Fujitsu ASBG09KMBA Service manual

AIR CONDITIONER
Wall mounted type
DESIGN & TECHNICAL MANUAL
INDOOR
ASBG09KMBA
ASBG12KMBA
OUTDOOR
AOBG09KMCA
AOBG12KMCA
DR_AS180EF_01
2023.01.20

Notices:
• Product specifications and design are subject to change without notice for future improvement.
• For further details, please check with our authorized dealer.
Trademarks
“AIRSTAGE Mobile” is a trademark of FUJITSU GENERAL LIMITED.
Google Play™ is trademark of Google LLC.
App Store® is a service mark of Apple Inc., registered in the U.S. and other countries.
Copyright © 2023 Fujitsu General Limited. All rights reserved.

CONTENTS
Part 1. INDOOR UNIT...........................................................................1
1. Specifications................................................................................................2
2. Dimensions....................................................................................................3
2-1. Models: ASBG09KMBA and ASBG12KMBA ...................................................................3
3. Wiring diagrams ............................................................................................5
3-1. Models: ASBG09KMBA and ASBG12KMBA ...................................................................5
4. Capacity table................................................................................................6
4-1. Cooling capacity...............................................................................................................6
4-2. Heating capacity ..............................................................................................................7
5. Fan performance ...........................................................................................8
5-1. Air velocity distributions....................................................................................................8
5-2. Airflow ............................................................................................................................10
6. Operation noise (sound pressure).............................................................12
6-1. Noise level curve............................................................................................................12
6-2. Sound level check point .................................................................................................13
7. Safety devices .............................................................................................14
8. External input and output...........................................................................15
8-1. External input.................................................................................................................15
8-2. External output...............................................................................................................17
9. Group connection .......................................................................................19
9-1. Precautions on creating a group connection..................................................................19
9-2. Remote controller address setting procedure for wireless remote controllers................20
10. Remote controller .......................................................................................21
10-1.Wireless remote controller ............................................................................................21
11. Function settings .......................................................................................23
11-1.Function settings by using remote controller.................................................................23
11-2.Custom code setting for wireless remote controller.......................................................27
12. Accessories.................................................................................................28
12-1.Models: ASBG09KMBA and ASBG12KMBA ................................................................28
13. Optional parts .............................................................................................29
13-1.Controllers ....................................................................................................................29
13-2.Others ...........................................................................................................................30

Part 2. OUTDOOR UNIT.....................................................................31
1. Specifications..............................................................................................32
2. Dimensions..................................................................................................33
2-1. Models: AOBG09KMCA and AOBG12KMCA ................................................................33
3. Installation space ........................................................................................34
3-1. Models: AOBG09KMCA and AOBG12KMCA ................................................................34
4. Refrigerant circuit .......................................................................................37
4-1. Models: AOBG09KMCA and AOBG12KMCA ................................................................37
5. Wiring diagrams ..........................................................................................38
5-1. Models: AOBG09KMCA and AOBG12KMCA ................................................................38
6. Capacity compensation rate for pipe length and height difference........39
6-1. Model: AOBG09KMCA ..................................................................................................39
6-2. Model: AOBG12KMCA ..................................................................................................40
7. Additional charge calculation ....................................................................41
7-1. Model: AOBG09KMCA ..................................................................................................41
7-2. Model: AOBG12KMCA ..................................................................................................41
8. Airflow..........................................................................................................42
8-1. AOBG09KMCA ..............................................................................................................42
8-2. AOBG12KMCA ..............................................................................................................42
9. Operation noise (sound pressure).............................................................43
9-1. Noise level curve............................................................................................................43
9-2. Sound level check point .................................................................................................44
10. Electrical characteristics............................................................................45
11. Safety devices .............................................................................................46
12. Accessories.................................................................................................47
12-1.Models: AOBG09KMCA and AOBG12KMCA ...............................................................47
CONTENTS (continued)

Part 1. INDOOR UNIT
WALL MOUNTED TYPE:
ASBG09KMBA
ASBG12KMBA

1. Specifications
Type
Wall mounted
Inverter, Heat pump
Model name ASBG09KMBA ASBG12KMBA
Power supply 220 V~ 60 Hz
Power supply intake Outdoor unit
Available voltage range 198—242 V
Capacity
Cooling
Rated kW 2.64 3.52
Btu/h 9,000 12,000
Min.—Max. kW 0.5—3.2 0.9—3.8
Btu/h 1,700—10,900 3,100—13,000
Heating
Rated kW 2.64 3.52
Btu/h 9,000 12,000
Min.—Max. kW 0.5—3.2 0.9—3.8
Btu/h 1,700—10,900 3,100—13,000
Input power
Cooling Rated
kW
0.69 0.94
Min.—Max. 0.15—1.20 0.16—1.29
Heating Rated 0.59 0.82
Min.—Max. 0.25—1.15 0.25—1.31
Current Cooling Rated A 3.5 4.7
Heating 3.3 4.2
EER Cooling kW/kW 3.83 3.74
COP Heating 4.47 4.29
Sensible capacity Cooling kW 2.47 2.96
Power factor Cooling %90 91
Heating 81 89
Moisture removal L/h (pints/h) 1.1 (1.9)
Maximum operating current*1Cooling A6.5
Heating 9.0
Fan
Airflow rate
Cooling
HIGH
m3/h
640 750
MED 560 640
LOW 480 480
QUIET 310 310
Heating
HIGH 640 750
MED 560 640
LOW 520 520
QUIET 330 330
Type × Qty Crossflow fan × 1
Motor output W 35
Sound pressure level*2
Cooling
HIGH
dB (A)
40 43
MED 36 40
LOW 32
QUIET 21
Heating
HIGH 40 43
MED 36 38
LOW 33
QUIET 22
Heat exchanger
Dimensions (H × W × D)
mm
Main: 320 × 630 × 20
Sub: 84 × 630 × 13.3
Fin pitch Main: 1.1
Sub: 1.4
Rows × Stages Main: 2 × 20
Sub: 1 × 4
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color White
Approximate color of Munsell N9.25/
Dimensions
(H × W × D)
Net mm 268 × 840 × 203
Gross 270 × 884 × 336
Weight Net kg 8.0
Gross 10.5
Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4) Gas Ø9.52 (Ø3/8)
Method Flare
Drain hose Material PP+HDPE
Tip diameter mm Ø13.8 (I.D.), Ø15.0 to Ø16.8 (O.D.)
Operation range Cooling °C 18 to 32 %RH 80 or less
Heating °C 16 to 30
Remote controller Wireless (Option: Wired, Mobile app*3 [AIRSTAGE Mobile])
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27°CDB/19°CWB, and outdoor temperature of 35°CDB/24°CWB.
– Heating: Indoor temperature of 20°CDB/15°CWB, and outdoor temperature of 7°CDB/6°CWB.
– Pipe length: 5 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *1: Maximum current is maximum value when operated within the operation range.
• *2: Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *3: Available on Google Play™ store or on App Store®. Optional WLAN Adapter is also required. For details, refer to the setting manual.
- 2 - 1. Specifications
WALL MOUNTED ASBG09-12KMBA WALL MOUNTED ASBG09-12KMBA

2. Dimensions
2-1. Models: ASBG09KMBA and ASBG12KMBA
Unit: mm
315 11532189
for pipe inlet Ø65 for pipe inlet Ø65
45 365 353 77
42
Outline of indoor unit
840 203
268
315
381
534
18
7
226
- 3 -
2-1. Models: ASBG09KMBA and ASBG12KMBA 2. Dimensions
WALL MOUNTED ASBG09-12KMBA WALL MOUNTED ASBG09-12KMBA

¢Installation space requirement
Provide sufficient installation space for product safety.
Unit: mm
Outline of unit
25 or more
70 or more
52 or more
130 or more
1,500 or more
45 or more
63 or more
2,300 or more
- 4 -
2-1. Models: ASBG09KMBA and ASBG12KMBA 2. Dimensions
WALL MOUNTED ASBG09-12KMBA WALL MOUNTED ASBG09-12KMBA

3. Wiring diagrams
3-1. Models: ASBG09KMBA and ASBG12KMBA
- 5 -
3-1. Models: ASBG09KMBA and ASBG12KMBA 3. Wiring diagrams
WALL MOUNTED ASBG09-12KMBA WALL MOUNTED ASBG09-12KMBA

4. Capacity table
Capacity tables show each of following values calculated based on the outdoor temperature and the
indoor temperature, under given Airflow Rate (AFR):
For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP)
For heating capacity: Total Capacity (TC) and Input Power (IP)
4-1. Cooling capacity
¢Model: ASBG09KMBA
AFR m3/h 640
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
18 2.49 2.33 0.56 2.70 2.42 0.55 2.85 2.48 0.55 2.99 2.54 0.55 3.05 2.61 0.55 3.28 2.66 0.54 3.49 2.75 0.53
20 2.46 2.33 0.56 2.67 2.42 0.56 2.82 2.48 0.55 2.96 2.54 0.55 3.02 2.61 0.55 3.24 2.66 0.54 3.46 2.75 0.54
25 2.37 2.31 0.59 2.58 2.39 0.59 2.72 2.45 0.58 2.85 2.51 0.58 2.91 2.58 0.58 3.13 2.63 0.57 3.33 2.72 0.56
30 2.27 2.23 0.64 2.47 2.35 0.63 2.60 2.41 0.63 2.73 2.47 0.62 2.79 2.54 0.63 2.99 2.58 0.61 3.19 2.67 0.61
35 2.15 2.11 0.70 2.34 2.29 0.69 2.46 2.35 0.69 2.58 2.40 0.69 2.64 2.47 0.69 2.83 2.51 0.68 3.02 2.60 0.67
40 2.01 1.98 0.78 2.19 2.15 0.77 2.30 2.27 0.77 2.42 2.32 0.76 2.47 2.39 0.77 2.65 2.43 0.75 2.83 2.51 0.75
46 1.83 1.83 0.90 1.99 1.99 0.89 2.09 2.09 0.89 2.20 2.15 0.88 2.25 2.21 0.89 2.41 2.25 0.87 2.57 2.33 0.86
50 1.59 1.59 0.78 1.73 1.73 0.77 1.82 1.82 0.77 1.92 1.92 0.76 1.96 1.96 0.77 2.10 1.99 0.75 2.24 2.06 0.74
¢Model: ASBG12KMBA
AFR m3/h 750
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
18 2.77 2.67 0.62 3.01 2.75 0.62 3.16 2.81 0.62 3.32 2.86 0.61 3.41 2.92 0.61 3.63 2.97 0.61 3.87 3.05 0.60
20 3.28 2.85 0.74 3.56 2.94 0.73 3.75 2.99 0.73 3.93 3.05 0.73 4.05 3.12 0.72 4.30 3.17 0.72 4.58 3.25 0.71
25 3.16 2.77 0.81 3.43 2.85 0.80 3.61 2.91 0.80 3.79 2.97 0.80 3.90 3.03 0.79 4.15 3.08 0.79 4.41 3.16 0.78
30 3.02 2.70 0.88 3.28 2.79 0.88 3.45 2.84 0.87 3.62 2.90 0.87 3.72 2.96 0.86 3.96 3.01 0.86 4.21 3.09 0.86
35 2.86 2.71 0.97 3.10 2.79 0.96 3.26 2.84 0.96 3.42 2.90 0.95 3.52 2.96 0.94 3.74 3.01 0.94 3.99 3.09 0.94
40 2.67 2.62 1.05 2.90 2.70 1.05 3.05 2.75 1.04 3.20 2.81 1.04 3.29 2.86 1.03 3.50 2.91 1.03 3.73 2.99 1.02
46 2.42 2.42 1.17 2.63 2.63 1.16 2.76 2.73 1.15 2.90 2.78 1.15 2.98 2.84 1.13 3.17 2.89 1.14 3.38 2.96 1.13
50 2.00 2.00 0.95 2.17 2.17 0.94 2.29 2.29 0.94 2.40 2.40 0.93 2.47 2.38 0.92 2.63 2.42 0.92 2.80 2.49 0.92
- 6 -
4-1. Cooling capacity 4. Capacity table
WALL MOUNTED ASBG09-12KMBA WALL MOUNTED ASBG09-12KMBA

4-2. Heating capacity
¢Model: ASBG09KMBA
AFR m3/h 640
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 1.71 0.90 1.71 0.93 1.70 0.93 1.70 0.97 1.69 0.99
-10 -11 2.06 0.95 2.05 0.98 2.04 0.98 2.04 1.02 2.03 1.05
-5 -7 2.40 1.00 2.39 1.02 2.38 1.03 2.38 1.07 2.37 1.10
0 -2 2.75 1.05 2.74 1.07 2.72 1.08 2.72 1.12 2.71 1.15
5 3 3.09 1.09 3.08 1.12 3.06 1.13 3.06 1.18 3.05 1.20
7 6 3.23 1.11 3.22 1.14 3.20 1.15 3.20 1.20 3.19 1.22
10 8 3.43 1.14 3.42 1.17 3.40 1.18 3.40 1.23 3.39 1.25
15 10 3.54 1.15 3.53 1.17 3.51 1.18 3.51 1.23 3.50 1.26
20 15 3.88 1.16 3.86 1.18 3.84 1.20 3.84 1.24 3.83 1.27
24 18 4.06 1.16 4.05 1.19 4.02 1.20 4.02 1.25 4.01 1.28
¢Model: ASBG12KMBA
AFR m3/h 750
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 2.07 1.03 2.05 1.05 2.02 1.06 2.01 1.10 1.99 1.13
-10 -11 2.48 1.08 2.46 1.11 2.42 1.12 2.41 1.16 2.39 1.19
-5 -7 2.89 1.14 2.87 1.16 2.83 1.17 2.82 1.22 2.79 1.25
0 -2 3.31 1.19 3.28 1.22 3.23 1.23 3.22 1.28 3.19 1.31
5 3 3.72 1.24 3.69 1.27 3.64 1.29 3.62 1.33 3.59 1.36
7 6 3.89 1.27 3.85 1.30 3.80 1.31 3.79 1.36 3.75 1.39
10 8 4.14 1.30 4.10 1.33 4.04 1.34 4.03 1.39 3.99 1.42
15 10 4.11 1.21 4.07 1.24 4.02 1.25 4.00 1.29 3.96 1.32
20 15 4.33 1.15 4.29 1.18 4.23 1.19 4.21 1.24 4.18 1.26
24 18 4.41 1.11 4.38 1.14 4.31 1.15 4.30 1.19 4.26 1.22
- 7 -
4-2. Heating capacity 4. Capacity table
WALL MOUNTED ASBG09-12KMBA WALL MOUNTED ASBG09-12KMBA

5. Fan performance
5-1. Air velocity distributions
¢Model: ASBG09KMBA
Measuring conditions Fan speed Operation mode
HIGH FAN
Top view
Horizontal louver: Up
Vertical louver: Center
2
1
0
1
2
Unit: m/s
(m)
(m)
0 1 2 3 4 5 6 7 8 9
2.0 1.5 1.0
0.5
Top view
Horizontal louver: Up
Vertical louver: Left & Right
2
3
3
1
0
1
2
Unit: m/s
(m)
(m)
0 1 2 3 4 5 6 7 8 9
0.5
0.5
2.0
2.0
1.5
1.5
1.0
1.0
Side view
Horizontal louver: Up
Vertical louver: Center
3
2
1
0
Unit: m/s
(m)
(m)
0 1 2 3 4 5 6 7 8 9
2.0
1.5 1.0 0.5
Side view
Horizontal louver: Down
Vertical louver: Center
3
2
1
0
Unit: m/s
(m)
(m)
0 1 2 3 4 5 6 7 8 9
2.0
1.5
1.0 0.5
- 8 -
5-1. Air velocity distributions 5. Fan performance
WALL MOUNTED ASBG09-12KMBA WALL MOUNTED ASBG09-12KMBA

¢Model: ASBG12KMBA
Measuring conditions Fan speed Operation mode
HIGH FAN
Top view
Horizontal louver: Up
Vertical louver: Center
2
1
0
1
2
Unit: m/s
(m)
(m)
0 1 2 3 4 5 6 7 8 9
2.0 1.5 1.0
0.5
Top view
Horizontal louver: Up
Vertical louver: Left & Right
2
3
3
1
0
1
2
Unit: m/s
(m)
(m)
0 1 2 3 4 5 6 7 8 9
0.5
0.5
2.0
2.0
1.5
1.5
1.0
1.0
Side view
Horizontal louver: Up
Vertical louver: Center
3
2
1
0
Unit: m/s
(m)
(m)
0 1 2 3 4 5 6 7 8 9
2.0
1.5 1.0
0.5
Side view
Horizontal louver: Down
Vertical louver: Center
3
2
1
0
Unit: m/s
(m)
(m)
0 1 2 3 4 5 6 7 8 9
2.0
1.5
1.0 0.5
- 9 -
5-1. Air velocity distributions 5. Fan performance
WALL MOUNTED ASBG09-12KMBA WALL MOUNTED ASBG09-12KMBA

5-2. Airflow
¢Model: ASBG09KMBA
Cooling
Fan speed Airflow
HIGH
m3/h 640
l/s 178
CFM 377
MED
m3/h 560
l/s 156
CFM 330
LOW
m3/h 480
l/s 133
CFM 283
QUIET
m3/h 310
l/s 86
CFM 182
Heating
Fan speed Airflow
HIGH
m3/h 640
l/s 156
CFM 377
MED
m3/h 560
l/s 156
CFM 330
LOW
m3/h 520
l/s 144
CFM 306
QUIET
m3/h 330
l/s 92
CFM 194
- 10 -
5-2. Airflow 5. Fan performance
WALL MOUNTED ASBG09-12KMBA WALL MOUNTED ASBG09-12KMBA

¢Model: ASBG12KMBA
Cooling
Fan speed Airflow
HIGH
m3/h 750
l/s 208
CFM 441
MED
m3/h 640
l/s 178
CFM 377
LOW
m3/h 480
l/s 133
CFM 283
QUIET
m3/h 310
l/s 86
CFM 182
Heating
Fan speed Airflow
HIGH
m3/h 750
l/s 178
CFM 441
MED
m3/h 640
l/s 178
CFM 377
LOW
m3/h 520
l/s 144
CFM 306
QUIET
m3/h 330
l/s 92
CFM 194
- 11 -
5-2. Airflow 5. Fan performance
WALL MOUNTED ASBG09-12KMBA WALL MOUNTED ASBG09-12KMBA

6. Operation noise (sound pressure)
6-1. Noise level curve
¢Model: ASBG09KMBA
Cooling
0
10
20
30
40
50
60
70
80
63 125 250 500 1,000 2,000 4,000 8,000
Octave band sound pressure level, dB: (0 dB = 0.0002 μbar)
Octave band center frequency, Hz
NC-65
NC-60
NC-55
NC-50
NC-45
NC-40
NC-35
NC-30
NC-25
NC-20
NC-15
HIGH
QUIET
Heating
0
10
20
30
40
50
60
70
80
63 125 250 500 1,000 2,000 4,000 8,000
Octave band sound pressure level, dB: (0 dB = 0.0002 μbar)
Octave band center frequency, Hz
NC-65
NC-60
NC-55
NC-50
NC-45
NC-40
NC-35
NC-30
NC-25
NC-20
NC-15
HIGH
QUIET
¢Model: ASBG12KMBA
Cooling
0
10
20
30
40
50
60
70
80
63 125 250 500 1,000 2,000 4,000 8,000
Octave band sound pressure level, dB: (0 dB = 0.0002 μbar)
Octave band center frequency, Hz
NC-65
NC-60
NC-55
NC-50
NC-45
NC-40
NC-35
NC-30
NC-25
NC-20
NC-15
HIGH
QUIET
Heating
0
10
20
30
40
50
60
70
80
63 125 250 500 1,000 2,000 4,000 8,000
Octave band sound pressure level, dB: (0 dB = 0.0002 μbar)
Octave band center frequency, Hz
NC-65
NC-60
NC-55
NC-50
NC-45
NC-40
NC-35
NC-30
NC-25
NC-20
NC-15
HIGH
QUIET
- 12 -
6-1. Noise level curve 6. Operation noise (sound pressure)
WALL MOUNTED ASBG09-12KMBA WALL MOUNTED ASBG09-12KMBA

6-2. Sound level check point
0.8 m
1 m
Microphone Microphone
NOTE: Detailed shape of the actual indoor unit might be slightly different from the one illustrated
above.
- 13 -
6-2. Sound level check point 6. Operation noise (sound pressure)
WALL MOUNTED ASBG09-12KMBA WALL MOUNTED ASBG09-12KMBA

7. Safety devices
Type of
protection Protection form Model
ASBG09KMBA ASBG12KMBA
Circuit protection Current fuse (PCB*) 250 V, 3.15 A
Fan motor
protection
Thermal protector
program
Activate 170 +25-30°C
Fan motor stop
Reset 145 +25-30°C
Fan motor restart
*PCB: Printed Circuit Board
- 14 - 7. Safety devices
WALL MOUNTED ASBG09-12KMBA WALL MOUNTED ASBG09-12KMBA

8. External input and output
With using external input and output functions, this product can be operated inter-connectedly with
an external device.
Connector Input Output Remarks
CNA01 Control input — See external input/output
settings for details.
CNB01 — Operation status output
CNB02 — Error status output
8-1. External input
With using external input function, some functions on this product can be controlled from an external
device.
• “Operation/Stop” mode or "Forced stop" mode can be selected with function setting of indoor unit.
• A twisted pair cable (22AWG) should be used. Maximum length of cable is 150 m.
• The wire connection should be separate from the power cable line.
¢Control input (Operation/Stop or Forced stop)
The air conditioner can be remotely operated by means of the following on-site work.
Unit operation is started at the following contents by adding the contact input of a commercially avail-
able on/off switch to a connector on the external control PCB and turning it on.
Unit operation Initial setting after power is on Starting mode other than initial setting
Operation mode Auto changeover Mode at previous operation
Set temperature 24 °C Temperature at previous operation
Airflow mode AUTO Mode at previous operation
Air direction (swing) Standard air direction (swing OFF) Air direction at previous operation
•Circuit diagram example:
Signal
Locally purchased
Indoor unit
control PCB Communication kit
Optional parts
Connector
1
3
10 m*
Connected unit
Example: Switch
• Contact capacity: DC 24 V or more, 10
mA or more.
• *: Make the distance from the PCB to the
connected unit within 10 m.
• Use non-polar relays and switches.
•When function setting is “Operation/Stop” mode:
Operation
Stop
On
Off
Input signal
Indoor unit
- 15 -
8-1. External input 8. External input and output
WALL MOUNTED ASBG09-12KMBA WALL MOUNTED ASBG09-12KMBA

•When function setting is “Forced stop” mode:
Remote controller On On On
Input signal
Indoor unit
Command
Remote control
operation invalidity
On
Off
Operation
Stop
Forced stop
Normal
•Optional part:
Part name Model name Exterior
External Connect Kit UTY-XWZXZ5
External input wire
Communication Kit UTY-XCBXZ2
* For operating the external function, the wall mounted type requires the communication kit in addi-
tion to the wire (UTY-XWZXZ5).
- 16 -
8-1. External input 8. External input and output
WALL MOUNTED ASBG09-12KMBA WALL MOUNTED ASBG09-12KMBA
