GE Zoneline AZ95E Operating instructions

Write the model and serial
numbers here:
Model #_________________
Serial # _________________
You can find them on a label on
the top panel.
GE is a trademark of the General Electric Company. Manufactured under trademark license.
AIR CONDITIONER
Zoneline®Vertical
49-5000561 Rev. 1 01-21 GEA
SAFETY INFORMATION .........3
USING THE ZONELINE
Temperature Control ...................6
About your Unit .......................6
Quick Heat Recovery...................6
Auxiliary Control Features ..............6
CARE AND CLEANING
Air Filters .............................8
Drain .................................8
Indoor/Outdoor Coils ..................9
Base Pan .............................9
INSTALLATION INSTRUCTIONS
Installation Overview..................10
Installation Preparation................15
Installing the Zoneline.................18
Servicing ........................... 24
Setting the Auxiliary Controls ..........25
TROUBLESHOOTING TIPS
Normal Operating Sounds .............28
Troubleshooting Tips................. 29
CONSUMER SUPPORT
Product Registration ..................31
Limited Warranty .....................33
Consumer Support ................... 34
OWNER’S MANUAL
AND INSTALLATION
INSTRUCTIONS
Heat/Cool
AZ95E
Heat Pump
AZ95H
FRANÇAIS
Pour une version français de
ce manuel d’utilisation, veuillez
visiter notre site web à l’adresse
Zoneline.com.
ESPAÑOL
Para consultar una version en
español de este manual de
instrucciones, visite
nuestro sitio de internet
Zoneline.com.
PTAC DIRECT SALES, INC.
185 S. Kimball Ave., Suite 130
Southlake, TX 76092
877.454.7822 (T)

249-5000561 Rev. 1
THANK YOU FOR MAKING GE APPLIANCES A PART OF YOUR HOME.
Whether you grew up with GE Appliances, or this is your first, we’re happy to have you in the family.
We take pride in the craftsmanship, innovation and design that goes into every GE Appliances
product, and we think you will too. Among other things, registration of your appliance ensures that we
can deliver important product information and warranty details when you need them.
Register your GE appliance now online. Helpful websites and phone numbers are available in the
Consumer Support section of this Owner’s Manual. You may also mail in the pre-printed registration
card included in the back of this manual.

49-5000561 Rev. 1 3
WARNING For your safety, the information in this manual must be followed to minimize the risk
of fire, explosion, electric shock, property damage, personal injury, or loss of life.
SAFETY PRECAUTIONS
■ This Zoneline must be properly installed in accordance with the Installation Instructions before it is used.
Zoneline Vertical units shall not be accessible to the room guest. See the Installation Instructions in the back
of this manual.
NOTE: GEA strongly recommends that any servicing be performed by a qualified person.
■ All air conditioners contain refrigerants, which under federal law must be removed prior to product disposal. If
you are getting rid of an old product with refrigerants, check with the company handling disposal about what
to do.
■ These R410A air conditioning systems require contractors and technicians to use tools, equipment and safety
standards approved for use with this refrigerant. DO NOT use equipment certified for R22 refrigerant only.
■ This unit is certified for installations up to 13,000 (3962m) feet above sea level.
■ This unit is not to be installed in a laundry room.
■ Children should be supervised to ensure that they do not play with the appliance.
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
SAFETY INFORMATION
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.

449-5000561 Rev. 1
WARNING Para su seguridad, siga la información de este manual a fin de minimizar riesgos
de incendio, explosión, descargas eléctricas, daños en su propiedad, lesiones personales o la
pérdida de la vida.
PRECAUCIONES DE SEGURIDAD
■ Este Zoneline debe ser instalado de forma apropiada de acuerdo con las Instrucciones de Instalación antes
de ser usado. Las unidades de Zoneline Vertical no serán accesibles en la sala de huéspedes. Consulte las
Instrucciones de Instalación que figuran en el reverso de este manual.
NOTA: GEA recomienda enfáticamente que cualquier reparación sea realizada por un individuo calificado.
■ Todos los acondicionadores de aire contienen refrigerantes, los cuales de acuerdo con la ley federal deben
ser retirados antes de deshacerse del producto. Si se deshará de un producto antiguo con refrigerantes,
consulte a la compañía a cargo sobre cómo deshacerse del mismo.
■ Estos sistemas de acondicionadores de aire R410A requieren que los contratistas y técnicos usen
herramientas, equipos y estándares de seguridad aprobados para su uso con este refrigerante. NO use
equipamiento certificado sólo para el refrigerante R22.
■ Esta unidad cuenta con certificación para instalaciones de hasta 13,000 (3962m) pies sobre el nivel del mar.
■ Esta unidad no se deberá instalar en un lavadero.
■ Se deberá supervisar a los niños a fin de asegurar que no se juegue con el electrodoméstico.
Este electrodoméstico no deberá ser usado por personas (incluyendo niños) con capacidades físicas,
sensoriales o mentales reducidas o con falta de experiencia y conocimiento, a menos que cuenten con
supervisión o instrucción con relación al uso de este electrodoméstico por parte de una persona responsable
de su seguridad.
INFORMACIÓN IMPORTANTE DE SEGURIDAD
LEA TODAS LAS INSTRUCCIONES ANTES DE USAR
INFORMACIÓN DE SEGURIDAD
LEA Y GUARDE ESTAS INSTRUCCIONES

49-5000561 Rev. 1 5
WARNING Pour votre sécurité, veuillez observer les consignes de ce manuel afin de réduire
le risque d’incendie, d’explosion, de choc électrique, de dommages à la propriété ou de blessures
graves ou fatales.
MESURES DE SÉCURITÉ
■ Avant son utilisation, ce climatiseur Zoneline doit être installé correctement en conformité avec les instructions
d'installation. Les invités ne doivent pas avoir accès aux unités du climatiseur Zoneline Vertical. Consultez les
instructions d'installation au dos de ce manuel.
REMARQUE : GEA recommande vivement que toute réparation soit effectuée par une personne qualifiée
en la matière.
■ Tous les climatiseurs contiennent un frigorigène qu’il faut retirer avant de disposer du produit en vertu de
la loi fédérale. Si vous vous débarrassez d’un produit qui contient un frigorigène, informez-vous auprès de
l’organisme responsable d’en disposer.
■ Ces systèmes de climatisation R410A exigent que les entrepreneurs et les techniciens utilisent des outils, des
équipements et des normes de sécurité approuvés pour ce type de frigorigène. N'utilisez PAS un équipement
certifié uniquement pour le frigorigène R22.
■ Cet appareil est certifié pour une installation pouvant s’élever jusqu’à 13 000 pieds (3 962 m) au-dessus du
niveau de la mer.
■ Cet appareil ne doit pas être installé dans une salle de lavage.
■ Les enfants doivent être surveillés afin de s’assurer qu’ils ne jouent pas avec l’appareil.
Cet appareil n’est pas destiné à être utilisé par des personnes (y compris les enfants) dont les capacités
physiques, sensorielles ou mentales sont réduites ou l’expérience et les connaissances sont insuffisantes,
sauf si une personne responsable de leur sécurité les surveille étroitement ou les familiarise avec l’utilisation
de l’appareil.
CONSIGNES DE SÉCURITÉ IMPORTANTES
LISEZ TOUTES LES INSTRUCTIONS AVANT D’UTILISER L’APPAREIL
CONSIGNES DE SÉCURITÉ
LISEZ ET CONSERVEZ CES INSTRUCTIONS

649-5000561 Rev. 1
FEATURES OF THE ZONELINE
Features
About Your Heat Pump (AZ95H Only)
Heat pumps can save money by removing heat from the
outside air—even when the outside temperature is below
freezing—and releasing that heat indoors.
To get the best energy performance from your heat
pump, don’t change the room thermostat by more than
one degree at one time. Raising the heat setting 2–3
degrees may cause the Zoneline to use its electric
heating elements in order to reach the new temperature
setting quickly.
The electric heating elements use more electricity than
heat pumps and cost more to operate.
There is a 3-minute minimum compressor run time at
any setting to prevent short cycling.
The fans start before the compressor and stop after the
compressor cycles off.
When the outdoor temperature is determined to be too
cold, heat is provided by the electric heater instead of by
the heat pump.
When the outdoor temperature is lower than 35°F,
cooling operation is locked out to prevent damage to the
compressor. Operation will resume when the outdoor
temperature rises above 40°F.
Temperature Control
This unit must be controlled by a Class 2 remote control
wall mounted heating and cooling thermostat. Refer to
the operating instructions of the thermostat being used
on how to control the unit.
Quick Heat Recovery
Activates each time the thermostat is switched from OFF or COOL mode to HEAT mode. Electric heaters are
energized until the thermostat set point is reached. On heat pump models, the heat pump operation will resume at
the next call for heat.
Do Not Operate the Air Conditioner (cool mode) in Freezing Outdoor Conditions
Air conditioners are not designed for use when freezing outdoor conditions exist. They must not
be used in freezing outdoor conditions.

49-5000561 Rev. 1 7
FEATURES OF THE ZONELINE
Features
Auxiliary Control Features
The unit is factory preset to operate to what most
customers prefer. The auxiliary controls allow the owner
to modify how the unit operates and performs in their
particular installation.
The auxiliary controls allow customization of up to nine
different parameters to be modified to meet specific
needs.
Modes of the Auxiliary Control
Mode 1 – Not Applicable
Mode 2 – Not Applicable
Mode 3 – Freeze Sentinel/Heat Sentinel
Mode 4 – Constant ON Fan
Mode 5 – Not Applicable
Mode 6 – Not Applicable
Mode 7 – Fan Boost Mode
Mode 8 – Electric Heat Only (AZ95H only)
Mode 9 – Heat Boost (AZ95H only)
To learn more about the auxiliary controls and how to
set them go to the Auxiliary Controls Setting section of
this manual.
If the owner modifies the auxiliary controls, it is then the
owner’s responsibility for ensuring the auxiliary controls
are set to the desired function. To change operating
or set up parameters see the Setting the Auxiliary
Control section of this manual.
Additional Control Features
Central Desk Control (Field Supplied) – The central
desk control is a feature that allows the unit to be made
operable /inoperable from a remote location.
To learn more about field installed features and how
to connect the devices to the unit see the Auxiliary
Control Termination/Connection section of this manual
Auxiliary Control Panel
Located behind the front case panel.

849-5000561 Rev. 1
Air Filters
NOTICE: Do not operate the Zoneline without the
filter in place. If a filter becomes torn or damaged, it
should be replaced immediately.
Operating without the filter in place or with a damaged
filter will allow dirt and dust to reach the indoor coil and
reduce the cooling/heating, performance, airflow, and
efficiency of the unit.
The most important thing you can do to maintain the
Zoneline is to change the filter at least every 30 days.
Dirty filters reduce cooling, heating performance and air
flow.
Changing the filter will: Decrease cost of operation,
save energy, prevent clogged heat exchanger coils, and
reduce the risk of premature component failure.
Replacement filters should be purchased from your local
retailer where air conditioner and furnace accessories
are sold.
Filter size for front of unit is 18” x 20” x 1”.
Filter sizes for RAVRG4 is 24” x 20”.
Filter sizes for RAVRG2B is 20” x 20”.
NOTE: Use only one filter in the installation.
To replace the filter (unit mounted return air filter):
1. Slide the filter up to clear the filter holders.
2. Remove the filter.
3. Install new disposable filter.
To maintain optimum performance, change the filter
at least every 30 days.
CARE AND CLEANING
Care and Cleaning
Drain
Clean the drain system regularly to prevent clogging.
The condensate drain must be routed to a suitable drainage area. Check the unit condensate drain periodically. Keep
it free of anything that may block or impeded the flow of condensate water. If there is any accumulation of foreign
matter in the drainpipe, it should be removed and cleaned. The entire drain line must be protected from freezing.
Unit-mounted filter
Remove Filter
Access-panel with
return air grille
Return air grille
Filter
Filter
To remove
and replace
the filter:
Turn off the Zoneline and disconnect the power supply before cleaning.

49-5000561 Rev. 1 9
CARE AND CLEANINGE
Care and Cleaning
Indoor/Outdoor Coils
The Indoor/Outdoor coils on the Zoneline should be
cleaned and checked regularly.
NOTE: When cleaning the coils do not use
acid-based coil cleaners. Care must be taken to
avoid bending the aluminum fins on the coils.
Indoor-Air Coil
Minor amounts of lint and dirt may pass through the
filter and collect on the indoor-air coil. These minor
accumulations can be carefully vacuumed away
with a brush attachment on a vacuum cleaner or
professionally cleaned.
Outdoor-Air Coil
The unit’s outdoor-air intake and outdoor-air exhaust
paths must remain clear. Check the outdoor-air
exhaust frequently. Keep it free of all debris, snow, or
ice. The outdoor-air intake should also be kept free
of obstructions. Blocking the outdoor-air exhaust or
outdoor-air intake opening will reduce the efficiency of
your unit and could cause premature compressor failure.
Inspection and cleaning of the outdoor-air coils may
require the unit to be removed from the case and closet.
See servicing section of this manual for instructions
on how to remove the unit. Professional cleaning is
recommended for the inside surface of the outdoor coil.
Base Pan
In some installations, dirt or other debris may be blown
into the unit from the outside and settle in the base pan
(the bottom of the unit).
In some areas of the United States, a “gel-like”
substance may be present in the base pan.
Check it periodically and clean, if necessary.
Outdoor coils
Have the coils cleaned regularly.
Turn off the Zoneline and disconnect the power supply before cleaning.

10 49-5000561 Rev. 1
ZONELINE COMPONENTS
• Install the wall plenum through the exterior wall in accordance with the Installation Instructions provided with
the plenum.
IMPORTANT: The wall plenum is not designed to carry structural
loads. Proper wall header construction is required. The plenum requires
proper flashing, shim, and caulk for a weather resistant installation.
Installation Overview
INSTALLATION INSTRUCTIONS
Zoneline unit
Architectural
Louver
RAVAL3
Return Air Grille
RAVRG2B
Wall Thermostat
Proper header for
structural support.
Apply proper caulking
and flashing.
Exterior/Outside
Wall
Wall Plenum (telescoping)
RAVWP15 – 8”-15”D x 233⁄4”W x 313⁄4”H
Properly square
and level plenum.
Drain Platform
RAVDPLAT

49-5000561 Rev. 1 11
Installation Overview
RETURN AIR GRILLE INSTALLATION OPTIONS
The room return air grille may be installed toward the front or either side of the unit. Improper return air
arrangements will cause performance problems.
There are three indoor return air grille installation options. Choose the option that best suits your
installation requirements. Follow the Installation Instructions provided with the return air grille accessory for
installation details.
NOTE: Use only one filter in the installation. The filter may be installed on the unit or in the access panel/
door.
Unit-mounted filter with a field-supplied return
air grille and access door/panel
Option 3
RAVRG2B – Return air grille
Option 2
Filter
Filter
Outside wall
INSTALLATION INSTRUCTIONS
RAVRG4 – Access panel with
return air grille
Option 1
Filter

12 49-5000561 Rev. 1
ACCESSORIES for NEW Installation
Accessory and model number Appearance Cutout Dimensions
Plenum (telescoping)
RAVWPT15
´´'[ñ»๞´:[ñ»๞´+
*excluding flange
Cutout
Dimensions:
24”W x 32”H
Architectural Louver
RAVAL3 Architectural Louver designed to fit
the following Plenums:
RAVWP15
´´'[ñ»๞´:[ñ»๞´+
Access Panel with Return Air
Grille
RAVRG4 Cutout
Dimensions:
ï»๢´:[ເ»๢´+
Return Air Grille
RAVRG2B 22 1⁄2”
22 1⁄2”
Cutout
Dimensions:
ñ»๢´:[ñ»๢´+
Drain Platform
RAVDPLAT
Not Applicable
Wall Thermostat
Installation Overview
INSTALLATION INSTRUCTIONS
Model Type Wiring Thermostat Type Fan Speed(s) Kit Number
Electric Resistance Models 5-wire 5-wire 1 RAK149P2
Electric Resistance Models 6-wire 6-wire 2 RAK149F2
Heat Pump Models 6-wire 6-wire 1 RAK149P2
Heat Pump Models 7-wire 7-wire 2 RAK149F2
All Models * * 2 RAK180W1
*0 wires if powered by a battery, 2 wires if powered by the unit

49-5000561 Rev. 1 13
Installation Overview
INSTALLATION INSTRUCTIONS
UTILITY CLOSET CONNECTION LOCATIONS
IMPORTANT: Plan and locate plenum, drains and thermostat
cable carefully to avoid interference. Hard-to-reach locations will make
installation and service difficult!
Reference Dimensions
A.Thermostat cable
B. Electrical connections -
Direct connections using conduit
C. Case width: 23 ຿»๢´
D.Case depth: 24 ï»๢´
E.Case height: 30”
F. Condensate drains: ñ»๞´connector
• Primary Drain – The centerline is
approximately 11 3⁄4” from left case wall
and 11 3⁄4” from back case wall.
• Secondary Drain – The centerline is
6 1⁄8” from centerline of drain platform and
6 3⁄16” from back case wall.
Clearance Requirements:
•Front Installation–
– 3” minimum clearance from front of case
and 3” minimum from two sides.
• Side Installation–
–5” minimum clearance from front of
case, 3” minimum from access side and 3”
minimum from non-access side.
CD
E
F
B
A
Primary Drain
Secondary
Drain
Electrical
Disconnect
Conduit
for direct
connection
Outside
Wall
Use rigid duct for
90⁰ bends and tees
Flex duct may be used
for transitions only

14 49-5000561 Rev. 1
Installation Overview
INSTALLATION INSTRUCTIONS
TYPICAL UTILITY CLOSET AND DIMENSIONS
(For Reference Only)
FRONT INSTALL
Top View
Architectural Louver
3”
minimum
clearance
Thermostat
Connection
Unit
Front
3” minimum
clearance
3” minimum
Electrical
Connection
10”
Duct ï»๜´
7.16” ñ»๞´
minimum
຿»๢´PLQLPXP
Door/access panel return air grille
Note: It is recommended to leave
additional space around the unit to ease
installation and access for service.
Top View
SIDE INSTALL
Thermostat
Connection
຿»๢´PLQLPXP
Electrical
Connection
3” minimum
clearance
Architectural Louver
10”
Duct
ï»๜´
7.16”
3”
minimum
clearance
Unit
Front 5” minimum
clearance
Door/access
panel
ñ»๞´
minimum
A
B
RAVRG4
A - Minimum recommended access door width: 28”
B - Minimum recommended access door height: 57 ï»๜´
* Kits beginning with


Side View
• FRONT INSTALLATION
– 3" minimum clearance from
front of case and 3" minimum
from two sides
• SIDE INSTALLATION
– 5" minimum clearance from
front of case, 3" minimum from
access side and 3" minimum from
non-access side.
Option 1
Return air grille
RAVRG2*
(used with field supplied
closet door)
Option 2
Access panel with
return air grille
RAVRG4*
Inside wall Outside wall
Field supplied
flashing
Plenum
cutout
32" H x
24" W Exterior/Outside
Wall
Plenum
Unit
Filter Bracket
ï»๢
'UDLQILWWLQJVñ»๞
Secure
Drain
Platform
Air
discharge
outlet
Flexible or
rigid duct
Rigid
ductwork
30"

49-5000561 Rev. 1 15
Installation Preparation
INSTALLATION INSTRUCTIONS
TYPE OF ELECTRIC CONNECTIONS
A power supply kit must be used to supply power to
the Zoneline unit.
Models must be installed using the appropriate GE
Appliances power supply kit for the branch circuit
amperage and the electrical resistance heater
wattage desired. See the POWER CONNECTION
CHART to select the appropriate kit.
It is the responsibility of the installer to ensure the
connection of components is done in accordance with
electrical codes.
Power Supply Kit Direct Connect
208/230/265 Volt Applications
Power Supply Kit - Direct Connect
IMPORTANT: Connection to a branch circuit MUST
be done by direct connection in accordance with the
National Electrical Code. Plugging this unit into a
building mounted exposed receptacle is not permitted
by code.
POWER CONNECTION CHART
*See NEC for 265 Volts applications
Direct Connections
Power Supply Kits
230 / 208 Volts Configuration Direct Connection Heater Wattage @ 230 / 208 Volts Circuit Protective Device 9k/12k/18k
RAK315D Hard Wired 2.45 / 2.00 KW 15/15/NA-Amp Time Delay-Fuse or Breaker
RAK320D Hard Wired 3.45 / 2.82 KW 20-Amp Time Delay-Fuse or Breaker
RAK330D Hard Wired 5.00 / 4.09 KW 30-Amp Time Delay-Fuse or Breaker
Power Supply Kits
265 Volts* Configuration Direct Connection Heater Wattage @ 265 Volts Circuit Protective Device 9k/12k/18k
RAK515D Hard Wired 2.45 KW 15/15/NA-Amp Time Delay-Fuse or Breaker
RAK520D Hard Wired 3.45 KW 20-Amp Time Delay-Fuse or Breaker
RAK530D Hard Wired 5.00 KW 30-Amp Time Delay-Fuse or Breaker
External Disconnect
There shall be disconnecting means from the
electrical supply located within line of sight of the
closet door opening or access panel opening. The
disconnecting means shall be readily accessible
while the air conditioner is installed in the closet. The
disconnect shall not obscure the rating plate or be
located on the access panel or closet door. A properly
rated field supplied switch is a common means for
electrical disconnection.

16 49-5000561 Rev. 1
Installation Preparation
Ductwork
Prepare the closet ductwork for later connection
to the case.
The duct system should be designed for a maximum
friction rate of .30” water column taking into
consideration all fittings, registers and/or diffusers.
DO NOT operate unit without a supply duct
attached.
The return air to the Zoneline unit MUST NOT be
ducted, and all units MUST have a free return air
configuration to perform properly.
The total flow rate (CFM) and external static pressure
(ESP) available can be estimated from the charts on
this page. Use these charts to select your fan speed
setting.
The collar on top of the unit accepts standard 10”
duct. Pull all duct tight. Extra duct slack can greatly
increase static pressure.
NOTICE: Flex duct can collapse and cause
airflow restrictions. Do not use flex duct for 90°
bends or unsupported runs of 5 ft. or more.
Indoor Air Flow Data
Indoor air flow may be determined by measuring the
external static pressure (ESP) of the duct system and
then using the chart below to determine the actual
airflow. Under no circumstances should the Zoneline
unit be operated to an ESP in excess of .3” W.C..
Operation of the Zoneline under this condition will result
in inadequate air flow thus leading to poor performance
and/or premature component failure.
Your airflow should be balanced based on many
factors, such as available ESP, room CFM, and
ductwork. Consult an HVAC engineer for proper
applications. External static pressure (ESP) can be
measured with a manometer or pitot tube. Once this
ESP is established, you can calculate the CFM using
the above chart.
INSTALLATION INSTRUCTIONS
Indoor Air Flow Data (cont)
Higher CFMs tend to increase Sensible capacity,
enhance room circulation and increase duct noise,
while lower CFMs tend to increase Latent capacity
and reduce noise.
Indoor Fan CFM
Fan Boost Mode
ON OFF
ESP
(in. water) High
CFM
Medium
CFM
Medium
CFM
Low
CFM
0.1
0.15
0.2
0.25
0.3
468
435
409
392
352
408
371
351
306
239
408
371
351
306
239
305
272
198
*
*
0.1
0.15
0.2
0.25
0.3
468
435
409
392
352
408
371
351
306
239
408
371
351
306
239
356
328
288
220
*
0.1
0.15
0.2
0.25
0.3
468
435
409
392
352
417
380
359
318
253
417
380
359
318
253
376
345
314
250
*
AZ95E12
AZ95H12
* Do not operate unit in these conditions
AZ95(H/E)18
0.1
0.15
0.2
0.25
0.3
543
514
481
458
442
468
435
409
392
352
468
435
409
392
352
408
371
351
306
239
AZ95(H/E)09
NOTE: Values taken at 70-75°F ambient temperature
CFM Recommendations
AZ95(H/E)09 AZ95E12 AZ95H12 AZ95(H/E)18
305 408 468 356 408 468 376 417 468 408 468 543
•• • •
• = Recommended Mid Range

49-5000561 Rev. 1 17
INSTALLATION INSTRUCTIONS
Installation Preparation
IMPORTANT ELECTRICAL
SAFETY—READ
CAREFULLY
WARNING
RISK OF ELECTRIC SHOCK.
• All electrical connections and wiring MUST be
installed by a qualified electrician.
• Follow the National Electrical Code (NEC) and/or
local codes and ordinances.
• For personal safety, this Zoneline unit and case
must be properly grounded.
• Protective devices (fuses or circuit breakers)
acceptable for Zoneline installations are specified on
the nameplate of each unit.
• Do not use an extension cord with this unit.
• Aluminum building wiring may present special
problems—consult a qualified electrician.
• When the unit is not running there is still voltage to
the electrical controls.
• Disconnect the power to the unit before servicing by:
1. Removing the branch circuit fuses or turning the
circuit breakers off at the panel.
2. Disconnect the power cord from the unit.
BEFORE YOU BEGIN
Read these instructions completely and carefully.
•IMPORTANT –Save these
instructions for local inspector’s use.
•IMPORTANT –Observe all governing
codes and ordinances.
• Note to Installer – Be sure to leave these
instructions with the owner.
•
Note to Owner – Keep these instructions for
future reference.
• Proper installation is the responsibility of the
installer. Completed installation of the Zoneline
shall not be accessible to the general public.
• Product failure due to improper installation is not
covered under the Warranty.
• Team lift is recommended when moving unit.
• You MUST use all supplied parts and use proper
installation procedures as described in these
instructions when installing this air conditioner.
Questions? Call 844-GE4-PTAC (or 844-434-7822 ) or Visit our Website at: GEAppliances.com
ELECTRICAL
REQUIREMENTS
NOTE: All field wiring must comply with NEC and
local codes. It is the responsibility of the installer
to ensure that the electrical codes are met.
Wire Size Use ONLY wire size recommended
for single outlet branch circuit
Fuse/Circuit
Breaker
Use ONLY type and size fuse or
HVACR circuit breaker indicted
on units rating plate. Proper over
current protection to the units is the
responsibility of the owner.
Grounding Unit MUST be grounded from branch
circuit to unit, or through separate
ground wire provided on permanently
connected units. Be sure that branch
circuit is grounded.
Wire Sizing Use recommended wire size given
in tables and install a single branch
circuit. All wiring must comply with
local and national codes.
NOTE: Use copper conductors
only.
WARNING
RISK OF ELECTRIC SHOCK.
Can cause injury or death. This appliance must be
properly grounded.
• Use ONLY the wiring size recommended for single
outlet branch circuit.
• Proper current protection is the responsibility
of the owner.
NOTE: Use copper conductors only.
Recommended Branch Circuit Wire Sizes*
Nameplate
Maximum Circuit
Breaker Size
AWG Wire Size**
15A
(9k & 12k products only)
14
20A 12
30A 10
AWG - American Wire Gauge
* Single circuit breaker from main box
** Based on copper wire, single insulated conductor
at 60⁰C

18 49-5000561 Rev. 1
Installing the Zoneline
1. Plan for proper electrical supply, drains and ductwork
locations.
2. Install the wall plenum and louver.
3. Install and level the drain platform.
4. Complete condensate drain connections.
5. Install unit drain platform.
6. Level and secure drain platform.
7. Connect the top ductwork.
8. Connect the remote thermostat.
9. Connect auxiliary features, if required.
10. Make electrical connections to unit.
11. Install front panel with filter.
12. Install air return grille or access cover.
13. Review the final installation checklist.
14. Turn power on.
15. Program auxiliary control settings, if required.
16. Check operation of the unit.
INSTALLATION SUMMARY
1. Plan for proper electrical supply, drains and ductwork locations.
2. Install the Wall Plenum and Louver
1. Install the wall plenum.
Refer to instructions included in the wall plenum kit RAVWPT15 for proper installation procedures.
2. Install the louver.
Refer to instructions included in the louver kit RAVAL3 for proper installation procedures.
INSTALLATION INSTRUCTIONS
3. Install the Zoneline Drain Platform
1. Refer to instructions included with Drain Platform kit RAVDPLAT for proper installation procedure.
2. Place the platform in the utility closet with the following clearance between it and the interior surface of the
walls/door/panel:
• Front Installation–
– 3” minimum clearance from front of case and 3” minimum from two sides
• Side Installation–
– 5” minimum clearance from front of case, 3” minimum from access side and 3” minimum from two sides.
3. Complete rough in plumbing for primary and secondary condensation drains.
INSTALLATION INSTRUCTIONS
Condensate Disposal System
The Condensate Disposal System increases energy efficiency utilizing a factory installed fan that slings the
condensate onto the hot outdoor coil.
When high outdoor humidity prevents the slinger from disposing of all condensate, the excess condensate
overflows into the condensate drain pan and out the 3/4” internal drain connections.
NOTE: If the condensate disposal system fails to remove all of the condensate from the unit, any
excess condensate will overflow from the drain pan into the secondary drain (if connected), and drain
outside the building. This is your indication that the chassis or drain requires servicing.

49-5000561 Rev. 1 19
INSTALLATION INSTRUCTIONS
Installing the Zoneline
4. Complete Condensate Drain
Connections
An external or an internal drain must be attached to
the primary drain connector. A secondary drain is
supplied if required by state and local codes. Refer
to the local codes for proper installation of the drains.
If the secondary drain is not used, seal its drain port
with a 3/4” FNPT plug.
Drain Overview
Internal Drain (Primary)
Secondary Drain
If not used, seal with
Dñ»๞´)137 plug.
Primary Drain
Run condensate line to
building interior drain
line with proper venting
according to local
building codes.
Drain line connection
to right of platform
4. Complete Condensate Drain
Connections (cont)
External Drain (Secondary)
Refer to drain platform instruction
manual for drain installation
If necessary, extend
secondary drain line though
the plenum and grille.
Use a pipe connector and
additional piping to ensure
drain pipe extends past the
outdoor grille.
Extend secondary
drain pipe into plenum
or through outdoor
grille. Grille must be
modified to allow drain
line to pass through.
Primary
Drain
5. Install Unit to Plenum
Align the unit with plenum opening and slide unit
toward plenum to ensure it is seated properly with the
drain platform.
Unit
Wall
Plenum
Drain
Platform

20 49-5000561 Rev. 1
Installing the Zoneline
6. Level and Secure Drain Platform
1. When installing drain platform, ensure that it is level in all
directions.
INSTALLATION INSTRUCTIONS
7. Connect the Top Ductwork
1. Use a field supplied clamp to clamp the flexible 10” duct
to the rigid ductwork above the unit.
2. Install the other end of the duct onto the air discharge
outlet. Use a field supplied clamp to secure the duct to
the air discharge outlet.
8. Connect the Remote Thermostat
The unit will be controlled by a remote thermostat.
IMPORTANT: The Zoneline thermostat connections provide
24V AC only. If using a digital/electronic wall thermostat,
you must set it to the 24V AC setting. See the Installation
Instructions for the wall thermostat. NOTICE: Damage
to a wall thermostat or to the Zoneline electronics can
result from improper connections. Exercise extra attention
when connecting blue and black wires. No line voltage
connections should be made to any circuit in the thermostat.
Isolate all wires in building from line voltage.
1. Thermostat electrical connector is included with the unit.
Follow the instructions included with the thermostat to
connect the thermostat to the unit.
2. Plug the thermostat connector into the control board.
Inside Wall Rigid
Ductwork
Flexible or
Rigid Ductwork
Air
Discharge
Outlet
10”
Inside Wall Rigid
Ductwork
Flexible or
Rigid Ductwork
Air
Discharge
Outlet
10”
Maximum Wiring
Length for Thermostat
Connection to the Unit
66 ft. for AWG 18
60 ft. for AWG 20
40 ft. for AWG 24
AWG – American Wire Gauge
Use only Class 2 wiring
Thermostat
Thermostat Connector
7
C
W
Y
GH
GL
R
yellow
black white
blue
green
tan red
654321
B
