Gama Sonic 20B50033 User manual

SILO BULB SOLAR LIGHT
Part #: 20B50033
Version 1.1
Instruction Manual
US Patent #9458970

page 2
Thank you for your purchase! GAMA SONIC®solar charged lights are brighter and last
all night with a typical solar charge. Unique design, superior light output and numerous
installation options confirm the outstanding value of our product. GAMA SONIC®has
been recognized as a worldwide leader in the lighting industry for over 20 years.
Technical Assistance/Warranty Claims/Replacement Parts
Toll Free Number: [phone] (only within the US) or www.gamasonic.com
Visit our website or download the latest version of your instruction manual:
www.gamasonic.com or www.gamasonic.com/user-guides
Please read the instruction manual carefully to obtain the best results from your purchase.
For best results, the solar light must be charged in the “ON” position (High or
Low) for at least 2 days of full direct sunlight.
Gama Sonic’s patented Bulb technology
gives your solar lamp the look and feel
of a traditional incandescent lamp. This
helps to distribute light further than
traditional solar lamps.
A = Top
B = Fixture
C = 3” Fitter A
B
C
D
E
D = Pier Base
E = Wall Mount
For optimum light duration throughout
the night, it is very important to mount
your solar lamp in a spot where it will
receive the maximum amount of direct
sunlight throughout the day.
GAMA SONIC’S BULB TECHNOLOGY 2. What's in the Box
1. Solar Lamp Location
Screws and
anchors

3. Assembly Instructions 4. Operation Instructions
page 3
NOTE: The following steps are for reference only. Consult your
local hardware store for the best installation method for your
surface.
1. Remove the top (A) from the fixture by removing the two
screws from the underside of the top.
2. Install the GS Solar LED Bulb into the top (A) by twisting it
clockwise. Be sure to hold the bulb by its base.
3. Turn the lamp on using the operation switch located on the
underside of the top (A)
4. Attach the top (A) to the fixture (B) and secure with the two
screws.
3” Fitter Mount
NOTE: If you are replacing an existing gas/electric post light,
you must consult a certified technician to disconnect them
before installation.
• Begin by attaching the Fitter (C) to the fixture (B). Secure the
fitter (C) by twisting it clockwise.
• Place part (C) on your existing 3” pole and secure with the
provided set screws.
• Be sure to not overtighten the screws.
Pier (Flat) Mount
• Using the pier mount (D) as a template, drill two holes in the
desired mounting location.
• Place the anchors in the holes and secure the mount (D) to
the surface using the provided screws.
• Attach the fixture (B) to the mount (D) by twisting the fixture
clockwise.
Wall Mount
Note: Installing the light on a wall may limit the solar panel
for sun exposure. Make sure the lamp is mounted so direct sun
exposure is available.
• Using the wall mount (E) as a template, drill two holes in the
desired mounting location.
• Place the anchors in the holes and secure the mount (E) to
the wall using the provided screws.
• Attach the fixture (B) to the mount (E) by twisting the fixture
clockwise.
1. Install the GS Solar LED Bulb in the top (A).
2. Locate the operation switch on the underside of the top (A).
3. Turn the operation switch to the Low or High position
according to your preferences:
- Low = Softer light and longer duration
- High = Brighter light output
The solar Lamp will automatically operate at dusk.
D
E
C
B B
B
Screws
Screws
Anchors
Anchors
D
E
C
B
BB
Screws
Screws
Anchors
Anchors
D
E
C
B
B
B
Screws
Screws
Anchors
Anchors
B. Pier Mount
C. Wall Mount
A.
3" Fitter

Replacing the Batteries
After several years of use, the battery may need replacing.
1. Remove the top (A) from the fixture by removing the two screws from
the underside of the top.
2. Make sure the ON/OFF switch is in the OFF (O) position.
3. Unscrew the battery compartment located on the silver reflector and
remove the compartment door.
4. Unclip the connector and remove the old battery.
5. Make sure the new battery is a Gama Sonic – 3.2V/1,500mAh (Item
GS32V15), Li-ion Rechargeable Battery with a connector.
6. Clip on the new battery and install it into the battery compartment.
Re-Install the battery compartment cover.
7. Repeat steps 3 to 6 for the second battery.
8. Reassemble the lamp by reversing steps 1-3.
Replacement Batteries and Bulbs are available at
www.gamasonic.com
or via our Toll Free number: [phone].
Your Lamp can use the following bulbs:
C37WW10W
Included bulb with Warm White LEDs (2700K)
C37BW10W
Bulb with Bright White LEDs (6000K)
F30WW05W
Flame bulb with simulated flame LEDs
Your Lamp uses the following battery:
GS32V15
Li-Ion 3.2V/1500mAh
Maintenance
Clean the solar panels regularly with a damp towel to guarantee optimum performance. Do not
use any type of solvent for cleaning and be careful not to put too much pressure on the solar
panels while cleaning.
Troubleshooting
If your solar light does not come on as expected despite observance of all the instructions,
please try the following steps:
1. Make sure that the solar lamp is not being affected by any other light source.
2. Ensure the solar lamp is not positioned in the shade during the day.
3. Check that the batteries are installed correctly.
NOTE: The performance of the solar lamp will vary with the time of year. It will last longer
when it has had a full day in the sun rather than a day in overcast weather.
WINTERTIME TIPS: For optimal performance, be sure to remove any snow or debris
accumulation from solar panel(s). A solar panel free of debris will charge the batteries much
more efficiently.
WARNING: Please keep out of reach of children. Do not dispose of the Li-Ion battery in the regular trash,
municipal waste stream or by fire as batteries may leak or explode. Do not open, short circuit, or mutilate
batteries as injury may occur. Preserve our environment by recycling Li-Ion batteries or disposing of them in
accordance with local, State and federal regulations. Do not mix old and new batteries.
