Installation Manual
ECDIS
Model FMD-3200/FMD-3300/FMD-3200-BB
(ELECTRONIC CHART DISPLAY AND INFORMATION SYSTEM)
SAFETY INSTRUCTIONS ................................................................................................ i
SYSTEM CONFIGURATION ........................................................................................... ii
EQUIPMENT LISTS......................................................................................................... v
1. MOUNTING..............................................................................................................1-1
1.1 Monitor Unit........................................................................................................................1-1
1.2 ECDIS Control Unit/Track Control Unit..............................................................................1-1
1.3 Processor Unit ...................................................................................................................1-4
1.4 Sensor Adapters (option)...................................................................................................1-6
1.5 Intelligent HUB (option)......................................................................................................1-7
1.6 Switching HUB (option)......................................................................................................1-8
1.7 Radar Connection Box (option)..........................................................................................1-8
2. WIRING....................................................................................................................2-1
2.1 Processor Unit ...................................................................................................................2-3
2.2 Monitor Unit......................................................................................................................2-13
2.3 Sensor Adapters (option).................................................................................................2-15
2.4 Intelligent HUB (option)....................................................................................................2-32
2.5 How to Extend the Control Unit Cable (option) ................................................................2-33
2.6 Radar Connection Box (option)........................................................................................2-37
2.7 Raytheon Anschutz Autopilot NP-5400............................................................................2-41
3. ECN-303/304 (OPTION) ..........................................................................................3-1
3.1 How to Install the Console .................................................................................................3-1
3.2 How to Dismount the Rack for the Processor Unit.............................................................3-2
3.3 How to Connect External Cables.......................................................................................3-4
3.4 How to Mount the Rack for the Processor Unit..................................................................3-6
4. SETTING UP THE EQUIPMENT .............................................................................4-1
APPENDIX 1JIS CABLE GUIDE...............................................................................AP-1
APPENDIX 2ROD TERMINALS................................................................................AP-2
APPENDIX 3RA/IF BOARD JUMPER VALUES.......................................................AP-8
APPENDIX 4ALERT LIST .........................................................................................AP-9
PACKING LIST(S) ....................................................................................................... A-1
OUTLINE DRAWING(S) .............................................................................................. D-1
INTERCONNECTION DIAGRAM(S) ........................................................................... S-1

The paper used in this manual
is elemental chlorine free.
・FURUNO Authorized Distributor/Dealer
9 52 Ashihara cho,
Nishinomiya, 662 8580, JAPAN
A
:
APR
2012
.
Printed in Japan
All rights reserved.
P
:
SEP
.
10, 2021
Pub. No.
IME-44730-P
(
DAMI
)
FMD-3200/3200BB/3300
0 0 0 1 9 5 3 0 6 1 3

i
SAFETY INSTRUCTIONS
Be sure that the power supply is
compatible with the voltage rating of
the equipment.
Connection of an incorrect power supply
can cause fire or damage the equipment.
Use only the specified power cable.
Fire or damage to the equipment can result
if a different cable is used.
Attach protective earth
securely to the ship's body.
The protective earth
(grounding) is required for the
AC power supply to prevent
electrical shock.
Do not open the equipment
unless totally familiar with
electrical circuits and
service manual.
Only qualified personnel
should work inside the
equipment.
WARNING
Turn off the power at the mains switch-
board before beginning the installation.
Fire, electrical shock or serious injury can
result if the power is left on or is applied
while the equipment is being installed.
ELECTRICAL
SHOCK
HAZARD CAUTION
Observe the following compass safe
distances to prevent deviation of a
magnetic compass:
Standard
compass
Monitor Unit
(MU-190) 1.65 m 1.05 m
Monitor Unit
(MU-231) 2.55 m 1.55 m
Trackball Control
Unit (RCU-026) 0.30 m 0.30 m
Steering
compass
Intelligent HUB
(HUB-3000)
2.05 m 1.35 m
1.20 m 0.75 m
Processor
Unit (EC-3000) 2.40 m 1.55 m
Sensor Adapter
(MC-3000S)
ECDIS Control
Unit (RCU-024) 0.30 m 0.30 m
0.75 m 0.50 m
Sensor Adapter
(MC-3010A)
Sensor Adapter
(MC-3020D)
Sensor Adapter
(MC-3030D)
1.05 m 0.70 m
0.90 m 0.60 m
Mandatory Action
Prohibitive Action
WARNING
Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not avoided,
can result in minor or moderate injury.
Warning, Caution
The installer of the equipment must read the safety instructions before attempting to
install the equipment.
WARNING
Do not install the monitor unit,
processor unit or control unit where
they may get wet from rain or
water splash, or in a dusty environment.
Water in the units can result in fire,
electrical shock, or damage the equipment.
Switching HUB
(HUB-100) 1.00 m 0.60 m
Radar Connection
Box (RCB-002) 1.45 m 0.95 m
Monitor Unit
(MU-270W) 0.90 m 0.55 m

ii
SYSTEM CONFIGURATION
System with one processor unit
*1: For the monitors available for connection with the ECDIS, see page iv.
*2: When the network complies with IEC 61162-450 Ed.1, the Switching Hub HUB-100 can also
be used.
Note: When using the EC-3000 as an AMS device, connect an emergency power supply, in ad-
dition to the main power supply.
Dashed lines indicate
optional or local supply
equipment.
Intelligent
HUB
HUB-3000
*2
Sensor Adapter
MC-3010A
Sensor Adapter
MC-3020D
Sensor Adapter
MC-3030D
Serial interface
Analog interface
Digital IN interface
Digital OUT interface
Category of units
All units protected
from the weather.
Sensor Adapter
MC-3000S
EC-3000
PROCESSOR
UNIT
100-115/220-230 VAC,
1ø, 50/60 Hz
ECDIS
Control Unit
RCU-024
or
Trackball
Control Unit
RCU-026
ECDIS
Control Unit
RCU-024
or
Trackball
Control Unit
RCU-026
(Max. 2)
100-115/200-230 VAC
1ø, 50/60 Hz
24 VDC
Intelligent HUB
HUB-3000
Radar 1
Radar Connection Box
RCB-002 Radar 2
100-230 VAC
Gateway network equipment
(radar, ECDIS, etc.)
AC/DC Power
Supply Unit
PR-240/241
IF Signal:
- Serial Interface ×4 (IEC 61162-1/2)
- Serial Interface ×4 (IEC 61162-1)
- Digital Out ×6
(power fail/system fail/ NO ×2, NC ×2)
- Digital In (ack in)
Monitor Unit
*1
(Conning Monitor)
Monitor Unit
*1
(Main Monitor)
Monitor Unit
*1
(Sub Monitor)

SYSTEM CONFIGURATION
iii
System with two processor units
*1: For the monitors available for connection with the ECDIS, see page iv.
*2: When the network complies with IEC 61162-450 Ed.1, the Switching Hub HUB-100 can also
be used.
Note: When using the EC-3000 as an AMS device, connect an emergency power supply, in ad-
dition to the main power supply.
EC-3000
PROCESSOR
UNIT
Dashed lines indicate
optional or local supply
equipment.
100-115/
220-230 VAC,
1ø, 50/60 Hz
Serial
interface
Analog
interface
Digital IN
interface
EC-3000
PROCESSOR
UNIT
Digital OUT
interface
Category of units
All units protected
from the weather.
Sensor Adapter
MC-3000S
Sensor Adapter
MC-3010A
Sensor Adapter
MC-3020D
Sensor Adapter
MC-3030D
IF Signal:
(Same as left.)
ECDIS
Control Unit
RCU-024
or
Trackball
Control Unit
RCU-026
ECDIS
Control Unit
RCU-024
or
Trackball
Control Unit
RCU-026
(Max. 2)
ECDIS
Control Unit
RCU-024
or
Trackball
Control Unit
RCU-026
ECDIS
Control Unit
RCU-024
or
Trackball
Control Unit
RCU-026
(Max. 2)
Gateway network
equipment
(radar, ECDIS, etc.)
Intelligent HUB
HUB-3000
100-115/
220-230 VAC,
1ø, 50/60 Hz
100-230 VAC
Radar 1
Radar Connection Box
RCB-002
Radar 2
100-115/200-230 VAC
1ø, 50/60 Hz
24 VDC
AC/DC Power
Supply Unit
PR-240/241
IF Signal:
- Serial Interface ×4
(IEC 61162-1/2)
- Serial Interface ×4
(IEC 61162-1)
- Digital Out ×6
(power fail/system fail/
NO ×2, NC ×2)
- Digital In (ack in)
Monitor Unit
*1
(Conning Monitor)
Monitor Unit
*1
(Main Monitor)
Monitor Unit
*1
(Sub Monitor) Monitor Unit
*1
(Conning Monitor)
Monitor Unit
*1
(Main Monitor)
Monitor Unit
*1
(Sub Monitor)
Intelligent HUB
HUB-3000
*2

SYSTEM CONFIGURATION
iv
Monitors compatible with the ECDIS
The following monitors are available for connection with the ECDIS:
*1: Standard supply for FMD-3200.
*2: Standard supply for FMD-3300.
*3: Do not connect this monitor to the DVI1 port. Connection to ports other than the DVI1 port is
available.
Maker Model Viewing distance
FURUNO
MU-190*11.02 m
MU-231*21.2 m
MU-201CE 1.0759 m
MU-231CE 1.0138 m
MU-270W*21.02 m
Hatteland
Technology
JH19T14 FUD 1.011 m
JH20T17 FUD 0.878 m
JH23T12 FUD*31.011 m
JH23T14 FUD 1.011 m
JH26T11 MMD*30.985 m
HD19T21 MMD*31.010 m
HD19T22 FUD 1.010 m
HD24T21 MMD*30.951 m
HD24T22 FUD 0.951 m
HD26T21 MMD 0.985 m
HD26T22 MMD*30.985 m
HD26T22 FUD 0.985 m
HD27T22 FUD 1.070 m
HD32T22 FUD 1.268 m
HD55T22 FUD 2.164 m
North Invent WA270-01.MON.01 1.02 m
WA460-01.MON.01 1.82 m

v
EQUIPMENT LISTS
Standard Supply
Console Type
Optional Supply
Name Type Code No. Qty Remarks
Monitor Unit MU-190 -
1
For FMD-3200, 19-inch
MU-231 - For FMD-3300, 23.1-inch
MU-270W - For FMD-3300, 27-inch
Processor Unit EC-3000 - 1
ECDIS Control Unit RCU-024 - 1
Trackball Control Unit RCU-026 - 1
Installation Materials CP24-02100 000-020-557 1 CP24-02101 and cables
CP24-02201 001-170-810 1 For RCU-024
CP24-02301 001-170-910 1 For RCU-026
Accessories FP24-00602 001-258-610 1 For EC-3000
FP24-00701 001-170-820 1 For RCU-024
FP24-00801 001-170-920 1 For RCU-026
Spare Parts SP24-00601 001-170-660 1 For 100VAC
SP24-00602 001-170-670 1 For 220VAC
Name Type Code No. Qty Remarks
Standard
Console
ECN-303 -
1
Built-in type, monitor unit: MU-231
ECN-304 - Built-in type, monitor unit: MU-190
ECN-319 - Stand-alone type, monitor unit: MU-190
ECN-323 - Stand-alone type, monitor unit: MU-231
ECN-327 - Stand-alone type, monitor unit: MU-270W
Name Type Code No. Remarks
Sensor Adapter MC-3000S - Serial IN/OUT type
MC-3010A - Analog IN
MC-3020D - Digital IN
MC-3030D - Digital OUT
Radar Connection
Box RCB-002 - For connection of external radar
Intelligent HUB HUB-3000 -
Switching HUB HUB-100 -
NOTICE
At least one AMS device must be installed
in the navigation equipment. This device
can operate as an AMS device as an
optional function. When connecting to INS,
do not use this device as an AMS device.

EQUIPMENT LISTS
vi
AC/DC Power
Supply Unit
PR-240 -
PR-241 -
Ferrite Core OP86-11 001-594-450 For PR-241
Monitor Unit MU-190 - 19-inch display
MU-231 - 23.1-inch display
MU-270W - 27-inch display
HD26T22-FUD-MA4-
FAGA -26-inch display
ECDIS Control Unit RCU-024 -
Trackball Control
Unit RCU-026 -
Bracket Assembly OP26-5 000-016-270 For MU-190, w/knobs
OP26-15 001-116-730 For MU-231
OP26-30 001-439-060 For MU-270W
IPX2 Kit OP24-23 001-171-780 For EC-3000
Flush Mount OP24-24 001-171-790 For RCU-024
OP24-27 001-171-820 For RCU-026
Connection Stand
(19) OP24-25 001-171-800 For RCU-024, FMD-3200
Connection Stand
(23) OP24-26 001-171-810 For RCU-024, FMD-3300
Case Gasket OP24-28 001-169-970 For MC-3000S
OP24-29 001-169-960 For MC-3010A/3020D/3030D
Hood Assembly OP26-6 001-080-930 For MU-190
OP26-16 001-116-740-01 For MU-231
Flush Mount Kit OP26-12 001-116-280 For MU-190
OP26-13 001-116-290 For two MU-190s
OP26-18 000-017-273 For two MU-231s
OP26-14 001-116-300 For three MU-190s
OP26-19 000-017-274 For three MU-231s
OP26-17 001-116-750 For MU-231
Flush Mount
Assembly (Rear) OP26-31 001-439-070 For MU-270W
Mounting Bracket OP26-21 001-139-310 For MU-190
Monitor Replace-
ment Kit
OP26-22 001-139-320 For MU-190, flush mounting
OP26-23 001-139-360 For MU-190, desktop mounting
OP26-26 001-139-390 For MU-190, hood
OP26-27 001-139-570 For MU-231, desktop mounting
Control Unit
Replacement Kit OP24-31 001-181-700 For RCU-024
Hood Assembly OP26-24 001-139-370 For MU-190
OP26-25 001-139-380-01 For MU-231
Hood Assembly
(Front) OP26-32 001-439-090 For MU-270W
Hood Assembly
(Rear) OP26-33 001-439-110 For MU-270W
Connection Stand
(27) OP26-34 001-462-860 For MU-270W
Terminal Opener OP24-33 001-188-850
Name Type Code No. Remarks

EQUIPMENT LISTS
vii
EC-3000 Attach-
ment Kit OP24-36 001-258-180 For EC-3000
Program Install
Software OP24-37 001-258-590
Replacement Kit OP24-50 000-027-446
Unit Mounting Base OP24-51 001-461-600 For ECN-319/323/327
FAN-LED Kit OP24-052 001-462-730 For ECN-319/323/327
Dust Cover 26-007-1201 001-116-260-10 For MU-190
26-007-2141 001-121-240-10 For MU-231
26-009-1093 001-439-120 For MU-270W
03-163-7271 001-121-230-10 For console type
Installation
Materials CP03-28900 000-082-658 LAN cable for sensor adapter, 10 m
CP03-28910 000-082-659 LAN cable for sensor adapter, 20
m
CP03-28920 000-082-660 LAN cable for sensor adapter, 30
m
CP24-02900 001-208-050 LAN cable for HUB-3000, 10 m
CP24-02910 001-208-060 LAN cable for HUB-3000, 20 m
CP24-02920 001-208-070 LAN cable for HUB-3000, 30 m
Connector CP03-28901 008-542-460
Spare Parts SP03-15001 001-042-330 For HUB-100
SP24-00801 001-235-320 For HUB-3000
Hand Grip
Assembly FP03-09840 008-535-570 For MU-190/231/270W
Name Type Code No. Remarks

EQUIPMENT LISTS
viii
Cable Assy. DSUB9P-X2-L5M 001-188-260 For monitor unit, 5 m
DSUB9P-X2-L5M-WP 001-207-890 For monitor unit, 5 m, waterproof
type
DSUB9P-X2-L10M 001-188-270 For monitor unit, 10 m
DSUB9P-X2-L10M-WP 001-207-900 For monitor unit, 10 m, water-
proof type
DSUB9P-X2-A-L5M 001-252-580 Brightness control cable for mon-
itor unit, 5 m
DSUB9P-X2-A-L10M 001-252-590 Brightness control cable for mon-
itor unit, 10 m
MC1.5-W-L600 001-187-470-10 Between sensor adapters, 0.6 m
MC1.5-W-L1000 001-187-480-10 Between sensor adapters, 1 m
MC1.5-W-L2000 001-187-490-10 Between sensor adapters, 2 m
MC1.5-W-L3000 001-187-500-10 Between sensor adapters, 3 m
TET-16-045A-2(L5M) 000-194-754-10 For RCU-024, 5 m
TET-16-045A-3(L10M) 000-194-755-10 For RCU-024, 10 m
TET-16-045A-4(L20M) 000-194-756-10 For RCU-024, 20 m
TET-16-045A-5(L30M) 000-194-757-10 For RCU-024, 30 m
6TPSH-XH12X2-
L5.0SP2 001-186-310-10 For RCU-026, 5 m
6TPSH-XH12X2-
L10SP2 001-186-320-10 For RCU-026, 10 m
6TPSH-XH12X2-
L20SP2 001-186-330-10 For RCU-026, 20 m
6TPSH-XH12X2-
L30SP2 001-186-340-10 For RCU-026, 30 m
DVI-D/D S-LINK 5M 001-132-960-10 For monitor unit, 5 m
DVI-D/D S-LINK 10M 001-133-980-10 For MU-190, 10 m
Cable Assy.
(con’t.) OP24-32 001-188-300 USB cable (between processor and control units), 5 m
MJ-A10SPF0020A-
050+ 001-283-370 Cable between RCB-002 and ex- ternal radar, 5 m
MJ-A10SPF0020A-
100+ 001-283-380 Cable between RCB-002 and ex- ternal radar, 10 m
MJ-A10SPF0020A-
200+ 001-283-390 Cable between RCB-002 and ex- ternal radar, 20 m
MJ-A10SPF0020A-
300+ 001-283-400 Cable between RCB-002 and ex- ternal radar, 30 m
AI.14-8AI.34-6L430 001-460-190 For ECN-319/323/327, cable be-
tween MC-3010A/3020D/3030D
IOK-V0024-2 001-460-210
For ECN-319/323/327, cable be-
tween HUB-3000 and processor
unit
Operator’s Manual OME-44730-* 000-176-125-** Hard copy manual, English
OMJ-44730-* 000-176-124-** Hard copy manual, Japanese
LOP Instruction
Manual E42-01411-* 000-190-356-** Hard copy manual, English
Radar Instruction
Manual E42-01502-* 000-190-843-** Hard copy manual, English
Crimping Tool CRIMPFOX10S 001-206-920 For ferrule
Name Type Code No. Remarks

1-1
1. MOUNTING
1.1 Monitor Unit
To mount the monitor unit, see the operator’s manual supplied with the monitor unit.
Make sure that the ground wire is connected between the earth terminal on the chas-
sis and the ship’s earth.
1.2 ECDIS Control Unit/Track Control Unit
The control units can be mounted on a desktop, with or without the KB fixing metal
(supplied), which mounts the control units at an angle. The control unit also can be
mounted in a console panel using the optional kit.
Note: The control unit RCU-024 can be used instead of the RCU-018 (for FEA-2xx7)
mounted in the connection stand (OP03-184 or OP26-20) using the option OP24-31.
Mounting considerations
When you select a mounting location, keep in mind the following points:
• Select a location where the control unit can be operated conventionally.
• Locate the unit away from heat sources because of heat that can build up inside the
cabinet.
• Locate the equipment away from places subject to water splash and rain.
• Leave sufficient space for maintenance and service, referring to the outline draw-
ings at the back of this manual.
Note: The outline drawing number for the ECDIS control unit (RCU-024) is different
depending on the serial number, as shown below:
• “199999” or earlier: See “C4473-G02” to “C4473-G04”.
• “200001” or later: See “C4473-G18” to “C4473-G20”.
• Determine the mounting location considering the length of the signal cable between
the control unit and the processor unit.
• A magnetic compass will be affected if the control unit is placed too close to the
magnetic compass. Observe the compass safe distances on page i to prevent com-
pass malfunction.
NOTICE
Do not apply paint, anti-corrosive sealant or contact
spray to coating or plastic parts of the equipment.
Those items contain organic solvents that can damage
coating and plastic parts, especially plastic connectors.

1. MOUNTING
1-2
• Make sure that the ground wire is
connected between the earth termi-
nal on the chassis and the ship’s
earth.
• Fasten the USB cable with the cable
tie (supplied) to the cable routing
peg.
1.2.1 Desktop Mounting
Fixing with KB fixing metal
1. Fix the KB fixing metal to the bottom of the control unit.
2. Fix the unit with self-tapping screws (5x20, local supply).
Fixing without KB fixing metal
1. Drill four mounting holes of 5 mm (RCU-024) or 4 mm (RCU-026) diameter refer-
ring to the outline drawing at the back of this manual.
2. Fix the control unit with four screws (RCU-024: M4, RCU-026: M3) from under
side of the desktop. (The M4 screws with a sufficient length for the thickness of
the desktop should be provided locally.)
USB cable
Ex. ECDIS control unit, bottom view
Cable tie
Cable routing peg
KB fixing metal
RCU-026RCU-024
RCU-026RCU-025

1. MOUNTING
1-3
1.2.2 Flush mounting
Use the optional flush mount kit to mount the control unit in a console panel.
Flush mount kits for RCU-024/025
1. Prepare a cutout in the mounting location as shown on below.
2. Set the control unit to the cutout.
3. Attach the mounting plate to the control unit with four screws from the rear side.
4. Screw the wing screw to each mounting plate and then insert hex. bolt to each
wing screw.
5. Fasten each wing screw and then fasten the wing nuts as shown in figure below.
Side view of control units
Control Unit Type Code No.
RCU-024 OP24-24 001-171-790
RCU-026 OP24-27 001-171-820
Outline of unit
398
180
388±2
170±2
RCU-024 RCU-026
120
Outline of unit
180
170±2
110±2
RCU-024
RCU-026

1. MOUNTING
1-4
1.3 Processor Unit
1.3.1 Mounting considerations
When you select a mounting location, keep in mind the following points:
• Locate the processor unit away from heat sources because of heat that can build
up inside the cabinet.
• The vibration at the mounting location should be minimum.
• Locate the equipment away from places subject to water splash and rain.
• Make the service clearance of 100 mm in front of the vent hole (left side).
• Leave sufficient space at the sides and rear of the unit to facilitate maintenance.
• Make sure that the ground wire is connected between the earth terminal on the
chassis and the ship’s earth.
• A magnetic compass will be affected if the processor unit is placed too close to the
magnetic compass. Observe the compass safe distances on page i to prevent com-
pass malfunction.
• Do not remove the dummy plate to prevent the wrong operation of the power switch.
The items behind the plate are for use by the serviceman.
• Mount the processor unit on the floor, or on a bulkhead with the following direction
(horizontal), because of the DVD drive unit.
Keep the
dummy
plate in this
position.
OK
UP

1. MOUNTING
1-5
1.3.2 How to mount the processor unit
Use six bolts (M6, local supply) to mount the processor unit.
1. Use 10 binding head screws (M4x8, supplied) to attach the chassis bases 1 and
2 to the processor unit.
Note: For bulkhead mounting, attach the chassis base 2 so that the notches on it
are facing the deck.
2. Use six bolts (M6, local supply) to fix the processor unit.
Chassis base 1
Chassis base 2
Notches Notches
: Bolt holes (notches)

1. MOUNTING
1-6
1.4 Sensor Adapters (option)
Mounting considerations
When you select a mounting location, keep in mind the following points:
• Locate the adapter away from heat sources because of heat that can build up inside
the cabinet.
• The vibration should be minimal.
• Locate the equipment away from places subject to water splash and rain.
• Make sure that the ground wire is connected between the earth terminal on chassis
and the ship’s earth.
• Leave sufficient space at the sides and rear of the unit to facilitate maintenance.
• A magnetic compass will be affected if the adapter is placed too close to the mag-
netic compass. Observe the compass safe distances at the front of this manual to
prevent interference to a magnetic compass.
• Select the mounting location considering the numbers of the sensor adapters con-
nected.
Maximum eight MC-3000S can be connected to a sensor network (for the redun-
dant connection:16).
Maximum 10 sensor adapters (MC-3010A/3020D/3030D) can be connected to a
MC-3000S. However, note that five MC-3010A can be connected.
• Select the mounting location so that the length of cables among the sensor adapters
(MC-3000S, 3010A, 3020D and 3030D) is less than 6 m. If the length is more than
6 m, the equipment may not work properly.
How to mount the sensor adapter
1. Unfasten four binding screws to remove the cover from the sensor adapter.
2. Fasten four self-tapping screws (4x20, supplied) to fix the sensor adapter.
3. Reattach the cover.
MC-3000S MC-3010A/3020D/3030D

1. MOUNTING
1-7
1.5 Intelligent HUB (option)
Use the optional Intelligent HUB (HUB-3000) to connect gateway network or sensor
network. Do not use the HUB to connect a network other than shipboard LAN gateway
network or sensor network. Note that a commercial PC cannot be connected in this
network, other than for the maintenance.
Mounting considerations
When you select a mounting location, keep in mind the following points:
• Locate the adapter away from heat sources because of heat that can build up inside
the cabinet.
• The vibration should be minimal.
• Locate the equipment away from places subject to water splash and rain.
• Make sure that the ground wire is connected between the earth terminal on chassis
and the ship’s earth.
• Leave sufficient space at the sides and rear of the unit to facilitate maintenance.
• A magnetic compass will be affected if the adapter is placed too close to the mag-
netic compass. Observe the compass safe distances at the front of this manual to
prevent interference to a magnetic compass.
How to mount the HUB-3000
1. Use two binding screws (M3x6, supplied) to attach the cable clamp (supplied) to
the bottom of the HUB-3000.
HUB-3000, bottom view
Cable clamp
Binding screw
(M3x6, 2 pcs)

1. MOUNTING
1-8
2. Fasten four self-tapping screws (4x20, supplied) to fix the unit.
1.6 Switching HUB (option)
Use this Switching HUB to connect the sensor network that complies with IEC 61162-
450 Ed.1. Do not use the HUB to connect a network other than shipboard LAN sensor
network. Note that a commercial PC cannot be connected in this network, other than
for the maintenance. The total length of all cables connected to the hub is 6 m.
For the mounting procedures, see the operator’s manual for HUB-100 (Pub. No.OMC-
35191).
Mounting considerations
When you select a mounting location, keep in mind the following points:
• Locate the adapter away from heat sources because of heat that can build up inside
the cabinet.
• The vibration should be minimal.
• Locate the equipment away from places subject to water splash and rain.
• Make sure that the ground wire is connected between the earth terminal on chassis
and the ship’s earth.
• Leave sufficient space at the sides and rear of the unit to facilitate maintenance.
• A magnetic compass will be affected if the adapter is placed too close to the mag-
netic compass. Observe the compass safe distances at the front of this manual to
prevent compass malfunctions.
1.7 Radar Connection Box (option)
You can display signals from up to two external radars on the chart display by using
the RCB-002. The RCB-002 must be connected via the Gateway Network.
Mounting considerations
Keep the following points in mind when selection a mounting location:
: Screw holes

1. MOUNTING
1-9
• Locate the unit away from heat sources. Heat can build up inside the cabinet, caus-
ing undue wear to electrical components.
• Take into account the length of the cables to connected to the unit when selecting
an installation location.
• Fix the unit firmly so that rough seas and vibrations do not cause the unit to move
in any manner.
• Locate the unit away from areas which may be subject to splash or rain.
• Leave sufficient space at the sides and rear of the unit to facilitate maintenance.
• A magnetic compass will be affected if the equipment is placed too close to the
magnetic compass. Observe the compass safe distances at the front of this manual
to prevent interference to a magnetic compass.
• Vibration at the mounting location should be minimum.
1. Referring to the outline drawing at the back of this manual, drill four holes (φ5×20)
in the mounting location.
2. Fix the unit firmly in place using φ5×20 self-tapping screws.
Connectors facing downwwards
Mounting holes

1. MOUNTING
1-10
This page is intentionally left blank.
