2010 Vertical Zoneline®/Zoneline®/Built-in models

Vertical Zoneline®units

Vertical Zoneline units

*A-B Series: Zoneline®units built before 1987 – Zoneline I, II, III, and IV; AZC Series: Zoneline units built from 1987 to 1992 – includes AZR Series – Zoneline 1000, 2000, 2500, 2700, 3000,

4000, 5000; AZ Series: Zonelines built after 1992 – Zoneline 2100, 3100, 2600, 5100 / Zoneline 2200, 3200, 5200 / Zoneline 2500, 3500, 5500 / Zoneline 2800, 2900, 3800, 3900, 4100,

5800, 6100, 7500, 8500.

RAVWP6 (AZ Series*—7500/8500)

Wall Plenum

• Wallplenumforinstallationinwallslessthan6"thick

• Wallplenum19-3/4"x32"

• Wallcutoutdimensions20"x32-1/4"

• Warmgraybeigecolor

RAVWP8 (AZ Series*—7500/8500)

Wall Plenum

• Wallplenumforinstallationinwallslessthan8"thick

• Wallplenum19-3/4"x32"

• Wallcutoutdimensions20"x32-1/4"

• Warmgraybeigecolor

RAVWP12 (AZ Series*—7500/8500)

Wall Plenum

• Wallplenumforinstallationinwallslessthan12"thick

• Wallplenum19-3/4"x32"

• Wallcutoutdimensions20"x32-1/4"

• Warmgraybeigecolor

RAVWP15 (AZ Series*—7500/8500)

Wall Plenum

• Wallplenumforinstallationinwallslessthan15"thick

• Wallplenum19-3/4"x32"

• Wallcutoutdimensions20"x32-1/4"

• Warmgray-beigecolor

Vertical Zoneline®units

RAVRG1 (AZ Series*—7500/8500)

Access Panel with Return Air Grille

• Accesspanelwithreturnairgrilleforinstallation

in closet wall

• Allowsaccess/removalofVerticalZonelinefor

cleaning or service

• Outsidedimensions30"x50"

• Wallcutoutdimensions28"x48"

• Accepts20"x20"x1"field-suppliedfilter

• Warmgray-beigecolor

RAVAL1 (AZ Series*—7500/8500)

Aluminum Outdoor Grille

• Extrudedaluminumoutdoorgrilleforinstallation

onRAVWPserieswallplenums

• Grilleis19-3/4"x32"x1-1/4"

• Millfinish

*A-B Series: Zoneline units built before 1987 – Zoneline I, II, III, and IV; AZC Series: Zoneline units built from 1987 to 1992 – includes AZR Series – Zoneline 1000, 2000, 2500, 2700, 3000,

4000, 5000; AZ Series: Zonelines built after 1992 – Zoneline 2100, 3100, 2600, 5100 / Zoneline 2200, 3200, 5200 / Zoneline 2500, 3500, 5500 / Zoneline 2800, 2900, 3800, 3900, 4100,

5800, 6100, 7500, 8500.

RAVRMS (AZ Series*—7500/8500)

Wall-Mounted Room Air Sensor

• Wall-mountedroomairsensorprovidesTemperature

Limiting and Freeze Sentinel™capability

•Includes3-meterconductorwireforhook-upto

Vertical Zoneline

• RequiredforMotionSensor/DoorSwitchapplications

RAVRG2 (AZ Series*—7500/8500)

Return Air Grille

• Returnairgrilleforinstallationinclosetwall

• Exteriordimensions22-1/2"x22-1/2"

• Wallcutoutdimension20-3/8"x20-3/8"

• Accepts20"x20"x1"field-suppliedfilter

• Warmgray-beigecolor

RAK4157/4207/4307†

(AZ Series*—7500 and 8500 only)

230/208-Volt Universal Power Supply Kit

• 9-pinconnectorwiththree7"12-gaugeconductorwires.

Circuit

Kit No. Volts Heater Wattage Ampacity

RAK4157 230/208 2,610/2,190 15

RAK4207 230/208 3,420/2,870 20

RAK4307 230/208 4,810/4,070 30

RAK5157/5207/5307†

(AZ Series*—7500 and 8500 only)

265/277-Volt Universal Power Supply Kit

• 9-pinconnectorwiththree7"12-gaugeconductorwires.

Circuit

Kit No. Volts Heater Wattage Ampacity

RAK5157 265/277 2.71 kw 15

RAK5207 265/277 3.55 kw 20

RAK5307 265/277 5.03 kw 30

RAK3152/3202/3302†

(AZ Series*—7500/8500 only)

15, 20, and 30 Amp (230/208 Volts)

Universal Power Supply

Circuit

Kit No. Volts Heater Wattage Ampacity

RAK3152 230/208 2,610/2,190 15

RAK3202 230/208 3,420/2,870 20

RAK3302 230/208 4,810/4,070 30

*A-B Series: Zoneline units built before 1987 – Zoneline I, II, III, and IV; AZC Series: Zoneline units built from 1987 to 1992 – includes AZR Series – Zoneline 1000, 2000, 2500, 2700, 3000,

4000, 5000; AZ Series: Zoneline units built after 1992 – Zoneline 2100, 3100, 2600, 5100 / Zoneline 2200, 3200, 5200 / Zoneline 2500, 3500, 5500 / Zoneline 2800, 2900, 3800, 3900, 4100,

5800, 6100, 7500, 8500.

†ThepowerconnectionkitdeterminestheheaterwattageandcurrentrequirementswhenitispluggedintotheZonelineunit.NOTE:7,000BTUmodelsdonothave5,000-wattheaters.

Zoneline®units

RAB71A (All Zoneline Series)

Standard Wall Case

TheRAB71Aisagalvanizedsteelwallsleevewithexpandedpolystyrene

foaminsulation.Itismechanicallyfastenedandprotectedwithbaked-

onenamelandprotectedwithasealingcompoundtopreventrust.The

RAB71A wall case accepts all Zoneline chassis models.

Alsoavailablewithextendeddepths:

•RAB7116—16"deep •RAB7128—28"deep

•RAB7124—24"deep •RAB7131—31"deep

Zoneline units

*A-B Series: Zoneline units built before 1987 – Zoneline I, II, III, and IV; AZC Series: Zoneline units built from 1987 to 1992 – includes AZR Series – Zoneline 1000, 2000, 2500, 2700, 3000,

4000, 5000; AZ Series: Zoneline units built after 1992 – Zoneline 2100, 3100, 2600, 5100 / Zoneline 2200, 3200, 5200 / Zoneline 2500, 3500, 5500 / Zoneline 2800, 2900, 3800, 3900, 4100,

5800, 6100, 7500, 8500.

RAD10 (All Zoneline Series)

Internal/External Drain Kit

Formorepositivecontrolofcondensatewater,theRAD10drainkit

routes condensate to the exterior or to the interior of the building

through the wall case. Suitable provision (field applied) should be

madetoconnecttheRAD10draintubetoadrainsysteminthe

building.Draintubeassembliesare1/2"ODcopperandconsist

ofashortright-angletubeanda6"-longstraighttubetosuitthe

particular application.

RAF452 (AZ Series*—2200, 3200 and 5200 only)

Replacement Standard Room Cabinet

Room cabinet with wraparound design has attractive textured finish

which matches unit sleeve. Cabinet is injection-molded of high-impact

polystyrene.Cabinetfastenstochassiswithouttoolsorhardware.The

room cabinet contains the slide-out filters and 2-position reversible

discharge louvers.

RAB77A4 (All Zoneline Series)

SMC Wall Case

TheZonelineSMCuniversallydesignedwallcasebyGEutilizesa

fiberglass-reinforced polyester compound to produce a durable,

non-corrosivewallcaseforallZonelinePackagedTerminalAir

ConditionersandHeatPumps.TheRAB77A4SMCwallcase

accepts all Zoneline chassis models.

RAF452A (AZ Series*—2500, 3500 and 5500 only)

Replacement Standard Room Cabinet

Room cabinet with wraparound design has attractive textured finish

which matches unit sleeve. Cabinet is injection-molded of high-impact

polystyrene.Cabinetfastenstochassiswithouttoolsorhardware.The

room cabinet contains the slide-out filters and 2-position reversible

discharge louvers.

RAG67 (AZ Series*)

Aluminum Architectural Outdoor Grille

• ExtrudedaluminumoutdoorgrilleforusewithRAB71,RAB77, 

and extended wall cases

• Grillesarepaintabletomatchbuildingdécor

RAKOIM (AZ Series*—2200, 3200 and 5200 only)

Optional Interface Module for Central Desk

Control or Remote Thermostat Control

TheRAKOIMisrequiredifaunitistobeinstalledwithaCentralDesk

ControloraRemoteThermostatControl.Includesscrew,andashort

wireharnessontheRAKOIMthatispluggedintothematingreceptacle

on the front of the control box.

*A-B Series: Zoneline units built before 1987 – Zoneline I, II, III, and IV; AZC Series: Zoneline units built from 1987 to 1992 – includes AZR Series – Zoneline 1000, 2000, 2500, 2700, 3000,

4000, 5000; AZ Series: Zoneline units built after 1992 – Zoneline 2100, 3100, 2600, 5100 / Zoneline 2200, 3200, 5200 / Zoneline 2500, 3500, 5500 / Zoneline 2800, 2900, 3800, 3900, 4100,

5800, 6100, 7500, 8500.

Zoneline®units

RAG61/62/63 (AZ Series*)

Architectural Rear Grille

Optional,one-piecemoldedgrilleandframeassemblyforimproved

appearance and protection. Grilles are molded of GE Cycoloy®and

have a slightly textured, colorfast surface to blend with most walls.

RAG61–Beige,RAG62–Maple,RAG63–DarkBrown

RAG61/62/63

RAG60 (AZ Series*)

Stamped Aluminum Exterior Rear Grille

Thestandardexteriorgrilleismadeofdurablealuminumtoprotect

chassis components and minimize air recirculation.

RAF453 (AZ Series*—2800, 2900, 3800, 3900 and

5800 only)

Replacement Standard Room Cabinet

Room cabinet with wraparound design has attractive textured finish

which matches unit sleeve. Cabinet is injection-molded of high-impact

polystyrene.Cabinetfastenstochassiswithouttoolsorhardware.The

room cabinet contains the slide-out filters and 2-position reversible

discharge louvers.

RAK40 (AZ Series*)

Air Deflector Kit

KitadaptsAZchassisforusewitholderGEarchitecturalgrilles.The

aluminum deflectors are installed to the condenser end sheet flanges

topreventcondenserairflowrecirculation.Thekitalsoallowssome

custom (non-standard) rear grilles to be used, provided they have

sufficient open area.

Zoneline units

RAK601/602 (AZC and AZ Series*—2100, 2200, 2500,

2800, 2900, 3100, 3200, 3500, 3800, 3900, 4100 and

6100 only)

Duct Extension, Register and Trim Flange

RAK601isa44"-longductandincludesanairregisterandtrimflange

forthesecondaryspace.IftwoextensionsaremadefromoneRAK601

duct, an additional air register and trim flange can be ordered

separately as an RAK602, reducing the cost of the installation. For use

with RAK605 and RAK6052.

*A-B Series: Zoneline units built before 1987 – Zoneline I, II, III, and IV; AZC Series: Zoneline units built from 1987 to 1992 – includes AZR Series – Zoneline 1000, 2000, 2500, 2700, 3000,

4000, 5000; AZ Series: Zoneline units built after 1992 – Zoneline 2100, 3100, 2600, 5100 / Zoneline 2200, 3200, 5200 / Zoneline 2500, 3500, 5500 / Zoneline 2800, 2900, 3800, 3900, 4100,

5800, 6100, 7500, 8500.

RAK605 (AZ Series*—2100 and 3100 only)

Duct Adapter

(Notfor2600and5100Series)

TheRAK605ductadapterisattachedtothetopofthewallcaseto

allow the air from the Zoneline unit to heat or cool an adjacent room.

DuctextensionRAK601canbeappliedtorightorleftoftheadapter.

(Zoneline 2600 and 5100 Series not approved for ducted application).

7-3/32"

6-1/2"

RAK6052 (AZ Series*—2200, 2500, 2800, 2900, 3200,

3500, 3800, 3900, 4100 and 6100 only)

Duct Adapter

(Notfor5200,5500or5800Series)

TheRAK6052ductadapterisattachedtothetopofthewallcase

to allow the air from the Zoneline unit to heat or cool an adjacent

room.DuctextensionRAK601canbeappliedtorightorleftof

the adapter. (Zoneline 5200, 5500 and 5800 Series not approved for

ducted application).

7-3/32"

6-1/2"

RAK201 (AZC and AZ Series*)

Access Plate Cover

TheRAK201accessplatecoverismadeofheavy-gaugesteelwith

multipleknockoutsforspecialapplications.Willadapttoservice

conduit.875"or1.125";circuitbreakerupto30ampor30amp

receptacle.TheRAK201fitsoldsub-basesRAK120,RAK121and

RAK122 for easy replacement of A-B series with AZC and AZ series.

RAK7022 (AZ Series*—2200, 2500, 2800, 2900, 3200,

3500, 3800, 3900, 4100 and 6100 only) Duct Transition

for Replacement of AZC with Rounded-Front AZ Chassis

TheRAK7022ducttransitionisdesignedtoallowductinstallationwherethe

original chassis was a slope-front discharge (AZC/AZR/AZ21/AZ31) chassis.

UsingtheRAK7022willallowtheexistingductadapterandextensionto

beusedwithoutrequiringtherelocationoftheholethroughthewalltothe

adjacent room.

*A-B Series: Zoneline units built before 1987 – Zoneline I, II, III, and IV; AZC Series: Zoneline units built from 1987 to 1992 – includes AZR Series – Zoneline 1000, 2000, 2500, 2700, 3000,

4000, 5000; AZ Series: Zoneline units built after 1992 – Zoneline 2100, 3100, 2600, 5100 / Zoneline 2200, 3200, 5200 / Zoneline 2500, 3500, 5500 / Zoneline 2800, 2900, 3800, 3900, 4100,

5800, 6100, 7500, 8500.

Zoneline®units

RAK702 (AZ Series*—2100 and 3100 only)

Duct Transition for Replacement of

AZC with Sloped-Front AZ Chassis

TheRAK702ducttransitionisdesignedtoallowductinstallationwhere

the original chassis was a slope-front discharge (AZC or AZR) chassis.

UsingtheRAK702willallowtheexistingductadapterandextensionto

beusedwithoutrequiringtherelocationoftheholethroughthewallto

the adjacent room.

RAK7012 (AZ Series*—2200, 2500, 3200, 3500,

2800, 2900, 3800 and 3900 only)

Duct Adapter for Replacement of

A-B with Rounded-Front AZ Chassis

TheRAK7012ductadapterisdesignedtolineupwiththeductextension

wheretheoriginalchassiswasaflat-topdischargeA-BSeries.Usingthe

RAK7012 will allow the existing duct extension to be used without

requiringtherelocationoftheholethroughthewalltotheadjacent

room.Dischargegrille,endplateandextensionmountinghardware

must be removed from old duct adapter and installed on the RAK7012.

8-3/8"

6-1/2"

RAK204 (AZ Series*—2200, 2500, 3200 and 3500 only)

Standard Sub-Bases WITHOUT power cord included

TheRAK204sub-baseismadeofheavy-gaugesteeltoprovidesupportofthewallcase.

Ithasfullbaseenclosurewithbreakawaysidechannels,simpleconnectiontowallcase

and4-pointlevelinglegs.Thesub-basewilladapttoserviceconduit,circuitbreakers

andreceptaclesupto30amps.Itmayalsobeusedasanon-electricalsub-baseto

provide support for the unit.

Circuit

Kit No. Sub-Base Ampacity Chaseway Power Cord

RAK204U** Standard N/A NotIncluded NotIncluded

RAK204D20 Sub-Base230/208V 15&20 Included NotIncluded

RAK204D30 Sub-Base230/208V 30 Included NotIncluded

RAK204E15 Sub-Base265/277V 15 Included NotIncluded

RAK204E20 Sub-Base265/277V 20 Included NotIncluded

RAK204E30 Sub-Base265/277V 30 Included NotIncluded

Power cord and junction box

not included with sub-base.

Chaseway

Zoneline units

RAK205CW

(AZ Series*—2200, 2500, 2800, 2900, 3200, 3500, 3800, 3900, 4100,

5200, 5500, 5800 and 6100 only)

Chaseway

Chaseway for wiring containment between junction box on

chassisandRAK204Usub-base.

Chaseway RAK204 (AZ Series*—2800, 2900, 3800, 3900, 4100, 5200, 5500, 5800

and 6100 only)

Standard Sub-Bases WITH power cord included

TheRAK204sub-baseismadeofheavy-gaugesteeltoprovidesupportofthewallcase.

Ithasfullbaseenclosurewithbreakawaysidechannels,simpleconnectiontowallcaseand4-point

levelinglegs.Thesub-basewilladapttoserviceconduit,circuitbreakersandreceptaclesupto30

amps.Itmayalsobeusedasanon-electricalsub-basetoprovidesupportfortheunit.

Circuit

Kit No. Sub-Base Ampacity Chaseway Power Cord

RAK204D15P Sub-Base230/208V 15 Included Included

RAK204D20P Sub-Base230/208V 20 Included Included

RAK204D30P Sub-Base230/208V 30 Included Included

RAK5157/5207/5307†

(AZ Series*—2800, 2900, 3800, 3900, 4100, 5500, 5800, 6100)

265/277-Volt Universal Power Supply Kit

• 9-pinconnectorwiththree7"12-gaugeconductorwires

Circuit

Kit No. Volts Heater Wattage Ampacity

RAK5157 265/277 2.4 kw 15

RAK5207 265/277 3.4 kw 20

RAK5307 265/277 4.8 kw 30

*A-B Series: Zoneline units built before 1987 – Zoneline I, II, III, and IV; AZC Series: Zoneline units built from 1987 to 1992 – includes AZR Series – Zoneline 1000, 2000, 2500, 2700, 3000,

4000, 5000; AZ Series: Zoneline units built after 1992 – Zoneline 2100, 3100, 2600, 5100 / Zoneline 2200, 3200, 5200 / Zoneline 2500, 3500, 5500 / Zoneline 2800, 2900, 3800, 3900, 4100,

5800, 6100, 7500, 8500.

**RAK204UMaybeusedwithAZCandAZ2100,3100,2600and5100.

†ThepowerconnectionkitdeterminestheheaterwattageandcurrentrequirementswhenitispluggedintotheZonelineunit.NOTE:7,000BTUmodelsdonothave5,000-wattheaters.

Zoneline®units

*A-B Series: Zoneline units built before 1987 – Zoneline I, II, III, and IV; AZC Series: Zoneline units built from 1987 to 1992 – includes AZR Series – Zoneline 1000, 2000, 2500, 2700, 3000,

4000, 5000; AZ Series: Zoneline units built after 1992 – Zoneline 2100, 3100, 2600, 5100 / Zoneline 2200, 3200, 5200 / Zoneline 2500, 3500, 5500 / Zoneline 2800, 2900, 3800, 3900, 4100,

5800, 6100, 7500, 8500.

RAK4002 (AZ Series*—2200, 3200 and 5200 only)

Direct-Connect Junction Box

(230/208 and 265/277 Volts)

RAK4002 junction box kit for permanent connection of 230/208- and

265/277-volt units to building power supply.

Includesmulti-circuitconnectorharnessforuseonvaluelineunits.

Junction box is included on 265/277-volt units.

RAK3153A/3203A/3303A

(AZ Series*—2800, 2900, 3800, 3900, 4100, 5500, 5800

and 6100 only)

15 and 20 Amp (230/208 Volts)

Universal Power Supply with LCDI

Circuit

Kit No. Volts Heater Wattage Ampacity

RAK3153A 230/208 2.4/2.32 kw 15

RAK3203A 230/208 3.3/3.2 kw 20

RAK3303A 230/208 4.7/4.53 kw 30

RAK4157/4207/4307†

(AZ Series*—2800, 2900, 3800, 3900, 4100, 5500, 5800 and

6100 only)

230/208-Volt Universal Power Supply Kit

• 9-pinconnectorwiththree7"12-gaugeconductorwires.

Circuit

Kit No. Volts Heater Wattage Ampacity

RAK4157 230/208 2.4/2.32 kw 15

RAK4207 230/208 3.3/3.2 kw 20

RAK4307 230/208 4.7/4.53 kw 30

RAK4002A (AZ Series*—2500, 2800, 2900, 3500, 3800, 3900,

4100 and 6100 only)

Direct-Connect Junction Box

(230/208 and 265/277 Volts)

RAK4002 junction box kit for permanent connection of 230/208- and 265/277-volt

units to building power supply.

Includesmulti-circuitconnectorharnessforuseonvaluelineunits.Junctionboxis

included on 265/277-volt units.

*A-B Series: Zoneline units built before 1987 – Zoneline I, II, III, and IV; AZC Series: Zoneline units built from 1987 to 1992 – includes AZR Series – Zoneline 1000, 2000, 2500, 2700, 3000,

4000, 5000; AZ Series: Zoneline units built after 1992 – Zoneline 2100, 3100, 2600, 5100 / Zoneline 2200, 3200, 5200 / Zoneline 2500, 3500, 5500 / Zoneline 2800, 2900, 3800, 3900, 4100,

5800, 6100, 7500, 8500.

Zoneline units

RAK4002B (AZ Series*—5500 and 5800 only)

Direct-Connect Junction Box

(230/208 and 265/277 Volts)

RAK4002 junction box kit for permanent connection of 230/208- and 265/277-volt

units to building power supply.

Includesmulti-circuitconnectorharnessforuseonvaluelineunits.Junctionboxis

included on 265/277-volt units.

RAK8023 (AZ Series*—2800, 2900, 3800, 3900, 4100, 5800 and

6100 only) Locking Door Kit

TheRAK8023providesdoorlockkitandkeytopreventaccesstoZonelineunitcontrols.

Also provides two thumb screws for securing the room cabinet to the chassis on the

lower right and left sides.

RAK4002CW (AZ Series*)

Direct-Connect Junction Box Wiring

(230/208 and 265/277 Volts)

In-line3-pinconnectorandwiringharness.Allowseasydisconnectofdirect-

connected applications.

RAK5172/5202/5302†

(AZ Series*—2800, 2900, 3800, 3900, 4100, 5500, 5800 and

6100 only)

15, 20, and 30 Amp (265/277 Volts)

Universal Power Supply

•Branchcircuitplugtobeusedonlyinconnectiontoappropriatesub-base

Circuit

Kit No. Volts Heater Wattage Ampacity

RAK5172 265/277 2.4 kw 15

RAK5202 265/277 3.4 kw 20

RAK5302 265/277 4.8 kw 30

RAK8022

(AZ Series*—2200, 2500, 3200, 3500, 5200 and 5500 only)

Locking Door Kit

TheRAK8022providesdoorlockkitandkeytopreventaccesstoZonelineunitcontrols.

Also provides two thumb screws for securing the room cabinet to the chassis on the

lower right and left sides.

Zoneline®units

RAK901L (AZ Series*)

Wall Case Insulation Kit

Fivepiecesof13"x14"x1/4"adhesive-backedpolyethylenetoinsulate

theinsideoftheRAB71AorRAB77A4wallcase.TheRAK901Lminimizes

the formation of moisture on exterior of wall case.

RAA63 (AZ Series*—2800, 2900, 3800, 3900, 4100, 5800 and

6100 only)

Replacement Filters

• Replacementfilters,inpairs

• 10pairsperbox

RAA62A (AZ Series*—2500, 3500 and 5500 only)

Replacement Filters

• Replacementfilters,inpairs

• 20pairsperbox

RAA62 (AZ Series*—2200, 3200 and 5200 only)

Replacement Filters for AZ Models

(20 pairs per box)

Theup-frontfiltersontheGEZonelineunitareconvenientlyaccessed

by simply pulling them up from the top of the room cabinet. By

simplifying the task, filter cleaning is more likely to occur on schedule

and the unit will operate as efficiently as possible. Sold in pairs.

RAK806 Universal Cover Label (10 covers per kit)

TheRAK806providesacoverforthecontrolareatoreferroom

occupanttousearemotethermostat.Double-sidedtapeprovided.

*A-B Series: Zoneline units built before 1987 – Zoneline I, II, III, and IV; AZC Series: Zoneline units built from 1987 to 1992 – includes AZR Series – Zoneline 1000, 2000, 2500, 2700, 3000,

4000, 5000; AZ Series: Zoneline units built after 1992 – Zoneline 2100, 3100, 2600, 5100 / Zoneline 2200, 3200, 5200 / Zoneline 2500, 3500, 5500 / Zoneline 2800, 2900, 3800, 3900, 4100,

5800, 6100, 7500, 8500.

Built-in units

RAK65A1 Window Installation Kit for “J” Series

Built-in Units

Adaptsbuilt-inwallcaseforwindowinstallation.(Thiskitisincludedin

“J”seriesunitsdesignedforwindowinstallation.)Windowopening

width—26-7/8"to40".Windowopeningheight—16-3/8"minimum.

RAD4A1 Drain Kit

Internal/External Drain Kit

Drainkitforuseon“J”serieswallcases.Formorepositivecontrolof

condensatewater,theRAD4A1drainkitroutescondensatetothe

exterior or to the interior of the building through the wall case. Suitable

provision (field applied) should be made to connect the drain tube to a

drainsysteminthebuilding.Draintubeassemblyis1/2"O.D.copper.

Note:TheRAG14EexteriorgrilleisNOTcompatiblewiththeRAD4A1

EXTERNALdraintube.Useofthisgrillewouldrequiretheuseofthe

INTERNALTUBEconfigurationtodraintheunit.

RAB47A/48A Tenant Option Wall Cases for “J” Chassis

Whentheairconditionerisofferedasatenantoption,thesewallcases

provide protection against outside elements.

RAB47A—includes wall case, exterior grille, weather panel and steel

closure panel.

RAB48A—includes wall case, exterior grille, insulated steel indoor

closure panel and insulated outdoor panel.

RAB46 Standard Wall Case for “J” Chassis

Built-in Unit

Solid-sided wall case fabricated of galvanized steel with baked-enamel

(beige)finish.Weldedareasarecoatedwithasealingcompoundto

help resist rust and corrosion. Polymer gasket surrounds opening to

assure tight weather seal. Aluminum grille (RAG13) is included. Panels

on interior and between case and grille provide weather protection

prior to installation of chassis.

Built-in units

RAF622 Replacement Room Front for Rounded-

Front “J” Chassis

Usedasreplacementgrilleforrounded-front“J”chassisunits.(Notfor

use with high-mount units.)

RAG14E Architectural Louvered Exterior Grille

for “J” Series

Extruded aluminum grille for application with RAB46, 47 or 48.

NOTE:TheRAG14EexteriorgrilleisNOTcompatiblewiththeRAD4A1

EXTERNALdraintube.Useofthisgrillewouldrequiretheuseofthe

INTERNALTUBEconfigurationtodraintheunit.

RAG13 Stamped Aluminum Exterior Grille “J” Series

Usedtoreplaceexteriorgrilleonold“J”wallcasetomaximize

efficiencyandcapacityofnewchassis.Thegrilleisincludedwithnew

wall cases RAB46, 47 or 48.

RAF622A Replacement Room Front for Rounded-

Front “J” Chassis

Replacement room front for “J” series chassis with oval control knob

opening.(Notforuseonhigh-mountmodels.)

RAK690 Architectural Louver Grille Adapter for

“J” Chassis Units

Permits most existing architectural louvered grilles to be used with

sloped-front or rounded-front “J” chassis units. Kit consists of two wire

mesh screen sections, clips to attach screen to existing wall case and

two aluminum air deflectors to be mounted to new chassis.

RAK1082 Whirlpool®Sleeve Adapter

KitadaptsWhirlpoolType23Wwallcaseforinstallationofthesloped-

frontorrounded-front“J”modelchassis.TheWhirlpoolcase

dimensionsare25-7/8"W,16-1/2"H,23-1/8"D.

RAK1102/RAB30 (FModel)Sleeve Adapter

Kit adapts RAB30 wall case for installation of the sloped-front or

rounded-front“J”modelchassis.TheRAB30casedimensionsare26"

W,18"H,24"D.

RAK123A64 Fedders®Sleeve Adapter

Kit adapts Fedders “A” wall case for installation of the “J” wall case

(includes outdoor grille) and “J” model chassis. Existing Fedders wall

casedimensionsare27"W,16-3/4"H,16-3/4"D.

Kit consists of four gaskets which are applied to the wall case

to assure a tight weather seal between the two cases.

RAK1072 Hotpoint®Chassis Sleeve Adapter

KitadaptsHotpointACXB10andACXB11wallcase(usedwithACTB

chassis) to the sloped-front or rounded-front “J” chassis. Existing case

dimensionsare25-3/4"W,16-7/8"H,18-5/8"D.

All needed gaskets and hardware, including the outdoor grille, are

included.

Built-in units

RAA72 Replacement Filter

for Rounded-Front “J” Chassis

• Replacementfilterforuseinroomfrontswith

 2roundcontrolknobopeningsONLY

• Washable/reusablenylonmeshfilter

• Orderindividuallyorbyboxof20

• Usedforstandardorhigh-mountmodels

RAA72A Replacement Filter

for Rounded-Front “J” Chassis

• Replacementfilterforuseinroomfrontswithovalcontrol 

 knobopeningsONLY

• Washable/reusablenylonmeshfilter

• Orderindividuallyorbyboxof20

• Usedforstandardorhigh-mountmodels

Thermostats—Heat pump

*A-B Series: Zoneline units built before 1987 – Zoneline I, II, III, and IV; AZC Series: Zoneline units built from 1987 to 1992 – includes AZR Series – Zoneline 1000, 2000, 2500, 2700, 3000,

4000, 5000; AZ Series: Zoneline units built after 1992 – Zoneline 2100, 3100, 2600, 5100 / Zoneline 2200, 3200, 5200 / Zoneline 2500, 3500, 5500 / Zoneline 2800, 2900, 3800, 3900, 4100,

5800, 6100, 7500, 8500.
