Func COOEE User manual

PAGE 1
ASSEMBLY GUIDE
2 Person Lift
CONTENTS FOR Cooee Monitor Wall
x1 Cooee Monitor Wall
Tools you will need:
a.
Lay Monitor wall on table.
Min 10”[254mm]
Overhang
x1
Monitor Wall
x4
3/8”
Flange Nut
x4
3/8” 5” Long
Hex Bolt
x8
3/8” Washer
15/16” Spanner Quick grip7mm SpannerTwo Person
Install
CAUTION
x16
M4
Flange Nut
x2
Metal Base
Plates
x4
Lockable
Castors
x16
M4 Countersunk
Bolts
• Clear open space for install
• May need need a sturdy table.
• + 65lbs lift required
COOEE
MONITOR WALL
1
0
b.
Hang bottom end off the table
to allow for base assembly.

PAGE 2
ASSEMBLY GUIDE
a.
Lay metal bases on Monitor Wall.
b.
Clamp with quick grip.
Ensure Holes are aligned.
COOEE
MONITOR WALL
2
a.
Insert countersunk bolts, castors and M4
Flange nuts then tighten with 7mm Spanner.
Repeat for all bolts
b.
Ensure all bolts and castor’s are secure
4
a.
Insert 3/8 bolt, Washer and Flange Nut.
Ensure all bolts are in the same direction
1
3
x4
4
2
Torque= 45Ft-Lb
b.
Clamp with quick grip. Tighten bolts in
order and repeat to prevent one bolt
tighter than the other.
Ensure Hole’s are aligned.
3
x16

PAGE 3
ASSEMBLY GUIDE
a.
Lift Monitor Wall onto the ground. b.
Stand up and ensure Tool is able
to move and castors can be locked.
a.
Mount Fixed TV Mount in the Blue area above.
Avoid damaging cables while drilling or
screwing.
Mounting screws must not exceed 1.5in long.
b.
Typical TV Mount shown above (this is a
representation only.
COOEE
MONITOR WALL
5
6
x1 Assembled
Cooee Monitor Wall
2 Person Lift
MOUNTING AREA
DISCONNECT POWER BEFORE DRILLING

PAGE 4
ASSEMBLY GUIDE
COOEE
MONITOR WALL
RECOMMENDED TV MOUNT.
Requirements
Size (mounting area)
Max Width 26in[660mm]
Max Height 8in[203m]
Max Depth 1.5in(38.1mm]
Weight
Max Weight 6.6lbs[3kgs]
Requirements
Size (50in TV)
Max Width 44in[1117.6mm]
Max Height 27.8in[706.12m]
Max Depth 1.5in(38.1mm]
Weight
Max Weight 21lbs[9.5kgs]
Requirements
Installer to use TV mount screws and
bolts provided by the TV Mount
manufacturer.
TV mount is be installed onto 0.5in-
[12.7mm] MDF construction. Installer
should follow TV Mount Instruction
supplied by Manufacturer.
Scan the QR with your smart phone
Scan the QR with your smart phone
Scan the QR with your smart phone
• Ensure wheel are locked and stationary
when attaching TV Mount & Accessories.
• Monitor Wall must be stored/displayed on
level surface.
• Monitor Wall has internal wiring and live
power when plugged in.
• Do not screw or drill anywhere unless
stated on the Func Assembly guide.
• Recommend TV Mount to be as slim as
possible to reduce chances of tipping.
• Escape routes must no be blocked.
• Disconnect Power when moving
• Move slowing, especially when crossing door
thresholds etc.
• Ensure all cables have no loops and are out
of foot traffic. (No trip hazards)
• Do not load one side of the wall heavy acces-
sories, as it increase the chance of tipping.
• Mount screws should be no longer than
1.5in[38.1]
TV MOUNT INSTALLATION
GUIDE
RECOMMENDED SMART TV
CAUTION & WARNING STATEMENT.
