Furniture of America CM1927-1 Installation guide

1 / 15
MODEL #
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
EASY DIFFICULT
2 - People
(Included)
Allen Wrench
Recommended
Phillips
Screwdriver
(Not Included)
CM1927
VERSION # 20-02-17

Thank you for your purchase!
We hope you enjoy this new addition to your home for many years to come.
Our commitment to providing quality products does not simply end when you purchase
our product. We fully stand behind our products from start to finish. Our customer
service department is available Monday – Friday 8:30 AM – 5:30 PM Pacific and can
help with assembly questions as well as, if necessary, replacing damaged or missing
parts. To help expedite our service, please have these assembly instructions readily
available, along with your order receipt.
E-MAIL
[e-mail]
Furniture of America
WEBSITE
www.foagroup.com
FOA Intro
FurnitureOfAmerica
foagroup
Monday to Friday
8:30AM- 5:30PM (PST)
Consumer Hotline
Toll-Free 1-888-980-5122
Prep Time!
Please review the assembly instructions and all
diagrams prior to assembling. Arrange parts as
recommended on Page 7 and group identical
hardware together to make assembling easier.
Check out our Quick Tips!
We recommend reviewing the pre-assembly
handouts. Even experts need a refresher now and
then!
Are you missing anything?
Double-check all parts, hardware and
accessories listed on Page 6 are
accounted for.
Should we send any replacements?
Are there any irregularities or flaws in the
parts? We can send replacements!
CHECK
BEFORE STARTING
2/ XXXXXXX15

PRE ASSEMBLY
INTRODUCTION
Suitable Location
Assembling near the area of the
intended location is highly
recommended.
Avoid Scratches
Use cardboard, blankets or a
carpeted area while assembling
furniture to prevent scratches.
Teamwork
ALWAYS have at least two people
to help with transporting and
assembling the product to avoid
potential injury and/or damage.
Flat Surface
Make sure the furniture rests on
a flat and level surface with each
leg evenly touching the floor.
Sufficient Space
Make sure you have enough
space to move around during the
assembly.
We understand building ready-to-assemble furniture can be a challenging
experience for some. To help avoid confusion, we have provided some helpful
tips that may speed up the process.
3/ XXXXXXX15

4 / XXXXXXX15

DAYBED
5 / 15
#1 1pc #2 1pc #3 1pc
#5 1pc #6 2pcs #7 1pc
#4 1pc
#8 1pc
#9 3pcs #10 3pcs
CM1927
#11 3pcs #12 3pcs
#13 3pcs #14 3pcs
Headboard (L) Headboard (R)
Front Drawer Panel
Crossbar
#15 1set
Guardrail Front Trundle Panel
Back Trundle Panel End Trundle Panel Top Trundle Support Bottom Trundle Support
Drawer Panel (L) Drawer Panel (R)
Back Drawer Panel Slat Kit (13pcs) Bottom Drawer Panel

#A 4pcs #B 4pcs #C 6pcs #D 20pcs
#E 12pcs #F 63pcs #G 3pcs
6 / 15
#H 6pcs
Bolt
Ø1/4" x 3-1/8"
#I 3pcs
Scroll Bar
Wood Dowel
Ø6 x 30mm
Barrel Nut Bolt
Ø1/4" x 1-3/8" Bolt
Ø1/4" x 1-3/16"
Screw
#4x30mm Screw #3x15mm
#J 3pcs #K 3pcs #L 1pc
Allen Wrench 4mm
Screw
#3x12mm
Bolt
Ø5/32" x 25mm Holder

7 / 15
Exploded View
#1
#2
#3
#13
#6
#6
#15
#7
#9
#8
#4
#12
#10
#5
#11
#9
#14

Carton Disignation Part Hardware
CM1927 is packed in 2 cases
8 / 15
#1
CM1927-2
CM1927-1
Headboard (L)
#Ax4pcs
#Bx4pcs
#2
Headboard (R)
#3
Guardrail
#4
Front Trundle Panel
#5
#6
#7
#9
Crossbar
Back Trundle Panel
End Trundle Panel
Top Trundle Support
Front Drawer Panel #10
Drawer Panel (L) #11
#12
Drawer Panel (R)
Back Drawer Panel #13
Bottom Drawer Panel #14
Slat Kit (13pcs) #15
#Cx6pcs
#Dx20pcs
#Ex12pcs
#Fx63pcs
#Gx3pcs
#Hx6pcs
#Jx3pcs
#Kx3pcs
#Lx1pc
#8
Bottom Trundle Support
#I
Scroll Bar

Carton Disignation Part Hardware
CM1927 is packed in 2 cases
9 / 15
CM1927-2 Bottom Drawer Panel #14
Slat Kit (13pcs) #15

ASSEMBLY INSTRUCTIONS
1
2
10 / 15
Part #1 x 1pc
Hardware #A x 4pcs
Hardware #B x 4pcs
Hardware #D x 8pcs
Part #2 x 1pc
Part #4 x 1pc
Part #3 x 1pc
Part #5 x 1pc
#1
#2
#3
#L
#B
#A
#L
#D
#6
#4
#5
#6
Part #6 x 2pcs
Align guardrail (#3) to headboards (#1,2), then
secure by using bolts (#A).
Align trundle panels (#6) to the front and back
trundle panels (#4,5). Secure by using bolts
(#D).

ASSEMBLY INSTRUCTIONS
3
4
11 / 15
Part #7 x 1pc
Hardware #D x 4pcs
Part #9 x 3pcs
Part #8 x 1pc
Hardware #C x 6pcs
#7
#8
#L
#D
#L
#C
#9
Align trundle supports (#7,8) to the trundle side panels, then secure by
using bolts (#D).
Align crossbars (#9) to the trundle, then secure by using
bolts (#C).

ASSEMBLY INSTRUCTIONS
5
6
12 / 15
Part
Hardware #E x 4pcs
Part #10 x 1pc
Hardware #F x 4pcs
#13 x 1pc
X3
X3
Part #11 x 1pc
Part #12 x 1pc
Part #14 x 1pc
Hardware #F x 4pcs
#E
#F
#12 #10
#11
#14
#F
#13
Insert dowels (#E) to front drawer panel (#10),
then align side panels (#11,12) and bottom
panel (#14) to the front panel (#10). Secure by
screwing screws (#F) directly to front panel
(#10). There will be no pre-drilled screw holes
for front panel (#10).
Align back drawer panel (#13) to the drawer side
panels, then secure by using screws (#F).

ASSEMBLY INSTRUCTIONS
7
8
13 / 15
Hardware #G x 1pc
Hardware #J x 1pc
#I
#H
#G
Hardware #H x 2pcs
Hardware #I x 1pc
X3
X3
#J
#K
Hardware #K x 1pc
Align scroll bar (#I) to the bottom of the drawer,
then secure by using screws (#H,G) as shown in
the diagram.
Secure knob (#K) onto drawer by using bolts
(#J).

14 / 15
ASSEMBLY INSTRUCTIONS
9
10
#D
#L
Hardware #D x 8pcs
#1
#2
#6
#6
Align trundle frame to the headboard (#1,2), then secure by using bolts (#D).
Align drawers to the railing, then
swiftly with slight force, push the
drawer in to lock.

15 / 15
ASSEMBLY INSTRUCTIONS
11
12
#15
Part #15 x 1set
Hardware #F x 39pcs
#F
Align slats (#15) to the product, then secure by
using screws (#F).
