Generay RSF-11-RGB User manual

USER MANUAL
Mini Moon RGB
11 IN. RGB LED
RSF-11-RGB

Mini Moon RGB 11 in. RGB LED - USER MANUAL
2
THANK YOU FOR CHOOSING GENARAY
The Genaray Mini Moon RGB is a portable fixture that
provides a natural and soft continuous light source with
broad coverage for still and tabletop photography, portraits,
and interviews. This light delivers highly accurate color
rendering in CCT and RGB modes. An integrated diffuser
furnishes a soft wraparound and single-shadow beam.
The Mini Moon RGB operates on either on AC or battery
power and will accept either NP-F or V-mount batteries. It
features dimming from 100% to 0% in 1% increments. This
light supports DMX-512, so its settings can be remotely
controlled from a DMX console. It has 512 selectable channels
and a DMX output jack to daisy-chain other DMX-compatible
lights. Remote operation from up to 60 feet away is possible
with Genaray’s RSF-11-R remote (available separately).
Mini Moon RGB
INTRODUCTION

Mini Moon RGB 11 in. RGB LED - USER MANUAL 3
· Please read and follow these
instructions, and keep this manual in
a safe place.
· Keep this unit away from water and
any flammable gases or liquids.
· Make sure the unit is powered off
when plugging it into a power source.
· Do not use 26-volt V-mount batteries
with this fixture. Doing so will damage
the unit and void the warranty. Use
only the correct, recommended
voltage posted on the battery plate and
in this manual.
· Handle the unit with care.
· Do not attempt to disassemble or
repair the equipment—doing so will
void the warranty, and Genaray will not
be responsible for any damage.
· Do not stare directly at the lights when
they are powered on.
· Clean the unit with only a soft, dry
cloth.
· Images are for illustrative purposes
only.
PRECAUTIONS
Precautions

Mini Moon RGB 11 in. RGB LED - USER MANUAL
4
PRODUCT
OVERVIEW
Light Fixture - Front
2-way 5/8 in.
mount
Tilt
adjustment
knobs
Diffuser
Yoke
Locking knob

Mini Moon RGB 11 in. RGB LED - USER MANUAL 5
Product overview
Light Fixture - Back
V-mount release button
V-mount battery plate
NP-F battery
plates
Color/Sat/FX
dial
DMX input and
output
LCD display
Power switch
Power socket
Dim/Channel dial
Mode
button
Bluetooth
button
Channel button
DMX button

Mini Moon RGB 11 in. RGB LED - USER MANUAL
6
CONTENTS INCLUDE
MOUNTING THE MINI
MOON RGB
· LED with yoke
· AC adapter
· Power cord
· Carry case
The Mini Moon RGB is equipped with a
2-way 5/8-inch receiver.
Mount the Mini Moon RGB on any light stand
with a 5/8-inch stud, in upright or horizontal
orientation, and turn the locking knob until
secure.
instructions

Mini Moon RGB 11 in. RGB LED - USER MANUAL 7
POWERING THE
MINI MOON RGB
The Mini Moon RGB can be powered directly
from an AC outlet, two NP-F batteries, or
one V-mount battery.
AC POWER
Connect the AC power adapter to the Mini
Moon RGB with the included 2-pin cable,
and plug the power cable into an outlet.
To turn on the fixture, press the power
switch to the AC position (II).
BATTERY POWER
The Mini Moon RGB can be powered by two
NP-F batteries or one V-mount battery.
Important
Use only V-mount batteries with a
maximum of 14.8 volts per battery. Two
NP-F batteries must be attached to the
Mini Moon RGB to power the light.
When attaching batteries, make sure the
power switch is in the off position, and the
fixture is not plugged into a wall outlet.
instructions

Mini Moon RGB 11 in. RGB LED - USER MANUAL
8
Installing a V-mount battery
Align the battery with the battery terminals,
and slide the battery onto the plate until
it clicks into place. To remove the battery,
press the release button to unlock the
battery and slide it off the plate.
The V-mount plate is equipped with a D-Tap
output for powering accessories.
Installing NP-F Batteries
Align the batteries with the terminals in the
battery plates. Place the batteries down
into the plates, and slide them toward the
terminals until secure.
To turn on the fixture, press the power
switch to the DC position (I).
The battery status indicator on the LCD
screen displays the remaining battery
power.
100% to 75%
75% to 50%
50% to 25%
25% to 10%
(the light will not operate under 10%)
instructions

Mini Moon RGB 11 in. RGB LED - USER MANUAL 9
OPERATING THE
MINI MOON RGB
SETTING THE CHANNEL
You can use Genaray’s wireless controller
(RSF-11-R available separately) to remotely
operate the Mini Moon RGB from up to
60 feet away. Make sure the Mini Moon RGB
and the remote are set to the same channel.
1. Press the Channel button. The channel
number will blink.
2. While the channel icon is blinking, use
the Dim/Channel dial to select a channel
from 1 to 99.
3. Press the Channel button again to set
the channel. The channel icon will stop
blinking.
OPERATING MODES
The Mini Moon RGB has four operating
modes:
CCT Mode allows you to adjust the color
temperature from 2700 to 9999 K.
RGB Mode allows you to select a hue on the
color wheel from 1° to 360°.
DMX Mode allows you to control the Mini
Moon RGB from a DMX console. When DMX
mode is selected, the onboard controls are
disabled.
FX Mode has twenty selectable
programmed animated effects.
Toggle between CCT and RGB modes by
pressing the Mode button.
instructions

Mini Moon RGB 11 in. RGB LED - USER MANUAL
10
Press the Mode button to select RGB mode.
· Adjust the hue from 0° to 360° in one-
degree increments by turning the Color/
Sat/FX dial.
· Adjust the saturation by pressing the
Color/Sat/FX dial. The saturation value
will blink.
Press the Mode button to select CCT mode.
· Adjust the color temperature from
2700 to 9999 K by turning the Color
Temperature dial.
· Adjust the brightness from 0% to 100%
by turning the DIM dial.
CCT MODE RGB MODE
instructions
Color temperature Hue (color)Brightness Saturation
Brightness

Mini Moon RGB 11 in. RGB LED - USER MANUAL 11
The Mini Moon RGB has twenty built-in CCT
and RGB effects.
FX mode can be accessed via CCT or RGB
mode. Activating FX mode from either mode
will access a different group of effects.
FX MODE
· While the saturation value is blinking,
turn the Color/Sat/FX dial to adjust the
value, and press the dial again to set it.
· Adjust the brightness from 0% to 100%
by turning the DIM dial.
instructions
Effect
number
BrightnessFrequency

Mini Moon RGB 11 in. RGB LED - USER MANUAL
12
CCT EFFECTS
These effects use the white and amber
LEDs to create animated lighting effects
with different color temperatures.
1. Pulsing
2. Lightning
3. TV
4. Faulty Bulb
5. Paparazzi
6. SOS
7. Fade-in
8. Fade
9. Campfire
10. Explosion
11. Candle
12. Breathe
ACTIVATING FX MODE
To activate FX mode, press and hold the
Mode button and press theColor/Sat/FX dial.
· Activating FX mode from CCT mode will
open a list of effects that use variations of
color temperature for the effects.
· Activating FX mode from RGB mode will
open a different list of effects that use the
Mini Moon’s RGB LEDs.
Once an effect is selected, it will begin to
play.
Press the Color Temp/Sat/FX dial to adjust
the frequency. Rotate the dial to adjust the
value, and then press the dial to set it. The
frequency controls how fast the effect plays.
Select from 1 to 9 (slowest to fastest).
Press the Mode button to stop or pause the
effect and return to CCT or RGB mode.
instructions

Mini Moon RGB 11 in. RGB LED - USER MANUAL 13
The Mini Moon RGB supports DMX-512,
so the light’s settings can be remotely
controlled from a DMX console.
Note
When the Mini Moon RGB is in DMX
mode, the adjustment dials are disabled.
Adjust the brightness and color
temperature via the DMX console.
To set up DMX operation on the Mini Moon
RGB, follow these steps:
1. Use a DMX cable to connect a DMX
controller to the Mini Moon’s DMX input
port. The Mini Moon RGB has RJ45
DMX ports. If your DMX controller has
XLR ports, you will need XLR-to-RJ45
adapters (available separately).
2. Use the DMX output port to connect
multiple lights.
RGB EFFECTS
These effects use the RGB LEDs to create
colorful animated lighting effects.
1. Cop Car
2. Party
3. Fireworks
4. Disco
5. Ambulance
6. Fire Siren
7. RGB Loop
8. Welding
USING DMX
instructions

Mini Moon RGB 11 in. RGB LED - USER MANUAL
14
To set the DMX address on the Mini Moon
RGB:
1. Press the DMX button to switch to
DMX mode. The current DMX channel
selection will appear onscreen.
2. Press the Channel button. The channel
number will blink.
3. While the channel icon is blinking, use
the Dim/Channel dial to select a DMX
channel from 01 to 512.
4. Press the Channel button to set the
channel selection. The channel number
will stop blinking.
Important
Make sure the DMX address on the Mini
Moon RGB matches the DMX console.
USING THE RSF11R
WIRELESS TRANSMITTER
The Mini Moon RGB’s wireless transmitter
allows you to operate the Mini Moon RGB
from up to 60 feet away.
OVERVIEW
instructions
Up/down buttons
On/Off button
(sleep mode)
FX button
+/− buttons
Mode button
Channel button

Mini Moon RGB 11 in. RGB LED - USER MANUAL 15
CHANGING OPERATING MODES
CCT and RGB Modes
1. Press the Mode button to toggle
between CCT and RGB modes.
2. Press the up/down buttons to select
the values for hue, brightness, and
saturation.
3. When the function is selected, use the +
and − buttons to adjust the setting.
FX Mode
FX mode can be accessed via CCT or RGB
mode. Pressing the FX button from either
mode will access a different group of effects.
Pressing the FX button in CCT mode will
open a list of effects that use variations of
color temperature.
POWERING ON
Press the On/Off Button. The remote will
power up to the most recently used settings.
SETTING THE CHANNEL
Press the Channel button to highlight the
channel number.
Use the – and + buttons to select the
channel, and press the Channel button
again to set it.
Make sure the Mini Moon RGB is set to the
same channel as the remote. See Setting
the Channel in Operating the Mini Moon
RGB above .
Selecting ALL will control all Mini Moon
RGB fixtures within range, regardless of the
channels they’re set to.
The settings for each channel are stored in
the RDF-11-R’s memory.
instructions

Mini Moon RGB 11 in. RGB LED - USER MANUAL
16
Pressing the FX button in RGB mode will
open a different list of effects that use the
Mini Moon’s RGB LEDs.
Refer to FX Mode above for a list of CCT and
RGB effects.
1. Press the FX button in CCT or RGB
mode to access the effects.
2. Use the + and − buttons to select one of
the effects. When the effect is selected,
it will begin to play.
3. Press the up/down buttons to select the
values for brightness and frequency.
Use the + and − buttons to adjust the
values. The frequency level controls how
fast the effect plays. Select from 1 to 9
(slowest to fastest).
4. Press the FX button again to pause the
effect and return to RGB or CCT mode.
SLEEP MODE
Using sleep mode will preserve battery life
without turning off the Mini Moon RGB.
Press and hold the On/Off button to put the
Mini Moon RGB to sleep. Press the On/Off
button again to resume operation.
instructions

Mini Moon RGB 11 in. RGB LED - USER MANUAL 17
PRODUCT
SPECIFICATIONS
Color Temperature: 2700 to 9999 K ±300 K
Brightness : @ 3 ft.: 2520 lx (5600 K)
@ 1 m: 2105 lx (5600 K)
Coverage: 120°
CRI: 96.9
TLCI: 99
Max Power Consumption: 75 W
Working Voltage: AC: 100–240 V 50~60 Hz
DC: 15 V ⎓ 4 A
Battery Type: NP-F750/950 (×2)
V-mount (14.8 V Max)
Mount: 2-way 5/8 in. Receiver
Cable Length: AC Adapter Cord: 12.5 ft. (3.8 m)
Power Cord: 12.75 ft. (3.9 m)
Dimensions with Yoke (H × W × D):
14.7 × 14.2 × 2.2 in.
(37.3 × 36.1 × 5.6 cm)
Weight (with yoke, without batteries):
3.1 lb. (1.4 kg)
sPecifications

Mini Moon RGB 11 in. RGB LED - USER MANUAL
18
WIRELESS TRANSMITTER
Frequency: 2.4 GHz
Working Distance: 60 ft. (18.3 m)
Functions: On/off, Mode selection, Brightness,
Color saturation, Channel selection ,Color
temperature, Effects selection, Effects frequency
adjustment
Power: Two AAA batteries (not included)
Dimensions (H × W × D): 1.75 × 5.5 × 0.7 in.
(4.4 × 14 × 1.8 cm)
Weight: Without batteries: 2.6 oz. (74 g)
sPecifications

ONE-YEAR LIMITED WARRANTY
This Genaray product is warranted to the original purchaser to be free from defects in materials and
workmanship under normal consumer use for a period of one (1) year from the original purchase date
or thirty (30) days after replacement, whichever occurs later. Genaray’s responsibility with respect
to this limited warranty shall be limited solely to repair or replacement, at Genaray’s discretion, of
any product that fails during normal use of this product in its intended manner and in its intended
environment. Inoperability of the product or part(s) shall be determined by Genaray. If the product
has been discontinued, Genaray reserves the right to replace it with a model of equivalent quality and
function.
This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse,
improper installation or maintenance. EXCEPT AS PROVIDED HEREIN, GENARAY MAKES NEITHER
ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This
warranty provides you with specific legal rights, and you may also have additional rights that vary from
state to state.
To obtain warranty coverage, contact the Genaray Customer Service Department to obtain a return
merchandise authorization (“RMA”) number, and return the defective product to Genaray along with the
RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk
and expense.
For more information, or to arrange service, visit www.genaray.com or contact us at [e-mail].
© 2023 Genaray. All Rights Reserved.

GG1
