Gantner GAT ECO.Side Lock 7010 F/ISO Quick guide

www.gantner.com HB_GAT-ECOSide-Lock7010-FISO--EN_11
1
GAT ECO.Side Lock 7010 (NW) F/ISO
Battery-Powered Multi-Technology Electronic Lock
Installation, Configuration, Operation
Installation, Configuration, Operation
Document Version 1.1

GAT ECO.Side Lock 7010 (NW) F/ISO
2 HB_GAT-ECOSide-Lock7010-FISO--EN_11 www.gantner.com
©
Copyright 2017-2018 by GANTNER Electronic GmbH, Schruns (Austria).
All rights are reserved. Operatinginstructions, manuals andsoftware are protected by copyright ©. Copying, duplication, translation,
installation in any electronic medium or machine-readable form in whole or in part is prohibited. The sole exception is represented
by creation of a back-up copy of software for own use as a safeguard, so far as this is technically possible and recommended by us.
Any infringement will render the party committing such infringement liable to compensation payment.
Liability
Any claims against the manufacturer based on the hardware or software products described in this manual shall depend exclusively
on the conditions of the guarantee. Any further-reaching claims are excluded, and in particular the manufacturer accepts no liability
for the completeness or accuracy of the contents of this manual. The right is reserved to make alterations, and alterations may be
made at any time without prior notice being given.
Trademarks
Attention is drawn at this point to the symbols and registered trademarks used in this manual. All product or company names
mentioned herein are used only for identification and explanatory purposes. These terms are used depending on the applicable
description and may include the trademarks or registered trademarks of their respective companies.
Contact
For general inquiries of further information on the GAT ECO.Side Lock 7010 F/ISO and GAT ECO.Side Lock 7010 NW F/ISO, see
the contact information below.
Contact address of manufacturer
GANTNER Electronic GmbH
Montafonerstrasse 8
A - 6780 Schruns/Austria
Tel.: [phone] - 0
Fax: [phone] - 8000
Email: [email protected]m
Website: www.gantner.com

GAT ECO.Side Lock 7010 (NW) F/ISO
www.gantner.com HB_GAT-ECOSide-Lock7010-FISO--EN_11 3
Important Information
Dear Customer,
Our aim is to ensure that our product operates with safety and to your complete satisfaction. To achieve this aim, please take
this opportunity to familiarize yourself with the following guidelines.
- Pay attention to the safety messages in this manual. The messages are indicated by the signal words "DANGER",
"WARNING", or "CAUTION", and inform you about hazardous situations and how to avoid them.
- Pay attention to messages indicated by the "NOTICE" signal word. These messages include important information for
avoiding property damage.
- Pay attention to the symbols and safety messages on the product.
- Read all instructions in this manual carefully before installing or operating the product.
- Where not otherwise specifically documented, the appropriate installation, commissioning, operation and maintenance
of the product is the customer’s responsibility.
- Keep this manual in a safe place for quick reference.
Notation of Safety Information and Safety Symbols
This manual includes important safety messages and symbols intended to inform the user about potentially hazardous situations
or important information for the safe and proper use of the described product(s). The safety messages also include directives on
how to avoid hazardous situations. These safety messages and directives must be read and observed.
The structure of the safety messages and the meaning of the symbols used in this manual are described in this section.
1. Safety Messages for Personal Injury
Personal safety messages contain a signal word, describe the nature of the hazard, and indicate how to avoid the hazard.
The safety alert symbol used without a signal word always precedes important safety information that must be read
carefully and the instructions carefully observed. Not doing so may cause personal injury.
Format of safety messages that apply to an entire section:
These safety messages may be used with or without a symbol.
Electrical shock
➔Touching current-conducting parts may result in injury due to electrical shock.
- Do not remove safety protection and covers.
- Do not touch the electrical connections while power is being supplied.
Format of safety messages that are embedded in text and apply to a specific point:
CAUTION! Electrical shock. Never remove safety protection and covers. Do not touch the electrical connections while
power is being supplied.

GAT ECO.Side Lock 7010 (NW) F/ISO
4 HB_GAT-ECOSide-Lock7010-FISO--EN_11 www.gantner.com
2. Property Damage Messages
Property damage messages are used to describe potentially hazardous situations that may lead to property damage. These
messages have the same layout as safety messages but use the signal word "NOTICE" instead of “CAUTION”.
Format of property damage messages that apply to an entire section:
Risk of damage to the device and connected devices
Risk of malfunction
- Read the following instructions carefully before installing the device.
- Always adhere to the instructions.
Format of property damage messages that are embedded in text and apply to a specific
point:
NOTE! Risk of damage to the device and connected devices. Read the following instructions carefully before installing the
device.
3. Definition of the Signal Words
Indicates a hazardous situation that, if not avoided, may result in minor or moderate injury.
Indicates information considered important, but not hazard-related (e.g., messages relating to
property damage).
4. Definition of the Safety Symbols
Caution: General Information
This symbol indicates general warnings or cautions that are not related to a particular type of hazard.
Caution: Electrical Shock
This symbol indicates warnings related to electrical hazards (danger due to high voltage).
Prohibited: Do Not Disassemble
This symbol indicates warnings about not disassembling certain components or equipment. Disassembling may
lead to damage or malfunction of the device.
Mandatory Action: General Information
This symbol indicates general information that must be read and followed before proceeding with the
accompanying instructions.
Mandatory Action: Read Instructions
This symbol indicates information referring to an important description in the manual, or other documentation,
which must be read and followed.

GAT ECO.Side Lock 7010 (NW) F/ISO
www.gantner.com HB_GAT-ECOSide-Lock7010-FISO--EN_11 5
Important Safety Information
−The installation, commissioning, and servicing of our products must be performed only by suitably trained
personnel. In particular, electrical connections must only be made by correspondingly qualified specialists.
Always observe the relevant installation regulations in accordance with the national Electrical Engineers
Association.
➔Unqualified personnel may potentially perform actions that result in injury due to electrical shock.
−Where not otherwise stated, installation and maintenance work on our products must be carried out when
disconnected from the power supply. This applies in particular to appliances that are normally supplied by
low-voltage current.
➔If the appliance is not disconnected from power, touching terminals or other internal parts of the
appliance may lead to injury due to electrical shock.
−It is prohibited to alter the products (devices, cabling, etc.).
➔Alterations to the products may subsequently result in personal injury, property damage, or damage to
the products.
−Do not remove protective shields and covers.
➔Removing protective shields and covers may result in personal injury or property damage.
−Do not attempt to repair a product after a defect, failure, or damage is detected. In addition, do not put the
product back into operation. In such cases, it is essential to contact your GANTNER representative or the
GANTNER support hotline.
−The installation, commissioning, operation, and maintenance of the product must be carried out in
accordance with the technical conditions of operation as described in the corresponding documentation.
Therefore, it is essential to read the corresponding chapter of this manual and observe the instructions and
information therein.
−If there are still some points that are not entirely clear, please do not take a chance. All queries can be
clarified by your GANTNER representative or by ringing the GANTNER support hotline.
−Directly on receipt of the goods, inspect both the packaging and the product itself for any signs of damage.
Also check that the delivery is complete and includes all accessories, documentation, auxiliary devices,
etc.
−If the packaging or product has been damaged in transport, or should you suspect that it may have a fault,
the product must not be put into service. Contact your GANTNER representative who will endeavor to
resolve the problem as quickly as possible.
−GANTNER Electronic GmbH accepts no responsibility for any injuries or damage caused as a result of
improper use.
Although great care is taken and we are continuously aiming for improvement, we cannot completely exclude the possibility of
errors appearing in our documentation. GANTNER Electronic GmbH therefore accepts no responsibility for the completeness or
the accuracy of this manual. The right is reserved to make alterations at any time without prior notice.
Should you discover any fault with the product or in its accompanying documentation, or you have any suggestions for
improvement, you may confidently inform your GANTNER representative or GANTNER Electronic GmbH directly.
We especially look forward to hearing from you if you want to let us know that everything is functioning perfectly.

GAT ECO.Side Lock 7010 (NW) F/ISO
6 HB_GAT-ECOSide-Lock7010-FISO--EN_11 www.gantner.com
The GAT ECO.Side Lock 7010 F/ISO and GAT ECO.Side Lock 7010 NW F/ISO are developed and fabricated under the quality
management standard ISO 9001 and GANTNER Electronic GmbH is also certified according to standard ISO 14001.
This product is in conformity with the following EC directives, including all applicable amendments:
- 2014/53/EU (Radio Equipment Directive)
The complete text of the CE Declaration of Conformity is available on the following internet link:
http://www.gantner.com/en/downloads-gat-eco-sidelock7xxx_90lweb4f22
GANTNER is committed to meeting or exceeding the requirements of the RoHS directive (2011/65/EU). The RoHS
directive requires that manufacturers eliminate or minimize the use of lead, mercury, hexavalent chromium,
cadmium, polybrominated biphenyls and polybrominated diphenyl ethers in electrical and electronic equipment sold
in the EU after July 1, 2006.
The WEEE symbol on GANTNER products and their packaging indicates that the corresponding material must not
be disposed of with normal household waste. Instead such marked waste equipment must be disposed of by
handing it over to a designated electronic waste recycling facility. Separating and recycling this waste equipment at
the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects
human health and the environment. Please contact your local authority for further details of your nearest electronic
waste recycling facility.
FCC INFORMATION (U.S.A.)
Note:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energyand, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that of which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Warning Statement:
[Any] changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
Compliance Statement:
INDUSTRY CANADA INFORMATION (IC ID: 11873A-1180085A)
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes :
1) l’appareil ne doit pas produire de brouillage;
2) l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le onctionnement.
ICES Statement (Canada)
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
FCC ID: NC4-GEA1180085A
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device must not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.

GAT ECO.Side Lock 7010 (NW) F/ISO
Table of Contents
www.gantner.com HB_GAT-ECOSide-Lock7010-FISO--EN_11 7
TABLE OF CONTENTS
1 INTRODUCTION..........................................................................................9
1.1 About this Manual.....................................................................................................................................9
1.2 Chapter Overview.....................................................................................................................................9
1.3 Contact & Inquiries ...................................................................................................................................9
1.4 Target Groups.........................................................................................................................................10
1.5 Formatting...............................................................................................................................................10
1.5.1 Safety-Critical Information....................................................................................................................10
1.5.2 Non-Safety-Critical Information............................................................................................................10
1.5.3 Instructions and Results.......................................................................................................................10
2 GENERAL INFORMATION ........................................................................11
2.1 Intended Use...........................................................................................................................................11
2.2 Functional Description ............................................................................................................................11
2.3 Terminology............................................................................................................................................12
2.4 RFID Technology....................................................................................................................................13
2.5 System Components ..............................................................................................................................14
3 INSTALLATION.........................................................................................17
3.1 Target Group...........................................................................................................................................17
3.2 Definition of the Door Hinge (Right of Left Door)....................................................................................17
3.3 Test Installation.......................................................................................................................................18
3.4 Metallic and Non-Metallic Doors.............................................................................................................18
3.5 Bolt Gauge..............................................................................................................................................18
3.6 Door Status Contact ...............................................................................................................................19
3.7 Transportation Guidelines.......................................................................................................................19
3.8 Replacement after a Burglary Attempt ...................................................................................................19
3.9 Measurement Diagrams for Installation..................................................................................................20
3.9.1 Door Width ...........................................................................................................................................20
3.9.2 Dimensions of the GAT ECO.Side Lock 7010 F/ISO and GAT NET.Lock Bolt Sets...........................20
3.10 Installation in Lockers with Non-Metallic Doors (except glass) ..............................................................22
3.10.1Installation Requirements for the GAT ECO.Side Lock 7010 F/ISO and Bolt Set...............................23
3.10.2Installation Instructions for the GAT ECO.Side Lock 7010 F/ISO and Non-Metallic Doors.................24
3.11 Installation in Lockers with Metallic Doors..............................................................................................25
3.11.1Cutouts in the Locker Door ..................................................................................................................26
3.11.2Installation Requirements for the GAT ECO.Side Lock 7010 F/ISO and Bolt Set...............................27
3.11.3Installation Instructions for the GAT ECO.Side Lock 7010 F/ISO and Metallic Doors.........................28
3.12 Installation in Lockers with Glass Doors.................................................................................................29
3.12.1Installation Requirements for the GAT ECO.Side Lock 7010 F/ISO and Bolt Set...............................30
3.12.2Installation Instructions for the GAT ECO.Side Lock 7010 F/ISO and Glass Doors............................31
4 COMMISSIONING .....................................................................................33
4.1 Target Group...........................................................................................................................................33
4.2 Power Supply..........................................................................................................................................33
4.2.1 Battery Information...............................................................................................................................33
4.2.2 Inserting the Battery.............................................................................................................................33
4.2.3 Replacing the Battery...........................................................................................................................34
4.3 USB Connection .....................................................................................................................................35
4.4 Automatic Antenna Adjustment ..............................................................................................................37
4.4.1 Antenna Adjustment using the SERVICE Data Carrier .......................................................................37
4.4.2 Antenna Adjustment via GAT Config Manager....................................................................................37

GAT ECO.Side Lock 7010 (NW) F/ISO
Table of Contents
8 HB_GAT-ECOSide-Lock7010-FISO--EN_11 www.gantner.com
5 CONFIGURATION .................................................................................... 39
5.1 General Information ............................................................................................................................... 39
5.2Configuration with GAT Config Manager............................................................................................... 39
5.2.1 Setup for Configuration in GAT Config Manager ................................................................................ 39
5.2.2 View and Edit the GAT ECO.Side Lock 7010 F/ISO Configuration Settings...................................... 41
5.2.3 Upload Configuration Settings to the GAT ECO.Side Lock 7010 F/ISO............................................. 42
5.2.4 Updating the GAT ECO.Side Lock 7010 F/ISO Firmware .................................................................. 43
5.3 Configuration with the MoLA App .......................................................................................................... 44
5.4 Configuration Settings of the GAT ECO.Side Lock 7010 F/ISO............................................................ 45
5.4.1 Operating Mode................................................................................................................................... 45
5.4.2 Locker Number.................................................................................................................................... 45
5.4.3 Sound Signals ..................................................................................................................................... 45
5.4.4 Alarm Mode......................................................................................................................................... 45
5.4.5 Auto-Unlock......................................................................................................................................... 46
5.4.6 Duration of Use.................................................................................................................................... 46
5.4.7 Locking of Personal Locker without Data Carrier................................................................................ 46
5.4.8 RF Standards ...................................................................................................................................... 46
5.4.9 MASTER Data Carriers....................................................................................................................... 47
5.4.10Configuration Settings Table............................................................................................................... 47
6 OPERATION............................................................................................. 49
6.1 General .................................................................................................................................................. 49
6.2 Target Group.......................................................................................................................................... 49
6.3 Operating Modes.................................................................................................................................... 49
6.3.1 Free Locker Mode (with or without Duration of Use Function)............................................................ 50
6.3.2 Free Locker Universal Mode............................................................................................................... 51
6.3.3 Free Locker Unique Number Mode..................................................................................................... 52
6.3.4 Personal Locker Programming Card Mode......................................................................................... 52
6.3.5 Personal Locker Expiry Date Mode..................................................................................................... 53
6.4 GAT ECO.Basic Set F/ISO .................................................................................................................... 55
6.5 Summary of System Data Carriers........................................................................................................ 55
6.5.1 MASTER Data Carriers....................................................................................................................... 55
6.5.2 OPEN MASTER Data Carrier.............................................................................................................. 56
6.5.3 DELETE MASTER Data Carrier.......................................................................................................... 56
6.5.4 PROGRAM Data Carrier..................................................................................................................... 56
6.5.5 BATTERY Data Carrier....................................................................................................................... 57
6.5.6 SERVICE Data Carrier........................................................................................................................ 57
6.5.7 APP KEY Data Carrier ........................................................................................................................ 57
6.6 Alarm and Handling ............................................................................................................................... 58
6.7 Summary of LED Signals....................................................................................................................... 58
7 CLEANING AND MAINTENANCE............................................................. 59
7.1 Target Group.......................................................................................................................................... 59
7.2 Functional Testing.................................................................................................................................. 59
7.3 Cleaning................................................................................................................................................. 60
7.4 Maintenance........................................................................................................................................... 60
8 TECHNICAL DATA ................................................................................... 61
8.1 Power Supply......................................................................................................................................... 61
8.2 Reading Field......................................................................................................................................... 61
8.3 Wireless Interface .................................................................................................................................. 61
8.4 Memory and Time Management............................................................................................................ 61
8.5 Control and Display Elements................................................................................................................ 62
8.6 Interface................................................................................................................................................. 62
8.7 Housing.................................................................................................................................................. 62
8.8 Environmental Conditions...................................................................................................................... 62

GAT ECO.Side Lock 7010 (NW) F/ISO
Introduction
www.gantner.com HB_GAT-ECOSide-Lock7010-FISO--EN_11 9
1 INTRODUCTION
1.1 About this Manual
This manual provides information on the functionality of the GAT ECO.Side Lock 7010 F/ISO and the GAT
ECO.Side Lock 7010 NW F/ISO and includes an overview of how to configure these devices using GAT Config
Manager configuration software. There is a separate manual available for GAT Config Manager, which explains in
greater detail all functions associated with the software.
The name “GAT ECO.Side Lock 7010 F/ISO” is henceforth used in this manual to refer to both the GAT
ECO.Side Lock 7010 F/ISO and the GAT ECO.Side Lock 7010 NW F/ISO. Functionality that is specific to one
type of lock will be noted.
1.2 Chapter Overview
In chapter 2. GENERAL INFORMATION, a functional description of the GAT ECO.Side Lock 7010 F/ISO, the RFID
technologies supported by the device, key terms used in this manual and a summary of system components can be
found.
Chapter 3. INSTALLATION contains the measurement diagrams and information required toinstall the GAT ECO.Side
Lock 7010 F/ISO into lockers with metallic, non-metallic, and glass doors.
Chapter 4. COMMISSIONING describes how to put the GAT ECO.Side Lock 7010 F/ISO into operation and includes
information on the battery and USB connection.
Chapter 5. CONFIGURATION describes how to configure the GAT ECO.Side Lock 7010 F/ISO using GAT Config
Manager. The main configuration settings for the lock are explained and a table listing every setting can be found
here.
Chapter 6. OPERATION describes the different operating modes of the GAT ECO.Side Lock 7010 F/ISO. The system
data carriers required to maintain the locker system and the alarm function are also explained in this section.
Contained in chapter “7. CLEANING AND MAINTENANCE” are the instructions for performing functional testing and
cleaning of the GAT ECO.Side Lock 7010 F/ISO to ensure that the correct operation is maintained.
Chapter 8. TECHNICAL DATA contains all the relevant technical information for the GAT ECO.Side Lock 7010
F/ISO.
1.3 Contact & Inquiries
For all inquiries concerning the GAT ECO.Side Lock 7010 F/ISO locker system please get in touch with your local
GANTNER representative/distributor or directly with one of the GANTNER Technology branch offices. The addresses,
phone and fax numbers are listed on the inner side of the manual cover.

GAT ECO.Side Lock 7010 (NW) F/ISO
Introduction
10 HB_GAT-ECOSide-Lock7010-FISO--EN_11 www.gantner.com
1.4 Target Groups
This manual contains information relevant for the different stages in the operating life of theGAT ECO.Side Lock 7010
F/ISO. Information regarding the installation, commissioning, and service/maintenance of the GAT ECO.Side Lock
7010 F/ISO is separated into corresponding chapters. When a chapter is intended for a specific audience, this is
clarified at the beginning of the chapter.
Information for the following target groups is available in this manual:
- Installation technicians (installation, operation, configuration).
- Service technicians and cleaning personnel (service and maintenance).
- End users of the GAT ECO.Side Lock 7010 F/ISO (user manual).
Where not explicitly stated, the information in this manual is intended for all target groups in general.
CAUTION! Injury and property/equipment damage. The tasks described in each chapter must only be
performed by the specified target group. Unqualified personnel who perform the described tasks risk personal injury
or damaging property/equipment.
1.5 Formatting
1.5.1 Safety-Critical Information
The following formatting (with example text) is used in this manual to display important, safety-critical information
that must be read and followed.
NOTE! Following on from this signal word in the manual is a reference text that must be read and followed. The
reference text contains important information. Non-observance can lead to damage of the device or associated
equipment.
1.5.2 Non-Safety-Critical Information
The following formatting (with example text) is used in this manual to display important, but not safety-critical
information.
The text accompanying this symbol contains interesting information relevant to the current chapter. You do not
necessarily need to read this text; however, it will help you better understand the information in this section or
provide interesting tips for the described device or the operation of the software.
1.5.3 Instructions and Results
Instructions, which must be completed by the reader, and the results of these instructions are formatted as follows.
►This symbol represents an action or instruction that that must be followed.
oThis symbol represents the result after completing the previous instruction.

GAT ECO.Side Lock 7010 (NW) F/ISO
General Information
www.gantner.com HB_GAT-ECOSide-Lock7010-FISO--EN_11 11
2 GENERAL INFORMATION
2.1 Intended Use
The GAT ECO.Side Lock 7010 (NW) F/ISO is intended for the electronic locking of lockers in facilities such as fitness
clubs, baths, golf resorts, hotels, and other individual company applications. The GAT ECO.Side Lock 7010 (NW)
F/ISO is locked and unlocked using contactless RFID (Radio Frequency Identification) data carriers.
2.2 Functional Description
Both lock variants are suitable for any type of locker material (e.g., sheet metal, wood, HPL, solid plastic, glass) and
can be used for left- and right-hinged doors alike. Due to the mechanical compatibility with the GAT NET.Lock 7000
series a quick and simple installation of existing locker rooms using the GAT ECO.Side Lock 7010 F/ISO is possible.
The GAT ECO.Side Lock 7010 F/ISO is installed on the inner side of the locker body. A bolt set is mounted on the
inside of the locker door. The bolt set holds the door shackle which inserts into the GAT ECO.Side Lock 7010 F/ISO
and locks the door. The GAT NET.Lock BoltSet 7100 is designed for use with locker doors made from wood, HPL,
and solid plastic. For locker doors made from metal, use the GAT NET.Lock BoltSet 7200 and for glass locker doors,
the GAT NET.Lock BoltSet 7300 is available. The bolt sets include apassive booster used to amplify the RFID reading
field.
The GAT ECO.Side Lock 7010 F/ISO is powered by one 3.6 V AA battery, which provides an operating life of up to
10 years* (at room temperature) before requiring replacement. The configuration (e.g., operating mode) of the GAT
ECO.Side Lock 7010 F/ISO can be done on site via USB interface and GAT Config Manager configuration software
or using the programming datacarrier. Forthe GAT ECO.Side Lock 7010 NW F/ISO, communication via the integrated
wireless interface is also possible.
Using a locker
The user closes the door of their locker and while holding the door shut, holds their data carrier next to the RFID
reading field on the locker door (the reading field is indicated by an LED inside the lock). The GAT ECO.Side Lock
7010 F/ISO reads the data carrier information and determines if the user is allowed to use the locker (depending on
their authorization status). If the user is authorized to use the locker, the GAT ECO.Side Lock 7010 F/ISO locks the
locker door.
To unlock a previously locked locker, the user presses the locker door while holding their data carrier next to the
RFID reading field. The GAT ECO.Side Lock 7010 F/ISO checks that the data carrier has valid authorization before
automatically unlocking the locker door.
* Different operating modes or configurations can reduce the battery lifetime.

GAT ECO.Side Lock 7010 (NW) F/ISO
General Information
12 HB_GAT-ECOSide-Lock7010-FISO--EN_11 www.gantner.com
2.3 Terminology
Several key terms that are used often in this manual are defined below.
Computer / PC
These terms refer to all desktop and laptop computers running a MicrosoftWindows®operating system.
Data Carrier
A data carrier is a form of identification media that is used by staff and visitors in a facility for identification. Data
carriers are available in a variety of different forms such as plastic wristbands and chip cards. Data carriers are also
available to suit different RFID technologies, e.g., LEGIC, MIFARE®, ISO 15693.
System Data Carrier
Several different types of System Data Carriers are used for programming, service and maintenance tasks. These
data carriers have special functionalities and because they are essential for operation of the GAT ECO.Side Lock
7010 F/ISO and they have security-related features, they must be kept in a secure place and be protected against
unauthorized use. Most of the System Data Carriers are included in the GAT ECO.Basic Set F/ISO. Some can be
ordered separately if needed.
FID (Company ID) and Site Key
The FID and site key are unique numbers assigned to every facility installation. The site key is a combination of the
FID and the read and write keys. The site key is used in MIFARE® and ISO 15693 systems and is encoded in every
data carrier and device used in the facility thereby ensuring that data carriers from one installation cannot be used in
other installations.
GAT Config Manager
GANTNER developed PC software that is used to configure GANTNER devices such as the GAT ECO.Side Lock
7010 F/ISO. A separate manual is available and integrated into the software. While the software is open, click on
the “Help” drop-down menu and select “How Do I”.
Lock
General term for the GAT ECO.Side Lock 7010 F/ISO and GAT ECO.Side Lock 7010 NW F/ISO.
Locker
The term "locker" is used to describe all possible locker applications that can be fitted with a GANTNER electronic
lock. Typical applications include a changing room locker, a deposit box, or a private box.
RFID (Radio-Frequency Identification)
Identification over a short distance using radio frequency. An RFID data carrier is used to identify users in
GANTNER systems.
User / Guest / Visitor
These general terms refer to the people in a facility who use the locker system, i.e., the GAT ECO.Side Lock 7010
F/ISO, data carriers, and other GANTNER devices.

GAT ECO.Side Lock 7010 (NW) F/ISO
General Information
www.gantner.com HB_GAT-ECOSide-Lock7010-FISO--EN_11 13
2.4 RFID Technology
Identification of users by GANTNER devices within a facility is achieved via RFID (radio-frequency identification)
technology using a frequency of 13.56 MHz. There are various RFID technologies available with different letters
added to the GANTNER model name to notify of the technology the device supports:
- "F": MIFARE®
- "ISO": ISO 15693
The GAT ECO.Side Lock 7010 F/ISO has a multi-technology RFID reader that allows it to operate with a range of
RFID technologies. The information in this manual is applicable for the following technologies that can be used with
the GAT ECO.Side Lock 7010 F/ISO.
UID and Sectors
- ISO 15693
- ISO 14443 (MIFARE)
- Classic (1k and 4k)
- Ultralight®
- DESFire EV1®and EV2®
In addition to the different RFID technologies, data carriers are available in a variety of shapes and sizes. The GAT
ECO.Side Lock 7010 F/ISO is designed to operate with all different types of data carrier media.

GAT ECO.Side Lock 7010 (NW) F/ISO
General Information
14 HB_GAT-ECOSide-Lock7010-FISO--EN_11 www.gantner.com
2.5 System Components
The GAT ECO.Side Lock 7010 F/ISO system consists of the following system parts.
Figure 2.1 –Components of the GAT ECO.Side Lock 7010 system
1. GAT ECO.Side Lock 7010 (NW) F/ISO
2. GAT NET.Lock BoltSet7100
3. GAT NET.Lock BoltSet 7200
5. GAT NET.Lock Tool 7000
6. GAT NET.Lock Label GEA xxx
(Door labels in different designs)
For lockers with glass doors
For lockers with non-metallic
doors
4. GAT NET.Lock BoltSet 7300
8. GAT ECO.Basic Set F
For lockers with metallic doors
7. Battery
Tadiran SL-860/S (EU)
Tadiran TL-4903/S (US)
9. GAT Key Tag F Open Master

GAT ECO.Side Lock 7010 (NW) F/ISO
General Information
www.gantner.com HB_GAT-ECOSide-Lock7010-FISO--EN_11 15
1. GAT ECO.Side Lock 7010 F/ISO (Part No. 693430)
Battery-powered locker lock for MIFARE®and ISO 15693 data carriers. Without batteries, without bolt set, and
without door label.
GAT ECO.Side Lock 7010 NW F/ISO (Part No. 849130)
Battery-powered locker lock for MIFARE®and ISO 15693 data carriers.With wireless interface.Without batteries,
without bolt set, and without door label.
2. GAT NET.Lock BoltSet 7100 (Part No. 369535)
Bolt set with door shackle and booster. Used for non-metallic doors. The bolt set is mounted on the inside of the
locker door.
3. GAT NET.Lock BoltSet 7200 (Part No. 532123)
Bolt set with door shackle and booster. Used for metallic doors. The bolt set is installed into locker door. The
label carrier is included in the set.
4. GAT NET.Lock BoltSet 7300 (Part No. 774232)
Bolt set with door shackle, booster, and metal support. Used for glass doors. The bolt set with metal support
attached are glued on the inner side of the glass door. Adhesive is not included with the set.
5. GAT NET.Lock Tool 7000 (Part No. 533831)
Centre punch gauge for bolt mounting on the locker door. By using the gauge drill holes for the bolt set installation
can be accurately marked on the locker door.
6. GAT NET.Lock Label 7000 GEA xxx
Self-adhesive locker door labels in GANTNER design. For metallic doors, the label is stuck onto the label carrier.
For non-metallic doors, the label is stuck directly onto the door. The labels are available for right and left doors
and with or without printed locker numbers:
- GAT NET.Lock Label GEA right (Part No. 679034)
For right-hinged doors, without numbering
- GAT NET.Lock Label GEA NUM right (Part No. 679236)
For right-hinged doors, with numbering
- GAT NET.Lock Label GEA left (Part No. 370022)
For left-hinged doors, without numbering
- GAT NET.Lock Label GEA NUM left (Part No. 679135)
For left-hinged doors, with numbering
7. Battery 3.6V Lithium, EU: Tadiran SL-860/S (Part No. 914430), US: Tadrian TL-4903/S
GANTNER approved battery for the GAT ECO.Side Lock 7010 F/ISO. One battery required for operation.
Batteries supplied per battery.
8. GAT ECO.Basic Set F/ISO (Part No. 812528)
Accessory set for configuring and maintaining the GAT ECO.Side Lock 7010 F/ISO system. Contains system
data carriers, 3 m USB cable, configuration software, and GANTNER lanyard. See section “6.4. GAT ECO.Basic
Set F/ISO”for more information.
9. GAT Key Tag F Open Master (Part No. 1100368)
Optional data carrier. Not included in the GAT ECO.Basic Set F/ISO. Can be used instead of another MASTER
data carrier in order to unlock a locked GAT ECO.Side Lock 7010 F/ISO. Unlike the MASTER data carriers the
OPEN MASTER data carrier can only open but not lock a locker.

GAT ECO.Side Lock 7010 (NW) F/ISO
General Information
16 HB_GAT-ECOSide-Lock7010-FISO--EN_11 www.gantner.com

GAT ECO.Side Lock 7010 (NW) F/ISO
Installation
www.gantner.com HB_GAT-ECOSide-Lock7010-FISO--EN_11 17
3 INSTALLATION
This chapter describes the process and what must be considered to install the GAT ECO.Side Lock 7010 F/ISO and
GAT ECO.Side Lock 7010 NW F/ISO into lockers with metallic, non-metallic, and glass doors. Since the mounting
process is identical for both lock variants, the general term GAT ECO.Side Lock 7010 F/ISO is used.
Risk of damage or failure to the GAT ECO.Side Lock 7010 F/ISO
- Read the information in this section carefully before installing the GAT ECO.Side Lock 7010 F/ISO.
- Carefully observe the installation diagrams.
- Use the correct tools to install the GAT ECO.Side Lock 7010 F/ISO.
3.1 Target Group
This chapter provides information for technicians who install the GAT ECO.Side Lock 7010 F/ISO. Experience in
mechanical work and basic electrical knowledge is required. Previous knowledge of the GAT ECO.Side Lock 7010
F/ISO is not required.
3.2 Definition of the Door Hinge (Right of Left Door)
For installation, it is important to determine whether the door is hinged to the left or the right. This is defined as follows:
Figure 3.1 –Locker door hinge definition (left/right)
In the following pages the installation for right-hinged doors is described. The installation process for left locker doors
is in principle the same as for right locker doors, only with reversed lock and door orientation.
NOTE! If spring hinges are used in the locker door, ensure that the spring strength is calibrated to allow correct
operation of the lock. For example, springs that are too strong can keep the bolt set permanently held in thereby
activating the lock’s electronics and draining the battery.

GAT ECO.Side Lock 7010 (NW) F/ISO
Installation
18 HB_GAT-ECOSide-Lock7010-FISO--EN_11 www.gantner.com
3.3 Test Installation
As the GAT ECO.Side Lock 7010 F/ISO is suitable for a wide range of installation applications, always perform a test
installation including functional testing of the GAT ECO.Side Lock 7010 F/ISO in a sample locker from the facility
before starting with the mass production of lockers.
The following important points must be met. Ensure that:
- the door shackle slides centrally into the opening of the GAT ECO.Side Lock 7010 F/ISO.
- the door locks without any problems.
- the door opens without resistance (ensure retaining hardware such as springs are correctly calibrated).
Also test the GAT ECO.Side Lock 7010 F/ISO using a data carrier, ideally of the same type to be used with the locker
system, to ensure the data carrier functions as required. Once the test installation is successfully completed, the
remaining locks can be installed in the same way. An installation checklist is available from GANTNER to assist with
the test installation process.
3.4 Metallic and Non-Metallic Doors
Because the RFID field of the GAT ECO.Side Lock 7010 F/ISO is distorted or blocked by metal (e.g., metallic locker
doors), a cutout is made in metallic locker doors into which the GAT NET.Lock Bolt Set 7200 and label carrier are
installed. A specific cutout fornon-metallic doors is not necessary, onlya drill hole for the status LED is required.
As the reading range of the GAT ECO.Side Lock 7010 F/ISO is limited, the door of non-metallic lockers must not be
too thick. The maximum door thickness of non-metallic doors depends on the RFID technology and the type of data
carriers used.
3.5 Bolt Gauge
The bolt gauge (GAT NET.Lock Tool 7000, Part No. 533831) can be used to assist installation in non-metallic
doors. The gauge allows you to mark the positions of the holes onto the door.
Figure 3.2 –Bolt gauge (dimensions in mm)
The instructions for using the bolt gauge are included with the installation instructions for non-metallic doors (see
"3.10.2 Installation Instructions for the GAT ECO.Side Lock 7010 F/ISO and Non-Metallic Doors").

GAT ECO.Side Lock 7010 (NW) F/ISO
Installation
www.gantner.com HB_GAT-ECOSide-Lock7010-FISO--EN_11 19
3.6 Door Status Contact
The GAT ECO.Side Lock 7010 F/ISO has a feedback function that is activated by the door contact (2 in Figure 3.3)
on the bolt set when the locker door is closed. To ensure the correct functionality of the GAT ECO.Side Lock 7010
F/ISO it is important that this contact remains clean and undamaged.
Figure 3.3 –Door status contact
3.7 Transportation Guidelines
The electronics of the GAT ECO.Side Lock 7010 F/ISO are activated when the locker door is pressed shut. For
factory-produced lockers that use the GAT ECO.Side Lock 7010 F/ISO, it is important to ensure the bolt set does not
activate the lock’s electronics during transportation or any time prior to delivery. Activation of the lock’s electronics
during transportation can decrease the battery lifetime.
3.8 Replacement after a Burglary Attempt
If a burglary (forced opening) is attempted or occurs in a locker, the entire GAT ECO.Side Lock 7010 F/ISO must be
replaced with a new one. The bolt set and the door shackle must also be replaced.

GAT ECO.Side Lock 7010 (NW) F/ISO
Installation
20 HB_GAT-ECOSide-Lock7010-FISO--EN_11 www.gantner.com
3.9 Measurement Diagrams for Installation
3.9.1 Door Width
The minimum door width allowed (measured from the door shackle to the hinge) is 230 mm (9.05´´). If the door is
narrower, the door shackle will hit the locker when the door is being closed.
Figure 3.4 - Minimum door width
3.9.2 Dimensions of the GAT ECO.Side Lock 7010 F/ISO and GAT NET.Lock Bolt Sets
Figure 3.5 - Dimensions of the GAT ECO.Side Lock 7010 F/ISO (dimensions in mm –inches shown in brackets)
