GEIGER GF20 Series User manual

1
www.geiger.de EN
EN
DE Original-Montage- und
Betriebsanleitung
Original assembly and
operating instructions
Notice originale de montage
et d’utilisation
Instrucciones originales de
instalación y funcionamiento
Istruzioni originali di installazione
e funzionamento
EN
FR
ES
IT
123456
Handheld transmitters
GF20..
Handsender
Handheld transmitters
Télécommandes

2Gerhard Geiger GmbH & Co. KG | 100W0689 1218V000en
EN
EN
Index
1. General information..................................................................2
2. Guarantee ..................................................................................2
3. Handheldtransmitter-specicsafetyinformation .................2
4. Scopeofdelivery ....................................................................2
5. GF20../Assignmentofkeys ....................................................3
6. Handheld transmitter coding ..................................................3
7. Programming a handheld transmitter to a Geiger
motor or an external radio receiver.........................................3
8. Programming the sun automatic function to a Geiger
motor or an external radio receiver.........................................4
9. Sun automatic ...........................................................................4
10. Createatransmittercopy........................................................5
11. Batteryreplacement .................................................................5
12. Technical data ...........................................................................5
13. Declarationofconformity ........................................................5
14. Disposal .....................................................................................5
1. General information
Dear customer,
By purchasing a Geiger radio-controlled handheld transmitter you have decided on a quality
product from Geiger.
Thank you very much for your decision and the condence placed in us.
2. Guarantee
In the case of incorrect installation contrary to the operating instructions and/or constructional
modication, the legal and contractual guarantee for property damage and product liability
lapses.
3. Handheldtransmitter-specicsafetyinformation
Please observe following instructions in order to avoid damage to this product:
fAvoid impacts
fDo not drop the device
fDonotimmerseinwateroranyliquid.Ensureprotectionagainstsplashingwater.
fNever use cleaning agents or abrasive solvents. Clean the surface of the transmitter
with a damp cloth.
4. Scopeofdelivery
• Handheld transmitter
• Wall holder with screw cover
• Mounting screws and plugs
• Battery type button cell CR2032 (inserted)
• Operating instructions

3
www.geiger.de EN
EN
5. GF20../Assignmentofkeys
Channel display
1, 2 or 6 channels depending on design
123456
Sun automatic function
ON / OFF
UP key
STOP key
DOWN key
Channel selection keys
6. Handheld transmitter coding
Each handheld transmitter of the series GF20.. is individually
coded.
The coding is done via a coding switch in the transmitter. It should only be changed in
exceptional cases. (see “Create a transmitter copy“).
7. Programming a handheld transmitter to a Geiger motor or
an external radio receiver
1. Select the desired channel with the channel selection keys ( ).
2. Connect the motor to the mains power supply.
The motor makes a short back and forth movement
(1x click-click).
Aftereachinterruptionofthepowersupplythe
programming mode can be activated for
30 minutes.
3. Hold the handheld transmitter to the power cable and
press the UP ( ) or DOWN ( ) key for about
3 seconds until the motor conrms with an audible sig-
nal (1x click-click).
4. Hold again the handheld transmitter to the power cable
and press UP ( ) or DOWN ( ) key for 1 second.
The motor conrms again (1 x “click–click“).
Repeat these steps for each desired channel.
I Please refer to the operating instructions
of the respective motor or receiver for
further information or for the adjustment
of the end stops.
123456
230 V
On
Off
connect to
mains
1 x “click-click“
max. 15 cm
click-
click
123456 or
about 3 sec.
1 x
max. 15 cm
click-
click
123456 or
about 1 sec.
1 x

4Gerhard Geiger GmbH & Co. KG | 100W0689 1218V000en
EN
EN
8. Programming the sun automatic function to a Geiger motor
or an external radio receiver
I The operation is to be performed during the 30 minutes after the
powersupplyhasbeenswitchedon.
1. Select the sun automatic channel ( ) with the channel
selection keys ( ).
2. In the near range press the UP ( ) or DOWN ( ) key
for about 3 seconds until the motor conrms with an
audible signal (1x click-click).
3. Hold the handheld transmitter to the power cable and
press the UP ( ) or DOWN ( ) key for 1 second. The
motor conrms with an audible signal (1x click-click).
Then program the handheld transmitter in the Geiger
sun/wind sensor.
4. Hold the bottom side of the handheld transmitter on
the left side of the sun/wind sensor, press the UP or
DOWN key – the sun icon of the handheld transmitter
lights up – until the red LED of the sun/wind sensor
lights up.
9. Sun automatic
To enable / disable the automatic sun function, press the channel selection keys ( ) until the
sun icon ( ) lights up.
The sun automatic function is activated with the UP key ( ) and deactivated with the DOWN
key ( ).
230 V
On
Off
connect to
mains
1 x “click-click“
max. 15 cm
click-
click
123456 or
about 3 sec.
1 x
max. 15 cm
click-
click
123456 or
about 1 sec.
1 x
123456 123456

5
www.geiger.de EN
EN
10. Createatransmittercopy
If you want to create a copy of your handheld transmitter with
all its functions (e.g. two identical handheld transmitters for two
persons), please proceed as follows:
1. Remove the four screws on the back of both handheld
transmitters.
2. Remove now the bottom parts of the handheld transmitters.
3. Use the same coding on the second transmitter (copy) as the
original one. The keys 7, 8 and 9 are not modied.
4. Screw down again the bottom parts.
Thisprocessallowsyoutocreateanunlimitednumberof
copies of the original handheld transmitter.
11. Batteryreplacement
If the display doesn‘t light up if actuating one of the control keys,
the batteries need to be replaced. In this case please unscrew
the screws on the back of the transmitter in order to remove the
bottom part. Make sure that you use the same type of battery
(CR2032).
12. Technical data
Transmittingfrequency 433,92 MHz
Temperature range between -0°C and +60°C
Dimensions 115 x 54 x 26 mm
Powersupply 3V type CR2032
Subject to technical modifications DE
V
geprüfte
Sicherheit
13. Declarationofconformity
The transmitter complies with the relevant technical regulations enacted by the European
Community. It bears the CE mark and is authorised for use in all EU member states and in
Switzerland without any need of prior registration.
To learn more about the EC Declaration of Conformity pertaining to this handheld transmitter,
please visit our website at: www.geiger.de.
14. Disposal
Recyclingofpackagingmaterials
In the interest of environmental protection, please contact your local government’s recycling or
solid waste management department to learn more about the services it provides.
Wastedisposalofelectricandelectronicequipment
Electronic equipment or batteries cannot be discarded along with the normal household waste.
Keep for more information on the recycling and disposal methods envisaged by the local regula-
tions in your area.
1
+
0
-
2345678
DIP
9
CR2032
Individual
coding
Channel
selection

6Gerhard Geiger GmbH & Co. KG | 100W0689 1218V000en
EN
EN

7
www.geiger.de EN
EN

8Gerhard Geiger GmbH & Co. KG | 100W0689 1218V000en
EN
EN
