Generay MOCHI LIGHT User manual

USER MANUAL
MOCHILIGHT

MOCHI On-Camera Mini RGB Light - USER MANUAL
2
The Mochi is a compact and fun on-camera mini RGB LED light
you can pop onto your camera and add advanced lighting effects
to any project you’re shooting. The Mochi’s simple interface
lets you select operating modes and control color temperature,
RGB, and brightness settings to match your subjects and add
some color when you need it. Turn on one of the twenty-one
lighting effects and dazzle your audience by adding realism
and drama to your video. The built-in rechargeable Li-ion
battery will give you nearly an hour and a half of run time at full
power, which is plenty of time to get all the shots you need.
THANK YOU FOR
CHOOSING GENARAY.

MOCHI On-Camera Mini RGB Light - USER MANUAL 3
introduction

MOCHI On-Camera Mini RGB Light - USER MANUAL
4
· Please read and follow these
instructions, and keep this
manual in a safe place.
· Keep this product away
from water and flammable
gases or liquids.
· Use with only the correct,
recommended voltage.
· Do not attempt to
disassemble or repair
this product.
· Clean this product with
only a soft, dry cloth.
· All images are for
illustrative purposes only.
PRECAUTIONS
precautions

MOCHI On-Camera Mini RGB Light - USER MANUAL 5
overview
Value dial
Adjustment
selector/
Effect selector
Mode
selector
USB-C
charging port
LCD screen
1/4-20
mounting
sockets

MOCHI On-Camera Mini RGB Light - USER MANUAL
6
MOUNTING TO A TRIPOD
OR LIGHT STAND
Screw the Mochi onto a
light stand’s 1/4-20 stud,
and tighten until secure.
MOUNTING TO A CAMERA
1. Screw the two
washers onto
the 1/4-20
stud so the flat
surfaces face
out away from
each other.
2. Slide the mounting foot
completely into the camera’s
mounting shoe. Tighten
the bottom washer until it’s
snug against the camera.
3. Screw the Mochi onto the
1/4-20 stud. Then tighten
the top washer until it’s
snug against the light.
MOUNTING THE LIGHT
instructions

MOCHI On-Camera Mini RGB Light - USER MANUAL 7
MAGNETIC MOUNTING
Use the built-in lightweight
magnets to attach the light
to a metal surface.
Note: This feature is best
for mounting the light
under a shelf or desk.
Plug the USB-C connector into
the Mochi, and plug the USB-A
connector to a powered USB port.
When it’s powered on, the
battery indicator will show
the battery’s power level.
CHARGING THE MOCHI
instructions

MOCHI On-Camera Mini RGB Light - USER MANUAL
8
ON-OFF / MODE SELECTOR
Turn the mode selector to
turn the light on and choose
one of the operating modes:
CCT, HSI, and EFF.
VALUE DIAL
In all operating modes, turn
the value dial to change the
selected onscreen parameter.
ADJUSTMENT SELECTOR
Press the adjustment
selector to cycle through
the adjustable parameters
in each operating mode.
CCT
Adjusts the color
temperature from
2500 to 9900 K.
BRIGHTNESS
Adjusts the brightness
from 1% to 100%.
USER INTERFACE CCT MODE
CCT 6200K
CCT 100%
instructions

MOCHI On-Camera Mini RGB Light - USER MANUAL 9
HSI MODE EFF MODE
HSI H:359°
HUE
Adjusts the
hue from 0°
to 360° of the
color wheel.
SATURATION
Controls the
saturation of
the hue from
0% to 100%.
BRIGHTNESS
Adjusts the
brightness from
1% to 100%.
Turn the
selector to
EFF mode.
Press the
effects
selector
button to
cycle through
the effects.
BRIGHTNESS
Adjusts the
brightness
from 1%
to 100%.
HSI S :10 0 %
F-5 Flame 1
F-6 25%
HSI 1%
instructions

MOCHI On-Camera Mini RGB Light - USER MANUAL
10
EFFECTS
1. Flash: Simulates multiple
camera flashes with short
bursts of white light.
2. Fast: Similar to Flash, with short
and rapid bursts of white light.
3. TV Screen: Simulates the
constant glow from a television.
4. Candle: Simulates the warm
light of a flickering candle with a
constant color temperature and
brief changes in brightness.
5. Flame 1: Simulates the dim light
of a campfire or fireplace with a
constant color temperature and
brief changes to brightness.
6. Flame 2: Similar to Flame 1, with
more rapid changes in brightness.
7. Police: Simulates the flashing
lights of an emergency vehicle with
alternating red and blue strobing.
8. Ambulance: Simulates the flashing
blue light of an ambulance.
9. Fire Truck: Simulates the
flashing red light of a fire truck.
10. Strobe 1: A constant
white strobe light.
11. Strobe 2: Similar to Strobe 1,
with more rapid strobing.
instructions

MOCHI On-Camera Mini RGB Light - USER MANUAL 11
12. Strobe 3: More rapid
strobing than Strobe 2.
13. Chase Slow: Scrolls through the
entire color wheel from 0% to
360% on a continuous loop.
14. Chase Mid: Similar to Chase
Slow, with a more rapid loop
through the color wheel.
15. Chase Fast: Similar to Chase
Mid, with a more rapid loop
through the color wheel.
16. Firework 1: Simulates the light
from a fireworks display with blue,
red, and orange bursts with a fade.
17. Firework 2: Similar to Firework
1 with blue, red, green, and
orange bursts with more rapid
color changes and fade.
18. Firework 3: Simulates fireworks
with alternating flashing red
light and solid white light.
19. Club 1: Simulates rapidly strobing
disco lights of different colors.
20. Club 2: Simulates disco lights
with alternating colors.
21. Romantic: Slowly pulsating
magenta light.
instructions

MOCHI On-Camera Mini RGB Light - USER MANUAL
12
Beam Angle: 120°
Color Temperature: 2500 to 9900 K
Color Accuracy Standard: CRI: >95
TLCI: 99
Cooling System: Passive
Dimming: Yes, 1% to 100%
Display: LCD
Housing Material: ABS plastic
Light Fixture
SPECIFICATIONS
Light Intensity @ 3 ft.: 135 lx
Number of LEDs: 60 (40 A/W, 20 RGB)
Expected Lamp Life: 50,000 hr.
Dimensions (H × W × D):
3 × 2.8 × 1.2 in. (7.6 × 7 × 3.3 cm)
Weight: 4 oz. (113 g)
specifications

MOCHI On-Camera Mini RGB Light - USER MANUAL 13
Fixture Mount: 1/4-20 (×2)
Removable shoe mount
Connectors
Mounting
Power Input Connector: USB Type-C DC Input Power: 5 V/2 A
DC Output: 3.7 V, 2000 mAh
Power Source: Internal battery
(Rechargeable Li-ion)
Max Power Consumption: 6 W
Battery Life: 1.4 hr. @9000 K, 100%
Battery Charge Time: 2.2 hr.
Power
specifications

ONE-YEAR LIMITED WARRANTY
This Genaray product is warranted to the original purchaser to be free from defects in
materials and workmanship under normal consumer use for a period of one (1) year from
the original purchase date or thirty (30) days after replacement, whichever occurs later.
Genaray’s responsibility with respect to this limited warranty shall be limited solely to
repair or replacement, at Genaray’s discretion, of any product that fails during normal use
of this product in its intended manner and in its intended environment. Inoperability of the
product or part(s) shall be determined by Genaray. If the product has been discontinued,
Genaray reserves the right to replace it with a model of equivalent quality and function.
This warranty does not cover damage or defect caused by misuse, neglect, accident,
alteration, abuse, improper installation or maintenance. EXCEPT AS PROVIDED
HEREIN, GENARAY MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY IMPLIED
WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This warranty provides
you with specific legal rights, and you may also have additional rights that vary from state
to state.
To obtain warranty coverage, contact the Genaray Customer Service Department to obtain
a return merchandise authorization (“RMA”) number, and return the defective product to
Genaray along with the RMA number and proof of purchase. Shipment of the defective
product is at the purchaser’s own risk and expense.
For more information, or to arrange service, visit www.genaray.com or contact us at [e-mail].
