GE Tetra GEPS24-180U User manual

• Supports Tetra PowerStrip DS, Tetra miniStrip DS, Tetra EdgeStrip,
Tetra Contour and Tetra Contour LS LED lighting systems
• Class 2 wiring per NEC Article 725 (SELV)
• Damp location rated
• IP66 rated: separate enclosure required
(GEPS24-180U)
Tetra® LED Systems Power Supply
24
Volt
GE
Lighting Solutions
Installation Guide
imagination at work
Power Supply Features
Power Supply Installation
RISK OF ELECTRIC SHOCK:
• Disconnect power at fuse box or circuit breaker before servicing or
installing product.
• Properly ground Tetra® power supply.
RISK OF FIRE:
• Use only Tetra® supply wire to make connection from Tetra® power
supply to Tetra® LED strip.
• Use only approved wire for input/output connection.
Minimum size 18 AWG (0.82 mm2)
• Follow all local codes.
RISQUES DE DÉCHARGES ÉLECTRIQUES
• Coupez l’alimentation électrique à la boîte de fusibles ou au
disjoncteur avant l’entretien ou l’installation du produit.
• Assurez-vous de correctement mettre à terre l’alimentation
électrique Tetra®.
RISQUES D’INCENDIE
• N’utilisez que le l d’approvisionnement Tetra® pour faire la
connexion entre l’alimentation Tetra® et la bande DEL Tetra®.
• N’utilisez que des ls approuvés pour les entrées/sorties de
connexion. Taille minimum 18 AWG (0.82 mm2).
• Respectez tous les codes locaux.
BEFORE YOU BEGIN
Read these instructions completely and carefully.
WARNING/AVERTISSEMENT
Connect the supply wire that is
attached to your LED system to the
red (+) and black (-) output wires
of the LED driver as outlined in the
“Electrical Connections” section
of your LED system’s Installation
Instructions.
2
Mount LED driver and remove
junction box cover. Carefully remove
knockout for AC line input wires. Install
appropriate electrical ttings in the
knockout holes for wire protection.
Connect the AC line to the black
(line) and white (neutral) input
wires of the LED driver using
18-14 AWG (0.82-2.08 mm2)
twist-on wire connectors.
Ground LED driver by connecting
green wire with yellow stripe
to grounding screw. Replace
junction box cover.
1
White (neutral) Black (line)
Green with
yellow
stripe
(ground)
AC line
3
To LED system
Output wires

NOTE: For CSA approval, a disconnect/toggle switch of appropriate rating needs to be placed within 29.5 ft. (9 m) of primary side of the
power supply. The minimum rating of the switch must be either 120 or 220 Volts AC. The switch must also support twice the amount of
input current.
NOTE: When installing power supply, connect to the appropriate sized building breaker or disconnect device for line and neutral
connections, in accordance with local, state or country regulations.
NOTE: Exceeding maximum load will cause the power supply to shut down. Once the excess load is removed, cycle the input power to
restart the power supply.
SIGN081-R012412
Power Supply Specications
Conforms to the following standards:
* Maximum case temperature is 80°C
Performance Data Min Typical Max
Input Voltage (VAC) 90 100-277 305
Input Frequency (Hz) - 50/60 -
Input Current (A) 0.7 - 2.5
Output Voltage (VDC) 23.25 24.0 24.75
Output Current (ADC) - - 3.8
Output Power (W) - - 180
Environmental Operating Temperature Range -40°C +25°C +60°C*
Environmental Humidity (non-condensing) 0% - 95%
Environmental Storage Temperature Range -40°C - +85°C
Dimensions 15.5 in. x 2.5 in. x 1.6 in. (392 mm x 62 mm x 40 mm)
Supports
Tetra
Products SKUs
Maximum Load
per Power Supply
Remote Mounting Distance
18 AWG/
0.82 mm2
16 AWG/
1.31 mm2
14 AWG/
2.08 mm2
12 AWG/
3.31 mm2
Tetra
PowerStrip DS
GEWHDSPS6, GEWWDSPS6-50K,
GEWWDSPS6-41K, GEWWDSPS6
14 modules/19.3 ft. (5.86 m) per bank;
28 modules/38.5 ft. (11.73 m) per PS 20 ft./6.1 m 25 ft./7.6 m 35 ft./10.6 m 40 ft./12.1 m
Tetra
miniStrip DS
GEWHBDP6, GEWWBDP6-50K,
GEWWBDP6-41K, GEWWBDP6
35 modules/35 ft. (10.67 m) per bank;
70 modules/70 ft. (21.34 m) per PS 20 ft./6.1 m 25 ft./7.6 m 35 ft./10.6 m 40 ft./12.1 m
Tetra
EdgeStrip
GEWHBIP2, GEWWBIP2-50K,
GEWWBIP2-41K, GEWWBIP2
33 modules/33 ft. (10.06 m) per bank;
66 modules/66 ft. (20.12 m) per PS 20 ft./6.1 m 25 ft./7.6 m 35 ft./10.6 m 40 ft./12.1 m
Tetra
Contour LS
GEWHXNLA2-WH, GEBLXNLA2-BL,
GEGLXNLA2-GL, GERDXNLA2-RD,
GEWHXNAA2-WH, GEBLXNAA2-BL,
GEGLXNAA2-GL, GERDXNAA2-RD,
27 ft. (8.23 m) per bank;
54 ft. (16.46 m) per PS 30 ft./9.1 m 50 ft./15.2 m 80 ft./24.4 m 120 ft./36.6 m
Tetra Contour GEWHXNLE1, GEWWXNLE1,
GEBLXNLE1, GEGLXNLE1,
GERDXNLE1, GERCXNLE1,
GEYAXNLE1
27 ft. (8.23 m) per bank;
54 ft. (16.46 m) per PS 30 ft./9.1 m 50 ft./15.2 m 80 ft./24.4 m 120 ft./36.6 m
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation. This Class [A] RFLD complies with the Canadian standard ICES-005. Ce DEFR de la classe [ A ] est conforme à la NMB-005 du Canada.
GE Lighting Solutions • 1-888-MY-GE-LED • www.gelightingsolutions.com
1 - 8 8 8 - 6 9 - 4 3 - 5 3 3
GE Lighting Solutions, LLC is a subsidiary of the General Electric Company. Tetra is a trademark of GE Lighting Solutions, LLC. The GE brand and logo are trademarks of the General Electric Company.
© 2012 GE Lighting Solutions, LLC. Information provided is subject to change without notice. All values are design or typical values when measured under laboratory conditions.
