Generay RGB Series User manual

USER MANUAL
PX1 / 2 / 4
RGB PIXEL TUBE LIGHTS
RGB SERIES

RGB Pixel Tube Lights - USER MANUAL
2
THANK YOU FOR CHOOSING GENARAY
Genaray’s RGB Pixel Tube Lights are a powerful and versatile
solution for advanced and customizable lighting effects for
studio, film, and TV production. Pixel control offers individual
parameter settings for color, width, speed, and grouping. Adjust
a full 360° RGB spectrum, 2800 to 8000 K CCT bicolor, and flow
direction. With wireless Bluetooth control or via DMX, you can
set up dazzling color arrays with multiple lighting effects and
patterns. Create spatial effects that add ambiance with eye-
catching motion.
RGB Pixel Tube Light

RGB Pixel Tube Lights - USER MANUAL 3
· Please read and follow these
instructions, and keep this manual in
a safe place.
· Keep this unit away from water and
any flammable gases or liquids.
· Make sure the unit is powered off
when plugging it into a power source.
· Use only the correct, recommended
voltage.
· Do not attempt to disassemble or
repair the equipment—doing so may
expose you to electric shock and will
void the warranty. Genaray will not be
responsible for any damage.
· Handle the unit with care.
· Do not stare directly at the lights when
they are powered on.
· Keep this product away from children.
· Clean the unit with only a soft, dry
cloth.
· Images are for illustrative purposes
only.
PRECAUTIONS
Precautions

RGB Pixel Tube Lights - USER MANUAL
4
PRODUCT
OVERVIEW
PX1-RGB
1/4-20 mount
1/4-20 mount
Magnet
Magnet
USB Type-C
charging port

RGB Pixel Tube Lights - USER MANUAL 5
Product overview
Power socket
DC 24 V charging port
PX2-RGB/PX4-RGB
1/4-20 mount
Side
3-pin mini DMX
input socket
3-pin mini DMX
output socket

RGB Pixel Tube Lights - USER MANUAL
6
Product overview
Interface
OLED
Mode select button
Setting select button
Increase button
Decrease button
Power button

RGB Pixel Tube Lights - USER MANUAL 7
CONTENTS INCLUDE
PX1RGB
· RGB Pixel Tube light
· USB Type-C to USB Type-A cable
· Wrist strap
· Soft bag
· User manual
PX2RGB / PX4RGB
· RGB Pixel Tube light
· Tripod
· Carrying case
· Power adapter
· User manual
The Genaray RGB Pixel Tube Lights can be
mounted onto any light stand with a 1/4-20
stud, and the models PX2 and PX4 include
a lightweight tripod. The PX1 has built-in
magnets so you can attach the light to any
ferrous metal surface.
MOUNTING THE LIGHT
instructions

RGB Pixel Tube Lights - USER MANUAL
8
TURNING ON THE
RGB PIXEL TUBE LIGHT
PX1RGB USB TYPEC 5V, 2A
PX2RGB/PX4RGB
DC 24V, 2A POWER ADAPTER
· When the light is powered off, a charging
status icon appears on the screen.
· When the light is powered on, a charging
icon appears in the top right corner of
the screen.
Warning!
When set to full brightness, the RGB Pixel
Tube Lights are powerful. Do not look
directly into the light while it’s turning on.
Press and hold the power button until the
settings are displayed on the LCD and the
light turns on.
To turn the Pixel Tube Light off, press and
hold the power button until the LCD and
light turns off.
CHARGING THE
BATTERY
instructions

RGB Pixel Tube Lights - USER MANUAL 9
USER INTERFACE
CCT: Correlated Color Temperature from
2800 to 8000 K
INT: Intensity from 0% to 100%
G/M: Green/Magenta from -1.00 to +1.00
CCT MODE BICOLOR
1. Mode
2. Group
3. Light number
4. Master/slave
status
5. Remaining
battery operation
time with current
settings
6. Settings
7. Setting value
instructions
CCT
INT
G/M
2800
G01 L01 M 2.5h
CCT:
CCT
INT
G/M
2800
G01 L01 M 2.5h
CCT:
1 2 3 4 5
76

RGB Pixel Tube Lights - USER MANUAL
10
HUE: Hue from 0° to 359°
SAT: Saturation from 0% to 100%
INT: Intensity from 0% to 100%
GEL: Standard gel colors: Blue, orange,
straw, cyan, green, yellow, red, and
magenta
INT: Intensity from 0% to 100%
HSI MODE RGB GEL MODE COLOR GELS
instructions
HSI
SAT
INT
G01 L01 M 2.5h
HUE: 180°
GEL
3/4 BLUE
INT 1/2 BLUE
G01 L01 M 2.5h
GEL: BLUE

RGB Pixel Tube Lights - USER MANUAL 11
Play/Stop: Starts and stops the effect.
Press the + or – buttons to
start and stop the effect.
INT: Intensity from 0 to 100
EFX EFFECTS
COLOR CHASE: Scrolls through different
colors.
VAR: Variety from 3 to 10
SPD: Speed from 1 to 10
LIGHTNING: Simulates lightning with short
and random bursts of light.
STL: Style from 1, 2, or 3
FRQ: Frequency from 1 to 10
COP CAR: Simulates the flashing lights of a
police car.
STL: Style: B+R (Blue+Red)
B+W (Blue+White)
B+R+W (Blue+Red+White)
PTTN: Pattern: 1 (Single flash)
2 (Double flash)
3 (Triple flash)
EFX MODE
STANDARD EFFECTS
instructions
EFX
INT
100
G01 L01 M 2.5h
VAR
SPD
7
5
COLOR CHASE

RGB Pixel Tube Lights - USER MANUAL
12
EXPLOSION: A burst of light that fades out.
CCT: Correlated Color Temperature from
2800 to 8000 K
DECAY: From 0.5 to 4.0 seconds
TELEVISION: Simulates the glow from a
television with different levels
of intensity.
RANG: CCT Range: LOW (2800 to 4500 K)
MID (4500 to 6200 K)
HIGH (6200 to 8000 K)
SPD: Speed from 1 to 10
FIRE: Simulates the light emitted from a
campfire or fireplace.
RANG: CCT Range: LOW (2800 to 2900 K)
MID (2900 to 3000 K)
HIGH (3000 to 3200 K)
SPD: Speed from 1 to 10
PAPARAZZI: Simulates multiple camera
flashes with short bursts.
STL: Style: 1 (Modern flash)
2 (Flash bulb)
FRQ: Frequency from 1 to 10
STROBE: Constant flashing light.
CCT: Correlated Color Temperature from
2800 to 8000 K
FRQ: Frequency from 1 to 10
FIREWORKS: Simulates fireworks with
pulses of color and white light.
COMB: Combination: Color, White, White
(Colors + White)
SPD: Speed from 1 to 10
PULSING: Light steadily fades in and out.
CCT: Correlated Color Temperature from
2800 to 8000 K
TIME: From 0.55 to 4.05 seconds
instructions

RGB Pixel Tube Lights - USER MANUAL 13
PIXEL EFFECTS
Pixel effects offer a wide range of controls
allowing you to adjust pixels independently
of each other.
RAINBOW: Cycles through all 360° of color.
PERIOD: Amount of time it takes to cycle
through all 360° colors from 0.5
to 20 seconds
DELAY: Amount of time each pixel holds
a selected color from 0.02 to 2
seconds
SYM: Light pulse from center outward
On/Off
DIR: Direction left or right
INT: Intensity from 0% to 100%
PXL MODE
PIXEL EFFECTS
instructions
PXL
PXL: RAINBOW
PERIOD
DELAY
2S
0.05S
G01 L01 M 2.5h

RGB Pixel Tube Lights - USER MANUAL
14
CYCLE: Cycle between four colors.
CLR1: Color 1 from 0° to 360°, 2800 to
8000 K, BLK (no color)
CLR2: Color 1 from 0° to 360°, 2800 to
8000 K, BLK (no color)
CLR3: Color 1 from 0° to 360°, 2800 to
8000 K, BLK (no color)
CLR4: Color 1 from 0° to 360°, 2800 to
8000 K, BLK (no color)
TIME: Amount of time between color is
visible from 0.2 to 20 seconds
FADE%: Smoothness between color
changes from 0% to 100%
DIR: Direction left or right
INT: Intensity from 0% to 100%
TRANS: Transition between two defined
colors.
CLR1: Color 1 from 0° to 360°
CLR2: Color 2 from 0° to 360°
PERIOD: Amount of time it takes to cycle
from CLR1 to CLR2 from 0.5 to
20 seconds
DELAY: Amount of time each pixel holds
a selected color from 0.02 to 2
seconds
DIR: Direction left or right
SYM: Light pulse from center outward
On/Off
INT: Intensity from 0% to 100%
instructions

RGB Pixel Tube Lights - USER MANUAL 15
RUNNING: One color running over a
background color.
RUN: Running color from 0° to 360°, 2800
to 8000 K, BLK (no color)
RUN INT: Running color intensity from
0% to 100%
BACK: Background color from 0° to 360°,
2800 to 8000 K, BLK (no color)
BAK INT: Background color intensity
from 0% to 100%
SPEED: Speed of running color from 1
to 10
LENGTH: Length of running color from
1 to 8
GRDNT: Gradates running color into the
background color On/Off
DIR: Direction left or right
FLOW: Four user defined colors, CCT, or
no color, flowing one at a time into
the next.
CLR1: Color 1 from 0° to 360°, 2800 to
8000 K, BLK (no color)
CLR2: Color 2 from 0° to 360°, 2800 to
8000 K, BLK (no color)
CLR3: Color 3 from 0° to 360°, 2800 to
8000 K, BLK (no color)
CLR4: Color 4 from 0° to 360°, 2800 to
8000 K, BLK (no color)
SPEED: Speed of color change from 1
to 10
DIR: Direction left or right
INT: Intensity from 0% to 100%
instructions

RGB Pixel Tube Lights - USER MANUAL
16
CCT TRANS.: Transition between
two Correlated Color
Temperatures (CCT)
CCT1: Correlated Color Temperature 1
from 2800 to 8000 K
INT: Intensity from 0% to 100%
CCT2: Correlated Color Temperature 2
from 2800 to 8000 K
INT: Intensity from 0% to 100%
PERIOD: Amount of time it takes to cycle
from CCT1 to CCT2 from 0.5 to
20 seconds
DELAY: Amount of time each pixel holds
a selected color from 0.02 to 2
seconds
SYM: Symmetry On/Off
DIR: Direction left or right
FLAME: Simulates a fire or candlelight with
one color over a background color
COLOR: Flame color from 0° to 360°,
2800 to 8000 K, BLK (no color)
FLM INT: Flame color intensity from 0%
to 100%
BACK: Background color from 0° to 360°,
2800 to 8000 K, BLK (no color)
BAK INT: Background color intensity
from 0% to 100%
FRQ: Frequency from 0.25 to 10 Hz
instructions

RGB Pixel Tube Lights - USER MANUAL 17
G#: Group number from 0 to 99.
L#: Assigned light number from 0 to 99.
M/S: Master, None, or Slave.
LNG: Language
RFD: Restore factory settings to default.
DMX: DMX address
SET MODE
SETTINGS
PRO: DMX profile settings
HSI 1 PXL, HSI 8 PXL, HSI 16 PXL,
CCT W. RGBW 1 PXL, CCT W. RGBW 8 PXL,
CCT W. RGBW 16 PXL, GEL 1 PXL.
SET: DMX signal loss behavior if the DMX
signal is interrupted.
HOLD: Holds the last DMX setting
BLK OUT: Displays no color
VER: Firmware version.
instructions
SET
L#
M/S
G01 L01 M 2.5h
G#: 1

RGB Pixel Tube Lights - USER MANUAL
18
GENARAY RGB APP
1. Press the Mode select button to enter the
Settings mode.
2. Press the Setting select button until DMX
is highlighted.
3. Press the + or − buttons to select a DMX
channel from 001 to 512. Make sure
the DMX channel on the light and your
console are the same.
Genaray RGB-series lights can be controlled
via the RGB Series app from approximately
33 feet away. The RGB Series app expands
the Pixel Tube Lights’ capabilities with a
wider range of editable parameters.
Visit genaray.com for a complete user
manual.
USING DMX
PX2RGB/PX4RGB
instructions
SET
RFD
DMX:
G01 L01 M 2.5h
LNG 001

RGB Pixel Tube Lights - USER MANUAL 19
DEFAULT PXL EFFECT
SETTINGS
RAINBOW
PERIOD: 2 seconds
DELAY: 0.05 seconds
SYM: Off
DIR: —>
INT: 100%
TRANS
CLR1: 340°
CLR2: 240°
PERIOD: 2 seconds
DELAY: 0.05 seconds
SYM: On
INT: 100%
CYCLE
CLR1: 0°
CLR2: 60°
CLR3: 120°
CLR4: 240°
TIME: 1 second
FADE: 30%
INT: 100%
RUNNING
RUN: 360°
RUN INT: 100%
BACK: 240°
BAK INT: 100%
SPEED: 6
LENGTH: 4
GRADIENT: Off
instructions

RGB Pixel Tube Lights - USER MANUAL
20
CCT TRANS
CCT1: 2800 K
INT: 100%
CCT2: 8000 K
INT: 100%
PERIOD: 2 seconds
DELAY: 0.1 seconds
SYM: Off
FLOW
CLR1: 240°
CLR2: 0°
CLR3: 120°
CLR4: 336°
SPEED: 6
INT: 100%
FLAME
COLOR: 0°
FLM INT: 100%
BACK: 30°
BAK INT: 100%
FRQ: 2.5 Hz
instructions
