GE JV535 Operating instructions

Range Hoods
Vented
www.GEAppliances.ca
350A4502P662 29-5643 04-08 ATS
Safety Information . . . . . . . . . . . 2
Operating/Care and
Cleaning Instructions
Charcoal Filters . . . . . . . . . . . . . . .4
Grease Filters . . . . . . . . . . . . . . . .3
Hood Lights . . . . . . . . . . . . . . . . .4
Hood Surfaces . . . . . . . . . . . . . . . .4
Stainless Steel Surfaces . . . . . . . . .4
Vent Controls . . . . . . . . . . . . . . . .3
Installation Instructions . . .5–14
Troubleshooting Tips . . . . . . . .15
Consumer Support
Consumer Support . . .Back Cover
Warranty . . . . . . . . . . . . . . . . . . . 18
JV535
JV536
JV565
JV566
JV635
JV636
JV665
JV666
Owner’s Manual
and Installation
Instructions
Write the model and serial
numbers here:
Model # ________________
Serial # __________________
Find these numbers on a label
on the back wall of the hood.

2
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
READ AND SAVE THESE INSTRUCTIONS
SAFETY PRECAUTIONS
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING – TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK OR INJURY TO PERSONS, OBSERVE
THE FOLLOWING:
A. Use this unit only in the manner intended by the
manufacturer. If you have questions, contact the
manufacturer.
B. Before servicing or cleaning unit, switch power
off at service panel and lock the service
disconnecting means to prevent power from
being switched on accidentally. When the service
disconnecting means cannot be locked, securely
fasten a prominent warning device, such as a tag,
to the service panel.
C. Do not use this unit with any solid-state speed
control device.
D. This unit must be grounded.
CAUTION – FOR GENERAL VENTILATING
USE ONLY. DO NOT USE TO EXHAUST HAZARDOUS
OR EXPLOSIVE MATERIALS AND VAPORS.
WARNING – TO REDUCE THE RISK OF INJURY
TO PERSONS IN THE EVENT OF A RANGE TOP GREASE
FIRE, OBSERVE THE FOLLOWING*:
A. SMOTHER FLAMES with a close-fitting lid, cookie
sheet or metal tray, then turn off the burner.
BE CAREFUL TO PREVENT BURNS. If the
flames do not go out immediately, EVACUATE
AND CALL THE FIRE DEPARTMENT.
B. NEVER PICK UP A FLAMING PAN—You may
be burned.
C. DO NOT USE WATER, including wet dishcloths
or towels—a violent steam explosion will result.
D. Use an extinguisher ONLY if:
1. You know you have a Class ABC extinguisher,
and you already know how to operate it.
2. The fire is small and contained in the area
where it started.
3. The fire department is being called.
4. You can fight the fire with your back to an exit.
* Based on “Kitchen Firesafety Tips” published
by NFPA.
WARNING – TO REDUCE THE RISK OF A
RANGE TOP GREASE FIRE:
A. Never leave surface units unattended at high
settings. Boilovers cause smoking and greasy
spillovers that may ignite. Heat oils slowly on
low or medium settings.
B. Always turn hood ON when cooking at high heat
or when cooking flaming foods.
C. Clean ventilating fans frequently. Grease should
not be allowed to accumulate on fan or filter.
D. Use proper pan size. Always use cookware
appropriate for the size of the surface element.
WARNING – TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK OR INJURY TO PERSONS, OBSERVE
THE FOLLOWING:
A. Installation work and electrical wiring must be
done by qualified person(s) in accordance with
all applicable codes and standards, including
fire-rated construction.
B. Sufficient air is needed for proper combustion
and exhausting of gases through the flue
(chimney) of fuel burning equipment to prevent
back drafting. Follow the heating equipment
manufacturer’s guideline and safety standards
such as those published by the National Fire
Protection Association (NFPA), the American
Society for Heating, Refrigeration and Air
Conditioning Engineers (ASHRAE) and the
local code authorities.
C. When cutting or drilling into wall or ceiling, do
not damage electrical wiring and other hidden
utilities.
D. Ducted fans must always be vented to the
outdoors.
WARNING – TO REDUCE THE RISK OF FIRE,
USE ONLY METAL DUCTWORK.
■Do not attempt to repair or replace any part of
your hood unless it is specifically recommended in
this guide. All other servicing should be referred
to a qualified technician.
Consumer Support Troubleshooting Tips Installation Instructions Operating Instructions Safety Instructions

3
Operating Instructions Installation Instructions Troubleshooting Tips Consumer SupportSafety Instructions
Using the hood controls.
Throughout this manual, features and appearance may vary from your model.
FAN Control
Turn to
LO, MED, HI
or
MAX
as needed.
Continuous use of the fan system while cooking
helps keep the kitchen comfortable and less humid.
It also reduces cooking odors and soiling moisture
that create a frequent need for cleaning.
LIGHT Control
Turn to
HI
while cooking or to
NITE
for use as
a night light.
FAN Control
Press the rocker switch at the top to turn the fan on
HI
and at the bottom to turn it on
LOW
. The center
position is
OFF
.
Continuous use of the fan system while cooking
helps keep the kitchen comfortable and less humid.
It also reduces cooking odors and soiling moisture
that create a frequent need for cleaning.
LIGHT Control
Press the rocker switch at the top to turn the light
ON
while cooking. Press the rocker switch at the bottom
for use as a night light. The center position is
OFF
.
Control Knobs (on some models) Rocker Switch Controls (on some models)
LO
HI
MAX
MED
OFF
FAN
HI
NITE
OFF
LIGHT
OFF
LOW
HI
FAN
OFF
NITE
HI
LIGHT
Reusable Metal Grease Filters
The hood has 2 metal reusable
grease filters.
The metal filters trap grease released
by foods on the cooktop. They also
help prevent flaming foods on the
cooktop from damaging the inside
of the hood.
For this reason, the filters must
ALWAYS
be in place when the hood
is used. The grease filters should
be cleaned once a month, or
as needed.
To remove, press the filter locks
back and pull the filters down
and out.
To replace, insert the rear filter tabs
in the frame slots at the back of the
opening. Push the filters up and lock
them into place.
To clean the grease filters, soak
them and then swish them around
in hot water and detergent.
Don’t use ammonia or ammonia
products because they will darken
the metal. Do not use abrasives or
oven cleaners. Light brushing can
be used to remove embedded dirt.
Rinse, shake and let them dry before
replacing. They may also be cleaned
in an automatic dishwasher.
NOTE: Before cleaning, make sure the
charcoal filters, if present, are unclipped and
removed. See the Charcoal Filters section.
If it ever becomes necessary to replace
the metal grease filters, they may be
ordered from your GE supplier.
Filter locks
Care and cleaning of the vent hood.
Be sure electrical power is off and all surfaces are cool before cleaning or servicing any part of the vent hood.

4
To clean the hood surface, use a hot,
damp cloth with a mild detergent
suitable for painted surfaces. Use a
clean, hot, damp cloth to remove soap.
Dry with a dry, clean cloth.
Do not use steel-wool pads or other
abrasive cleaners. They will scratch
the surface. Wipe with a clean, hot,
damp cloth after using cleansers.
Painted Surfaces
(on some models)
Do not use a steel-wool pad; it will
scratch the surface.
Shake bottle well.
Place a small amount of CERAMA
BRYTE®Stainless Steel Cleaning
Polish and Conditioner on a dry
cloth or dry paper towel.
Clean a small area (approximately
8” x 8”/20.3 cm x 20.3 cm),
rubbing with the grain of the
stainless steel if applicable.
Dry and buff with a clean, dry paper
towel or soft cloth.
Repeat as necessary.
Stainless Steel Surfaces
(on some models)
This hood requires two bulbs (not
included), maximum 50 watts.
Purchase and install PAR20, 50 W
Maximum halogen bulbs.
When replacing a bulb, let it cool first.
Make sure that power to the light has
been turned off. Never allow a hot bulb
to come into contact with water.
WARNING: To reduce the risk of
electric shock, do not connect electrical power to
the hood without both bulbs in place.
To change the light bulbs:
Grasp the bulb on the edges and
unscrew it.
Replace with the same size bulb.
CAUTION:
■
Do not touch the hood light bulbs when they
are on. They may be hot enough to cause
injury.
■
The light bulbs operate at extremely high
temperatures. If they shatter, the hot glass
could cause personal injury.
Hood Lights
NOTE: Charcoal filters are not
included with the hood. They
must be ordered from your
GE supplier.
If the model is not vented
to the outside, the air will
be recirculated through
disposable charcoal filters
that help remove smoke
and odors.
The charcoal filters should
be replaced when they
are noticeably dirty or
discolored (usually after
6–12 months, depending
on hood usage).
NOTE: DO NOT rinse, or put
charcoal filters in an automatic
dishwasher.
Charcoal Filters
(on some models)
The charcoal filters
cannot be cleaned.
They must be replaced.
For 30 ” (76.2 cm) hood
models, order
Kit no. WB02X11000.
For 36 ” (91.4 cm) hood
models, order
Kit no. WB02X11001.
These kits can be ordered
from your GE supplier.
The charcoal filters are clipped inside
of each reusable metal grease filter.
Consumer Support Troubleshooting Tips Installation Instructions Operating Instructions Safety Instructions
Care and cleaning of the vent hood. www.GEAppliances.ca
To order:
To order CERAMA BRYTE
®
Stainless
Steel Cleaning Polish and Conditioner,
please call our toll-free number:
National Parts Center 1.800.661.1616
www.GEAppliances.ca
CERAMA BRYTE
®
Stainless Steel Cleaning Polish
and Conditioner . . . . . . . # PM10X313

BEFORE YOU BEGIN
5
Read these instructions completely and carefully.
•IMPORTANT – Save these
instructions for local inspector’s use.
•IMPORTANT – Observe all
governing codes and ordinances.
•Note to Installer – Be sure to leave these
instructions with the Consumer.
•Note to Consumer – Keep these instructions
for future reference.
• Skill level – Installation of this appliance requires
basic mechanical and electrical skills.
• Completion time – 1–3 hours
•Proper installation is the responsibility of the
installer.
•Product failure due to improper installation is not
covered under the Warranty.
•Use only with approved cord kit, JXHC1.
NOTE: Read the ductwork sections only if you do not
have existing ductwork. If you have existing ductwork,
skip to the “Damage” section and proceed.
The venting system must exhaust to the outside.
This hood can be vented vertically through upper
cabinets or horizontally through an outside wall.
Ductwork is not included.
Exhaust connection:
The hood exhaust has been designed to mate with
standard 3¼” x 10” rectangular ducting or 7” diameter
round ducting.
If a 6” round duct is required, a rectangular-to-round
transition adaptor must be used*. Do not use less than
a 6”diameter duct.
Maximum duct length:
For satisfactory air movement, the total duct length
of a 3¼” x 10” rectangular, 6” or 7” diameter round
duct should not exceed 65 equivalent feet.
NOTE: It’s important that ducting be installed using
the most direct route and with as few elbows as possible.
This ensures clear venting of exhaust and helps prevent
blockages. Also, make sure dampers swing freely and
nothing is blocking the ducts.
Elbows, transitions, wall and roofcaps, etc.,
present additional resistance to airflow and are
equivalent to a section of straight duct longer than their
actual physical size. When calculating the total duct
length, add the equivalent lengths of all transitions and
adaptors plus the length of all straight duct sections. The
charts on the following pages show you how to calculate
total equivalent ductwork length using the approximate
feet of equivalent length of some typical ducts.
* IMPORTANT: If a rectangular-to-
round transition adaptor is used, the
bottom corners of the damper will
have to be cut to fit, using the tin
snips, in order to allow free
movement of the damper.
Equivalent lengths of duct pieces
are based on actual tests and reflect
requirements for good venting
performance with any hood.
DUCTWORK REQUIREMENTS
WARNING – Before beginning the
installation, switch power off at service panel and lock
the service disconnecting means to prevent power
from being switched on accidentally. When the service
disconnecting means cannot be locked, securely
fasten a prominent warning device, such as a tag,
to the service panel.
FOR YOUR SAFETY:
Questions?
Call
1.800.561.3344
or Visit our Website at:
www.GEAppliances.ca
Installation Range Hood
Instructions
1 Ft = 0.3 m
1” = 2.5 cm

6
3¼” x 10” Rectangular Transition to 6” Round = 4.5 ft.
7” Round 90° Elbow = 8 ft.
7” Roof Cap = 30 ft.
Follow the guidelines for proper duct sizing in the ducting charts.
Installation Instructions
MAXIMUM DUCT LENGTH: For satisfactory air movement, the total duct length of a 3¼” x 10” rectangular,
6” or 7” diameter round duct should not exceed 65 equivalent feet.
DUCTING CHART—JV5 Series Models
0 25 50 75 100 125 150 175
Equivalent Length (feet)
300
250
200
150
Air Volume (CFM)
31/4” x 10”
Rectangular
7” Round
•
•
•
••
•
•
•
•
•
•
•
DUCTING CHART—JV6 Series Models
0 25 50 75 100 125 150
Equivalent Length (feet)
450
400
350
300
250
200
Air Volume (CFM)
3¼” x 10”
Rectangular
7” Round
•
•
•
•
•
•
•
•
•
•
•
•
1 Ft = 0.3 m
1” = 2.5 cm

DUCT EQUIVALENT NUMBER
PIECES LENGTH x USED = TOTAL
3¼”x 10”1 Ft. x ( ) = Ft.
Rect.,
straight
7”Round, 1 Ft. x ( ) = Ft.
straight
6”Round, 1 Ft. x ( ) = Ft.
straight
3¼”x 10”8.5 Ft. x ( ) = Ft.
Rect. 90°
elbow
3¼”x 10”7 Ft. x ( ) = Ft.
Rect. 45°
elbow
3¼”x 10”24 Ft. x ( ) = Ft.
Rect. 90°
flat elbow
3¼”x 10”45 Ft. x ( ) = Ft.
Rect.
(7 ft. w/o
wall cap
damper)
x ( ) = Ft.
with
damper
3¼”x 10”4.5 Ft. x ( ) = Ft.
Rect. to
6”round
transition
3¼”x 10”11.5 Ft. x ( ) = Ft.
Rect. to
6”round
transition
90° elbow
6”Round, 8 Ft. x ( ) = Ft.
90° elbow
6”Round, 6.5 Ft. x ( ) = Ft.
45° elbow
Subtotal column 1 = Ft.
7
WORKSHEET—CALCULATE TOTAL EQUIVALENT DUCTWORK LENGTH
DUCT EQUIVALENT NUMBER
PIECES LENGTH x USED = TOTAL
6”Round 34 Ft. x ( ) = Ft.
wall cap
(6 ft. w/o
with
damper)
x ( ) = Ft.
damper
6”Round 30 Ft. x ( ) = Ft.
roof cap
6”Round 5.5 Ft. x ( ) = Ft.
to
3¼”x 10”
rect.
transition
6”Round 14.5 Ft. x ( ) = Ft.
to
3¼”x 10”
rect.
transition
90° elbow
7”Round, 8 Ft. x ( ) = Ft.
90° elbow
7”Round, 6.5 Ft. x ( ) = Ft.
45° elbow
7”Round 34 Ft. x ( ) = Ft.
wall cap (
6 ft. w/o
with
damper)
x ( ) = Ft.
damper
7”Round 30 Ft. x ( ) = Ft.
roof cap
7”Round 5.5 Ft. x ( ) = Ft.
to
3¼”x 10”
rect.
transition
7”Round 14.5 Ft. x ( ) = Ft.
to
3¼”x 10”
rect.
transition,
90° elbow
Subtotal column 2 = Ft.
Subtotal column 1 = Ft.
Total ductwork =
Ft.
Installation Instructions
MAXIMUM DUCT LENGTH: For satisfactory air
movement, the total duct length of a 3¼” x 10”
rectangular, 6” or 7” diameter round duct should
not exceed 65 equivalent feet.
1 Ft = 0.3 m
1” = 2.5 cm

PART QUANTITY
Metal Grease Filters 2
Mounting Screws 4
Exhaust Adaptor/Damper 1
(for 3¼”x 10”rect. venting)
Exhaust Adaptor Screws 1
Exhaust Adaptor 1
(for 7” round venting)
• If the unit is damaged in shipment, return the unit to the
store in which it was bought for repair or replacement.
• If the unit is damaged by the customer, repair or
replacement is the responsibility of the customer.
• If the unit is damaged by the installer (if other than
the customer), repair or replacement must be made
by arrangement between customer and installer.
DAMAGE—SHIPMENT/INSTALLATION
PARTS INCLUDED
MOUNTING SPACE
NOTES:
•This range hood is for installation over ranges up to
36” wide.
•If you are going to vent your range hood to the
outside, see the “Ducting Requirements” section for
exhaust duct preparation.
66”or more
from the floor
to the top of
the hood
30”or 36”
30”
min.
Bottom edge of
cabinet needs
to be 30”or
more from
the cooking
surface
Flat blade and Phillips
screwdrivers
Pencil
Metal snips
(in some
applications)
Electric drill
Saw (saber or keyhole)
Duct tape
Pliers
Level
Caulking
Tape measure
Damper for 7”Round
Exhaust Adaptor (Obtain Locally)
PARTS YOU MAY NEED
Charcoal Filters—JV5 Series only, if recirculating
For 30”hood models, order Kit no. WB02X11000.
For 36”hood models, order Kit no. WB02X11001.
OPTIONAL ACCESSORIES
These kits can be ordered from your GE supplier.
Cord Kit—For both 30”and 36”models,
order Kit no. JXHC1.
TOOLS YOU WILL NEED
1/4”pivoting
hex socket
Flashlight
Wire stripper
1/4”Nutdriver
Installation Instructions
8
1 Ft = 0.3 m
1” = 2.5 cm

9
Outside top exhaust
(Vertical duct—3¼” x 10” Rectangular)
Outside rear exhaust
(Horizontal duct—3¼” x 10”
Rectangular)
Outside top exhaust
(Vertical duct — 7” Round)
AC
BRecirculating
(Non-vented ductless — Optional for
JV5 Series models only)
D
Installation Instructions
CHOOSE VENT OPTION
Determine the vent option that your installation will
require from the following choices:
The outside vent exhaust option that your installation
requires will determine the hood knockouts that you
will use.
NOTE: Only JV5 Series models may be recirculated.
The JV6 Series models cannot be recirculated.
IMPORTANT: If the hood is to be installed in a
recirculating, non-vented ductless manner, do not knock
out any vent openings in the hood. Only an electrical
access hole will be knocked out of the hood.
1
1 Ft = 0.3 m
1” = 2.5 cm

10
REMOVE EXHAUST ADAPTOR
Remove the 7”round exhaust adaptor from the top of
the hood. Set it aside along with its mounting screws.
NOTE: Save the screws for 3¼”x 10”rectangular
ducted installation, if that is your chosen venting option.
7”round
exhaust
adaptor
REMOVE FILTERS
Remove the protective shipping film from the edges
of the metal grease filters. Press the filter locks back
and lift the filters out. Set them aside.
REMOVE WIRING COVER
FROM THE JUNCTION BOX
Remove the wiring cover from inside the hood.
Set the cover and its mounting screw aside.
Wiring
cover
REMOVE WIRING KNOCKOUT
Remove either the top or the back wiring knockout as
needed and install an approved strain relief clamp.
Strain relief
clamp
2
3
4
5
Filters
Installation Instructions
1 Ft = 0.3 m
1” = 2.5 cm

11
REMOVE DUCT KNOCKOUT(S)
If recirculating, non-vented ductless (optional for
JV5 Series models only), see note below and skip to
Step 9 D and proceed. The JV6 Series models cannot
be recirculated.
Using a flat blade screwdriver, remove the appropriate
duct knockout(s) from the top or back of the hood.
3¼”x 10”Rectangular
vertical discharge.
Remove top rectangular
duct knockout only.
7
”Round vertical
discharge. Remove semi-
circular duct knockout and top
rectangular duct knockout.
3¼” x 10” Rectangular
horizontal discharge. Remove
rear rectangular duct knockout only.
FOR 3¼”x10”RECTANGULAR
DUCTED DISCHARGE
INSTALLATIONS ONLY:
Attach exhaust adaptor/damper over knockout
opening with two exhaust adaptor screws. Make sure
damper pivot is nearest to top/back edge of hood.
Remove tape from damper flap.
Up to 1”side-to-
side adjustment
Tape
Top/back edge
Exhaust adaptor/damper
(vertical discharge position
shown)
Pivot
FOR 7”ROUND VERTICAL
DUCTED DISCHARGE
INSTALLATIONS ONLY:
Re-install the 7”round exhaust adaptor with its
screws, removed in Step 2 under the “Prepare the
Hood” section.
7
8
7”round
exhaust
adaptor
NOTE: The 7” round exhaust adaptor can be installed
up to 1 inch on either side of the hood center to
accommodate off-center ductwork. In extreme off-center
installations, one end of the duct connector may need
to be trimmed to clear the electrical cable clamp.
NOTE: The 7”round damper is not included with
this product. It can be purchased as a kit by calling
1.800.661.1616. Order kit number JXDA22.
Installation Instructions
NOTE: The exhaust adaptor/damper can be installed
up to 1 inch on either side of the hood center to
accommodate off-center ductwork. In extreme off-
center installations, one end of the duct connector may
need to be trimmed to clear the electrical cable clamp.
NOTE: If the hood is to be installed in a recirculating,
non-vented ductless manner, order charcoal filters,
kit number WB02X11000 for 30”hood models, or
kit number WB02X11001 for 36”hood models.
These kits can be ordered from your GE supplier.
Skip to Step 9 D and proceed.
6
1 Ft = 0.3 m
1” = 2.5 cm

12
MARK HOLES
Select the vent option that your installation will
require and proceed to that section:
Hood mounting screws (4)
1315/16”(30”hood)
1615/16”(36”hood)
1315/16
”
(30
”
hood)
1615/16
”
(36
”
hood)
Cabinet front
Center
line
Electrical access hole
(in cabinet bottom)
Wood shims (recessed-
bottom cabinets only)
Vertical duct
access hole
101/2”
11/4”
2”
12 9/16”
5”
11/4”
A.
Outside top exhaust
(Vertical duct–31/4
”
x 10
”
Rectangular)
•Use the diagram or the hood as a template and
mark the locations on the cabinet for ductwork,
electrical wiring and keyhole screw slots.
B.
Outside top exhaust (Vertical duct–7”Round)
•Use the diagram or the hood as a template and
mark the locations on the cabinet for ductwork,
electrical wiring and keyhole screw slots.
Hood mounting screws (4)
1315/16”(30”hood)
1615/16”(36”hood)
1315/16
”
(30
”
hood)
1615/16
”
(36
”
hood
)
Cabinet front
Center
line
Electrical access
hole (in cabinet bottom)
Wood shims (recessed-
bottom cabinets only)
Access
hole for 7”
round duct
101/2”
11/2”
11/4”
121/2”
5”
Cabinet
bottom
8”DIA.
HOLE
CHOOSE VENTING OPTION
(for JV5 Series models only)
Cabinet Bottom
9
10
Wood shims (recessed-bottom cabinets only)
Cabinet front
Center line Electrical access hole
(in wall)
Hood mounting screws (4)
Horizontal duct
access hole
Cabinet
bottom
1315/16”(30”hood)
1615/16”(36”hood)
17/16”
1/8”
33/4”
51/4”51/4”
127/16”
1315/16”(30”hood)
1615/16”(36”hood)
C.
Outside rear exhaust
(Horizontal duct–31/4
”
x 10
”
Rectangular)
•Use the diagram or the hood as a template and
mark the locations on the cabinet for ductwork,
electrical wiring and keyhole screw slots.
D.
Recirculating (non-vented ductless–
Available on JV5 Series models only)
•Use the hood as a template and mark the locations
on the cabinet for the electrical wiring and keyhole
screw slots.
•Since the hood is to be recirculated (not to be vented
outside), do not cut out any vent openings in the wall
or cabinet bottom.
The hood can be set to vent outside or to recirculate
air back into the kitchen.
The plastic vent lever is located near the center of the
hood opening.
•To vent to the outside, make sure the plastic vent
lever is in the HORIZONTAL position (flat against
the metal top of the hood).
•To recirculate air into the kitchen, make sure the
plastic vent lever is in the VERTICAL position
(flat against the plastic blower housing).
NOTE: In order to change the vent lever position,
you will need to pull the lever out slightly to clear
the plastic tabs.
51/4”
51/4”
Installation Instructions
Set for
outside venting
Set for
recirculating
Stop tab
Hood shown lying upside down
Stop tab
1 Ft = 0.3 m
1” = 2.5 cm

13
Installation Instructions
CUT HOLES
Cut holes at marked locations for duct and electrical
wiring. For the vertical duct, cut out ¾”extra toward
the front of the cabinet so you can move the duct
freely when installing the hood. It may also ease
installation by cutting the hole 10½”instead of 10”.
FOR RECESSED-BOTTOM
CABINETS ONLY
RUN WIRES
Run the electrical wires through the wall or
cabinet according to National Electrical Code
and applicable local codes.
NOTE: DO NOT turn the power on until
installation is complete.
12
11 13
SCREW IN PARTWAY
Drive a mounting screw (from the hardware packet)
partway into each center of the narrow neck of the
keyhole slots marked on the cabinet bottom.
FEED IN WIRES
Lift the hood into position and feed the house
wiring through the wiring knockout.
14
15
Wood shims
•If the cabinets have front, side or back trim, make
2 wood shims the width of the trim and attach them
to the cabinet bottom recess on both sides. See Step
9 for marking locations.
SECURE HOOD
Slide the hood back against the wall. Tighten
the mounting screws. Be sure the screw heads
are in the narrow neck of the keyhole slot.
Keyhole (4)
Mounting
screw (4)
16
1 Ft = 0.3 m
1” = 2.5 cm

TROUBLESHOOTING CHECKLIST
If the hood seems to be operating at high speed when
the control is not set on high, or if ventilation seems
inadequate, check the following:
❏Knockouts not removed from hood.
❏Damper blade not opening.
❏Reduced airflow because the duct is too small
or the duct length is too long.
❏The duct is blocked.
❏Undersized or restrictive wall or roof cap.
REPLACE WIRING COVER
Replace the wiring cover.
14
FOLLOW ELECTRICAL CODE
Complete the electrical wiring according to
National Electrical Code and local codes.
NOTE: This hood must be permanently grounded.
Connect house wiring (120 VAC) to hood wiring.
CONNECT WIRING
Connect house black to hood black wire, house
white to hood white wire, and house ground to
hood green/yellow wire. Securely tighten the
strain relief clamp onto the house wiring.
19
20
21
22
INSTALL LIGHT BULBS
Purchase and install two PAR20, 50 W maximum
halogen bulbs. Light bulbs are not included with
the hood.
WARNING:
To reduce the risk of electric
shock, do not connect electrical power to the hood
without both bulbs in place.
18
CONNECT DUCTWORK
TO HOOD
Use duct tape to make joints secure and air tight.
Duct tape
17
REPLACE FILTERS
The installation is complete. Turn on power at
service panel, and test for proper operation.
Installation Instructions
1 Ft = 0.3 m
1” = 2.5 cm

Notes.
Safety Instructions Operating Instructions Installation Instructions Troubleshooting Tips Consumer Support

16
Before you call for service…
Troubleshooting Tips
Save time and money! Review the following chart first
and you may not need to call for service.
Problem Possible Causes What To Do
Fan does not operate
A fuse may be blown or a •Replace fuse or reset circuit breaker.
when the switch is on
circuit breaker may be tripped.
Fan fails to circulate air
Excessively soiled filter. •Wash and replace the filters. See the
Reusable
or moves air more slowly Metal Grease Filters
section.
than normal
•Replace the filter if it is too soiled to clean. If it
is not soiled, or if replacing the filter does not
solve the problem, call for service.
Fan continually cycles
The motor is probably •Replace the filter if it is soiled. If it is not soiled,
off and on
overheating and turning itself or if replacing the filter does not solve the problem,
off. This can be harmful to call for service.
the motor. Filter may be
excessively soiled.
Air coming from the
Vent lever is in the •Move the lever back to the HORIZONTAL position
front vent (on some
VERTICAL position (flat (flat against the metal top of the hood) to vent
models) when it is
against the plastic blower to the outside. See Step 10 in the Installation
ducted to the outside
housing) for recirculating. Instructions for vent lever operation. This is normal
if the hood has been installed to recirculate.
Consumer Support Troubleshooting Tips Installation Instructions Operating Instructions Safety Instructions

17
OWNERSHIP REGISTRATION
P.O. BOX 1780
MISSISSAUGA, ONTARIO
L4Y 4G1
(FOR CANADIAN CONSUMERS ONLY -
POUR RÉSIDENTS CANADIENS SEULEMENT)
Please place in envelope and mail to:
Veuillez mettre dans une enveloppe et envoyez à :

18
CUT ALONG THIS LINE AND RETURN CARD – THANKS
DÉCOUPEZ ICI ET ENVOYEZ LA FICHE – MERCI
For Canadian
Customers
Pour les
consommateurs
canadiens
OWNERSHIP REGISTRATION CERTIFICATE – FICHE D’INSCRIPTION DU PROPRIÉTAIRE
Please register your product to enable us to contact you in
the remote event a safety notice is issued for this product
and to allow for efficient communication under the terms of
our warranty, should the need arise.
REGISTER ON-LINE:
www.geappliances.ca
ENREGISTREMENT SUR INTERNET À :
www.electromenagersge.ca
MAIL TO: P.O. BOX 1780, MISSISSAUGA
POSTEZ À : ONTARIO, L4Y 4G1
MR. / M. MRS. / MME
MISS/MLLE MS.
FIRST NAME / PRÉNOM LAST NAME / NOM
STREET NO / N
O
RUE STREET NAME / RUE APT.NO/APP./RR#
CITY / VILLE PROVINCE
AREA CODE/
IND. RÉG. TELEPHONE/TÉLÉPHONE E-MAIL/COURRIEL
DID YOU PURCHASE A SERVICE CONTRACT FOR THIS APPLIANCE?
AVEZ-VOUS ACHETÉ UN CONTRAT DE SERVICE POUR CET APPAREIL ?
YES/OUI
NO/NON
IF YES/SI OUI : EXPIRATION
Y/A M D/J
NAME OF SELLING DEALER / NOM DU MARCHAND
INSTALLATION DATE / DATE D’INSTALLATION
Y/A M D/J CORRESPONDENCE
ENGLISH
CORRESPONDANCE
FRANÇAIS
I do not wish to receive any promotional offers regarding this product.
Je ne désire pas recevoir d’offres promotionnelles concernant ce produit
.
MODEL / MODÈLE
SERIAL / SÉRIE
Veuillez enregistrer votre produit afin de nous permettre de
communiquer avec vous si jamais un avis de sécurité concernant
ce produit était émis et de communiquer facilement avec vous en
vertu de votre garantie, si le besoin s’en fait sentir.
POSTAL CODE/CODE POSTAL

19
Safety Instructions Operating Instructions Installation Instructions Troubleshooting Tips Consumer Support
Range Hood Warranty.
For The Period Of: Mabe Will Replace:
One Year Any part
of the range hood which fails due to a defect in materials or workmanship.
From the date of the
During this
full one-year warranty,
Mabe will also provide,
free of charge,
all labor and
original purchase
in-home service to replace the defective part.
■Service trips to your home to teach you how to use
the product.
■Improper installation, delivery or maintenance.
■Failure of the product if it is abused, misused, or
used for other than the intended purpose or used
commercially.
■Replacement of house fuses or resetting of circuit
breakers.
■Damage to the product caused by accident, fire, floods
or acts of God.
■Incidental or consequential damage caused by possible
defects with this appliance.
■Damage caused after delivery.
What Mabe Will Not Cover:
All warranty service provided by our Factory Service Centers,
or an authorized Customer Care®technician. To schedule service,
on-line, 24 hours a day, visit us at GEAppliances.ca, or call
1.800.561.3344.
Staple your receipt here.
Proof of the original purchase
date is needed to obtain service
under the warranty.
This warranty is extended to the original purchaser and any succeeding owner for products purchased in Canada
for home use within Canada. If the product is located in an area where service by a Mabe Authorized Servicer is not
available, you may be responsible for a trip charge or you may be required to bring the product to an Authorized Mabe
Service Location for service.
Some provinces do not allow the exclusion or limitation of incidental or consequential damages. This warranty
gives you specific legal rights, and you may also have other rights which vary from province to province. To know
what your legal rights are, consult your local or provincial consumer affairs office.
Warrantor: Mabe Canada Inc. Burlington, Ontario
EXCLUSION OF IMPLIED WARRANTIES—Your sole and exclusive remedy is product repair as provided in this
Limited Warranty. Any implied warranties, including the implied warranties of merchantability or fitness for a
particular purpose, are limited to one year or the shortest period allowed by law.

Consumer Support.
GE Appliances Website GEAppliances.ca
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day of
the year! For greater convenience and faster service, you can now download Owner’s Manuals, order parts or even
schedule service on-line.
Schedule Service GEAppliances.ca
Expert Mabe repair service is only one step away from your door. Get on-line and schedule your service at your
convenience 24 hours any day of the year! Or call 1-800-461-3636 during normal business hours.
Extended Warranties GEAppliances.ca
Purchase a GE extended warranty and learn about special discounts that are available while your warranty is still in
effect. You can purchase it on-line anytime, or call 1-888-261-2133 during normal business hours. Mabe Consumer
Home Services will still be there after your warranty expires.
Parts and Accessories GEAppliances.ca
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or by phone at
1-800-661-1616 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing generally should be
referred to qualified service personnel. Caution must be exercised, since improper servicing may cause unsafe operation.
Contact Us GEAppliances.ca
If you are not satisfied with the service you receive from Mabe, contact us on our Website with all the details
including your phone number, or write to: General Manager, Customer Relations, Mabe Canada Inc.
Suite 310, 1 Factory Lane
Moncton, N.B. E1C 9M3
Register Your Appliance GEAppliances.ca
Register your new appliance on-line—at your convenience! Timely product registration will allow for enhanced
communication and prompt service under the terms of your warranty, should the need arise. You may also mail in
the pre-printed registration card included in the packing material.
Other manuals for JV535
2
This manual suits for next models
7
Table of contents
Other GE Ventilation Hood manuals

GE
GE GE Monogram ZVB30BN Manual

GE
GE PVUS930 Operating instructions

GE
GE Monogram ZV800 User manual

GE
GE JV386 Installation instructions

GE
GE PVB94 User manual

GE
GE Monogram ZV750 User manual

GE
GE Monogram ZV48R User manual

GE
GE Monogram Refrigerator User manual

GE
GE UVC9420 Original instructions

GE
GE Monogram ZV750 User manual
Popular Ventilation Hood manuals by other brands

Air King
Air King VH1303 Important instructions & operating manual

Siemens
Siemens LC98BA521I Instructions for installation and use

Amica
Amica AH5014 instruction manual

Kenmore
Kenmore 233.52153002 Use & care guide

Home appliances
Home appliances AAS9SE3 instruction manual

inventum
inventum AKD8005ZWA user manual
