Fujitsu PRIMERGY BX900 S1 User manual

Operating Manual - English
PRIMERGY BX900 S1
Blade Server
System Unit Operating Manual
Edition March 2011

Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Feel free to send us your comments by e-mail to
email: [email protected].
Certified documentation
according to DIN EN ISO 9001:2008
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2008.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademarks
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-4944-006.fm
Copyright © 2011 Fujitsu Technology Solutions GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trade names and/or trademarks of their respective
manufacturers.
– The contents of this manual may be revised without prior notice.
– Fujitsu assumes no liability for damages to third party copyrights or other rights arising from
the use of any information in this manual.
– No part of this manual may be reproduced in any form without the prior written permission
of Fujitsu.
Microsoft, Windows, Windows Server, and Hyper V are trademarks or registered trademarks of
Microsoft Corporation in the USA and other countries.
Intel and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries
in the USA and other countries.

BX900 S1 Operating Manual
Before reading this manual
For your safety
This manual contains important information for safely and correctly using this
product.
Carefully read the manual before using this product. Pay particular attention to
the accompanying manual "Safety Notes and Regulations" and ensure these
safety notes are understood before using the product. Keep this manual and the
manual "Safety Notes and Regulations" in a safe place for easy reference while
using this product.
Radio interference
This product is a "Class A" ITE (Information Technology Equipment). In a
domestic environment this product may cause radio interference, in which case
the user may be required to take appropriate measures. VCCI-A
Aluminum electrolytic capacitors
The aluminum electrolytic capacitors used in the product's printed circuit board
assemblies and in the mouse and keyboard are limited-life components. Use of
these components beyond their operating life may result in electrolyte leakage
or depletion, potentially causing emission of foul odor or smoke.
As a guideline, in a normal office environment (25°C) operating life is not
expected to be reached within the maintenance support period (5 years).
However, operating life may be reached more quickly if, for example, the product
is used in a hot environment. The customer shall bear the cost of replacing
replaceable components which have exceeded their operating life. Note that
these are only guidelines, and do not constitute a guarantee of trouble-free
operation during the maintenance support period.
High safety use
This product has been designed and manufactured for general uses such as
general office use, personal use, domestic use and normal industrial use. It has
not been designed or manufactured for uses which demand an extremely high
level of safety and carry a direct and serious risk to life or body if such safety
cannot be ensured.

Operating Manual BX900 S1
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-4944-006.fm
These uses include control of nuclear reactions in nuclear power plants,
automatic airplane flight control, air traffic control, traffic control in mass
transport systems, medical devices for life support, and missile guidance control
in weapons systems (hereafter, "high safety use"). Customers should not use
this product for high safety use unless measures are in place for ensuring the
level of safety demanded of such use. Please consult the sales staff of Fujitsu if
intending to use this product for high safety use.
Measures against momentary voltage drop
This product may be affected by a momentary voltage drop in the power supply
caused by lightning. To prevent a momentary voltage drop, use of an AC
uninterruptible power supply is recommended.
(This notice follows the guidelines of Voltage Dip Immunity of Personal
Computer issued by JEITA, the Japan Electronics and Information Technology
Industries Association.)
Technology controlled by the Foreign Exchange and Foreign Trade
Control Law of Japan
Documents produced by Fujitsu may contain technology controlled by the
Foreign Exchange and Foreign Trade Control Law of Japan. Documents which
contain such technology should not be exported from Japan or transferred to
non-residents of Japan without first obtaining authorization in accordance with
the above law.
Harmonic Current Standards
This product conforms to harmonic current standard JIS C 61000-3-2.
Only for the Japanese market:
About SATA hard disk drives
The SATA version of this server supports hard disk drives with SATA / BC-SATA
storage interfaces. Please note that the usage and operation conditions differ
depending on the type of hard disk drive used.
Please refer to the following internet address for further information on the
usage and operation conditions of each available type of hard disk drive:
http://primeserver.fujitsu.com/primergy/harddisk/

BX900 S1 Operating Manual
Only for the Japanese market:
IAlthough described in this manual, some sections do not apply to the
Japanese market. These options and routines include:
– USB Flash Module (UFM)
– CSS (Customer Self Service)
– Replacing the lithium battery

Operating Manual BX900 S1
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-4944-006.fm

BX900 S1 Operating Manual
Contents
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.1 Concept and target groups for this manual . . . . . . . . . 11
1.2 Documentation overview . . . . . . . . . . . . . . . . . . . 12
1.3 Performance features . . . . . . . . . . . . . . . . . . . . . 13
1.4 Notational conventions . . . . . . . . . . . . . . . . . . . . 20
1.5 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . 21
2 Installation steps, overview . . . . . . . . . . . . . . . . . . 25
3 Important notes . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 27
3.2 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.3 Transporting the system unit . . . . . . . . . . . . . . . . . 35
3.4 Notes on installation into the rack . . . . . . . . . . . . . . 36
3.5 Environmental protection . . . . . . . . . . . . . . . . . . . 37
4 Installing the hardware . . . . . . . . . . . . . . . . . . . . . 39
4.1 Installation procedure . . . . . . . . . . . . . . . . . . . . . 40
4.2 Unpacking the system unit . . . . . . . . . . . . . . . . . . 40
4.3 Installing the system unit in the rack . . . . . . . . . . . . . 41
4.3.1 Installation in PRIMECENTER/DataCenter rack . . . . . . . . . 44
4.3.2 Installing/removing the system unit . . . . . . . . . . . . . . . 48
4.4 Connecting devices to the system unit . . . . . . . . . . . . 51
4.4.1 Cable routing . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
4.5 Connecting the system unit to the mains . . . . . . . . . . 52
4.5.1 Using cable ties . . . . . . . . . . . . . . . . . . . . . . . . . 55
4.6 Instructions for connecting/disconnecting cables . . . . . . 56

Operating Manual BX900 S1
Contents
© cognitas. Gesellschft für Technik-Dokumentation mbH 2010 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-4945-006.fm
5 Installation and operation . . . . . . . . . . . . . . . . . . . . 57
5.1 Control and display elements . . . . . . . . . . . . . . . . . . 57
5.1.1 Front of system . . . . . . . . . . . . . . . . . . . . . . . . . . 57
5.1.1.1 Control elements . . . . . . . . . . . . . . . . . . . . . . . 61
5.1.1.2 LEDs on the control panel . . . . . . . . . . . . . . . . . . . 61
5.1.2 Back of system . . . . . . . . . . . . . . . . . . . . . . . . . . 63
5.1.2.1 Control and display elements on the management blade . . . 63
5.1.2.2 Indicators on the hot-plug power supply units . . . . . . . . . 66
5.1.2.3 Indicators on the hot-plug fans . . . . . . . . . . . . . . . . 67
5.2 Switching the system unit on/off . . . . . . . . . . . . . . . . 68
5.3 Configuring management blades . . . . . . . . . . . . . . . . 70
5.4 Cleaning the system unit . . . . . . . . . . . . . . . . . . . . 74
6 Property and data protection . . . . . . . . . . . . . . . . . . 75
7 Troubleshooting and tips . . . . . . . . . . . . . . . . . . . . 77
7.1 System power indicator does not light up . . . . . . . . . . . 77
7.2 Front or back error LED flashes orange . . . . . . . . . . . . 78
7.3 System switches itself off . . . . . . . . . . . . . . . . . . . . 79
7.4 Screen remains blank . . . . . . . . . . . . . . . . . . . . . . 79
7.5 Flickering stripes on monitor screen . . . . . . . . . . . . . 80
7.6 No screen display or display drifts . . . . . . . . . . . . . . . 80
7.7 No mouse pointer displayed on screen . . . . . . . . . . . . 80
7.8 Incorrect date and time . . . . . . . . . . . . . . . . . . . . . 81
7.9 Server blade does not boot . . . . . . . . . . . . . . . . . . . 81
7.10 Defective drive . . . . . . . . . . . . . . . . . . . . . . . . . . 82
8 Hot-plug components . . . . . . . . . . . . . . . . . . . . . . 83
8.1 Server blades and storage blades . . . . . . . . . . . . . . . 83
8.2 Connection blades . . . . . . . . . . . . . . . . . . . . . . . 91

BX900 S1 Operating Manual
Contents
8.2.1 Connection Blade GbE Switch/IBP 36/12 (SB11A) . . . . . . . 92
8.2.2 Connection Blade GbE Switch/IBP 36/8+2 (SB11) . . . . . . . 93
8.2.2.1 Connection blade stacking . . . . . . . . . . . . . . . . . . 96
8.2.3 Connection Blade 10 GbE Switch/IBP 18/8 . . . . . . . . . . . 103
8.2.4 Connection Blade 8Gb FC Switch 18/8 . . . . . . . . . . . . . 105
8.2.5 Connection Blade Ethernet Pass Thru 10Gb 18/18 . . . . . . . 107
8.2.6 Connection Blade 8Gb FC Pass Thru 18/18 . . . . . . . . . . . 110
8.2.7 Connection Blade Infiniband Switch 40 Gb 18/18 . . . . . . . 112
8.2.8 Connection Blade GbE Switch/IBP 18/6 (SB6) . . . . . . . . . 114
8.2.9 Fitting rules for connection blades . . . . . . . . . . . . . . . . 116
8.2.10 Port assignment of the connection blades . . . . . . . . . . . . 118
8.2.11 Installing a connection blade . . . . . . . . . . . . . . . . . . . 120
8.3 Management blades . . . . . . . . . . . . . . . . . . . . . . 125
8.4 Hot-plug power supply units . . . . . . . . . . . . . . . . . 126
8.4.1 Fitting rules for power supply units and fan modules . . . . . . 127
8.4.1.1 Configuration examples . . . . . . . . . . . . . . . . . . . 131
8.4.2 Replacing the power supply unit . . . . . . . . . . . . . . . . . 135
8.5 Hot-plug fan modules . . . . . . . . . . . . . . . . . . . . . 137
8.5.1 Replacing a fan unit . . . . . . . . . . . . . . . . . . . . . . . 138
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

Operating Manual BX900 S1
Contents
© cognitas. Gesellschft für Technik-Dokumentation mbH 2010 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-4945-006.fm

BX900 S1 Operating Manual 11
Technical data
1 Introduction
The PRIMERGY BX900 S1 blade server is a highly compact, energy-saving
and scalable server system for installation in a 19-inch rack. The BX900 S1
system unit has 18 installation slots for dual-socket server blades in two rows
on top of each other. Six server blade slots can be fitted with storage blades
which provide additional storage capacity for the neighboring server blades.
With its advanced infrastructure modules, the BX900 S1 system unit offers the
server blades a high level of connectivity and availability. These include hot-plug
connection blades, redundant management blades and power supply units, the
server management of the ServerView suite, Prefailure Detection and
Analyzing (PDA), and Automatic Server Reconfiguration and Restart (ASR&R).
Security functions in the BIOS-setup of the server blades and on the system
boards protect the data on the blade server from manipulation. Additional
security is provided by the lockable rack door.
The BX900 S1 system unit takes up 10 height units (U) in the rack.
1.1 Concept and target groups for this manual
This operating manual describes how to install, set up and operate your server.
This operating manual is intended for those responsible for installing the
hardware and ensuring that the system runs smoothly. It contains all the
information you need to put your PRIMERGY BX900 S1 system unit into
operation.
To understand the various expansion options, you will need to be familiar with
the fields of hardware and data transmission and you will require a basic
knowledge of the underlying operating system.

12 Operating Manual BX900 S1
Technical data
© cognitas. Gesellschft für Technik-Dokumentation mbH 2010 Pfad: C:\Programme\FCT\tim_app\tim_local\work\RENATE\OBJ_DOKU-4946-005.fm
1.2 Documentation overview
More information on your PRIMERGY BX900 S1 system unit can be found in
the following documents:
– "Quick Start Hardware - PRIMERGY BX900 S1" leaflet
"はじめにお読みください -PRIMERGY BX900 S1" for the Japanese market
(only included as a printed copy)
– "Quick Start Software - Quick Installation Guide" DVD booklet
(only included with the ServerView Suite as a printed copy) except for the
Japanese market
– "Safety Notes and Regulations" manual
"安全上のご注意 " for the Japanese market
– "Warranty" manual
"保証書 " for the Japanese market
– "ServerView Suite Local Service Concept - LSC" manual
– "Returning used devices" manual and "Service Desk" leaflet
"サポート＆サービス " for the Japanese market
– "PRIMERGY BX900 S1 Blade Server System Unit Operating Manual"
IPRIMERGY manuals are available in PDF format on the
ServerView Suite DVD 2. The ServerView Suite DVD 2 is part of the
ServerView Suite supplied with every server.
If you no longer have the ServerView Suite DVDs, you can obtain the
relevant current versions using the order number U15000-C289 (the
order number for the Japanese market: please refer to the configurator
of the server http://primeserver.fujitsu.com/primergy/system.html).
The PDF files of the manuals can also be downloaded free of charge
from the Internet. The overview page showing the online documentation
available on the Internet can be found using the URL (for EMEA market):
http://manuals.ts.fujitsu.com. The PRIMERGY server documentation can
be accessed using the Industry standard servers navigation option.
For the Japanese market please use the URL:
http://primeserver.fujitsu.com/primergy/manual.html.

BX900 S1 Operating Manual 13
Technical data
Further sources of information
Further information is provided:
– The Deployment Manager manual (only relevant for cloning server blades)
– Documentation on the server blades and storage blades
– The manual "PRIMERGY BX900 Blade Server Systems ServerView
Management Blade S1 User Interface Description"
1.3 Performance features
Customer Self Service (CSS)
The Fujitsu Technology Solutions Customer Self Service (CSS) concept
enables you to identify and replace the affected component yourself in the case
of certain error scenarios.
In the CSS concept, you can replace the following components yourself in the
event of an error:
– Hot-plug hard disk drives
– Hot-plug power supply units
– Memory modules
–Systemfan
– expansion cards
For information on replacing these components, see chapter "Hot-plug
components" on page 83.
CSS indicators on the control panel and on the back of the PRIMERGY server
provide you with information if a CSS event arises (for more information on the
behavior of these indicators, see chapter "Installation and operation" on
page 57 and the "ServerView Suite Local Service Concept - LSC" manual on
the ServerView Suite DVD 2).
Your system unit is fitted with a ServerView Local Service Panel, which enables
you to identify the type of component affected by the error directly on the server
(for more information, see the "ServerView Suite Local Service Concept - LSC"
manual on the ServerView Suite DVD 2).
In addition, CSS errors are displayed in the ServerView Operations Manager -
the server management software from Fujitsu Technology Solutions.

14 Operating Manual BX900 S1
Technical data
© cognitas. Gesellschft für Technik-Dokumentation mbH 2010 Pfad: C:\Programme\FCT\tim_app\tim_local\work\RENATE\OBJ_DOKU-4946-005.fm
In the event of errors, the ServerView Operations Manager refers you directly to
the affected component and its order information in the Illustrated Spares
catalog of the server in question.
Server performance
The PRIMERGY BX900 S1 system unit has 18 slots for server blades. Six
server blade slots can be fitted with storage blades which provide additional
storage capacity for the neighboring server blades. For information on installing
and removing server blades and storage blades, see section "Server blades
and storage blades" on page 83. For further information on the server blades
and storage blades, see the relevant operating manuals.
Connection blades
The PRIMERGY BX900 S1 system unit has eight slots for connection blades on
the back. These provide the installed server blades with connections to the
Ethernet LAN as well as to SAN environments.
The following connection blade types are available:
●Ethernet connection blades
– Connection Blade GbE Switch/IBP 36/12 (SB11A)
– 36 internal 1-Gbit ports to the server blades
– 8 external 1-Gbit ports through RJ45 connections
– 4 external 1-Gbit ports through SFP modules
IThis connection blade can be used in all connection blade slots.
Ethernet connection blades in slots CB3/4 (fabric 2), CB5/6 (fabric
3) and CB7/8 (fabric 4) only support server blades that are fitted
with an Ethernet mezzanine card.
– Connection Blade GbE Switch/IBP 36/8+2 (SB11)
– 36 internal 1-Gbit ports to the server blades
– 8 external 1-Gbit ports through RJ45 connections
– 2 external 10-Gbit ports through SFP+ modules
– 1 internal stacking port to the midplane of the BX900 S1 system unit
– 1 external stacking port through a CX4 connection
The stacking ports allow up to 8 SB11 connection blades to be
switched together to form a so-called stack, see "Connection blade
stacking" on page 96.

BX900 S1 Operating Manual 15
Technical data
To use connection blade stacking, the firmware version of the
management blade of the BX900 S1 system unit must be at least
V4.27.
IThis connection blade can be used in all connection blade slots.
Ethernet connection blades in slots CB3/4 (fabric 2), CB5/6 (fabric
3) and CB7/8 (fabric 4) only support server blades that are fitted
with an Ethernet mezzanine card.
– Connection Blade GbE Switch/IBP 18/6 (SB6)
– 18 internal 1-Gbit ports to the server blades
– 6 external 1-Gbit ports through RJ45 connections
IThis connection blade can be used in all connection blade slots.
Ethernet connection blades in slots CB3/4 (fabric 2), CB5/6 (fabric
3) and CB7/8 (fabric 4) only support server blades that are fitted
with an Ethernet mezzanine card.
– Connection Blade 10 GbE Switch/IBP 18/8
– 18 internal 10-Gbit ports to the server blades
– 8 external 10-Gbit ports through SFP+ modules or active twinax
cables (copper)
IThis connection blade can be used in slots CB1/2 (fabric 1), CB3/4
(fabric 2) and CB5/6 (fabric 3).
10 GbE connection blades in slots CB3/4 (fabric 2) and CB5/6
(fabric 3) only support server blades that are fitted with a 10 Gbit
Ethernet mezzanine card.
– Connection Blade Ethernet Pass Thru 10Gb 18/18
– 18 internal 1/10-Gbit ports to the server blades
– 18 external 1/10-Gbit ports through SFP/SFP+ modules
IThis connection blade can be used in slots CB1/2 (fabric 1), CB3/4
(fabric 2) and CB5/6 (fabric 3).
10 GbE connection blades in slots CB3/4 (fabric 2) and CB5/6
(fabric 3) only support server blades that are fitted with a 10 Gbit
Ethernet mezzanine card.

16 Operating Manual BX900 S1
Technical data
© cognitas. Gesellschft für Technik-Dokumentation mbH 2010 Pfad: C:\Programme\FCT\tim_app\tim_local\work\RENATE\OBJ_DOKU-4946-005.fm
●Fiber Channel connection blades
– Connection Blade 8Gb FC Switch 18/8
– 18 internal 8-Gbit ports to the server blades
– 8 external ports through 8-Gb SFP+ modules or 4-Gb SFP modules
This connection blade is available in three license variants:
– Brocade 5450 with 14-port license
– Brocade 5450 with 26-port license (applies only to EMEA market)
– Brocade 5450 with 26 port license and performance bundle (applies
only to EMEA market)
– Connection Blade 8Gb FC Pass Thru18/18
– 18 internal 8-Gbit ports to the server blades
– 18 external ports through 8-Gb SFP+ modules or 4-Gb SFP modules
IFibre Channel connection blades can only be installed in slots CB3/4
(fabric 2) and CB5/6 (fabric 3) and only support server blades that are
fitted with a Fibre Channel mezzanine card.
●Infiniband connection blade
– Connection Blade Infiniband Switch 40 Gb 18/18
– 18 internal 40-Gbit Infiniband ports to the server blades
– 18 external 40-Gbit Infiniband connections through QSFP modules
IInfiniband connection blades can only be used in the slots CB 3/4, CB
5/6 and CB 7/8, see figure "Connection blade slots" on page 116.
They only support server blades that are fitted with an Infiniband
mezzanine card.
The connection blades support hot-swapping. By installing two connection
blades in two adjacent slots (not possible with Infiniband connection blades),
you can provide redundant network connections for the server blades (for
details, see section "Connection blades" on page 91).
Information
For the latest information on optional products provided for the BX900 S1
system unit see the configurator of the system unit:
https://sp.ts.fujitsu.com/dmsp/docs/cnfgbx900-systemunits.pdf
(for the EMEA market)
http://primeserver.fujitsu.com/primergy/system.html (for the Japanese market)

BX900 S1 Operating Manual 17
Technical data
Management blade
The PRIMERGY BX900 S1 system unit has slots for two redundant, hot-swap
management blades with an integrated management solution for complete
remote administration of the system. The base configuration of the system unit
contains one management blade (for details, see section "Management blades"
on page 125).
Power supply
The system unit has six installation bays for hot-plug power supply units which
automatically set themselves to a voltage in the range of 100 - 240 V. The base
configuration includes three power supply units. As an option, you can set up a
redundant power supply with three additional power supply units. If a power
supply unit fails, the redundant configuration assures continued operation. The
defective power supply unit can be replaced during operation (for further details
see section "Hot-plug power supply units" on page 126).
Cooling
Cooling of the system is ensured by two fan units in each power supply unit and
by the fan modules. Each of the fan units contains 2x2 fans. The fan modules
have the same aspect ratio as the power supply units. Depending on the
number of installed server blades and storage blades in the system unit, empty
power supply installation bays must be fitted with fan modules. The
configuration is redundant and offers hot-swap functionality (for more
information, see "Hot-plug power supply units" on page 126).
High level of availability and failure protection
ASR&R (Automatic Server Reconfiguration and Restart) restarts the system in
the event of an error and automatically "hides" the defective system
components.
The PDA (Prefailure Detection and Analyzing) technology from Fujitsu
Technology Solutions analyzes and monitors all components that are critical for
system reliability.
The hot-swap components provide additional failure protection. Failure
protection for the entire system is ensured by four redundant hot-swap power
supply units as well as redundant hot-swap fans.

18 Operating Manual BX900 S1
Technical data
© cognitas. Gesellschft für Technik-Dokumentation mbH 2010 Pfad: C:\Programme\FCT\tim_app\tim_local\work\RENATE\OBJ_DOKU-4946-005.fm
Server management
Server management is implemented using the ServerView Operations Manager
supplied and the PDA (Prefailure Detection and Analysis) technology from
Fujitsu. PDA reports the threat of a system error or overload at an early stage,
allowing preventive measures to be taken.
The ServerView Operations Manager enables the management of all
PRIMERGY servers in the network via a central console. The ServerView
Operations Manager supports the following functions:
●Round-the-clock monitoring, regardless of server status
●High-performance, graphical console bypass (AVR) protected by
HTTPS/SSL (128 bit)
●Remote storage via USB
●Remote power on
●Temperature monitoring of the CPU and the surrounding area
●Detailed status and error reports for processors and main memory
●Watchdog timer for Automatic Server Reconfiguration and Restart (ASR&R)
in the event that memory modules or processors fail
●Power monitoring
●End-of-life monitoring of fans with prompt notification before failure
●Watchdog timer for monitoring the operating system with ASR&R
Further information on the ServerView Operations Manager is provided in the
associated documentation.

BX900 S1 Operating Manual 19
Technical data
Service and support
PRIMERGY servers are easy to maintain and modular, thus enabling quick and
simple maintenance.
The handles and locks (touch points) on the various hot pluggable components
are colored green to ensure simple and immediate recognition.
In order to prevent the components from being damaged by incorrect handling
when they are being installed and removed, the areas of all components that
can be touched without damaging them are also marked green.
The redundant management blades and the optional remote test and
diagnostics system ServerView Remote Management allows the PRIMERGY
BX900 S1 blade servers to be serviced from a remote system. This enables
remote diagnosis for system analysis, remote configuration and remote restart
should the operating system or hardware fail.

20 Operating Manual BX900 S1
Technical data
© cognitas. Gesellschft für Technik-Dokumentation mbH 2010 Pfad: C:\Programme\FCT\tim_app\tim_local\work\RENATE\OBJ_DOKU-4946-005.fm
1.4 Notational conventions
The following notational conventions are used in this manual:
Text in italics indicates commands or menu items.
"Quotation marks" indicate names of chapters and terms that are being
emphasized.
Êdescribes activities that must be performed in the order
shown.
VCAUTION! pay particular attention to texts marked with this symbol.
Failure to observe this warning may endanger your life,
destroy the system or lead to the loss of data.
Iindicates additional information, notes and tips.
