gefran ADV200-...-DC Series Troubleshooting guide

...... Quick start up guide
Specification and installation
SIEIDrive
Field oriented vector AC Drive
for syncronous/asyncronous motors
ADV200
ADV200-...-DC

2ADV200 • Quick start up guide - Specification and installation
Information about this manual
The ADV200 Quick start guide is a handy-sized manual for mechanical installation, electrical
connection and fast start-up.
The manual explaining the functions and a description of the parameters and the manuals of
the expansions and field bus can be found on the CD provided with the drive.
Software version
This manual is updated according the software version V 5.X.0
Variation of the number replacing “X” have no influence on the functionality of the device.
The identification number of the software version is indicated on the identification plate of the
drive or can be checked with the Firmware ver.rel - PAR 490 parameter, menu 2.5.
General information
Note ! In industry, the terms “Inverter”, “Regulator” and “Drive” are sometimes interchanged. In this document, the
term “Drive” will be used.
Before using the product, read the safety instruction section carefully. Keep the manual in a
safe place and available to engineering and installation personnel during the product function-
ing period.
Gefran S.p.A has the right to modify products, data and dimensions without notice. The data
can only be used for the product description and they can not be understood as legally stated
properties.
Thank you for choosing this Gefran product.
We will be glad to receive any possible information which could help us improvingthis manual.
The e-mail address is the following: [email protected].
All rights reserved

ADV200 • Quick start up guide - Specification and installation 3
Table of contents
Information about this manual ................................................. 2
1 - Safety Precautions ............................................................... 6
1.1 Symbols used in the manual ............................................................................6
1.2 Safety precaution..............................................................................................7
1.3 General warnings .............................................................................................7
1.4 Instruction for compliance with UL Mark (UL requirements), U.S. and Canadian
electrical codes.......................................................................................................9
2 - Introduction to the product................................................ 11
2.1 Drive type designation ....................................................................................12
2.1.1 Parallel inverters ..............................................................................................................13
3 - Transport and storage........................................................ 14
3.1 General...........................................................................................................14
3.2 Permissible Environmental Conditions ...........................................................15
4 - Mechanical installation ...................................................... 16
4.1 Inclination and mounting clearance ................................................................16
4.2 Fastening positions.........................................................................................17
5 - Wiring Procedure................................................................ 22
5.1 Power section .................................................................................................25
5.1.1 Cable Cross Section ........................................................................................................25
5.1.2 Connection of shielding ...................................................................................................27
5.1.3 EMC guide line ................................................................................................................28
5.1.4 Block diagram power section...........................................................................................29
5.1.5 Internal EMC filter ............................................................................................................31
5.1.6 Power line connection......................................................................................................32
5.1.7 Input mains choke (L1) ....................................................................................................35
5.1.8 Motor connection .............................................................................................................36
5.1.9 Braking unit connection (optional) ...................................................................................37
5.1.10 Parallel connection on the AC (Input) and DC (Intermediate Circuit) side of several
inverters ....................................................................................................................................38
5.1.11 Parallel DC connection...................................................................................................39
5.1.12 Connection of fans.........................................................................................................40
5.2 Regulation section ..........................................................................................42
5.2.1 Removing the terminal cover ........................................................................................... 42
5.2.2 Cable Cross Section ........................................................................................................42
5.2.3 Regulation section connection.........................................................................................42
5.2.4 Switches, jumpers and LED............................................................................................. 44
5.2.5 Power supply unit regulation card (only for sizes ≥71600) .............................................47
5.3 Braking ...........................................................................................................49
5.3.1 Braking unit......................................................................................................................49
5.4 Encoder ..........................................................................................................51
5.5 Serial interface (XS connector).......................................................................51
5.5.1 Drive / RS 485 Port (not insulated) point-to-point connection.......................................... 51
5.5.2 Drive / RS485 port point-to-point connection (with insulation).........................................53
5.5.3 RS 485 multi-drop connection .........................................................................................53
5.6 Typical connection diagrams ..........................................................................54
6 - Use of the keypad ............................................................... 58
6.1 Description......................................................................................................58
6.2 Navigation.......................................................................................................59
6.2.1 Scanning of the first and second level menus ................................................................. 59
6.2.2 Display of a parameter.....................................................................................................59
6.2.3 Scanning of the parameters ............................................................................................ 60
6.2.4 List of the last parameters modified.................................................................................60
6.2.5 “Goto parameter” function................................................................................................60

4ADV200 • Quick start up guide - Specification and installation
6.3 Parameter modification...................................................................................61
6.4 How to save parameters.................................................................................62
6.5 Configuration of the display ............................................................................63
6.5.1 Language selection..........................................................................................................63
6.5.2 Selection of Easy / Export mode...................................................................................... 63
6.5.3 Startup display .................................................................................................................63
6.5.4 Back-lighting of the display ..............................................................................................63
6.6 Alarms.............................................................................................................64
6.6.1 Alarm reset.......................................................................................................................64
6.7 Messages .......................................................................................................64
6.8 Saving and recovery of new parameter settings ............................................65
6.8.1 Selection of the keypad memory .....................................................................................65
6.8.2 Saving of parameters on the keypad ...............................................................................65
6.8.3 Load parameters from keypad.........................................................................................66
6.8.4 Transfer of parameters between drives ...........................................................................66
7 - Commissioning via keypad (STARTUP WIZARD) ............ 67
7.1 Startup Wizard................................................................................................71
7.1.1 Startup Wizard for Asynchronous Motors ........................................................................71
7.1.2 Startup Wizard for Synchronous Motors..........................................................................79
7.2 First customized start-up ................................................................................86
7.2.1 For Asynchronous Motors................................................................................................86
7.2.2 For Synchronous Motors and FOC-CL control ................................................................ 90
7.3 Programming ..................................................................................................94
7.3.1 Menu display modes........................................................................................................94
7.3.3 Variable interconnections mode.......................................................................................95
7.3.4 Multiple destination ..........................................................................................................97
8 - Troubleshooting.................................................................. 98
8.1 Alarms.............................................................................................................98
8.1.1 Speed fbk loss alarm according to the type of feedback ............................................... 104
8.2 Messages .....................................................................................................110
9 - Specification ..................................................................... 116
9.1 Environmental Conditions.............................................................................116
9.2 Standards .....................................................................................................116
9.3 Accuracy (Asyncronous)...............................................................................116
9.3.1 Current control ............................................................................................................... 116
9.3.2 Speed control................................................................................................................. 116
9.3.3 Speed control limits ....................................................................................................... 117
9.3.4 Torque control ................................................................................................................ 117
9.3.5 Overload ........................................................................................................................ 117
9.4 Accuracy (Synchronous)...............................................................................117
9.4.1 Current control ............................................................................................................... 117
9.4.2 Speed control................................................................................................................. 117
9.4.3 Initial torque limit............................................................................................................ 117
9.4.4 Overload ........................................................................................................................ 117
9.4.5 Flux reduction ................................................................................................................ 118
9.5 DC circuit ......................................................................................................118
9.6 Input electrical data ......................................................................................119
9.6.1 AC power supply............................................................................................................ 119
9.6.2 DC power supply ...........................................................................................................120
9.7 Output electrical data....................................................................................121
9.7.1 Derating values for switching frequency ........................................................................ 123
9.7.2 Overload for output frequency ....................................................................................... 124
9.8 Voltage level of the inverter for safe operations ...............................................126
9.9 Cooling .........................................................................................................127
9.10 Weight and dimensions ..............................................................................128
10 - Options ............................................................................ 137
10.1 Optional external fuses ..............................................................................137
10.1.1 AC input side fuses (F1) ..............................................................................................137
10.1.2 Fuses of the power section DC input side (F2)............................................................ 138

ADV200 • Quick start up guide - Specification and installation 5
10.2 Choke .........................................................................................................139
10.2.1 Optional input chokes (L1)...........................................................................................139
10.2.2 Optional external choke (L2)........................................................................................ 139
10.3 External EMC filter (optional)......................................................................144
10.4 Braking resistor (optional)...........................................................................146
10.5 Installation of optional cards .......................................................................147
10.5.1 SLOT / Encoder Card Management ............................................................................ 148
10.5.2 Procedure ...................................................................................................................149
10.5.3 Shielding of optional card connections ........................................................................ 150
Appendix 1 - Parallel connection (400 ... 1000kW sizes).... 151
A 1.1 Introduction................................................................................................151
A 1.2 MS-SL interface cable wiring sizes 400...710 kW .....................................153
A 1.2 MS-SL interface cable wiring sizes 900...1000 kW ...................................154
A 1.4 Jumpers and Switches ..............................................................................155
A 1.5 LEDs..........................................................................................................155
A 1.6 Scheda EXP-SFTy-ADV............................................................................157
Appendix 2 - Miscellaneous.................................................. 158
A 2.1 DC-link capacity ........................................................................................158
A 2.2 Encoders ...................................................................................................159
A.2.3 - Phasing .......................................................................................................................161

6ADV200 • Quick start up guide - Specification and installation
1 - Safety Precautions
1.1 Symbols used in the manual
Indicates a procedure, condition, or statement that, if not strictly observed, could result
in personal injury or death.
Indique le mode d’utilisation, la procédure et la condition d’exploitation. Si ces consignes ne
sont passtrictement respectées, il y a des risques de blessures corporelles ou de mort.
Indicates a procedure, condition, or statement that, if not strictly observed, could result
in damage to or destruction of equipment.
Indique et le mode d’utilisation, la procédure et la condition d’exploitation. Si ces consignes
ne sont pas strictement respectées, il y a des risques de détérioration ou de destruction des
appareils.
Indicates that the presence of electrostatic discharge could damage the appliance.
When handling the boards, always wear a grounded bracelet.
Indique que la présence de décharges électrostatiques est susceptible d’endommager l’appa-
reil. Toujours porter un bracelet de mise à la terre lors de la manipulation des cartes.
Indicates a procedure, condition, or statement that should be strictly followed in order to
optimize these applications.
Indique le mode d’utilisation, la procédure et la condition d’exploitation. Ces consignes doivent
êtrerigoureusement respectées pour optimiser ces applications.
Note ! Indicates an essential or important procedure, condition, or statement.
Indique un mode d’utilisation, de procédure et de condition d’exploitation essentiels ou importants
Qualified personnel
For the purpose of this Instruction Manual , a “Qualified person” is someone who
is skilled to the installation, mounting, start-up and operation of the equipment and
the hazards involved. This operator must have the following qualifications:
- trained in rendering first aid.
- trained in the proper care and use of protective equipment in accordance with
established safety procedures.
- trained and authorized to energize, de-energize, clear, ground and tag circuits
and equipment in accordance with established safety procedures.
Personne qualifiée
Aux fins de ce manuel d’instructions, le terme « personne qualifiée » désigne toute personne
compétente en matière d’installation, de montage, de mise en service et de fonctionnement
de l’appareil et au fait des dangers qui s’y rattachent. L’opérateur en question doit posséder
les qualifications suivantes :
- formation lui permettant de dispenser les premiers soins
- formation liée à l’entretien et à l’utilisation des équipements de protection selon les consigne
de sécurité en vigueur
- formation et habilitation aux manoeuvres suivantes : branchement, débranchement,
Warning!
Caution
Attention

ADV200 • Quick start up guide - Specification and installation 7
vérification des isolations, mise à la terre et étiquetage des circuits et des appareils selon les
consignes de sécurité en vigueur
Use for intended purpose only
The power drive system (electrical drive + application plant) may be used only for
the application stated in the manual and only together with devices and compo-
nents recommended and authorized by Gefran.
Utiliser uniquement dans les conditions prévues
Le système d’actionnement électrique (drive électrique + installation) ne peut être utilisé que
dans les conditions d’exploitation et les lieux prévus dans le manuel et uniquement avec les
dispositifs et les composants recommandés et autorisés par Gefran.
1.2 Safety precaution
The following instructions are provided for your safety and as a means of prevent-
ing damage to the product or components in the machines connected. This sec-
tion lists instructions, which apply generally when handling electrical drives.
Specific instructions that apply to particular actions are listed at the beginning of
each chapters.
Les instructions suivantes sont fournies pour la sécurité de l’utilisateur tout comme pour éviter
l’endommagement du produit ou des composants à l’intérieur des machines raccordées. Ce
paragraphe dresse la liste des instructions généralement applicables lors de la manipulation
des drives électriques.
Les instructions spécifiques ayant trait à des actions particulières sont répertoriées au début
de chaque chapitre.
Read the information carefully, since it is provided for your personal safety and will
also help prolong the service life of your electrical drive and the plant you connect
to it.
Lire attentivement les informations en matière de sécurité personnelle et visant par ailleurs à
prolonger la durée de vie utile du drive tout comme de l’installation à laquelle il est relié.
1.3 General warnings
This equipment contains dangerous voltages and controls potentially dangerous rotat-
ing mechanical parts. Non-compliance with Warnings or failure to follow the instructions
contained in this manual can result in loss of life, severe personal injury or serious
damage to property.
Cet appareil utilise des tensions dangereuses et contrôle des organes mécaniques en mou-
vement potentiellement dangereux. L’absence de mise en pratique des consignes ou le non-
respect des instructions contenues dans ce manuel peuvent provoquer le décès, des lésions
corporelles graves ou de sérieux dégâts aux équipements.
This equipment contains dangerous voltages and controls potentially dangerous rotat-
ing mechanical parts. Non-compliance with Warnings or failure to follow the instructions
contained in this manual can result in loss of life, severe personal injury or serious
damage to property.
Les drives occasionnent des mouvements mécaniques. L’utilisateur est tenu de s’assurer
que de tels mouvements mécaniques ne débouchent pas sur des conditions d’insécurité.
Les butées de sécurité et les seuils d’exploitation prévus par le fabricant ne doivent être ni
contournés ni modifiés.
Only suitable qualified personnel should work on this equipment, and only after becom-
ing familiar with all safety notices, installation, operation and maintenance procedures
contained in this manual. The successful and safe operation of this equipment is
Warning!

8ADV200 • Quick start up guide - Specification and installation
dependent upon its proper handling,installation, operation and maintenance.
Seul un personnel dûment formé peut intervenir sur cet appareil et uniquement après avoir
assimilé l’ensemble des informations concernant la sécurité, les procédures d’installation, le
fonctionnement et l’entretien contenues dans ce manuel. La sécurité et l’efficacité du fonction-
nement de cet appareil dépendent du bon accomplissement des opérations de manutention,
d’installation, de fonctionnement et d’entretien.
In the case of faults, the drive, even if disabled, may cause accidental movements if it
has not been disconnected from the mains supply.
En cas de panne et même désactivé, le drive peut provoquer des mouvements fortuits s’il n’a
pas été débranché de l’alimentation secteur.
Electrical Shock
The DC link capacitors remain charged at a hazardous voltage even after cutting off the
power supply.
Never open the device or covers while the AC Input power supplyis switched on. Mini-
mum time to wait before working on the terminals or inside the device is listed in section
9.6 .
Risque de décharge électrique
Les condensateurs de la liaison à courant continu restent chargés à une tension dangereuse
même après que la tension d’alimentation a été coupée.
Ne jamais ouvrir l’appareil lorsqu’il est suns tension. Le temps minimum d’attente avant de
pouvoir travailler sur les bornes ou bien àl’intérieur de l’appareil est indiqué dans la section 9.6 .
Electrical Shock and Burn Hazard:
When using instruments such as oscilloscopes to work on live equipment, the oscil-
loscope’s chassis should be grounded and a differential probe input should be used.
Care should be used in the selection of probes and leads and in the adjustment of the
oscilloscope so that accurate readings may be made. See instrument manufacturer’s
instruction book for proper operation and adjustments to the instrument.
Décharge Èlectrique et Risque de Brúlure : Lors de l’utilisation d’instruments (par example
oscilloscope) sur des systémes en marche, le chassis de l’oscilloscope doit être relié à la terre
et une sonde différentiel devrait être utilisé en entrée. Les sondes et conducteurs doivent être
choissis avec soin pour effectuer les meilleures mesures à l’aide d’un oscilloscope. Voir le
manuel d’instruction pour une utilisation correcte des instruments.
Fire and Explosion Hazard:
Fires or explosions might result from mounting Drives in hazardous areas such as loca-
tions where flammable or combustible vapors or dusts are present. Drives should be
installed away from hazardous areas, even if used with motors suitable for use in these
locations.
Risque d’incendies et d’explosions: L’utilisation des drives dans des zônes à risques (pré-
sence de vapeurs ou de poussières inflammables), peut provoquer des incendies ou des
explosions. Les drives doivent être installés loin des zônes dangeureuses, et équipés de
moteurs appropriés.

ADV200 • Quick start up guide - Specification and installation 9
1.4 Instruction for compliance with UL Mark (UL require-
ments), U.S. and Canadian electrical codes
Short circuit ratings
ADV200 inverters must be connected to a grid capable of supplying a symmetrical
short-circuit power of less than or equal to “xxxx A rms (at 480 V +10% V max).
The values of the “xxxx” A rms short-circuit current, in accordance with UL require-
ments (UL 508 c), for each motor power rating (Pn mot in the manual) are shown
in the table below.
Short current rating
Pn mot (kW) SCCR ( A ) @480Vac
1,1...37,3 5000
39....149 10000
150....398 18000
299.....447 30000
448 ... 671 42000
672 ... 1193 85000
Note! Drive will be protected by semiconductor Fuse type as specified in the instruction manual.
Branch circuit protection
In order to protect drive against over-current use fuses specified in par. “10.1
Optional external fuses”, page 137.
Environmental condition
The drive has to be considered “Open type equipment”. Max surrounding air
temperature equal to 40°C. Pollution degree 2.
Wiring of the input and output power terminals
Use UL listed cables rated at 75°C and round crimping terminals. Crimp terminals
with tool recommended by terminal manufacturer.
Field wiring terminals shall be used with the tightening torque specified in par.
“5.1.1 Cable Cross Section”, page 25.
Over-voltage control
In compliance with CSA-requirements Overvoltage at mains terminal is achieved
installing an overvoltage protection device as for :
Type OVR 1N 15 320 from ABB or similar.
Minimum time required for safe DC-link voltage
Before removing drive cover in order to access internal parts, after mains discon-
nection wait for time as follow :
Drive size Safe time ( sec )
size 1.....5 300
size 6...7 and Parallels 300

10 ADV200 • Quick start up guide - Specification and installation
Over-speed; over-load/current limit; motor overload
Drive incorporate over-speed, over-current/current limit, motor overload protection.
Instruction manual specify degree of protection and detailed installation instruction.
Overload protection for solid state motor.
The drive is provided with motor overload protection. This protection is imple-
mented as a software function. The degree of protection and detailed installation
instructions are specified in the instruction manual.*
*Applicable up to 9 May 2013.
New requirement. Applicable as from 9 May 2013.
The drive is not provided with the internal motor overload protection (software
function) as required under UL 508c as from 9 May 2013.
The drive is designed for use with motors with integrated thermal overload protec-
tion.
The integrated thermal overload protection signal must be connected to the equip-
ment, starting from a contact, on the “digital input connector” terminal, pins 4 and
10, that accepts a maximum of 24 VDC, 5 mA. The final result of this signal is the
switching of the motor control device output to solid state OFF.

ADV200 • Quick start up guide - Specification and installation 11
2 - Introduction to the product
The new inverter series “SIEIDrive ADV200” represents an innovative concept in
drive technology, as a result of the constant technological research and of the ex-
perience that the Gefran Group has acquired keeping a constant presence aside
that of the major sector players.
The new range has been engineered and developed to satisfy the real needs of
System Integrators and OEM’s in order to provide them the best innovations and
economical competitiveness in the international markets.
Based on full mechanical modularity and on a powerful, intuitive and “fully open”
programming platform, ADV200 offers absolute integration flexibility with high-
end performance in any system architectures of the most advanced automation
environments.
• Modularity
An innovative concept of integrated technology that offers full modularity. Mountable
side by side and with accessories specifically dedicated to system solutions, ADV200
has been engineered to make installation easy for any operator, both in existing
systems and in specific machine solutions, always offering a real reduction of required
space in the cabinet and the best manageability.
• Integrated Quality
ADV200 integrates the fundamental devices for an absolute quality level, such as the
DC choke that ensures maximum reliability in any conditions of working and the input
filter that renders the drive in compliance with the EMC normative EN61800-3. Note: the
choke and filter are not present in ADV200-DC models.
• Fast Access
Structured to offer simple and fast management of the product in any situation of instal-
lation and mounting. From the terminal access to the rack assembling of the options,
each operation is quick and easy.
• Smart Connections
Dedicated accessories and fully removable terminals, ensure simple and fast installa-
tion and start-up in compliance with the EMC normative.
• Options
ADV200 manages up to 3 option cards.
• Safety Card
Integrated on board as the 4th option (ADV200-...-SI models), the EXP- SFTy card al-
lows the motor to be disabled without the use of a safety contactor on the drive output,
guaranteeing compliance to the directive for machine safety EN61800-5-2 SIL3.
The EXP- SFTy card is integrated as standard in the master inverter of 400 to 1000 kW
parallel versions.
• Serial Line
Integrated standard RS485 serial line with Modbus RTU protocol, for peer-to-peer or
multidrop connections (with OPT-RS485-ADV card).
• Back-Up Supply
ADV200 can be supplied through an external +24Vdc supply in order to be kept active
in case of mains input loss, ensuring in this situation the operation of all monitoring
functions, programming and any connected fieldbus network.
• Cables shield
OMEGA clamp to grounding 360° of shielded cables.

12 ADV200 • Quick start up guide - Specification and installation
2.1 Drive type designation
The main technical characteristic of the drive are showed in the product code and
in the nameplate. I.e. product code:
ADV 1 040 -K B X -4 -XX YY -DC -SI
Safety card EXP-SFTy-ADV included
DC bus power supply version
Parallel version only:
XX : MS = MASTER
SL = SLAVE
YY : 04 = 400.0 kW
05 = 500.0 kW
06 = 630.0 kW
07 = 710.0 kW
09 = 900.0 kW
10 = 1000.0 kW
Rated voltage :
4= 400 Vac 4A = 460 Vac
Software: X = standard
Braking unit:
X = non included B = included
Keypad:
X = not included K = included
Drive power, in kW:
007 = 0.75 kW
015 = 1.5 kW
022 = 2.2 kW
030 = 3.0 kW
040 = 4.0 kW
055 = 5.5 kW
075 = 7.5 kW
110 = 11.0 kW
150 = 15.0 kW
185 = 18.5 kW
220 = 22.0 kW
300 = 30.0 kW
370 = 37.0 kW
450 = 45.0 kW
550 = 55.0 kW
750 = 75.0 kW
900 = 90.0 kW
1100 = 110.0 kW
1320 = 132.0 kW
1600 = 160.0 kW
2000 = 200.0 kW
2500 = 250.0 kW
3150 = 315.0 kW
3550 = 355.0 kW
Mechanical drive sizes:
1 = size 1
2 = size 2
3 = size 3
4 = size 4
5 = size 5
6 = size 6
7 = size 7
Drive ADV200 series
Identification Nameplate
Type : ADV1040 -KBX S/N: 07012345
Inp: 400Vac-480Vac (Fctry set=400) 50/60Hz 3Ph
11.1A@400Vac 10A@480Vac
Out : 0-480Vac 500Hz 3Ph 4kW@400Vac 5 Hp @ 460Vac
9.5A @400V Ovld . 150%-60s 8.55A@460V Ovld.150%-60s
13 A @400V Ovld . 110%-60s 11.7A@460V Ovld.110%-60s
®
Drive model
Serial number
Input (mains supply, frequency, AC Input
Current at constant torque)
Output (Output voltage, frequency, power,
current, CT and VT overloads)
Approvals IND. CONT. EQ.
31KF
Firmware & cards revision level nameplate
Firmware HW release S/N 07012345 Prod.
Release D F P R S BU SW . CFG CONF
A 1.00 A -.A -.- 1.000 A1
Cards revision
Firmware revision
Power
Regulation
Safety
Braking unit
Software
revision
Product
configuration

ADV200 • Quick start up guide - Specification and installation 13
The inverter must be selected according to the rated current of the motor.
The rated output current of the drive must be higher than or equal to the rated cur-
rent of the motor used.
The speed of the three-phase motor is determined by the number of pole pairs and
the frequency (nameplate, data sheet) of the motor concerned.
Operation above the rated frequency and speed of the motor must take into ac-
count the specifications given by the manufacturer losses (bearings, unbalance
etc.). This also applies to temperature specifications for continuous operation under
20 Hz (poor motor ventilation, not applicable to motors with external ventilation).
2.1.1 Parallel inverters
• Inverters of between 400 kW and 710 kW comprise one master and one
slave.
• Inverters of over 900 kW comprise one master and two slaves.
When placing your order please give the code number of the master and slave
and number of these:
Power code Description (Designation) Power code Description (Designation)
400kW S9O25M ADV-72000-KXX-4-MS 04 -SI 400kW S9O25MC ADV-72000-KXX-4- MS 04-DC- SI
S9O25S ADV-72000-XXX-4-SL S9O25SC ADV-72000-KXX-4- SL-DC
500kW S9O26M ADV-72500-KXX-4-MS 05 -SI 500kW S9O26MC ADV-72500-KXX-4-MS 05-DC-SI
S9O26S ADV-72500-XXX-4-SL S9O26SC ADV-72500-KXX-4-SL-DC
630kW S9O27M ADV-731500-KXX-4-MS 06 -SI 630kW S9O27MC ADV-73150-KXX-4-MS 06-DC-SI
S9O27S ADV-731500-XXX-4-SL S9O27SC ADV-73150-KXX-4-SL-DC
710kW S9O28M ADV-735500-KXX-4-MS 07 -SI 710kW S9O28MC ADV-73550-KXX-4- MS 07-DC-SI
S9O28S ADV-735500-XXX-4-SL S9O28SC ADV-73550-KXX-4- SL-DC
900kW
S9O27M1 ADV-731500-KXX-4-MS 09 -SI
900kW
S9O27M2 ADV-73150-KXX-4-MS 09-DC-SI
S9O27S ADV-731500-XXX-4-SL S9O27SC ADV-73150-KXX-4-SL-DC
S9O27S ADV-731500-XXX-4-SL S9O27SC ADV-73150-KXX-4-SL-DC
1000kW
S9O28M1 ADV-735500-KXX-4-MS 10-SI
1000kW
S9O28M2 ADV-73550-KXX-4- MS 10-DC-SI
S9O28S ADV-735500-XXX-4-SL S9O28SC ADV-73550-KXX-4- SL-DC
S9O28S ADV-735500-XXX-4-SL S9O28SC ADV-73550-KXX-4- SL-DC
630kW S9O29M ADV-73150-KXX-4A-MS 06-SI 630kW S9O29MC ADV-73150-KXX-4A-MS 06-DC-SI
S9O29S ADV-73150-KXX-4A -SL S9O29SC ADV-73150-KXX-4A -SL-DC
710kW S9O30M ADV-73550-KXX-4A- MS 07-SI 710kW S9O30MC ADV-73550-KXX-4A- MS 07-DC-SI
S9O30S ADV-73550-KXX-4A- SL S9O30SC ADV-73550-KXX-4A- SL-DC
900kW
S9O29M1 ADV-73150-KXX-4A-MS 09-SI
900kW
S9O29M2 ADV-73150-KXX-4A-MS 09-DC-SI
S9O29S ADV-73150-KXX-4A -SL S9O29SC ADV-73150-KXX-4A -SL-DC
S9O29S ADV-73150-KXX-4A -SL S9O29SC ADV-73150-KXX-4A -SL-DC
1000kW
S9O30M1 ADV-73550-KXX-4A- MS 10-SI
1000kW
S9O30M2 ADV-73550-KXX-4A- MS 10-DC-SI
S9O30S ADV-73550-KXX-4A- SL S9O30SC ADV-73550-KXX-4A- SL-DC
S9O30S ADV-73550-KXX-4A- SL S9O30SC ADV-73550-KXX-4A- SL-DC

14 ADV200 • Quick start up guide - Specification and installation
3 - Transport and storage
Correct transport, storage, erection and mounting, as well as careful operation and
maintenance are essential for proper and safe operation of the equipment.
Protect the inverter against physical shocks and vibration during transport and storage.
Also be sure to protect it against water (rainfall) and excessive temperatures.
Le bon accomplissement des opérations de transport, de stockage, d’installation et de mon-
tage, ainsi que l’exploitation et l’entretien minutieux, sont essentiels pour garantir à l’appareil
un fonctionnement adéquat et sûr.
If the Drives have been stored for longer than two years, the operation of the DC link
capacitors may be impaired and must be “reformed”. Before commissioning devices
that have been stored for long periods, connect them to a power supply for two hours
with no load connected in order to regenerate the capacitors, (the input voltage has to
be applied without enabling the drive).
En cas de stockage des variateurs pendant plus de deux ans, il est conseillé de contrôler
l’état des condensateurs CC avant d’en effectuer le branchement. Avant la mise en service
des appareils, ayant été stockés pendant long temps, il faut alimenter variateurs à vide pen-
dant deux heures, pour régénérer les condensateurs : appliquer une tension d’alimentation
sans actionner le variateur.
3.1 General
A high degree of care is taken in packing the ADV Drives and preparing them for
delivery. They should only be transported with suitable transport equipment (see
weight data). Observe the instructions printed on the packaging. This also ap-
plieswhen the device is unpacked and installed in the control cabinet.
Upon delivery, check the following:
- the packaging for any external damage
- whether the delivery note matches your order.
Open the packaging with suitable tools. Check whether:
- any parts were damaged during transport
- the device type corresponds to your order
In the event of any damage or of an incomplete or incorrect delivery please notify
the responsible sales offices immediately. The devices should only be stored in
dry rooms within the specified temperature ranges .
Note! A certain degree of moisture condensation is permissible if this arises from changes in temperature.
This does not, however, apply when the devices are in operation. Always ensure that there is no
moisture condensation in devices that are connected to the power supply!
Caution

ADV200 • Quick start up guide - Specification and installation 15
3.2 Permissible Environmental Conditions
Temperature
storage ____________________ -25…+55°C (-13…+131°F), class 1K4 per EN50178
-20…+55°C (-4…+131°F), for devices with keypad
transport___________________ -25…+70°C (-13…+158°F), class 2K3 per EN50178
-20…+60°C (-4…+140°F), for devices with keypad
Air humidity
storage ____________________ 5% to 95 %, 1 g/m3to 29 g/m3(class 1K3 as per EN50178)
transport___________________ 95 % (3), 60 g/m3(4)
A light condensation of moisture may occur for a short time occasionally if the device is not in operation
(class 2K3 as per EN50178)
Air pressure:
storage ____________________ [kPa] 86 to 106 (class 1K4 as per EN50178)
transport___________________ [kPa] 70 to 106 (class 2K3 as per EN50178)
(3) Greatest relative air humidity occurs with the temperature @ 40°C (104°F) or if the temperature of the
device is brought suddenly from -25 ...+30°C (-13°...+86°F).
(4) Greatest absolute air humidity if the device is brought suddenly from 70...15°C (158°...59°F).
The drive is suitable for use under the environmental service conditions (climate,
mechanical, pollution, etc.) defined as usual service conditions according to
EN61800-2.
Attention

16 ADV200 • Quick start up guide - Specification and installation
4 - Mechanical installation
The Drive must be mounted on a wall that is constructed of heat resistant material.
While the Drive is operating, the temperature of the Drive’s cooling fins can rise to a
temperature of 158° F (70°C).
Le drive doit être monté sur un mur construit avec des matériaux résistants à la chaleur.
Pendant le fonctionnement du drive, la température des ailettes du dissipateur thermique peut
arriver à 70°C (158° F).
Because the ambient temperature greatly affects Drive life and reliability, do not install
the Drive in any location that exceeds the allowable temperature.
Étant donné que la température ambiante influe sur la vie et la fiabilité du drive, on ne devrait
pasinstaller le drive dans des places ou la temperature permise est dépassée.
Be sure to remove the desicant dryer packet(s) when unpacking the Drive. (If not
removed these packets may become lodged in the fan or air passages and cause the
Drive to overheat).
Lors du déballage du drive, retirer le sachet déshydraté. (Si celui-ci n’est pas retiré, il em-
pêche la ventilation et provoque une surchauffe du drive).
Protect the device from impermissible environmental conditions (temperature, humidity,
shock etc.).
Protéger l’appareil contre des effets extérieurs non permis (température, humidité, chocs etc.).
4.1 Inclination and mounting clearance
The Drives must be mounted in such a way that the free flow of air is ensured see
paragraph “9.9 Cooling”, page 127.
Maximum angle of inclination ___________30° (referred to vertical position)
Minimum top and bottom distance _______150 mm (≥ADV71600 = 400mm)
Minimum free space to the front _________25 mm
Minimum distance between drives _______none
Minimum distance to the side with the cabinet 10 mm
10 mm [ 0.4" ]≥
≥
400 mm [ 15.75" ] (ADV 7...)
150 mm [ 6" ]
≥
25 mm [ 0.98” ]≥10 mm [ 0.4" ]≥
≥150 mm [ 6" ]
≥400 mm [ 15.75" ] (ADV 7...)
Caution

ADV200 • Quick start up guide - Specification and installation 17
4.2 Fastening positions
Taglia 3
Size 3
150 [5.91”]
500.1 [19.7”]
(A)
No. 4 screw 5MA
(B)
(A) 120 [4.72”]
Taglia 2
Size 2
376.6 [14.83”]
Taglia 1
Size 1
No. 4 screw 5MA
(B)
100 [3.94”]
306.4 [12.06”]
Fissaggio a muro
Wall mounting
(A)
126.2 [4.97”]
364.4 [14.33”]
320 [12.6”]
82 [3.23”]
(B)
No. 4 screw 5MA
156.2 [6.15”]
392 [15.43”]
440 [17.32”]
135 [5.31”]
187.6 [7.4”]
557 [21.93”]
517 [20.35”]
110 [4.33”]
Taglia 4
Size 4
220 [8.66”]
612 [24.09”]
595 [23.43”]
(A)
(B)
No. 4 screw 6MA
268 [10.55”]
682 [26.85”]
267 [10.51”]
Fissaggio a muro
Wall mounting
No. 5 screw 6MA
Taglia 6
Size 6
Taglia 5
Size 5
(B)
(A)
(B)
(A)
No. 4 screw 6MA
422 [16.61”]
350 [13.78”]
175 [6.89”]
836 [32.91”]
175 [6.89”]
853 [33.58”]
311 [12.24”]
220 [8.66”]
853 [33.58”]
748 [29.45”]
265 [10.43”]

18 ADV200 • Quick start up guide - Specification and installation
ADV200-...-DC
Taglia 3
Size 3
150 [5.91”]
500.1[19.7”]
(A)
No. 4 screw 5MA
(B)
Fissaggio amuro
Wall mounting
187.6[7.4”]
517 [20.35”]
ADV200-...-DC
Taglia 4
Size 4
220 [8.66”]
612 [24.09”]
595 [23.43”]
(A)
(B)
No. 4 screw 6MA
268 [10.55”]
616 [24.25”]
267 [10.51”]
ADV200-...-DC
Taglia 5
Size 5
(B)
(A)
No. 4 screw 6MA
311 [12.24”]
190 [7.48”]
730.4 [28.76”]
748[29.45”]
265 [10.43”]
Fissaggio amuro
Wall mounting
No. 5screw 6MA
ADV200-...-DC
Taglia 61110
Size 61110
(B)
421 [16.57”]
350 [13.78”]
175 [6.89”]
836 [32.91”]
853 [33.58”]
(B)
(A) (A)
350 [13.78”]
175 [6.89”]
275 [10.83”]275 [10.83”]
421 [16.57”]
888 [34.96”]
No. 5screw 6MA
924.5[36.4”]
836 [32.91”]
865.5[34.07”]
ADV200-...-DC
Taglia 61320
Size 61320

ADV200 • Quick start up guide - Specification and installation 19
Taglia 7
Size 7
417 [16.42”]
177.8[7.00”]
355.6[140”]
1264[49.76”]
1209.5[47.62”]
Fissaggio amuro
Wall mounting
(B)
(A)
6.5
[0.26”]
6.5
[0.26”]
Ø13
[0.51”]
19
[0.75”]
17.45
[0.69”]
15.25
[0.6”]
(A)
(B)
1407 [55.4”]
(*)Protezione in policarbonato trasparente
(*) Protective trasparent policarbonate
(*)
(*)
ADV200-...-DC
Taglia 7
Size 7
417 [16.42”]
177.8[7.00”]
355.6[140”]
1264[49.76”]
1209.5[47.62”]
(A)
(B)
(B)(A)
7.25
[0.29”]
5.5 [0.21”]
5.5 [0.21”]
15
[0.59”]
Ø
10 [0.39”]
11.25
[0.44”]
6.5 [0.26”]
Ø
13
[0.51”]
19
[0.75”]
6.5 [0.26”]
12.5 [0.49”]
12
[0.47”]
Taglie 1-2-3
Sizes 1-2-3
Taglia 4
Size 4
(B)(A)
Taglia 5
Size 5
(B)(A)
6.5 [0.26”]
19
[0.75”]
Ø
13
[0.51”]
6.5 [0.26”]
12
[0.47”]
12.75 [0.50”]
(B)(A)
Taglia 6
Size 6
6.5 [0.26”]
6.5 [0.26”]
Ø
13
[0.51”]
19
[0.75”]
24.95 [0.98”]
12
[0.47”]
Recommended screws for fastening
Size 1 (ADV 1...) Size 2 (ADV 2...) Size 3 (ADV 3...) 4 x M5 x 12 mm screws + Grover (spring-lock) washer + Flat washer
Size 4 (ADV 4...) Size 5 (ADV 5...) 4 x M6 x 16 mm screws + Grover (spring-lock) washer + Flat washer
Size 6 (ADV 6...) 5 x M6 x 16 mm screws + Grover (spring-lock) washer + Flat washer
Size 7 (ADV 7...) 6 x M6 x 16 mm screws + Grover (spring-lock) washer + Flat washer
Note! Other dimensions see chapter “9.10 Weight and dimensions”, page 128.

20 ADV200 • Quick start up guide - Specification and installation
417 [16.42”]
177.8[7.00”]
355.6[140”]
1264
[49.76”]
1209.5
[47.62”]
Fissaggio a muro
Wall mounting
(A)
(B)
417 [16.42”]
177.8[7.00”]
355.6[140”]
(A)
(B)
400 ... 710 kW
(*)Protezione in policarbonato trasparente
(*) Protective trasparent policarbonate
1407
[55.4”]
(*) (*)
(*)
417 [16.42”]
177.8[7.00”]
355.6[140”]
1264
[49.76”]
1209.5
[47.62”]
Fissaggio a muro
Wall mounting
(A)
(B)
417 [16.42”]
177.8[7.00”]
355.6[140”]
(A)
(B)
900 ... 1000 kW
417 [16.42”]
177.8[7.00”]
355.6[140”]
(A)
(B)
1407
[55.4”]
(*)Protezione in policarbonato trasparente
(*) Protective trasparent policarbonate
(*)(*)
(*) (*)
(*)
