GARDINER TECHNOLOGY 2897PDF Setup guide

Gardtec 350+
2897PDF
GARDINER TECHNOLOGY
Gardtec 350+
Quick Start
User Guide

Introduction
This Quick Start Guide is intended to help end users who are new to security
systems in the day to day use of the system.We recommend that this guide is used
in conjunction with the end user manual that was supplied with the control panel.
Your Gardtec 350 Control Panel will have been fully programmed by your installation
engineer to suit your needs. Should your requirements change with time the
installation company who originally installed your system are the people best suited
to advise you on your new requirements.
Display of the system status is given via eight LEDs (Light Emitting Diodes).When
using the Gardtec 350 in its normal mode the bold legend to the left of the LEDs is
used (see below).
Bold legend for normal use User programming mode legend
System Status LEDs
The legend to the right of the LEDs is used when in user programming mode, this is
dealt with later in this guide.
Caring for your System
Your security system needs to be serviced on a regular basis to ensure its reliability
and effectiveness.Your installation company will advise you on suitable service
periods for your system.
Day to Day care of your system is a wipe over with a slightly moist cloth.
Under no circumstances should you use abrasives or detergent on any part of
the system.
Damage to any control equipment, detectors or sounders should be reported to your
installation company as soon as possible.

Tampers & PAs
Your security system protects itself against tampering. In the event of any control
equipment, detectors or sounders being opened or cables being cut the internal
and/or the external will sound. Dependant on the level of system you have installed
this may require an engineer call-out to reset the system.
The keypad (onboard or remote) is also protected. If more than 24 invalid digits are
pressed an internal alarm will be generated if the system is unset or a full alarm will
be generated if the system is set.
Your installer may have fitted various PA (Personal Attack) buttons on to your system
and instructed you on the use of them.You can also activate a PA by pressing keys
1 & 3 together.
To Activate PA from Keypad
PA is a 24 hour function and will operate if the system is set or unset.
To Silence Sounders After PA Activation
Unset & Set Display Status
The following shows the display status when the system is Set and Unset
&Together = PA
The system is Unset
(Day Mode)
Only PA and Tampers are active
The system is Set
All or Part of the system is active

Power LED
The Power LED gives an indication of that the mains supply to the unit is good. It
should be illuminated at all times except when User Programming mode is being
used. Please refer to User Programming Mode section for more details.
Setting the System
When you set the system fully all zones are active after the setting delay has
expired.
Exit Wait
After exiting and securing the premises always wait until the exit sounders have
stopped before leaving.
To Abort Setting During Exit Time
Part Setting the System
Your installation engineer may have programmed up to two part sets for your
system, these part sets are defined below.
Part 1 A group of system zones that will be removed (turned off)
when Part 1 set is used. Some or all of these zones may also
be contained within Part 2.
Part 2 A group of system zones that will be removed (turned off)
when Part 2 set is used. Some or all of these zones may also
be contained within Part 1.
A third part set is also available as defined below.
Part 3 All system zones that are programmed as Part 1 and Part 2
will be removed (turned off) when Part 3 set is used.
Your installation engineer will provide you with information about system zones that
are programmed as part set zones (if any).

To Part Set the System
Then retire to an unprotected area
Note: Your engineer may have programmed the Part Set exit sounders as silent.
If so a single beep will be given when the exit time expires.
Unsetting the System
Your installation engineer will have defined to you what route you should take when
entering the premises with the system set.To avoid false alarms you must always
take this route.
To Unset the System
Enter
Note: If an alarm has occurred when the system was set all LEDs will be flashing
when you unset the system. Pressing the No key will display the cause of the
alarm for 3 seconds. Please refer to the Resetting After An Alarm section for
reset details.
+
or
+
or
+
For Part Set 1
For Part Set 2
For Part Set 3

Resetting After An Alarm
After an alarm all the LEDs will be flashing. Pressing No will display the cause of the
alarm for 3 seconds. For example.
System is Unset. Z 3 illuminated.
All LEDs are flashing. Zone 3 was activated
when system was set.
To Reset The Alarm
If the system is set, unset it and then proceed as follows.
Display shows.

User Programming Mode
To enhance the flexibility of the Gardtec 350 control panel there are five user
programmable options available.When programming the user options the display is
via the five zone LEDs and the legend to the right of the LEDs is used (see
illustration below). It should be noted that User Programming Mode is only available
to Master level codes ( User Numbers 1, 4 and 5 please refer to user code
programming for more details).
Bold legend for normal use User programming mode legend
System Status LEDs
LED Modes
When programming the user options three LED states are possible.
User Programmable Options
Five User Programmable options are available, these are.
REMOVE
This option enables a Master user to Remove (turn off) individual zones when
setting the system.This is in addition to any part sets that may have been
programmed by the installation engineer. When this option is used it should be
noted that the selected zones will be removed for the one set only.

TEST
This option allows a Master User to test the system zones and sounders.
LOG
This option allows a Master User to view the system Event Log.
CHIME
One or more system zones may have been programmed as chime zones by your
installation engineer.This option allows a Master User to turn the Chime function On
or Off.
PROGRAM
Up to nine user codes may be programmed onto the system by a Master User.
Removing Individual Zones
With the system in Day Mode (Unset).
The display will show. *
The display will show.
Press the key (1-5)
corresponding to the zone
you wish to remove from
this set.

The display will show.
If you wish to Remove more zones return to *
OR
To set the system with the Zone(s) you selected Removed
Exit Wait
After exiting and securing the premises always wait until the exit sounders have
stopped before leaving.
Note: The selected zones have been Removed for this one set only.
Testing The System
With the system in Day Mode (Unset).

The display will show.
The display will show.
The display will show.
When you have finished testing the system press.
This is Test Mode.You may now ‘walk Test’ the system.
Each time you activate a zone the internal sounder will
sound and the corresponding LED will illuminate on the
control panel.
To test the external sounder use the 9 key to toggle them
on and off.

Viewing The Log
With the system in Day Mode (Unset).
The display will show.
The display will show.
The display will show.

The display will now show the last system event and will vary dependant on what
that event was.
Whilst using the Log Mode the No key is used to move to the previous event and the
Yes key is used to move to the next event.
Whilst Viewing The Log
Moves to previous event Moves to next event
Whilst viewing the Log the LEDs may show the following
All LEDs On Panel was Powered Up
Day + Zone 1 LED Unset by user No.1
Day + Zone 2 LED Unset by user No.2
Day + Zone 4 LED Unset by user No.4
Day + Zone 5 LED Unset by user No.5
Day LED Unset by user No.6 or 7
Day + Tamper LED Unset by user No.8
Rapid Flashing Day LED System was Set
Slow Flashing Day LED System was Part Set
Zone LED Flashing Zone was Removed when system was Set
All LEDs Flashing Alarm press No to view the cause
To escape from the Log Mode

Turning Chime On/Off
Chime zones will have been previously programmed by your installation engineer. A
Master level user may turn the Chime function On or Off. Zones that are
programmed as Chime zones will give a low level ‘beep’ sequence when activated.
With the system in Day Mode (Unset).
The display will show.
The display will show.
The display will show.

The display will show.
The display will show.
To Escape back to Day Mode.
Programming User Codes
Up to nine user codes may be programmed into the 350+ control panel, each user
code has a predetermined level of access.
User Number 1 Factory Default Master (5678 default code)
User Numbers 1, 4and 5Are Master level Codes and may set, partset,
unset and access user programming mode.
User Numbers 2, 6, 7and 8Are User level Codes and may set, partset and
unset.
User Numbers 3 and 9Are Set Only levels Codes and may only set the
system.
To change from On
to Off or Off to On

The sequence for programming User Codes is.
Enter User Code Programming Mode
Enter the User Number (1 to 9) you wish to program
Enter the Code you require for the User
Re-Enter the Code you require for the User
Return to Day Mode
This is shown step by step below.
Programming User Codes
With the system in Day Mode (Unset).
The display will show.

The display will show.
The display will show.
The display will show.

The display will show.
The display will show.
The display will show.
Enter
User Number
(1 to 9)
Note:Tamper LED has rapid flash
Enter
New Code
Note:Tamper LED has slow flash

The display will show.
The display will show.
To Escape back to Day Mode
Note: To delete a User Code enter 0000 as the New Code.User Number 1 is
the main system code, therefore it may only be changed and not deleted.
Additional information is contained within the User Manual that was supplied
with the Gardtec 350 Control Panel.
Enter
New Code
Again
Note:Tamper LED has faster flash
