GE MP100 Series User manual

GE Healthcare
CIC Pro™
English
2026420-003 (CD)
2026421-026E (paper)
© 2008-2010 General Electric Company.
All rights reserved.
CIC Pro™ Clinical Information Center
Service Manual
Software Version 5.1
MP100 Series

T-2 CIC Pro™ 2026419-033E
21 September 2010
NOTE
The information in this manual only applies to CIC Pro center software versions 5.1.x or later. It does not apply to earlier
software versions. Due to continuing product innovation, specifications in this manual are subject to change without
notice.
NOTE
For technical documentation purposes, the abbreviation GE is used for the legal entity name, GE Medical Systems
Information Technologies, Inc.
NOTE
The product names CIC Pro, CIC Pro center, CARESCAPE CIC Pro Clinical Information Center, CARESCAPE CIC Pro,
CARESCAPE CIC Central Station, CARESCAPE Clinical Information Center Pro, and CARESCAPE Clinical
Information Center all refer to the CIC Pro Clinical Information Center product.
Listed below are GE Medical Systems Information Technologies, Inc. trademarks used in this document. All other trademarks
contained herein are the property of their respective owners.
APEX, Aware, SOLAR, and MUSE are trademarks of GE Medical Systems Information Technologies, Inc., registered in the
United States Patent and Trademark Office.
APEXPRO, CARESCAPE, CD TELEMETRY-LAN, CENTRALSCOPE, CIC PRO, and UNITY NETWORK are trademarks
of GE Medical Systems Information Technologies, Inc.

2026419-033E CIC Pro™ i
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Equipment information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
License agreement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Intended use of the equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Safety information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Equipment symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Service requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Manufacturer responsibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
Equipment identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
Manual information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Manual purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Intended audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Related manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Conventions used. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Ordering manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
2 Equipment overview . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Standard components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Processor box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Power indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Optional components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Secondary display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Touchscreen displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Mirror display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Laser printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
PRN 50-M digital writer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Un-interruptible power supply (UPS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Theory of operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Functional description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
Physiological data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
File and data management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
Licensing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Full disclosure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Networking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
Patient monitoring network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
Web access server network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21

ii CIC Pro™ 2026419-033E
Patient data interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-22
Multi-patient viewer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-22
Single patient viewer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24
Patient data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24
Real-time patient data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
Stored patient data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
Service interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
3 Licensing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
CIC Pro center configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
License requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Available licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Description of licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
License packages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Patient Data Server information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
License activation methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
4 Service interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Access methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Direct access method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Network access method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Administrator mode access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Service interface access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Setup CIC with service access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Command-line interface access (for advanced users) . . . . . . . . . . . . . . . . 4-5
Windows utilities access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Screen-sharing interface access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Webmin interface access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Webmin overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
Information tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
Configuration tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
Diagnostics tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
5 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Complete product training . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

2026419-033E CIC Pro™ iii
Complete site survey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Service PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Pre-installation checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Format a USB memory stick . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Procure necessary licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Gather required tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Inspect equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Evaluate site. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Installation process. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Installation process checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
Mount the equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
Connect the cables and peripheral devices . . . . . . . . . . . . . . . . . . . . . . . 5-12
Remote view (view only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15
Install optional accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
Plug in the power cable to the CIC Pro center . . . . . . . . . . . . . . . . . . . . 5-18
Turn on the power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-19
6 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Pre-configuration process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Pre-configuration requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Pre-configuration instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Configuration process checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
Disconnect CARESCAPE Network IX and MC networks . . . . . . . . . . . . . 6-7
Install licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
Configure Webmin-related settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
Configure desktop-related settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Configure clinical application settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Reconnect the CIC Pro center with the network . . . . . . . . . . . . . . . . . . . . . 6-9
Perform MultiKM (Multimouse) setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Run Log File Compression Configuration Utility . . . . . . . . . . . . . . . . . . . . . 6-9
Disconnect from the CARESCAPE Network IX and MC networks . . . . . . 6-10
Configure Webmin-related settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10
Activate software licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10
Set the network IP address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
Configure clinician review workstation . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
Configure network laser printers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
Configure the server for remote connectivity . . . . . . . . . . . . . . . . . . . . . . 6-16
Set up a Citrix client . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-19
Configure browser favorites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-21
Configure set flags settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-22
Configure the CIC Pro center language . . . . . . . . . . . . . . . . . . . . . . . . . 6-27
Configure desktop-related settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-28

iv CIC Pro™ 2026419-033E
Configure USB laser printers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-28
Set the laser printer default paper size . . . . . . . . . . . . . . . . . . . . . . . . . . 6-30
Configure a secondary display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-30
Calibrate a touchscreen display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-32
Set the time zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-34
Restart CIC Pro center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-36
Configure clinical application settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-36
Configure the printer settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-36
Configure clinical application, telemetry, and care unit settings. . . . . . . . 6-36
Set the Telemetry Unit Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-44
Set the Telemetry Alarm Control Defaults . . . . . . . . . . . . . . . . . . . . . . . . 6-45
Full disclosure license management setup. . . . . . . . . . . . . . . . . . . . . . . . 6-47
Set the Display Configuration (non-mirror CIC Pro centers) . . . . . . . . . . 6-49
Set the Current Telemetry Listings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-51
Set up locked beds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-53
(Chinese only) Set the pressures unit-of-measure . . . . . . . . . . . . . . . . . 6-53
Screen calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-55
Browser configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-57
Configure customize groupings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-61
Set up customize groupings for graphic trends . . . . . . . . . . . . . . . . . . . . 6-61
Set up custom groupings for vital signs . . . . . . . . . . . . . . . . . . . . . . . . . . 6-64
Configure shortcuts to favorite CIC Pro center views . . . . . . . . . . . . . . . 6-65
Configure the print location settings for stored patient data . . . . . . . . . . 6-67
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-67
Configure the print location settings for the patient data categories . . . . 6-67
Set the time-of-day or the date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-68
Back up and restore the CIC Pro center configuration . . . . . . . . . . . . . . . 6-71
Back up care unit default configuration settings . . . . . . . . . . . . . . . . . . . 6-71
Planning your care unit defaults restore strategy. . . . . . . . . . . . . . . . . . . 6-72
Backing up and restoring local custom default configuration settings . . . 6-75
Reconnect the CIC Pro center with the network . . . . . . . . . . . . . . . . . . . . 6-77
Perform MultiKM (Multimouse) setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-77
Pre-configure the CIC Pro centers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-78
Configure the keyboard and mouse group . . . . . . . . . . . . . . . . . . . . . . . 6-80
Change a keyboard and mouse group . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-83
Run Log File Compression Configuration Utility . . . . . . . . . . . . . . . . . . . . 6-88
Equipment/tools required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-88
Create a Log File Compression Configuration Utility USB memory stick 6-88
Run Log Compression Configuration Utility . . . . . . . . . . . . . . . . . . . . . . . 6-89
Complete configuration checkout procedures . . . . . . . . . . . . . . . . . . . . . 6-91

2026419-033E CIC Pro™ v
7 Checkout procedures . . . . . . . . . . . . . . . . . . . . . . . . 7-1
Safety tests and checkout procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Test equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Configuration checkout procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Check the unit defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Check status of installed printers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
View system information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Check operation of the secondary display . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Check mirror configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Check the status of installed licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Verify settings with Check Centrals command . . . . . . . . . . . . . . . . . . . . . 7-5
Check and configure the speaker volume . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Check operation of audible alarm tones . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Check access to all other care units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Check the operation of the Citrix application viewed at the CIC Pro center 7-
7
Check the hospital intranet browser functionality . . . . . . . . . . . . . . . . . . . 7-7
Check the status of locked beds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Check the language settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Check the pressures unit-of-measure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Check the custom groupings for patient data . . . . . . . . . . . . . . . . . . . . . . 7-8
Check the shortcuts to favorite CIC Pro center views . . . . . . . . . . . . . . . . 7-8
Check MultiKM (Multimouse) operation . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Check current system settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Check full disclosure license type for all admitted in-unit beds . . . . . . . . . 7-9
Check full disclosure report printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
Save backup defaults file on the USB memory stick . . . . . . . . . . . . . . . . 7-10
FRU checkout procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-10
Check read and write integrity of hard drive and solid state flash drive . 7-10
Check USB devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
Check internal hardware temperature and voltage status . . . . . . . . . . . . 7-12
Check COMM ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-13
Check BIOS information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-13
Check drive operation information (Flash drive and hard drive) . . . . . . . 7-14
Check audio component operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-16
Check speaker status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-17
Check operation of the Watchdog countdown function . . . . . . . . . . . . . . 7-18
Check processor fan status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-19
Check video function and status of video card and drivers . . . . . . . . . . . 7-19
Check integrity of system files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-20
Check asset information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-21
Check successful execution of Log File Compression Configuration Utility 7-
21
8 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2

vi CIC Pro™ 2026419-033E
Required tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Display issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8
Blank screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8
Blue screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8
Red screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Incorrect colors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Browser connectivity issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Printer issues. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Laser printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Digital display writer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10
MultiKM issues. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10
License activation failures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10
CIC Pro center setup issues. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11
Unable to communicate with a device . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11
List full disclosure beds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-12
Set full disclosure mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-13
Ping full disclosure server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14
Display current system settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14
Enable alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-15
Admit Request Info button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-15
Display waveform indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-15
Require age selection for admit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-16
Licensing issues. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-16
Time zone, daylight saving time setting, and network time issues . . . . . 8-19
PDF file access from MUSE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-19
Environment Monitor messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-19
Log files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-20
Download log files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-20
Access current log files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-21
Application logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-23
Operating system event logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-24
Operating system Dr. Watson log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-25
Webmin action log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-25
Access additional runtime diagnostic information . . . . . . . . . . . . . . . . . . 8-26
Device driver information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-26
Network information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-26
Operating system runtime statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-27
Operating system service process information . . . . . . . . . . . . . . . . . . . . 8-28
Process information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-28
Time zone information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-29
SMART drive status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-29

2026419-033E CIC Pro™ vii
Perform safe restart of the CIC Pro center . . . . . . . . . . . . . . . . . . . . . . . . . 8-30
Perform safe shutdown of the CIC Pro center . . . . . . . . . . . . . . . . . . . . . . 8-31
Change the logon password for Webmin . . . . . . . . . . . . . . . . . . . . . . . . . . 8-32
9 Field replaceable units (FRUs) . . . . . . . . . . . . . . . . . 9-1
Exploded views . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2
Desktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2
Rack-mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4
Interconnect diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-6
FRUs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-6
Disaster recovery software kit and Service Tools CD . . . . . . . . . . . . . . . . . 9-6
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-6
Power cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-7
Keyboard kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-8
Replacement procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-8
Desktop assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-9
Rack-mount assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10
Common replacement procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-11
Replacing the CPU PCB (mother board) . . . . . . . . . . . . . . . . . . . . . . . . . 9-14
Replacing the CPU battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-15
Replacing the hard drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-17
Replacing the flash drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-18
Replacing the SATA drive cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-19
Replacing the power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-20
Replacing the fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-21
Replacing the dual speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-22
Replacing the fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-22
Replacing the front bezel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-23
Re-assemble the cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-24
10 Preventive maintenance . . . . . . . . . . . . . . . . . . . . . 10-1
Maintenance schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-2
Checklist. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-2
Visual inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-3
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-3
Power source tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-6
Power outlet test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-6
Power cord and plug test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-6

viii CIC Pro™ 2026419-033E
Electrical safety tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-6
Ground (earth) integrity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-6
Ground (earth) wire leakage current test . . . . . . . . . . . . . . . . . . . . . . . . . 10-7
Enclosure leakage current test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-8
Test completion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-10
Check the operation of input devices and displays . . . . . . . . . . . . . . . . 10-10
Perform checkout procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-10
System resource indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11
Resource indicator messages when hovering over icon . . . . . . . . . . . . 10-12
Resource indicator messages when icon is double-clicked . . . . . . . . . 10-12
Resource indicator messages from Environment Monitoring Service . . 10-12
System resource restart procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-13
Access log files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-14
11 Reload software . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-1
Purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-2
Process overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-2
Gather required equipment and tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-2
Create a CIC Pro center image restore USB memory stick . . . . . . . . . . . 11-2
Reload CIC Pro center software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-5
Complete checkout procedures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-7
Confirm images restored to correct drives . . . . . . . . . . . . . . . . . . . . . . . . 11-7
Complete FRU checkout procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-7
Check proper operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-8
Reload process troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-8
Incorrect boot order . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-8
Software image on USB stick does not match hardware . . . . . . . . . . . . 11-9
12 Upgrade software . . . . . . . . . . . . . . . . . . . . . . . . . . 12-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-2
Establish alternate monitoring methods . . . . . . . . . . . . . . . . . . . . . . . . . . 12-3
Gather the required equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-3
Prepare the CIC Pro center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-3
Prepare the service PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-4
Connect the service PC to the CARESCAPE Network IX network . . . . . 12-4

2026419-033E CIC Pro™ ix
Start the software transfer utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-4
Enter the CARESCAPE Network IX network addresses of CIC Pro centers to
be updated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-5
Install the software on the target CIC Pro centers . . . . . . . . . . . . . . . . . . 12-6
Activate the software packages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-8
Complete the checkout procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-9
A Electromagnetic compatibility . . . . . . . . . . . . . . . . .A-1
Electromagnetic compatibility (EMC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Guidance and manufacturer’s declaration . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Electromagnetic emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Electromagnetic immunity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3
Recommended separation distances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-5
Compliant cables and accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-6
B Backup and restore - backed up data modules . . .B-1
Data module detail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
C Device compatibility . . . . . . . . . . . . . . . . . . . . . . . . .C-1
CIC Pro center v5.1.x compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-2
Central stations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-2
Telemetry devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-2
Bedside monitors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-2
Other GE systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-3

x CIC Pro™ 2026419-033E

2026419-033E CIC Pro™ 1-1
1 Introduction

1-2 CIC Pro™ 2026419-033E
Introduction
Equipment information
License agreement
It is important that you carefully read the terms and conditions of this license
agreement before commencing the use of the clinical information center workstation
(the “workstation”) and the clinical information center program recorded therein and
any accompanying user documentation (“program”). This license represents the entire
license agreement concerning the program between you and GE and supersedes all
other communications or advertising related to the program except any terms and
conditions of sale or warranties or warranty limitations relative to the program and/or
the workstation as may be embodied in any documentation supplied with the
workstation. By commencing the use of the workstation and the program contained
therein, you are accepting and agreeing to be bound by all the terms and conditions of
this license agreement. If you are not willing to be bound by the terms and conditions
of this license agreement, you should promptly return the workstation to GE and you
will receive a refund of the purchase price.
I. Grant
The Program is capable of coupling one to sixteen patient monitoring units to the
Workstation. GE hereby grants you a non-exclusive, non-transferable right and
license to use the Program for coupling the number of patient monitoring units to the
Workstation for which a per-unit royalty has been paid pursuant to Article II hereof.
II. Royalty
You have paid GE a one-time, per-unit royalty equal to GE Medical Systems
Information Technologies, Inc.’s current published price for the use of the Program.
The per-unit royalty is based on the actual number of patient monitors intended to be
coupled by the Program to the Workstation as stated in the Purchase Order for the
Workstation and the Program. If you use the Program to couple any patient
monitoring units to the Workstation in addition to the number for which a per unit
royalty was previously paid, you agree to pay GE an additional per-unit royalty equal
to GE Medical Systems Information Technologies, Inc.’s then current published
royalty for the Program for each such additional patient monitoring unit so coupled.
The additional per-unit royalty shall be paid to GE within 30 days of the use of the
Program to couple any such additional patient monitoring units to the Workstation.
III. Limitations
You hereby agree not to: (1) use the Program in any network or system other than to
couple patient monitoring units to the Workstation; (2) make any copy of the Program
for any reason, or allow or assist others to do so; (3) modify, reverse engineer, de-
compile or disassemble the Program or merge any part of the Program into any other
program; (4) rent, sell, sublease, assign, transfer or otherwise share the Program or
any of your rights in the Program under this Agreement with any third party; or, (5)
remove or alter any copyright notice, labels or trademarks from the Program or the
Workstation.

Introduction
2026419-033E CIC Pro™ 1-3
IV. Title
This License is not a sale. Title and all copyrights to the Program and any copy made
by you remains the sole property of GE.
V. Term
This Agreement shall continue in force until terminated. This Agreement shall
terminate automatically when you cease using the Workstation and the Program for
their intended purpose. GE may terminate this Agreement on 30 days written notice if
you make any unauthorized copies of the Program or fail to comply with any of the
restrictions on use of the Program as set forth herein.
VI. Limited warranty, disclaimer and limitation of liability
A. Licensor warrants that on the acceptance date the Program shall be free from
significant programming errors and shall operate and conform to the published
functional specifications applicable thereto, and that the Program shall conform to the
standards generally observed in the industry for similar software.
B. This warranty shall be invalidated by your modification of the Program if such
modification or the interaction between such modification and the Program as
supplied by GE is the cause of the defect, error or non-conformity.
C. Except as stated above, the warranty covering the Program and the Workstation
shall be either GE Standard Warranty or Limited Extended Parts Warranty as
published by GE and hereby made a part hereof.
D. Except for the express warranties stated herein, GE disclaims all warranties with
regard to the program including implied warranties of merchantability or fitness for a
particular purpose.
E. GE Medical Systems Information Technologies, Inc.’s entire liability to you arising
out of or in connection with this Agreement shall not exceed the per-unit royalty paid
to GE for use of the Program. You acknowledge that the amount paid to GE for use of
the Program is insufficient for GE to undertake any greater risk. In no event shall GE
be liable for any indirect, incidental, consequential, special or exemplary damages
(including without limitation, lost profits, business interruption, loss of business
information, personal injury or any other pecuniary loss) arising from the use of the
program, even if GE has been advised of the possibility of such damages.
VII. Governing law
This Agreement shall be governed by the laws of the State of Wisconsin.
VIII. Partial invalidity
If any provision of this Agreement is held invalid or unenforceable, the remaining
portions of the Agreement shall continue in full force and effect.

1-4 CIC Pro™ 2026419-033E
Introduction
Intended use of the equipment
The CIC Pro Clinical Information Center central station is intended for use under the
direct supervision of a licensed healthcare practitioner. The intended use is to provide
clinicians with adult, pediatric and neonatal patient data in a centralized location
within a hospital or clinical environment.
CIC Pro Clinical Information Center central station is intended to collect information
from a network and display this data. This data includes physiological, patient
demographic and/or other non-medical information. Physiological parameters and
waveforms from monitors and telemetry systems can be displayed and printed from
the CIC Pro Clinical Information Center central station. Beat to beat patient
information for all parameters and waveforms from the bedside and telemetry
systems can be displayed.
The CIC Pro Clinical Information Center central station supports the ability to access
information from the CIC Pro Clinical Information Center central stations’ products
in a web browser format. Additionally, the CIC Pro Clinical Information Center
central station supports the ability to access patient information collected from the
unity network and stored on a network server.
Safety information
The terms danger, warning, and caution are used throughout this manual to point out
hazards and to designate a degree or level of seriousness. Familiarize yourself with
their definitions and significance.
Hazard is defined as a source of potential injury to a person.
Danger indicates an imminent hazard, which, if not avoided, will result in death
or serious injury.
Warning indicates a potential hazard or unsafe practice, which, if not avoided,
could result in death or serious injury.
Caution indicates a potential hazard or unsafe practice, which, if not avoided,
could result in minor personal injury or product/property damage.
Note provides application tips or other useful information to assure that you get
the most from your equipment.
Dangers
No danger statements apply to this product.
Warnings
The following warnings apply to this product.

Introduction
2026419-033E CIC Pro™ 1-5
WARNING
ELECTRIC SHOCK— To avoid electric shock, the CIC Pro center
and its accessories should not be placed within the patient
environment, which is a volume related to an object (bed, chair,
table, treadmill, etc.) where a patient is intended to be diagnosed,
monitored, or treated.
WARNING
ACCESSORIES (SUPPLIES) — To ensure patient safety, use only
parts and accessories recommended by GE.
WARNING
ACCIDENTAL SPILLS — To avoid electric shock or device
malfunction, liquids must not be allowed to enter the device. If
liquids have entered a device, take it out of service and have it
checked by a service technician before it is used again.
WARNING
ACCURACY — If the accuracy of any value displayed on the
screen or printed on a graph strip is questionable, first determine the
patient's vital signs by alternative means. Then, verify the CIC Pro
center and printer are working correctly.
WARNING
ALARMS — Do NOT rely exclusively on the audible alarm system
for Bedside Monitoring. Adjustment of CIC Pro center alarm
volume to a low level or OFF during Bedside Monitoring may result
in inability to hear the alarm and a hazard to the patient. Remember
that the most reliable method of Bedside Monitoring combines close
personal surveillance with correct operation of monitoring
equipment.
After connecting the monitor to the central station and/or nurse-
alert, verify the function of the alarm system. Repeat this
verification periodically, including a check of all connected
speakers.
CIC Pro center audible alarms will not sound for patients with
bedside monitoring devices configured to “Operating Room” mode.
The functions of the alarm system for monitoring of the patient must
be verified at regular intervals. Check speaker volume periodically
to ensure audio alarm functionality.

1-6 CIC Pro™ 2026419-033E
Introduction
WARNING
BEFORE USE — Before putting the system into operation, visually
inspect all connecting cables for signs of damage. Damaged cables
and connectors must be replaced immediately.
Before using the system, the operator must verify that it is in correct
working order and operating condition.
Periodically, and whenever the integrity of the product is in doubt,
test all functions.
WARNING
DISCONNECTION FROM MAINS — When disconnecting the
system from the power line, remove the plug from the wall outlet
first. Then you may disconnect the power cord from the device. If
you do not observe this sequence, there is a risk of coming into
contact with line voltage by inserting metal objects, such as the pins
of leadwires, into the sockets of the power cord by mistake.
WARNING
DISPOSAL — Dispose of the packaging material, observing the
applicable waste control regulations and keeping it out of children’s
reach.
WARNING
EXPLOSION HAZARD — Do not use this equipment in the
presence of flammable anesthetics, vapors or liquids.
WARNING
INTERFACING OTHER EQUIPMENT — Devices may only be
interconnected with each other or to parts of the system when it has
been determined by qualified biomedical engineering personnel that
there is no danger to the patient, the operator, or the environment as
a result. The devices must comply with relevant IEC and ISO safety
standards.
Safe and proper operation should be verified with the applicable
manufacturer’s instructions for use.
WARNING
NETWORK INTEGRITY — The CIC Pro center can reside on the
hospital’s computer network, and it is possible that inadvertent or
malicious network activity could adversely affect patient
monitoring. The integrity of the computer network is the
responsibility of the hospital.

Introduction
2026419-033E CIC Pro™ 1-7
Cautions
The following cautions apply to this product.
CAUTION
EMC — Magnetic and electrical fields are capable of interfering
with the proper performance of the device. For this reason make sure
that all external devices operated in the vicinity of the monitor
comply with the relevant EMC requirements. X-ray equipment or
MRI devices are a possible source of interference as they may emit
higher levels of electromagnetic radiation.
CAUTION
EMC — Magnetic and electrical fields are capable of interfering
with the proper performance of the device. For this reason make sure
that all external devices operated in the vicinity of the monitor
comply with the relevant EMC requirements. X-ray equipment or
MRI devices are a possible source of interference as they may emit
higher levels of electromagnetic radiation.
Changes or modifications to this device/system not expressly
approved by GE may cause EMC issues with this or other
equipment. This device/system is designed and tested to comply
with applicable standards and regulations regarding EMC and needs
to be installed and put into service according to the EMC
information stated as follows:
Use of known RF sources, such as cell/portable phones, or other
radio frequency (RF) emitting equipment near the system may cause
unexpected or adverse operation of this device/system. Consult
qualified personnel regarding device/system configuration.
The device/system should not be used adjacent to, or stacked with,
other equipment. If adjacent or stacked use is necessary, the device/
system should be tested to verify normal operation in the
configuration in which it is being used. Consult qualified personnel
regarding device/system configuration.
The use of accessories, transducers and cables other than those
specified may result in increased emissions or decreased immunity
performance of the device/system.
This device/system is suitable for use in all establishments other
than domestic and those directly connected to the public low-voltage
power supply network that supplies buildings used for domestic
purposes. Mains power should be that of a typical commercial or
hospital environment.
Refer to the electromagnetic compatibility and guidelines in the
service manual for additional compliance and safety information.

1-8 CIC Pro™ 2026419-033E
Introduction
CAUTION
NEGLIGENCE — GE does not assume responsibility for damage to
the equipment caused by improperly vented cabinets, improper or
faulty power, or insufficient wall strength to support equipment
mounted on such walls.
CAUTION
POWER REQUIREMENTS — Before connecting the device to the
power line, check that the voltage and frequency ratings of the
power line are the same as those indicated on the unit’s label. If this
is not the case, do not connect the system to the power line until you
adjust the unit to match the power source.
In the USA, if the installation of the equipment will use 240V rather
than 120V, the source must be a center-tapped, single-phase circuit.
This equipment is suitable for connection to public mains as defined
in CISPR11/EN55011.
CAUTION
RESTRICTED SALE — U.S. federal law restricts this device to be
sold by or on the order of a physician.
CAUTION
SECURITY — The web browser which runs in conjunction with the
CIC Pro center is intended for hospital intranet use only. If
confidential patient information is made available from the hospital
intranet, the security of the data is the responsibility of the hospital.
CAUTION
SUPERVISED USE — This equipment is intended for use under the
direct supervision of a licensed health care practitioner.
CAUTION
During shutdown or while in administrator mode, beds displayed by
the CIC Pro center will be unmonitored if not displayed by a
different CIC Pro center.
Notes
The following notes apply to this product.
NOTE
This device is not intended for home use.
