NetworX™Series
NX-148E-CF Commercial Fire
LCD Keypad
User manual

UP & DOWN
SCROLL KEYS
POWER
light is “on”
when AC power is
present, flashes to indicate a low battery condition.
5 FUNCTION
KEYS
The door (not shown)
is detachable and can
be removed or replaced when desired.
FIRE light is “on” to indicate fire alarm, flashes to indicate a trouble condition with your fire system. READY light is “on”
when the system is
ready to arm, flashes if ready to “force arm”. ARMED light is “on”
when armed, “off”
when disarmed,
flashes to indicate a
previous alarm.
NUMERIC CODE ENTRY KEYS PROGRAMMABLE EMERGENCY ACTIVATION KEYS
The appropriate stickers should be applied on the keypad door for the Emergency
Activation keys that are programmed to work with your system.
COMMERCIAL FIRE SYSTEM LCD KEYPAD
Model NX-148E-
CF

NX-148E-CF 1
Installing/Service Company
For Service Call
Central Station
This system is is not partitioned.
EMERGENCY ACTIVATION KEYS
(check if enabled)
Fire Auxiliary Emergency Police
PROGRAMMED FUNCTIONS
Abort Delay (s) Group Bypass (s)
Battery Test Quick Arm (s)
Cancel Alarm Re Exit
Chime Siren Test
Forced Arming (s)
(s)These features should not be enabled on UL listed systems.
NOTE: Some of the features described above may or may not be available for
your system. Check with your installation company to find out how your
system is programmed.
To Arm or Disarm or Silence Alarm: Enter your user code.
To Quick Arm and Stay: Press “Stay” key.
To Quick Arm and Exit: Press “Exit” key.
Door Chime: Press “Chime” key to activate.
Reset Smoke Detector and Panel Reset: Press 7

NX-148E-CF 3
TABLE OF CONTENTS
GLOSSARY OF TERMS...........................................................................4
UNDERSTANDING THE LIGHTS.............................................................6
KEYPAD FUNCTIONS..............................................................................7
Arming Your System In The “Away” Mode...........................................7
Making Your System Ready To Arm....................................................7
Arming Your System In The “Stay” Mode ............................................8
Using The Quick Arm...........................................................................9
Disarming Your System .......................................................................9
Cancel / Abort Feature.......................................................................10
Bypassing Zones................................................................................10
Group Bypass ....................................................................................11
Unbypassing ......................................................................................11
Emergency Activation Keys ...............................................................11
Function Menu ...................................................................................12
View Zone Status...............................................................................13
Setting The Keypad Tone ..................................................................13
View Alarm Memory...........................................................................13
Test Function .....................................................................................13
Display Test Function.........................................................................14
Light Control For X-10 Devices..........................................................14
Change Languages............................................................................14
Changing User Codes........................................................................15
Assigning User Code Authority Levels...............................................15
Reset Function...................................................................................16
Reading The Event Log .....................................................................17
Adjusting The View / Brightness Of The LCD....................................17
Setting The System Clock..................................................................18
Using The Door Chime Feature.........................................................18
PARTITIONED SYSTEMS OPERATION................................................19
Lights In Partitioning Master Mode.....................................................19
Displays In The Partitioning Master Mode .........................................19
KEYPAD CONTROL TONES (BEEPS) ..................................................22
SERVICE DISPLAY................................................................................23
APPENDIX A - EVENT LOG...................................................................25
EMERGENCY EVACUATION PLANS....................................................27

NX-148E-CF
4
THIS MANUAL IS FURNISHED TO HELP YOU UNDERSTAND YOUR SECURITY
SYSTEM AND BECOME PROFICIENT IN ITS OPERATION. ALL USERS OF YOUR
SECURITY SYSTEM SHOULD READ AND FOLLOW THE INSTRUCTIONS AND
PRECAUTIONS IN THIS BOOKLET. FAILURE TO DO SO COULD RESULT IN THE
SECURITY SYSTEM NOT WORKING PROPERLY. THIS BOOKLET SHOULD BE KEPT
IN AN ACCESSIBLE LOCATION FOR THE LIFE OF THE SECURITY SYSTEM. IF YOU
DO NOT UNDERSTAND ANY PART OF THIS MANUAL, YOU SHOULD NOTIFY YOUR
INSTALLING COMPANY. READ THE ENTIRE MANUAL AND, IF POSSIBLE, PRACTICE
ON THE KEYPAD CONTROL WHILE YOUR PROFESSIONAL INSTALLER IS ON SITE.
The SECURITY CONTROL can be turnedon(ARMED)andoff (DISARMED) byentering a 4
or 6 digit code into the Keypad Control, which is similar to a telephone keypad. If your
Security Control has been so programmed, you may be able to turn on (ARM) your System
by simplypressing the [STAY] or [EXIT] key. The system must always be Disarmed using a4
or 6 digit code. The LCD keypad includes 9 lights and a 32-character liquid crystal display
and a built-in electronic sounder. These provide specific information relating to the status of
the security system which is described in the booklet. Understanding what the lights and
sounds mean will help you to easily operate your system.
KEEP IN MIND, THE LEVEL OF SECURITY YOU WILL OBTAIN WITH THIS SYSTEM
RELATES SPECIFICALLY WITH TWO MAJOR FACTORS:
1. The quantity, quality, and placement of security devices attached to this system.
2. The knowledge you have of the security system and how that knowledge is utilized
in a weekly test of the complete system.
YOU SHOULD BE AWARE OF THE FOLLOWING FACTS WHEN PREPARING A
SAFETY/SECURITY PLAN FOR YOUR HOME/BUSINESS.
1. Your security system is an electronic device and is subject to failureormalfunction.
Do not rely on it as your single source of security.
2. Your system should be tested weekly.
3. Your system will not work without power.
4. Warning devices will need to be loud enough, wired correctly, and properlyplaced
to provide notification of an alarm event.
5. Smoke and heat detectors may not detect heat and smoke in all situations.
6. Use qualified security professionals to install and maintain your security system.
7. It may be possible to arm the securitysystem without thebackup batteryconnected.
Your periodic test should be done with A.C. Power removed to verifythe battery is
connected and adequately charged.
8. Care should be taken to plug in and restrain the A.C. Transformer after testing.
PLEASE READ THE FOLLOWING INFORMATION AND INSTRUCTIONS CAREFULLY
BEFORE OPERATING YOUR SECURITY CONTROL SYSTEM. IF YOU DO NOT
UNDERSTAND ANY PORTION OF THIS MANUAL, OR IF YOU HAVE ANY QUESTIONS
ABOUT YOUR SYSTEM, CONTACT THE INSTALLING COMPANY.

NX148E-CF 5
GLOSSARY OF TERMS
Abort Delay: An option that allows a delay in reporting to the central
station.
Authority Level: The level of access an individual has when using an alarm
panel.
Central Station: Location where alarm data is sent during an alarm report.
Chime Feature: An option that allows the keypad to sound a ding-dong
whenever an entry/exit door is opened.
Codes: Can be either User Codes (relating to a person) or
Function Codes (a toggle switch to turn specific functions
on/off). NOTE: A system may have either 4-digitcodes
or 6-digit codes, but not a mixture of the two.
Duress Code: An option that allows a special code to be sent to the
central station that indicates the alarm system is being
operated under duress.
Forced Arming: An option that allows the system to be turned on (ARMED)
with one or more zones open. A system that is ready to be
“force armed” will flash the ready light. NOTE: Those
zones that are not ready will not create an alarm.
Function Code: AFunctionCode is either a four(4)or six (6) digit codethat
has been programmed by the installer to operate a device.
Group Bypass: An option that allows the user to bypass multiple zones
with a single operation.
Instant/Delay: An option that allows an instant alarm condition for
Entry/Exit doors, or grants a delay to allow someone to
enter/exit the building without an alarm orbefore entering a
user code to disarm.
Master Code: A master arm/disarm code that can program other user
codes.
Partitioned System: A system divided into multiple areas in which its own user
or users control each area.
Perimeter: The outer edge of the protected area.
Quick Arm: An option that allows you to turn on (ARM) the security
system by pressing either the [STAY] or [EXIT] key on the
keypad control (for ARMING only) as programmed by the
installing company.
User Code: A 4- or 6-digit entry used to arm or disarm the system.

NX-148E-CF
6
UNDERSTANDING THE LIGHTS
Armed Light The armed light is “on” when the system is armed. The armed
light is “off” when it is disarmed. The armed light will flash
whentherehas been an alarm duringthe previousarmcycle.
Bypass Light The bypass light is “on” when any zone in this keypad’s
partition is bypassed. If the bypass light is “off”, no zones are
bypassed.
Cancel Light The cancel light will flash during an abort delay time. Entering
a code followed by the [CANCEL] key during or after an
alarm report to the central station will cause the cancel light
to come on. It will stay on until the central station has
receivedthecancel report. NOTE: The cancel feature must
be enabled. (See "Cancel/Abort Feature" on page 10.)
Chime Light The chime light is “on” when the chime feature is “on”; “off”
otherwise.
Exit Light The exit light is “on” during the exit delay. Please note that the
lightwillflash during the last10seconds of theexitdelayasa
warning that the time is running out. (The user may want to
disarm the system if the exit light is flashing in order to
prevent an alarm. The user may then re-arm the system and
exit before the delay expires.)
Fire Light A steady fire light means a fire zone has been faulted. A
rapidly flashing fire light means that a fire zone is in a trouble
condition.
Power Light The power light is on if the primary power is on. The power
light will flash if the system has a low battery condition.
Ready Light The ready light is “on” when the system is ready to arm and
“flashes” if ready to force arm. The ready light is “off” when
the system is not ready to arm because of a zone(s) being
faulted.
Stay Light The stay light is illuminated when all interior zones are
bypassed.
Instant Message The LCD display will read “Instant“ when theentry/exit door(s)
havenodelay. (See “Arming System inStayMode”, page 8.)
The doors can be changed from instant to delay (toggled) by
pressing the [STAY] key when the system is armed.

NX148E-CF 7
KEYPAD FUNCTIONS
ARMING YOUR SYSTEM IN THE “AWAY” MODE
AWAY is utilized when the user is going away from the premise and wants the
interior protected. Listed below are the steps to arm in the AWAY Mode:
Step 1 Close all protected doors and windows.
 Ready light will be on or
flashing when all protected
zones and sensors are
secure. NOTE: If any zones
are bypassed, a sensor in
that zone can be violated without affecting the ready light.
 The security system will not
arm if the ready light is off.
Refer to "Making Your
System Ready to Arm".
 If the power light is off, you have no AC power. Restore power if
possible. If not, contact the installing company.
Step 2 Enter your 4 or 6 digit user code to arm the system.
 The armed and exit lights will illuminate.
 You may now leave the building.
IMPORTANT!
The exit light will flash rapidly for the last 10 seconds of the exit delay as a
warning to the user that the exit time is about to expire. The user may wish
to disarm and rearm the system if more time is needed.
MAKING YOUR SYSTEM READY TO ARM
If the ready light is not on or if it is flashing, a zone is not secure. To identify this
zone, use the scroll keys •–to the right of the display to browse through the
zones that are not normal. If you wish to bypass or unbypass one of these zones,
press the [BYPASS] key while that zone is being displayed. When finished
viewing the zones, press the #key to return to the code entry screen.
System Ready
Type Code to Arm
System Not Ready
For help, press º
System Armed
All Zones Secure

NX-148E-CF
8
ARMING YOUR SYSTEM IN THE “STAY” MODE
STAY is utilized when the user is inside the premise and wants protectionaround
the perimeter. The steps to arm in the STAY Mode are as follows:
Step 1 Close all protected doors and windows.
 Ready light must be on or flashing (force armed) when all protected
zones and sensors are secure. NOTE: If any zones are bypassed,
a sensor in that zone can be violated without affecting the ready
light.
 Thesecuritysystem will not armifthe ready light isnoton or flashing.
 If the power light is off, you have no AC power. Restore power if
possible. If not, contact the installing company for service.
Step 2 Enter your 4 or 6 digit user code. (Optional, if programmed.)
 If “Auto Bypass” is enabled, all interior zones will be bypassed if you
do not leave through a designated entry/exit door. If Auto Bypass is
enabled, omit Step 3.
 When “Auto Instant” is enabled, if you do not leave through a
designated entry/exit door, the display will read “Instant”, indicating
that the entry/exit doors no longer have an entry delay. If “Auto
Instant” is enabled, omit Step 4.
Step 3 Press the [STAY] key.
 The stay light will illuminate indicating that all interior zones are
bypassed. (All interior devices will bypass automatically, giving the
user freedom of movement within the interior area.)
 The bypass light will illuminate if any zone(s) are bypassed. If any
zone (s) have been bypassed previously by the user, the light(s)
corresponding to the bypassed zone(s) will illuminate, alerting the
userthata zone(s) may be unprotectedandcan befaultedwithoutan
alarm.
Step 4 To toggle from a “delayed entry” mode to an “Instant” mode, press the
[STAY] key again.
 The LCD display will read
“Instant” meaning the entry/exit
doors do NOT have an entry
delay.
System Ready
Type code to arm
System Armed
Instant

NX148E-CF 9
USING THE QUICK ARM
The Quick Arm feature may be used if it is enabled. Quick Arm will allow the user
to arm the security system in the AWAY mode by pressing the [EXIT] key. The
system can be quick armed in the STAY mode by pressing the [STAY] key. This
feature is used for ARMING ONLY, and willnot disarm thesecurity system. This is
ideal for a maid or baby sitter code, etc.
CHANGING MODES WHILE YOUR SYSTEM IS ARMED
Step 1 Pressing the [STAY] key will turn on/off (toggle) a delay on Entry/Exit
doors. The “Instant” message will toggle on the LCD display.
Step 2 (Optional, if programmed.) Press the [BYPASS] key at this time to turn
on/off (toggle) all designated interior zones. If all interior zones are not
bypassed, the stay light will extinguish.
Step 3 (Optional, if programmed.) When armed, pressing the [EXIT] key will
start the Exit delay, enabling you to leave the building.
IMPORTANT!
An alarm will be created if the “Instant” message is ON at this time and you re-
enter the building. You may re-initiate an entry/exit delay by pressing the [STAY]
key again. The “Instant” message will disappear.
DISARMING YOUR SYSTEM
Whenyouenter theprotectedarea throughoneof thedesignatedEntry/Exitdoors,
the keypad control will sound a continuous tone for the duration of the entrydelay
time, or until you enter a valid code.
Step 1 Enter a valid user code.
Step 2 The red armed light will go off and
the tone will stop. The security
system is now DISARMED. If a valid code is not entered before the end
of the entry delay, an alarm will occur. NOTE: If the red armed light is
flashing during the entry delay, the alarm system has been activated
in your absence. Leave the building immediately and call your alarm
company and/or the police from a safe location.
Type code to
Disarm

NX-148E-CF
10
CANCEL / ABORT FEATURE (Optional, if programmed)
The cancel light will flash during an abort delay time. If a code is entered followed
by the [CANCEL] key while this light is flashing, all abortable reports will stop the
communication process. NOTE: The abort feature must be enabled. Entering a
code followed by the [CANCEL] key during or after an alarm report to the central
station will cause the cancel light to come on. It will stay on until the central station
has received the cancel report. NOTE: The cancel feature must be enabled.
BYPASSING ZONES
If you wish to bypass one or more zones, this must be done while the system is in
the disarmed state. If the zone is not known, refer to Procedure #2.
If you know the number of the zone to bypass, use the
following:
Step 1 Press the [BYPASS] key.
Step 2 WhentheLCD prompts for a code(optional,if programmed),enteryour
user code.
Step 3 The bypass light flashes.
Step 4 Enter the zone you wish to bypass. (Example: Press 6 for zone 6 or
1 1 2 for zone 112.)
Step 5 Press the [BYPASS] key again. The zone is now bypassed.
Step 6 Repeat steps 4 and 5 for any other zone(s) that need to be bypassed.
Step 7 Press the [BYPASS] key again OR press #to exit the Bypass Mode.
The bypass light will stop flashing upon exiting the Bypass Mode.
Pressing the •–scroll keys will display all bypassed zones. Press
the # key to exit this viewing mode.
Proc
edure #1

NX148E-CF 11
If you do not know the number of the zone you wish to bypass,
use the following steps:
Step 1 Press r•The description for zone 1 will be displayed.
Step 2 Use the •–scroll keys to browse through the custom descriptions
for the zones in this system.
Step 3 To bypass or unbypass a specific zone, press the [BYPASS] key while
that zone is displayed.
Step 4 When finished, press the # key to return to the code entry screen.
GROUP BYPASS
By pressing the [BYPASS] key, followed by the 0key, then the [BYPASS] key
again, all zones that are designated as group bypass zones will be bypassed.
Press the [BYPASS] key again to exit group bypassing.
UNBYPASSING
To manually unbypass zones, perform the bypassing procedure on a zone thatis
already bypassed. NOTE: All zones will automatically be unbypassed each time
the system is disarmed.
EMERGENCY ACTIVATION KEYS
NOTE: You must press and hold these keys for 2 seconds to activate these
functions. Your system may not be programmed for these activations.
Fire Key - If programmed, you can activate the Fire alarm by pressing the
Emergency Activation [Fire] key for two seconds. If your system is connected to a
monitoring center, an emergency report could be sent to that center. This key
should only be pressed in an emergency situation requiring response by fire
department personnel.
Procedure #2

NX-148E-CF
12
Select an Option
Press for Help
Auxiliary Key - If programmed, you can activate the auxiliary alarm by pressing
the Emergency Activation [Auxiliary] key for two seconds. If your system is
connected to a monitoring center, an emergency report could be sent to that
center. This key should only be pressed in an emergency situation requiring
response by emergency personnel.
Police (Panic/Hold-Up) Key - If programmed, when the Emergency Activation
[Police] key is pressed for two seconds, a local audible alarm will sound. If your
system is connected to a monitoring center, an emergency report could be
transmitted to that center. These keys should only be pressed in an emergency
situation requiring immediate response by law enforcement personnel. NOTE:
Some Panic/Hold-Up alarms are programmed to be silent at the protected site
while reporting an alarm to the monitoring center. Check with your installing
companytodeterminehowyoursecurity system willrespond tothePanic/Hold-Up
activation.
FUNCTION MENU
The functions listed below are found in the Function Menu.
Step 1 Press rThe display will now begin scrolling though a list of functions
and the corresponding numbers associated with those functions.
Step 2 Press the number listed on the display in order to access that particular
function. Hint: If you already knowthe function numbers simply press [r]followed
by the function number.
The following list of menu selections will scroll automatically. NOTE: Some of the
functions are not listed because they are installer level functions. Each time the
[r] key is pressed the next menu item will be displayed. Press # to exit to this
menu.
This is a sample of the display. The list
below reflects the available functions.
ù=Zone Review 44=Test 6=User Authority CHIME=Walk Test
0=Set Tone 45=Display Test 7=Detector Reset EXIT=Silent Exit
1=Master Mode 46=Light
Control
90=Log Review
2=Service Check 49=Español 91=View Settings
3=Alarm Memory 5=User PIN 97=Set Date/Time

NX148E-CF 13
VIEW ZONE STATUS
Step 1 Press r•. The LCD Screen will display the zone status.
Step 2 Use the •–scroll keys to browse through the descriptions. TheLCD
Screenwilldisplay the list of allzonesin sequentialorderby zonenumber.
Step 3 Press [#] to exit this function.
SETTING THE KEYPAD TONE
Step 1 Press r0. Keypad is now in the “Adjust Tone” mode.
Step 2 Press •to adjust the keypad
sounder to higher tones.
Step 3 Press –to adjust the keypad
sounder to lower tones.
Step 4 When the desired tone is reached, press # to set this tone and exit from
the “Adjust Tone” mode.
VIEW ALARM MEMORY
Step 1 Press r3to display the zone(s) on the keypad that created the last
alarm.
Step 2 The LCD Screen will display the zone
description for those zones.
Step 3 Press [#] to exit the alarm memory.
TEST FUNCTION (Optional, if programmed)
If programmed, this function will perform a battery test, communicator test,and/or
a siren test. No alarms will be sent, and no reports will be sent unless a
communicator test is performed, in which case a test signal will be sent.
Step 1 Press r4 4 . The test will be performed as programmed.
Step 2 If the siren test is performed, enter a user code to silence the siren.
Raise tone º
Lower tone º
Alarm Memory 1
ZONE 1

NX-148E-CF
14
DISPLAY TEST FUNCTION
This function will perform a test of the LCD display. No alarms or reports will be
sent.
Step 1 Press r4 5 . The test will be performed and all of the display
pixels and LED indicators will flash until another key is pressed.
Step 2 Press any key to end the test.
LIGHT CONTROL FOR X-10 DEVICES (Optional, if programmed)
This menu allows you to control up to ten X-10 devices from each keypad.
Step 1 Press r4 6 . The LCD screen will prompt you to “Select Light
Number 0 - 9”.
Step 2 Enter the number of the X-10 device you want to control. The LCD screen
will show the light number on the left. On the right side of the displayit will
prompt you to turn the light (X-10 device) “On” or “Off”.
Step 3 Press the •to turn the X-10 device “On” or press the –to turn the
X-10 device “Off”.
Step 4 The LCD screen will again prompt you to “Select Light Number 0 - 9”.
Step 5 Repeat Steps 2 and 3 until complete.
Step 6 Press #to exit from the X-10 menu.
CHANGE LANGUAGES
This function allows you to switch between the twolanguages programmed inyour
keypad. NOTE: You must exit any other function mode before attempting to
change languages.
Step 1 Press r4 9 . The LCD keypad is now toggled to the second
language.
Step 2 Repeat Step 1 to revert to the first language.

NX148E-CF 15
CHANGING USER CODES
Step 1 Press r5. The LCD Screen will prompt for a code.
Step 2 Enter [master code]. The LCD Screen will prompt for a user number.
NOTE: For partitioned systems, if you are changing the code of
another person, you must have access to all partitions, or at least
all of the partitions to which the other person has access.
Step 3 Enter the 2-digit user number. Always use leading zeros when
necessary, i.e. "04" for user number 4.
The LCD keypad will display the current code for this user. Stars (r)
represent blanks. NOTE: To delete a user code, press [r]-[r]-[r]-[r]
for a 4-digit code or [r]-[r]-[r]-[r]-[r]-[r] for a 6-digit code.
Step 4 Enter the new user code for that individual. If you are changing the
current code, you may use the up and down scroll keys to select the digit
to change and enter the correct number. If it rejects the code because of
duplication or such, the sounder will beep 3 times.
Step 5 If another user code needs to be programmed, return to step 3 and enter
the user code.
Step 6 Press #while the LCD screen is prompting for a new user to exit
Code Programming,
ASSIGNING USER CODE AUTHORITY LEVELS
Assign authority levels to users by following the steps below. Assign user codes
before assigning authority levels.
NOTE: You must have authority to the partition you wish to add or remove
from another person’s authority.
Step 1 Press r6 . The LCD Screen will now prompt for a code.
Step 2 Enter [master code]. The LCD Screen will prompt for a user number.
Step 3 Enter the 2-digit user number. Always use leading zeros when
necessary, i.e. "04" for user number 4. The LCD will nowprompt you for
the attributes in the following chart.

NX-148E-CF
16
PROMPT
Outputs used? »DO NOT CHANGE THIS SEGMENT!
Open / Close Rprt?
Bypass enable?
Arm / Disarm? (These are for use by a professional installer only.)
Master code?
Sched arm only?
Arm only?
Reserved
0=No 1=Yes
Your keypress will apply to the user code you entered in
Step 3.
Output 4 ?
Output 3 ?
Output 2 ?
Output 1?
If these messages appear on the LCD screen, press the [r]
key until you return to the prompt for the user code or until
you exit this adjust mode.
Step 4 NOTE: The LCD will now display all of the partitions to which this user
has access. If you wish to remove apartition, press the partition number
on the keypad, and the display will mark that partition with a (-) hyphen
indicating access has been removed. If you wish to re-establish user
access to the partition, press the partition number again.
Step 5 Press [r] to save the data. The LCD will then prompt you for the next
user code.
Step 6 If another user code needs to be programmed, return to Step 3. If not,
press [#] to exit this feature without saving the data.
RESET FUNCTION
This function is used to reset Smoke Detectors, Zone Troubles, and Zone
Tampers.
Step 1 Disarm the system if it is not already disarmed.
Step 2 Press r7. Resets have now been performed.
Step 3 If the keypad begins beeping, the reset did not execute properly. Enter
your code to silence the keypad. Wait a few minutes and repeat step 2
to attempt another reset. If the keypad still beeps after repeated
attempts, please contact your installer.

NX148E-CF 17
Open 75
9/25 17:57 P3*
READING THE EVENT LOG
The control panel has an event log that can be retrieved using a master code.
This log contains a listing of the events along with date, time, and partition where
the event occurred.
Step 1 To view the log, press r90. The LCD screen will prompt you
for a code.
Step 2 Enter your master code. The LCD screen will now show the most
recent event.
Step 3 To view the events from most recent to the oldest, press the –down
scroll key.
Step 4 To view the events from the oldest to the newest, press the •upscroll
key. The display contains the following information.
Event º ³ User or Zone ID
Date º»Indicates partition
(Month/Day) üTime shown in and rindicates an
24 hour format event not reported
This screen shows an opening of Partition 3 on September 25th at 5:27 p.m. by
user 75. The [r] shows that this event is not programmed to be reported to the
centralmonitoringstation. Refer to Appendix Aon page 25for a listof possible log
messages.
ADJUSTING THE VIEW / BRIGHTNESS OF THE LCD
Step 1 Enter r91 . The LCD Screen will prompt for a code.
Step 2 Enter [master code]. The LCD will now prompt you to raise or lower the
view.
Step 3 Using the scroll keys to the right of the LCD, you can raise or lower the
viewing angle of the text.
Step 4 Toadvanceto the Brightness option,press [r]. TheLCDwillprompt you
to brighten or dim the LCD lighting. Use the scroll keys again toadjust to
desired brightness.
Step 5 When completed, exit by pressing [r].

NX-148E-CF
18
SETTING THE SYSTEM CLOCK
Step 1 Enter r97. The LCD Screen will prompt for a code.
Step 2 Enter [master code]. The time and date will be displayed with the
current hour flashing.
Step 3 Use the •–scroll keys to select the proper hour.
Step 4 Press the rkey to move to the minutes, day of week, date, month,
and year.
Step 5 Repeat Steps 3 and 4 until the entire time and date are set.
USING THE DOOR CHIME FEATURE
Thedoorchime is turned on oroffby pressing the [CHIME]key. Ifthe chimeison,
the chime light will be illuminated. If the chime is off, the chime light will be off.
Each press of the [CHIME] key will toggle the chime feature on/off and produce a
momentary ding-dong sound.
