Fujitsu SLR 50 GBYTE User manual

SLR 50/100 GBYTE
SLR 50/100 GBYTESLR 50/100 GBYTE
SLR 50/100 GBYTE
BETRIEBSANLEITUNG
BETRIEBSANLEITUNGBETRIEBSANLEITUNG
BETRIEBSANLEITUNG
OPERATING MANUAL
OPERATING MANUALOPERATING MANUAL
OPERATING MANUAL

Dieses Handbuch wurde auf Recycling-Papier gedruckt.
This manual has been printed on recycled paper.
Ce manuel est imprimé sur du papier recyclé.
Este manual ha sido impreso sobre papel reciclado.
Questo manuale è stato stampato su carta da riciclaggio.
Denna handbok är tryckt på recyclingpapper.
Dit handboek werd op recycling-papier gedrukt.
Bestell-Nr./Order No.: A26361-H583-Z100-1-7419
A26361-H583-Z100-1-7419A26361-H583-Z100-1-7419
A26361-H583-Z100-1-7419
Printed in the Federal Republic of Germany
AG 0900 09/00
A26361-H583-Z100-1-7419
SLR 50/100 GBYTE BETRIEBSANLEITUNG
OPERATING MANUAL

SLR 50/100 GBYTE
Betriebsanleitung
Operating Manual
Deutsch
En
g
lish
Ausgabe September 2000
September 2000 edition

Microsoft, MS, MS-DOS und Windows sind eingetragene Warenzeichen der Microsoft
Corporation.
Die übrigen im Buch erwähnten Software- und Hardwarebezeichnungen sind in den meisten
Fällen auch eingetragene Warenzeichen und unterliegen als solche gesetzlichen
Bestimmungen.
Copyright ã2000
Alle Rechte vorbehalten, insbesondere (auch auszugsweise) die der Übersetzung, des
Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.
Zuwiderhandlungen verpflichten zu Schadenersatz.
Alle Rechte vorbehalten, insbesondere für den Fall der Patenterteilung oder GM-Eintragung.
Liefermöglichkeiten und technische Änderungen vorbehalten.
Dieses Handbuch wurde erstellt von
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Microsoft, MS, MS-DOS and Windows are registered trademarks of Microsoft Corporation.
Other software and hardware names referred to in the manual are generally also registered
trademarks whose use is also subject to legal conditions.
Copyright ã2000
All rights, including rights of translation, reproduction by printing, copying or similar methods,
even of parts are reserved.
Offenders will be liable for damages.
All rights, including rights created by patent grant or registration of a utility model or design,
are reserved.
Delivery subject to availability. Right of technical modification reserved.
This manual was produced by
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de

A26361-H583-Z100-1-7419 English
Contents
Introduction........................................................................................................................................1
Notational conventions ..............................................................................................................1
Important notes .................................................................................................................................2
Safety........................................................................................................................................2
Manufacturer's note...................................................................................................................2
Installation.........................................................................................................................................2
Setting the jumpers....................................................................................................................3
Mounting the drive.....................................................................................................................5
Connecting the drive..................................................................................................................5
Operation...........................................................................................................................................6
Meaning of the indicators...........................................................................................................7
Handling magnetic tape cartridges.............................................................................................8
Cleaning..........................................................................................................................................10
Technical data.................................................................................................................................11

A26361-H583-Z100-1-7419 English - 1
Introduction
SLR100SLR 50/100 GBYTE is a drive for magnetic tape cartridges with a storage capacity of
50 Gbyte (without compression) or 100 Gbyte (with 2:1 compression).
The drive is an inexpensive mass storage which is especially suited for the following applications:
• Backup of hard disk drives
• Data archiving
• Data exchange
• Software distribution
• Emergency recovery
The drive has an SCSI interface of the type Ultra Wide LVD/SE (Low Voltage Differential or Single-
Ended). Therefore, in order to operate the drive the computer must have a SCSI host adapter and
the appropriate SCSI drivers must be installed.
This manual contains all the information you require to install and operate the drive.
Target group
To install the drive, you need some knowledge of hardware. Make sure you observe the instructions
in the "Important notes" chapter of your system unit's Operating Manual.
In the event of any problems occurring, please contact your sales outlet or our customer service
center.
Further information
For details of the drive mounting procedure refer to the Operating Manual or Technical Manual of
your system unit.
Information on the SCSI host adapter is contained in the Technical Manual of the SCSI host adapter
or in the Operating Manual or Technical Manual of your system unit.
For information on the required SCSI drivers and the backup software, refer to the software
documentation.
Notational conventions
The meanings of the symbols and fonts used in this manual are as follows:
!Pay particular attention to texts marked with this symbol. Failure to observe this warning
endangers your life, destroys the system, or may lead to loss of data.
i
Supplementary information, remarks and tips follow this symbol.
Ê Texts which follow this symbol describe activities that must be performed in the order shown.
"Quotation marks" indicate names of chapters, disks and terms that are being emphasized.

SLR 25/50 Gbyte
2 - English A26361-H583-Z100-1-7419
Important notes
!In this chapter you will find information regarding safety which is essential to take note of
with your drive.
Safety
This device complies with the relevant safety regulations for data processing equipment, including
electronic office machines for use in an office environment. If you have any questions, contact your
sales outlet or our customer service center.
• This device has been developed for use in approved systems with a fire-proof casing (in
accordance with IEC 950 / EN 60950).
• Note the power loss and the notes on environmental conditions in the "Important notes"
chapter of the system unit's Operating Manual.
Manufacturer's note
CE certificate
The shipped version of this drive complies with the requirements of the EC Guideline
89/336/EEC "Electromagnetic compatibility".
Compliance was tested in a typical system configuration.
When installing the drive, observe the specific installation notes in the Operating
Manual or Technical Manual of the receiving device.
Installation
!Please note the information provided in the chapter "Important notes" in the Operating
Manual of the system unit or in the manual "Safety, Guarantee and Ergonomics".
The following steps must be performed to install the drive:
• Setting the jumpers (e. g. SCSI address, parity)
• Mounting the drive
• Connecting the drive
• Installing the software required (drivers, backup program)
i
The drivers required for operating SCSI drives are either part of the operating system or
are provided with the backup software.
