INSTALLATION, OPERATION AND MAINTENANCE
MANUAL
Forged Globe Valves Class 800
With threaded, Socket Weld or Flange ends
Ref. GENEBRE: 2233N –2233S –2233A

Genebre Building. Av. de Joan Carles I, 46-48
08908 L'Hospitalet de Llobregat. Barcelona (Spain)
[e-mail] - www.genebre.es
GENEBRE S.A.
LAST UPDATE: 08/11/2011 UPDATE NUMBER: 0
2
Installation, operation and maintenance instructions
1. Product description ............................................................................... 3
2. Transport and Storage conditions ....................................................... 3
3. Installation instructions …….............................................................. 4
3.1 Preparation ………………….................................................................. 4
3.2 Installation of valves with threaded ends (2233N) ……………………... 4
3.3 Installation of valves with flanged ends (2233A) …………......………... 5
3.4 Installation of valves with socket weld ends (2233S) ……….………... 5
4. Operating instructions
4.1 Usage .................................................................................................... 6
4.2 Manual operation .................................................................................. 6
5. Maintenance instructions ...................................................................... 6
6. Reparation instructions ....................................................................... 7
7. Hygiene and Safety Instructions ........................................................... 7
