Before connecting or operating the Wireless Keypad,
please read these instructions carefully and save this
manual for future reference.
Congratulations
The GE Choice Alert™ Wireless Alarm System is one of
the most affordable and expandable wireless alarm
systems available. You’ll discover that the system offers
many features typically found in custom installed
Alarm systems. The Choice Alert system is reliable and
easy-to-use. With Choice Alert you can select from a
line of Sensors, Accessories and Remote Transmitters;
start small and expand as you need, or create a system
that meets all your needs.
The Choice Alert System is protected by Priority
Code Selection technology which provides increased
security and trouble-free wireless connections. It also
guarantees the Control Center will only respond to
signals from your Sensors in and around your
home, and prevents anyone from tampering with
your system.
This user manual explains in simple steps how to
install, use and care for your new Choice Alert Wireless
Keypad.
If you have any questions or would like additional
information please visit our web site
www.jascoproducts.com, or contact our Tech Support
at 1-800-654-8483.

4
5
Important safeguards
PreCautions
1. Do not attempt to disassemble the Wireless Keypad,
unless described in the user’s manual. There are no
user serviceable parts.
2. Handle with Care – Avoid striking or shaking.
Improper use or storage could damage the Wireless
Keypad. Modifying or tampering the device or its
internal components can cause a malfunction
and void the Wireless Keypad’s warranty.
3. If you feel the Wireless Keypad or any part of the
Choice Alert system is not operating correctly or
as described, please contact Technical Support for
assistance (1-800-654-8483).

4
5
Introduction
The Wireless Keypad allows you to wirelessly control
your Choice Alert System. With this keypad, you will
be able to arm, disarm and immediately activate the
alarm with up to three personalized security codes.
Parts Check List
Identify all the parts before proceeding.
2- double sided adhesive tape
Wireless Keypad
2 - Screws
2 - Plastic anchors
1 2
3 4

6
7
1 2 3 4 Arm
Zone
Armed Power
1 2 3 4
Alert
Chime
Off
Mute
Learn
InputDC12V
-+
Step 1
Press and hold
the Learn button
for three seconds
Step 3
To activate the keypad
press the panic button
on the unit.
Step 2
Press and release the
Device number
Activating the Battery
The Wireless Keypad is packaged with the battery
installed, but not activated. To activate the battery,
remove the yellow battery isolation strip on the side
edge; pull to remove. Once the strip is removed, the
Wireless Keypad will be active.
Assigning a Wireless Keypad to a Device Location
The Control Center is designed to store up to four
remote transmitters, such as the Wireless Keypad. In
order to ensure that the Wireless Keypad will operate
only with your Control Center, it must be assigned to
one of the four device locations on the Control Center.
Step 1. Press and hold the Learn button on the Control
Center. You will hear a short beep, followed shortly by a
long continuous beep. Release the Learn button.
Step 2. On the Control Center, press and release one of
the device numbers (1,2,3 or 4) that you want to assign
the Wireless Keypad. The LED for that device number
will begin to flash.

6
7
Step 3. Press the red Panic button on the wireless
keypad. The Control Center will sound a long beep and
the LED will stop flashing. This confirms the Wireless
Keypad has been assigned to the selected device
number.
Programming Security Codes into the Wireless Keypad
The Wireless Keypad operates independently from
the Control Center. The Wireless Keypad can store
up to three different security user codes into its
memory – the Master Code and two alternate User
codes. The Master Code (1) has been set to 1-2-3-4. It
is recommended to change the Master Code to a new
personal 4-digit number. The Master Code is also used
to set/change either of the alternate User codes, so it
is important to remember the Master code. Alternate
User codes can be set to provide access for different
individuals outside of the immediate occupants,
such as a ‘vacation’ code used to temporarily allow
someone access to the house while you are away.
Changing the Master code or alternate User code
Step 1. Press and release the Green button (disarm
button). Enter Current Master code. Press and release
the Green button. The LED will remain on during the
programming progress.
NOTE: After placing the wireless keypad into the
programming mode, you have approx 30 seconds to
enter a selection at each step or the LED will flash 3
times and turn off. If it does, it means you timed out of
the programming mode and must start over.

8
9
Step 2. Enter a number (1, 2, or 3) for the User code
you would like to change (1=Master code, 2= User 2
code, 3 = User 3 code).
Step 3. Press and release the Green button.
Step 4. Enter the new 4-digit code. Press and release
the Green button.
Step 5. Re-enter new 4-digit code again. Press and
release the Green button.
The LED will flash 5 times and turn off indicating the
code for that User code has been stored/changed.
Example: To set User 2 code to 2222
Press and release the Green button
(The LED will turn on)
Enter 1,2,3,4 (Wireless keypad is now in Program Mode)
Press and release the green button
Enter 2
Press and release the green button
Enter 2,2,2,2
Press and release the green button
Re-enter 2,2,2,2
Press and release the green button (red LED will flash 5
times and turn off)
In this example, User 2 code has been set as 2222.
Erasing Alternate User Codes
Alternate user codes can be removed completely from
the memory if necessary. Note: the Master Code (1)
cannot be erased, only changed.

8
9
Step 1. Press and release Green button. Enter Current
Master code. Press and release the Green button. The
LED will light.
Note: You have approx 30 seconds to make a selection
at each step, or the LED will flash 3 times and turn off.
If it does, you’ll have to start over.
Step 2. Enter a number (2, or 3) for the code you
would like to erase (2= User 2 code, 3 = User 3 code).
Press and release the Green button three times.
The LED will flash 5 times and turn off indicating the
code for that number has been erased.
Placement of the Wireless Keypad.
The Wireless Keypad is designed to be mounted inside
onto a wall, or it can lay on a flat surface (such as a
night stand). If mounting to a wall, use the double-
sided tape strips or the screws/wall anchors (both
included).
Note (1): Do not mount in an exterior location; the
Wireless Keypad is not weather resistant.
Note (2): The Wireless Keypad can transmit up to
150ft. However like all wireless devices, this distance
is subject to conditions of the home. The number of
walls and appliances between the Wireless Keypad
and the location of the Control Center can reduce
the signal transmission distance. When selecting a
placement, test the Wireless Keypad at the location
before mounting. Using a signal repeater can extend
the transmission distance.

10
11
Mounting the Wireless Keypad onto a Wall (using
double sided tape strips)
Select a suitable location that provides protected, easy
access. Be sure to test the device before mounting.
Clean both surfaces with 50/50 mix of isopropyl
alcohol and water. Using the provided double sided
tape strips, peel one side and firmly apply to the
indented areas on the back of the mounting plate.
Peel the remaining side of the double sided tape and
lightly mount to the wall. Once you are confident with
the placement, press firmly to secure to the wall.
Mounting the Wireless Keypad onto a Wall (using
screws/wall anchors) – you will need a drill, 3/16” or
1/8” drill bit and screwdriver.
Step 1. Remove the top cover from the mounting
plate. (See Removing the Top Cover from the
Mounting Plate.) Set the top cover aside.
Step 2. Select a suitable location that provides
protected, easy access. Be sure to test the device
before mounting. Use the mounting plate as a
template. Be sure to position the mounting plate with
the arrow pointing up. Mark the two holes on the wall
for the anchors and/or screws as shown. Please be
sure to mark the center of the holes.

10
11
Step 3. (a) If mounting into drywall, use the plastic
anchors. Using a 3/16” drill bit, drill holes and insert
anchors for a snug fit. Align mounting plate holes to
anchor holes, insert screws and screw in until plate
has secure fit. Do not over-tighten screws.
Step 3. (b) If mounting into a stud or wood surface, use
a 1/8” drill bit, drill holes. Align mounting plate holes to
drilled holes, insert screws and screw in until plate has
secure fit. Do not over-tighten screws.
Removing the Top cover from
the Mounting Plate
To remove the top cover, locate the snap
latch at the bottom of the plate. Using a
paperclip or small blade-type screwdriver,
gently push in on the latch. The top cover will
separate from the mounting plate and can
be lifted off
Attaching the Top Cover to the Mounting
Plate
To secure top cover onto mounting plate, position
top cover over mounting plate and gently apply
equal pressure to top cover. It will snap securely in
place onto the mounting plate. Check all sides to
ensure secure fit.
Operating the Wireless Keypad
Arming the Alarm in Away mode
Enter a 4-digit user code (See Programming Security
Codes into the Wireless Keypad) and press the Away
Disarm Button
Away Button
Panic Button
Home Button
1 2
3 4

12
13
button. If the Control Center is in range, the Armed
light will begin flashing on the Control Center and
the Control Center will begin beeping for 45 seconds
indicating the alarm has been set.
Arming the Alarm in Home mode
Enter a 4-digit user code (See Programming Security
Codes into the Wireless Keypad) and press the Home
button. If the Control Center is in range, the Armed light
on the Control Center will light indicating the alarm has
been set.
Disarming the Alarm*
Enter a 4-digit user code (See Programming Security
Codes into the Wireless Keypad) and press the
Disarm button. If the Control Center is in range, the
Armed light on the control center will turn off, or if the
alarm is sounding, it will stop.
Using the Panic Button*
Pressing the red Panic Button at any time will cause
the siren to sound instantly. It is not necessary to enter
a 4-digit user code to activate the Panic button.
To stop the siren from sounding, you must disarm
the system (see Disarming the Alarm).
*Note: The Wireless Keypad will transmit up to 150ft
from the Control Center. When pressing the Panic
or Disarm buttons, there will be up to 3 seconds
delay before the Control Center can receive another
command. The Control Center must complete
transmitting activation signals (3 seconds) before it
can receive a new command.

12
13
Replacing a Wireless Keypad
If a Wireless Keypad is lost or broken, you can replace
it (with another Wireless Keypad or any remote access
device). Simply assign the new Wireless Keypad to the
same device number in the Control Center location.
Erasing a Wireless Keypad from a Control Center
CAUTION: Erasing a Wireless Keypad from the Control
Center will also erase any sensors in the associated
zone. Sensors will have to be added back to the zone
(refer to sensor manual or Control Center manual for
specific instructions).
To remove a Wireless Keypad (or any remote
transmitters) from a device number location on the
Control Center, press and hold the ‘Learn’ button and
the device number at the same time on the Control
Center until the Control Center sounds two beeps.
Release the buttons.
NOTE: Some early production Control Center products
were designed to allow replacement only. In this
situation you will only be able to replace the remote
transmitter with another.
Low Battery Indication
The Wireless Keypad has a low battery notification
circuit. When the battery reaches a low level, the LED
on the Wireless Keypad will begin to flash slowly. It will
continue to flash until battery is replaced or becomes
exhausted.
Replacing the Battery
Note: The Choice Alert system is ‘range dependent’,
which means a Wireless Keypad located closer to the

14
15
Control Center may seem to have batteries that last
longer than a Wireless Keypad located farther away.
As battery power reduces, the transmission distance
reduces.
Step 1. Remove the top cover (see Removing the Top
cover from the Mounting Plate). Slide the battery
out from the battery slot. You may need to use small
screwdriver or paper clip to push battery from the
back.
Step 2. Replace the old battery with a new “2032” (3v)
battery. Be sure to battery polarity matches.
Step 3. Replace top cover.
Resetting Master Code
To reset the master code to factory default if the
master code is forgotten or lost, you can reset back to
factory default (1,2,3,4).
Align with the mounted
part of the wallplate
and push on
3V Battery
Description Battery Type Battery Life*
Control Center (4) “AAA” 24 months
Wireless Keypad (1) “2032” 24 months
*maximum potential life based upon usage and location

14
15
Step 1. Remove battery.
Step 2. Press and hold both the panic (RED) button
and the Disarm (GREEN) button at the same time.
Step 3. While pressing both the buttons, reinsert the
battery. The LED will flash rapidly for a short time and
willl then flash slowly. Release the buttons.
It will take approximately four hours for the reset to
complete.
WARNING!
Risk of personal injury
- Prolonged exposure to alarm
siren may cause permanent
hearing loss
Battery Warnings!
- Remove batteries before storing
the Alarm or Sensor for extended periods
- Batteries may leak harmful liquids or
ignitable materials or explode causing injury
and product damage
- Do not mix old and new or other battery types
- Replace all batteries at the same time
- Replace fully discharged batteries immediately

16
17
Wireless Keypad Remote F.A.Q.’S
Q. I bought a Wireless Keypad and the Control Center will not
recognize it. Why?
A. First, make sure that the battery is new and has been
correctly installed, paying attention to polarity symbols
(“+”, “-”). Confirm that the Wireless Keypad has been
correctly assigned to a Device.
Q. If I assign the Wireless Keypad to Zone 4, will it still arm
and disarm the alarm system?
A. Yes. When assigning the Wireless Keypad (or other remote
transmitters), it is being assigned to a device number, not
a zone. You can assign up to 4 different remote access
devices; only one keypad can be assigned to a device
number.
Q. I’ve tried several times to erase a wireless keypad from
the device number memory but it still remains - What can
I do?
A. If you are unable to completely erase a keypad from
the device number memory, you may have an early
production Control Center. Early production versions only
allowed for replacement. Contact Tech Support at
800-654-8483 for any questions.

16
17
FCC Warning
Any unauthorized changes or modifications to the equipment
would void the user’s warranty and may conflict with both
state and federal laws. The Choice Alert system complies with
part 15 of the FCC rules. Operation is subject to the following
conditions:
1) The Choice Alert system may not cause
harmful interference.
2) The Choice Alert system may accept any interference
received including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment
and receiver.
– Connect the equipment into an outlet on a circuit
different from that to which the receiver
is connected.
– Consult the dealer or an
experienced radio/TV technician for help

18
WARNING
Limitations of Alarm Products
This product should be tested periodically to make sure
it is working properly. The product, if used properly, may
reduce the risk of burglary, robbery, or other adverse events.
However, JASCO is not an insurer, this product is neither
insurance nor a guarantee that such an event will be
prevented, and users should protect themselves with proper
insurance. JASCO makes no representation that this product
cannot be compromised or circumvented, that it will provide
an adequate warning, or that it will prevent any personal
injuries, property damage, or other losses. Like any alarm
product, including expensive commercial systems, it may be
bypassed, it is subject to compromise, and it may fail to warn
for a variety of reasons, including, but not limited to: improper
installation or positioning; improper maintenance; tampering;
dead or improperly installed batteries; sensing limitations;
component failures; receivers; intrusions may be outside
of a product’s designed range and certain environmental
conditions may impact performance and audible alarm
signals may be outside of hearing range, muted by doors,
walls, and floors, unheard by deep sleepers or the hearing-
impaired, or overwhelmed by other sounds.

18
is a trademark of the General
Electric Company and is used under
license to Jasco Products Company
LLC, 10 E. Memorial Road,
Oklahoma City, OK 73114.
This Jasco product comes with a
1 year limited warranty. Visit
www.jascoproducts.com for details. 45145-1 9/30/09
