GE AHLE06CA User manual

Write the model and serial
numbers here:
Model #_________________
Serial # _________________
You can find the rating label on the
side of the air conditioner.
GE is a trademark of the General Electric Company. Manufactured under trademark license.
OWNER’S MANUAL
AIR CONDITIONER
ROOM
49-5000719 Rev. 1 10-22 GEA
SAFETY INFORMATION .........3
USING THE AIR CONDITIONER
Controls ..............................5
Remote Control .......................6
Cool Mode ............................6
Eco..................................6
Air Direction ..........................7
CARE AND CLEANING
Grille and Case ........................8
Air Filter..............................8
Outdoor Coils .........................8
Install Batteries in Remote ..............8
INSTALLATION INSTRUCTIONS
Before you begin ......................9
Electrical Requirements ................9
Parts Included ........................10
Window Requirements ................ 11
Prepare the Air Conditioner ............ 11
Install the Air Conditioner..............12
TROUBLESHOOTING TIPS......14
Normal Operating Sounds .............15
CONSUMER SUPPORT
Limited Warranty .....................17
Consumer Support ....................18
AHLE06CA
ENGLISH/ESPAÑOL

249-5000719 Rev. 1
THANK YOU FOR MAKING GE APPLIANCES A PART OF YOUR HOME.
Whether you grew up with GE Appliances, or this is your first, we’re happy to have you in the family.
We take pride in the craftsmanship, innovation and design that goes into every GEAppliances
product, and we think you will too. Among other things, registration of your appliance ensures that we
can deliver important product information and warranty details when you need them.
Register your GE appliance now online. Helpful websites and phone numbers are available in the
Consumer Support section of this Owner’s Manual. You may also mail in the pre-printed registration
card included in the packing material.

49-5000719 Rev. 1 3
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
WARNING For your safety, the information in this manual must be followed to minimize the risk of
fire, electric shock or personal injury.
Ŷ8VHWKLVDSSOLDQFHRQO\IRULWVLQWHQGHGSXUSRVHDV
described in this Owner’s Manual.
ŶThis air conditioner must be properly installed in
accordance with the Installation Instructions before it is
used.
ŶNever unplug your air conditioner by pulling on the
power cord. Always grip plug firmly and pull straight
out from the receptacle.
ŶReplace immediately all electric service cords that
have become frayed or otherwise damaged. A
damaged power supply cord must be replaced with a
new power supply cord obtained from the manufacturer
and not repaired. Do not use a cord that shows cracks
or abrasion damage along its length or at either the
plug or connector end.
ŶTurn the unit OFF and unplug your air conditioner
before cleaning.
ŶFor your safety…do not store or use combustible
materials, gasoline or other flammable vapors or
liquids in the vicinity of this or any other appliance.
ŶIf the receptacle does not match the plug, the
receptacle must be changed out by a qualified
electrician.
Ŷ'RQRWXVHPHDQVWRDFFHOHUDWHWKHGHIURVWLQJSURFHVV
or to clean, other than those recommended by the
manufacturer.
ŶThe appliance shall be stored in a room without
continuously operating ignition sources (for example:
open flames, an operating gas appliance or an
operating electric heater.
ŶDo not pierce or burn refrigerant tubing. Be aware that
refrigerants may not contain an odor.
ŶKeep ventilation openings clear of obstruction.
ŶWhen handling, installing, and operating the appliance,
care should be taken to avoid damage to the
refrigerant tubing.
ŶDo not drill holes in the unit.
ŶMaintenance, cleaning, and service should only be
performed by technicians properly trained and qualified
in the use of flammable refrigerants.
ŶGE Appliances does not support any servicing of the
air conditioner.
ŶDispose of air conditioner in accordance with Federal
and Local Regulations. Flammable refrigerants require
special disposal procedures. Contact your local
authorities for the environmentally safe disposal of your
air conditioner.
WARNING
Risk of Fire or Explosion. This unit contains flammable refrigerant.
Additional safety precautions must be followed.

449-5000719 Rev. 1
SAFETY INFORMATION
WARNING USE OF EXTENSION CORDS
RISK OF FIRE. Could cause serious injury or death.
Ŷ'2127XVHDQH[WHQVLRQFRUGZLWKWKLV:LQGRZ$LU
Conditioner.
Ŷ'2127XVHVXUJHSURWHFWRUVRUPXOWLRXWOHWDGDSWRUV
with this Window Air Conditioner.
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the third
(ground) prong from the power cord. For personal safety,
this appliance must be properly grounded.
DO NOT use an adapter plug with this appliance.
The power cord of this appliance is equipped with a
3-prong (grounding) plug which mates with a standard
3-prong (grounding) wall outlet to minimize the possibility
of electric shock hazard from this appliance.
Power cord includes a current interrupter device. A test
and reset button is provided on the plug case. The device
should be tested on a periodic basis by first pressing the
TEST button and then the RESET button while plugged
into the outlet. If the TEST button does not trip or if the
RESET button will not stay engaged, discontinue use of the
air conditioner and contact a qualified service technician.
Have the wall outlet and circuit checked by a qualified
electrician to make sure the outlet is properly grounded.
Where a 2-prong wall outlet is encountered, it is your
personal responsibility and obligation to have it replaced
with a properly grounded 3-prong wall outlet.
The air conditioner should always be plugged into its
own individual electrical outlet which has a voltage rating
that matches the rating plate.
This provides the best performance and also prevents
overloading house wiring circuits which could cause a
fire hazard from overheated wires.
See the Installation Instructions, Electrical
Requirements section for specific electrical connection
requirements.
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
READ AND SAVE THESE INSTRUCTIONS

49-5000719 Rev. 1 5
Controls
Controls
1. Power Pad
Turns air conditioner on and off. When turned on, the
display will show the Set temperature.
2. Display
Shows the Set temperature or time remaining on the
Delay timer. Shows the Set temperature while setting
the temperature in Cool or Eco modes.
3. Temp and Delay Increase + /Decrease –Pads
8VHWRVHWWHPSHUDWXUHRUGHOD\WLPH7HPSHUDWXUH
can be set in Cool and Eco mode.
4. Mode Pad
8VHWRVHWWKHDLUFRQGLWLRQHUWR Fan Only, Cool, or
Eco mode.
5. Fan Speed Pad
In Cool, Eco mode:
8VHWRVHWWKHIDQVSHHGWR Auto, High, Med or Low
on the unit.
In Fan Only mode:
8VHWRVHWWKHIDQVSHHGWR High, Med, or Low
on the unit.
6. Delay Pad
Delay ON—When the air conditioner is off, it can be
set to automatically come on in 1 to 24 hours at its
previous mode and fan settings.
Delay OFF—When the air conditioner is on,
it can be set to automatically turn off in 1 to
24 hours.
How to set:
Press the Delay 1–24hr pad on the unit or the remote
control. Each touch of the Increase + / Decrease –
pads on the unit or the remote control will set the timer
in 1-hour intervals.
To review the remaining time on the Delay 1–24hr
timer, press the Delay 1–24hr pad on the unit or the
UHPRWHFRQWURO8VHWKH Increase +/ Decrease –
pads on the unit or on the remote control to set a new
time if desired.
To cancel the timer, press Decrease – pad on the
unit or the remote control until the set time is zero.
After 3 seconds the light on the Delay 1-24 hour pad
goes off.
7. Filter Reset Pad
This feature automatically notifies you that the air filter
must be cleaned. The indicator light will come on after
250 hours of operation. Clean the air filter (refer to
page 8), place it back in the front panel, and press the
Filter Reset pad. The light will go off.
Features and appearance will vary.
Lights below the touch pads on the air conditioner control panel indicate the selected settings.
Air Conditioner Controls Remote Control
2
6
3
4
5
7
1
CONTROLS
Power
Speed
Mode
Eco Delay
1
4
5
6
3

649-5000719 Rev. 1
Using the Air Conditioner
Remote Control
Ŷ To ensure proper operation, aim the remote control at the
signal receiver on the air conditioner.
Ŷ The remote control signal has a range of up to 20 feet.
Ŷ Make sure nothing is between the air conditioner and the
remote control that could block the signal.
Ŷ Make sure batteries are fresh and installed correctly as
indicated on the remote control.
Do Not Operate in Freezing Outdoor Conditions
This cool-only air conditioner was not designed for freezing
outdoor conditions. It must not be used when the outdoor
temperature is below freezing (32°F).
Cool Mode
8VHWKH&RROPRGHDWLow, Med, High or Speed for
FRROLQJ8VHWKHTemperature Increase + / Decrease –
pads to set the desired temperature between 64°F and
86°F in 1°F increments.
An electronic thermostat is used to maintain the room
temperature. The compressor will cycle on and off
to keep the room at the set level of comfort. Set the
thermostat at a lower number and the indoor air will
become cooler. Set the thermostat at a higher number
and the indoor air will become warmer.
NOTE: If the air conditioner is off and is then turned on
while set to a Cool setting or if turned from a fan setting
to a Cool setting, it may take approximately 3 minutes for
the compressor to start and cooling to begin.
Cooling Descriptions
For Normal Cooling—Select the Cool mode and
High or Med fan with a middle set temperature.
For Maximum Cooling—Select the Cool mode
and High fan with a lower set temperature.
For Quieter and Nighttime Cooling—Select the
Cool mode and Low fan with a middle set temperature.
Eco
Controls the fan.
ON—The fan will cycle on and off with the compressor.
This may result in wider variations of room temperature
and humidity. NOTE: the fan may continue to run
for a short time or may pulse intermittently after the
compressor cycles off to sample the room air.
OFF—The fan runs all the time, while the compressor
cycles on and off.
Fan Only Mode
8VHWKH)DQ2QO\0RGHDW/RZ0HGRU+LJKIDQVSHHG
to provide air circulation and filtering without cooling.
Since fan-only settings do not provide cooling, a Set
temperature cannot be entered. The room temperature
will appear in the display.
USING THE AIR CONDITIONER

49-5000719 Rev. 1 7
Using the Air Conditioner
USING THE AIR CONDITIONER
Auto Fan Mode
Set to Auto for the fan speed to automatically set to the
speed needed to provide optimum comfort settings with
the set temperature.
If the room needs more cooling, the fan speed will
automatically increase. If the room needs less cooling,
the fan speed will automatically decrease.
Air Direction
8VHWKHOHYHUWRDGMXVWWKHDLUGLUHFWLRQOHIWWRULJKW

849-5000719 Rev. 1
CARE AND CLEANING
Care and Cleaning
Grille and Case
Turn the air conditioner off and remove the plug from the
wall outlet before cleaning. To clean, use water and a mild detergent. Do not use bleach or abrasives.
Air Filter
The air filter behind the front grille should be checked
and cleaned at least every 30 days or more often if
necessary.
To remove:
Slide the filter from the left side of the unit. Remove the
filter.
Clean the filter with warm, soapy water. Rinse and let the
filter dry before replacing it. Do not clean the filter in a
dishwasher.
CAUTION
DO NOT operate the air conditioner
without a filter because dirt and lint will clog it and reduce
performance.
Outdoor Coils
The coils on the outdoor side of the air conditioner should
be checked regularly. If they are clogged with dirt or soot,
they may be professionally cleaned.
How to Insert the Batteries in the Remote Control
1. Remove the battery cover by sliding it according to the
arrow direction.
2. Insert new batteries, making sure that the (+) and (–)
of battery are installed correctly.
3. Reattach the cover by sliding it back into position.
NOTES:
Ŷ8VH³$$$´YROWEDWWHULHV'RQRWXVH
rechargeable batteries.
Ŷ5HPRYHWKHEDWWHULHVIURPWKHUHPRWHFRQWUROLIWKH
system is not going to be used for a long time.
Ŷ'RQRWPL[ROGDQGQHZEDWWHULHV'RQRWPL[VWDQGDUG
(carbon-zinc) or rechargeable (ni-cad, ni-mh, etc)
batteries.

49-5000719 Rev. 1 9
Installation Instructions
INSTALLATION INSTRUCTIONS
BEFORE YOU BEGIN
Read these instructions completely and carefully.
•IMPORTANT –Save these
instructions for local inspector’s use.
•IMPORTANT –Observe all
governing codes and ordinances.
• Note to Installer – Be sure to leave these
instructions with the Consumer.
• Note to Consumer – Keep these instructions for
future reference.
• Skill level – Installation of this appliance requires
basic mechanical skills.
• Completion time – Approximately 1 hour
• We recommend that two people install
this product.
• Proper installation is the responsibility
of the installer.
• Product failure due to improper installation is not
covered under the Warranty.
 <RX0867XVHDOOVXSSOLHGSDUWVDQGXVHSURSHU
installation procedures as described in these
instructions when installing this air conditioner.
Questions? Visit our Website at: GEAppliances.com
ELECTRICAL REQUIREMENTS
These models require a 115/120-volt AC,
60-Hz grounded outlet protected with a
15-amp time-delay fuse or circuit breaker.
The 3-prong grounding plug minimizes the possibility
of electric shock hazard. If the wall outlet you plan to
use is only a 2-prong outlet, it is your responsibility
to have it replaced with a properly grounded 3-prong
wall outlet.
CAUTION
Do not, under any circumstances, cut or remove the
third (ground) prong from the power cord.
Do not change the plug on the power cord of this air
conditioner.
Aluminum house wiring may present special
problems—consult a qualified electrician.
Power cord includes a current interrupter device. A
test and reset button is provided on the plug case.
The device should be tested on a periodic basis
by first pressing the TEST button and then the
RESET button while plugged into the outlet. If the
TEST button does not trip or if the RESET button
will not stay engaged, discontinue use of the air
conditioner and contact a qualified service technician.
TOOLS YOU WILL NEED
Phillips head screwdriver
Ruler or tape measurePencil
Level Scissors or knife
'ULOODQG´GULOOELW

10 49-5000719 Rev. 1
Installation Instructions
INSTALLATION INSTRUCTIONS
Temp / Delay Hrs
-
Side Curtain
Frame
Type B (9)
´:RRG
Screws
Foam top window gasket
Side
Curtain (2)
Top mounting rail
Air
conditioner
Window locking
bracket (1)
Side Brackets
(2)
PARTS INCLUDED
(Appearance may vary)
Remote
Control
Left Right
Type A (3)
+
-
DELAY
MODE
ON/OFF
SPEED
TEMP/TIME
TEMP/TIME
Power
Speed
Mode
Eco Delay

49-5000719 Rev. 1 11
Installation Instructions
INSTALLATION INSTRUCTIONS
3. PREPARE THE AIR CONDITIONER
A. Install the top mounting rail with Type A screws
from the outside of the case.
B. Slide the side curtain panels into the side panel
rails.
C. Slide left and right side curtain frames into top
and bottom rails. Make sure that side curtains
snap into side of the frames.
1. WINDOW REQUIREMENTS
• These instructions are for a standard
double-hung window. You will need to modify
them for other types of windows.
• The air conditioner can be installed without the
side curtain panels if needed to fit in a narrow
window. See the window opening dimensions.
• All supporting parts must be secured to firm
wood, masonry or metal.
• The electrical outlet must be within reach of
the power cord.
• Follow the dimensions in the table and
illustration for your model.
2. STORM WINDOW REQUIREMENTS
A storm window frame will not allow the air
conditioner to tilt toward the outside, and will
NHHSLWIURPGUDLQLQJSURSHUO\7RDGMXVWIRUWKLV
attach a piece of wood to the sill.
WOOD PIECES
WIDTH: 2Ǝ
LENGTH: Long enough to fit inside the window
frame.
THICKNESS: To determine the thickness, place
DSLHFHRIZRRGRQWKHVLOOWRPDNHLWƎKLJKHU
than the top of the storm window frame or the
vinyl frame.
Attach securely with nails or screws provided by
the installer.
(With side curtain panels)
´´
´
ƎKLJKHU
than storm
window
frame
Storm window
frame
Wood
Sill
ƎKLJKHU
than vinyl frame
(on some windows)
Vinyl frame
Top Mounting rail
CLICK

12 49-5000719 Rev. 1
Installation Instructions
INSTALLATION INSTRUCTIONS
5. SECURE AIR CONDITIONER
A. Install the side bracket into the unit and into the
ZLQGRZVLOOXVLQJWZR´ZRRGVFUHZVSURYLGHG
repeate on other side.
4. INSTALL THE AIR CONDITIONER
IN THE WINDOW
A. Mark the center of the window. Set the air
conditioner in the window so that is it centered.
Place the air conditioner so that front edge of
the bottom mounting rail is against the back
edge of the sill.
B. Bring the window down so that the front edge
of the top mounting is in front of the window.
Make sure that the air conditioner is level or
tilting slightly to the outside.
C. Extend the curtain panels until they fill the
window. Mark the location of the holes in each
FRUQHU8VHWKHGULOODQG´GULOOELWWRGULOOSLORW
KROHV8VHW\SH%VFUHZVWRVHFXUHWKHVLGH
panels in place.
Type B screws

49-5000719 Rev. 1 13
Installation Instructions
INSTALLATION INSTRUCTIONS
6. INSTALL WINDOW LOCK
BRACKET AND FOAM TOP
WINDOW GASKET
8VH7\SH%6FUHZWRLQVWDOOWKHZLQGRZORFN
bracket on top of the bottom window.
A. CAUTION
To prevent broken glass or
damage to windows, on vinyl
or other similarly constructed
windows, attach the window
locking bracket to the
ZLQGRZVLGHMDPEZLWKRQH
Type B screw.
B. Cut the foam top window gasket to the window
width.
C. Stuff the foam between the glass and the
window to prevent air and insects from getting
into the room.
NOTE: If the gasket supplied does not fit your
window, obtain appropriate material locally to
provide a proper installation seal.
Wood
Vinyl

14 49-5000719 Rev. 1
Troubleshooting Tips
TROUBLESHOOTING TIPS
Save time and money! Review the charts on the following pages first and you may not need to call for service.
Problem Possible Cause What To Do
Air conditionerdoes not
start. The unit is unplugged. Make sure the air conditioner plug is pushed completely into the outlet.
The fuse is blown/circuit breaker
is tripped. Check the house fuse/circuit breaker box and replace the fuse or reset the breaker.
Power Failure. The unit will automatically restart in the setting last
used after the power is restored.
There is a protective time delay (approximately
3 minutes) to prevent tripping of the compressor
overload. For this reason, the unit may not start normal
cooling for 3 minutes after it is turned back on.
The current interrupter device is
tripped. Press RESET button located on the power cord plug.
If the RESET button will not stay engaged, discontinue
use of the air conditioner and contact a qualified
service technician.
Air conditioner does not
cool as it should. Indoor airflow is restricted. Make sure there are not curtains, blinds or furniture blocking the front of the air conditioner.
The temp control may not be set
properly. Turn the temperature control to a higher number.
The air filter is dirty. Clean the filter at least every 30 days. See Care and
Cleaning section.
The room may have been hot. When the air conditioner is first turned on, you need to
allow time for the room to cool down.
Cold air is escaping. Check for open furnace registers and cold air returns.
Cooling coils have iced up. 6HH³$LUFRQGLWLRQHUIUHH]LQJXS´EHORZ
Air conditioner freezing up Ice blocks the air flow and stops
the air conditioner from cooling
the room.
Set the mode control to High Fan or High Cool with the
temperature setting as high as it can be set.
Water drips outside Hot, humid weather. This is normal.
Water drips inside The air conditioner is not tilted to
the outside. For proper disposal, make sure the air conditioner slants slightly from the case front to the rear.
Water collects in base pan Moisture removed from air and
drain into base pan. This is normal for a short period in areas with little humidity; normal for a longer period in very humid
areas.

49-5000719 Rev. 1 15
Ŷ<RXPD\KHDUDSLQJLQJQRLVHFDXVHGE\ZDWHUEHLQJSLFNHGXSDQGWKURZQDJDLQVWWKHFRQGHQVHURQUDLQ\GD\V
or when the humidity is high. This design feature helps remove moisture and improve efficiency.
Ŷ<RXPD\KHDUWKHWKHUPRVWDWFOLFNZKHQWKHFRPSUHVVRUF\FOHVRQDQGRII
Ŷ:DWHUZLOOFROOHFWLQWKHEDVHSDQGXULQJKLJKKXPLGLW\RURQUDLQ\GD\V7KHZDWHUPD\RYHUIORZDQGGULSIURPWKH
outdoor side of the unit.
Ŷ7KHIDQPD\UXQHYHQZKHQWKHFRPSUHVVRUGRHVQRW
Ŷ:DWHUGURSOHWVEHLQJWKURZQDJDLQVWWKHRXWVLGHFRLOVFDQPDNHDSLQJLQJQRLVH7KLVKHOSVFRROWKHFRQGHQVHU
You can reduce this noise by removing the subbase water plug.
To ensure maximum efficiency it is recommended to check to ensure the rubber drain plug is properly inserted.
This plug may be removed during operation to minimize water in the back of the unit; however, removing it will
lower the efficiency of your unit.
NOTE: Do not drill hole in the base pan.
Normal Operating Sounds
TROUBLESHOOTING TIPS
Subbase Water Plug

16 49-5000719 Rev. 1
Notes
NOTES

49-5000719 Rev. 1 17
GE Appliances Dehumidifier Limited Warranty
Staple your receipt here. Proof of the original purchase date is needed to obtain service under the warranty.
EXCLUSION OF IMPLIED WARRANTIES - Your sole and exclusive remedy is product repair as provided in this
Limited Warranty. Any implied warranties, including the implied warranties of merchantability or fitness for a particular
purpose, are limited to one year or the shortest period allowed by law.
For US Customers: This limited warranty is extended to the original purchaser and any succeeding owner for
SURGXFWVSXUFKDVHGIRUKRPHXVHZLWKLQWKH86$,IWKHSURGXFWLVORFDWHGLQDQDUHDZKHUHVHUYLFHE\D*(
Appliances Authorized Servicer is not available, you may be responsible for a trip charge or you may be required to
bring the product to an Authorized GEAppliances Service location for service. In Alaska, the limited warranty excludes
the cost of shipping or service calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This limited warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To know what your
legal rights are, consult your local or state consumer affairs office or your state’sAttorney General.
Warrantor US:
GE Appliances, aHaier company
Louisville, KY 40225
• Customer instruction. This owner’s manual provides
information regarding operating instructions and user
controls.
• Improper installation. If you have an installation
problem, or if the product is of improper capacity,
contact your dealer or installer. You are responsible
for providing adequate electrical connecting facilities.
• Failure of the product resulting from modifications
to the product or due to unreasonable use including
failure to provide reasonable and necessary
maintenance.
• Replacement of house fuses or resetting of circuit
breakers.
• Failure due to corrosion.
• Damage to the product caused by improper power
supply voltage, accident, fire, floods or acts of God.
• Incidental or consequential damage caused by
possible defects with this product.
• Damage caused after delivery.
What Will Not Cover:
For The Period Of: Will Replace:
One Year
From the date of the
original purchase
Replacement, repair, or refund of the original retail price for any product which fails due
to a defect in materials or workmanship. If the unit is exchanged, the replacement unit
is warranted for the remainder of your product’s original one-year warranty period. GE
Appliances will, at its sole discretion, replace the product with a product of the same or
comparable functionality and quality or refund the original retail price.
• Properly pack your unit. We recommend using the
original carton and packing materials.
• Return the product to the retail location where it was
purchased.
• Include in the package a copy of the sales receipt
or other evidence of date of original purchase. Also
print your name and address and a description of the
defect.
In Order to Make a Warranty Claim During Your Retailer’s Allowable Return Period:
• Locate your original sales receipt and make a note of your model and serial number.
• Call LQWKH8QLWHG6WDWHV to initiate a warranty claim.
• You will be asked to provide your name, address, date of purchase, model and serial number.
• Warrant claims may require electronic or mailed-in evidence of purchase.
In Order to Make a Warranty Claim During the Remainder of the One-Year Warranty:
LIMITED WARRANTY

18 49-5000719 Rev. 1
Consumer Support
CONSUMER SUPPORT
GE Appliances Website
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day
of the year! You can also shop for more great GE Appliances products and take advantage of all our on-line support
VHUYLFHVGHVLJQHGIRU\RXUFRQYHQLHQFH,QWKH86GEAppliances.com
Register Your Appliance
Register your new appliance on-line at your convenience! Timely product registration will allow for enhanced
communication and prompt service under the terms of your warranty, should the need arise. You may also mail in
WKHSUHSULQWHGUHJLVWUDWLRQFDUGLQFOXGHGLQWKHSDFNLQJPDWHULDO,QWKH86GEAppliances.com/register
Parts and Accessories
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, MasterCard and Discover cards are accepted). Order on-line today 24 hours every day.
,QWKH86GEApplianceparts.com or by phone at 877.959.8688 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing
generally should be referred to qualified service personnel. Caution must be exercised, since improper
servicing may cause unsafe operation.
Contact Us
If you are not satisfied with the service you receive from GE Appliances, contact us on our Website with all the
details including your phone number, or write to:
,QWKH86*HQHUDO0DQDJHU&XVWRPHU5HODWLRQV_*($SSOLDQFHV$SSOLDQFH3DUN_/RXLVYLOOH.<
GEAppliances.com/contact

ACCONDICIONADORES DE AIRE
PARA SALA
INFORMACIÓN DE SEGURIDAD ...3
USO DEL ACONDICIONADOR DE
AIRE
Controles .............................4
Control Remoto .......................5
Modo de Frío .........................5
Modo de Ahorro de Energía ............5
Dirección del Aire .....................6
CUIDADO Y LIMPIEZA
Parrilla y Caja .........................6
Filtro de Aire .........................6
Bobinas Externas ......................6
Instalación de Baterías en el
Modo Remoto .......................6
INSTRUCCIONES DE INSTALACIÓN
Antes de comenzar ....................7
Requisitos Eléctricos ..................7
Piezas Incluidas .......................8
Requisitos de la Ventana ...............9
Preparación del Acondicionador de Aire .9
Instalación del Acondicionador de Aire . 10
CONSEJOS PARA LA SOLUCIÓN
DE PROBLEMAS .................14
Sonidos de Funcionamiento Normal ....15
SOPORTE AL CLIENTE
Garantía Limitada.....................17
Soporte al Cliente ....................18
GE es una marca registrada de General Electric Company. Fabricado bajo licencia de marca.
MANUAL DEL
PROPIETARIO
Escriba los números de modelo y de
serie aquí:
Nº de Modelo ____________
Nº de Serie ______________
Estos números se encuentran en una
etiqueta al costado del acondicionador
de aire.
49-5000719 Rev. 1 10-22 GEA
AHLE06CA

249-5000719 Rev. 1
GRACIAS POR HACER QUE GE APPLIANCES SEA PARTE DE SU HOGAR.
Ya sea que haya crecido usando GE Appliances, o que ésta es su primera vez, nos complace
tenerlo en la familia.
Sentimos orgullo por el nivel de arte, innovación y diseño de cada uno de los electrodomésticos de
GE Appliances, y creemos que usted también. Entre otras cosas, el registro de su electrodoméstico
asegura que podamos entregarle información importante del producto y detalles de la garantía
cuando los necesite.
Registre su electrodoméstico GE ahora a través de Internet. Sitios Web y números telefónicos útiles
están disponibles en la sección de Soporte para el Consumidor de este Manual del Propietario.
También puede enviar una carta en la tarjeta de inscripción preimpresa que se incluye con
el material embalado.
