gefran VDI100 Series User manual

.... Instruction manual
General Purpose
Full Vector Inverter
VDI100

Information about this manual
The VDI100 product is an inverter designed to control a three-phase induction motor and permanent magnet.
Please read this manual carefully to ensure correct operation, safety and to become familiar with the inverter
functions.
The VDI100 inverter is an electrical / electronic product and must be installed and handled by qualied service
personnel.
Improper handling may result in incorrect operation, shorter life cycle, or failure of this product as well as the
motor.
All VDI100 documentation is subject to change without notice. Be sure to obtain the latest editions for use or
visit our website at http://www.gefran.com/en/product_categories/93-motion-control
Available Documentation:
1. VDI100 Start-up and Installation Manual
2. VDI100 Instruction Manual
Ensure you have sound knowledge of the device and familiarize yourself with all safety information and precau-
tions before proceeding to operate the inverter.
Software version
This manual is updated according the software version V 1.04
The identication number of the software version is indicated on the identication plate of the drive or can be
checked with the par. 13.01.
General information
Note ! In industry, the terms “Inverter”, “Regulator” and “Drive” are sometimes interchanged. In this document, the term “Drive” will be
used.
Before using the product, read the safety instruction section carefully.
Keep the manual in a safe place and available to engineering and installation personnel during the product
functioning period.
Gefran S.p.A has the right to modify products, data and dimensions without notice. The data can only be used
for the product description and they can not be understood as legally stated properties.
Thank you for choosing this Gefran product.
We will be glad to receive any possible information which could help us improving this manual. The e-mail
address is the following: [email protected].
All rights reserved
2 VDI100 • Instruction manual

Table of contents
Information about this manual..................................................................................................................2
Software version.....................................................................................................................................................2
General information ................................................................................................................................................2
1. Safety Precautions..............................................................................................................................5
1.1. Symbols used in the manual ....................................................................................................................5
1.2. Before Supplying Power to the Inverter / Avant d’alimenter le variateur ..................................................5
1.3. Wiring / Câblage.......................................................................................................................................6
1.4. Before Operation / Avant l’opération ........................................................................................................7
1.5. Parameters Setting / Conguration Paramètre ........................................................................................8
1.6. Operation / Opération...............................................................................................................................8
1.7. Maintenance, Inspection and Replacement / Entretien, Inspection et remplacement .............................9
1.8. Disposal of the Inverter / Mise au rebut du variateur ...............................................................................9
2. Model Description............................................................................................................................. 11
2.1. Nameplate Data .....................................................................................................................................11
2.2. Inverter Models – Motor Power Rating (HD – Heavy Duty) ...................................................................11
3. Environment and Installation...........................................................................................................13
3.1. Environment ...........................................................................................................................................13
3.2. Installation ..............................................................................................................................................13
3.3. External View .........................................................................................................................................14
3.4. Warning Labels ......................................................................................................................................16
3.5. Removing the Front Cover and Keypad.................................................................................................16
3.5.1. Standard Type..........................................................................................................................................................17
3.5.2. Add-onltertype(400VClass:0.75~45kW)........................................................................................................19
3.6. Wire Gauges and Tightening Torque......................................................................................................20
3.7. Wiring Peripheral Power Devices...........................................................................................................21
3.8. General Wiring Diagram.........................................................................................................................24
3.9. User Terminals (Control Circuit Terminals).............................................................................................24
3.10. Power Terminals.....................................................................................................................................26
3.11. Input / Output Power Section Block Diagram.........................................................................................28
3.11.1. CoolingFanSupplyVoltageSelection(400Vclass)................................................................................................29
3.12. Inverter Wiring........................................................................................................................................30
3.13. Input Power and Motor Cable Length ....................................................................................................31
3.14. Motor Cable Length vs. Carrier Frequency ............................................................................................31
3.15. Installing an AC Line Reactor.................................................................................................................31
3.16. Wire Section...........................................................................................................................................31
3.17. Control Circuit Wiring .............................................................................................................................32
3.18. Inverter Specications............................................................................................................................34
3.18.1. Powerloss ................................................................................................................................................................36
3.18.2. GeneralSpecications .............................................................................................................................................37
3.19. Inverter Derating Based on Carrier Frequency ......................................................................................38
3.20. Inverter Derating Based on Temperature ...............................................................................................39
3.21. Inverter Derating Based on Altitude .......................................................................................................39
3.22. Inverter Dimensions ...............................................................................................................................40
3.23. Dimensions for Models with Add-on lter...............................................................................................43
4. Keypad and Programming Functions .............................................................................................45
4.1. LED Keypad (KB-LED-VDI100)......................................................................................................45
4.1.1. KeypadDisplayandKeys ........................................................................................................................................45
4.1.2. SevenSegmentDisplayDescription........................................................................................................................46
4.1.3. LEDIndicatorDescription ........................................................................................................................................47
4.1.4. Power-upMonitor.....................................................................................................................................................48
4.1.5. ModifyingParameters/SetFrequencyReference...................................................................................................49
4.1.6. OperationControl.....................................................................................................................................................50
4.2. LCD Keypad (KB-LCD-VDI100) .............................................................................................................51
4.2.1. KeypadDisplayandKeys ........................................................................................................................................51
4.2.2. KeypadMenuStructure ...........................................................................................................................................52
4.2.3. Notes........................................................................................................................................................................54
4.3. Parameters.............................................................................................................................................56
4.3.1. Attachment1:Parameters’defaultvalueandupperlimitvalueareadjustedbydifferentinvertersizes .................92
4.3.2. LowVoltageDetectionLevelFunction.....................................................................................................................94
4.4. Description of Parameters......................................................................................................................95
00-BasicParameters..............................................................................................................................................................95
01-V/fControlParameters.................................................................................................................................................... 112
02-IMMotorParameters......................................................................................................................................................138
03-ExternalDigitalInputandOutputParameters.................................................................................................................142
04-ExternalAnalogInput/OutputParameter ......................................................................................................................172
05-Multi-SpeedParameters..................................................................................................................................................182
06-AutomaticProgramOperationParameters .....................................................................................................................186
07-Start/StopParameters.....................................................................................................................................................189
08-ProtectionParameters.....................................................................................................................................................202
09-CommunicationParameters............................................................................................................................................ 211
10-PIDParameters...............................................................................................................................................................213
11-AuxiliaryParameters........................................................................................................................................................224
12-MonitoringParameters....................................................................................................................................................239
VDI100 • Instruction manual 3

13-MaintenanceParameters ................................................................................................................................................241
14-PLCParameters..............................................................................................................................................................246
15-PLCMonitoringParameters............................................................................................................................................247
16-LCDFunctiongroup ........................................................................................................................................................248
17-AutomaticTuningParameters .........................................................................................................................................253
18-SlipCompensationParameters.......................................................................................................................................257
19-WobbleFrequencyParameters.......................................................................................................................................260
20-SpeedControlParameters..............................................................................................................................................262
21-TorqueAndPositionControlParameters ........................................................................................................................271
22-PMMotorParameters .....................................................................................................................................................280
4.4.1. Annexed1:Parameters’defaultandupperlimitvaluesaccordingtotheinvertersizes ........................................283
4.5. Built-in PLC Function ...........................................................................................................................286
4.5.1. BasicCommand.....................................................................................................................................................286
4.5.2. BasicCommandFunction......................................................................................................................................287
4.5.3. ApplicationFunctions............................................................................................................................................288
4.6. Modbus Protocol Descriptions .............................................................................................................294
4.6.1. CommunicationConnectionandDataFrame........................................................................................................294
4.6.2. RegisterandDataFormat......................................................................................................................................296
4.6.3. ParameterData......................................................................................................................................................302
5. Check Motor Rotation and Direction.............................................................................................309
6. SpeedReferenceCommandConguration.................................................................................. 311
6.1. Reference from Keypad .......................................................................................................................311
6.2. Reference from External Analog Signal (0-10V / 4-20mA)...................................................................311
6.3. Reference from Serial Communication RS485 (00-05=3) ...................................................................312
6.4. Reference from Pulse Input (00-05=4).................................................................................................313
6.5. Reference from two Analog Inputs.......................................................................................................314
6.6. Change Frequency Unit from Hz to rpm ..............................................................................................315
7. OperationMethodConguration(Run/Stop) .............................................................................316
7.1. Run/Stop from the LED/LCD Keypad (00-02=0) .................................................................................316
7.2. Run/Stop from External Switch / Contact or Pushbutton (00-02=1).....................................................317
7.3. Run/Stop from Serial Communication RS485 (00-02=3) .....................................................................318
8. MotorandApplicationSpecicSettings ......................................................................................319
8.1. Set Motor Nameplate Data (02-01, 02-05)...........................................................................................319
8.2. Acceleration and Deceleration Time (00-14, 00-15).............................................................................319
8.3. Torque Compensation Gain (01-10).....................................................................................................320
8.4. Automatic Energy Saving Functions (11-19)........................................................................................321
8.5. Emergency Stop...................................................................................................................................322
8.6. Forward and Reverse Jog....................................................................................................................322
8.7. Direct / Unattended Startup..................................................................................................................324
8.8. Analog Output Setup............................................................................................................................324
9. UsingPIDControlforConstantFlow/PressureApplications...................................................326
9.1. What is PID Control?............................................................................................................................326
9.2. Connect Transducer Feedback Signal (10-01) ....................................................................................328
9.3. Engineering Units (only for LCD) .........................................................................................................328
9.4. Sleep / Wakeup Function .....................................................................................................................328
10. Troubleshooting and Fault Diagnostics .......................................................................................330
10.1. General ................................................................................................................................................330
10.2. Fault Detection Function ......................................................................................................................330
10.3. Warning / Self-diagnosis Detection Function .......................................................................................333
10.4. Auto-tuning Error..................................................................................................................................339
10.5. PM Motor Auto-tuning Error ................................................................................................................339
11. Inverter
Accessories and Options.................................................................................................340
11.1. Braking Resistors and Braking Units....................................................................................................340
11.2. AC Line Reactors .................................................................................................................................341
11.3. Output Choke .......................................................................................................................................342
11.4. Input
EMC Filters .................................................................................................................................343
11.5. Input Current and Fuse Specications .................................................................................................344
11.6. PG Speed Feedback Card ...................................................................................................................345
11.7. Other Options.......................................................................................................................................348
11.8. Communication Options.......................................................................................................................350
Appendix A: Communication Networks...............................................................................................351
A1.1 RS485 –Network (Modbus)........................................................................................................................351
A1.2 Probus DP Network ..................................................................................................................................352
Appendix B: UL Instructions.................................................................................................................353
4 VDI100 • Instruction manual

1. Safety Precautions
Preface
• Ensure you have sound knowledge of the device and familiarize yourself with all safety information and
precautions before proceeding to operate the inverter.
• Please pay close attention to the safety precautions indicated by the warning and caution symbol.
Préface
• Vériez que vous avez une bonne connaissance de l’entraînement et de vous familiariser avec les con-
signes de sécurité et les précautions avant de procéder à fonctionner le lecteur.
• Prêter attention aux consignes de sécurité indiquées par l’avertissement (Warning) et symbole Attention
(Caution).
1.1. Symbols used in the manual
Indicates a procedure, condition, or statement that, if not strictly observed, could result in personal injury or death.
Indiquelemoded’utilisation,laprocédureetlaconditiond’exploitation.Sicesconsignesnesontpasstricte-
mentrespectées,ilyadesrisquesdeblessurescorporellesoudemort.
Indicates a procedure, condition, or statement that, if not strictly observed, could result in damage to or destruc-
tion of equipment.
Indiqueetlemoded’utilisation,laprocédureetlaconditiond’exploitation.Sicesconsignesnesontpasstricte-
mentrespectées,ilyadesrisquesdedétériorationoudedestructiondesappareils.
Indicates that the presence of electrostatic discharge could damage the appliance. When handling the boards,
always wear a grounded bracelet.
Indiquequelaprésencededéchargesélectrostatiquesestsusceptibled’endommagerl’appareil.Toujours
porterunbraceletdemiseàlaterrelorsdelamanipulationdescartes.
Indicates a procedure, condition, or statement that should be strictly followed in order to optimize these applications.
Indiquelemoded’utilisation,laprocédureetlaconditiond’exploitation.Cesconsignesdoiventêtrerigoureuse-
mentrespectéespouroptimisercesapplications.
Note ! Indicates an essential or important procedure, condition, or statement.
Indique un mode d’utilisation, de procédure et de condition d’exploitation essentiels ou importants
1.2. BeforeSupplyingPowertotheInverter/ Avant d’alimenter le variateur
The main circuit must be correctly wired. For single phase supply use input terminals (R/L1, T/L3) and for three
phase supply use input terminals (R/L1, S/L2, T/L3). Terminals U/T1, V/T2, W/T3 must only be used to connect
the motor. Connecting the input supply to any of the U/T1, V/T2 or W/T3 terminals will cause damage to the
inverter.
Avertissement !
Lecircuitprincipaldoitêtrecorrectementcâblée.Pourlesterminauxmonophasésd’approvisionnementde
l’utilisationdesintrants(R/L1,T/L3)etdetroisbornesd’entréedel’utilisationdel’offredephase(R/L1,S/L2,T/
L3).U/T1,V/T2,W/T3nedoiventêtreutiliséspourconnecterlemoteur.Raccordementdel’alimentationd’en-
tréeàl’undesU/T1,V/T2W/T3oubornesrisqued’endommagerlelecteur.
• To avoid the front cover from disengaging or other physical damage, do not carry the inverter by its cover.
Support the unit by its heat sink when transporting. Improper handling can damage the inverter or injure
Warning
Caution
Important
Warning
Caution
VDI100 • Instruction manual 5

personnel, and should be avoided.
• To avoid the risk of re, do not install the inverter on or near ammable objects. Install on nonammable
objects such as metal surfaces.
• If several inverters are placed inside the same control panel, provide adequate ventilation to maintain the
temperature below 40°C/104°F (50°C/122°F) without a dust cover) to avoid overheating or re.
• When removing or installing the digital operator, turn off the power rst, and then follow the instructions in
this manual to avoid operator error or loss of display caused by faulty connections.
Attention !
•  Pouréviterledétachementducacheavantoud’autresdommagesmatériels,nepassaisirlevariateurpar
soncache.Lorsdutransport,maintenirl’unitéparsondissipateurdechaleur.Evitertoutemanutention
incorrecte,sourcepotentiellededommagescorporelsetmatériels.
•  Pourévitertoutrisqued’incendie,nepasinstallerlevariateursurouprèsd’objetsinammables.Installer
levariateursurdessurfacesmétalliquesnoninammables.
•  Siplusieursvariateurssontlogésàl’intérieurd’unemêmearmoire,assurerunebonneventilationpour
maintenirunetempératureinférieureà40°C/104°F(50°C/122°F)(sanscache-poussière),pourévitertout
risquedesurchauffeetd’incendie.
•  Lorsdeladépose/reposedel’opérateurnumérique,couperd’abordl’alimentationpuissuivrelesinstruc-
tionsci-contenuespourévitertouteerreurouperted’afchagedueàdesconnexionsdéfectueuses.
• This product is sold subject to IEC 61800-3. In a domestic environment this product may cause radio inter-
ference in which case the user may need to apply corrective measures.
• Motor over temperature protection is not provided.
Avertissement !
•  CesproduitestcommercialiséconformémentàlanormeIEC61800-3.Enmilieurésidentiel,ceproduit
peutprovoquerdesinterférencesradio;danscecas,l’utilisateurdevraentreprendredesactionscorrec-
tives.
•  Laprotectioncontrelasur-températuredumoteurn’estpasprévue.
1.3. Wiring /Câblage
• Always turn OFF the power supply before attempting inverter installation and wiring of the user terminals.
• Wiring must be performed by a qualied personnel / certied electrician.
• Make sure the inverter is properly grounded. (230V Class: Grounding impedance shall be less than 100Ω.
400V Class: Grounding impedance shall be less than 10Ω.)
• Make sure the inverter is properly grounded. It is required to disconnect the ground wire in the control
board to avoid the sudden surge causing damage on electronic parts if it is improperly grounded.
• RCD is required to be in compliance with the protection norm of B-type leakage current.
• Please check and test emergency stop circuits after wiring. (Installer is responsible for the correct wiring.)
• Never touch any of the input or output power lines directly or allow any input of output power lines to come
in contact with the inverter case.
• Do not perform a dielectric voltage withstand test (megger) on the inverter this will result in inverter dam-
age to the semiconductor components.
Avertissement !
•  Coupeztoujoursl’alimentationélectriqueavantdeprocéderàl’installationd’entraînementetlecâblage
desterminauxutilisateurs.
•  Lecâblagedoitêtreeffectuéparunpersonnelqualié/électriciencertié.
•  Assurez-vousquelelecteurestcorrectementmisàlaterre.(230VClasse:impédancedemiseàlaterre
doitêtreinférieureà100Ω.Classe440V:Impédancedemiseàlaterredoitêtreinférieureà10Ω.)
•  Vérierettestermescircuitsd’arrêtd’urgenceaprèslecâblage.(L’Installateurestresponsabledu
câblage.)
•  Netouchezjamaisdel’entréeoudelignesélectriquesdesortiepermettantdirectementoutouteentréeou
delignesdepuissancedesortieàvenirencontactavecleboîtierd’entraînement.
Warning
Warning
6 VDI100 • Instruction manual

•  Nepaseffectueruntestdetenueentensiondiélectrique(mégohmmètre)surlevariateuroucelavaentraî-
nerdesdommagesdelecturepourlescomposantssemi-conducteurs.
• The line voltage applied must comply with the inverter’s specied input voltage. (See product nameplate
section 2.1)
• Connect braking resistor and braking unit to the designated terminals. (See section 3.10)
• Do not connect a braking resistor directly to the DC terminals P (+) and N (-), otherwise re may result.
• Use wire gauge recommendations and torque specications. (See Wire Gauge and Torque Specication in
section 3.6)
• Never connect input power to the inverter output terminals U/T1, V/T2, W/T3.
• Do not connect a contactor or switch in series with the inverter and the motor.
• Do not connect a power factor correction capacitor or surge suppressor to the inverter output.
• Ensure the interference generated by the inverter and motor does not affect peripheral devices.
Attention !
•  Latensiond’alimentationappliquéedoitseconformeràlatensiond’entréespéciéeparlelecteur(voirla
sectionsignalétiqueduproduit,ch.2.1).
•  Raccorderlarésistancedefreinageetdel’unitédefreinagesurlesbornesassignées(voirch.3.10).
•  NepasbrancherunerésistancedefreinagedirectementsurlesbornesCCP(+)etN(-),sinonrisque
d’incendie.
•  Utilisezdesrecommandationsdelajaugedeletlesspécicationsdecouple(VoirWireGaugeetlasec-
tiondespécicationdecouple,ch.3.6).
•  Nejamaisbrancherl’alimentationd’entréeauxbornesonduleurdesortieU/T1,V/T2,W/T3.
•  Nepasbrancheruncontacteurouinterrupteurensérieaveclevariateuretlemoteur.
•  Nebranchezpasunfacteurcondensateurdecorrectiondepuissanceousuppresseurdetensionàlasor-
tieduvariateur.
•  S’assurerquel’interférencegénéréeparl’entraînementetlemoteurn’apasd’incidencesurlespériphé-
riques.
1.4. Before Operation/Avantl’opération
• Make sure the inverter model matches the parameters 13-00.
• Reduce the carrier frequency (parameter 11-01) If the cable from the inverter to the motor is greater than 80
ft (25m). A high-frequency current can be generated by stray capacitance between the cables and result in
an overcurrent trip of the inverter, an increase in leakage current, or an inaccurate current readout.
• Be sure to install all covers before turning on power. Do not remove any of the covers while power to the
inverter is on, otherwise electric shock may occur.
• Do not operate switches with wet hands, otherwise electric shock may result.
• Do not touch inverter terminals when energized even if inverter has stopped, otherwise electric shock may
result.
Avertissement !
•  Assurez-vousquelemodèleduvariateurcorrespondauxparamètres13-00denotationavantd’alimenter.
•  Réduireleparamètre11-01delafréquenceporteusesilecâbleduvariateuraumoteurestsupérieureà
80pi(25m).Uncourantdehautefréquencepeutêtregénéréeparlacapacitéparasiteentrelescâbles
etentraînerundéclenchementdesurintensitéduvariateur,uneaugmentationducourantoud’unelecture
actuelleinexactes.
•  Veillezàinstallertouslescouverclesavantdel’allumer.Neretirezpaslescapotspendantquel’alimenta-
tiondulecteurestallumé,unchocélectriquepeutseproduireautrement.
•  Nepasactionnerd’interrupteursaveclesmainsmouillées,unchocélectriquepourraitsurvenirautrement.
•  Netouchezpaslesbornesd’entraînementlorsqu’ilestalimenté,mêmesilelecteurestarrêté,unchoc
électriquepourraitsurvenirautrement.
Caution
Warning
VDI100 • Instruction manual 7

1.5. Parameters Setting /CongurationParamètre
• Do not connect a load to the motor while performing a rotational auto-tune.
• Make sure the motor can freely run and there is sufcient space around the motor when performing a rota-
tional auto-tune.
Attention !
•  Nebranchezpasunechargepourlemoteurtouteneffectuantunauto-tune.
•  Assurez-vousquelemoteurpeutfonctionnerlibrementetilyasufsammentd’espaceautourdumoteur
lorsdel’exécutiond’unauto-tunerotation.
1.6. Operation/Opération
• Be sure to install all covers before turning on power. Do not remove any of the covers while power to the
inverter is on, otherwise electric shock may occur.
• Do not connect or disconnect the motor during operation. This will cause the inverter to trip and may cause
damage to the inverter.
• Operations may start suddenly if an alarm or fault is reset with a run command active. Conrm that no run
command is active upon resetting the alarm or fault, otherwise accidents may occur.
• Do not operate switches with wet hands, otherwise electric shock may result.
• It provides an independent external hardware emergency switch, which emergently shuts down the inverter
output in the case of danger.
• If automatic restart after power recovery (parameter 07-00) is enabled, the inverter will start automatically
after power is restored.
• Make sure it is safe to operate the inverter and motor before performing a rotational auto-tune.
• Do not touch inverter terminals when energized even if inverter has stopped, otherwise electric shock may
result.
• Do not check signals on circuit boards while the inverter is running.
• After the power is turned off, the cooling fan may continue to run for some time.
Avertissement !
•  Veillezàinstallertouslescouverclesavantdel’allumer.Neretirezpaslescapotspendantquel’alimenta-
tiondulecteurestallumé,unchocélectriquepeutseproduireautrement.
•  Nepasbrancheroudébrancherlemoteurpendantlefonctionnement.Levariateurpourraisedéclencher
etainsiendommagerlelecteur.
•  Lesopérationspeuventcommencersoudainementsiunealarmeouundéfautestréarméavecunordre
demarcheactive.Assurez-vousqu’unordredemarcheestactiflorsdelaréinitialisationdel’alarmeoude
défaut,autrementdesaccidentspeuventseproduire.
•  Nepasactionnerd’interrupteursaveclesmainsmouillées,unchocélectriquepourraitsurvenir.
•  Uninterrupteurd’urgenceexterneindépendantestfourni,quis’arrêteenurgenceverslebaslasortiede
l’onduleurencasdedanger.
•  Sileredémarrageautomatiqueaprèsunerécupérationd’énergieestactivée(par07-00),levariateurdé-
marreraautomatiquementaprèslerétablissementducourant.
•  Assurez-vousqu’ilestsûrdefairefonctionnerlevariateuretlemoteuravantd’effectuerunauto-tunerota-
tion.
•  Netouchezpaslesbornesd’entraînementlorsqu’ilestalimentémêmesil’onduleurs’estarrêté,unchoc
électriquepourraitsurvenir.
•  Nepascontrôlerlessignauxsurlescircuitspendantquelelecteurestenmarche.
•  Aprèslamisehorstension,leventilateurderefroidissementpeutcontinueràfonctionnerpendantuncer-
taintemps.
• Do not touch heat-generating components such as heat sinks and braking resistors.
• Carefully check the performance of motor or machine before operating at high speed, otherwise Injury may
Caution
Warning
Caution
8 VDI100 • Instruction manual

result.
• Note the parameter settings related to the braking unit when applicable.
• Do not use the inverter braking function for mechanical holding, otherwise injury may result.
• Do not check signals on circuit boards while the inverter is running.
Attention !
•  Netouchezpaslescomposantsgénérantdelachaleurtelsqueradiateursetdesrésistancesdefreinage.
•  Vériezsoigneusementlaperformancedumoteuroudelamachineavantd’utiliseràgrandevitesse,sous
peinedeblessure.
•  Notezlesréglagesdesparamètresliésàl’unitédefreinagelorsqueapplicable.
•  Nepasutiliserlafonctiondefreinaged’entraînementpourunmaintienmécanique,souspeinedebles-
sure.
•  Nepascontrôlerlessignauxsurlescircuitspendantquelelecteurestenmarche.
1.7. Maintenance,InspectionandReplacement/Entretien, Inspection et remplacement
• Wait a minimum of ve minutes after power has been turned OFF before starting an inspection. Also conrm
that the charge light is OFF and that the DC bus voltage has dropped below 25Vdc.
• Never touch high voltage terminals in the inverter.
• Make sure power to the inverter is disconnected before disassembling the inverter.
• Only authorized personnel should perform maintenance, inspection, and replacement operations. (Take off
metal jewelry such as watches and rings and use insulated tools.)
Avertissement !
•  Attendreunminimumde5minutesaprèsquel’alimentationaétédébranchéeavantdecommencerune
inspection.Vériezégalementquelevoyantdechargeestéteintetquelatensiondubusccachuté
au-dessousde25Vdc.
•  Nejamaistoucherlesbornesàhautetensiondanslelecteur.
•  Assurez-vousquel’alimentationdulecteurestdébranchéavantdedémonterlelecteur.
•  Seullepersonnelautorisépeuventfairel’entretien,l’inspectionetlesopérationsderemplacement.(Enle-
vezlesbijouxenmétaltelsquelesmontresetlesbaguesetutiliserdesoutilsisolés.).
• The Inverter can be used in an environment with a temperature range from 14°~104 (140) °F (-10~+40 (60)
°C) and relative humidity of 95% non-condensing.
• The inverter must be operated in a dust, gas, mist and moisture free environment.
Attention !
•  Levariateurpeutêtreutilisédansunenvironnementavecunegammedetempératureallantde14°-104°
F(10-40°C)etl’humiditérelativede95%sanscondensation.
• Levariateurdoitêtreutilisédansunenvironnementsanspoussière,gaz,vapeurethumidité.
1.8. DisposaloftheInverter/ Mise au rebut du variateur
• Please dispose of this unit with care as an industrial waste and according to your required local regula-
tions.
• The capacitors of inverter main circuit and printed circuit board are considered as hazardous waste and
must not be burned.
• The Plastic enclosure and parts of the inverter such as the top cover board will release harmful gases if
burned.
Warning
Caution
Caution
VDI100 • Instruction manual 9

Attention !
•  Jetercetappareilavecsoincommeundéchetindustrieletselonlesréglementationslocalesnécessaires.
•  Lescondensateursducircuitprincipald’entraînementetcircuitsimpriméssontconsidéréscommedes
déchetsdangereuxetnedoiventpasêtrebrûlés.
•  L’enveloppeetd’autresélémentsenplastiqueduvariateur,telslaplaquederevêtementsupérieure,dé-
gagentdesfuméestoxiquesencasd’incinération.
10 VDI100 • Instruction manual

2. Model Description
2.1. Nameplate Data
It is essential to verify the VDI100 inverter nameplate and make sure that the VDI100 inverter has the correct
rating so it can be used in your application with the proper sized AC motor.
Unpack the VDI100 inverter and check the following:
(1) The VDI100 inverter and start-up and installation manual are contained in the package.
(2) The VDI100 inverter has not been damaged during transportation there should be no dents or parts miss-
ing.
(3) The VDI100 inverter is the type you ordered. You can check the type and specications on the main name-
plate.
(4) Check that the input voltage range meets the input power requirements.
(5) Ensure that the motor kW (HP) matches the motor rating of the inverter.
HD: Heavy Duty (Constant Torque); ND: Normal Duty (Variable Torque) (1HP = 0.746 kW)
Drive model -> <- Power rating
Input and output data ->
<- Approvals
Serial number ->
ModelIdentication
VDI100-X XXX -KXX -X -Y
EMC Filter: F = included; [Empty] = not included
Rated voltage: 2T = 230 Vac, (1ph)(1) / 3ph; 4 = 400 Vac , 3ph
Software: X = standard
Braking unit: B = included; X = not included
Keypad: K = Integrated (LED keypad with 5-digits 7-segment
display)
Drive power, in kW
Mechanical drive sizes
VDI100 drive series
(1)
1ph / 3ph, VDI100-1007-KBX-2T ... VDI100-2022-KBX-2T only.
2.2. InverterModels–MotorPowerRating(HD–HeavyDuty)
230V Class
Voltage VDI100 Model Applied Motor Filter
(HP) (kW) with without
1ph / 3ph,
200~240V +10%/-15%,
50/60Hz
VDI100-1007-KBX-2T 1 0.75 •
VDI100-1015-KBX-2T 2 1.5 •
VDI100-2022-KBX-2T 3 2.2 •
3ph, 200~240V
+10%/-15%
50/60Hz
VDI100-2037-KBX-2T 5 3.7 •
VDI100-2055-KBX-2T 7.5 5.5 •
VDI100-3075-KBX-2T 10 7.5 •
VDI100-4110-KBX-2T 15 11 •
VDI100-4150-KBX-2T 20 15 •
VDI100-4185-KBX-2T 25 18.5 •
VDI100-5220-KXX-2T 30 22 •
Short Circuit Rating: 230V Class: 5kA
VDI100 • Instruction manual 11

400V Class
Voltage VDI100 Model Applied Motor Filter
(HP) (kW) with without
3ph, 380~480V
+10%/-15%
50/60Hz
VDI100-1007 1 0.75 •
VDI100-1015 2 1.5 •
VDI100-1022 3 2.2 •
VDI100-2037 5 3.7 •
VDI100-2055 7.5 5.5 •
VDI100-3075 10 7.5 •
VDI100-3110 15 11 •
VDI100-4150 20 15 •
VDI100-4185 25 18.5 •
VDI100-4220 30 22 •
VDI100-5300 40 30 •
VDI100-5370-KXX-4-F 50 37 •
VDI100-5450-KXX-4-F 60 45 •
Voltage VDI100 Model Applied Motor Filter
(HP) (kW) with without
3ph, 380~480V
+10%/-15%
50/60Hz
VDI100-1007-KBX-4 1 0.75 •
VDI100-1015-KBX-4 2 1.5 •
VDI100-1022-KBX-4 3 2.2 •
VDI100-2037-KBX-4 5 3.7 •
VDI100-2055-KBX-4 7.5 5.5 •
VDI100-3075-KBX-4 10 7.5 •
VDI100-3110-KBX-4 15 11 •
VDI100-3150-KBX-4 20 15 •
VDI100-4185-KBX-4 25 18.5 •
VDI100-4220-KBX-4 30 22 •
VDI100-5300-KBX-4 40 30 •
VDI100-5370-KXX-4 50 37 •
VDI100-5450-KXX-4 60 45 •
VDI100-5550-KXX-4 75 55 •
VDI100-6750-KXX-4 100 75 •
VDI100-6900-KXX-4 125 94 •
VDI100-71100-KXX-4 150 112 •
VDI100-71320-KXX-4 175 130 •
VDI100-71600-KXX-4 215 160 •
Short Circuit Rating: 400V Class: 5kA
12 VDI100 • Instruction manual

3. Environment and Installation
3.1. Environment
The environment will directly affect the proper operation and the life span of the inverter. To ensure that the
inverter will give maximum service life, please comply with the following environmental conditions:
Protection
Protection Class IP20/NEMA 1 or IP00
Operating Temperature Ambient Temperature: (-10°C - +40°C (14 -104 °F)
Without Cover: -10°C - +50°C (14-122 °F); but it is required to derate 2% of current at each additional 1°C.
The maximum operating temperature is 60°C.
If several inverters are placed in the same control panel, provide a heat removal means to maintain ambient
temperatures below 40°C
Storage Temperature -20°C - +70°C (-4 -158 °F)
Humidity 95% non-condensing
Relative humidity 5% to 95%, free of moisture.
(Follow IEC60068-2-78 standard)
Altitude Altitude: Below 1000 m (3281 ft.)
It is required to derate 1% of current at each additional 100 m.
The maximum altitude is 3000 m.
Installation Site Avoid exposure to rain or moisture.
Avoid direct sunlight.
Avoid oil mist and salinity.
Avoid corrosive liquid and gas.
Avoid dust, lint fibers, and small metal filings.
Keep away from radioactive and flammable materials.
Avoid electromagnetic interference (soldering machines, power machines).
Avoid vibration (stamping, punching machines etc.).
Add a vibration-proof pad if the situation cannot be avoided.
Shock Maximum acceleration: 1.0G (9.8m/s²), from 49.84 to 150 Hz
Displacement amplitude : 0.3mm (peak value), from 10 to 49.84 Hz (Follow IEC60068-2-6 standard)
3.2. Installation
When installing the inverter, ensure that inverter is installed in upright position (vertical direction) and there is
adequate space around the unit to allow normal heat dissipation as per the following Fig. 3.2.1
5.9in.
150mm
X
5.9in.
150mm
Air Flow
Ambient
temperature
-10 to +40°C
5.9in.
150mm
X
5.9in.
150mm
Fig3.2.1:VDI100Installationspace
X=1.18”(30mm)forinverterratingsupto18.5 kW (25HP)
X=1.96”(50mm)forinverterratings22 kW(30HP)orhigher
The inverter heatsink temperature can reach up to 194°F / 90°C during operation; make sure to use insulation mate-
Important
VDI100 • Instruction manual 13

rial rated for this temperature.
Latempératuredudissipateurdechaleurdel’inverseurpeutatteindre194°F/90°Cpendantle
fonctionnement;veilleràutiliserunmatériauisolantcompatibleaveccettetempérature.
3.3. External View
(a)Sizes1and2(230VClass:0.75~5.5kW/400VClass:0.75~5.5kW)
Fan cover
Mounting hole
Heatsink
Nameplate
and barcode
Front cover
Keypad
Terminal
cover
Fan cover
Mounting hole
Rings (4 rings)
Nameplate
and barcode
Front cover
Keypad
Terminal
cover
Anti-dust cover
(Wall-mounted type, IEC IP20) (Wall-mounted type, IEC IP20, NEMA1)
(b)Sizes3and4(230VClass:7.5~18.5kW/400VClass:7.5~22kW)
Mounting hole
Nameplate
and barcode
Front cover
Keypad
Terminal
cover
Mounting hole
Nameplate
and barcode
Front cover
Keypad
Terminal
cover
Anti-dust cover
(Wall-mounted type, IEC IP20) (Wall-mounted type, IEC IP20, NEMA1)
14 VDI100 • Instruction manual

(c)Size5(230VClass:22kW/400VClass:30~55kW)
(Wall-mounted type, IEC IP20, NEMA1)
(d)Size6(400VClass:75~90kWandmodelswith“NEMA1kitforVDI100”)
(Wall-mounted type, IEC IP20) (Wall-mounted type, IEC IP20, NEMA1)
(e)Size7(400VClass:110~160kWandmodelswith“NEMA1kitforVDI100”)
(Wall-mounted type, IEC IP00) (Wall-mounted type, IEC IP20, NEMA1)
VDI100 • Instruction manual 15

3.4. Warning Labels
Warning information located on the front cover must be read upon installation of the inverter.
Lorsdel’installationdel’inverseur,lirelesavertissementsapposéssurlecachedefaçade.
(a) Drive sizes 1, 2 and 3
WARNING / AVERTISSEMENT
Risk of electrical shock. Shut off main power and wait for 5 minutes before servicing.
Risque de choc électrique. Couper l’alimentation principale et attendre 5 minutes avant l’entretien.
Hot surface. Risk of burn.
Surface chaude. Risque de brûlure.
See manual before operation.
Consultez le manuel avant l’operation.
(b) Drive sizes 4, 5, 6 and 7
WARNING / AVERTISSEMENT
Risk of electrical shock. Shut off main power and wait for 15 minutes before servicing.
Risque de choc électrique. Couper l’alimentation principale et attendre 15 minutes avant l’entretien.
CAUTION / ATTENTION
See manual before operation.
Consultez le manuel avant l’operation.
3.5. Removing the Front Cover and Keypad
• Before making any wiring connections to the inverter the front cover needs to be removed.
• It is not required to remove the digital operator before making any wiring connections.
• Models 230V Class 2.2 ~ 18.5 kW and 400V Class 0.75 ~ 22 kW have a plastic cover. Loosen the screws
and remove the cover to gain access to the terminals and make wiring connections. Place the plastic cover
back and fasten screws when wiring connections have been made.
• Models 230V Class 22 kW and 400V Class 30 ~ 160 kW have a metal cover. Loosen the screws and
remove the cover to gain access to the terminals and make wiring connections. Place the metal cover back
and fasten screws when wiring connections have been made.
• Avant de procéder aux branchements des câblages sur l’inverseur, il est nécessaire de retirer le cache de
façade.
• En revanche, il n’est pas nécessaire de retirer l’opérateur numérique avant les branchements des câblages.
• Les modèles 230V Classe 2.2 ~ 18,5 kW et 400V Classe 0,75 ~ 22 kW sont pourvus d’un cache en plas-
tique. Desserrer les vis et retirer le cache pour pouvoir accéder aux terminaux et réaliser les branchements
des câblages. Ensuite, reposer le cache en plastique et serrer ses vis de xation.
• Les modèles 230V Classe 22 kW et 400V Classe 30 ~ 160 kW sont pourvus d’un cache en métal. Desser-
rer les vis et retirer le cache pour pouvoir accéder aux terminaux et réaliser les branchements des câblag-
es. Ensuite, reposer le cache en métal et serrer ses vis de xation.
Important
Caution
16 VDI100 • Instruction manual

3.5.1. Standard Type
(a)Sizes1and2(230VClass:0.75~5.5kW/400VClass:0.75~5.5kW)
Step 1: Unscrew Step 2: Remove cover
Step 3: Make wire connections and place cover back Step 4: Fasten screw
(b)Sizes3and4(230VClass:7.5~18.5kW/400VClass:7.5~22kW)
Step 1: Unscrew cover Step 2: Remove cover
VDI100 • Instruction manual 17

Step 3: Make wire connections and place cover back Step 4: Fasten screw
(c)Size5(230VClass:22kW/400VClass:30~55kW)
Step 1: Unscrew cover Step 2: Remove cover
Step 3: Make wire connections and place cover back Step 4: Fasten screw
18 VDI100 • Instruction manual

(d)Sizes6and7(400VClass:75~160kW)
Step 1: Unscrew cover Step 2: Remove cover
Step 3: Make wire connections and place cover back Step 4: Fasten screw
3.5.2. Add-on lter type (400V Class: 0.75 ~ 45 kW)
Step 1: Unscrew cover Step 2: Remove cover
VDI100 • Instruction manual 19

Step 3: Unscrew filter section Step 4: Remove filter cover
Step 5: Make connections and place filter cover back Step 6: Fasten screw
3.6. Wire Gauges and Tightening Torque
To comply with UL standards, use UL approved copper wires (rated 75° C) and round crimp terminals (UL List-
ed products) as shown in table below when connecting to the main circuit terminals. Gefran recommends using
crimp terminals manufactured by NICHIFU Terminal Industry Co., Ltd and the terminal crimping tool recom-
mended by the manufacturer for crimping terminals and the insulating sleeve.
Wire size Terminal
screw size
Model of the round
crimp terminal Fastening torque Model of insulating sleeve
Model of
crimp tool
mm2(AWG) kgf.cm (in.lbs)
0.75 (18) M3.5 R1.25-3.5 8.2 to 10 (7.1 to 8.7) TIC 1.25 NH 1
M4 R1.25-4 12.2 to 14 (10.4 to 12.1) TIC 1.25 NH 1
1.25 (16) M3.5 R1.25-3.5 8.2 to 10 (7.1 to 8.7) TIC 1.25 NH 1
M4 R1.25-4 12.2 to 14 (10.4 to 12.1) TIC 1.25 NH 1
2 (14)
M3.5 R2-3.5 8.2 to 10 (7.1 to 8.7) TIC 2 NH 1 / 9
M4 R2-4 12.2 to 14 (10.4 to 12.1) TIC 2 NH 1 / 9
M5 R2-5 22.1 to 24 (17.7 to 20.8) TIC 2 NH 1 / 9
M6 R2-6 25.5 to 30.0 (22.1 to 26.0) TIC 2 NH 1 / 9
3.5 / 5.5 (12/10)
M4 R5.5-4 12.2 to 14 (10.4 to 12.1) TIC 5.5 NH 1 / 9
M5 R5.5-5 20.4 to 24 (17.7 to 20.8) TIC 5.5 NH 1 / 9
M6 R5.5-6 25.5 to 30.0 (22.1 to 26.0) TIC 5.5 NH 1 / 9
M8 R5.5-8 61.2 to 66.0 (53.0 to 57.2) TIC 5.5 NH 1 / 9
8 (8)
M4 R8-4 12.2 to 14 (10.4 to 12.1) TIC 8 NOP 60
M5 R8-5 20.4 to 24 (17.7 to 20.8) TIC 8 NOP 60
M6 R8-6 25.5 to 30.0 (22.1 to 26.0) TIC 8 NOP 60
M8 R8-8 61.2 to 66.0 (53.0 to 57.2) TIC 8 NOP 60
20 VDI100 • Instruction manual
