GE AEG14 Operating instructions

Write the model and serial
numbers here:
Model #_________________
Serial # _________________
You can find the rating label on the
side of the air conditioner.
GE is a trademark of the General Electric Company. Manufactured under trademark license.
AIR CONDITIONER
ROOM
49-5000434 Rev. 2 01-20 GEA
AEG14
AEG18
AEG24
SAFETY INFORMATION .........3
USING THE AIR CONDITIONER
Controls ..............................4
CARE AND CLEANING
Air Filter..............................7
Outdoor Coils .........................7
INSTALLATION
INSTRUCTIONS ....................8
TROUBLESHOOTING TIPS......16
Normal Operating Sounds .............16
WIFI SETUP ......................17
LIMITED WARRANTY............. 19
CONSUMER SUPPORT...........20
OWNER’S MANUAL
AND INSTALLATION
INSTRUCTIONS

249-5000434 Rev. 2
THANK YOU FOR MAKING GE APPLIANCES A PART OF YOUR HOME.
Whether you grew up with GE Appliances, or this is your first, we’re happy to have you in the family.
We take pride in the craftsmanship, innovation and design that goes into every GE Appliances
product, and we think you will too. Among other things, registration of your appliance ensures that we
can deliver important product information and warranty details when you need them.
Register your GE appliance now online. Helpful websites and phone numbers are available in the
Consumer Support section of this Owner’s Manual. You may also mail in the pre-printed registration
card included in the packing material.

49-5000434 Rev. 2 3
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
SAFETY INFORMATION
WARNING For your safety, the information in this manual must be followed to minimize the risk of
fire, electric shock or personal injury.
Ŷ8VHWKLVDSSOLDQFHRQO\IRULWVLQWHQGHGSXUSRVHDV
described in this Owner’s Manual.
ŶThis air conditioner must be properly installed in
accordance with the Installation Instructions before it is
used.
ŶNever unplug your air conditioner by pulling on the
power cord. Always grip plug firmly and pull straight
out from the receptacle.
ŶReplace immediately all electric service cords that
have become frayed or otherwise damaged. A
damaged power supply cord must be replaced with a
new power supply cord obtained from the manufacturer
and not repaired. Do not use a cord that shows cracks
or abrasion damage along its length or at either the
plug or connector end.
ŶTurn the unit OFF and unplug your air conditioner
before cleaning.
ŶGE Appliances does not support any servicing of the
air conditioner. We strongly recommend that you do
not attempt to service the air conditioner yourself.
ŶFor your safety…do not store or use combustible
materials, gasoline or other flammable vapors or
liquids in the vicinity of this or any other appliance.
ŶAll air conditioners contain refrigerants, which under
federal law must be removed prior to product disposal.
If you are getting rid of an old product with refrigerants,
check with the company handling disposal about what
to do.
ŶIf the receptacle does not match the plug, the
receptacle must be changed out by a qualified
electrician.
ŶThese R410A air conditioning systems require
contractors and technicians to use tools, equipment
and safety standards approved for use with this
refrigerant. DO NOT use equipment certified for R22
refrigerant only.
WARNING USE OF EXTENSION CORDS
RISK OF FIRE. Could cause serious injury or death.
Ŷ'2127XVHDQH[WHQVLRQFRUGZLWKWKLV:LQGRZ$LU
Conditioner.
Ŷ'2127XVHVXUJHSURWHFWRUVRUPXOWLRXWOHWDGDSWRUV
with this Window Air Conditioner.
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the third
(ground) prong from the power cord. For personal safety,
this appliance must be properly grounded.
DO NOT use an adapter plug with this appliance.
The power cord of this appliance is equipped with a
3-prong (grounding) plug which mates with a standard
3-prong (grounding) wall outlet to minimize the possibility
of electric shock hazard from this appliance.
Power cord includes a current interrupter device. A
test and reset button is provided on the plug case. The
device should be tested on a periodic basis by first
pressing the TEST button and then the RESET button
while plugged into the outlet. If the TEST button does
not trip or if the RESET button will not stay engaged,
discontinue use of the air conditioner and contact a
qualified service technician.
Have the wall outlet and circuit checked by a qualified
electrician to make sure the outlet is properly grounded.
Where a 2-prong wall outlet is encountered, it is your
personal responsibility and obligation to have it replaced
with a properly grounded 3-prong wall outlet.
The air conditioner should always be plugged into its
own individual electrical outlet which has a voltage rating
that matches the rating plate.
This provides the best performance and also prevents
overloading house wiring circuits which could cause a
fire hazard from overheated wires.
See the Installation Instructions, Electrical
Requirements section for specific electrical connection
requirements.
For appliance recycling information please visit geappliances.com/recycling.

449-5000434 Rev. 2
USING THE AIR CONDITIONER
Controls
Features and appearance will vary.
/LJKWVQH[WWRWKHWRXFKSDGVRQWKHDLUFRQGLWLRQHUFRQWUROSDQHOLQGLFDWHWKHVHOHFWHGVHWWLQJV
Air Conditioner Controls
NOTE: 7KHGLVSOD\DOZD\VVKRZVWKHURRPWHPSHUDWXUHH[FHSWZKHQ
setting the Set temperature or the Delay timer.
Remote Control
NOTE: The default temperature reading on the display is degree Fahrenheit ( °F). To change the display to degree
Celcius (°C), press the Temp Increase + and Temp Decrease –buttons together and hold for 3 seconds. Repeat the
process to change back to degree Fahrenheit (°F)
Auto
High
Med
Low
Cool
Fan
Eco
WiFiSleepFan Mode
Power
Temp
Do Not Operate in Freezing Outdoor Conditions
This cool-only air conditioner was not designed for freezing outdoor conditions. It must not be used in freezing
outdoor conditions.
Power Pad
Turns air conditioner on and off. When turned on,
the display will show the room temperature.
Display
Shows the room temperature or time remaining on
the Delay timer. Shows the Set temperature while
setting the temperature in Cool or ECO modes.
The Set light will turn on while setting.
Temp Increase + /Decrease – Pads
8VHWRVHWWHPSHUDWXUHZKHQLQCool or ECO
mode. The Set light will turn on while setting.
Fan Speed Pads
8VHWRVHWWKHIDQVSHHGWRLow, Med, High or
Auto on the unit. NOTE: On the remote control,
use the fan speed Increase + / Decrease – pads
to set the fan speeds to Low, Med or High8VH
the Auto pad to turn Auto fan on.
Mode Pad
8VHWRVHWWKHDLUFRQGLWLRQHUWR&RRO(&2RU)DQ
Only mode.
WiFI
Enables connection of the air conditioner to
the home WiFi. Download App for details at
GEAppliances.com/connect6HH:LIL6HW8SRQ
page 17.

49-5000434 Rev. 2 5
Using the Air Conditioner
USING THE AIR CONDITIONER
Remote Control
Ŷ7RHQVXUHSURSHURSHUDWLRQDLPWKHUHPRWHFRQWURODW
the signal receiver on the air conditioner.
Ŷ0DNHVXUHQRWKLQJLVEHWZHHQWKHDLUFRQGLWLRQHUDQG
the remote control that could block the signal.
Ŷ7KHUHPRWHFRQWUROVLJQDOKDVDUDQJHRIXSWR
20 feet.
Ŷ0DNHVXUHEDWWHULHVDUHIUHVKDQGLQVWDOOHGFRUUHFWO\
as indicated on the remote control.
Ŷ5HPRWHFRQWDLQVDPDJQHWDOORZLQJLWWRDWWDFKWR
metal surfaces.
Cool Mode
8VHWKH&RROPRGHDW/RZ0HG+LJKRU$XWR)DQ
6SHHGIRUFRROLQJ8VHWKH7HPSHUDWXUH,QFUHDVH
Decrease –pads to set the desired temperature between
64°F and 86°F in 1°F increments.
An electronic thermostat is used to maintain the room
temperature. The compressor will cycle on and off
to keep the room at the set level of comfort. Set the
thermostat at a lower number and the indoor air will
become cooler. Set the thermostat at a higher number
and the indoor air will become warmer.
NOTE: If the air conditioner is off and is then turned on
while set to a Cool setting or if turned from a fan setting
WRD&RROVHWWLQJLWPD\WDNHDSSUR[LPDWHO\PLQXWHVIRU
the compressor to start and cooling to begin.
Cooling Descriptions
For Normal Cooling—Select the Cool mode and High
or Med fan with a middle set temperature.
For Maximum Cooling—Select the Cool mode and
High fan with a lower set temperature.
For Quieter and Nighttime Cooling—Select the Cool
mode and Low fan with a middle set temperature.
Sleep Pad
The SLEEP mode sets the unit to gradually change
settings over an 8 hour period to allow for some
increased energy efficiency during sleep hours.
The SLEEP mode is available only in COOL and
FAN only settings.
Press the SLEEP mode pad and its light will
illuminate. The fan indicator will stay at the same
setting but the air conditioner will automatically
change the FAN speed to low in either COOL or
FAN only mode.
In FAN only mode, the fan will stay in the LOW
speed setting for 8 hours. After 8 hours, the air
conditioner will resume the settings that were in
place before the SLEEP mode pad was pressed.
In COOL mode, the fan will stay in the LOW speed
setting for 8 hours from the time the SLEEP mode
pad was pressed. The air conditioner will also
raise the set point 2°F in 30 minutes and 2°F more
in another 30 minutes where it will remain for the
QH[WKRXUV$IWHUKRXUVWKHDLUFRQGLWLRQHUZLOO
resume the settings that were in place before the
SLEEP mode pad was pressed.
While the unit is in SLEEP mode, pressing any pad
will return it to the settings that were in place before
the SLEEP mode pad was pressed.
Control Display On and Off
To reduce brightness during sleeping hours, this
air conditioner control display has an automatic
off feature where the control display will turn off
completely after 5 minute of inactivity. To illuminate
the control interface, press any button on the
control display or remote control. The control
display will illuminate all previously illuminated
LED’s. The control interface will now respond to
any prescribed button press after it is illuminated.
Press and hold the FAN+MODE buttons
simultaneously to toggle this feature ON or OFF.
The LED’s will now stay ON anytime the unit is
ON.
Control Sound On and Off
This air conditioner will make a beep when
the buttons on the control are pushed or if the
unit receives a command from the mobile app
or remote control. To silence these beeps,
simultaneously press the FAN and “-” buttons for 3
seconds. Press these buttons again to toggle the
sound back on.

649-5000434 Rev. 2
USING THE AIR CONDITIONER
Using the Air Conditioner
ECO Mode
This mode optimizes the cooling power of your air
conditioner, thereby saving you energy. Once the set
point temperature has been reached, the fan will cycle
off to save energy. The fan will cycle back on periodically
to insure all cooling capacity in the system is used. This
mode is the default mode for the unit. Each time the
unit is powered off, it will restart in ECO mode ON. This
includes Delay timer mode. The first time the unit is
turned on, the settings will be 70° and Low fan. You can
adjust the fan speed and temperature to your personal
comfort.
ECO ON—Helps minimize electricity use. It is normal
for the fan to cycle off and then back on in this mode.
7KLVRQRIIF\FOHFDQUHSHDWPXOWLSOHWLPHV%HFDXVH
the fan will cycle off, you may notice a variation in room
temperature and humidity.
ECO OFF—When this mode is not engaged, the fan will
run continuously, and in Cool mode the compressor will
cycle on and off to maintain room temperature.
Fan Only Mode
8VHWKH)DQ2QO\0RGHDW/RZ0HGRU+LJKIDQVSHHG
to provide air circulation and filtering without cooling.
Since fan-only settings do not provide cooling, a Set
temperature cannot be entered. The room temperature
will appear in the display.
NOTE: Auto Fan Speed cannot be used when in the Fan
Only Mode.
Auto Fan Speed
Set to Auto fan speed for the fan speed to automatically
set to the speed needed to provide optimum comfort
settings with the set temperature.
If the room needs more cooling, the fan speed will
automatically increase. If the room needs less cooling,
the fan speed will automatically decrease.
NOTE: Auto Fan Speed cannot be used when in the Fan
Only Mode.
Power Outage Recovery Feature
In the case of a power outage or interruption, the unit will
automatically restart in the settings last used after the
power is restored.
Air Direction
8VHWKHOHYHUWRDGMXVWWKHDLUGLUHFWLRQOHIWDQGULJKW
only.

49-5000434 Rev. 2 7
Care and Cleaning
Grille and Case
Turn the air conditioner off and remove the plug from the
wall outlet before cleaning.
To clean, use water and a mild detergent. Do not use
bleach or abrasives.
Air Filter
The air filter behind the front grille should be checked and
cleaned at least every 30 days or more often if necessary.
To remove:
Open the inlet grille by pulling downward on the tabs at
the top upper corners of the inlet grille until the grille is in
a 45º position. Remove the filter.
Clean the filter with warm, soapy water. Rinse and let the
filter dry before replacing it. Your filter is also dishwasher
safe, top rack and straight placement in dishwasher is
recommended.
CAUTION
DO NOT operate the air conditioner
without a filter because dirt and lint will clog it and reduce
performance.
Outdoor Coils
The coils on the outdoor side of the air conditioner should
be checked regularly. If they are clogged with dirt or soot,
they may be professionally cleaned.
How to Insert the Battery in the Remote Control
1. Remove the battery cover by sliding it according to the
arrow direction.
2. Insert new batteries, making sure that the (+) and (–)
of battery are installed correctly.
3. Reattach the cover by sliding it back
into position.
NOTES:
Ŷ8VH³$$$´YROWEDWWHULHV'RQRWXVH
rechargeable batteries.
ŶRemove the batteries from the remote control if the
system is not going to be used for a long time.
Ŷ'RQRWPL[ROGDQGQHZEDWWHULHV'RQRWPL[DONDOLQH
standard (carbon-zinc) or rechargeable (ni-cad, ni-mh,
etc) batteries.
CARE AND CLEANING
Tab Tab

849-5000434 Rev. 2
BEFORE YOU BEGIN
Read these instructions completely and
carefully.
•IMPORTANT – Save these
instructions for local inspector’s use.
•IMPORTANT – Observe all
governing codes and ordinances.
• Note to Installer ±%HVXUHWROHDYHWKHVH
instructions with the Consumer.
• Note to Consumer – Keep these instructions for
future reference.
• Skill level – Installation of this appliance requires
basic mechanical skills.
• Completion time ±$SSUR[LPDWHO\KRXU
• We recommend that two people install
this product.
• Proper installation is the responsibility
of the installer.
• Product failure due to improper installation is not
covered under the Warranty.
 <RX0867XVHDOOVXSSOLHGSDUWVDQGXVHSURSHU
installation procedures as described in these
instructions when installing this air conditioner.
Questions? Call 1-800-GE-CARES or Visit our Website at: GEAppliances.com
ELECTRICAL
REQUIREMENTS
6RPHPRGHOVUHTXLUHDYROW$&
60-Hz grounded outlet protected with a
15-amp time-delay fuse or circuit breaker.
The 3-prong grounding plug minimizes the possibility
of electric shock hazard. If the wall outlet you plan to
use is only a 2-prong outlet, it is your responsibility to
have it replaced with a properly grounded 3-prong wall
outlet.
6RPHPRGHOVUHTXLUHYROW$&
protected with a time-delay fuse or circuit
breaker. These models should be installed on
their own single branch circuit for best
performance and to prevent overloading
house or apartment wiring circuits, which
could cause a possible fire hazard from
overheating wires.
CAUTION
Do not, under any circumstances, cut or remove the
third (ground) prong from the power cord.
Do not change the plug on the power cord of this air
conditioner.
Aluminum house wiring may present special
problems—consult a qualified electrician.
Installation Instructions
INSTALLATION INSTRUCTIONS
TOOLS YOU WILL NEED
Phillips head screwdriver
Ruler or tape measurePencil
Level Scissors or knife
Flat-blade screwdriver
Power cord includes a current interrupter device. A
test and reset button is provided on the plug case.
The device should be tested on a periodic basis
by first pressing the TEST button and then the
RESET button while plugged into the outlet. If the
TEST button does not trip or if the RESET button
will not stay engaged, discontinue use of the
air conditioner and contact a qualified service
technician.

49-5000434 Rev. 2 9
Installation Instructions
INSTALLATION INSTRUCTIONS
Window
locking
bracket (2)
Top
mounting
rail
Sill angle
bracket (2)
Foam top window
gasket (1)
Side rail (2)
PARTS INCLUDED
(Appearance may vary)
Top rail gasket (1)
Type E bolt with
nut (4)
Type A
screws (10)
7\SH%
screws (2) Type C screws (4)
Type C
screws (5)
Type F bolt with
nut (2)
V-supports (2)
Window
sash seal
Left accordion
panel Right accordion
panel
For Model: AEG24
For Models: AEG14, AEG18

10 49-5000434 Rev. 2
Installation Instructions
INSTALLATION INSTRUCTIONS
2. STORM WINDOW REQUIREMENTS
A storm window frame will not allow the air
conditioner to tilt toward the outside, and will
keep it from draining properly. To adjust for this,
attach a piece of wood to the sill.
WOOD PIECES
WIDTH: 2Ǝ
LENGTH: Long enough to fit inside the window
frame.
THICKNESS: To determine the thickness, place
DSLHFHRIZRRGRQWKHVLOOWRPDNHLWƎKLJKHU
than the top of the storm window frame or the
vinyl frame.
Attach securely with nails or screws provided by
the installer.
ƎKLJKHU
than storm
window
frame
Storm window
frame
Wood
Sill
ƎKLJKHU
than vinyl frame
(on some windows)
Vinyl frame
3. PREPARE THE AIR
CONDITIONER
A. Pull down the front panel and remove the filter.
Remove the front panel by lifting up at an angle.
B. Remove the four front screws. Save them for
reinstalling the front housing.
C. Grasp the lower corners of the grille while
pressing in on the case sides with your finger
tips. Pull out to release and lift it up.
NOTE: Do not pull the bottom edge toward you
PRUHWKDQƎRU\RXPD\GDPDJHWKHWDEVRIWKH
grille.
D. When the front grille is removed the control
panel will still be attached by a harness. Turn
the grille around so you can see the back side
of the grille. Remove the 2 screws to separate
the control panel housing from the grille. NOTE:
%HVXUHWRVDYHWKHVHVFUHZV<RXZLOOQHHG
them later in the installation.
Remove Screws
1. WINDOW REQUIREMENTS
• These instructions are for a standard
double-hung window. You will need to modify
them for other types of windows.
• The air conditioner can be installed without the
accordion panels if needed to fit in a narrow
window. See the window opening dimensions.
• All supporting parts must be secured to firm
wood, masonry or metal.
• The electrical outlet must be within reach of the
power cord.
A
(With accordion panels)
%
Model A B
AEG14, AEG18 ´PLQ 26”- 41”
AEG24 ´PLQ 30”- 41”

49-5000434 Rev. 2 11
4. PREPARE THE CASE
A. Attach the top rail gasket to
the bottom of the top rail.
B. Install the top mounting rail with 4 type A screws
from the inside of the case. Press firmly to drive
the screws into the gasket and through the top
mounting rail.
Installation Instructions
INSTALLATION INSTRUCTIONS
3. PREPARE THE AIR
CONDITIONER (continues)
E. Remove the ground screw from the left side of
the case. Keep it in a safe location.
NOTE: %HVXUHWRVDYHWKLVVFUHZ<RXZLOO
need them later in the installation.
F. Slide the air conditioner from the case by
gripping the base pan handle and pulling
forward while bracing the case. Do not pull or lift
on the foam discharge area.
FRONT
Do not pull
or lift in
this area—
damage to
the unit may
result
4. PREPARE THE CASE
C. Slide each side retainer onto the edge of each
according panel. The figure shows the orientation
of each accordion panel and side retainer
assembly relative to the case from a top view of
the unit.
D. Slide the left and right accordion panels into the
top and bottom mounting rails.
E. Attach the side retainers to the case using 6 type A
screws.
WINDOW FILLER PANEL
WINDOW FILLER PANEL
SIDE RETAINER
SIDE RETAINER
Top mounting rail
Top left Top right
Top mounting rail
%RWWRPPRXQWLQJUDLO

12 49-5000434 Rev. 2
Installation Instructions
INSTALLATION INSTRUCTIONS
5. PREPARE THE WINDOW AND
INSTALL THE CASE
A. Cut the window sash seal to the proper length.
Peel off the backing and attach the seal to the
underside of the window sash.
B. Open the window and mark the center of the
window sill.
C. Carefully slide the case into the window and
center the case. Lower the window behind the
top mounting rail. Pull the bottom of the case
forward so that the bottom mounting rail is tight
against the back of the window stool. Mount the
FDVHWRWKHZLQGRZVLOOXVLQJW\SH%VFUHZV
Drill pilot holes, if necessary.
D. Assemble the V-support and V-support bracket
with Type F nut and bolt
5. PREPARE THE WINDOW AND
INSTALL THE CASE (continues)
E. Position the V-supports on
the case bottom so that they
will be near the outside wall.
Attach a V-support to each
side of the bottom of the
case with Type E bolts, 2 for
each support.
F. Adjust sill angle brackets to rest on sill.
G. ([WHQGWKHOHIWDQGULJKWDFFRUGLRQSDQHOVWRWKH
vertical window sashes. Drill pilot holes and attach
the top corners with 2 type C screws.
W\SH%VFUHZV
Stool
V-support
Sill
%UDFNHW
Type C
screw Type C
screw
Sill angle
bracket
V-support
Type F bolt
and nut
Right
and nut
Type E bolt

49-5000434 Rev. 2 13
Installation Instructions
INSTALLATION INSTRUCTIONS
5. PREPARE THE WINDOW AND
INSTALL THE CASE (continues)
8VH7\SH%6FUHZWRLQVWDOOWKHZLQGRZORFN
bracket on top of the bottom window.
H. CAUTION
To prevent broken glass or
damage to windows, on vinyl
or other similarly constructed
windows, attach the window
locking bracket to the
window side jamb with one
7\SH%VFUHZ
I. Cut the foam top window gasket to the
window width.
J.Stuff the foam between the glass and the
window to prevent air and insects from getting
into the room.
NOTE: If the gasket supplied does not fit your
window, obtain appropriate material locally to
provide a proper installation seal.
Wood
Vinyl
6. INSTALL THE AIR CONDITIONER
IN THE CASE
A. Slide the air conditioner into the case by
the base pan. Do not push on the controls, foam
air discharge housing or the finned coils. Make
sure the air conditioner is firmly seated.
Do not press on
these areas—
damage to the unit
may result
%DVH3DQ

14 49-5000434 Rev. 2
Installation Instructions
INSTALLATION INSTRUCTIONS
6. INSTALL THE AIR CONDITIONER
IN THE CASE (continues)
B. Replace the 1 screw removed earlier, one
on each side of the case.
,03257$177+(*5281'6&5(:60867
%(5(,167$//('72(1685(3523(5
*5281'
C. Reinstall the control to the panel housing by
replacing the 2 screws you removed earlier.
D. Attach the front grille to the case by inserting
the tabs on the grille into the slots on the front
top of the case. Push the grille in.
E. Replace the screws.
F. Install the filter and the front grille.
G. Plug in the air conditioner.
Install Screws

49-5000434 Rev. 2 15
The case may be installed through-the-wall in
both existing and new construction.
Read completely, then follow step-by-step.
NOTE: Obtain all materials locally for mounting
the air conditioner through-the-wall.
1. IMPORTANT
Through-the-wall installation is not
appropriate if any of the side or top louvers
in the case will be obstructed by the wall.
All side and top louvers in the case must
project on the outdoor side of the wall.
The room side of the case must project into
the room far enough to maximize the balance
of the unit.
The case must be installed level from side-
to-side and with a slight tilt from front to
rear. Use a level; no more than a 1/2 bubble
will be the correct case slant to the outside.
Lintel angle is required to support bricks or
blocks above opening.
Flashing is required and should extend the
length of the opening to ensure no inside
cavity leakage occurs.
A. Remove the air conditioner from the case.
For specific instruction, refer to the Window
Installation Instructions.
B. Make certain that a wall receptacle is available
close to the hole location or make arrangements
to install a receptacle.
C. Place the case in the wall opening and place
wood support strips between the case bottom
and the flashing on both sides of the bottom rail.
They should be the same height as the bottom
rail and the same length as the wall opening.
2. FINISH THE WALL OPENING
A. Caulk all four sides on the outdoor side of the
case to prevent moisture from getting through
WRWKHLQWHULRUZDOO8VHRIIODVKLQJGULSUDLOZLOO
further prevent water from dripping inside the
wall and down the outside of the building.
B. Place the air conditioner into the case.
For specific instruction, refer to the Window
Installation Instructions.
1. IMPORTANT (cont.)
D. Secure with 14 wood screws anchored at least
an inch into the wall support structure.
NOTE: Drill pilot holes, if necessary, for proper
installation. If the frame is oversized, use shims
to prevent case distortion.
Lintel angle
Plaster line
Trim molding
(if desired)
INSIDE
%RWWRPUDLO
Wood filler and
caulking (above
and below the
flashing)
Air louvers
(top and sides
must project
on the outdoor
side of the
wall)
2876,'(
Flashing
(Drip rail)
Case
bottom
%RWWRP
rail
Flashing
(Drip rail) Wood support strips
Caulking
Through-the-Wall Installation Instructions—Optional
INSTALLATION INSTRUCTIONS

16 49-5000434 Rev. 2
Troubleshooting Tips... %HIRUH\RXFDOOIRUVHUYLFH
Save time and money! Review the charts on the following pages first and you may not need to call for service.
TROUBLESHOOTING TIPS
Problem Possible Causes What To Do
Air conditioner does
not start The air conditioner is unplugged. Make sure the air conditioner plug is pushed completely into the outlet.
The fuse is blown/circuit breaker
is tripped. &KHFNWKHKRXVHIXVHFLUFXLWEUHDNHUER[DQGUHSODFHWKH fuse or reset the breaker.
Power failure. The unit will automatically restart in the settings last used
after the power is restored.
7KHUHLVDSURWHFWLYHWLPHGHOD\DSSUR[LPDWHO\PLQXWHVWR
prevent tripping of the compressor overload. For this reason,
the unit may not start normal cooling for 3 minutes after it is
turned back on.
The current interrupter device is
tripped. Press the RESET button located on the power cord plug.
If the RESET button will not stay engaged, discontinue
use of the air conditioner and contact a qualified service
technician.
Air conditioner does
not cool as it should Airflow is restricted. Make sure there are no curtains, blinds or furniture blocking the front of the air conditioner.
The temp control may not be set
correctly. On models with touch pads: In the Cool mode, press the Decrease – pad.
On models with control knobs, turn the temperature knob to
a higher number.
The air filter is dirty. Clean the filter at least every 30 days. See the Care and
Cleaning section.
The room may have been hot. When the air conditioner is first turned on, you need to allow
time for the room to cool down.
Cold air is escaping. Check for open furnace registers and cold air returns.
Cooling coils have iced up. See “Air conditioner freezing up” below.
Air conditioner freezing
up Ice blocks the air flow and stops the air conditioner from cooling
the room.
On models with control knobs, set the mode control at High
Fan or High Cool with the Temp at 1or 2.
On models with touch pads, set the controls at High Fan or
High Cool and set the thermostat to a higher temperature.
The remote control is
not working The batteries are inserted incorrectly. Check the position of the batteries. They should be inserted in the opposite (+) and (–) direction.
The batteries may be dead. Replace the batteries.
Water drips outside Hot, humid weather. This is normal.
Water drips indoors The air conditioner is not tilted
to the outside. For proper water disposal, make sure the air conditioner slants slightly from the case front to the rear.
Water collects in base
pan Moisture removed from air and drains into base pan. This is normal for a short period in areas with little humidity; normal for a longer period in very humid areas.
Normal Operating Sounds
ŶYou may hear a pinging noise caused by water being
picked up and thrown against the condenser on rainy
days or when the humidity is high. This design feature
helps remove moisture and improve efficiency.
ŶYou may hear the thermostat click when the
compressor cycles on and off.
ŶWater will collect in the base pan during high humidity
or on rainy days. The water may overflow and drip
from the outdoor side of the unit.
ŶThe fan may run even when the compressor does not.

49-5000434 Rev. 2 17
WiFi Setup
WIFI SETUP
GE Appliances WiFi Connect (for customers in the United States)
GE Appliances U+ Connect Enabled* If your Air Conditioner (AC) has a Connected Appliance Information label
located on the outside as shown below, your AC is GE Appliances U+ Connect Enabled. A WiFi communication
card is built into the product allowing it to communicate with your smart phone for remote monitoring, control and
notifications. Please visit GEAppliances.com/connect to learn more about connected appliance features, and to
learn what connected appliance apps will work with your smart phone. For assistance,
call 1-800-220-6899.
Network: GE_MODULE_XXXXNetwork: GE_MODULE_XXXX
PASSWORD: XXXXXXXX
MAC ID: XX-XX-XX-XX-XX-XX
CONTAINS FCCID: ZKJ-WCATB002 CONTAINS IC: 100229A-WCATB002
123-45-678
How it Works
Download the GE Appliances App 8VHWKHDSSWRFRQQHFW\RXUURRPDLU
conditioner to WiFi
Once connected, use the app to turn
down your air conditioner as you
leave work.
CHANGE TEMP
TO 65
Getting Started
To connect your room air conditioner, you’ll need the
GE Appliances App. The app will walk you through the
connection process. Download the app from iTunes or
Google Play.
All connected appliace data is held in strict accordance
with the GE Appliances Connected Data Privacy Policy.
Visit geappliances.com/privacy/privacy_policy_
connected to view this policy.
Questions about U+ Connect
Get answers you need about setting up WiFi appliances
and connecting to your home network in our support
articles.
Visit products.geappliances.com/appliance/gea-
support-search-content to view wifi connect room air
conditioner support articles.

18 49-5000434 Rev. 2
WiFi Setup
WIFI SETUP
REGULATORY INFORMATION
FCC/IC Compliance Statement:
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation.
This equipment has been tested and found to comply
ZLWKWKHOLPLWVIRUD&ODVV%GLJLWDOGHYLFHSXUVXDQWWR
Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
&RQVXOWWKHGHDOHURUDQH[SHULHQFHGUDGLRWHOHYLVLRQ
technician for help.
Labelling: Changes or modifications to this unit not
H[SUHVVO\DSSURYHGE\WKHPDQXIDFWXUHUFRXOGYRLGWKH
user’s authority to operate the equipment.
*Select Models Only
This product has Wi-Fi capability and requires
Internet connectivity and a wireless router to enable
interconnection with an Energy Management System,
DQGRUZLWKRWKHUH[WHUQDOGHYLFHVV\VWHPVRU
applications.
8VHRIWKH:RUNVZLWK$SSOH+RPH.LWORJRPHDQV
that an electronic accessory has been designed to
connect specifically to iPod touch®, iPhone®, or iPad®,
respectively, and has been certified by the developer
to meet Apple®performance standards. Apple is
not responsible for the operation of this device or its
compliance with safety and regulatory standards.

49-5000434 Rev. 2 19
LIMITED WARRANTY
GE Appliances Air Conditioner - One-Year Limited Warranty
Ŷ6HUYLFHWULSVWR\RXUKRPHWRWHDFK\RXKRZWRXVH
the product.
Ŷ,PSURSHULQVWDOODWLRQGHOLYHU\RUPDLQWHQDQFH,I\RX
have an installation problem, or if the air conditioner
is of improper cooling capacity for the intended use,
contact your dealer or installer. You are responsible
for providing adequate electrical connecting facilities.
Ŷ)DLOXUHRIWKHSURGXFWUHVXOWLQJIURPPRGLILFDWLRQV
to the product or due to unreasonable use including
failure to provide reasonable and necessary
maintenance.
Ŷ,QFRPPHUFLDOORFDWLRQVODERUQHFHVVDU\WRPRYHWKH
unit to a location where it is accessible for service by
an individual technician.
Ŷ5HSODFHPHQWRIKRXVHIXVHVRUUHVHWWLQJRIFLUFXLW
breakers.
Ŷ)DLOXUHGXHWRFRUURVLRQRQPRGHOVQRWFRUURVLRQ
protected.
Ŷ'DPDJHWRWKHSURGXFWFDXVHGE\LPSURSHUSRZHU
supply voltage, accident, fire, floods or acts of God.
Ŷ,QFLGHQWDORUFRQVHTXHQWLDOGDPDJHFDXVHGE\
possible defects with this air conditioner.
Ŷ'DPDJHFDXVHGDIWHUGHOLYHU\
What GE Appliances Will Not Cover:
7KLVOLPLWHGZDUUDQW\LVH[WHQGHGWRWKHRULJLQDOSXUFKDVHUDQGDQ\VXFFHHGLQJRZQHUIRUSURGXFWVSXUFKDVHG
IRUKRPHXVHZLWKLQWKH86$,IWKHSURGXFWLVORFDWHGLQDQDUHDZKHUHVHUYLFHE\D*($SSOLDQFHV$XWKRUL]HG
Servicer is not available, you may be responsible for a trip charge or you may be required to bring the product to an
$XWKRUL]HG*($SSOLDQFHV6HUYLFHORFDWLRQIRUVHUYLFH,Q$ODVNDWKHOLPLWHGZDUUDQW\H[FOXGHVWKHFRVWRIVKLSSLQJ
or service calls to your home.
6RPHVWDWHVGRQRWDOORZWKHH[FOXVLRQRUOLPLWDWLRQRILQFLGHQWDORUFRQVHTXHQWLDOGDPDJHV7KLVOLPLWHGZDUUDQW\
gives you specific legal rights, and you may also have other rights which vary from state to state. To know what your
legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: GE Appliances, aHaier company
Louisville, KY 40225
(;&/86,212),03/,(':$55$17,(6²<RXUVROHDQGH[FOXVLYHUHPHG\LVSURGXFWUHSDLUDVSURYLGHGLQWKLV
Limited Warranty. Any implied warranties, including the implied warranties of merchantability or fitness for a particular
purpose, are limited to one year or the shortest period allowed by law.
For The Period Of: GE Appliances Will Replace:
One Year
From the date of the
original purchase
Any part of the air conditioner which fails due to a defect in materials or workmanship. During
this limited one-year warranty, GE Appliances will also provide, free of charge, all labor
and related service to replace the defective part.
Staple your receipt here. Proof of the original purchase date is needed to obtain service under the warranty.
All warranty service provided by our Factory Service Centers, or an authorized Customer Care® technician. To
schedule service, visit us on-line at geappliances.com, or call 1-800-GE-CARES Have serial number and model
number available when calling for service.

20 49-5000434 Rev. 2
Printed in China
Consumer Support
CONSUMER SUPPORT
GE Appliances Website
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day
of the year! You can also shop for more great GE Appliances products and take advantage of all our on-line support
VHUYLFHVGHVLJQHGIRU\RXUFRQYHQLHQFH,QWKH86GEAppliances.com
Register Your Appliance
Register your new appliance on-line at your convenience! Timely product registration will allow for enhanced
communication and prompt service under the terms of your warranty, should the need arise. You may also mail in
WKHSUHSULQWHGUHJLVWUDWLRQFDUGLQFOXGHGLQWKHSDFNLQJPDWHULDO,QWKH86GEAppliances.com/register
Parts and Accessories
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, MasterCard and Discover cards are accepted). Order on-line today 24 hours every day.
,QWKH86GEApplianceparts.com or by phone at 877.959.8688 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing
generally should be referred to qualified service personnel. Caution must be exercised, since improper
servicing may cause unsafe operation.
Contact Us
If you are not satisfied with the service you receive from GE Appliances, contact us on our Website with all the
details including your phone number, or write to:
,QWKH86*HQHUDO0DQDJHU&XVWRPHU5HODWLRQV_*($SSOLDQFHV$SSOLDQFH3DUN_/RXLVYLOOH.<
GEAppliances.com/contact
