Generay TIR-1X1B User manual

USER MANUAL
Bright Beast
1×1 BI-COLOR PANEL
TIR-1X1B

Bright Beast 1×1 Bi-Color Panel - USER MANUAL
2
THANK YOU FOR CHOOSING GENARAY
The Genaray Bright Beast is a 1×1 bi-color panel that uses 256
LEDs to throw an ultrabright, flicker-free light that’s ideal for
photo and video shoots. It operates on AC power or a single
V-mount battery, and it features 0% to 100% dimming for a full
6 stops of light. Built-in Bluetooth, DMX, and an AC adapter
give you an all-in-one unit that needs no extra components or
accessories for full functionality.
The Bright Beast supports DMX-512 so the light’s settings
can be remotely controlled from a DMX console. It has 512
selectable channels and a 5-pin XLR output jack to daisy-chain
other DMX-compatible lights. The Bright Beast can also be
controlled via Bluetooth with the Bright Beast app, which will
let you operate the light from 30 feet away.
For compatibility in the studio, the yoke can be mounted to a
light stand with a baby pin or junior pin.
Bright Beast
INTRODUCTION

Bright Beast 1×1 Bi-Color Panel - USER MANUAL 3
· Please read and follow these
instructions, and keep this manual in
a safe place.
· Keep this unit away from water and
any flammable gases or liquids.
· Make sure the unit is powered off
when plugging it into a power source.
· Use only the correct, recommended
voltage.
· Handle the unit with care.
· Do not attempt to disassemble or
repair the equipment—doing so will
void the warranty, and Genaray will not
be responsible for any damage.
· Do not stare directly at the lights when
they are powered on.
· Clean the unit with only a soft, dry
cloth.
· Images are for illustrative purposes
only.
PRECAUTIONS
Precautions

Bright Beast 1×1 Bi-Color Panel - USER MANUAL
4
PRODUCT
OVERVIEW
Light Fixture - Front
Yoke
Tilt lock
256 LED
Panel
Barndoor lock
Diffuser
registration
pins
Barndoor brackets
5/8 in. receiver
Locking knob

Bright Beast 1×1 Bi-Color Panel - USER MANUAL 5
Product overview
Light Fixture - Back
Mode selector/
Brightness dial
Color/Set Dial
LCD display
Fan vent Fan power switch
Power switch
AC power input
V-mount
battery plate
V-mount
release button
DMX out
(female)
DMX in (male)

Bright Beast 1×1 Bi-Color Panel - USER MANUAL
6
MOUNTING INSTRUCTIONSCONTENTS INCLUDE
· LED with yoke
· Power cable
· Carry bag
Mount the Bright Beast on any heavy-duty
light stand with a 5/8-inch baby pin, and turn
the locking knob until secure. Remove the
locking knob to mount the Bright Beast into
a junior receiver.
contents

Bright Beast 1×1 Bi-Color Panel - USER MANUAL 7
POWERING THE
BRIGHT BEAST
FROM AN AC OUTLET
The Bright Beast can be powered directly
from an AC outlet or by a V-mount battery
(not included).
USING THE BRIGHT BEAST WITH AC
POWER
Connect the AC power cable to the Bright
Beast by aligning the tabs and inserting the
cam lock into the AC input. Turn the cam
lock a quarter-turn to the right until it clicks.
Power on the Bright Beast by flipping the
power switch to the AC position.
To unplug the AC cable, pull the AC release,
twist the cam lock a quarter-turn to the left,
and slide the plug out of the socket.
instructions

Bright Beast 1×1 Bi-Color Panel - USER MANUAL
8
USING THE BRIGHT BEAST WITH
BATTERY POWER
The Bright Beast can be powered by a
V-mount battery.
When attaching the battery, make sure the
power switch is in the center Off (O) position,
and the fixture is not plugged into a wall
outlet.
Once the battery is mounted, flip the power
switch to the DC position to power on the
light.
Anton-Bauer batteries can be used by
connecting them to the Bright Beast with an
adapter plate (sold separately).
The battery status indicator on the LCD
display shows the remaining battery power.
Tip
The battery loses some of its charge when
not in use. If the battery has not been in use
for several months, Genaray recommends
fully recharging the battery before a shoot.
75% to 100%
50% to 75%
25% to 50%
Less than 25%
instructions

Bright Beast 1×1 Bi-Color Panel - USER MANUAL 9
OPERATING THE FAN
SELECTING AN OPERATING MODE
The Bright Beast has three operating
modes: CCT, Effects, and Bluetooth Reset.
Press the Mode Selector button repeatedly
to cycle through and select a mode.
Fast and Slow Scrolling Settings
The scrolling rate setting lets you rapidly
scroll to a color temperature and brightness
or fine-tune the settings.
Press and hold the Mode Selector button for
3 seconds to select Fast or Slow settings. An
F or an S will appear onscreen to indicate
the setting.
· Selecting Fast lets you adjust the color
temperature in 100 K increments, and
brightness in 10% increments.
· Selecting Slow lets you fine-tune the
color temperature in 50 K increments,
and brightness in 1% increments.
The Bright Beast is outfitted with a manual
fan control. The fan is extremely quiet, but
it can be switched off if a microphone is
picking up some fan noise.
· When the fan power switch is in the On
position (|), the lights’ brightness can be
adjusted to 100%.
· When the fan power switch is in the
Off position (O), the light’s maximum
brightness is 50%.
USER INTERFACE
instructions

Bright Beast 1×1 Bi-Color Panel - USER MANUAL
10
The Bright Beast is preset with 9 animated
lighting effects that can be selected and
edited on the LCD screen or the Bright
Beast app.
To enter Effects mode, press the Brightness/
Mode dial repeatedly until Effects mode
appears on the screen.
Press the Color/Set Dial repeatedly to
highlight the scene, and turn it to select one
of the 9 preloaded effects.
CCT MODE EFFECTS MODE
CCT mode allows you to adjust color
temperature and brightness.
· Turn the Mode/Brightness Dial to adjust
the brightness.
· Turn the Color/Set Dial to change the
color temperature from 3000 to 5600 K.
instructions
CH 001
078
CCT 5600K
%
24°S
09
SCENE
05401 %
CH 001 24°S

Bright Beast 1×1 Bi-Color Panel - USER MANUAL 11
Screen: Simulates the flicker from a
television with random brightness changes
of bright white light.
Candle Light: Simulates the light of a
candle or fireplace. A constant warm
white light randomly switches and fades at
random intervals between a set range of
brightnesses.
Flash Light: Simulates multiple camera
flashes with short bursts of white light.
Strobe: Rapid, even bursts of white light.
Far and Near Light: A steady pulse of bright
white light with equal intervals of on and off.
Alarm: A steady pulse of warm white light
with equal intervals of on and off.
Heartbeat: Warm white light fades on and
off with a steady rhythmic pulse.
EDITING THE EFFECT
When you select an effect, it immediately
begins playing.
Pressing the Color/Set Dial selects between
DMX channel, scene, speed, and brightness.
DMX Channel: Set the DMX channel
between 000 and 512. (See Using DMX
below)
Speed: Determines how rapidly the effect
plays or cycles. Select between 0 (slowest)
and 10 (fastest).
Brightness: Select between 0% to 100%.
EFFECTS
Lightning 1: Simulates lighting with a cycle
of four short and long bursts.
Lightning 2: Simulates lightning with a cycle
of seven long and short bursts.
instructions

Bright Beast 1×1 Bi-Color Panel - USER MANUAL
12
The Bright Beast supports DMX-512 so the
light’s settings can be remotely controlled by
a DMX lighting control console.
To set up DMX operation on the Bright
Beast, follow these steps:
1. Use a 5-pin XLR cable to connect a DMX
controller to the Bright Beast’s DMX input
jack.
2. Use the Bright Beast’s DMX output jack
to connect multiple lights or to insert a
DMX terminator.
3. Set a DMX address by selecting Effects
or Bluetooth Reset mode. Press the
Color/Set Dial until the DMX channel is
highlighted, and turn the dial to set the
DMX address.
Important!
You will need two consecutive DMX
addresses for each light, one to adjust the
light intensity, and another to adjust the
color temperature.
Make sure the DMX address of the Bright
Beast matches the DMX console.
USING DMX
instructions
BT-RESET
?
ID 66DE
CH 24°S001

Bright Beast 1×1 Bi-Color Panel - USER MANUAL 13
BLUETOOTH
OPERATION
If the app is unable to find the Bright Beast,
press the Mode Selector dial until the
Bluetooth Refresh page appears on the LCD
screen.
Press the Color/Set Dial to highlight the
“?” icon, and turn the dial so “OK” appears
onscreen. This resets the Bright Beast’s
built-in Bluetooth, and you will be able to
proceed.
The Bright Beast app is available for iOS
and Android devices. Go to the App Store or
Google Play Store to download the free app,
and install it on your device.
PAIRING THE BRIGHT BEAST WITH
YOUR DEVICE
Open the Bright Beast app, and touch the
Add Device icon.
Your light’s icon will appear in a few
seconds. Press the + icon to the right of the
device to pair it with your device.
instructions
BT-RESET
ID 66DE
CH 001 24°S
OK

Bright Beast 1×1 Bi-Color Panel - USER MANUAL
14
Once the light has been added, touch its icon
to select a new icon and create a custom
name for the light.
Scroll through the icons, and tap to select.
Type a name for the light in the text field.
Press OK to complete pairing the light with
your device.
The paired device screen will appear.
The green flag indicates the light is paired
with your device.
If a red flag appears, the Bright Beast is
powered off or your device is out of range.
Connect the power source to the light, turn it
on, and make sure your device is nearby. In a
few seconds, the green flag will reappear.
Touch the illuminated power icon to pause
the light’s operation. Touch it again to
illuminate the power icon and resume
operation.
instructions

Bright Beast 1×1 Bi-Color Panel - USER MANUAL 15
CCT MODE
Touch your device on the Bluetooth pairing
screen to bring up the CCT mode screen.
Use the preset buttons to select a color
temperature.
DELETING A DEVICE
To delete the device, press and hold the
name of the device and choose, "Delete
device" from the pull down menu.
instructions

Bright Beast 1×1 Bi-Color Panel - USER MANUAL
16
· To set the brightness, touch the +
or – icons on the brightness slider, or
touch the dot and slide it to the desired
brightness.
· To set a custom color temperature, touch
the + or – icons on the color temperature
slider, or touch the dot and slide it to the
desired color temperature.
EFFECTS MODE
Switch to the Effects mode screen from the
CCT screen by touching Scene at the bottom
of the screen.
· Select one of the nine lighting effects.
· Increase or decrease the speed of the
effect by pressing the + or – icons on the
speed slider, or touch one of the preset
speeds.
· To adjust the brightness, touch the +
or – icons on the brightness slider, or
touch the dot and slide it to the desired
brightness.
instructions

Bright Beast 1×1 Bi-Color Panel - USER MANUAL 17
USING OPTIONAL
ACCESSORIES
MOUNTING THE BARNDOORS
Align the barndoors with the flat edge on the
bottom and the notched edge on top.
1. Place the bottom edge into the barndoor
brackets.
2. Lift the barndoor lock, press the
barndoors so they’re flush against the
front panel, and release the barndoor
lock to secure it.
MOUNTING THE DIFFUSER
Mount the diffuser onto the panel by aligning
the registration pins on the light with the
holes at the top corners of the diffuser. Once
aligned, the diffuser magnetically attaches
to the Bright Beast’s front panel.
instructions

Bright Beast 1×1 Bi-Color Panel - USER MANUAL
18
PRODUCT
SPECIFICATIONS
LED Type: SMD
LED Count: 256 (Amber: 128, White: 128)
Brightness @ 3 ft.: 3200 K: 18,700 lx
5600 K: 19,800 lx
Beam Angle: 45°
CRI: 3200 K: 97
5600 K: 96
TLCI: 3200 K: 98
5600 K: 97
Output Power: 100 W
Working Voltage: AC: 100–240 V
DC: 18 V @ 5.6 A
Mount: 5/8 in., baby pin convertible to 1 1⁄8in.
junior pin
Dimensions:
Light only:
11.75 × 11.75 × 3.25 in. (29.8 × 29.8 × 8.2 cm)
With yoke:
15.25 × 17 × 4 in. (38.7 × 43.2 × 10.2 cm)
Weight: 9 lb. (4.1 kg) with yoke, without battery
sPecifications

ONE-YEAR LIMITED WARRANTY
This Genaray product is warranted to the original purchaser to be free from defects in materials and
workmanship under normal consumer use for a period of one (1) year from the original purchase date
or thirty (30) days after replacement, whichever occurs later. Genaray’s responsibility with respect
to this limited warranty shall be limited solely to repair or replacement, at Genaray’s discretion, of
any product that fails during normal use of this product in its intended manner and in its intended
environment. Inoperability of the product or part(s) shall be determined by Genaray. If the product
has been discontinued, Genaray reserves the right to replace it with a model of equivalent quality and
function.
This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse,
improper installation or maintenance. EXCEPT AS PROVIDED HEREIN, GENARAY MAKES NEITHER
ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This
warranty provides you with specific legal rights, and you may also have additional rights that vary from
state to state.
To obtain warranty coverage, contact the Genaray Customer Service Department to obtain a return
merchandise authorization (“RMA”) number, and return the defective product to Genaray along with the
RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk
and expense.
For more information, or to arrange service, visit www.genaray.com or contact us at [e-mail].
© 2022 Genaray. All Rights Reserved.

GG1
