gefran RADIUS APV 1700-2M-TL-US User manual

.... Installation & operation manual
APV-...-US
Solar Inverters
RADIUS Home
Single phase solar inverters

2 RADIUS Home
Informationaboutthismanual
Before using the product, read the safety instruction section carefully. Keep the manual in a safe place and
available to engineering and installation personnel during the product functioning period.
Gefran S.p.A has the right to modify products, data and dimensions without notice.
The data can only be used for the product description and they can not be understood as legally stated properties.
Thank you for choosing this Gefran product.
We will be glad to receive any possible information which could help us improving this manual. The e-mail
address is the following: [email protected].
All rights reserved.

RADIUS Home 3
Contents
1. Notesonthismanual...........................................................................................................................5
1.1 Validity............................................................................................................................................................5
1.2 Target Group ..................................................................................................................................................5
1.3 Safety .............................................................................................................................................................5
2. APV...-2M-TL-USInverter....................................................................................................................7
2.1 Overview ........................................................................................................................................................7
2.2 Identifying model and basic data sheet .........................................................................................................7
3. Unpackingandinspection...................................................................................................................8
4. Installation.............................................................................................................................................9
4.1 Safety instructions / Consignes de sécurité ...................................................................................................9
4.2 Selecting the mounting location ...................................................................................................................10
4.3 Mounting the wall mounting frame ...............................................................................................................10
4.4 Mounting the inverter on the wall mounting frame .......................................................................................11
4.5 Checking inverter installation .......................................................................................................................11
5. ElectricalConnection.........................................................................................................................12
5.1 System diagram with electrical connection of inverter .................................................................................12
5.2 Safety ...........................................................................................................................................................13
5.3 Connecting to the grid (AC utility) ................................................................................................................13
5.3.1 GRID standards ..........................................................................................................................................................13
5.3.2 Connection of the AC wiring (AC output) ....................................................................................................................14
5.4 Connect to PV Panel (DC input) ..................................................................................................................14
5.5 Commissioning checks ................................................................................................................................15
6. Display.................................................................................................................................................16
6.1 LCD display .................................................................................................................................................16
6.2 LCD control ..................................................................................................................................................16
6.3 Setting the LCD display ...............................................................................................................................18
7. Operatingmodes................................................................................................................................19
7.1 Normal mode ...............................................................................................................................................19
7.2 Fault mode ...................................................................................................................................................19
7.3 Shutdown mode ...........................................................................................................................................19
7.4 Automatic ON-OFF ......................................................................................................................................19
8. Inverterstatus.....................................................................................................................................20
9. Communications.................................................................................................................................21
9.1 Communications software instructions ........................................................................................................21
9.2 Monitoring ....................................................................................................................................................21
9.3 Detailed information .....................................................................................................................................21
10.Troubleshooting.................................................................................................................................22
10.1 System fault .................................................................................................................................................22
10.2 Inverter failure ..............................................................................................................................................23
11.Specications......................................................................................................................................24
12.Warrantyconditions...........................................................................................................................27
13.Contact.................................................................................................................................................28

4 RADIUS Home

RADIUS Home 5
1. Notesonthismanual
1.1 Validity
This manual describes the assembly, installation, commissioning and maintenance of the following RADIUS
Home - APV Inverters:
APV 1700-2M-TL-US
APV 2300-2M-TL-US
APV 3100-2M-TL-US
This manual does not cover any details concerning equipment connected to the APV ...-2M-TL-US ( i.e. PV
modules). Information concerning the connected equipment is available from the equipment manufacturer.
1.2 TargetGroup
This manual is for qualied personnel. Qualied personnel have received training and have demonstrated skills
and knowledge in the construction and operation of this device.
Qualied personnel are trained to deal with the dangers and hazards involved in installing electric devices.
Additionalinformation
You will nd further information on special topics in the download area at www.radius-Gefran.com .
1.3 Safety
AppropriateUsage
The RADIUS Home - APV is a PV Inverter that converts DC Current from PV generator into AC current. The
RADIUS Home - APV is suitable for mounting indoors and outdoors.
You can use the AC current generated as follows:
Householdgrid
Energy ows into the house grid. The consumers connected, for example, household appliances or lighting,
consume the energy. The energy left over is fed into the public grid. When the RADIUS Home - APV is not
gernerating any energy, e.g., at night, the connected consumers are supplied by the public grid.
The RADIUS Home - APV does not have its own energy meter. When energy is fed into the public grid, the
energy meter spins backwards.
Publicgrid
Energy is fed directly into the public grid. The RADIUS Home - APV is connected to a separate energy meter.
The energy produced is compensated at a rate dened by the utility company.
Standalonegrid
The RADIUS Home - APV is connected to a stand-alone grid. The energy generated is consumed directly on
site. Surplus energy can be stored in batteries.

6 RADIUS Home
Info Policies vary from one utility company to another. Consult with a representative of the local utility company before proceeding.
Les règles peuvent varier d’une entreprise de service public à une autre. Veuillez consulter un représentant de l’entreprise de
service public locale avant de concevoir et installer un système PV.
DCandACdisconnectswitch
Separate the RADIUS Home - APV securely from the grid and the PV generators using DC and AC disconnect
switch. DC and AC Switch shall be able to disconnect all ungrounded conductors after installation. You must
provide an AC circuit breaker. If DC Switch is included in the delivery of the RADIUS Home - APV, it must be
used for operating the inverter.
GroundingthePVmodules
The APV 1700-2M-TL-US, APV 2300-2M-TL-US and APV 3100-2M-TL-US is a transformerless inverter. Hence,
it has no galvanic separation. Do not ground the DC circuits of the PV modules connected to the RADIUS
Home - APV. Only ground the mounting frame of the PV modules.
If you connect grounded modules to the RADIUS Home - APV, the error message “PV ISO Low” is displayed.
We normally recommend monocrystalline silicon and polycrystalline silicon modules for transformerless tech-
nology. However, some thin-lm technologies have been developed which manufacturers claim can also be
used with a transformerless inverter.

RADIUS Home 7
2. APV...-2M-TL-USInverter
2.1 Overview
2.2 Identifyingmodelandbasicdatasheet
You can identify the PV inverter by the type label which is on the left side of the enclosure.
• The type of product (Type/Model).
• Device-specic characteristics.
• Certicates and approvals.
APV 1700-2M-TL-US
Nominal output power:
Nominal grid voltage:
Nominal grid frequency:
Nominal output current:
Gefran S.p. A - via Carducci,24 - 21040 Gerenzano (VA), Italy

8 RADIUS Home
3. Unpackingandinspection
Please check the contents of the shipping box upon receipt. It should contain the following:
B
D
E
C
A
Item Name Quantity
A Solar inverter 1
B Mounting frame 1
C Safety-lock screws 2
D Mounting screws 4
E Sleeve for mounting frame screws 4
RS485 terminals connection 2
Manuals & software on cd-rom 1

RADIUS Home 9
4. Installation
4.1 Safetyinstructions/Consignesdesécurité
A) All electrical installations must be carried out in accordance with the local and national electrical codes
ANSI/NFPA 70, NEC. The RADIUS Home - APV inverters are listed to UL1741/IEEE1547 . Do not remove
the casing. Inverter contains no user serviceable parts. Refer servicing to qualied service personnel.
Toute installation électrique doit être faite en accord avec les normes électriqueslocales et nationales
ANSI/NFPA 70, NEC. Les onduleurs RADIUS Home - APV sont listés à UL1741/IEEE1547. Ne pas
retirer le revêtement. L’onduleur contient des parties non utilisables. Veuillez vous référer à un employé
de service qualié.
B) Both AC and DC voltage sources are terminated inside the PV Inverter. Please disconnect these circuits
before servicing.
Les sources de voltage CA et CC se trouvent à l’intérieur de l’onduleur PV. Veuillez déconnecter ces
circuits avant manipulation.
C) When a photovoltaic panel is exposed to light, it generates a DC voltage. When connected to this equip-
ment, a photovoltaic panel will charge the DC link capacitors.
Lorsqu’un panneau photovoltaïque est exposé à la lumière, il génère un courant continu. Connecté à cet
équipement, un panneau photovoltaïque rechargera les condensateurs de liaison CC.
D) Energy stored in this equipment’s DC link capacitors presents a risk of electric shock. Even after the unit
is disconnected from the grid and photovoltaic panels, high voltages may still exist inside the PV-Invert-
er. Do not remove the casing until at least 5 minutes after disconnecting all power sources.
L’énergie stockée dans les condensateurs de liaison CC de cet équipement présentent un risqué de
choc électrique. Même après la déconnection de l’unité de la grille et des panneaux photovoltaïques,
une surtension peut toujours être présente dans l’onduleur PV. Ne pas retirer le revêtement jusqu’à au
moins 5 minutes après avoir déconnectés toutes les sources d’énergie.
E) This unit is designed to feed power to the public power grid (utility) only. Do not connect this unit to an
AC source or generator. Connecting the inverter to external devices could result in serious damage to
your equipment.
Cette unité a été conçue pour fournir de l’énergie uniquement aux réseaux électriques publics. Ne pas
connecter cette unité à une source de courant alternatif ou à un générateur. Connecter un onduleur à
des appareils externes peut causer de graves dommages à votre matériel.
F) Carefully remove the unit from its packaging and inspect for external damage. If you nd any imperfec-
tions, please contact your local dealer.
Retirer prudemment l’unité de son emballage et inspectez la pour d’éventuels dommages extérieurs. Si
vous trouvez quelconques imperfections, veuillez contacter votre revendeur local.
G) Although designed to meet all safety requirements, some parts and surfaces of inverter become hot
during operation. To reduce the risk of injury, do not touch the heat sink at the back of the PV Inverter or
nearby surfaces while Inverter is operating.
Bien que conçu an de remplir tous les critères de sécurité, certaines parties ou surfaces de l’onduleur
sont chaudes pendant son fonctionnement. An de réduire le risques de blessures, ne pas toucher le
dissipateur de chaleur à l’arrière de l’onduleur PV et toute surface avoisinante lors du fonctionnement de
l’onduleur.
Warning!

10 RADIUS Home
4.2 Selectingthemountinglocation
A) Raintight or wet location hubs that comply with the requirements of UL 514B for Conduit, Tubing and
Cable Fittings must be used.
B) The unit shall be mounted at least 914 mm (3 feet) above the ground.
C) The installation method and mounting location must be suitable for the weight and dimensions of the
inverter. Select a wall or solid vertical surface that can support the PV-Inverter.
D) Mount on a solid surface, the mounting location must be accessible at all times.
E) Installation can be vertical or tilted backwards by max. 15°.
F) The connection area must point downwards.
G) Do not install horizontally.
4.3 Mountingthewallmountingframe
A) Inverter requires adequate cooling space. Allow at least 20cm space above and below the inverter.
B) Using the mounting frame as a template, drill 4 holes as shown in the diagram.
C) Fix the mounting frame as shown in the diagram. Do not tighten the screws so that they are ush to the
wall. Leave 2 to 4 mm exposed.

RADIUS Home 11
4.4 Mountingtheinverteronthewallmountingframe
A) Hang the inverter on the mounting frame.
B) Insert safety-lock screws through the bottom section of the frame to secure the inverter.
4.5 Checkinginverterinstallation
A) Check the upper straps of PV-Inverter and ensure that it ts on the frame.
B) Check that the PV inverter is mounted securely by trying to raise it from the bottom. The PV-Inverter
should remain rmly attached.
C) Select the installation location so that the status display can be easily viewed.
D) Choose a strong mounting wall to prevent vibrations while inverter is operating.

12 RADIUS Home
5. ElectricalConnection
Allelectricalinstallationsmustbecarriedoutinaccordancewiththelocalandnationalelectricalcodes
ANSI/NFPA70,NEC.
Toute installation électrique doit être effectué en accord avec les norms électriques locales et nationales
ANSI/NFPA 70, NEC.
Policiesvaryfromoneutilitycompanytoanother.Consultwitharepresentativeofthelocalutilitycompany
beforedesigningandinstallingaPVsystem.
Les règles peuvent varier d’une entreprise de service public à une autre. Veuillez consulter un représentant
de l’entreprise de service public locale avant de concevoir et installer un système PV.
5.1 Systemdiagramwithelectricalconnectionofinverter
A) This unit or system is provided with xed trip limits; no single common connection point should exceed
30 kW.
B) PV Panel: Provide DC power to the inverter.
C) Inverter: converts DC (direct current) power from the PV panel(s) to AC (alternating current) power.
Because the inverter is grid-connected it controls the current amplitude according to the PV panel power
supply. The inverter always tries to convert the maximum power from your PV panel(s).
D) Connection system: This “interface” between Utility and PV inverter may consist of an electrical circuit
breaker, a fuse and connecting terminals. To comply with local safety standards and codes, the connec-
tion system should be designed and implemented by a qualied technician.
E) Utility: Referred to as “grid” in this manual, is the way your electricity company provides power to your
home. Please note that inverter can only be connected to low-voltage systems (namely, 230VAC, 50Hz).
Model DCbreaker(suggested) ACbreaker(suggested)
APV 1700-2M-TL-US ≥15A , >450VDC ≥15A, the breaker voltage must greater than the grid
voltage.
APV 2300-2M-TL-US ≥15A , >500VDC ≥15A, the breaker voltage must greater than the grid
voltage.
APV 3100-2M-TL-US ≥20A , >500VDC ≥20A, the breaker voltage must greater than the grid
voltage.
Position Description
A PV modules
B DC load circuit breaker
C RADIUS Home - APV-...-US inverter
D AC load circuit breaker
E Energy meter
F Utility grid
Warning!
Warning!

RADIUS Home 13
F) Wire Box
5.2 Safety
ThePVInvertermustbeconnectedtotheACgroundfromthegridviatheGroundTerminal(PE)
5.3 Connectingtothegrid(ACutility)
5.3.1 GRIDstandards
Before wiring the RADIUS Home - APV-...-US inverter, the installer needs to determine the grid conguration
that the inverter will be connected to. The RADIUS Home - APV-...-US inverter is factory-set for a 240 Vac split
phase connection.
However, you can choose the Net MODEL through the LCD to set the RADIUS Home - APV-...-US inverter to
the commonly used utility conguration types shown in the gure below.
Based on the local GRID standards, it is possible to select different connection types. The available congura-
tions are shown in the following table:
GRID STANDARD
L1
L3
L2
L1
L2 L3
L1
L2 L3
N
208 Vac
3phase-
240 Vac
3phase-
277
3phase-Y
TERMINAL 123123123
WIRE L1 L2 PE L1 L2 PE L1 N PE
NET MODEL NET MODEL : 2
(Option)
NET MODEL : 3
(Default)
NET MODEL : 4
(Option)
If several RADIUS Home - APV-...-US inverters are installed in a three-phase AC grid, it is recommended that the
inverters are distributed between the phases in order to reduce the power unbalances between the phases. Always
refer to the local standards.
Si plusieurs RADIUS Home - APV-...-US sont installés sur un réseau électrique à courant alternatif à trois phases. Il
est recommandé de distribuer les onduleurs entre les phases pour réduire les déséquilibres de puissance entre les
phases. Toujours vous référer aux normes locales.
Warning!
Attention

14 RADIUS Home
5.3.2 ConnectionoftheACwiring(ACoutput)
A)
Determine the correct grid (utility) configuration type, if it
is not 240 Vac split phase. You should use the LCD to set
the correct net model as detailed in sections 5.3.1 and
6.3.
B) Open the breaker or fuse between PV Inverter and the
grid.
C) Open the wire box cover and the knockout.
D) For the inverter, connect the AC wires of all net models as
shown in section 5.3.1.
E) Cable requirements
Model _(mm) Area(mm²) AWGno.
APV 1700-2M-TL-US _ 2.05 3.332 12
APV 2300-2M-TL-US _ 2.05 3.332 12
APV 3100-2M-TL-US _ 2.05 3.332 12
5.4 ConnecttoPVPanel(DCinput)
RISKOFELECTRICSHOCKANDFIRE.USEONLYWITHPVMODULESWITHAMAXIMUMSYSTEMVOLTAGE
RATING!
RISQUE DE CHOC ÉLECTRIQUE ET D’INCENDIE. UTILISER UNIQUEMENT AVEC LES MODULES PV AYANT
UNE TENSION SYSTÈME MAXIMALE ÉGALE À LA TENSION NOMINALE !
ELECTRICSHOCKHAZARD,THEDCCONDUCTORSOFTHISPHOTOVOLTAICSYSTEMARENORMALLY
UNGROUNDEDBUTWILLBECOMEINTERMITTENTLYGROUNDEDWITHOUTINDICATIONWHENTHEIN-
VERTERMEASURESTHEPVARRAYISOLATION!
RISQUE DE CHOC ÉLECTRIQUE : LES CONDUCTEURS CC DE CE SYSTÈME PHOTOVOLTAïQUE NE SONT
NORMALEMENT PAS MIS À LA TERRE MAIS LE SERONT PAR INTERMITTENCE ET SANS INDICATION
PRÉALABLE LORSQUE L’ONDULEUR MESURERA L’ISOLATION DU PANNEAU PV !
A) DC input connection terminal.
B) Always make sure that the maximum open circuit voltage (Voc) of each PV string is less than 600 Vdc.
The length of the input wire must be less than 30m.
C) Open the independent DC circuit breaker as well as the DC switch on the RADIUS Home - APV-...-US
inverter.
Warning!
Warning!

RADIUS Home 15
D) Before connecting PV panels to DC terminals, please make sure the polarity is correct . Incorrect polarity
could permanently damage the unit. Check short-circuit current of the PV string. The total short-circuit
current of the PV string should be less than the inverter’s maximum DC current.
E) Connect the positive and negative terminals from the PV panel to positive (+) terminals and negative (-)
terminals on the PV inverter.
F) High voltages exist when the PV panel is exposed to the sun. To reduce risk of electric shock, avoid
touching live components and treat connection terminals carefully.
G) Cable requirements
Model _(mm) Area(mm²) AWGno.
APV 1700-2M-TL-US _ 2.05 3.332 12
APV 2300-2M-TL-US _ 2.05 3.332 12
APV 3100-2M-TL-US _ 2.05 3.332 12
5.5 Commissioningchecks
A) When the PV panels are connected and their output voltage is greater than 100 VDC but the AC grid
is not yet connected, the LCD display shows the following messages in order: “RADIUS Home - APV
Inverter”-> “No AC connection” and the LED will be red.
B) Close the AC breaker or fuse between the PV inverter and the grid. The normal operating sequence
begins (it take 30 seconds).
C) Under normal operating conditions the LCD displays “Power: xxxx.xW”. That is the power fed to the grid.
The LED turns green.
D) This completes the check.

16 RADIUS Home
6. Display
6.1 LCDdisplay
Starting-up display sequence: once the PV power is sufcient, the inverter displays the following start-up infor-
mation:
Module: xxxxxx
SerNo: xxxxxxxxxx
FW Version: x.x.x
Connect in: xxS
Connect : OK
Power: xxxx.xW
6.2 LCDcontrol
KNOCKHERE
To save power, the LCD display’s backlight automatically turns off after 30 seconds.
The inverter display can be controlled by knocking on the front of it.
The rst line of the display shows inverter status information; there are 5 inverter states (see table below).
TheFirstLineofLCD
ProgramState Programming UpdateSoftware
STATE DISPLAY CONTENT REMARK
Wait State Standby PV voltage low
Waiting Initial waiting
Connect in xxS System checking
Inverter State Connect OK Connect to Grid
Power: xxxx.xW Inverter watt during operation
Fault State Error: xxx System fault
Auto Test State Auto Testing Protection auto test
Program State Programming Update Software
While the RADIUS Home - APV inverter is working, the rst line of the display will normally show the power
status:
Power: 2016.2W
AC:241V F: 60.0Hz
The second line can be changed by knocking on the display.

RADIUS Home 17
TheSecondLineOfLCD
CYCLEDISPLAY DISPLAYTIME/S REMARK
Power : 2013.4W
Module : P7U1M2S4 2 Inverter model
Power : 2016.8W
FW Version: U.1.2 2 Software version
Power : 2012.8W
SerNO : DK00000000 2 Serial number
Power : 2009.6W
Etoday : 7.1KWh 4 Energy today
Power : 2017.0W
Eall : 90KWH 4 Total energy
Power : 2123.4W
Ppv : 2123.4W 4 PV input watt
Power : 2103.4W
PV: 313 B: 370V 4 PV and bus voltage
Power : 2016.2W
AC: 241V F: 60.0Hz 4 Grid system
Enable auto test
Power : 2021.8W
Enable Auto Test
4 Enable auto test
Set Language
Power : 2019.5W
Set Language
4 Set language
Set contrast
Power : 2008.2W
Sel LCD Contrast
4 Set LCD contrast
Set COM Address
Power : 2019.5W
COM Address: Move
4 Set communications address
Set GRID standards
Power : 2016.2W
Net Model: 2
4 Set GRID standards

18 RADIUS Home
6.3 SettingtheLCDdisplay
The LCD can be controlled by knocking on the display to dene the display language, contrast, auto-test and
frequency.
WhentheLCDisdark
Knock to make it becomes bright. The display remain visible for 30 seconds for 1-5 information
WhentheLCDisBright
Knock to make it display next information (all range).
Settingthelanguage
Knock to make the display bright→ knock to “set language”→ double knock to enter “language: English”→
knock to select the language you need and wait until the display becomes dark.
Settingthedisplaycontrast
Knock to make the display bright → knock to “set LCD contrast”→ double knock to enter“LCD contrast 2”→
knock to select the contrast setting you need and wait until the display becomes dark.
Settingthecommunicationaddress
Knock to make the display bright → knock to “COM Address:xx” → double knock to change the address model
→ clock to set the address.
Settingthenetmodel
Knock to make the display bright→knock to “Net Model: xx” → double knock to enter “Net Model: xx”→ knock
to select the Netmodel you need and wait until the display becomes dark.
Power : 2016.2W
Net Model: 2
Power : 2016.2W
Net Model: 3
Power : 2016.2W
Net Model: 4
Autotest
Knock to make the display bright → knock to “Enable Auto test”→ double knock to enter “Waiting to start”→
knock to start auto test and wait for the test result.

RADIUS Home 19
7. Operatingmodes
The inverter has three different operating modes.
7.1 Normalmode
In this mode, the inverter works normally. Whenever the supplied power from PV panel is sufcient
(voltage>120VDC), the inverter converts power generated by the PV panel to the grid. If the power is insuf-
cient (voltage<120VDC), the inverter enters a “waiting” state. Whilst “waiting” the inverter uses just enough
power from the PV panel to monitor the internal system status. In normal mode the LED is green.
7.2 Faultmode
The internal intelligent controller can continuously monitor and adjust the system status. If the inverter detects
any unexpected conditions such as grid problems or internal failure, it will display the information on its LCD
and the LED will be red.
7.3 Shutdownmode
During periods of little or no sunlight, the inverter automatically stops running. In this mode, the inverter does
not take any power from the grid. The display and LEDs on the front panel do not work.
Note ! Operating the inverter is quite easy. During normal operation, the inverter runs automatically. However, to achieve maximum
inverter conversion efficiency, please read the following information:
Le fonctionnement d’un onduleur est assez facile. Lors d’une phase normale, l’onduleur fonctionne automatiquement. Cependant,
afin d’atteindre l’efficacité de conversion maximale de l’onduleur, veuillez lire les instructions suivantes:
7.4 AutomaticON-OFF
TheinverterstartsupautomaticallywhenDCpowerfromthePVpanelissufcient.
OncethePVinverterstartsitentersoneofthefollowing3states:
1) Standby: The PV string can only provide just enough voltage to meet the minimum requirements of the
controller.
2) Waiting: When the PV string DC voltage is greater than 100V, the inverter enters a enters “waiting” state
and attempts to connect to the grid.
3) Normal operation (rst start up): When PV string DC voltage is greater than 150V, the inverter operates
in the normal state.

20 RADIUS Home
8. Inverterstatus
The inverter is designed to be user-friendly; therefore, the status of the inverter can be easily understood by
reading the information shown on the front panel display. All possible messages are shown in the following
table.
Systemfault
DISPLAY OPERATION
Auto Test Failed Auto test did not run successfully
No AC Connection No utility, no grid connection
PV Isolation Low Insulation problem
Output High DCI Output current DC offset too high
PV Voltage High PV panel voltage too high
AC V Outrange Grid voltage out of range
AC F Outrange Grid frequency out of range
Inverterfault
DISPLAY OPERATION
Error: 100 2.5V reference voltage fault
Error: 101 Communication fault
Error: 102 Consistent fault
Error: 116 EEPROM fault
Error: 117 Relay fault
Error: 118 Init model fault
Error: 119 GFCI fault
Error: 120 HCT fault
Error: 121 Communication fault
Error: 122 Bus voltage fault
Error: 123 Auto Test Fail
