GE Protimeter MMS User manual

GE
Sensing
Protimeter MMS
Moisture Measurement System
Instruction Manual

GE
Sensing
Protimeter MMS
Moisture Measurement System
Instruction Manual
INS5800A
October 2005

i
Table of Contents
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1. Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 Switching the MMS ON and OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Optional Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2. Moisture Meter Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 Search Mode - Selection and Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Measure Mode - Selection and Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.3 Hygrometer Mode - Selection and Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.4 Condensator Mode - Selection and Use . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.5 Setup Mode - Selection and Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.6 Holding and Measurement Storage Mode - Selection and Use . . . . 13
3. Diagnostic Procedure Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4. Calibration Checking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5. Care and Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6. Technical Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
7. Displaying the MMS Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
A1. Using the Protimeter MMS to Measure Moisture in Floors . . . . . . . . . . . . . 18
A1.1 Rapid Moisture Level Assessment of Solid Floors. . . . . . . . . . . . . . . . 18
A1.2 Equilibrium Relative Humidity Measurements in Solid Floors. . . . . 19

Protimeter MMS Moisture Measurement System Page 1
Introduction
The Protimeter Moisture Measurement System (Protimeter MMS), is a
powerful and versatile instrument for measuring and diagnosing dampness in
buildings and building materials. This product enables building surveyors and
other practitioners to measure moisture levels of building elements such as
walls, floors and building environments simply by switching between the
three different modes of operation. In this way, a detailed understanding of the
moisture condition of the property can be obtained.
1 Product Features
The Protimeter MMS kit comprises a carry case containing the MMS
instrument and a range of standard accessories, as detailed in Table 1 below.
As an example, the figure on the next page shows a BLD5800 kit.
Table 1: Protimeter MMS Kit
Description Part Number
Standard Kit
Kit with Hygrostick/Data cable/software
Kit with Humistick/Data cable/software
BLD5800
BLD5800LH
BLD5800HS
Kit Components
Protimeter MMS instrument POL5800JC
Instruction manual INS5800
Carry case POU5800-01
Moisture probe BLD5060
Deep Wall Probes (5.5 in. (140 mm) long) BLD5018
Surface temperature sensor (direct contact) BLD5804
Calibration check device (for %WME) BLD5086
Hygrostick/Humistick extension lead BLD5802
Hygrostick hygrometer probe POL4750
Humistick moisture probe POL7750-2
Data cable and software (option) BLD5810

Page 2 Protimeter MMS Moisture Measurement System
BLD5800 Kit
The Protimeter MMS instrument is a battery-powered, handheld unit that has
a cluster of four buttons and a large liquid crystal display (LCD). A sensor for
detecting moisture within solid materials is housed in the bulge at the top of
the instrument. The following external connections are found on the
instrument case (see the figure on the next page):
•EC 1 - This edge connection socket is for use with a Hygrostick or
Humistick probe.
•JC - This jack connection socket is for use with a moisture probe, deep
wall probes or a hammer electrode.
•EC 2 - This edge connection socket is for use with the Direct Contact
Surface Temperature Sensor and for connection to a PC when using the
optional MMS logging software.
POU5800-01
POL5800
BLD5802
BLD5804
BLD5018
POL4750
BLD5060

Protimeter MMS Moisture Measurement System Page 3
The following probes and sensors are included in the standard Protimeter
MMS kits:
•The Hygrostick®(POL4750) and Humistick®(POL7750-2) probes
measure relative humidity (%RH) and ambient air temperature (TAIR) in
rooms or materials. They can be connected to the Protimeter MMS
instrument either directly or by means of the Hygrostick/Humistick
extension lead.
•The surface temperature sensor (TS) is used when investigating
condensation situations.
•The moisture probe is used to obtain percent moisture content values in
wood or wood moisture equivalent (WME) values in other non-conductive
materials.
•Deep wall probes are used to obtain WME values deep below the surface in
solid structures such as walls and floors.
EC 1
EC 2
JC
Search Mode Sensor

Page 4 Protimeter MMS Moisture Measurement System
1.1 Switching the MMS ON and OFF
Prior to initial use, ensure that two AA batteries are correctly inserted in the
battery compartment.
Note: Low battery power is indicated by on the display; when this
symbol appears, replace the batteries.
Switch the MMS ON by pressing momentarily.
The MMS switches OFF automatically after 1 minute, unless the default setup
is changed (see section 2.5 for instructions). To switch the instrument OFF
immediately, press and hold for at least 3 seconds. Once has been
depressed for 3 seconds or more, all text blocks appear on the display; when
is released, the text blocks disappear and the unit switches OFF.
1.2 Optional Accessories
A range of optional accessories may be used with the Protimeter MMS. These
include:
•hammer electrodes
•data download software & cable
•additional Hygrosticks and Humisticks
For more information please contact GE Sensing.
2 Moisture Meter Modes
The Protimeter MMS can be used to detect and measure moisture in non-
conductive solid materials such as wood, drywall and masonry. Two modes of
operation are available, the Search Mode for qualitative measurements and the
Measure Mode for precise and localized moisture content measurements in
wood or WME values in materials other than wood.
!

Protimeter MMS Moisture Measurement System Page 5
2.1 Search Mode - Selection and Use
Turn the MMS ON by pressing . Select the moisture meter mode by
pressing XX repeatedly until the word MOISTURE is visible in the top right
corner of the LCD. Then press Xto select the Search mode, indicated by
on the LCD.
The instrument can now be used to take relative moisture readings in solid,
homogenous materials (such as walls and floors) by holding the leading edge
of the sensor bulge against the surface (see the figure below) at an angle
ranging from 20° to 50°. Relative readings ranging from 0-1000 appear on the
LCD together with a progress bar that indicates whether the material is in a
DRY, AT RISK or WET condition.
As reliable readings are obtained only
if the leading edge of the sensor bulge
is in direct contact with the surface, the
Search mode is not suitable for
surveying textured finishes. The
nominal depth of penetration is up to
0.6 in. (15 mm) in dense, homogeneous
materials. Readings taken through low-
density coverings (carpets, polystyrene
tiles, etc.) will not be representative of
the moisture level in the substrate itself.
When using the MMS in Search mode,
it is recommended that no attachments
(i.e. Hygrostick probe, Humistick
probe, Surface Temperature Sensor, or
Moisture probe) are connected. This
practice will minimize reading errors
and the potential for electromagnetic
interference with other electronic
equipment.
2.1.1 Search Mode - Zeroing Function
If that instrument is used in Search Mode at an ambient temperature that is
significantly different from the ambient temperature at the time of the original
calibration, the instrument may show a small, non-zero reading when held in
free air.
REL
)
)
)
)

Page 6 Protimeter MMS Moisture Measurement System
If this should occur, re-zero the instrument as follows:
1. Remove any attached accessories
and select Moisture Search Mode
(see section 2.1 for instructions).
MOISTURE & REL is displayed.
2. With one hand, hold the instrument
at least 12 in. (0.3 m) from all
objects (see the figure to the right).
3. With your other hand,
simultaneously press the XXand X
buttons. Hold them down until the
display shows nul, then Air. Quickly
release the buttons and continue to
hold the instrument as shown, well
clear of your body and your other
hand. Keep the instrument in free
air (i.e. at least 12 in. (0.3 m) from
all objects) while the display is
showing Air.
4. After about 10 seconds, the display should return to normal and the
instrument should read zero when held in free air.
You may now take normal Search Mode readings with the MMS.
2.1.1.1 Troubleshooting the Zeroing Function - The instrument
changes mode when zeroing Is attempted
If the instrument changes mode when you attempt to zero it, you have most
likely not pressed the two buttons at exactly the same time. Return to Search
Mode and attempt to press and hold the two buttons simultaneously.
2.1.1.2 Troubleshooting the Zeroing Function - The instrument
shows Air, but then displays Err or E30 and shuts OFF
If this situation occurs, repeat the zeroing procedure. If this does not solve the
problem, it is likely that the temperature adjustment is outside the permitted
range. If possible, allow the unit to return to normal room temperature (about
20°C/68°F). If the unit will not re-zero at this temperature, the unit is likely
faulty and requires repair/service.

Protimeter MMS Moisture Measurement System Page 7
2.2 Measure Mode - Selection and Use
Turn the MMS ON by pressing .
Select the moisture meter mode by
pressing XX repeatedly until the word
MOISTURE is visible in the top right
corner of the LCD. Then press Xto
select the Measure mode, indicated by
on the LCD. Connect the
Moisture Probe, Deep Wall Probe, or
Hammer Electrode into socket JC of
the MMS instrument.
The instrument can now be used to take
actual %MC readings in wood and
%WME readings in non-conductive
solid materials other than wood by
pushing the moisture probe pins into
the surface (see the figure to the right).
The measured value is displayed and the progress bar indicates whether the
material is in a DRY, AT RISK or WET condition, as listed in Table 2 below.
Table 2: Measure Mode Readings
%MC (wood only) or %WME MMS Measure Mode Display
<8% – – – % (denotes out of range),
[inactive progress bar]
≥8% but <17% %MC or %WME value, DRY,
[active progress bar]
≥17% but <20% %MC or %WME value, AT RISK,
[active progress bar]
≥20% but <28% %MC or %WME value, WET,
[active progress bar]
≥28% to 100% Relative value only,
[active progress bar]
%WME

Page 8 Protimeter MMS Moisture Measurement System
2.2.1 Using Auxiliary Moisture Probes in Measure Mode
To take sub-surface readings in masonry,
the Deep Wall Probes should be used
instead of the standard Moisture Probe.
To use the deep wall probes, drill two
1/4” (6 mm) diameter clearance holes,
spaced 2-3 in. (50-75 mm) apart, to the
required depth (see figure at right). Push
the two Deep Wall Probes into the holes
and press and hold the tips firmly
against the bottom of the holes. Ensure
that the probes are connected to socket
JC and measure the %WME value as
described in section 2.2.
Note: The most convenient way to take sub-surface readings in wood is by
using an optional Hammer Electrode.
2.2.2 Detecting Hygroscopic Salts
The Protimeter MMS instrument can be used as a basic salts detector when
used with the Moisture Probe, filter papers and distilled water (not included).
Moisten the filter paper with the water and take a reference reading across it
with the Moisture Probe. Then place the moistened filter paper against the
surface of interest and hold in place for 30 seconds. Remove the paper and
place the pins of the Moisture Probe across the paper again and observe the
reading. Compare this reading with the original reference reading. If the
difference is more than 20 points, there is significant salts contamination that
may warrant further investigation.
2.3 Hygrometer Mode - Selection and Use
To use the Protimeter MMS as a hygrometer, connect the Hygrostick or
Humistick probe into socket EC1 either directly or indirectly with the
extension lead. Turn the MMS ON by pressing . Then, select the
hygrometer mode by pressing XX repeatedly until the word HYGROMETER is
visible in the top left corner of the LCD. Then press Xto select relative
humidity (%rh), ambient temperature (TAIR), dew point temperature (TDEW), or
specific humidity (g.Lb or AbS) as required. Temperature values can be
displayed in °C or °F (see section 2.5 for instructions).

Protimeter MMS Moisture Measurement System Page 9
Note: The Mixing Ratio (AbS) or Specific Humidity (g.Lb) displays are
preceded by a momentary beep to draw attention to the unit of
measure prior to displaying the value.
%rh and TAIR measurements are
made with the Hygrostick or
Humistick sensor, and the MMS
instrument uses these values to
calculate TDEW. When using the
MMS to measure the conditions in
air, the humidity probe is normally
connected directly to the instrument.
However, when it is impractical or
awkward to use the instrument in this
way, the extension lead may be used
to connect the Hygrostick or
Humistick to the instrument.
Typically, the extension lead will be
used when taking readings from
probes that have been embedded in
structures such as walls and floors.
2.4 Condensator Mode - Selection and Use
The Condensator Mode enables the
user to assess the risk of
condensation occurring on surfaces
or to confirm whether or not
condensation is present on a surface.
To use the MMS as a Condensator,
connect a Hygrostick probe directly
into socket EC1 and connect the
surface temperature sensor into
socket EC2. Turn the MMS ON by
pressing . Select the condensator
mode by pressing XX repeatedly
until the word CONDENSATOR is
visible at the top of the LCD. Then
press Xto select relative humidity (%rh), ambient temperature (TAIR), dew
point temperature (TDEW), surface temperature (TS) or temperature difference
(TDIFF) as required. TSand TDIFF measurements can only be obtained if a

Page 10 Protimeter MMS Moisture Measurement System
Surface Temperature Sensor is connected to the instrument and held against
the surface of interest. Temperature values can be displayed in °C or °F (see
section 2.5 for instructions).
TDIFF is a useful function when investigating condensation, as it tells the user
how many degrees a surface is above or below the prevailing dew point
temperature. When a surface exceeds the dew point by more than 3°C, TDIFF is
displayed with the message NO CONDENSATION. When a surface exceeds
the dew point by 3°C or less, TDIFF is displayed with the message AT RISK, NO
CONDENSATION. When the surface temperature is equal to or lower than the
dew point, a negative TDIFF is displayed with the message CONDENSATION.
The progress bar is activated when TDIFF is less than 14°C above the dew
point. The indicator moves from left to right to signify the increasing risk and
degree of condensation. Table 3 below summarizes this functionality.
Table 3: Condensator Mode Readings
Temperature of Surface MMS Condensator Mode Display
>14°C above dew point TDIFF, NO CONDENSTATION,
[inactive progress bar]
≤14°C but >3°C above dew point TDIFF, NO CONDENSTATION,
[active progress bar]
≤3°C above dew point TDIFF, AT RISK, NO CONDENSTATION,
[active progress bar]
≤dew point TDIFF, CONDENSTATION,
[active progress bar]

Protimeter MMS Moisture Measurement System Page 11
2.4.1 Sensor Installation
All humidity probes must be plugged into socket EC1 in the top (“nose”) of
the instrument. This includes:
•POL4750 Hygrostick (30-100% RH)
•POL7750-2 Humistick (1-100% RH)
The only accessories that should be plugged into socket EC2 on the side of the
instrument are:
•BLD5804 Surface Temperature Probe
•MMS-to-PC Data Logging Cable
Note: With older instruments, the Low RH Sensor (0-40% RH) BLD5812
was plugged into socket EC2 on the side of the instrument.
2.5 Setup Mode - Selection and Use
The Protimeter MMS instrument has a range of features that can be selected
by the user (see Table 4 on the next page).
To enter the Setup Mode, switch the instrument ON and disconnect any
attachments that may be connected. When the display shows three horizontal
dashes ( - - - ), press momentarily; the word SETUP then appears in the
bottom left corner of the LCD together with the code S 1 in the middle of the
display. Within three seconds, press XX repeatedly to scroll through the setup
codes as detailed in Table 4 on the next page. Press Xto set the desired setup
option.

Page 12 Protimeter MMS Moisture Measurement System
Example 1: To deactivate the backlight and change the temperature
readings from °C to °F:
•Enter Setup Mode by pressing momentarily.
•When the display shows - - - , scroll to S 4 by pressing XX.
•Press Xto select the deactivated backlight option.
•Scroll to S 2 by pressing XX.
•Press Xto select the °F display option.
•Press momentarily (or wait for three seconds) to return to
Operating Mode.
The instrument now displays temperatures in °F with no backlighting.
Example 2: To change the auto switch off time from the default 1 minute
to 5 minutes:
•Enter Setup Mode by pressing momentarily.
•When the display shows - - - , scroll to T 1 by pressing XX.
•Press Xfour times to display T 5.
•Press momentarily (or wait for three seconds) to return to
Operating Mode.
The instrument now switches OFF automatically after 5 minutes.
Table 4: Setup Options
Setup Code Setup Selection
S 1 Displays temperature values in °C
S 2 Displays temperature values in °F
S 3 Activates LCD backlight
S 4 Deactivates LCD backlight
S 5 Activates beeper
S 6 Deactivates beeper
DEF Default settings (°C, activated backlight, activated beeper, 1 min.
auto switch off)
0.00 Real-time clock (adjustable only through IrdA comm port with
Protimeter software)
T 1 Auto switch off adjustment, from 1-6 minutes

Protimeter MMS Moisture Measurement System Page 13
2.6 Holding and Measurement Storage Mode -
Selection and Use
Moisture, temperature and RH readings can be held by pressing and holding
. If the button is held down for less than three seconds, the instrument
reverts to the previously selected mode of measurement. If the button is held
down for more than three seconds, the instrument switches off when the
button is released (see section 1.1).
Readings can be stored in the MMS memory (minimum of 300 line entries)
by pressing . Table 5 below details the information that is stored when using
this function in the various modes. Contents of the memory can be
downloaded to a PC running Microsoft®Windows 95 or later, and can be
uploaded to the MMS with the Protimeter MMS Logging Software.
Note: For further information see the MMS Logging Help document
(INS5800L) supplied with the Protimeter Logging Software CD.
Table 5: Logging Information
Mode Display Information Logged
MOISTURE
Meter
yr/mm/dd, hr:min, relative value
(e.g. 00/01/07, 09:30, 530)
yr/mm/dd, hr:min, %WME value
(e.g. 00/01/07, 09:30, 12.5)
HYGROMETER %rh yr/mm/dd, hr:min, %rh, TAIR, Hygrostick SN
(e.g. 00/01/07, 09:30, 52.5, 21.2, 123456)
TAIR yr/mm/dd, hr:min, TAIR, Hygrostick SN
(e.g. 00/01/07, 09:30, 21.2, 123456)
TDEW yr/mm/dd, hr:min, TAIR, TDEW, Hygrostick SN
(e.g. 00/01/07, 09:30, 21.2, 10.5, 123456)
CONDENSATOR %rh yr/mm/dd, hr:min, %rh, TAIR, Hygrostick SN
(e.g. 00/01/07, 09:30, 52.5, 21.2, 123456)
TAIR yr/mm/dd, hr:min, TAIR, Hygrostick SN
(e.g. 00/01/07, 09:30, 21.2, 123456)
TDEW yr/mm/dd, hr:min, TAIR, TDEW, Hygrostick SN
(e.g. 00/01/07, 09:30, 21.2, 10.5, 123456)
TSyr/mm/dd, hr:min, TS
(e.g. 00/01/07, 09:30, 18.6)
TDIFF yr/mm/dd, hr:min, TDIFF, TAIR, TDEW, Hygrostick SN
(e.g. 00/01/07, 09:30, 8.1, 21.2, 10.5, 123456)
REL
)
)
)
)
%WME

Page 14 Protimeter MMS Moisture Measurement System
3 Diagnostic Procedure Guidelines
When diagnosing dampness in buildings, there are three key criteria that must
be considered. These are outlined in Table 6 below.
Item 1: The Search and Measure modes should be used in combination to
map out the extent of a moisture problem and to distinguish between
surface and sub-surface moisture. The profile of readings obtained
will give insight into the potential cause (e.g. condensation, lateral
ingress or rising dampness) of a moisture-related problem.
Far greater insight will be obtained from moisture readings taken in a
methodical manner than from those taken in a random manner. When
testing walls, the user should start by taking readings at the lower
levels and move up the wall in regular steps of 4-6 in. (10-15 cm).
Table 6: Diagnostic Criteria
Item Criteria Notes
1 Is a wall or other building
element in a safe air-dry
condition?
Air-dry is the moisture content that is
normal and safe (from moisture-related
deterioration or decay) in buildings. When
the Protimeter MMS moisture meter modes
are selected, measured values are identified
as DRY, AT RISK or WET.
2 Is the surface temperature of a
wall or other building element
above or below the dew point?
Dew point is the temperature at which a
given quantity of air becomes saturated
(100% RH) and forms dew, or
condensation. If a surface is colder than the
dew point, condensation occurs. When the
Protimeter MMS Condensator Mode is
selected to measure TDIFF (the proximity of
a surface to the dew point) the instrument
identifies either a NO CONDENSATION
condition, an AT RISK condition, or a
CONDENSATION occurring condition.
3 Is a wall surface or other
building element
contaminated with
hygroscopic salts or other
conductive material?
Artificially high moisture meter readings
may be obtained either in material that has
been heavily contaminated by hygroscopic
salts or in materials that are conductive by
nature. The presence or absence of nitrates
and chlorides should be established when
investigating suspected rising dampness
situations in particular.

Protimeter MMS Moisture Measurement System Page 15
When high sub-surface relative readings are obtained in the Search
mode, the user is strongly recommended to quantify these values in
%WME terms by using the Deep Wall Probes in the Measure mode.
If the depth of clearance holes is increased incrementally by a
nominal 0.4 in. (10 mm) at a time, the moisture profile through the
wall can be established.
Item 2: Condensation related moisture problems are common. When
assessing the risk of condensation, or confirming its existence, the
proximity of the actual temperature of the surface under
investigation to the dew point must be established. The TDIFF
measurement in CONDENSATOR mode tells the user how many
degrees the temperature of a surface is above or below the dew point.
As many condensation situations are transient, TDIFF readings should
be taken in a methodical and regular manner, similar to moisture
meter readings in materials. Ambient RH and temperature values
should also be taken to assess the moisture condition of the room as a
whole. Dwellings and working environments generally have an RH
from 40% to 60%, so there may be cause to investigate environments
that register RH values outside this range.
Item 3: Two hygroscopic salts, chlorides and nitrates, may build up on the
surface of walls where rising dampness or wicking occurs. As
groundwater moves through the wall and migrates to the surface,
salts tend to accumulate where the rate of evaporation of this water is
greatest. The salts themselves are non-conductive, but when mixed
with a small amount of moisture a highly conductive solution is
formed. The presence (or absence) of such salts should therefore be
established when rising dampness is suspected by using the
Protimeter MMS in Measure mode as described. When required, the
Protimeter Salts Analysis Kit (part number BLD4900) can be used to
identify the relative concentrations of nitrates and chlorides.
In summary, effective dampness diagnosis is a process that draws on the
knowledge and expertise of the surveyor. The Protimeter MMS kit enables the
user to investigate moisture levels in materials and environments from various
perspectives that, in turn, permits a more thorough and reliable judgement as
to the cause of dampness related problems.

Page 16 Protimeter MMS Moisture Measurement System
4 Calibration Checking
Check the Moisture meter Measure Mode by holding the pins of the Moisture
Probe across the exposed wires of the calibration check device (Calcheck).
The WME value of correctly calibrated instruments is 17-19. Instruments that
register values outside this range should be returned to GE Sensing (or an
official GE Sensing distributor) for servicing.
Note: Search mode can be checked against a stable area of wall. For
comparative purposes, humidity and ambient temperature conditions
should be stable and consistent.
Working Hygrostick and Humistick probes can be checked against reference
probes and/or over standard salt solutions.
5 Care and Maintenance
The Protimeter MMS is a precision-built electronic instrument that will
provide many years of reliable service if the following points are observed:
•When not in use, keep the MMS instrument and its accessories in the
factory Carry Case. Store the case in a stable, dust-free environment and
keep it out of direct sunlight.
•If the instrument is to be stored for more than four weeks or if the low
battery power symbol appears on the display, remove the batteries from the
instrument.
•When using the MMS in Search mode, do not slide the bulge across
surfaces, as this may lead to rapid instrument case wear. The instrument
should be lifted and placed in position to prevent such wear.
•Check the condition of the MMS accessories on a regular basis, and replace
them if they become worn or damaged.
•To preserve their calibration characteristics, Hygrostick probes should not
be exposed to saturated environments. If this is unavoidable, Hygrostick
probes should be replaced on a regular basis and their calibration should be
checked frequently.

Protimeter MMS Moisture Measurement System Page 17
6 Technical Specifications
Weights and Dimensions
Protimeter MMS Kit (BLD5800): 2.5 lb (1.1 kg),
9 in. x 7.5 in. x 3.5 in. (230 mm x 190 mm x 90 mm)
Protimeter MMS Instrument (POL5800JC): 10.58 oz (300 g),
7 in. x 2.75 in. x 1.9 in. (180 mm x 70 mm x 49 mm)
Hygrostick Probe (POL4750): 2 in. long x 0.3 in. (50 mm long x 8 mm),
optimal clearance hole 12 mm dia. (when used with compression sleeve
to measure ERH in solid material)
Humistick Probe (POL7750-2): 2.5 in. long x 0.5 in. (65 mm long x 12 mm)
Power
2 x AA batteries
Measurement Ranges
Moisture Meter
Search Mode: 0-1000 relative scale, nominal depth of
measurement 0.6 in. (15 mm),
tolerance ±10 relative scale
Measure Mode: 8-29 %WME, 30-100 relative scale in
saturated material
Hygrostick Probe
Measurement Range: 30-100 %rh, 32 to 122°F (-10 to 50°C)
Tolerance (nominal): 30-40 %rh, ±3 %rh @68°F (20°C)
41-98 %rh, ±2 %rh @68°F (20°C)
32 to 122°F (-10 to 50°C), ±0.6°F (±0.3°C)
Humistick Probe
Measurement Range: 0-100 %rh, 32 to 122°F (-10 to 50°C)
Tolerance (nominal): 0-10 %rh, ±3 %rh @68-86°F (20-30°C)
10-90 %rh, ±2 %rh @68-86°F (20-30°C)
90-100 %rh, ±3 %rh @68-86°F (20-30°C)
32 to 122°F (-10 to 50°C), ±0.6°F (±0.3°C)
Surface Temperature Sensor: 32 to 122°F (-10 to 50°C), ±0.6°F (±0.3°C)
