Personal Computer
PCDC Pixel Count Dispense Control
PH Paper Handling
PHD Printer Head
PNK Pink
POP Paper On Photoreceptor
PPM Prints Per Minute
PR,P/R Process
PV Print Volume
PWB(A) Printed Wiring Boad
(Assembly)
R Right
RRear
R/H Right Hand
REF Refresher
REGI. Registration
RH Right Hand
ROS Raster Output Scanner
ROT Rotary
RTC Rubber Tube Charger
RTN Return
SEF Short Edge Feed
SG Signal Ground
SMH Special Material Handler
SNR Sensor
SOL. Solenoid
SOS Start Of Scan
STM Single Tray Module
SW Switch
TEMP. Temperature
TM Tray Module
TNER, TNR Toner
TP Thermopile
TR Transfer
VIO Violet
WHT White
XERO Xerographic
Y Yellow
YEL Yellow

Chapter 1 Service Call Procedure

CONTENTS
1.1 Before Starting the Servicing......................................................................................1-1
1.1.1 Safety..............................................................................................................................................1-1
1.1.2 Notes on the Handling of Customer Information.............................................................................1-4
1.1.3 Other Things to Note.......................................................................................................................1-5
1.2 Servicing Call Procedure............................................................................................1-6
1.2.1 Initial Actions...................................................................................................................................1-6
1.2.2 UM Call ...........................................................................................................................................1-6
1.2.3 SM Call ...........................................................................................................................................1-6
1.2.4 Final Actions ...................................................................................................................................1-6
1.3 Servicing Call Details..................................................................................................1-7
1.3.1 Initial Actions...................................................................................................................................1-7
1.3.2 Checking Repeatability ...................................................................................................................1-7
1.3.3 Checking Copy Quality ...................................................................................................................1-7
1.3.4 Trim Servicing.................................................................................................................................1-7
1.4 TRIM Check List.........................................................................................................1-8
1.5 Periodic Replacement Parts.....................................................................................1-11

Chapter 1 Service Call Procedure
1.1 Before Starting the Servicing
1-1
1.1 Before Starting the Servicing
1.1.1 Safety
To prevent any accident that may occur during maintenance servicing, any WARNING or CAUTION regarding
the servicing must be strictly observed. Do not perform any hazardous operation.
1Power Supply
To prevent accidents such as electrical shocks, burns, and injury,besuretoswitchOFFthemachine
and disconnect the plug before starting the maintenance servicing. Ifthemachinehastobeswitched
ON, such as when measuring the voltage, take extra care to prevent an electrical shock.
2Drive Area
Never inspect or lubricate the drive area such as the chain belts, sprockets, and gears while the
machine is in operation.
3Heavy Parts
The weight of the machine is 18.1 kg (the main unit with consumables). When moving the machine to
ensure sufficient working space, take extra care to prevent back pain.
When moving it, always carry it by a team of two or more persons to avoid mishandling or injury. When lift-
ing this machine, use the handholds on both sides of the machine with two people.
4Safety Device
See that safety devices for preventing mechanical accidents, such as fuses, circuit breakers, and inter-
lock switches and those for protecting customers from injury, such as panels and covers, function prop-
erly. Modifications that hinder the function of any safety devices are strictly prohibited.

Chapter 1 Service Call Procedure
1.1 Before Starting the Servicing
1-2
5Installing and Removing Parts
Since the edge of parts and covers may be sharp, take care not to touch them. If the oil gets onto your
hand, wipe it off before getting on with the servicing. When pulling out parts or cables, do not yank but
pull gently and gradually.
Do not replace the lithium battery(Lithium metal battery) mounted on the ESS PWB alone.
NOTE
If the terminals of the lithium battery(Lithium metal battery) come in contact with other metal parts, leading
to short circuit, the battery may overheat, burst, or ignite. If the battery alone needs to be collected, the ter-
minals must be covered with adhesive insulation tape or by other means. When collecting the PWB or other
part with the lithium battery(Lithium metal battery) installed, carry the entire part in the packaging materials
(bag/box) for it.
6Specified Tools
Use the tools for the servicing procedure if any are specified.
7Cleaning the Toner and Developer
As the toner may cause a dust explosion, sweep the spilt toner into a waste container.
When using a cleaner to clean the remaining toner, be sure to use the FX standard toner-proof cleaner
and not a customer's cleaner.
Also, as the developer also contains toner, exercise the same caution during cleaning.
8Organic Solvents
When using an organic solvent such as the Drum Cleaner or Machine Cleaner, pay attention to the fol-
lowing:
zEnsure good ventilation in the room to prevent too much intake of the solvent.
zDo not use heated solvent.
zKeep away from fire.
Never throw, use, or store Drum Cleaner or Machine Cleaner in and around fire. Doing so may cause fire
due to flammability. Before disposing of a container of Drum Cleaner or Machine Cleaner, make sure that it
is completely depleted.
9Modifications
If any modifications are deemed necessary for the printer, submit an Application for Approval of Modifi-
cation prior to performing any work.

Chapter 1 Service Call Procedure
1.1 Before Starting the Servicing
1-3
10 Harmful Laser
The customer or service personnel would not be exposed to any harmful laser during the usual copying
or scanning of documents. If your customer feels dazzled by the exposure lamp during normal opera-
tions of copying and scanning via the document glass, it is possible to shield light leakage by covering
the document glass except for the area used most commonly for copying and scanning.
11 Lithium battery
Lithium battery is used in the following component.
zPWBA ESS (PL18.1.2)
If not replaced properly , the battery can explode. Dispose of the old battery according to the instructions.
12 Other Safety Precautions
For safety, you should also pay attention to precautions other than the items 1 through 10 above. Fol-
low the instruction below to ensure greater safety during servicing.
zSafe Working Practices for Engineers issued by TS PSC OSG and APO RTS
