Ganz PIXELPRO SERIES User manual

PixelPro GXi Series ZN1-B4NVD43 Installation Guide
03-2014-A 2
Precaution
Please read this manual carefully before installing the unit.
Never disassemble the camera. Unauthorized disassembly may cause equipment
failure or damage to the unit.
Please do not install the camera in a place exposed to direct sunlight.
Do not operate the camera in environments beyond the specified temperature.
Refer to “Environment Condition”on “APPENDIX (A) : SPECIFICATIONS”in this manual.
Before applying power to the camera, check the power source to ensure that it is
within the specifications. Refer to “Electrical Characteristics”on “APPENDIX (A) :
SPECIFICATIONS”

PixelPro GXi Series ZN1-B4NVD43 Installation Guide
03-2014-A 3
Table of Contents
Precaution................................................................................................................ 2
1. FEATURES............................................................................................................. 4
2. PACKAGE CONTENTS............................................................................................. 5
3. PART NAMES ........................................................................................................ 6
4. CAMERA INSTALLATION........................................................................................ 8
4.1. Installing a camera ................................................................................................. 8
4.2. Adjusting angle of the camera............................................................................. 10
4.3. Adjusting Zoom and Focus................................................................................... 10
4.4. Setting the Image Attribute ................................................................................. 11
5. CONNECTIONS.................................................................................................... 12
6. CONFIGURATION ................................................................................................ 15
6.1. Set up network environment............................................................................... 15
6.1.1. Generic IP Environment ............................................................................................ 15
6.1.2. Custom IP Environment............................................................................................. 16
6.2. View video on web page...................................................................................... 17
6.2.1. ActiveX Installation.................................................................................................... 17
6.2.2. View video using IPAdmin Tool................................................................................. 18
6.3. Reset .................................................................................................................... 19
6.4. Factory Default..................................................................................................... 19
6.5. Safe Mode ............................................................................................................ 20
APPENDIX (A): SPECIFICATIONS .............................................................................. 22
Summary ..................................................................................................................... 22
Electrical Characteristics ............................................................................................. 23
Environment Condition............................................................................................... 23
Mechanical Condition ................................................................................................. 23
APPENDIX (B): POWER OVER ETHERNET ................................................................. 24
PoE compatibility ........................................................................................................ 24
Power Comparison...................................................................................................... 24
APPENDIX (C): DIMENSIONS ................................................................................... 25
APPENDIX (D): HEXADECIMAL-DECIMAL CONVERSION TABLE ................................. 26
REVISION HISTORY ................................................................................................. 27

PixelPro GXi Series ZN1-B4NVD43 Installation Guide
03-2014-A 4
1. FEATURES
Camera
SONY EXMOR 1/2.9”1080p CMOS Image Sensor
True Day / Night
DC Auto Iris Lens
WDR
Embedded IR Illuminator
Weather Proof (IP66)
Video
H.264 Baseline, Main, High profile(MPEG-4 Part 10/AVC), MJEPG(Motion JPEG)
Max 30 fps in 1080p
Text Overlay
Analog Video Output for 3 minutes (only for installation purpose)
Network
10/100 Base-T Ethernet
Integration
Software Development Kit (SDK) available
ONVIF Compliant (Profile S)
General
microSD slot
Power Over Ethernet (PoE)
Video Contents Analytics (VCA)
VCA Presence (Standard)
VCA Surveillance (Optional)

PixelPro GXi Series ZN1-B4NVD43 Installation Guide
03-2014-A 5
2. PACKAGE CONTENTS
Please unpack the package carefully and handle the equipment with care. The package
contains:
Installation Template
Note
i
The contents above are subject to change without prior notice.
Camera
DC Power Adaptor
Universal Plugs
Screws and anchor blocks
Quick Installation Guide
Hex Wrench Driver
Silicon Waterproof Band
Video Output Cable socket

PixelPro GXi Series ZN1-B4NVD43 Installation Guide
03-2014-A 6
3. PART NAMES
①Sunshield
Position the sunshield to prevent direct sunshine.
②Video Out Cable socket
Socket for the video output cable included in the package (CVBS: 1.0Vp-p / 75Ω BNC)
Once the PAL/NTSC button is pressed, the video displays for 3 minutes before returns back to
‘no video output’status.
③PAL/NTSC button
Pressing the PAL/NTSC button each time changes the mode as follows.
No video output -> PAL-> NTSC
④Reset button
Use the button to restart the device or to reset it to Factory Default. Refer to “6.3. Reset”and
6.4. Factory Default for more details.
⑤Focus Puller
Use the puller to manually determine correct focus of the camera. Refer to “4.3. Adjusting
Zoom and Focus”for more details.
SD Card
Reset
PAL/NTSC
T/W
F/N
Video Out
* Models herein and their appearance are subject to change without any prior notice.
①
③
④
⑥
⑩
⑨
⑧
②
②
⑦
⑤

PixelPro GXi Series ZN1-B4NVD43 Installation Guide
03-2014-A 7
⑥Zoom Puller
Use the puller to manually determine appropriate field of view of the camera.
Refer to “4.3. Adjusting Zoom and Focus”for more details.
⑦microSD slot
Supports up to 64GB. Recommend Class 4 and higher for HD recordings.
⑧Terminal Connector
Connector for cable connection of digital input/output. Refer to “5. Connections”for more
details.
⑨Power Adaptor Connector
Use 12VDC for the power supply.
⑩LAN connector
RJ45 LAN connector for 10/100 Base-T Ethernet (PoE supported)

PixelPro GXi Series ZN1-B4NVD43 Installation Guide
03-2014-A 8
Caution
!
4. CAMERA INSTALLATION
4.1. Installing a camera
Caution
!
Sealing gaps is recommended as gaps may appear after the camera installation.
Gaps may cause problems such as moisture, water leakage, and etc., which
negatively affect the operation of the camera if gaps appear but remain
unsealed.
To prevent products from damage, place the camera on a stable and non-
vibrating surface. If the stability is in doubt, consult safety personnel for
reinforcements, and then proceed with the installation.
1) Place the installation template (outline
shown on the next page) provided in the
package on the desired installation surface.
2) Drill holes in correct positions based on
the template paper, and insert anchor
blocks into the holes.
3) Make sure the necessary cables including
a LAN cable and a power cable are properly
connected to the camera either thru the
ceiling or thru the groove around the
mounting plate.
4) Place the camera body and match three
alignment holes with three anchor blocks
and hold against the mounting surface.
5) Tighten the anchor blocks with screws.
6) Adjust the angle of the camera. Refer to
“4.2. Adjusting the angle of the camera”for
more details.
7) Adjust zoom and focus of the camera.
Refer to “4.3. Adjusting zoom and focus”for
more details.
8) Attach the lens cover on the main body
by rotating it clockwise.

PixelPro GXi Series ZN1-B4NVD43 Installation Guide
03-2014-A 9
Installation Template
(Unit: mm)
Caution
!
Installation template’s image size scale in this installation guide is not 1:1.
The correct-size template design paper can be found inside the package
separately.
Installation template
6702 V1.0

PixelPro GXi Series ZN1-B4NVD43 Installation Guide
03-2014-A 10
4.2. Adjusting angle of the camera
1. Adjust the camera to the desired angle by unscrewing the joints referring to the following
pictures.
4.3. Adjusting Zoom and Focus
Adjust the joint to install
the camera on the wall.
Tilting adjustment
Panning adjustment
SD Card
Reset
PAL/NTSC
T/W
F/N
Video Out
Zoom Puller
Focus Puller
1. Unscrew the zoom puller and the focus puller
counterclockwise.
2. Adjust the zoom/focus of the lens.
3. Tighten the zoom puller and focus puller again by
turning it clockwise.

PixelPro GXi Series ZN1-B4NVD43 Installation Guide
03-2014-A 11
4.4. Setting the Image Attribute
Through the camera’s webpage, users can configure image settings. The menu of image
attribute is available under Video Appearance menu in Setup > Video & Audio > Camera. The
following features can be adjusted: Brightness, Contrast, Saturation, Sharpness and
Orientation
For more detailed information, refer to the provided “PixelPro GXi series Web Page User's
Manual”.

PixelPro GXi Series ZN1-B4NVD43 Installation Guide
03-2014-A 12
5. CONNECTIONS
GREEN : DI
WHITE : DI COM
ORNAGE : DO
YELLOW : DO COM
LAN
12VDC
(not included)
③
④
①&②
①

PixelPro GXi Series ZN1-B4NVD43 Installation Guide
03-2014-A 13
①Sensor (DI) connection
Sensor (DI) can be connected to either a voltage type sensor or a relay type sensor as the
following figures. The interface type can be controlled by web user interface.
Refer to the provided “PixelPro GXi series Web Page User's Manual”for more details.
Input voltage range: 0VDC minimum to 5VDC maximum, Max 50mA
Caution
!
Before connecting sensors, check driving voltage and output signal type of the
sensor. Since the connection is different according to sensor type, be careful to
connect the sensor. Do not exceed the maximum input voltage or relay rate.
②Alarm (DO) connection
Only the relay type is supported.
Relay Rating: Max 24VDC 50mA
Caution
!
Do not exceed the maximum relay rating.
DO
COM
Relay Type
Device
Internal
+3.3V
DI
COM
DI
COM
+
-
Relay Type
Voltage Type
+
-
Output of
Sensor
Output of
Sensor
Internal
Internal
+
-

PixelPro GXi Series ZN1-B4NVD43 Installation Guide
03-2014-A 14
③LAN connection
This is a RJ45 LAN connector for 10/100 Base-T Ethernet. Use the Ethernet cable (RJ45) to
connect the device to a hub or a router in the network. Refer to “Appendix (B). Power over
Ethernet”for more details.
④Power Connection
The camera can be powered from either 12VDC or PoE. If the camera is powered via PoE, refer
to “Appendix (B). Power over Ethernet”for more details.

PixelPro GXi Series ZN1-B4NVD43 Installation Guide
03-2014-A 15
6. CONFIGURATION
6.1. Set up network environment
The default IP address of the device is 192.168.XXX.XXX. Users can identify the IP address of the
device from converting the MAC address’s hexadecimal numbers, which is attached to the
device. Be sure that the device and PC are on a same area network before running the
installation.
IP address : 192.168.xxx.xxx
Subnet mask: 255.255.0.0
6.1.1. Generic IP Environment
In case of generic private network environment where IP address 192.168.XXX.XXX are used,
users may view the live streaming images on a web page using the device’s default IP address:
1. Convert the device’s MAC address to the IP address. Refer to the Hexadecimal-Decimal
Conversion Chart at the end of the manual.
(The MAC address of the device is attached on the side or bottom of the device.)
2. Start the Microsoft® Internet Explorer web browser and enter the address of the device.
3. Web streaming and device configurations are supported through ActiveX program. When the
ActiveX installation window appears, authorize and install the ActiveX.
MAC address = 00-1C-B8-01-23-45 →IP address = 192.168.35.69
Convert the last two sets of hexadecimal numbers to decimal numbers.

PixelPro GXi Series ZN1-B4NVD43 Installation Guide
03-2014-A 16
6.1.2. Custom IP Environment
IPAdminTool is a management tool, which automatically scans all of the network products for
users to perform administrative tasks, which includes network configurations, firmware update,
device reboot, and device organizations.
To modify the device’s default IP address for customized network area;
1. Find the device from the IPAdminTool’s list and highlight the device’s name.
2. Right-click the mouse and select “IP Address”; IP Setup window appears.
3. In the IP Setup’s window, information under “Local Network information”displays the
user/PC’s network area information. Those information need to be incorporated to the IP
Address, Subnet Mask, Gateway, and DNS boxes, except the last 2 sets of IP Address, which
are to be the unique numbers for the device. Refer to the image above for the setting
4. Click “Setup”to complete the modification.

PixelPro GXi Series ZN1-B4NVD43 Installation Guide
03-2014-A 17
6.2. View video on web page
Type the proper IP address to view the live streaming images through a web browser.
The default username and password is root / pass.
6.2.1. ActiveX Installation
1. When the browser asks to install the AxUMF software, click “Install”to proceed.
2. When Setup installation pop-up window appears, click “Install”to proceed with rest of
installations.
Note
i
Depending on system OS and Internet Explorer version, installation experience
may differ from one another. Figures described above are from Windows 7,
Internet Explorer 9 environment.

PixelPro GXi Series ZN1-B4NVD43 Installation Guide
03-2014-A 18
Caution
!
6.2.2. View video using IPAdmin Tool
IPAdminTool automatically searches all activated network encoders and IP cameras and shows
the product name, IP address, MAC address and etc.
1. From the IPAdminTool’s product list, select the device by highlighting it.
2. Right-click the mouse and select “Web view”.
3. The system’s default web browser opens the device’s address.
Whether directly accessing the streaming video through typing IP address on a
web page or taking steps through IPAdminTool, the ActiveX is needed to be
installed for the Microsoft® Internet Explorer to have the complete
configuration privileges.

PixelPro GXi Series ZN1-B4NVD43 Installation Guide
03-2014-A 19
6.3. Reset
Perform the following procedures to reset your device:
1. Press the reset button for 2 seconds while the device is in use.
2. Wait for the system to reboot.
Caution
!
Please do not hold for more than 2 seconds. Otherwise, the camera may be
switched to its Factory Default settings.
6.4. Factory Default
Resetting the device back to the factory default will initialize all parameters including the IP
address back to the factory defaults. To reset back to the factory default:
1. Press the reset button and hold.
2. Release the button after 10 seconds.
3. Wait for the system to reboot.
Note
i
The factory default settings can be inferred as follows:
IP address: 192.168.xx.yy
Network mask: 255.255.0.0
Gateway: 192.168.0.1
User ID: root
Password: pass

PixelPro GXi Series ZN1-B4NVD43 Installation Guide
03-2014-A 20
6.5. Safe Mode
What is Safe Mode?
Your IP camera or encoder could encounter an unexpected occasion such as broken firmware
file or uncompleted loading of firmware file during system booting. To restore the device from
the occasions, the device provides the emergency firmware as a factory default. Your device
will get restarted with safe mode when there is any error on your booting system files.
Why does your IP camera or encoder boot in Safe Mode?
Normally, the cause of ‘safe mode’ is classified into two types.
* When the power supply is unplugged in the middle of system booting.
* When the firmware files required for system booting are damaged.
IMPORTANT: Your device will turn into the safe mode when it fails to boot certain times.
How to recover your system from Safe Mode
The messages above will appear on the webpage when your device has been rebooted in ‘safe
mode’. Then, you should follow the instructions on the webpage according to the steps in a
row.
Note
i
There are two types of firmware files when you receive a firmware folder from
your vendor. When you need to update the firmware as the final resolution in case
your device is in safe mode like above, ensure that the firmware means the
firmware file for the device with the file name as GXi-V.1.X.X.X-~~~.enc.
Browse
