GE NX-320E User manual

GE
Security
NetworXTM Series
NX-320E Remote Power Supply
Installation manual
g
imagination at work

NX-320E Installation manual Page 2 19/09/05

CONTENTS
CONTENTS .................................................................................................................................................................................... 3
GENERAL INFORMATION............................................................................................................................................................ 4
ORDERING INFORMATION ......................................................................................................................................................... 4
INSTALLING THE NX-320E.......................................................................................................................................................... 5
ENROLLING THE NX-320E REMOTE POWER SUPPLY............................................................................................................. 5
UNDERSTANDING THE LED’S..................................................................................................................................................... 5
PROGRAMMING THE NX-320E POWER SUPPLY...................................................................................................................... 6
PROGRAMMING THE NX-320E VIA THE LED KEYPAD..................................................................................................................................................6
ENTERING THE PROGRAM MODE.....................................................................................................................................................................6
SELECTING THE MODULE TO PROGRAM.......................................................................................................................................................6
PROGRAMMING A LOCATION.............................................................................................................................................................................6
EXITING A LOCATION .............................................................................................................................................................................................6
EXITING THE PROGRAM MODE..........................................................................................................................................................................7
PROGRAMMING THE NX-320E VIA THE LCD KEYPAD .................................................................................................................................................7
PROGRAMMING DATA.........................................................................................................................................................................................................8
PROGRAMMING THE LOCATIONS ............................................................................................................................................. 9
NX-320E PROGRAMMING WORKSHEETS...............................................................................................................................16
TERMINAL AND LED DESCRIPTIONS....................................................................................................................................... 20
NX-320E PRINT LAYOUT ...........................................................................................................................................................21
ENCLOSURE DIAGRAM..............................................................................................................................................................22
TECHNICAL SPECIFICATIONS...................................................................................................................................................23
CE DECLARATION ......................................................................................................................................................................24
NX-320E Installation manual Page 3 19/09/05

GENERAL INFORMATION
The NX-320E is a microprocessor controlled remote power supply module for the NETWORX
control panel range. The NX-320E has three (3) programmable outputs and one (1) dedicated
bell output. A maximum of four (4) NX-320E power supply modules can be added to the
NetworX control panel NX-8 and a maximum of eight (8) power supply modules can be added
to the NetworX control panel NX-8E. This means a total output count of 16 (32 for NX-8E), of
which 12 (24 for NX-8E) are programmable and 4 (8 for NX-8E) are dedicated bell outputs.
These 12 (24 for NX-8E) programmable outputs can be used as auxiliary power, smoke
detector power, siren driver power, etc. (see chart on page 8). Each NX-320E has a tamper
terminal that can be used to supervise the metal enclosure. When the NX-320E is connected
to the NetworX control panels, the maximum total wire run from the panel to all devices,
including the NX-320E, is 800 m. Additionally, the maximum total wire run from the NX-320E to
all outgoing devices is 800 m.
ORDERING INFORMATION
For detailed ordering information and part numbers, please refer to the EMEA Distribution
price list of the Caddx product range.
NX-320E Installation manual Page 4 19/09/05

INSTALLING THE NX-320E
The first thing that must be decided is the address of this particular power supply. This is the
address that will be selected when programming the NX-320E. To set the addresses use the
table below.
DIP switch 4 is used to disable the tamper feature of the NX-320E (“On” = enabled / “Off” =
disabled).
Location Dip switch 1 Dip switch 2 Dip switch 3
84 OFF OFF OFF
85 ON OFF OFF
86 OFF ON OFF
87 ON ON OFF
88 OFF OFF ON
89 ON OFF ON
90 OFF ON ON
91 ON ON ON
ENROLLING THE NX-320E REMOTE POWER SUPPLY
For supervision purposes, the presence of all keypads, zone expanders, wireless receivers,
output modules, and any other devices can automatically be found and stored in the panel’s
memory. To enroll the devices, enter the program mode for the NetworX control panel as
described on page 5. If necessary, go on to program the rest of the control panel and the
devices. When you exit from program mode, the control panel will automatically enroll the
devices. The enrolling process takes about 12 seconds, during which time a “Service”
indication will be displayed. If a module has been enrolled but it is not detected by the control,
the “Service” indication (LED or LCD screen) will be displayed.
UNDERSTANDING THE LED’S
The NX-320E has four (4) LED’s, which provide valuable information about the status of the
NX-320E. The following chart furnishes the indications of each LED.
LED Description
DS1 Flashes when data is transmitted out from the NX-320E
DS2 Flashes when data is transmitted into the NX-320E
DS3 Flashes during normal operation
DS4 Used for hardware, and will only glow dimly when connected to the NetworX
control panels
NX-320E Installation manual Page 5 19/09/05

PROGRAMMING THE NX-320E POWER SUPPLY
Programming the NX-320E via the LED keypad
ENTERING THE PROGRAM MODE
To enter the program mode, press [*]-[8]. At this time, the five functions LED’s (Stay, Chime,
Exit, Bypass and Cancel) will begin to flash. Next, enter the “Go To Program Code” (factory
default is [9]-[7]-[1]-[3]). If the “Go To Program Code” is valid, the “Service” LED will flash and
the five function LED’s will illuminate steady. You are now in the program mode and ready to
select the module to program.
Note : it is impossible to enter program mode if any partition or the system is armed.
SELECTING THE MODULE TO PROGRAM
Since all modules connected to the NetworX are programmed through the keypad, the
module you are programming should be the first entry. To program the NX-320E module,
enter the address of the NX-320E, followed by [#]. See DIP switch chart on page 4.
PROGRAMMING A LOCATION
Once the number of the module to be programmed has been entered, the “Armed” LED will
illuminate, indicating it is waiting for a programming location to be entered. Any location can
be accessed by directly entering the desired programming location followed by the pound [#]
key. If the location entered is a valid location, the “Armed” LED will extinguish, the “Ready” LED
will illuminate, and the zone LED’s will show the binary data for the first segment of this
location. While entering new data, the “Ready” LED will begin flashing to indicate a data
change in process. The flashing will continue until the new data is stored by pressing the [*]
key. Upon pressing the [*] key, the keypad will advance to the next segment and display its
data. This procedure is repeated until the last segment is reached. Pressing the [#] key will exit
from this location and the “Armed” LED will illuminate again waiting for a new programming
location to be entered. If the desired location is the next sequential location, press the [Police]
key. If the previous location is desired press the [Fire] key. If the same location is desired press
the [Medic] key. To review the data in a location, repeat the above procedure, pressing the [*]
key without any numeric data entry. Each time the [*] key is pressed, the programming data
of the next segment will be displayed for review.
EXITING A LOCATION
After the last segment of a location is programmed, pressing the [*] key will exit that location,
turn the “Ready” LED off and the “Armed” LED on. As before, you are now ready to enter
another programming location. If an attempt is made to program an invalid entry for a
particular segment, the keypad sounder will emit a triple error beep (beep, beep, beep) and
remain in that segment awaiting a valid entry.
NX-320E Installation manual Page 6 19/09/05

EXITING THE PROGRAM MODE
When all the desired changes in programming have been made, it is time to exit the program
mode. Pressing the [Exit] key will exit this programming level, and then return to the “Select a
Module to Program” level. If no additional modules are to be programmed, pressing the [Exit]
key again will exit the program mode. If there is a module to be programmed, it may be
selected by entering its address followed by the [#] key (see “Selecting the Module To
Program” above). The procedure for programming these devices is the same as for the control
panel, except the locations will be for the module selected.
Note: the timeout for the program mode is 15 minutes.
Programming the NX-320E via the LCD keypad
All steps required for programming are the same as the aforementioned LED keypad. The LCD
keypad display will prompt you for the data required. While in the programming mode, and
not in a location, the number in parenthesis is the location you were previously changing.
For example: if the display reads “Enter location, then # (5)”, it is reminding you that location 5
was the last location you programmed. Refer also to “Programming Data” which follows.
NX-320E Installation manual Page 7 19/09/05

Programming data
Programming data is always one of two types. One type of data is numerical, which can have
values from 0-15 or 0-255 depending on the segment size. The other type of data, feature
selection data, is used to turn features on or off. Use the following procedures with these two
data types:
NUMERICAL DATA: Numerical data is programmed by using the numeric keys of the system
keypad to enter a number from 0-255. To view the data in a location, a binary process is used.
With this process, the LED’s for zones 1 through 8 are utilized, and the numeric equivalents of
their illuminated LED’s are added together to determine the data in a programming location.
The numeric equivalents of these LED’s are as follows:
Zone 1 LED = 1 Zone 2 LED = 2 Zone 3 LED = 4 Zone 4 LED = 8
Zone 5 LED = 16 Zone 6 LED = 32 Zone 7 LED = 64 Zone 8 LED = 128
Example:
If the numerical data to be programmed in a location is “66”, press [6]-[6] on the keypad. The
LED’s for zone 2 and zone 7 will become illuminated indicating 66 is in that location (2 + 64 =
66).
Once the data is programmed, press the [*] key to enter the data and advance to the next
segment of that location. After the last segment of a location is programmed, pressing the [*]
key will exit that location, turn the “Ready” LED off and the “Armed” LED on. As before, you are
now ready to enter another programming location. If an attempt is made to program a
number too large for a particular segment, the keypad sounder will emit a triple beep,
indicating an error, and remain in that segment awaiting a valid entry.
Remark: on the LCD keypad, the number in the location will be displayed. For locations with a
maximum of 15, the hexadecimal equivalent will be displayed in parenthesis. Example: 11 (B)
or 14 (E).
FEATURE SELECTION DATA: Feature selection data will display the current condition (on or off)
of eight features associated with the programming location and segment selected. Pressing a
button on the keypad (1 through 8) that corresponds to the “feature number” within a
segment will toggle (on/off) that feature. Pressing any numeric key between [1] and [8] for
selection of a feature will make the corresponding LED illuminate (feature ON). Press the
number again, and the LED will extinguish (feature OFF). You will see that numerous features
can be selected from within one segment. For instance, if all eight features of a segment are
desired, pressing [1] - [2] - [3] - [4] - [5] - [6] - [7] - [8] will turn on LED’s 1 through 8 as you
press the keys, indicating that those features are enabled.
LCD keypad users note: the numbers of the enabled features will be displayed. However, the
features not enabled will display a hyphen (-).
After the desired setting of features is selected for this segment, press the [*] key. This will
enter the data and automatically advance to the next segment of the location. When you are
in the last segment of a location and press the [*] to enter the data, you will exit that location.
This will now turn the “Ready” LED off and the “Armed” LED on. As before, you are now ready
to enter another programming location.
NX-320E Installation manual Page 8 19/09/05

PROGRAMMING THE LOCATIONS
LOCATION 0 - PROGRAMMING THE EVENT, ZONE AND TIME FOR OUTPUT 1 (2 segments, numerical data)
Segment 1 - Event
Selects the event that will trigger the output. See chart below for the specific events that can
be selected.
Segment 2 - Time
Selects the amount of time an output will remain activated when an output triggers. If this
location is programmed as a zero, the output will follow the particular event.
Nr. Event Nr. Event Nr. Event
0 Always on 11 Smoke power reset 22 Disarmed
1 AC fail (control or expander).
Does not follow AC fail
delay time.
12 Yelping siren 23 Ready to arm
2 Low battery (control or
expander)
13 Steady siren 24 Not ready to arm
3 Dynamic battery test time 14 Any siren 25 Fire
4 Listen in 15 Steady siren (intermittent) 26 Fire trouble
5 Line seizure 16 Any siren (intermittent) 27 Chime
6 Telephone line fault 17 Alarm memory 28 Beeping keypad
7 Program mode 18 Entry 29 uKeypad function: fire
alarm
8 Over-current (control or
expander)
19 Exit 30 uKeypad function: medical
alarm
9 Box tamper (control or
expander)
20 Entry or exit 31 uPanic keypad function
10 Siren tamper (control or
expander)
21 Armed 32 uCode entry (set codes in
loc.8-17)
uIf set to follow condition, these events will be one second.
NX-320E Installation manual Page 9 19/09/05

LOCATION 1 - PROGRAMMING SPECIAL FUNCTIONS AND PARTITIONS FOR OUTPUT A (2 segments, feature
selection data)
Segment 1 - selects the following special conditions
Option Function
ON If output should time in minutes1
OFF If output times in seconds
ON Output “Latch”: should latch until a code is entered2
OFF Output is timed
ON Timed or output should be reset if a code is entered while it is being timed3
OFF Stays timed (not reset) after code is entered
4 ON For inverted output
5 ON Disables output during listen-in (only events 12-16)
6 Reserved
7 Reserved
8 Reserved
Segment 2 - selects the following partitions
Option Function
1 ON If the event should activate when it occurs in partition 1
2 ON If the event should activate when it occurs in partition 2
3 ON If the event should activate when it occurs in partition 3
4 ON If the event should activate when it occurs in partition 4
5 ON If the event should activate when it occurs in partition 5
6 ON If the event should activate when it occurs in partition 6
7 ON If the event should activate when it occurs in partition 7
8 ON If the event should activate when it occurs in partition 8
LOCATION 2 - PROGRAMMING THE EVENT AND TIME FOR OUTPUT B (2 segments, numerical data)
Segment 1 - event
Is used to program the particular event that will trigger the output. See chart on page 8 for the
specific events that can be selected.
Segment 2 - time
Is used to select the amount of time an output will remain activated when an output triggers.
If this location is programmed as a zero, the output will follow the particular event.
NX-320E Installation manual Page 10 19/09/05

LOCATION 3 - PROGRAMMING SPECIAL FUNCTIONS AND PARTITIONS FOR OUTPUT B (2 segments, feature
selection data)
Segment 1 - selects the following special conditions
Option Function
ON If output should time in minutes1
OFF If output times in seconds
ON Output “Latch”: should latch until a code is entered2
OFF Output is timed
ON Timed or output should be reset if a code is entered while it is being timed3
OFF Stays timed (not reset) after code is entered
4 ON For inverted output
5 ON Disables output during listen-in (only events 12-16)
6 Reserved
7 Reserved
8 Reserved
Segment 2 - selects the following partitions
Option Function
1 ON If the event should activate when it occurs in partition 1
2 ON If the event should activate when it occurs in partition 2
3 ON If the event should activate when it occurs in partition 3
4 ON If the event should activate when it occurs in partition 4
5 ON If the event should activate when it occurs in partition 5
6 ON If the event should activate when it occurs in partition 6
7 ON If the event should activate when it occurs in partition 7
8 ON If the event should activate when it occurs in partition 8
LOCATION 4 - PROGRAMMING THE EVENT AND TIME FOR OUTPUT C (2 segments, numerical data)
Segment 1 - event
Is used to program the particular event that will trigger the output. See chart on page 8 for the
specific events that can be selected.
Segment 2 - time
Is used to select the amount of time an output will remain activated when an output triggers.
If this location is programmed as a zero, the output will follow the particular event.
NX-320E Installation manual Page 11 19/09/05

LOCATION 5 - PROGRAMMING SPECIAL FUNCTIONS AND PARTITIONS FOR OUTPUT C (2 segments, feature
selection data)
Segment 1 - selects the following special conditions
Option Function
ON If output should time in minutes1
OFF If output times in seconds
ON Output “Latch”: should latch until a code is entered2
OFF Output is timed
ON Timed or output should be reset if a code is entered while it is being timed3
OFF Stays timed (not reset) after code is entered
4 ON For inverted output
5 ON Disables output during listen-in (only events 12-16)
6 Reserved
7 Reserved
8 Reserved
Segment 2 - selects the following partitions
Option Function
1 ON If the event should activate when it occurs in partition 1
2 ON If the event should activate when it occurs in partition 2
3 ON If the event should activate when it occurs in partition 3
4 ON If the event should activate when it occurs in partition 4
5 ON If the event should activate when it occurs in partition 5
6 ON If the event should activate when it occurs in partition 6
7 ON If the event should activate when it occurs in partition 7
8 ON If the event should activate when it occurs in partition 8
LOCATIONS 6 & 7 - RESERVED
LOCATION 8 - AUTHORIZING USERS 1 - 10 TO TRIGGER OUTPUTS A-C (10 segments, feature selection data)
When activating outputs with a user code (event 30), location 8 can be used to restrict certain
codes from activating certain outputs. Location 8 contains 10 segments. Segment 1
corresponds to user 1, segment 10 corresponds to user 10. The LED’s correspond to outputs A
- C.
Option Function
ON Code will activate Output A1
OFF Code will NOT activate output A
ON Code will activate Output B2
OFF Code will NOT activate output B
ON Code will activate Output C3
OFF Code will NOT activate output C
4-8 Reserved
NX-320E Installation manual Page 12 19/09/05

LOCATION 9 - AUTHORIZING USERS 11 - 20 TO TRIGGER OUTPUTS A-C (10 segments, feature selection data)
When activating outputs with a user code (event 30), location 9 can be used to restrict certain
codes from activating certain outputs. Location 9 contains 10 segments. Segment 1
corresponds to user 11, segment 10 corresponds to user 20. The LED’s correspond to outputs
A - C.
Refer to location 8 chart.
LOCATION 10 - AUTHORIZING USERS 21 - 30 TO TRIGGER OUTPUTS A-C (10 segments, feature selection data)
When activating outputs with a user code (event 30), location 10 can be used to restrict
certain codes from activating certain outputs. Location 10 contains 10 segments. Segment 1
corresponds to user 21, segment 10 corresponds to user 30. The LED’s correspond to outputs
A - C.
Refer to location 8 chart.
LOCATION 11 - AUTHORIZING USERS 31 - 40 TO TRIGGER OUTPUTS A-C (10 segments, feature selection data)
When activating outputs with a user code (event 30), location 11 can be used to restrict
certain codes from activating certain outputs. Location 11 contains 10 segments. Segment 1
corresponds to user 31, segment 10 corresponds to user 40. The LED’s correspond to outputs
A - C.
Refer to location 8 chart.
LOCATION 12 - AUTHORIZING USERS 41-50 TO TRIGGER OUTPUTS A-C (10 segments, feature selection data)
When activating outputs with a user code (event 30), location 12 can be used to restrict
certain codes from activating certain outputs. Location 12 contains 10 segments. Segment 1
corresponds to user 41, segment 10 corresponds to user 50. The LED’s correspond to outputs
A - C.
Refer to location 8 chart.
LOCATION 13 - AUTHORIZING USERS 51-60 TO TRIGGER OUTPUTS A-C (10 segments, feature selection data)
When activating outputs with a user code (event 30), location 13 can be used to restrict
certain codes from activating certain outputs. Location 13 contains 10 segments. Segment 1
corresponds to user 51, segment 10 corresponds to user 60. The LED’s correspond to outputs
A - C.
Refer to location 8 chart.
NX-320E Installation manual Page 13 19/09/05

LOCATION 14 - AUTHORIZING USERS 61-70 TO TRIGGER OUTPUTS A-C (10 segments, feature selection data)
When activating outputs with a user code (event 30), location 14 can be used to restrict
certain codes from activating certain outputs. Location 14 contains 10 segments. Segment 1
corresponds to user 61, segment 10 corresponds to user 70. The LED’s correspond to outputs
A - C.
Refer to location 8 chart.
LOCATION 15 - AUTHORIZING USERS 71-80 TO TRIGGER OUTPUTS A-C (10 segments, feature selection data)
When activating outputs with a user code (event 30), location 15 can be used to restrict
certain codes from activating certain outputs. Location 15 contains 10 segments. Segment 1
corresponds to user 71, segment 10 corresponds to user 80. The LED’s correspond to outputs
A - C.
Refer to location 8 chart.
LOCATION 16 - AUTHORIZING USERS 81-90 TO TRIGGER OUTPUTS A-C (10 segments, feature selection data)
When activating outputs with a user code (event 30), location 16 can be used to restrict
certain codes from activating certain outputs. Location 16 contains 10 segments. Segment 1
corresponds to user 81, segment 10 corresponds to user 90. The LED’s correspond to outputs
A - C.
Refer to location 8 chart.
LOCATION 17 - AUTHORIZING USERS 91-99 TO TRIGGER OUTPUTS A-C (10 segments, feature selection data)
When activating outputs with a user code (event 30), location 17 can be used to restrict
certain codes from activating certain outputs. Location 17 contains 10 segments. Segment 1
corresponds to user 91, segment 10 corresponds to user 99. The LED’s correspond to outputs
A - C.
Refer to location 8 chart.
LOCATION 18 - A/C DELAY AND DYNAMIC BATTERY TEST (2 segments, feature selection data)
Location 18 is used to enable the A/C delay and the dynamic battery test, both of which are
timed in minutes. The factory default is 5-0, meaning the A/C power will be off for 5 minutes
before a report is sent or a service indication will be given, and the dynamic battery test is
disabled (“0” minutes). If you desire the A/C delay to be 8 minutes and the dynamic battery
test to be 3 minutes, you would program 8-3.
NX-320E Installation manual Page 14 19/09/05

LOCATION 19 - DEVICE OPTIONS (8 segments, feature selection data)
Location 19 is used to enable various system features of the NX-320E power supply.
Option Function
ON AC report always
sent
1
OFF Follows control
panel
If enabled, an AC Fail report will be sent if power is lost
for the time programmed in location 18. If “off”, the
report will only be sent if the control panel has not sent
an AC power lost report, and AC fail report is enabled in
location 37 of the control panel.
2 ON Enables periodic battery test.
Enables battery missing every 30 seconds.
3 ON Enables low battery test.
If enabled, the NX-320E will report low battery to the central station.
4 ON Enables siren tamper/trouble reporting.
If enabled, the NX-320E will report a siren tamper to the central station.
5-8 Reserved
NX-320E Installation manual Page 15 19/09/05

NX-320E PROGRAMMING WORKSHEETS
(Defaults are printed in bold italic text)
At default: Output A = AUX power, Output B = AUX power, Output C = smoke power
LOC PG DESCRIPTION DEFAULT PROGRAMMING DATA
0 9 OUTPUT A: EVENT & TIME 0 10
OUTPUT A: SPECIAL FEATURES & PARTITIONS
Segment 1 (Circle Numbers To Program)
1 ON: if timed in minutes. OFF: if timed is seconds
2 ON: If latched until code is entered. OFF: for timed
3 ON: If output should stop timing when a code is entered. OFF: timed
4 ON: for inverted output
5 ON: disables output during listen-in
6 Reserved
7 Reserved
8 Reserved
Segment 2 (Circle Numbers To Program)
1 Partition 1
2 Partition 2
3 Partition 3
4 Partition 4
5 Partition 5
6 Partition 6
7 Partition 7
1 10
8 Partition 8
2 10 OUTPUT B: EVENT & TIME 0 10
OUTPUT B: SPECIAL FEATURES & PARTITIONS
Segment 1 (Circle Numbers To Program)
1 ON: if timed in minutes. OFF: if timed is seconds
2 ON: If latched until code is entered. OFF: for timed
3 ON: If output should stop timing when a code is entered. OFF: timed
4 ON: for inverted output
5 ON: disables output during listen-in
6 Reserved
7 Reserved
8 Reserved
Segment 2 (Circle Numbers To Program)
1 Partition 1
2 Partition 2
3 Partition 3
4 Partition 4
5 Partition 5
6 Partition 6
7 Partition 7
3 11
8 Partition 8
NX-320E Installation manual Page 16 19/09/05

LOC PG DESCRIPTION DEFAULT PROGRAMMING DATA
4 11 OUTPUT C: EVENT & TIME 11 8
OUTPUT C: SPECIAL FEATURES & PARTITIONS
Segment 1 (Circle Numbers To Program)
1 ON: if timed in minutes. OFF: if timed is seconds
2 ON: If latched until code is entered. OFF: for timed
3 ON: If output should stop timing when a code is entered. OFF: timed
4 ON: for inverted output
5 ON: disables output during listen-in
6 Reserved
7 Reserved
8 Reserved
Segment 2 (Circle Numbers To Program)
1 Partition 1
2 Partition 2
3 Partition 3
4 Partition 4
5 Partition 5
6 Partition 6
7 Partition 7
5 12
8 Partition 8
6-7 12 Reserved
NX-320E Installation manual Page 17 19/09/05

Codes 1-10 Output enable (circle the numbers to program)
User 1 2 3 4 5 6 7 8 9 10
Output A 1 1 1 1 1 1 1 1 1 1
Output B 2 2 2 2 2 2 2 2 2 2
8 12
Output C 3 3 3 3 3 3 3 3 3 3
Codes 11-20 Output enable (circle the numbers to program)
User 11 12 13 14 15 16 17 18 19 20
Output A 1 1 1 1 1 1 1 1 1 1
Output B 2 2 2 2 2 2 2 2 2 2
9 13
Output C 3 3 3 3 3 3 3 3 3 3
Codes 21-30 Output enable (circle the numbers to program)
User 21 22 23 24 25 26 27 28 29 30
Output A 1 1 1 1 1 1 1 1 1 1
Output B 2 2 2 2 2 2 2 2 2 2
10 13
Output C 3 3 3 3 3 3 3 3 3 3
Codes 31-40 Output enable (circle the numbers to program)
User 31 32 33 34 35 36 37 38 39 40
Output A 1 1 1 1 1 1 1 1 1 1
Output B 2 2 2 2 2 2 2 2 2 2
11 13
Output C 3 3 3 3 3 3 3 3 3 3
Codes 41-50 Output enable (circle the numbers to program)
User 41 42 43 44 45 46 47 48 49 50
Output A 1 1 1 1 1 1 1 1 1 1
Output B 2 2 2 2 2 2 2 2 2 2
12 13
Output C 3 3 3 3 3 3 3 3 3 3
Codes 51-60 Output enable (circle the numbers to program)
User 51 52 53 54 55 56 57 58 59 60
Output A 1 1 1 1 1 1 1 1 1 1
Output B 2 2 2 2 2 2 2 2 2 2
13 13
Output C 3 3 3 3 3 3 3 3 3 3
Codes 61-70 Output enable (circle the numbers to program)
User 61 62 63 64 65 66 67 68 69 70
Output A 1 1 1 1 1 1 1 1 1 1
Output B 2 2 2 2 2 2 2 2 2 2
14 14
Output C 3 3 3 3 3 3 3 3 3 3
Codes 71-80 Output enable (circle the numbers to program)
User 71 72 73 74 75 76 77 78 79 80
Output A 1 1 1 1 1 1 1 1 1 1
Output B 2 2 2 2 2 2 2 2 2 2
15 14
Output C 3 3 3 3 3 3 3 3 3 3
Codes 81-90 Output enable (circle the numbers to program)
User 81 82 83 84 85 86 87 88 89 90
Output A 1 1 1 1 1 1 1 1 1 1
Output B 2 2 2 2 2 2 2 2 2 2
16 14
Output C 3 3 3 3 3 3 3 3 3 3
Codes 91-99 Output enable (circle the numbers to program)
User 91 92 93 94 95 96 97 98 99
Output A 1 1 1 1 1 1 1 1 1
Output B 2 2 2 2 2 2 2 2 2
17 14
Output C 3 3 3 3 3 3 3 3 3
NX-320E Installation manual Page 18 19/09/05

LOC PG DESCRIPTION DEFAULT PROGRAMMING DATA
18 14 A/C delay (in minutes)
Dynamic battery test (in minutes)
5
0
Device options (circle the numbers to program)
1 On for AC report always sent; Off follows control
2 On enables periodic battery test
3 On enables low battery reporting
4 On enables siren tamper/trouble reporting
5 Reserved
6 Reserved
7 Reserved
19 15
8 Reserved
NX-320E Installation manual Page 19 19/09/05

TERMINAL AND LED DESCRIPTIONS
Terminal Description
DATA Connect to the control panel data terminal. This terminal is the incoming data-
signalling terminal to the NX-320E. The maximum total wire run from the control
panel to all devices, including the NX-320E is 800 m.
COM Connect to the control panel COMMON terminal. This terminal supplies the
common side of the power to the NX-320E board.
POS Connect to control panel AUX POWER + terminal. This terminal supplies power to
the NX-320E board.
DATA This terminal is the outgoing data-signalling terminal for buss extension. The
maximum total wire run from the NX-320E to all outgoing devices is 800 m.
COM Common terminal for any device powered from the NX-320E.
OUT A Programmable output current limited to 1.5 Amps.
NOTE: the total current of the NX-320E is 2.5 Amps.
OUT B Programmable output current limited to 1.5 Amps.
COM Common terminal for any device powered from the NX-320E.
OUT C Programmable output current limited to 1.5 Amps.
BELL + Positive of bell output current limited to 2.0 Amps. Connect as in diagram on page
20.
BELL - Negative of bell output current limited to 2.0 Amps. Connect as in diagram on
page 20.
TAM This is an optional tamper terminal. To use this feature, connect the normally
closed tamper switch between this terminal and COM. If switch 4 is off, this
feature is not used.
EARTH Earth ground.
AC AC input. Connect to a 16.5V 40 VA transformer.
AC AC input. Connect to a 16.5V 40 VA transformer.
LED Description
DS1 Flashes when data is transmitted out from the NX-320E.
DS2 Flashes when data is transmitted into the NX-320E.
DS3 Flashes during normal operation.
DS4 Used for hardware, and will only glow dimly when connected to the NX-8 / NX-8E
control panel.
NX-320E Installation manual Page 20 19/09/05
