GE SPM User manual

SPM
SYNCHRONOUS MOTOR PROTECTION
AND CONTROL
Instruction Manual
Software Revision: 210.000
Manual P/N: 1601-0072-A9 (GEK-113045B)
Copyright © 2008 GE Multilin
GE Multilin
215 Anderson Avenue, Markham, Ontario
Canada L6E 1B3
Tel: [phone] Fax: [phone]
Internet: http://www.GEmultilin.com
g
GE Industrial Systems
GE Multilin’s Quality Manage-
ment System is registered to
ISO9001:2000
QMI # 005094
*1601-0072-A9*

GE Multilin SPM Synchronous Motor Protection and Control i
TABLE OF CONTENTS
1. INTRODUCTION 1.1 OVERVIEW
1.1.1 GENERAL DESCRIPTION ................................................................................ 1-1
1.1.2 FUNCTIONAL OVERVIEW................................................................................ 1-1
1.2 ORDERING
1.2.1 ORDER CODES ................................................................................................ 1-3
1.2.2 ACCESSORIES ................................................................................................. 1-3
1.3 SPECIFICATIONS
1.3.1 TECHNICAL SPECIFICATIONS........................................................................ 1-4
2. INSTALLATION 2.1 OVERVIEW
2.1.1 DESCRIPTION................................................................................................... 2-1
2.1.2 ELEMENTS OF A SYNCHRONOUS MOTOR CONTROLLER ......................... 2-1
2.2 MECHANICAL INSTALLATION
2.2.1 UNPACKING THE SPM ..................................................................................... 2-2
2.2.2 REMOVING THE DRAWOUT RELAY ............................................................... 2-2
2.2.3 INSERTING THE DRAWOUT RELAY ............................................................... 2-2
2.2.4 MOUNTING THE SPM....................................................................................... 2-2
2.2.5 SPM MOUNTING ACCESSORIES.................................................................... 2-2
2.3 ELECTRICAL INSTALLATION
2.3.1 DESCRIPTION................................................................................................... 2-4
2.3.2 GROUNDING..................................................................................................... 2-6
2.3.3 FIELD AND EXCITER VOLTAGE INPUTS........................................................ 2-6
2.3.4 RELAY OUTPUTS ............................................................................................. 2-6
2.3.5 CURRENT TRANSFORMER INPUT ................................................................. 2-6
2.3.6 POWER FACTOR OUTPUT .............................................................................. 2-6
2.3.7 DC FIELD CURRENT INPUT ............................................................................ 2-6
2.3.8 EXCITER VOLTAGE OUTPUT MONITOR........................................................ 2-6
2.3.9 POWER FACTOR REGULATION OUTPUT...................................................... 2-7
2.3.10 CONTROL VOLTAGE........................................................................................ 2-7
2.3.11 EXTERNAL VOLTAGE PF REFERENCE ......................................................... 2-7
2.3.12 RS485 COMMUNICATIONS PORT................................................................... 2-8
3. SYNCHRONOUS MOTOR
APPLICATIONS
3.1 OVERVIEW
3.1.1 GENERAL .......................................................................................................... 3-1
3.2 COLLECTOR-RING MOTORS
3.2.1 STARTING AND SYNCHRONIZING ................................................................. 3-5
3.2.2 RELUCTANCE TORQUE SYNCHRONIZING ................................................... 3-6
3.2.3 STARTING PROTECTION ................................................................................ 3-7
3.2.4 REDUCED VOLTAGE STARTING .................................................................... 3-8
3.2.5 POWER FACTOR (PULL-OUT) PROTECTION .............................................. 3-10
3.2.6 POWER FACTOR OPERATION...................................................................... 3-11
3.2.7 CONTROLLER ACTION DURING PULL-OUT ................................................ 3-12
3.2.8 EFFECT OF VOLTAGE DIPS ON MOTOR POWER FACTOR....................... 3-13
3.2.9 POWER FACTOR DETECTION & INDICATION – OVERHAULING LOAD.... 3-15
3.2.10 POWER FACTOR REGULATION ................................................................... 3-16
3.3 BRUSHLESS CONTROLLER
3.3.1 DESCRIPTION................................................................................................. 3-17
3.3.2 BRUSHLESS MOTOR REVIEW...................................................................... 3-17
3.3.3 STARTING THE BRUSHLESS MOTOR.......................................................... 3-18
3.3.4 STALL PROTECTION...................................................................................... 3-19
3.3.5 POWER FACTOR (PULL-OUT) PROTECTION .............................................. 3-19
3.3.6 POWER FACTOR REGULATION ................................................................... 3-19
4. USER INTERFACE 4.1 SPMPC SOFTWARE
4.1.1 DESCRIPTION................................................................................................... 4-1

ii SPM Synchronous Motor Protection and Control GE Multilin
TABLE OF CONTENTS
4.1.2 SPMPC INSTALLATION ....................................................................................4-2
4.1.3 CONFIGURATION..............................................................................................4-3
4.1.4 CREATING A NEW SETPOINT FILE.................................................................4-4
4.1.5 EDITING A SETPOINT FILE ..............................................................................4-5
4.1.6 LOADING SETPOINTS FROM A FILE...............................................................4-6
4.1.7 UPGRADING SETPOINT FILES TO A NEW REVISION ...................................4-7
4.1.8 PRINTING SETPOINTS & ACTUAL VALUES....................................................4-8
4.1.9 TRENDING .........................................................................................................4-9
4.2 KEYPAD INTERFACE
4.2.1 DESCRIPTION .................................................................................................4-10
4.2.2 CHANGING SETPOINTS .................................................................................4-11
4.2.3 CHANGING CALIBRATION VALUES ..............................................................4-12
4.2.4 CHANGING CONFIGURATIONS.....................................................................4-13
4.2.5 VIEWING & CHANGING STATUS MODE PARAMETERS..............................4-14
4.2.6 ALTERNATE MENU OPERATION...................................................................4-14
5. SETPOINTS 5.1 OVERVIEW
5.1.1 DESCRIPTION ...................................................................................................5-1
5.2 SETPOINTS MENU
5.2.1 POWER FACTOR TRIP .....................................................................................5-2
5.2.2 POWER FACTOR DELAY..................................................................................5-2
5.2.3 POWER FACTOR SUPRESSION......................................................................5-2
5.2.4 POWER FACTOR MODE...................................................................................5-3
5.2.5 FIELD APPLICATION RELAY DELAY ...............................................................5-3
5.2.6 FIELD CONTACTOR AUXILIARY RELAY DELAY.............................................5-3
5.2.7 AC CT PRIMARY RATING .................................................................................5-4
5.2.8 MOTOR FULL LOAD AMPS...............................................................................5-4
5.2.9 MOTOR LOCKED ROTOR AMPS......................................................................5-4
5.2.10 SYNCHRONOUS SLIP.......................................................................................5-5
5.2.11 STALL TIME .......................................................................................................5-5
5.2.12 RUN TIME ..........................................................................................................5-5
5.2.13 DIRECT CURRENT CT PRIMARY RATING ......................................................5-6
5.2.14 FIELD OVERTEMPERATURE (HIGH FIELD OHMS) PROTECTION ...............5-7
5.2.15 FIELD UNDERCURRENT ..................................................................................5-8
5.2.16 FIELD UNDERCURRENT DELAY......................................................................5-8
5.2.17 FIELD UNDERVOLTAGE ...................................................................................5-8
5.2.18 FIELD UNDERVOLTAGE DELAY ......................................................................5-9
5.2.19 INCOMPLETE SEQUENCE DELAY ..................................................................5-9
5.3 OPTIONAL POWER FACTOR REGULATION SETPOINTS
5.3.1 DESCRIPTION .................................................................................................5-10
5.3.2 POWER FACTOR REGULATOR .....................................................................5-10
5.3.3 REGULATOR GAIN..........................................................................................5-10
5.3.4 STABILITY........................................................................................................5-10
5.3.5 REGULATOR OUTPUT LIMIT .........................................................................5-11
5.3.6 FLOOR VOLTS.................................................................................................5-11
5.4 CONFIGURATIONS MENU
5.4.1 MOTOR TYPE ..................................................................................................5-12
5.4.2 LINE FREQUENCY ..........................................................................................5-12
5.4.3 POWER FACTOR REFERENCE .....................................................................5-12
5.4.4 RTU ADDRESS ................................................................................................5-12
5.4.5 BAUD RATE .....................................................................................................5-12
5.4.6 PARITY.............................................................................................................5-12
5.4.7 TURNAROUND ................................................................................................5-13
5.4.8 STATUS MODE................................................................................................5-13
5.4.9 PASSWORD.....................................................................................................5-13
5.5 CALIBRATION MENU
5.5.1 FULL-SCALE EXCITER DC VOLTAGE ...........................................................5-14
5.5.2 FULL-SCALE EXCITER DC AMPS ..................................................................5-14
5.5.3 FULL-SCALE MOTOR AC AMPS ....................................................................5-14

GE Multilin SPM Synchronous Motor Protection and Control iii
TABLE OF CONTENTS
6. ACTUAL VALUES 6.1 DISPLAY SCROLLING
6.1.1 DESCRIPTION................................................................................................... 6-1
6.2 STATUS
6.2.1 MOTOR RUNNING HOURS .............................................................................. 6-2
6.2.2 INCOMPLETE SEQUENCE TRIP COUNTER................................................... 6-2
6.2.3 FIELD LOSS TRIP COUNTER .......................................................................... 6-2
6.2.4 PULL-OUT TRIP COUNTER ............................................................................. 6-2
6.2.5 RESYNCRONIZATION ATTEMPTS TRIP COUNTER...................................... 6-2
6.2.6 MISSING EXTERNAL PF VOLTAGE REFERENCE COUNTER ...................... 6-2
6.2.7 CHECK EXCITER TRIP COUNTER .................................................................. 6-3
6.2.8 POWER FACTOR TRIP COUNTER.................................................................. 6-3
6.2.9 SQUIRREL CAGE TRIP COUNTER.................................................................. 6-3
6.2.10 FIELD OVERVOLTAGE TRIP COUNTER......................................................... 6-3
7. TESTING AND
TROUBLESHOOTING
7.1 START-UP PROCEDURE
7.1.1 INSPECTION ..................................................................................................... 7-1
7.1.2 SPM TEST CHECKS ......................................................................................... 7-1
7.1.3 START-UP DESCRIPTION................................................................................ 7-2
7.2 DISPLAY AND MESSAGES
7.2.1 DISPLAY ............................................................................................................ 7-3
7.2.2 SPM MESSAGES .............................................................................................. 7-3
7.3 REGULATOR TUNE-UP
7.3.1 INSTRUCTIONS ................................................................................................ 7-5
7.4 TROUBLESHOOTING
7.4.1 TROUBLESHOOTING GUIDE........................................................................... 7-6
7.5 PROGRAMMING
7.5.1 PROGRAMMING EXAMPLE ............................................................................. 7-8
7.6 DOS AND DON’TS
7.6.1 DOS ................................................................................................................. 7-12
7.6.2 DON'TS............................................................................................................ 7-12
7.7 FREQUENTLY ASKED QUESTIONS
7.7.1 SPM FAQ ......................................................................................................... 7-13
7.8 REVISION HISTORY
7.8.1 FIRMWARE...................................................................................................... 7-15
8. ACCESSORIES 8.1 VOLTAGE DIVIDER NETWORK
8.1.1 GE MULTILIN VDN ............................................................................................ 8-1
8.1.2 GE MEBANE VDN ............................................................................................. 8-2
8.2 FIELD CURRENT CALIBRATION MODULE
8.2.1 GE MULTILIN MODULE .................................................................................... 8-3
8.3 DC CURRENT TRANSFORMER
8.3.1 DESCRIPTION................................................................................................... 8-6
9. MODBUS
COMMUNICATIONS
9.1 IMPLEMENTATION
9.1.1 MODBUS PROTOCOL ...................................................................................... 9-1
9.1.2 PERFORMANCE REQUIREMENTS ................................................................. 9-1
9.1.3 SETPOINTS....................................................................................................... 9-1
9.1.4 EXECUTE OPERATION COMMAND CODES (COIL NUMBERS) ................... 9-1
9.2 MEMORY MAPPING
9.2.1 MODBUS MEMORY MAP ................................................................................. 9-2
9.2.2 FORMAT CODES .............................................................................................. 9-7

iv SPM Synchronous Motor Protection and Control GE Multilin
TABLE OF CONTENTS
10. FUNCTIONAL TESTS 10.1 INTRODUCTION
10.1.1 DESCRIPTION .................................................................................................10-1
10.2 COLLECTOR-RING MOTOR FIELD APPLICATION TEST
10.2.1 SETUP..............................................................................................................10-2
10.2.2 RELAY PROGRAMMING .................................................................................10-2
10.2.3 TEST.................................................................................................................10-2
10.3 COLLECTOR-RING MOTOR POWER FACTOR TEST
10.3.1 SETUP..............................................................................................................10-3
10.3.2 RELAY PROGRAMMING .................................................................................10-3
10.3.3 TEST.................................................................................................................10-3
10.4 COLLECTOR-RING MOTOR POWER FACTOR TRIP TEST
10.4.1 SETUP..............................................................................................................10-4
10.4.2 RELAY PROGRAMMING .................................................................................10-4
10.4.3 TEST.................................................................................................................10-4
10.5 BRUSHLESS MOTOR FIELD APPLICATION TEST
10.5.1 SETUP..............................................................................................................10-5
10.5.2 RELAY PROGRAMMING .................................................................................10-5
10.5.3 TEST.................................................................................................................10-5
10.6 BRUSHLESS MOTOR POWER FACTOR TEST
10.6.1 SETUP..............................................................................................................10-6
10.6.2 RELAY PROGRAMMING .................................................................................10-6
10.6.3 TEST.................................................................................................................10-6
10.7 BRUSHLESS MOTOR POWER FACTOR TRIP TEST
10.7.1 SETUP..............................................................................................................10-7
10.7.2 RELAY PROGRAMMING .................................................................................10-7
10.7.3 TEST.................................................................................................................10-7
10.8 AC CURRENT METERING AND PULL-OUT TEST
10.8.1 SETUP..............................................................................................................10-8
10.8.2 RELAY PROGRAMMING .................................................................................10-8
10.8.3 TEST.................................................................................................................10-8
10.9 EXCITER / FIELD VOLTAGE METERING TEST
10.9.1 SETUP..............................................................................................................10-9
10.9.2 RELAY PROGRAMMING .................................................................................10-9
10.9.3 TEST.................................................................................................................10-9
10.10 EXCITER / FIELD CURRENT METERING TEST
10.10.1 SETUP............................................................................................................10-10
10.10.2 RELAY PROGRAMMING ...............................................................................10-10
10.10.3 TEST...............................................................................................................10-10
A. COMMISSIONING A.1 COMMISSIONING
A.1.1 COLLECTOR-RING SETTINGS........................................................................ A-1
A.1.2 BRUSHLESS SETTINGS .................................................................................. A-2
B. WARRANTY B.1 WARRANTY
B.1.1 WARRANTY ...................................................................................................... B-1

GE Multilin SPM Synchronous Motor Protection and Control 1-1
1 INTRODUCTION 1.1 OVERVIEW
1
1 INTRODUCTION 1.1 OVERVIEW 1.1.1 GENERAL DESCRIPTION
The SPM Synchronous Motor Protection and Control relay controls starting, synchronizing, and protection of
collector-ring and brushless type synchronous motors.
The SPM control functions for starting synchronous motors include accurate sensing of motor speed and rotor
angle, allowing the unit to apply excitation at optimum speed and angle. This permits closer matching of the
motor to the load. Optimum application of excitation also reduces power system disturbance, which occurs
when the motor goes through a complete slip cycle with the field energized. In addition, the SPM can take
advantage of the extended stall time of a reduced voltage start. It also responds with the proper application of
excitation in the event that the motor synchronizes on reluctance torque.
The SPM provides the functions necessary to protect the motor during startup and in the event of asynchro-
nous operation. During startup and restarting, the SPM prevents overheating of the cage winding. To protect
against asynchronous operation, the motor power factor is monitored. Two modes of pull-out protection can trip
the motor if resynchronization does not occur after a programmed time delay. Motor run time and the number
and type of trips are recorded.
The SPM has an optional power factor regulator containing five adjustable setpoints that can be changed while
the motor is running for convenient regulator tune-up.
A backlit LCD display and keys allow user configurable setting ranges to meet many applications. The unit
comes in a compact S1 drawout case.
The SPM can be applied as part of a complete synchronous motor controller. This consists of four parts. A
main device switches the motor on and off the power system. Multifunction digital relays (such as the GE Mul-
tilin 469 Motor Management Relay) provide stator protection. DC field protection and control are provided by
the SPM. The field contactor and field discharge resistor completes the control assembly.
1.1.2 FUNCTIONAL OVERVIEW
The DC portion of the synchronous motor (rotor assembly) is protected and controlled using a drawout micro-
processor based multifunction relay. The relay is adaptable to either collector-ring or brushless type synchro-
nous motors. Protection features include all of the following:
• Cage winding and stall protection during start
• Lockout feature to protect a hot rotor after an incomplete start
• Incomplete sequence trip due to failed acceleration
• Automatic acceleration time adjustment for reduced voltage starting
• Power factor (pull-out) trip with auto resynchronizing feature
• Loss of DC field current trip
• Loss of DC field voltage trip
• Field winding overtemperature trip
After a successful start, the relay automatically applies the DC field to the rotor at a prescribed slip and slip
angle to minimize mechanical stresses to the shaft as well as minimizes possible electrical transients to the
power system. This is achieved by a dedicated output to close the DC field contactor. The relay is also capable
of reluctance torque synchronizing (collector-ring machines only).
A dedicated output is provided in the relay to enable the loading of the motor following the DC field application
and unloading of the motor following a trip and/or loss of synchronization (pole slipping).
Control of an SCR type excitation system by means of an analog output to maintain power factor (PF regula-
tion) is available as an option.

1-2 SPM Synchronous Motor Protection and Control GE Multilin
1.1 OVERVIEW 1 INTRODUCTION
1
The man-machine interface (MMI) consists of a backlit alphanumeric display and a keypad to accommodate
relay programming as well as viewing actual motor parameters which comprise:
• AC stator current
• Power factor
• DC field current
• DC field voltage
• DC field resistance
• Running time meter (RTM)
Statistical data includes number and type of trips.
The SPM performs a complete system check prior to starting the motor.
Figure 1–1: SINGLE LINE DIAGRAM
701767A9.CDR
MOTOR
LOAD
AC BUS
CLUTCH
COUPLING
DC SUPPLY
27 26F 95
96
56
95
48
94
86
94
48
55
SPM
Stator
Protection
(469)
Calibrator
DC
CT
37
50
IAC
VDC
IDC
VAC
ANSI DEVICE NUMBERS
Fie ld o ve rte m p e ra tu re
Un d e rv o l t a g e
Und e rc urre n t o r und e rp o we r
Inc o m p le te se q ue nc e
Insta nta n e o us o ve rc urre n t
Po w e r f a c t o r
Field application
Lo c k o u t
Tripping
Re l u c t a n c e t o r q u e sy n c . / re sy n c .
Autoloading relay
26F
27
37
48
50
55
56
86
94
95
96

GE Multilin SPM Synchronous Motor Protection and Control 1-3
1 INTRODUCTION 1.2 ORDERING
1
1.2 ORDERING 1.2.1 ORDER CODES
The SPM has all features built into the standard relay and programmable by the user to fit the specific applica-
tion. The only option in the order code is for Power Factor Regulation. Some of the standard features require
an optional external hardware package that must be ordered in addition to the relay itself. These separate
packages are explained in the following section.
1.2.2 ACCESSORIES
•PG2SPM: External hardware package for overtemperature and current loss protection up to 200 A
(includes 1-DCCT200 and 1-CM)
•PG4SPM: External hardware package for overtemperature and current loss protection up to 400 A
(includes 1-DCCT400 or DCCT500 and 1-CM)
•MSPM: Mounting panel to retrofit existing µSPM cutouts for SPM
SPM –*–*
Base Unit SPM ||
Configuration 0|Standard starting and protection relay with VDN board
PF |Power Factor regulation option. Used on motors with SCR exciter
(not recommended for brushless applications)
Harsh Environment 0Standard meter
HHarsh (chemical) environment conformal coating

1-4 SPM Synchronous Motor Protection and Control GE Multilin
1.3 SPECIFICATIONS 1 INTRODUCTION
1
1.3 SPECIFICATIONS 1.3.1 TECHNICAL SPECIFICATIONS
PHASE CURRENT INPUTS
CT primary: 5 to 2000 A
CT secondary: 5 A
Conversion range: 0.05 to 6 ×CT
Frequency: 50 / 60 Hz
Accuracy: at <2 ×CT: ±0.5% of 2 ×CT true RMS
at ≥2 ×CT: ±1% of 6 ×CT true RMS
Current input burden: <1 VA at 5 A
FIELD CURRENT INPUTS
CT Primary: 5 to 1000 A
Conversion range: 0.05 to 1 ×CT
Accuracy: ±2%
EXCITER VOLTAGE INPUTS
Conversion: 0 to 350 V DC (prior to VDN)
Accuracy: ±1%
POWER FACTOR
Range: 0.01 to 1 to –0.01
Time Delay: 0.1 to 10 seconds
Accuracy: ±5%
SWITCH INPUTS (MX AND NX)
Type: Dry contact
Internal interrogation voltage: 85 to 265 V AC (control voltage)
PF ANALOG OUTPUT
Type: Active
Output: 0 to 10 V DC max. at RL ≥1 KW (min. load)
Accuracy: ±10% (0.1 V)
Isolation: 36 V pk
CONTROL VOLTAGE
Input: 85 to 265 V AC at 48 to 60 Hz
Power: 10 VA nominal
Holdup: 100 ms typical at 120 V AC
RELAY CONTACT
Type: FAR, TRP: Form A
FCX: Form C
Rated load: 10 A AC continuous: NEMA A300
1 A DC continuous: NEMA R300
Break: 10 A at 250 V AC or 30 V DC
Max. operating voltage: 250 V AC
ENVIRONMENT
Humidity: 0 to 95% non-condensing
Operating Temp.: –20°C to +70°C
Storage Temp.: –40°C to +85°C
TYPE TESTS
Dielectric Strength: Per IEC 255-5 and ANSI/IEEE C37.90
2.0 kV for 1 min. from relays, CTs, VTs
power supply to Safety Ground
Insulation Resistance: IEC255-5 500 VDC, from relays, CTs, VTs
power supply to Safety Ground
Transients: ANSI C37.90.1 Oscillatory (2.5kV/1MHz)*
ANSI C37.90.1 Fast Rise (5kV/10ns)*
Ontario Hydro A-28M-82
IEC255-4 Impulse/High Frequency Distur-
bance, Class III Level
Impulse Test: IEC 255-5 0.5J 5kV
EMI: C37.90.2 Electromagnetic Interference at
150 MHz and 450 MHz, 10V/m
Static: IEC801-2 Static Discharge
Vibration: Sinusoidal Vibration 8.0g for 72 hrs.
* With the use of an isolation transformer. Please contact GE
Multilin technical support for recommended products.
CERTIFICATION
UL: UL listed for the USA and Canada
PHYSICAL
Shipping Box: 12.50" ×10.50" ×9.75" (L ×H ×D)
318 mm ×267 mm ×248 mm (L ×H ×D)
Ship Weight: 14.25 lb. / 6.45 kg
It is recommended that the SPM be powered up at least once per year to prevent deterioration
of electrolytic capacitors in the power supply.
Specifications are subject to change without notice.
NOTE
