Geberit aquaclean sela User manual

QUICK GUIDE
4885414283 © 06.2018
968.704.00.0 (00)
GEBERIT AQUACLEAN SELA
DOWNLOAD THE
APP AND REAP THE
REWARDS
www.geberit-aquaclean.com
The following shower toilet functions can
be executed via the Geberit AquaClean
app:
• remote control of the Geberit AquaClean
shower toilet
• adjustment of the device settings
The Geberit AquaClean app offers the
following additional benefits:
• saving your personal settings on your
smartphone
• support for care and maintenance of the
device
• easy registration of your Geberit
AquaClean shower toilet
• function films
• service and contact information
The Geberit AquaClean app is available
free of charge for Android and iOS
smartphones in the respective app stores.
iOS: Android:
What you need for cleaning
The Geberit AquaClean cleaning set (art. no. 242.547.00.1) includes a ready-made cleaning
agent that is optimal for cleaning all Geberit AquaClean surfaces.
CAUTION
Cleaning with aggressive descaling and cleaning agents can cause surface
damage.
• Only use Geberit AquaClean descaling agent in the device.
• Only use cleaning agents permitted by Geberit.
Only skin-friendly cleaning agents
Only liquid cleaning agents
Permissible cleaning agents
Cleaning agents with a low acid content (e.g. heavily diluted citric acid)
Mildly foaming cleaning agents
Preferably water-diluted cleaning agents
Permissible cleaning equipment
Soft, fine-pored sponges
Lint-free, soft cloths which are free of dust
Toilet brush
Geberit AquaClean consumables
Geberit AquaClean cleaning set (art. no. 242.547.00.1)
Geberit AquaClean descaling agent (art. no. 147.040.00.1)
Selecting suitable cleaning agents and cleaning equipment
Operating the shower toilet using
the app
Geberit AquaClean app

The device at a glance The remote control at a glance How to use the device
1 WC lid
2 Remote control with magnetic
wall-mounted holder
3 WC seat ring
4 Spray arm with spray nozzle
and Lady shower nozzle




Geberit AquaClean Sela
Press the <Shower> button once to switch on the
anal shower.
Using the anal shower
Press the <Shower> button again to
stop the shower procedure early.
Using the Lady shower
Press the <Lady shower> button once to switch
on the Lady shower.
Press the <Lady shower> button again
to stop the shower procedure early.
Setting the spray intensity
Press the <–> button to decrease the spray
intensity in stages.
Press the <+> button to increase the spray
intensity in stages.
You can set the spray intensity in 5
stages.
Setting the spray arm position
Press the arrow keys to position the spray arm.
You can set the spray arm position in 5
stages.
Switching on the oscillating motion
Press the <Oscillating motion> button to start the
oscillating motion of the anal shower.
Press the <Oscillating motion> button
again to switch off the oscillating spray
early.
Switching on the orientation light
Press the <Orientation light> button to switch
on the orientation light.
Press the <Orientation light> button
again to switch off the orientation
light.
Individual functions can be selected from the rear side of the remote control.
Rear side of the remote control
1 Battery compartment
2 LCD display
3 <up>/<down>, <left>/<right> arrow keys


All functions for daily use can be operated from the front side of the remote control.
Front side of the remote control
1 <Shower> button
2 <–>/<+> buttons
3 <left>/<right> arrow keys
4 <Lady shower> button
5 <Oscillating motion> button
6 <Orientation light> button
7 User profile buttons







User profiles allow you to access your personal settings directly. You can save 4 user
profiles.
Assigning the remote control
Switch on the device, then press and hold the <+> button on the remote control for
approximately 30 seconds until <Pairing ok> appears on the rear display.



T
Saving user pro󹺌les
T
Press and hold one of the user profile buttons
for 2 seconds to save the current settings as
the user profile for this button.
Press the user profile button again to
activate your user profile.

The device at a glance The remote control at a glance How to use the device
1 WC lid
2 Remote control with magnetic
wall-mounted holder
3 WC seat ring
4 Spray arm with spray nozzle
and Lady shower nozzle




Geberit AquaClean Sela
Press the <Shower> button once to switch on the
anal shower.
Using the anal shower
Press the <Shower> button again to
stop the shower procedure early.
Using the Lady shower
Press the <Lady shower> button once to switch
on the Lady shower.
Press the <Lady shower> button again
to stop the shower procedure early.
Setting the spray intensity
Press the <–> button to decrease the spray
intensity in stages.
Press the <+> button to increase the spray
intensity in stages.
You can set the spray intensity in 5
stages.
Setting the spray arm position
Press the arrow keys to position the spray arm.
You can set the spray arm position in 5
stages.
Switching on the oscillating motion
Press the <Oscillating motion> button to start the
oscillating motion of the anal shower.
Press the <Oscillating motion> button
again to switch off the oscillating spray
early.
Switching on the orientation light
Press the <Orientation light> button to switch
on the orientation light.
Press the <Orientation light> button
again to switch off the orientation
light.
Individual functions can be selected from the rear side of the remote control.
Rear side of the remote control
1 Battery compartment
2 LCD display
3 <up>/<down>, <left>/<right> arrow keys


All functions for daily use can be operated from the front side of the remote control.
Front side of the remote control
1 <Shower> button
2 <–>/<+> buttons
3 <left>/<right> arrow keys
4 <Lady shower> button
5 <Oscillating motion> button
6 <Orientation light> button
7 User profile buttons







User profiles allow you to access your personal settings directly. You can save 4 user
profiles.
Assigning the remote control
Switch on the device, then press and hold the <+> button on the remote control for
approximately 30 seconds until <Pairing ok> appears on the rear display.



T
Saving user pro󹺌les
T
Press and hold one of the user profile buttons
for 2 seconds to save the current settings as
the user profile for this button.
Press the user profile button again to
activate your user profile.

The device at a glance The remote control at a glance How to use the device
1 WC lid
2 Remote control with magnetic
wall-mounted holder
3 WC seat ring
4 Spray arm with spray nozzle
and Lady shower nozzle




Geberit AquaClean Sela
Press the <Shower> button once to switch on the
anal shower.
Using the anal shower
Press the <Shower> button again to
stop the shower procedure early.
Using the Lady shower
Press the <Lady shower> button once to switch
on the Lady shower.
Press the <Lady shower> button again
to stop the shower procedure early.
Setting the spray intensity
Press the <–> button to decrease the spray
intensity in stages.
Press the <+> button to increase the spray
intensity in stages.
You can set the spray intensity in 5
stages.
Setting the spray arm position
Press the arrow keys to position the spray arm.
You can set the spray arm position in 5
stages.
Switching on the oscillating motion
Press the <Oscillating motion> button to start the
oscillating motion of the anal shower.
Press the <Oscillating motion> button
again to switch off the oscillating spray
early.
Switching on the orientation light
Press the <Orientation light> button to switch
on the orientation light.
Press the <Orientation light> button
again to switch off the orientation
light.
Individual functions can be selected from the rear side of the remote control.
Rear side of the remote control
1 Battery compartment
2 LCD display
3 <up>/<down>, <left>/<right> arrow keys


All functions for daily use can be operated from the front side of the remote control.
Front side of the remote control
1 <Shower> button
2 <–>/<+> buttons
3 <left>/<right> arrow keys
4 <Lady shower> button
5 <Oscillating motion> button
6 <Orientation light> button
7 User profile buttons







User profiles allow you to access your personal settings directly. You can save 4 user
profiles.
Assigning the remote control
Switch on the device, then press and hold the <+> button on the remote control for
approximately 30 seconds until <Pairing ok> appears on the rear display.



T
Saving user pro󹺌les
T
Press and hold one of the user profile buttons
for 2 seconds to save the current settings as
the user profile for this button.
Press the user profile button again to
activate your user profile.

The device at a glance The remote control at a glance How to use the device
1 WC lid
2 Remote control with magnetic
wall-mounted holder
3 WC seat ring
4 Spray arm with spray nozzle
and Lady shower nozzle




Geberit AquaClean Sela
Press the <Shower> button once to switch on the
anal shower.
Using the anal shower
Press the <Shower> button again to
stop the shower procedure early.
Using the Lady shower
Press the <Lady shower> button once to switch
on the Lady shower.
Press the <Lady shower> button again
to stop the shower procedure early.
Setting the spray intensity
Press the <–> button to decrease the spray
intensity in stages.
Press the <+> button to increase the spray
intensity in stages.
You can set the spray intensity in 5
stages.
Setting the spray arm position
Press the arrow keys to position the spray arm.
You can set the spray arm position in 5
stages.
Switching on the oscillating motion
Press the <Oscillating motion> button to start the
oscillating motion of the anal shower.
Press the <Oscillating motion> button
again to switch off the oscillating spray
early.
Switching on the orientation light
Press the <Orientation light> button to switch
on the orientation light.
Press the <Orientation light> button
again to switch off the orientation
light.
Individual functions can be selected from the rear side of the remote control.
Rear side of the remote control
1 Battery compartment
2 LCD display
3 <up>/<down>, <left>/<right> arrow keys


All functions for daily use can be operated from the front side of the remote control.
Front side of the remote control
1 <Shower> button
2 <–>/<+> buttons
3 <left>/<right> arrow keys
4 <Lady shower> button
5 <Oscillating motion> button
6 <Orientation light> button
7 User profile buttons







User profiles allow you to access your personal settings directly. You can save 4 user
profiles.
Assigning the remote control
Switch on the device, then press and hold the <+> button on the remote control for
approximately 30 seconds until <Pairing ok> appears on the rear display.



T
Saving user pro󹺌les
T
Press and hold one of the user profile buttons
for 2 seconds to save the current settings as
the user profile for this button.
Press the user profile button again to
activate your user profile.
