GE B90 User manual

B90 revision: 6.0x
Manual P/N: 1601-0115-X3 (GEK-113612A)
GE Digital Energy
650 Markland Street
Markham, Ontario
Canada L6C 0M1
Tel: [phone] Fax: [phone]
Internet: http://www.GEDigitalEnergy.com
IISO 9001
G
N
E
I
L
M
I
U
T
L
T
E
S
I
R
G
E
E D
R
GE Multilin's Quality Management
System is registered to ISO
9001:2008
QMI # 005094
UL # A3775
*1601-0115-X3*
836771A2.CDR
B90 Low Impedance Bus
Differential System
UR Series Instruction Manual
GE
Digital Energy
LISTED
52TL
IND.CONT. EQ.
E83849

Copyright © 2015 GE Multilin Inc. All rights reserved.
B90 Low Impedance Bus Differential System UR Series Instruction Manual
revision 6.0x.
FlexLogic, FlexElement, FlexCurve, FlexAnalog, FlexInteger, FlexState, EnerVista,
HardFiber, Digital Energy, Multilin, and GE Multilin are trademarks or registered
trademarks of GE Multilin Inc.
The contents of this manual are the property of GE Multilin Inc. This
documentation is furnished on license and may not be reproduced in whole or
in part without the permission of GE Multilin. The content of this manual is for
informational use only and is subject to change without notice.
Part number: 1601-0115-X3 (August 2015)

GE Multilin B90 Low Impedance Bus Differential System iii
