Garmin SPEED SENSOR 2 Instruction manual

Speed Sensor 2
Cadence Sensor 2
Quick Start Manual .........................4
快速入門手冊 .................................17
快速入门手册 .................................30
クイックスタートマニュアル .......46
빠른 시작 설명서..............................60
คูมือ Quick Start .............................70
Panduan Cepat Penggunaan........80
Hướng dẫn bắt đầu nhanh ...........92

Spd/Cad Sensor 2 1
EN
© 2019 Garmin Ltd. or its subsidiaries
Garmin, the Garmin logo, and ANT+ are trademarks of Garmin
Ltd. or its subsidiaries, registered in the USA and other
countries. Garmin Connect is a trademark of Garmin Ltd. or its
subsidiaries. These trademarks may not be used without the
express permission of Garmin.
The Bluetooth®word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by Garmin is
under license.
This product is ANT+ certied. Visit www.thisisant.com/
directory for a list of compatible products and apps.
M/N: A03650, A03610

2 Spd/Cad Sensor 2
EN
IMPORTANT SAFETY AND
PRODUCT INFORMATION
WARNING
Failure to heed the following warnings could result in an
accident or medical event resulting in death or serious injury.
Battery Warnings
Coin cell batteries can be used in the accessory.
If these guidelines are not followed, batteries may experience
a shortened life span or may present a risk of damage to the
device, re, chemical burn, electrolyte leak, and/or injury.
• Do not disassemble, modify, remanufacture, puncture or
damage the device or batteries.
• Do not expose the device or batteries to re, explosion,
or other hazard.
• Do not place in high temperature environments, such as
a clothes dryer.
• Do not use a sharp object to remove the removable
batteries.
• KEEP BATTERIES AWAY FROM CHILDREN.
NEVER PUT BATTERIES IN MOUTH. Swallowing
can lead to chemical burns, perforation of soft tissue,
and death. Severe burns can occur within 2 hours of
ingestion. Seek medical attention immediately.
Health Warnings
• Always consult your physician before beginning or
modifying any exercise program.
NOTICE
Failure to heed the following notice could result in personal
or property damage, or negatively impact the device
functionality.

Spd/Cad Sensor 2 3
EN
Battery Notices
• Do not immerse or expose batteries to water or other
liquids.
• Do not leave the device exposed to a heat source or in
a high-temperature location, such as in the sun in an
unattended vehicle. To prevent the possibility of damage,
remove the device from the vehicle or store it out of
direct sunlight, such as in the glove box.
• Do not operate the device outside of the temperature
ranges specied in the printed manual in the product
packaging.
• When storing the device for an extended time period,
store within the temperature ranges specied in the
printed manual in the product packaging.
• Replaceable coin cell batteries may contain perchlorate
material. Special handling may apply. Contact your local
waste disposal department to dispose of the device/
batteries in accordance with applicable local laws
and regulations.
Product Environmental Programs
Information about the Garmin product recycling program and
WEEE, RoHS, REACH, and other compliance programs can be
found at Garmin.com/aboutGarmin/environment.
Limited Warranty
The Garmin standard limited warranty applies to this
accessory. For more information, go to Garmin.com.sg/
support/warranty.html.

4 Spd/Cad Sensor 2
EN
Quick Start Manual
WARNING
See the Important Safety and Product
Information guide in the previous pages
for product warnings and other important
information.
Installing the Speed Sensor
NOTE: If you do not have this sensor, you can
skip this task.
TIP: Garmin recommends you secure your
bike on a stand while installing the sensor.
1Place and hold the speed sensor on top of
the wheel hub.
2Pull the strap ① around the wheel hub,
and attach it to the hook ② on the sensor.
The sensor may be tilted when installed on
an asymmetrical hub. This does not affect
operation.

Spd/Cad Sensor 2 5
EN
3Rotate the wheel to check for clearance.
The sensor should not contact other parts
of your bike.
NOTE: The LED ashes green for ve
seconds to indicate activity after two
revolutions.
Installing the Cadence Sensor
NOTE: If you do not have this sensor, you can
skip this task.
TIP: Garmin recommends you secure your
bike on a stand while installing the sensor.
1 Select the band size that ts your crank
arm ① securely.
The band you select should be the
smallest one that stretches across the
crank arm.
2On the non-drive side, place and hold the
at side of the cadence sensor on the
inside of the crank arm.
3Pull the bands ② around the crank arm,
and attach them to the hooks ③ on the
sensor.

6 Spd/Cad Sensor 2
EN
4Rotate the crank arm to check for
clearance.
The sensor and bands should not contact
any part of your bike or shoe.
NOTE: The LED ashes green for ve
seconds to indicate activity after two
revolutions.
5Take a 15 minute test ride and inspect the
sensor and bands to ensure there is no
evidence of damage.
Pairing the Sensors with Your
Garmin Device
The rst time you connect a wireless sensor
to your device using ANT+ or Bluetooth®
technology, you must pair the device and
sensor. After they are paired, the device
connects to the sensor automatically when
you start an activity and the sensor is active
and within range.

Spd/Cad Sensor 2 7
EN
NOTE: The pairing instructions differ for each
Garmin compatible device. See your owner’s
manual.
• Bring the Garmin compatible device within
3 m (10 ft.) of the sensor.
• Stay 10 m (33 ft.) away from other
wireless sensors while pairing.
After you pair the rst time, your Garmin
compatible device automatically recognizes
the wireless sensor each time it is activated.
Pairing the Speed Sensors With Your
Smartphone
The speed sensors must be paired directly
through the Garmin Connect app, instead
of from the Bluetooth settings on your
smartphone.
1From the app store on your smartphone,
install and open the Garmin Connect app.
2Bring your smartphone within 3 m (10 ft.)
of the sensor.
NOTE: Stay 10 m (33 ft.) away from other
wireless sensors while pairing.
3Select an option to add your device to your
Garmin Connect account:
• If this is the rst device you have
paired with the Garmin Connect app,
follow the on-screen instructions.
• If you have already paired another

8 Spd/Cad Sensor 2
EN
device with the Garmin Connect
app, from the or menu, select
Garmin Devices > Add Device, and
follow the on-screen instructions.
User Replaceable Batteries
WARNING
See the Important Safety and Product
Information guide in the previous pages box
for product warnings and other important
information.
Replacing the Speed Sensor Battery
The LED ashes red to indicate a low battery
level after two revolutions.
1Locate the circular battery cover ① on the
front of the sensor.

Spd/Cad Sensor 2 9
EN
2Twist the cover counter-clockwise until the
marker points to unlocked and the cover is
loose enough to remove.
3Remove the cover and the battery ② .
4Wait 30 seconds.
5Insert the new battery into the cover,
observing polarity.
NOTE: Do not damage or lose the O-ring
gasket.
6Twist the cover clockwise until the marker
points to locked.
NOTE: The LED ashes red and green for a
few seconds after battery replacement.
When the LED ashes green and then
stops ashing, the device is active and
ready to send data.
Replacing the Cadence Sensor Battery
The LED ashes red to indicate a low battery
level after two revolutions.
1Locate the circular battery cover ① on the
back of the sensor.

10 Spd/Cad Sensor 2
EN
2Twist the cover counter-clockwise until the
marker points to unlocked and the cover is
loose enough to remove.
3Remove the cover and the battery ② .
4Wait 30 seconds.
5Insert the new battery into the cover,
observing polarity.
NOTE: Do not damage or lose the O-ring
gasket.
6Twist the cover clockwise until the marker
points to locked.
NOTE: The LED ashes red and green for a
few seconds after battery replacement.
When the LED ashes green and then
stops ashing, the device is active and
ready to send data.

Spd/Cad Sensor 2 11
EN
Speed Sensor and Cadence Sensor
Specications
Battery type User-replaceable
CR2032, 3 volts
Battery life Approximately 12 mo.
at 1 hr./day
Operating
temperature range
From -20º to 60ºC
(from -4º to 140ºF)
Water rating IEC 60529 IPX7*
*The device withstands incidental exposure to
water of up to 1 m for up to 30 min.
For more information, go to Garmin.com.sg/
legal/waterrating.

12 Spd/Cad Sensor 2
EN

TW
Spd/Cad Sensor 2 13
© 2019 Garmin Ltd. 及其子公司版權所有
Garmin、Garmin 標誌、ANT+ 與Garmin Connect
均為 Garmin Ltd. 或其子公司的註冊商標。未經
Garmin Ltd. 或其子公司的同意，不得使用其商標。
Bluetooth®文字及商標為 Bluetooth SIG, Inc. 所
有，Garmin 已取得此類商標使用許可。
本產品經 ANT+ 認證，請參考 www.thisisant.
com/directory 取得相容產品與 APP 應用程式的清
單。
M/N: A03650, A03610

TW
14 Spd/Cad Sensor 2
安全及產品資訊須知
警告
未能避免下列潛在危險情況，有導致死亡或嚴重
傷害的可能。
電池警告
此配件使用鈕扣電池。
若未遵照下列準則，裝置內的鋰離子電池壽命可
能會縮短，或有裝置損壞、發生火災、化學品灼
傷、電解液洩漏或受傷的風險。
• 請勿拆解、鑿孔或損壞裝置或電池。
• 請勿將裝置或電池曝露於火焰、爆炸或其他危
險中。
• 請勿將裝置曝露於高溫的環境（例如烘衣機）。
• 請勿使用尖銳物品取出電池。
• 請勿將電池放置在兒童可取得的地方。
請勿將電池放入口中。吞下電池可能造成
化學灼傷、軟組織穿孔，甚至死亡。吞入 2小
時內便可能造成嚴重灼傷，請立即尋求醫療協
助。
健康警告
• 在開始或改變運動計畫前，請務必先諮詢您的
醫師。
注意
未遵守以下事項可能會導致個人或財產損失，或
對裝置造成不良的影響。
電池注意事項
• 請勿將電池浸入或曝露於水或其他液體中。
• 請勿將裝置曝露於熱源或處於高溫地點，例如
將車輛停放在無人看管的太陽直射處。為防止
裝置損壞，可將裝置從車上拆下或將其存放在
如置物箱內等以避免陽光直射。

TW
Spd/Cad Sensor 2 15
• 裝置請在包裝內使用手冊指示的溫度範圍內進
行操作。
• 若需長時間存放裝置，請將其存放在包裝內使
用手冊指示的溫度範圍內。
• 替換的鈕扣電池可能含有高氯酸鹽物質，可能
需使用特殊處理方式，處置裝置 /電池時請依
照當地適用法規，洽詢當地廢棄物處置部門。
產品環境計劃
如需 Garmin 產品回收計劃及 WEEE、RoHS、
REACH 和其他符合性計劃的詳細資訊，請參考
Garmin.com/aboutGarmin/environment。
低功率電波輻射電機管理宣告
本產品僅遵循中華民國國家通訊傳播委員會所頒
布低功率電波輻射性電機管理辦法規範，並經驗
證通過合格，請使用者遵循相關電信法規以避免
違反規定受罰。若使用者欲攜帶本機至其它國家
應用，也請遵循該地區或國家之相關法令限制。
根據國家通訊傳播委員會低功率電波輻射性電機
管理辦法規定：
1. 第十二條
經型式認證合格之低功率射頻電機，非經許
可，公司、商號或使用者均不得擅自變更頻
率、加大功率或變更原設計之特性及功能。
2. 第十四條
低功率射頻電機之使用不得影響飛航安全及干
擾合法通信；經發現有干擾現象時，應立即停
用，並改善至無干擾時方得繼續使用。
前項合法通信，指依電信法規定作業之無線電
通信。低功率射頻電機須忍受合法通信或工
業、科學及醫療用電波輻射性電機設備之干擾。
有限保固
關於 Garmin 保固條款，請前往 Garmin.com.tw/
support/warranty 了解更多資訊。

TW
16 Spd/Cad Sensor 2
銷售廠商 : 台灣國際航電股份有限公司
聯絡地址 : 新北市汐止區樟樹二路 68 號
電 話 : [phone]
客服專線 : [phone]
廢電池請回收，當機台不易拆解時，
請整機交由資源回收系統回收。

TW
Spd/Cad Sensor 2 17
快速入門手冊
警告
關於產品風險以及重要資訊，請詳閱
包裝內手冊前段的《安全及產品資訊
須知》。
安裝速度感測器
備註：如果您沒有此配件，請略過此
段說明。
小秘訣：建議您在安裝感測器時，將
自行車固定在自行車架上。
1將速度感測器 Garmin 字樣朝上，
固定於花鼓上。
2將固定帶 ①繞過花鼓並扣上 ②的
凹槽。
安裝在不對稱的花鼓上可能會造成
感測器的傾斜，但這不會影響其運
作。
3轉動車輪確認不會造成干擾。

TW
18 Spd/Cad Sensor 2
感測器不應與自行車其它部位有任
何接觸或摩擦。
備註：轉動兩圈後，LED 閃爍綠燈
5 秒代表已啟動。
安裝踏頻感測器
備註：如果您沒有此配件，請略過此
段說明。
小秘訣：建議您在安裝感測器時，將
自行車固定在自行車架上。
1請選擇適合您曲柄 ①厚度的橡膠
環。請選用能繞過曲柄的最小橡膠
環。
2將踏頻感測器放在非大盤側的曲柄
內側。
3請將橡膠環 ②勾住感測器一邊的
卡榫，繞過曲柄再勾住另一邊的卡
榫③。
4轉動曲柄確認不會造成干擾。

TW
Spd/Cad Sensor 2 19
感測器與橡膠環不應接觸到您的鞋
子或自行車其它部位。
備註：轉動兩圈後，LED 閃爍綠燈
5 秒代表已啟動。
5試騎 15 分鐘並檢查感測器與橡膠
環無損壞之虞。
配對感測器與 Garmin 裝置
首次使用 ANT+ 或藍牙連結感測器
前，必須先將您的裝置與感測器進行
配對。完成配對後，每當您開始活動
且感測器在連結範圍內時，裝置即會
自動與感測器連線。
備註：每種相容裝置配對方式不盡相
同，請查閱各裝置的使用手冊。
• 將裝置與感測器保持在 3 公尺以
內的距離。
• 配對時請遠離其他無線感測器 10
公尺以上。
完成第一次配對後，您相容的 Garmin
裝置即會自動識別已啟動的無線感測
器。
配對速度感測器與智慧型手機
速度感測器必須先在 Garmin Connect
應用程式內進行配對，而非在手機的
藍牙設定頁面配對。
