USER MANUAL
Endeavor
150-WATT DAYLIGHT LED MONOLIGHT
ML-33K

Endeavor 150-Watt Daylight LED Monolight - USER MANUAL
2
THANK YOU FOR CHOOSING GENARAY
The Genaray Endeavor 150-watt monolight features an
advanced chip-on-board (COB) LED that outputs a powerful
constant light source to deliver a brilliant daylight-balance
beam for video and photo shoots. The fixture’s natural-looking
5600 K daylight-balance light is dimmable from 100% to 0%
in 10% increments for the brightness your exposures need.
The COB array emits 33,000 lux @ 3 feet from a compact
area for a traditional single-shadow light, even without
a diffuser. The Endeavor emits a flicker-free beam that
eliminates unwanted strobing effects when shooting
in slow motion. And the CRI and TLCI of over 97 deliver
extremely accurate color rendering for vibrant and
realistic color reproduction on your monitor.
The Endeavor is outfitted with Genaray’s 2.4 GHz Lightseeker
remote receiver, which adds the capability of selecting
between 16 channels and five groups. The Lightseeker remote
is available separately, and it allows you to control multiple
Lightseeker-equipped Genaray lights from up to 300 feet away.
Endeavor
INTRODUCTION

Endeavor 150-Watt Daylight LED Monolight - USER MANUAL 3
· Please read and follow these
instructions, and keep this manual in
a safe place.
· Keep this unit away from water and
any flammable gases or liquids.
· Make sure this unit is powered off
when plugging it into a power source.
· Use only the correct, recommended
voltage.
· Handle the unit with care.
· Do not attempt to disassemble of
repair the equipment. Doing so will
void the warranty, and Genaray will not
be responsible for any damage.
· Do not stare directly at the lights when
they are powered on.
· Clean the unit with only a soft, dry
cloth.
· Images are for illustrative purposes
only.
PRECAUTIONS
Precautions

Endeavor 150-Watt Daylight LED Monolight - USER MANUAL
4
PRODUCT
OVERVIEW
Light Fixture - Front
Umbrella hole
COB LED array
Bowens mount
Bowens mount
release button
Light stand mount
DC power socket
5/8 in. receiver
Locking knob
Locking button
Tilt lock
Umbrella locking screw
Umbrella mount
Reflector

Endeavor 150-Watt Daylight LED Monolight - USER MANUAL 5
Product overview
Light Fixture - Back
Power switch
Power socket
Fuse
Adjustment dial
Group button
Channel button
Display
Battery status
Channel indicator
Color temperature
Brightness
Group indicator

Endeavor 150-Watt Daylight LED Monolight - USER MANUAL
6
MOUNTING THE
ENDEAVORCONTENTS INCLUDE
· Endeavor 150-Watt LED Monolight
· 7 in. reflector
· Tungsten filter
· Power cord
· User manual
To mount the Endeavor on any heavy-
duty light stand with a 5/8-inch pin:
1. Loosen the locking knob so it
doesn’t obstruct the receiver.
2. Press and hold the locking button,
place the fixture over the baby pin,
and release the locking button.
3. Tighten the locking knob
until the light is secure.
contents

Endeavor 150-Watt Daylight LED Monolight - USER MANUAL 7
POWERING THE
ENDEAVOR
WITH DC POWER
The Endeavor can be powered by V-mount
batteries, using the Genaray BA-VMOUNT
dual-battery adapter (available separately).
Dual 14.8-volt, 160-watt-hour V-mount
batteries will power the Endeavor
for approximately one hour.
Use the 3-pin XLR cable that’s included
with the BA-VMOUNT to connect the
battery adapter to the Endeavor. Refer to
the BA-VMOUNT user manual for further
information and mounting instructions.
FROM AN AC OUTLET
Warning!
The Endeavor is a powerful light. Do not look
directly into the light when it’s powered on.
Connect the AC power cable to the
Endeavor and to an AC outlet.
Turn on the power switch.
instructions

Endeavor 150-Watt Daylight LED Monolight - USER MANUAL
8
ATTACHING THE REFLECTOR
The Endeavor includes a 7-inch reflector
and is compatible with Bowens-mount
accessories. To attach the reflector:
1. Insert the three mounting studs
into the notches on the fixture.
2. Turn the reflector clockwise
until it clicks into place.
To remove the reflector, push and
hold the release button, and rotate
the reflector counterclockwise.
ATTACHING AN UMBRELLA
1. Make sure the reflector’s
umbrella pass-through is aligned
with the umbrella mount.
2. Insert the umbrella’s shaft through
the umbrella pass-through, and then
through the umbrella mount.
3. Tighten the locking knob until secure.
OPERATING THE
ENDEAVOR
instructions

Endeavor 150-Watt Daylight LED Monolight - USER MANUAL 9
SETTING THE CHANNEL AND GROUP
The Endeavor and remote must be
set to the same channel and group
for wireless remote operation.
Channel Selection
Press the channel button (CH). The
channel will be highlighted on the
screen. Use the adjustment knob to
select a channel from 1 to 16.
Group Selection
Press the group button (GR). The
group will be highlighted on the
screen. Use the adjustment knob
to select group A, B, C, D, or E.
Note
Other brands’ Bowens-style reflectors
will work with the Endeavor. Make
sure the reflector has a pass-through
hole to use it with an umbrella.
ADJUSTING THE BRIGHTNESS
The adjustment knob controls
the brightness from 100% to
0% in 10% increments.
instructions

Endeavor 150-Watt Daylight LED Monolight - USER MANUAL
10
PRODUCT
SPECIFICATIONS
LED Chip Type: COB
Color Temperature: 5600 K ±200 K
Light Intensity @ 3 ft.: 33,000 lx
Dimming: 100% to 0%
Coverage: 120°
CRI: 97.5
TLCI: 98.5
Power Draw: 150 W
Working Voltage: 90 to 240 V AC, 50/60 Hz
Mount: 5/8 in.
Channels and Groups: 16 channels, 5 groups
(A, B, C, D, E)
Dimensions (H × D × W): 9.8 × 16.8 × 7 in.
(24.9 × 42.7 × 17.8 cm)
with mount and reflector
Weight: 6 lb. (2.7 kg) with mount and reflector
sPecifications

ONE-YEAR LIMITED WARRANTY
This Genaray product is warranted to the original purchaser to be free from defects in materials and
workmanship under normal consumer use for a period of one (1) year from the original purchase date
or thirty (30) days after replacement, whichever occurs later. Genaray’s responsibility with respect
to this limited warranty shall be limited solely to repair or replacement, at Genaray’s discretion, of
any product that fails during normal use of this product in its intended manner and in its intended
environment. Inoperability of the product or part(s) shall be determined by Genaray. If the product
has been discontinued, Genaray reserves the right to replace it with a model of equivalent quality and
function.
This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse,
improper installation or maintenance. EXCEPT AS PROVIDED HEREIN, GENARAY MAKES NEITHER
ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This
warranty provides you with specific legal rights, and you may also have additional rights that vary from
state to state.
To obtain warranty coverage, contact the Genaray Customer Service Department to obtain a return
merchandise authorization (“RMA”) number, and return the defective product to Genaray along with
the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own
risk and expense.
For more information, or to arrange service, visit www.genaray.com or contact us at [e-mail].
