Gardeners 8587631 User manual

1-800-876-5520 • gardeners.com
[e-mail]
8% of our profits go back to our communities.
Learn more at gardeners.com/FoRCE-FoR-GoOD
0481S Rev 04/2020#8587631, 8596760
PLEASE
RECYCLE
Parts List Tools Needed
(4) 8' CEDAR BOARDS Screw gun or drill with #2 Phillips bit
(4) CORNERS Phillips screwdriver
(2) PLATFORM SUPPORTS Rubber mallet or hammer
(4) FLAT STOCK Tape Measure
(2) 2' END PANELS Clamp (optional)
(3) CROSS SUPPORTS
(4) CORNER CAPS
(66) SCREWS
FLOOR PLANKS
FABRIC LINER
Assembly is easiest with two people.
Assembly
NOTE: The CEDAR BOARDS have rough and smooth sides. The FLOOR PLANKS vary in width.
For video instructions, go to gardeners.com
1. Align the short edges of two 8' CEDAR BOARDS (rough sides facing up) and clamp or hold them firmly together.
2. Slide a CORNER onto the ends of the CEDAR BOARDS, positioning it as shown in Figure 1. The top CEDAR BOARD should
come to sit ⅛" above the top of the CORNER.
3. Making sure there is no gap between CEDAR BOARDS and that they are fully seated into the CORNER, secure with PHILLIPS
SCREWS. Leave the 2nd hole from the bottom open for now.
4. Repeat Steps 1-3 to attach another CORNER to the other end.
5. Take a PLATFORM SUPPORT and place the face with 4 holes against the CEDAR BOARDS as shown in Figure 1. Align the
holes on the ends with the holes you left open in Step 3 and secure with PHILLIPS SCREWS.
6. Slide 2 FLAT STOCK underneath the PLATFORM SUPPORT and align holes as shown in Figure 1. Secure the FLAT STOCK with
PHILLIPS SCREWS.
7. Repeat Steps 1-6 to assemble the other side panel.
8' CEDAR BOARDS
(rough faces)
holes
PLATFORM SUPPORT
FLAT STOCK
CORNER
Figure 1
The top CEDAR
BOARD should
sit ⅛" above
the CORNER.
Instructions for 2' x 8' Elevated Cedar Planter Box

8. Use a rubber mallet to tap a pre-assembled 2' END PANEL into the open channel of a CORNER, positioning it so the CROSS
SUPPORT sits under the PLATFORM SUPPORT on the 8' side panel as shown in Figure 2. Ensure END PANEL is fully seated and ⅛"
above the top of the CORNER, then secure with PHILLIPS SCREWS as shown. Repeat to attach the remaining 2’ END PANEL to the
other end.
9. Place the remaining 8’side panel on a flat surface. Carefully guide the ends of the 2’ END PANELS of your partially assembled
box into the open channels of the CORNERS. Secure with PHILLIPS SCREWS. Once all panels are attached, stand your Planter
Box right side up and tap a CORNER CAP into the top of each aluminum CORNER.
10. Install the 3 CROSS SUPPORTS to and under the PLATFORM SUPPORTS as shown in Figure 3. Secure with SCREWS from the
top.
11. Insert the cedar FLOOR PLANKS, leaving small gaps between them (this will allow water to drain). Then, insert the FABRIC
LINER.
Filling and Planting
Fill your Planter Box with a lightweight potting mix. Do not use a heavy garden soil as that may overload your planter. Add
some organic matter, such as compost and a slow-release fertilizer for best results. You're now ready to add your plants!
For gardening tools and supplies plus how-to articles and videos on
growing vegetables and flowers in containers and raised beds, visit us at gardeners.com
CROSS
SUPPORT
Figure 2
8' SIDE PANEL
2' END PANEL
PLATFORM
SUPPORT
SCREW
CROSS SUPPORTS
Figure 3
CROSS
SUPPORT
SCREW
PLATFORM SUPPORT
