Func COOEE HALF WALL WITH POWER User manual

PAGE 1
ASSEMBLY GUIDE
2 Person Lift
CONTENTS FOR Cooee Three Quarter With Power
x1 Cooee Half Wall
With Power
Tools you will need:
a.
Lay Cooee Wall on table. b.
Hang bottom end off the table
to allow for base assembly.
Min 10”[254mm]
Overhang
x1
Cooee Half Wall
With Power
x4
3/8”
Flange Nut
x4
3/8” 5” Long
Hex Bolt
x8
3/8” Washer
15/16” Spanner Quick grip7mm SpannerTwo Person
Install
CAUTION
x16
M4
Flange Nut
x2
Metal Base
Plates
x4
Lockable
Castors
x16
M4 Countersunk
Bolts
• Clear open space for install
• May need need a sturdy table.
• + 40lbs lift required
COOEE
HALF WALL
WITH POWER
1
0

PAGE 2
ASSEMBLY GUIDE
a.
Lay metal bases on Cooee Wall.
b.
Clamp with quick grip.
Ensure Holes are aligned.
COOEE
HALF WALL
WITH POWER
2
a.
Insert countersunk bolts, castors and M4
Flange nuts then tighten with 7mm Spanner.
Repeat for all bolts
b.
Ensure all bolts and castor’s are secure
4
a.
Insert 3/8 bolt, Washer and Flange Nut.
Ensure all bolts are in the same direction
1
3
x4
4
2
Torque= 45Ft-Lb
b.
Clamp with quick grip. Tighten bolts in
order and repeat to prevent one bolt
tighter than the other.
Ensure Hole’s are aligned.
3
x16

PAGE 3
ASSEMBLY GUIDE
a.
Lift Cooee Wall onto the ground. b.
Stand up and ensure Cooee Wall is
able to move and castors can be
locked.
COOEE
HALF WALL
WITH POWER
5
x1 Assembled
Cooee Half Wall With Power
2 Person Lift
• Ensure wheels are locked and stationary
when attaching Accessories.
• Cooee Wall With Power has internal wiring
and live power when plugged in.
• Do not screw or drill anywhere unless
stated on the Func Assembly guide.
• Escape routes must no be blocked.
• Disconnect Power when moving.
• Move slow, especially when crossing door
thresholds etc.
• Ensure all cables have no loops and are out of
foot traffic. (No trip hazards)
• Do not load heavy accessories on one side of the
wall, as it increase the chance of tipping.
CAUTION & WARNING STATEMENT.
