Geemarc AmpliPOWER 40 User manual

AmpliPOWER 40/50
English
Français
Deutsch
!!!Warning, AmpliPOWER40/50 has an extra loud receiving
volume gain!!! (Risk of acoustic shock)
!!!Attention, l’AmpliPOWER40/50 possède un amplifiacteur
de volume très puissant!!! (Risque de choc accoustique)
!!!Seien Sie vorsichtig: der AmpliPOWER40/50 hat ein sehr
starke Lautstärke!!! (Akustisches Schockrisiko)

!!!User manual to read carefully before start to
use!!!
!!!Manuel d’utilisation à lire impérativement avant
la mise en service!!!
!!! Bevor Ihr neues Telefongerät zu benutzen,
bitte lesen Sie dies Benutzerhandbuch sehr
sorgfältig!!!
CAUTION: this telephone is specifically designed for the people with hearing
difficulties and is provided with a handset earpiece volume control for individual
requirements. Due care must be taken by all users that the handset earpiece
volume control is set to the lowest level acceptable by each respective user.
Care should therefore be exercised to ensure that any naive users are familiar
with this requirement.
ATTENTION: Ce téléphone peut être destiné aux personnes ayant des
problèmes auditifs. il possède un écouteur a volume variable. A la première
utilisation, assurez vous que le volume soit réglé au minimum. Les personnes
malentendantes pourront par la suite augmenter le volume pour l’adapter à leur
besoin.
WARNUNG: Dieses Telefon wurde speziell für schwerhörige Personen
konzipiert und besitzt eine auf die individuellen Bedürfnisse einstellbare
Hörerlautstärke. In Folge dessen sollten alle Nutzer darauf achten, dass der
Lautstärkeregler des Hörers, in Rücksicht auf andere Nutzer, auf das
niedrigste Niveau gestellt wird. Es ist darauf zu achten, dass unwissende
Benutzer mit der Handhabung dieser Apparatur vertraut gemacht werden.

Index
INDEX
Description 5-7
Setting up
1 - Connecting the telephone 8
2 - Alarm and ring options 8
-Ring only
-Ring and shaker
-Ring and strobe flash
3 - Ringer settings 9
4 - Tone/Pulse switch (T/P) 10
5 - Time break recall switch (270/100) 10
6 - Hotel message waiting switch 10
7 - Wall mounting 11
Using the phone
8- Answering incoming calls 12
-Without headset
-With headset (option)
-In handsfree mode
9- Volume and tone receiving 13

4
10 - Making a cal 15
- Without headset
- With headset (option)
- In handsfree mode
11 - Last number redial 16
12 - Recall, * & # buttons 16
13 - Mute button 17
14 - Storing telephone numbers 17
15 - Dialling stored numbers 18
Options:
16 - Direct Vibe handset 19
17 - Shaker 20
18 - Headset with microphone 20
Guarantee 21
For product support and help visit our
website at www.geemarc.com
telephone [phone]
or fax [phone]
Index

5
IndexDescription
Reception tone
adjustment
Last number redial
Memory storing
Mute
Flashing incoming ring indicator
Direct memories
3 emergency
numbers Reception volume
adjustment
Time break recall
Extra volume and
tone adjustment
Handset cord socket
Clip for wall
mounting
Red light of tone/
volume activation
Speaker volume
adjustement
Handsfree /
Headset button

Description
Battery
compartment
Time break
recall
Dialling mode
Pulse/Tone
Handset
cord socket
Memo card
Holes for wall
mounting
6

Description
7
Ring Hi/Low/
OFF Switch
Ring alarm
setting
Volume and tone
adjustment ON/OFF switch
Line socket
Hotel switch
message
Shaker socket
Headset socket Adaptator
socket

8
1- Connecting the telephone
- Connect the handset cord.
- Open the battery door by unscrewing the
retaining screw. Insert 4 x AAA alkaline batteries
(not included).
Snap the battery door in place.
In case of power failure, batteries are required
for the ring.
- Connect the line cord.
- Connect the shaker cord (optional).
- Connect the headset cord (optional).
- Connect the PTT plug to the wall socket.
- Connect the 12V DC adaptor cord to the
telephone.
- Connect the 12V DC adaptor to your
wall socket (**).
(**) Classified “hazardous voltage” according to EN60950 standard.
2- Alarm and ringer volume setting
A 3 position switch located on the right side
of the phone allows the settings below:
Setting up

9
(*) Classified TNV-3 according to EN60950 standard.
-
: Ringer and shaker are activated.
-
: Ringer and strobe flash are activated.
3- Ringer settings
A switch located on right side allows the ringer to
be switched HI,LOW,OFF:
: Off, : Low,
: Hi
Your phone comes with the ringer switched to
«High» and the melody set to «6».
Low Mid High
Melody 1 1 2 3
Melody 2 4 5 6(by default)
Melody 3 7 8 9
If you don’t like the ringer melody,you can choose
a new one by changing the settings as follow:
- Lift the handset.
- Press button.
- Press # button.
- Press any button 1 to 9.
Ringer will be activated on next call.
Setting up

10
- 0 : Only the ringer is activated.
4- Tone/Pulse switch (T/P)
The Tone/Pulse switch is factory pre-set to
Tone position (T). In the UK,all telephone
exchanges now use Tone dialling.If your phone
does not dial out, it is probably being used from
an older private switch- board (PBX). In this
case,theTone/Pulse switch must be moved to
Pulse.
5- Time break recall switch (270/100)
For the UK, the TBR switch is factory pre-set to
100ms. It can be switched to 270ms for other
locations or PBX’s.
6- Hotel message waiting switch
These are used with the new services provided on
hotel network. A switch located behind your
phone allows to set ON the hotel message waiting
function.When the switch is setting ON and when
you receivea message, the red light is
Setting up

11
lit to inform you that you have a message on
phone.
7- Wall mounting
Drill 2 holes in the wall (80 mm apart).
Insert the wall plugs and the screws leaving about
6 mm of the screws projecting from the wall. Slide
the telephone downwards to secure
Setting up




















































































































80 mm
6 mm
Screw

12
8- Answering incoming call
Without headset:
- When an incoming call is received, the phone
will ring, to answer the call lift the handset and
speak.
- On completion of the call, carefully replace the
handset in the cradle to release the line.
With headset (option):
- When an incoming call is received, and if you
wish to answer the call with the headset, press
the
/ button and speak.
- On completion of the call, press the /
button again to release the line.
In handsfree mode:
- When an incoming call is received, the phone
will ring, to answer the call press the /
button.
- On completion of the call, press the /
button to release the line.
Using the phone

13
9 - Volume and tone receiving adjustement
You can increase the volume and adjust the
receiving tone according to your own hearing
requirements.The button +40 dB allows extra-
receiving and tone functions to be activated or not
during the conversation.
When the function is activated, the red light of extra
receiving and tone function located near the button
+40 dB is lit. Adjust the TONE and VOLUME but-
tons to remove the level according to your own
hearing requirements.
TONE
Bass
+10db max
Treble
+10db max
Normal
Using the phone

14
Using the phone
Note:
When the switch located behind the phone
is ON, the extra-receiving and tone functions are
automatically activated each time you use the
phone.When the switch is switched OFF, you
will need to activate the function by pressing the
button + 40dB (or +60 dB for the AmpliPOWER
50). Tone and volume adjustment (20dB to 40dB
for the AmpliPOWER 40 and 30 dB to 60 dB for
the AmpliPOWER 50) is only activated when the
button is set to ON. When this button is set to OFF
only the volume can be adjusted from 0 dB to 20
dB (0 dB to 30 dB for the AmpliPOWER 50)
Volume
O dB 20 dB
20 dB* 40 dB*
*press button +40 dB
AmpliPOWER40
Volume
O dB 30 dB
30 dB** 60 dB**
**press button +60 dB
AmpliPOWER50

15
Using the phone
10- Making a call
Without headset:
- Lift the handset.
- Await the dial tone and dial required number.
- On completion of the call,carefully replace the
handset in the cradle.
With headset (option):
- Press the
/
button.
- Await the dial tone and dial required number.
- On completion of the call, press the
/
button
again to clear the line.
In handsfree mode
- Press the
/
button.
- Await the dial tone and dial required number.
- On completion of the call, press the
/
button
to release the line.
- If your correspondent doesn’t answer your call,
press the
/ button again to release the line.

16
Note:
- To deactivate the handsfree function during a call,
lift the handset.
To activate the handsfree function during a call,
press the /
button and place the handset on
the cradle.
- During a call in handsfree, you can adjust the
speaker volume to a desirable level.
Simply use the slide control VOLUME located on
the left of the unit.
11- Last number redial
- Lift the handset.
- Await the dial tone and press button.
- The previously dialled number will be automatically
redialled (not in use for memory numbers).
12- Recall, * & # Buttons
These are used with the new services provided on
digital exchanges.For details please contact your
network operator.
Using the phone

17
Using the phone
13- Mute button
If you wish to speak privately to someone else in
the room without your caller overhearing, press
and hold the
button.You will still be able to hear
the callers but they cannot hear you during the
mute operation.To resume normal conversation,
release the
button.
14- Storing telephone number
Your phone can store12 direct memories including
3 priorities numbers (21 digits maximum for each
memory).
For example, the 3 priority P1,P2,P3 memories
allow you to store the 3 numbers below:
- Local,Police station,
- Your doctor
- 1471

18
Using the phone
To store a number please follow instructions below:
- Lift the handset.
- Press
button.
- Press M1, M2, ..., or M9 or one of 3 priorities
numbers to store your number.
- Dial the number.
- Press
button again.
Numbers will be lost after a few hours if you
disconnect your phone. Entering a new number in
memory will automatically erase the previous
number.
15- Dialling stored number
- Lift the handset and await the dial tone.
- Press appropriate button M1, M2, ..., or M9 or
one of the 3 priorities P1,P2,P3 numbers, the
stored number will be dialled automatically.
To register your stored phone numbers,use the
index card located under the base.

19
Options
16- Direct vibe handset (optional)
If you have conductive hearing loss you can use a
Direct Vibe Handset, try placing the Direct Vibe
handset on your telephone,in front and slightly
below your ear or behind your ear to see which
position works best for you.
If you don’t have hearing loss you can use your
phone normally and put the receiver on your ear.
If you require a Direct Vibe Handset ref: CLA4 may
purchase it from your retailer or audiologist.
In case of difficulty please visit our website
(www.geemarc.com) or phone our HELPLINE
01707 384 438 .
To set up the Direct Vibe handset only disconnect
the standard handset on the handset socket then
replace it with the Direct Vibe Handset.

20
17- Shaker (Optional)
If you wish to complement you phone by using a
SHAKER ref: CLA2 connect the shaker plug in the
socket
located behind your phone.When an
incoming call is received, the shaker will be
activated during ringing.
Note: This option must be set in the ALARM AND
RINGER OPTIONS item (page 9) to be activated.
To purchase a SHAKER see item 1 above.
18- Headset with microphone (optional)
If you wish to answer or make calls by using a
Geemarc headset ref: CLA3, connect the headset
plug in the headset socket located behind your
phone.
Note:When using a headset, the speaker will be
activated and it’s recommended to adjust the spea-
ker to the low position.
Options
