GE Infinity M Series User manual

Energy Connections
Installation Guide
Service and Assistance - [phone] [e-mail]
© 2017 General Electric Company. All rights reserved. www.gecriticalpower.com
850050111 Issue 03 August 2017 1
H5692448 Power Systems
Infinity M1(NE-M)
High Capacity
With
Horizontal Distribution
NE-M systems with left and right vertical distribution use installation guide document CC848815325.
1Trademark of General Electric Company
13 U System
with Galaxy Pulsar
Plus Controller
22U System
with Galaxy
Millennium II
Controller
22U System with Supplemental Frame
and Galaxy Millennium II Controller
Initial Frame
Supplemental Frame

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 2
Table of Contents
Table of Contents............................................................................................................................................................................................................................. 2
Table of Figures.................................................................................................................................................................................................................................4
Table of Tables................................................................................................................................................................................................................................... 5
Introduction........................................................................................................................................................................................................................................ 6
Reference Documents.......................................................................................................................................................................................................... 6
Contact Information.............................................................................................................................................................................................................. 6
Product Description........................................................................................................................................................................................................................ 7
Components............................................................................................................................................................................................................................10
Installation ........................................................................................................................................................................................................................................16
Preparation..............................................................................................................................................................................................................................16
Safety ................................................................................................................................................................................................................................16
Installation Tools .........................................................................................................................................................................................................16
Equipment Identification.........................................................................................................................................................................................16
Anchor Frame.........................................................................................................................................................................................................................17
Floor Mounted Frame................................................................................................................................................................................................17
Battery or Battery Stand Mounted Frame.......................................................................................................................................................18
Sub-frame Mounted Systems:...............................................................................................................................................................................18
Ground Frame ........................................................................................................................................................................................................................19
Floor Mounted Frame................................................................................................................................................................................................19
Battery or Battery Stand Mounted Frame.......................................................................................................................................................19
Connect Central Office Ground (COG)........................................................................................................................................................................20
Connect Supplemental Frame........................................................................................................................................................................................20
Connect Interframe Bus Bars ................................................................................................................................................................................21
Connect Interframe Secondary Voltage Cables............................................................................................................................................22
Connect Interframe Signal Cables.......................................................................................................................................................................24
Set Supplemental Frame ID on BIC 10..............................................................................................................................................................27
Install PV/AC Partition Kit – NE-M Eco systems only...........................................................................................................................................27
Connect Input Power..........................................................................................................................................................................................................30
Install Battery Trays.............................................................................................................................................................................................................33
Install Batteries .....................................................................................................................................................................................................................33
Tray Mounted Batteries............................................................................................................................................................................................33
External Batteries .......................................................................................................................................................................................................34
Connect Batteries.................................................................................................................................................................................................................35
Connect Tray Mounted Batteries.........................................................................................................................................................................35
Connect External Batteries ....................................................................................................................................................................................40
Connect Battery Probes...........................................................................................................................................................................................41
Verify Battery Bus Voltage and Polarity.....................................................................................................................................................................41
Connect Load Wiring ..........................................................................................................................................................................................................41
Verify Installation..................................................................................................................................................................................................................47
Install Controller ...................................................................................................................................................................................................................48
Install Pulsar Plus ........................................................................................................................................................................................................48
Install Millennium II ....................................................................................................................................................................................................54
Install BSM6 Modem..................................................................................................................................................................................................58
Install Optional Controller Peripherals .............................................................................................................................................................58
Install Rectifiers/Converters............................................................................................................................................................................................58
Install Rectifiers ...........................................................................................................................................................................................................60
Verify Rectifier Positions..........................................................................................................................................................................................61
Install Converters........................................................................................................................................................................................................62
Install Battery Voltage Temp (VT)-Probes.................................................................................................................................................................62
Install Aux Display (NE830A) Alarm Cable (Optional)..........................................................................................................................................62
Configure Controller – Minimum...................................................................................................................................................................................63
Configure Pulsar Controller....................................................................................................................................................................................63
Configure Millennium II Controller......................................................................................................................................................................65
Acceptance Testing.......................................................................................................................................................................................................................68
Troubleshooting..............................................................................................................................................................................................................................71
System .......................................................................................................................................................................................................................................71
Rectifiers/Converters..........................................................................................................................................................................................................78
Voltage Temp (VT)-Probes................................................................................................................................................................................................79

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 3
Specifications and Application ................................................................................................................................................................................................80
Millennium II Alarm & Control Signals ........................................................................................................................................................................81
Fuse Alarm Major (FAJ) - BSL-63 .........................................................................................................................................................................84
Fuse Alarm Minor (FAN) - BSL-65 ........................................................................................................................................................................84
Open String Alarm (OS) - BSL-72 .........................................................................................................................................................................84
Aux Major (AMJ) - BSL-64........................................................................................................................................................................................84
Aux Minor (AMN) - BSL-66.......................................................................................................................................................................................84
Low Voltage Disconnect Active (LVD1) - BSL-84..........................................................................................................................................84
Low Voltage Disconnect Active (LVD2/LVD2R) - BSL-61/62 ...................................................................................................................84
External Boost Option (TFLT/TBST/PBT) - BSL-67-69.................................................................................................................................84
Rectifier Hold OFF on Engine Option (RO/ROR) - BSL-77-78..................................................................................................................84
Rectifier External Sequence Option (TR1-TR4) - BSL-73/79/85/80......................................................................................................85
Safety...................................................................................................................................................................................................................................................86
Deutsch............................................................................................................................................................................................................................88
Español.............................................................................................................................................................................................................................89
Revision History..............................................................................................................................................................................................................................90

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 4
Table of Figures
Figure 1 Block Diagram..................................................................................................................................................................................................................9
Figure 2 NE-M Components..................................................................................................................................................................................................... 10
Figure 3 Pulsar Front Panel ...................................................................................................................................................................................................... 11
Figure 4 Millennium II Controller Front Panel.................................................................................................................................................................. 11
Figure 5 NE830 Display .............................................................................................................................................................................................................. 12
Figure 6 Rectifier and Converter Type Badge .................................................................................................................................................................. 12
Figure 7 Power Input Panel ...................................................................................................................................................................................................... 14
Figure 8 Battery Stand................................................................................................................................................................................................................ 14
Figure 9 DC Distribution 4 Bullet Panels............................................................................................................................................................................ 15
Figure 10 DC Distribution – Bolt In Panel with return bar......................................................................................................................................... 15
Figure 11 NE-M System – 22U ................................................................................................................................................................................................ 15
Figure 12 Frame Mount Footprint......................................................................................................................................................................................... 17
Figure 13 Battery Stand Mount.............................................................................................................................................................................................. 18
Figure 14 Mount Sub-Frame.................................................................................................................................................................................................... 18
Figure 15 Ground Frame............................................................................................................................................................................................................ 19
Figure 16 Ground Short Frame............................................................................................................................................................................................... 19
Figure 17 CO Ground Landing................................................................................................................................................................................................. 20
Figure 18 Supplemental Frame.............................................................................................................................................................................................. 20
Figure 19 Interframe Bus Bars................................................................................................................................................................................................ 21
Figure 20 L635L Dual Voltage Panel Location................................................................................................................................................................. 22
Figure 21 Secondary Voltage Bus.......................................................................................................................................................................................... 22
Figure 22 Interframe Cables .................................................................................................................................................................................................... 24
Figure 23 Breaker Panel Alarm Connections................................................................................................................................................................... 25
Figure 24 RPM Connections..................................................................................................................................................................................................... 26
Figure 25 Set Frame ID on BIC 10.......................................................................................................................................................................................... 27
Figure 26 Eco Input Panel.......................................................................................................................................................................................................... 27
Figure 27 Input Panel Screws.................................................................................................................................................................................................. 28
Figure 28 Partition Labels ......................................................................................................................................................................................................... 28
Figure 29 Partition Insert .......................................................................................................................................................................................................... 29
Figure 30 Label Input Panel...................................................................................................................................................................................................... 29
Figure 31 Label Input Panel Cover ........................................................................................................................................................................................ 29
Figure 32 Input Power Terminal Block Positions ........................................................................................................................................................... 30
Figure 33 Rectifier / Converter and Shelf Numbering.................................................................................................................................................. 30
Figure 34 Rectifier Dual Feed Jumper Positions – ac feeds only............................................................................................................................ 30
Figure 35 Input Conduit Locations........................................................................................................................................................................................ 31
Figure 36 Input Jumper Dividers ........................................................................................................................................................................................... 31
Figure 37 AC Bridging Jumper ................................................................................................................................................................................................ 31
Figure 38 Input Panel Sections............................................................................................................................................................................................... 32
Figure 39 Battery Trays .............................................................................................................................................................................................................. 33
Figure 40 Batteries in Tray – 48V........................................................................................................................................................................................... 33
Figure 41 Place Batteries........................................................................................................................................................................................................... 34
Figure 42 Battery Inter-Cell Bus Bars .................................................................................................................................................................................. 34
Figure 43 Battery Disconnect Switch .................................................................................................................................................................................. 35
Figure 44 Batt Disconnect Switch Input Bus.................................................................................................................................................................... 35
Figure 45 Battery Cable -48V .................................................................................................................................................................................................. 36
Figure 46 Battery Cable +24V ................................................................................................................................................................................................. 36
Figure 47 Battery Return Cable -48V................................................................................................................................................................................... 37
Figure 48 Battery Return Cable +24V.................................................................................................................................................................................. 37
Figure 49 Anderson Battery Connector ............................................................................................................................................................................. 38
Figure 50 Battery Connections - Anderson ...................................................................................................................................................................... 38
Figure 51 Battery Cable Direct -48V .................................................................................................................................................................................... 39
Figure 52 Battery Cable Direct +24V ................................................................................................................................................................................... 39
Figure 53 Battery Return Cable Direct -48V..................................................................................................................................................................... 39
Figure 54 Battery Return Cable Direct +24V.................................................................................................................................................................... 40
Figure 55 External Battery Connections............................................................................................................................................................................ 40
Figure 56 Battery Additional Landings................................................................................................................................................................................ 40
Figure 57 Battery and Return Bus Lug Spacers .............................................................................................................................................................. 40
Figure 58 Battery Bus Labels................................................................................................................................................................................................... 41

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 5
Figure 59 Bullet Distribution Panel - Selectable Voltage ........................................................................................................................................... 42
Figure 60 2-Pole and 3-Pole Breaker Install..................................................................................................................................................................... 43
Figure 61 GMT Fuse Module..................................................................................................................................................................................................... 44
Figure 62 Bolt-In Breaker or Fuse Holder Mounting..................................................................................................................................................... 45
Figure 63 Bolt-in TPL-C Fuse Holder Wiring..................................................................................................................................................................... 45
Figure 64 Bolt-in Breaker Wiring ........................................................................................................................................................................................... 45
Figure 65 Bolt-in Position Return Bar.................................................................................................................................................................................. 46
Figure 66 850038647 Alarm Cable ....................................................................................................................................................................................... 46
Figure 67 Rectifier Positions.................................................................................................................................................................................................... 47
Figure 68 ESD Grounding Connector................................................................................................................................................................................... 48
Figure 69 Alarm Relay Jumpers – Pulsar Plus ................................................................................................................................................................. 48
Figure 70 Alarm Relay Jumper Positions - Pulsar Plus................................................................................................................................................ 49
Figure 71 1-Wire Jumper - Pulsar Plus ............................................................................................................................................................................... 50
Figure 72 Controller Connections......................................................................................................................................................................................... 50
Figure 73 Local Port - Pulsar Plus.......................................................................................................................................................................................... 54
Figure 74 ESD Grounding Connector................................................................................................................................................................................... 54
Figure 75 Millennium II Circuit Card..................................................................................................................................................................................... 55
Figure 76 Controller Connections......................................................................................................................................................................................... 55
Figure 77 Alarm Connections Millennium II ..................................................................................................................................................................... 57
Figure 78 RS232 Connection - Millennium II.................................................................................................................................................................... 58
Figure 79 Insert Rectifier ........................................................................................................................................................................................................... 58
Figure 80 Open Rectifier Door ................................................................................................................................................................................................ 59
Figure 81 Close Rectifier Door ................................................................................................................................................................................................ 59
Figure 82 Open Rectifier Door ................................................................................................................................................................................................ 59
Figure 83 Remove Rectifier ...................................................................................................................................................................................................... 59
Figure 84 Inventory Screen ...................................................................................................................................................................................................... 61
Figure 85 Main Screen - web ................................................................................................................................................................................................... 61
Figure 86 Front Panel - Pulsar Plus Controller ................................................................................................................................................................ 63
Figure 87 Front Panel - Millennium II Controller ............................................................................................................................................................ 65
Figure 88 Rectifier Face Plate.................................................................................................................................................................................................. 78
Table of Tables
Table 1 Rectifiers and Converters......................................................................................................................................................................................... 13
Table 2 Conduit Size - Input Feed.......................................................................................................................................................................................... 32
Table 3 Alarm Defaults – Standard Pulsar Plus .............................................................................................................................................................. 49
Table 4 Analog Interface Connector Signals – Pulsar Plus ........................................................................................................................................ 51
Table 5 Auxiliary Input Connector Signals - Pulsar Plus ............................................................................................................................................. 52
Table 6 Alarm Signals - Pulsar Plus....................................................................................................................................................................................... 53
Table 7 Power and Sense Signals - Millennium II........................................................................................................................................................... 56
Table 8 Power Connections - NE830 ................................................................................................................................................................................... 62
Table 9 Alarm Connections - NE830.................................................................................................................................................................................... 62
Table 10 Push Buttons - Millennium II................................................................................................................................................................................. 65
Table 11 Rectifier/Converter LEDs........................................................................................................................................................................................ 78
Table 12 Alarm and Control - Signal Names and BSL Pins ........................................................................................................................................ 81
Table 13 Alarm - Descriptions, BLS Pins, and Signal Names .................................................................................................................................... 82
Table 14 Alarm and Control Inputs - Descriptions, BLS Pins, and Signal Names............................................................................................ 83
Table 15 TR Leads and Associated Rectifiers .................................................................................................................................................................. 85

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 6
Introduction
This manual is intended as a guide in assisting equipment understanding, installation, testing, and troubleshooting.
For additional assistance contact Technical Support or access additional information on-line.
Reference Documents
Document Title
Infinity M Product Line Brochure – Specifications and Ordering Guide
H5692448-AD NE System, 24V and/or 48V Assembly Drawing
CC848815341 Galaxy Pulsar Plus2Family Product Manual
108994645 Galaxy Millennium II3Installation and User’s Guide
107570517 RPM J85501G-1 Product Manual
Contact Information
Phone: [phone]
Email: [e-mail]
Web site: www.gecriticalpower.com
2Referred to as “Pulsar Plus” throughout this document.
3Referred to as “Millennium II” throughout this document.

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 7
Product Description
Infinity M (NE-M) is available in multiple system arrangements. Block diagram - Figure 1.
Refer to the Infinity M Product Line Brochure for detail description.
Single or Dual Output Voltage
Primary DC Voltage Secondary DC Voltage
(Battery and Rectifiers) (dc/dc Converters)
24V none
24V 48V
48V none
48V 24V
Battery Connections
•Direct connection to NE-M system bus
•Through a Low Voltage Battery Disconnect (LVBD)
•Through battery maintenance switches or circuit breakers located at the battery
DC Distribution
•Panel Positions: 2, 3, or 4 (13U, 18U, or 22U systems)
•Panels: Bullet Positions, Selectable Bullet Positions, Bolt In Breakers / Fuses
•DC Voltage: Primary only or Primary and Secondary
•Selectable distribution options
Universal Power Shelf
•Accepts rectifiers or converters interchangeably in any power slot
•Can be installed with no AC connected, as a converter only shelf
AC Feeds
•Front accessible terminal blocks
•One or two rectifier positions per feed
Controller
The controller monitors and controls system operation.
•Pulsar Plus (Eco features included)
•Millennium II
Framework
•84 inch, 72inch, or 42 inch frame
•Sub-frame - mount in customer provided 23 inch frame
Supplemental Frame
The optional Supplemental Frame and adds DC distribution, power shelves, and battery connections.
•Millennium II controller required in Initial Frame.

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 8
Eco Capable Systems - Pulsar Plus only
Eco capable systems (Eco systems) add support for multiple power inputs of multiple types, including PV (photo voltaic
or solar) arrays.
Power Input
•PV (photo voltaic or solar) arrays
•AC generators
•AC mains
Rectifiers
NE Eco Rectifiers4
•Input - AC or DC (PV or solar) input
•MPPT (Maximum Power Point Tracking) maximizes power harvested from PV arrays
•Recommended for all rectifier positions in Eco systems
Controller
•Pulsar Plus
•Eco features included (PV, Gen Set, etc.)
4REQUIRED – Eco rectifiers in all DC (PV or solar) powered rectifier positions.
RECOMMENDED – Eco rectifiers in all Eco system rectifier positions.
NOT RECOMMENDED – non-Eco rectifiers in Eco systems.
Non Eco rectifiers will not function properly when powered by DC (PV or solar) input in Eco systems.
Use of non-Eco rectifiers in Eco systems increases the risk of improperly filling all system rectifier positions.
Non Eco rectifiers may be installed in AC powered rectifier positions of Eco systems.

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 9
Figure 1 Block Diagram

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 10
Components
•
Systems (with 4 rectifier shelves)
•13 U with 2 distribution panel positions
•18 U with 3 distribution panel positions
•22 U with 4 distribution panel positions
•Frameworks:
•Full-Height Frame
•Half-Height Frame
•Sub-frame
with frame mounting brackets
•Pulsar Plus or Millennium II controller
•NE830 Redundant Voltage Monitor
•NE-Series Rectifiers and Converters
•Front accessible AC terminal blocks
•Battery Options and Monitoring:
•Battery Trays with Disconnect Breakers or
Anderson PowerPole® disconnects
•LVBD Contactors
•Thermal/Voltage Probes
•External Ambient Temperature Probes
•Battery Shunt
•DC distribution options:
•Bullet Terminal Panels – 26 position
•Fit in 1 distribution position
•Single Voltage (24V or 48V) or
Selectable Voltage per position
•Integrated return bar
•Bullet terminal breakers up to 250A
•TPS fuses up to 70A
•GMT module fuses up to 15A – 6 position
•Shunt option
•Bolt-in breaker Panel – 12 position
•Mounted in
•Bottom 2 distribution positions with
integrated return bar
or
•Bottom distribution position with top
of frame return bar.
•KS22012 breakers up to 600A
•TPL-C Fuse holders
Figure 2 NE-M Components
•
Additional Power shelves
9 shelves maximum
7 AC powered shelves maximum
AC Input
Terminals, DC
Output
Distribution,
and Battery
Connections
Milllennium
Controller
NE Series
Rectifiers and
Converters
NE830
Voltage
Display

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 11
Controller – Pulsar Plus
Figure 3 Pulsar Front Panel
•Local or remote viewing and configuration of system
parameters, alarm thresholds, and user-definable
alarm inputs and relays
•Extensive rectifier/converter Monitoring and Control
•Advanced Battery Management to maximize and
manage battery health
•Emergency Power Off (EPO) to meet local emergency
services code requirements
•System voltage and current monitoring
•LVBD and LVLD Low Voltage Disconnect contactor
control and monitoring
•dc Distribution monitoring
•Standard and Programmable Alarms
•Extensive Voltage, Current, Temperature, and Binary
Input monitoring
•Standard and programmable Office Alarm relays
•Digital communications to all system devices
See the Pulsar Plus Controller Family Product Manual for further detail.
Controller – Millennium II
Figure 4 Millennium II Controller Front Panel
Plant Voltages and
Load Currents
Voltage Test Jacks
RS-232 and LAN
Ports for PC
Web Pages
Plant Status LEDs
Plant Mode
Menu Navigation
Date and Time
Number of Alarms
and Warnings
Plant Voltage and Load
Current
Voltage Test Jacks
RS-232 Port
Plant
Mode
Menu Navigation
Plant Status LEDs
Alarm Test
Increment / Decrement

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 12
•Local or remote viewing and configuration of system
parameters, alarm thresholds, and user-definable
alarm inputs and relays
•Extensive rectifier/converter Monitoring and Control
•Advanced Battery Management to maximize and
manage battery health
•Emergency Power Off (EPO) to meet local emergency
services code requirements
•System voltage and current monitoring
•LVBD and LVLD Low Voltage Disconnect contactor
control and monitoring
•dc Distribution monitoring
•Standard and Programmable Alarms
•Extensive Voltage, Current, Temperature, and Binary
Input monitoring
•Standard and programmable Office Alarm relays
•Digital communications to all system devices
•Remote Peripheral Modules (RPMs)
See the Galaxy Millennium II Installation and User’s Guide for further detail.
Aux Display - NE830A (Optional)
The Aux Display is a voltage monitor that alarms when the voltage of the power system is out of the normal operating
range. It is mounted on the door of the distribution box.
Figure 5 NE830 Display
•
Fully independent of the main system controller
•Displays one or two system voltages and battery state:
•Single voltage systems, -48V, +24V
•Dual voltage systems, -48V and +24V with common return
•The display and LED color indicates battery charge state and wiring errors:
•Green display = batteries are not discharging
•Red display = batteries are discharging
•Amber display = wiring error
•A Battery on Discharge alarm relay with form-C contacts is provided
•Can be panel, wall or frame rail mounted within 150 ft. of the power system
Rectifiers and Converters
NE-Series rectifiers and converters are hot-pluggable for quick, simple, plug-and-play installation without tools.
Figure 6 Rectifier and Converter Type Badge
NE Eco Rectifiers
Input AC or DC (PV or solar)
Compatibility All Infinity Rectifier Positions
Eco Feature MPPT (Maximum Power Point Tracking) maximizes power harvested from PV arrays
NE Non-Eco Rectifiers
Input AC only
Compatibility All AC powered Infinity Rectifier Positions5
5Non Eco rectifiers will not function properly when powered by DC (PV or solar) input in Eco systems.
Type Badge

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 13
Table 1 Rectifiers and Converters
Rectifier/Converter Input Output Eco Compatible
Eco Rectifier
blue
NE050ECO48ATEZ
ac 110/200-240 Vac
dc 60Vdc (+/-30V)
to 310Vdc (+/-150)
11A max
48V, 50A10 Yes6
Eco Rectifier
orange
NE100ECO24TEZ
ac 110/200-240 Vac
dc 60Vdc (+/-30V)
to 310Vdc (+/-150)
11A max
24V, 100A7Yes6
Converter
blue
NE040DC48ATEZ
24 Vdc
48V, 40A Yes
NE030DC48A 48V, 30A Yes
Converter
orange
NE075DC24A 48 Vdc 24V, 75A Yes
Rectifier
blue
NE075AC48ATEZ 110/200-277 Vac 48V, 75A8
AC Only9
NE055AC48ATEZ 110/200-277 Vac 48V, 55A10
NE050AC48ATEZ 110/200-277 Vac 48V, 50A10
NE050AC48A
12
200-240 Vac 48V, 50A
12
Rectifier
orange
NE100AC24ATEZ 110/200-277 Vac
24V, 100A11 AC Only9
NE100AC24A12 208/200-240 Vac
NE850 Slot Filler
6REQUIRED – Eco rectifiers in all DC (PV or solar) powered rectifier positions.
RECOMMENDED – Eco rectifiers in all Eco system rectifier positions.
NOT RECOMMENDED – non-Eco rectifiers in Eco systems.
Non Eco rectifiers will not function properly when powered by DC (PV or solar) input in Eco systems.
Use of non-Eco rectifiers in Eco systems increases the risk of improperly filling all system rectifier positions.
Non Eco rectifiers may be installed in AC powered rectifier positions of Eco systems.
744A with 120Vac input
822A with 120Vac input
9NOT RECOMMENDED for use in Eco systems - Non Eco rectifiers will not function properly when powered by DC (PV or
solar) input in Eco systems.
Use of non-Eco rectifiers in Eco systems increases the risk of improperly filling system rectifier positions.
10 25A with 120Vac input
11 50A with 120Vac input
12 Non-TEZ rectifiers are no longer orderable and have lower efficiency than TEZ rectifiers

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 14
Power Input Panel
Power Input
Terminal blocks in a front
access panel at the bottom
of the distribution box.
Figure 7 Power Input Panel
Battery Options and Monitoring Features
Figure 8 Battery Stand
Battery Options
•Designed for operation with GE flooded, VRLA and Durathon™ Sodium batteries, as
well as other vendors’ batteries.
•Battery trays are available for 100Ahr to 170Ahr batteries with Anderson
PowerPole® connectors or circuit breaker disconnects.
•Half-height and third-height systems can be mounted on floor-mounted VRLA
strings or on GE Universal Battery Stands.
Battery Monitoring Features
•Open String (OS) Alarms
•Emergency Power Off (EPO) for disconnecting batteries from the system
•Temperature/voltage probes (up to 16) used in Battery Management options
•Slope Thermal Compensation – High and Low Temperature
•Battery High Temp Disconnect
•Mid-String Voltage Monitoring
•Battery Discharge Test
•Battery Shunt
•Low Voltage Battery Disconnect/Reconnect Contactor (LVDB)
with Emergency Power Off (EPO)
Knockouts
each side:
(2) 1” and
(2) 1-1/2”
Terminal Blocks Accept 24-
6 AWG wire.
Straps provided to
feed rectifier pairs.
Conduit Ground
¼-20 x 0.75” or
0.625” Studs

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 15
DC Distribution and Battery Termination
Distribution panels are factory installed.
Examples Features
Figure 9 DC Distribution 4 Bullet Panels
Figure 10 DC Distribution – Bolt In Panel with return bar
22U System Examples
•11 pair Battery and Return bus landings for battery
cables
•LVBD Contactor option
•26 Bullet Distribution positions per panel arranged for:
•Bullet terminal breakers to 250A
•TPS fuse holders for fuses to 70A
•GMT Fuse Module - 6 position
•12 Bolt-in positions
•KS22012 circuit breaker
•TPL-C Fuse holders
•Distribution Panel Positions
System
Distribution Panel Positions
13U
2
18U
3
22U
4
•Universal Power Shelves
Figure 11 NE-M System – 22U
26 Position Bullet Panel
26 Position Bullet Panel
12 Position Bolt-in Panel
with integrated return bar
Mounts in bottom 2
distribution panel
positions
26 Position Bullet Panel
26 Position Bullet Panel
26 Position Bullet Panel
26 Position Bullet Panel
Battery Return
Bus
Battery Bus
Panel A
Panel B
Panel C
Panel D
Shelf
Positions
1
2
3
4
Rectifier Positions
AC Terminal
Blocks

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 16
Installation
Follow all site engineering instructions. This section is provided only as a guide.
Preparation
Safety
Read and follow all safety statements, warnings, and precautions in the Safety section of this manual and manuals of all
other equipment before installing, maintaining or repairing the equipment.
Installation Tools
You will need the following tools.
•Wire cutters and strippers
•Heat shrink gun
•Digital meter with an accuracy of ±0.02%
•Screw drivers (flat-blade and Phillips)
•ESD wrist strap
•24 or 48V test load
•Calibrated clamp-on dc current meter (0.1 ADC
sensitivity)
•Torque wrench
•Sockets -: SAE and metric
5/16”, 7/16”, 9/16”, 19 mm, etc.
•12" extension for socket
•Masonry drill kit as required
•Compression tool for installation of various
compression lugs
•Protective canvas
•Insulating rubber mat
•Standard insulated installation tools, screwdrivers,
etc.
•Windows-based personal computer laptop (PC) and
cable to connect the PC communications port to
the local port of the controller or a CAT5 LAN cable.
(Optional. See the controller manual for more
information).
Equipment Identification
Identify the equipment you have received. Follow procedural steps which match the equipment being installed.

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 17
Anchor Frame
Ventilation space is required to the rear of the equipment: 4” to solid surface, 6” to heat producing surface.
Floor Mounted Frame
Using the 847135688 Floor Anchor Kit (recommended):
Anchor Type (Hilti) Wrench Torque
(4) 12 mm Cap Bolts 19 mm
720 in-lb
60 ft-lb
82 Nm
Note: If using Equivalent Floor Anchors, make sure the floor anchors are rated for this application.
Note: An optional Supplemental Frame (without controller) may be located on either side of the Initial Frame (with
Millennium II controller).
Step Action
Figure 12 Frame Mount Footprint
6 ft. and 7ft Frames
CAUTION: Health Hazard
Follow safe floor drilling procedures to prevent possible asbestos exposure.
1
Drill anchor holes.
2
Place frame and install floor anchors per manufacturer requirements.
3
Repeat for Supplemental Frame, if it is to be installed.

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 18
Battery or Battery Stand Mounted Frame
Step Action
1
Verify that battery or battery stand is positioned to provide adequate ventilation space to the rear of the
equipment: 4” to solid surface, 6” to heat producing surface. Figure 13 shows the placement of the base of the
floor mounted frame to meet ventilation space requirements
Place and secure frame to battery or battery stand per instructions provided with the battery stand or
adapter.
Figure 13 Battery Stand Mount
Sub-frame Mounted Systems:
Sub-frame mounted systems can be mounted in any standard 23” equipment mounting rack or frame with EIA-310
standard 1-3/4” rack spaces or 1” standard rack spaces. The brackets are 36.75” (21U) tall. Comcode CC848819607 kit
provides two brackets and 20 12-24 mounting screws.
Step Action
1
Verify that the rack is positioned to provide adequate ventilation space to the rear of the equipment: 4” to solid
surface, 6” to heat producing surface.
Distance required to rear of mounting rails: 16.5” to solid surface, 18.5” to heat producing surface.
Position the sub-frame system in the rack as desired.
Secure the sub-frame system into the rack with at least (12) frame mounting screws, 6 screws per side.
Torque to 35 in-lb – 5/16 socket.
Figure 14 Mount Sub-Frame
Minimum Distance to Surface
7.5" to Solid Surface
9.5" to Heat Producing Surface
Mounting
Rails

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 19
Ground Frame
Floor Mounted Frame
Select a Frame Ground landing on the top of the frame and clean.
Step Action
1
Secure Frame Ground connection with provided
hardware:
(2) ¼-20 x ¾” HH Bolt
(2) ¼-inch lock washer
(2) ¼-inch flat washer
If required by local code or practice, treat with an
oxidation inhibitor such as NO-OX.
6 AWG minimum recommended.
Torque to 65 in-lb - 7/16” socket.
Note: Lug landings are 1/4” on 5/8”and 1” centers.
Figure 15 Ground Frame
Battery or Battery Stand Mounted Frame
If required by local code or practice, battery or battery stand mounted frames may be grounded to the frame or chassis of
the other equipment. Select a Frame Ground landing at the side of the frame and clean.
Step Action
1
Secure Frame Ground connection with provided
hardware:
(2) ¼-20 x ¾” HH Bolt
(2) ¼-inch lock washer
(2) ¼-inch flat washer
If required by local code or practice, treat with an
oxidation inhibitor such as NO-OX.
6 AWG minimum recommended.
Torque to 65 in-lb - 7/16” socket.
Note: Lug landings are 1/4” on 5/8” centers.
Figure 16 Ground Short Frame
Use either of two frame
ground lug landing locations.

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 20
Connect Central Office Ground (COG)
Step Action
1
Secure COG connection with provided hardware:
(2) 3/8-16 nut
(2) 3/8-inch lock washer
(2) 3/8-inch flat washer
If required by local code or practice, treat with an
oxidation inhibitor such as NO-OX.
Torque to 240 in-lb - 9/16” socket.
Figure 17 CO Ground Landing
Lug landings are 3/8” on 1” centers
Lugs not provided.
Connect Supplemental Frame
This section applies only to installations with an Initial and a Supplemental Frame.
The Initial Frame must be equipped with a Millennium II controller.
Interconnecting bus bars, hardware, and cables are shipped loose with the Supplementary Frame.
Initial Supplemental
Frame Frame
Figure 18 Supplemental Frame
CO Ground
Lug Landing
