Genie GS-1530 User manual

Maintenance Manual -
Scissor Lifts
Slab Scissor Lifts
This manual includes detailed
procedures for each
maintenance
inspection.
Rough Terrain
Scissor Lifts
For Repair procedures, Fault
Codes, Electrical and Hydraulic
Schematics, refer to the
appropriate Service and Repair
Manual for your machine.
Refer
to the inside cover for a list of models
included in this manual.
Part No. 1272215
Rev B2
September 2016

Maintenance Manual September 2016
Introduction
ii Scissor Lifts Part No. 1272215
Intr oduct io n Intr oduct io n
Impor tant Inf ormati on
Important
Read, understand and obey the safety rules and
operating instructions in the appropriate Operator's
Manual on your machine before attempting any
maintenance procedure.
This manual provides detailed scheduled
maintenance information for the machine owner
and user.
Basic mechanical, hydraulic and electrical skills are
required to perform most procedures. However,
several procedures require specialized skills, tools,
lifting equipment and a suitable workshop. In these
instances, we strongly recommend that
maintenance be performed at an authorized Genie
dealer service center.
Compliance
Machine Classification
Group A/Type 2, 3 as defined by ISO 16368
Machine Design Life
Unrestricted with proper operation, inspection and
scheduled maintenance.
Technical Publications
Genie has endeavored to deliver the highest
degree of accuracy possible. However, continuous
improvement of our products is a Genie policy.
Therefore, product specifications are subject to
change without notice.
Readers are encouraged to notify Genie of errors
and send in suggestions for improvement. All
communications will be carefully considered for
future printings of this and all other manuals.
Contact Us:
Internet: www.genielift.com
E-mail: [e-mail]
Copyright © 2016 by Terex Corporation
1272215 Rev B, May 2016
First Edition, Second Printing
Genie is a registered trademark of Terex South Dakota, Inc. in
the U.S.A. and many other countries.
“GS” is a trademark of Terex South Dakota, Inc.

September 2016 Maintenance Manual
Introduction
Part No. 1272215 Scissor Lifts iii
Models included in this manual
Use the following chart to identify the specific serial
number for models included in this manual.
Models
Serial number
GS
-1530 / GS-1532
GS
-1930 / GS-1932
from SN
GS3010A-110000
from SN GS3011C
-10000 to
GS3016C
-23999
from SN GS3014D
-101 to
GS3016D
-607
from SN GS3016P
-151487 to
GS3016P
-160599
from GS30C
-24000
from GS30D
-6080
from GS30P
-160600
GS
-2032/2632/3232
from SN GS3211A
-110000
from SN GS3212C
-10000 to
GS3216C
-17299
from SN GS3216P
-142676 to
GS3216P
-148699
from GS32C
-17300
from GS32P
-148700
GS
-2046/2646/3246
from SN GS4612A
-110000
from SN GS4612C
-10000 to
GS4616C
-18099
from SN GS4614D
-101 to
GS4616D
-5029
from SN GS4616P
-138362 to
GS4616P
-141799
from GS4
6C-18100
from GS46D
-5030
from GS46P
-141800
GS
-2646 AV/2646 AV35
from SN GS4612A
-110000
from SN GS4616P
-138383 to
GS4616P
-141799
GS
-4047
from SN GS4712C
-101 to
GS4716C
-4499
from SN GS4714D
-101 to
GS4716D
-3959
from GS4716P
-101 to
GS4716P
-999
from
GS47C-4500
from GS47D
-3960
from GS47P
-1000
GS
-2669/3369/4069 RT
from SN GS6911
-101
from SN GS6916F
-7897 to
GS69F
-10499
from GS69F
-10500
GS
-2669/3369/4069 DC
from SN GS6912
-1300
from SN GS6916F
-7897 to
GS6916F
-10499
from GS69F
-10500
GS
-2669/3369/4069 BE
from SN GS6914
-5000
from SN GS6916F
-7897 to
GS6916F
-10499
from GS69F
-10500
GS
-3384
from SN GS8413
-42181 to
GS8415
-42382
from SN GS8416F
-42383 to
GS8416F
-45499
from GS84F
-45500
GS
-3390/4390/5390
from SN GS9013
-48427 to
GS9015
-51064
from SN GS9016F
-51064 to
GS9016F
-53299
from GS90F
-53300
Find additional Manuals for your
Model
Go to http://www.genielift.com
Use the links to locate Service Manuals,
Maintenance Manuals, Service and Repair
Manuals, Parts Manuals and Operator's Manuals.

Maintenance Manual September 2016
Introduction
iv Scissor Lifts Part No. 1272215
Identifying the Correct Procedure
for your Model
Unless otherwise noted, each procedure will apply
to all models. Procedures that only apply to specific
models or options will include the information in the
procedure title.
Examples of procedures that apply to specific
models:
•Test the Oscillate Axle - GS-90
•Grease the Steer Yokes - GS-30, GS-32,
GS-46 and GS-47
•Model Abbreviations:
GS-30: GS-1530, GS-1532, GS-1930,
GS-1932
GS-32: GS-2032, GS-2632, GS-3232
GS-46: GS-2046, GS-2646, GS-2646 AV,
2646 AV35, GS-3246
GS-47: GS-4047
GS-69: Unless specified DC, BE or RT
GS-2669 (all models), GS-3369 (all models),
GS-4069 (all models)
GS-84: GS-3384
GS-90: GS-3390, GS-4390, GS-5390
Examples of procedures that apply to all models:
•Test the Drive Speed – Stowed Position
•Inspect the Electrical Wiring
Glossary of terms:
ECM – Electronic Control Module
(GS-69 RT, GS-84, and GS-90)
GCON – Ground Controller. Located at the chassis
ground controls. (GS-30, GS-32, GS-46, GS-47,
GS-69 DC, and GS-69 BE)
PCON – Platform Controller. Located at the
platform. (GS-30, GS-32, GS-46, GS-47, GS-69
DC, and GS-69 BE)
CAT5 Cable – Standard Ethernet cable used for
networking purposes.

September 2016 Maintenance Manual
Introduction
Part No. 1272215 Scissor Lifts v
RevisionHistory
Revision History
Revision
Date
Section
Procedure / Description
A 3/2016 Initial Release
B 5/2016 Specifications Add GM .998L engine
Maintenance Add GM Maintenance intervals
Programmed Maint. Report
Update C-2 and P2-1, Add P0-8
B1 7/2016 Maintenance A-8
B2 9/2016 Introduction Models Included
Reference Examples:
Section – Specifications Electronic Version
Click on any content or procedure in the Table of Contents to view
the update.
Section – Maintenance, (procedure)

Maintenance Manual September 2016
Introduction
vi Scissor Lifts Part No. 1272215
Revision History (continued)
Revision Date Section Procedure / Description
Reference Examples:
Section – Specifications Electronic Version
Click on any content or procedure in the Table of Contents to view
the update.
Section – Maintenance, (procedure)

September 2016 Maintenance Manual
Safety Rules
Part No. 1272215 Scissor Lifts vii
Section 1 Safet y Rul es G eneral Saf ety Rules
Danger
Failure to obey the instructions and safety rules in
this manual and the appropriate Operator's Manual
on your machine will result in death or serious
injury.
Many of the hazards identified in the operator's
manual are also safety hazards when maintenance
and repair procedures are performed.
Do Not Perform Maintenance
Unless:
You are trained and qualified to perform
maintenance on this machine.
You read, understand and obey:
•manufacturer's instructions and safety rules
•employer's safety rules and worksite
regulations
•applicable governmental regulations
You have the appropriate tools, lifting
equipment and a suitable workshop.

Maintenance Manual September 2016
Safety Rules
viii Scissor Lifts Part No. 1272215
Personal Safety
Any person working on or around a machine must
be aware of all known safety hazards. Personal
safety and the continued safe operation of the
machine should be your top priority.
Read each
procedure thoroughly. This
manual and the decals on the machine,
use signal words to identify the following:
Safety alert symbol
—
used to alert
personnel to potential personal
injury hazards. Obey all safety
messages that follow this symbol
to avoid poss
ible injury or death.
Indicates a imminently hazardous
situation which, if not avoided, will
result in death or serious injury.
Indicates a potentially hazardous
situation which, if not avoided,
could result in death or serious
injury.
Indicates a
potentially hazardous
situation which, if not avoided,
may cause minor or moderate
injury.
Indicates a potentially hazardous
situation which, if not avoided,
may result in property damage.
Be sure to wear protective eye wear and
other protective
clothing if the situation
warrants it.
Be aware of potential crushing hazards
such as moving parts, free swinging or
unsecured components when lifting or
placing loads. Always wear approved
steel
-toed shoes.
Workplace Safety
Any person working on or around a machine must
be aware of all known safety hazards. Personal
safety and the continued safe operation of the
machine should be your top priority.
Be sure to keep sparks, flames and
lighted tobacco away from flammable and
combustible materials like
battery gases
and engine fuels. Always have an
approved fire extinguisher within easy
reach.
Be sure that all tools and working areas
are properly maintained and ready for
use. Keep work surfaces clean and free of
debris that could get into machine
com
ponents and cause damage.
Be sure any forklift, overhead crane or
other lifting or supporting device is fully
capable of supporting and stabilizing the
weight to be lifted. Use only chains or
straps that are in good condition and of
ample capacity.
B
e sure that fasteners intended for one
time use (i.e., cotter pins and self
-locking
nuts) are not reused. These components
may fail if they are used a second time.
Be sure to properly dispose of old oil or
other fluids. Use an approved container.
Please
be environmentally safe.
Be sure that your workshop or work area
is properly ventilated and well lit.

September 2016
Table of Contents
Part No. 1272215 Scissor Lifts ix
Introduction Introduction...........................................................................................................ii
Important Information .............................................................................................ii
Models included in this manual............................................................................. iii
Find additional Manuals for your Model ................................................................ iii
Identifying the Correct Procedure for your Model .................................................iv
Glossary of terms: ................................................................................................. iv
Revision History......................................................................................................v
Section 1 Safety Rules........................................................................................................vii
General Safety Rules ........................................................................................... vii
Section 2 Performance Specifications................................................................................1
Function Speeds GS-30, GS-32, GS-46, GS-47....................................................1
Function Speeds GS-69, GS-84, GS-90................................................................2
Drive Speeds..........................................................................................................3
Torque Specifications..........................................................................................4
Tires and Wheels....................................................................................................4
Battery Specifications..........................................................................................5
Battery Specifications - DC and BE Models...........................................................5
Engine Specifications..........................................................................................6
Engine Operator and Maintenance Manuals..........................................................6
Deutz Engine Models .............................................................................................6
Perkins Engine Models...........................................................................................7
Ford Engine Models ...............................................................................................7
Kubota Engine Models ...........................................................................................8
Kohler Engine Models ............................................................................................8
GM Engine Models.................................................................................................9
Hydraulic Specifications....................................................................................10
Hydraulic Relief Valves ........................................................................................10
Hydraulic and Drive Hub Fluid Capacities............................................................12
Hydraulic Oil Specifications..................................................................................13
Hydraulic Hose and Fitting Torque Specifications ...............................................16
Torque Procedure ................................................................................................17

September 2016
Table of Contents
x Scissor Lifts Part No. 1272215
Section 3 Maintenance Procedures ..................................................................................20
Introduction ..........................................................................................................20
Maintenance Schedule ........................................................................................22
Pre-Delivery Preparation Report..........................................................................23
Scheduled Maintenance Inspection Report - Scissor Lifts..................................24
Programmed Maintenance Inspection Report - Scissor Lifts ..............................25
Commissioning Procedures.............................................................................26
C-1 Perform 50 Hour Service...............................................................................26
C-2 Perform Engine Maintenance – 50 Hours.....................................................26
C-3 Perform 150 Hour Service.............................................................................27
Quarterly Maintenance Procedures .................................................................28
Q-1 Check for Open Bulletins and Owner Registration.......................................28
Q-2 Battery Inspection .........................................................................................29
Q-3 Check the Module Tray Latch Components .................................................31
Q-4 Inspect the Battery Balancer - GS-69 DC.....................................................32
Q-5 Inspect the Electrical Wiring..........................................................................33
Q-6 Inspect the Electrical Contactor - GS-30, GS-32, GS-46, GS-47,
GS-69 DC and GS-69 BE ............................................................................34
Q-7 Inspect the Voltage Inverter (if equipped).....................................................34
Q-8 Test the Flashing Beacons (if equipped) ......................................................35
Q-9 Visual Inspection of the Hydraulic Oil ...........................................................36
Q-10 Inspect the Hydraulic Filters........................................................................37
Q-11 Check the Exhaust System - Engine Models..............................................38
Q-12 Inspect the Fuel Tank Check Valve Venting System -
GS-69 RT Gas Models.................................................................................38
Q-13 Test the Fuel Select Operation - Gasoline/LPG Models.............................39
Q-14 Check and Adjust the Engine RPM ............................................................40
Q-15 Inspect the Tires, Wheels and Lug Nut Torque..........................................42
Q-16 Confirm the Proper Brake Configuration - GS-69, GS-84, GS-90..............43
Q-17 Test the Drive Brakes .................................................................................43
Q-18 Test the Drive Speed – Stowed Position ....................................................44
Q-19 Test the Drive Speed - Raised Position......................................................44

September 2016
Table of Contents
Part No. 1272215 Scissor Lifts xi
Q-20 Test the Down Limit Switch, Level Sensor and Pothole Limit Switches -
GS-30, GS-32, GS-46 and GS-47................................................................45
Q-21 Test the Platform Gate Proximity Switches and the Extension Deck Limit
Switch - GS-2646 AV, GS-2646 AV35 .........................................................49
Annual Maintenance Procedures......................................................................51
A-1 Check the Drive Hub Oil Level and Fastener Torque....................................51
A-2 Test the Function Pump - GS-69 BE and GS-69 DC ....................................51
A-3 Test the Oscillate Axle - GS-90 .....................................................................52
A-4 Test the Down Limit Switch Descent Delay - GS-69, GS-84 and GS-90 (if
equipped)......................................................................................................55
A-5 Test the Platform Overload Pressure Transducer and Platform
Height Sensor - GS-30, GS-32, GS-46 and GS-47 (if equipped).................57
A-6 Test the Platform Overload System - GS-30, GS-32, GS-46 and GS-47
(if equipped)..................................................................................................60
A-7 Test the Platform Overload System - GS-69 (if equipped)............................62
A-8 Test the Platform Overload System - GS-84 and GS-90 (if equipped) .........64
Programmed Maintenance Procedures ...........................................................66
P0-1 Inspect the Engine Air Filter - GS-69 RT.....................................................66
P0-2 Grease the Steer Yokes - GS-30, GS-32, GS-46 and GS-47.....................67
P0-3 Deutz Engine Maintenance – Under 1000 Hours........................................68
P0-4 Ford Engine Maintenance – Under 1000 Hours..........................................69
P0-5 Kohler Engine Maintenance – Under 1000 Hours.......................................70
P0-6 Kubota Engine Maintenance – Under 1000 Hours......................................71
P0-7 Perkins Engine Maintenance – Under 1000 Hours .....................................72
P0-8 GM Engine Maintenance – Under 1000 Hours............................................73
P1-1 Perform Engine Maintenance – 1000 Hours ...............................................74
P1-2 Replace the Drive Hub Oil - GS-69, GS-84 and GS-90 ..............................75
P2-1 Perform Engine Maintenance – 2000 Hours ...............................................75
P2-2 Replace the Hydraulic Filters.......................................................................76
P2-3 Check the Free-wheel Configuration - GS-84 and GS-90...........................77
P2-4 Check the Scissor Arm Wear Pads (and Slider Blocks, if equipped)..........79
P2-5 Grease the Steer Axle Wheel Bearings - GS-69 BE and GS-69 DC...........82
P2-6 Test or Replace the Hydraulic Oil................................................................83
P3-1 Perform Engine Maintenance – 3000 Hours ...............................................84

September 2016 Maintenance Manual
Performance Specifications
Part No. 1272215 Scissor Lifts 1
Section 2 Perf ormanc e Speci ficati ons
FunctionSpeedsGS-30,GS-32, GS-46, G S-47
Function Speeds
(models without proportional lift)
Function speed, maximum from platform controls
(with maximum rated load in platform)
GS
-1530, GS-1532, GS-1930 and GS-1932
Platform up (fast mode)
Platform up (slow mode)
Platform down
15 to 17 s
econds
30 to 32 s
econds
28 to 30 s
econds
GS
-2032 and GS-2632
Platform up (fast mode)
Platform up (slow mode)
Platform down
28 to 32 s
econds
58 to 62 s
econds
32 to 36 s
econds
GS-2046 and GS-2646
Platform up (fast mode)
Platform up (slow mode)
Platform down
28 to 32 s
econds
58 to 62 s
econds
32 to 36 s
econds
GS
-2646 AV and GS-2646 AV35
Platform up (fast mode)
Platform up (slow mode)
Platform down
Platform Ext. Deck
- Extend
Platform Ext. Deck
- Retract
28 to 32 s
econds
58 to 62 s
econds
32 to 36 s
econds
28 to 32 s
econds
31 to 35 s
econds
GS-3232 and GS-3246
Platform up (fast mode)
Platform up (slow mode)
Platform down
55 to 59 s
econds
108 to 112 s
econds
33 to 37 s
econds
GS
-4047
Platform up (fast mode)
Platform up (slow mode)
Platform down
71 to 76 s
econds
83 to 87 s
econds
41 to 46 s
econds
GS
-2669DC
Platform up (fast mode)
Platform up (slow mode)
Platform down
71 to 76 s
econds
83 to 87 s
econds
41 to 46 s
econds
Function Speeds
(models with proportional lift)
Function speed, maximum from platform controls
(with
1 person in platform)
GS
-1530, GS-1532, GS-1930 and GS-1932
Platform up
Platform down 15 to 17 s
econds
18 to 25 s
econds
GS-2032 and GS-2632
Platform up
Platform down 28 to 32 s
econds
24 to 28 s
econds
GS
-2046 and GS-2646
Platform up
Platform down 28 to 32 s
econds
28 to 32 s
econds
GS
-2646 AV and GS-2646 AV35
Platform up
Platform down
Platform Ext. Deck
- Extend
Platform Ext. Deck
- Retract
28 to 32 s
econds
28 to 32 s
econds
28 to 32 s
econds
31 to 35 s
econds
GS
-3232 and GS-3246
Platform up
Platform down 55 to 59 s
econds
28 to 32 s
econds
GS
-4047
Platform up
Platform down 71 to 76 s
econds
41 to 46 s
econds
GS
-2669DC
Platform up (fast mode)
Platform down 71 to 76 s
econds
41 to 46 s
econds

Maintenance Manual September 2016
Performance Specifications
2 Scissor Lifts Part No. 1272215
FunctionSpeedsGS-69,GS-84, GS-90
Function Speeds
Function speed,
maximum from platform controls
(with maximum rated load in platform)
GS
-2669 DC, GS-2669 BE, GS-2669 RT
Platform up
Platform down
29 to 39 s
econds
26 to 36 s
econds
GS
-3369 DC, GS-3369 BE, GS-3369 RT
Platform up
Platform down
34 to 44 s
econds
24 to 34 s
econds
GS
-4069 DC, GS-4069 BE, GS-4069 RT
Platform up
Platform down
56 to 66 s
econds
23 to 33 s
econds
GS
-3384, GS-3390
Platform up
Platform down
40 to 50 s
econds
24 to 34 s
econds
GS
-4390
Platform up
Platform down
40 to 50 s
econds
34 to 44 s
econds
GS
-5390
Platform up
Platform down
50 to 60 s
econds
44 to 54 s
econds

September 2016 Maintenance Manual
Performance Specifications
Part No. 1272215 Scissor Lifts 3
Dri ve Sp eeds
Drive Speeds
Model Stowed position Elevated
position
Braking distance,
maximum
High range on
paved surface
Gradeability
GS
-1530, GS-1532 10.9 seconds
40 ft / 12.2 m 55 seconds 40 ft /
12.2 m
1 - 3 ft
0.3 - 0.9 m
30%
GS
-1930, GS-1932 10.9 seconds
40 ft / 12.2 m 55 seconds 40 ft /
12.2 m
1 - 3 ft
0.3 - 0.9 m
25%
GS-2032, GS-2046,
GS
-2646 12.4 seconds
40 ft / 12.2 m 55 seconds 40 ft /
12.2 m
1 - 3 ft
0.3 - 0.9 m
30%
GS
-2632, GS-3232,
GS
-3246 12.4 seconds
40 ft / 12.2 m 55 seconds 40 ft /
12.2 m
1 - 3 ft
0.3 - 0.9 m
25%
GS
-2646 AV 12.4 seconds
40 ft / 12.2 m 55 seconds 40 ft /
12.2 m
1 - 3 ft
0.3 - 0.9 m
25%
20% (35mph Wind Rating)
GS
-4047 13.6 seconds
40 ft / 12.2 m 55 s
econds
40 ft /
12.2 m
1 - 3 ft
0.3 - 0.9 m
25%
GS
-2669 RT High speed 7.8 seconds
40 ft / 12.2 m
High torque 30 seconds
40 ft / 12.2 m
91 seconds
40 ft /
12.2 m
2 ft
0.6 m
40%
35% (with outriggers)
GS-3369 RT
GS
-4069 RT High speed 7.8 seconds
40 ft / 12.2 m
High torque 30 seconds
40 ft / 12.2 m
91 seconds
40 ft /
12.2 m
2 ft
0.6 m
35%
30% (with
outriggers)
GS
-2669
GS
-3369
GS
-4069
(DC and BE
models)
Forward - 6.1 seconds
Reverse - 9.1 seconds
40 ft / 12.2 m
91 seconds
40 ft /
12.2 m
3 ft
0.9 m
35% (ext deck uphill)
15% (ext deck downhill)
GS
-3384 6.8 seconds
40 ft / 12.2 m 39 seconds 40 ft /
12.2 m
5 ft
1.5 m
50%
GS
-3390
GS
-4390 5.5 seconds
40 ft / 12.2 m 39 seconds
40 ft /
12.2 m
5 ft
1.5 m
50%
GS
-5390 5.5 s
econds
40 ft / 12.2 m 39 seconds 40 ft /
12.2 m
5 ft
1.5 m
40%

Maintenance Manual September 2016
Torque Specifications
4 Scissor Lifts Part No. 1272215
Torque Specifications
Tires an d W heel s
Tires and Wheels
Torque values are listed as lubricated unless
otherwise noted. Lug nuts must be coated with a
mineral based lubricant when removed and
replaced on the machine.
Model
GS-1530, GS-1532, GS-
1930,
GS-1932, GS-2032, GS-
2632,
GS-3232, GS-2046, GS-
2646,
GS-3246, GS-4047, GS-
2646AV
Castle nut torque
225 ft-
lbs
305 Nm
Model
GS-2669 RT, GS-
3369 RT,
GS-
4069 RT
Castle
nut torque
(steer end)
225 ft-
lbs
305 Nm
Lug nut torque
(steer end)
68 ft-
lbs
92 Nm
Lug nut torque
(non
-steer end) 130 ft-
lbs
176 Nm
Model
GS-2669, GS-3369, GS-
4069
(DC and BE models)
Castle nut torque
(steer end)
35 ft-
lbs
47.5 Nm
Lug nut torque
(steer end)
68 ft-
lbs
92 Nm
Lug nut torque
(non
-steer end) 130 ft-
lbs
176 Nm
Model
GS-3384, GS-3390, GS-
4390,
GS-
5390
Lug nut torque
94 ft-
lbs
127 Nm
Tire pressure
high flotation
38 p
si
2.6 b
ar

September 2016 Maintenance Manual
Battery Specifications
Part No. 1272215 Scissor Lifts 5
Batt ery Spe cific ation s
Batter y Sp ecifi cati ons - DC an dB EM odels
GS-1530, GS-1532, GS-1930, GS-1932,
GS
-2032, GS-2632, GS-3232, GS-
2046,
GS
-2646, GS-3246, GS-2646 AV
(standard)
Voltage 6V DC
Group GC2
Type T-105
Quantity 4
Battery capacity, maximum 225 AH
Reserve capacity @ 25A rate 447 minutes
GS
-1530, GS-1532, GS-1930, GS-1932
GS
-2032, GS-2632, GS-3232, GS-
2046,
GS
-2646, GS-3246, GS-2646 AV
(optional)
Voltage 6V DC
Group GC2
Type 6V-AGM
Quantity 4
Battery capacity, maximum 200 AH
Reserve capacity @ 25A rate 380 m
inutes
Note: When upgrading from standard to AGM
batteries the machine software must be configured
for AGM batteries. Refer to Repair Procedure,
Machine Setup in the Service and Repair Manual.
GS-4047
(standard)
Voltage 12V DC
Group GC2
Type T-1275
Quantity 4
Battery capacity, maximum 150 AH
Reserve capacity @ 25A rate 280 minutes
GS
-2669, GS-3369, GS-4069
(DC and BE models)
(standard)
Voltage 6V DC
Group GC2
Type T-105
Quantity 8
Battery capacity, maximum 225 AH
Reserve capacity @ 25A rate 447 minutes
GS
-2669, GS-3369, GS-4069
(DC models)
(optional)
Voltage 6V DC
Group 902
Type J305GH
Quantity 8
Battery capacity, maximum 315 AH
Reserve capacity @ 25A rate 678 minutes
GS
-2669, GS-3369, GS-4069
(BE models)
(optional)
Voltage 6V DC
Group GC2
Type T145
Quantity 8
Battery capacity, maximum 260 AH
Reserve capacity @ 25A rate 530 minutes

Maintenance Manual September 2016
Engine Specifications
6 Scissor Lifts Part No. 1272215
Engine Specifications
Engin e Opera tor and M aint enance M anual s
Engine Operator and Maintenance
Manuals
Deutz D2011L03i
Genie part number
139320
Deutz D 2.9 L4
Genie part number
1251561
Perkins
403D-11
Genie part number
131661
Ford MSG
-425
Genie part number
215322
Diagnostic Manual
Genie part number
162067
Kubota D1105
-E3B
Genie part number
229761
Kubota WG
-972
Genie part number
227584
Kohler KD350
Genie part number
1255885
GM
.998L
Genie part number
Not available until May 2016
Deutz En gin e M odel s
Deutz Engine Models
D2011 L03i
Low idle
1500 r
pm
313 Hz
High idle
2500 r
pm
522 Hz
Oil capacity (including filter)
9.5 quarts
9 liters
Fan belt deflection
3/8 to 1/2 inch
9 to 12 m
m
D 2.9 L4
Low idle
1500 r
pm
1500 Hz
High idle
2500 r
pm
2500 Hz
Oil capacity (including filter)
9.4 quarts
9 liters
Engine coolant
Ethylene Glycol
Engine coolant capacity
10 quarts
9.4 liters
Fan belt deflection
3/8 to 1/2 inch
9 to 12 m
m
Unit ships with 15W-40. Extreme operating
temperatures may require the use of alternative
engine oils. For oil requirements, refer to the
Engine Operator Manual for your engine.

September 2016 Maintenance Manual
Engine Specifications
Part No. 1272215 Scissor Lifts 7
Perki ns Engi ne M o dels
Perkins Engine Models
403D
-11
Low idle
1500 r
pm
150
Hz
High idle
3000 r
pm
300 Hz
Oil capacity (including filter)
4.6 q
uarts
4.4 l
iters
Engine coolant capacity
2.0 q
uarts
1.9 l
iters
Fan belt deflection
3/16 i
nch
5 m
m
Unit ships with 15W-40. Extreme operating
temperatures may require the use of alternative
engine oils. For oil requirements, refer to the
Engine Operator Manual for your engine.
Ford E ngine Mo dels
Ford Engine Models
MSG
-425
Low idle
1600 r
pm
53.3 Hz
High idle
2500 r
pm
83.3 Hz
Oil capacity (including filter)
6.7 q
uarts
6.4 l
iters
Engine coolant capacity
10 q
uarts
9.5 l
iters
Spark plug gap
0.049 to 0.053 i
nches
1.25 to 1.35 m
m
Fan belt deflection
3/8 to 1/2 i
nch
9 to 12 m
m
Unit ships with 15W-40. Extreme operating
temperatures may require the use of alternative
engine oils. For oil requirements, refer to the
Engine Operator Manual for your engine.

Maintenance Manual September 2016
Engine Specifications
8 Scissor Lifts Part No. 1272215
KubotaEngineM odels
Kubota Engine Models
D1105
-E3B, D1105-E4B
Low idle
1500 r
pm
250 Hz
High idle
3000 r
pm
500 Hz
Oil capacity (including filter)
5.4 q
uarts
5.1 l
iters
Engine coolant capacity
3.3 q
uarts
3.1 l
iters
Fan belt deflection
5/16 i
nch
8 m
m
WG
-972
Low idle
1500 r
pm
250 Hz
High idle
3000 r
pm
500 Hz
Oil capacity (including filter)
3.6 q
uarts
3.4 l
iters
Engine coolant capacity
2.4 q
uarts
2.3 l
iters
Spark
plug gap 0.024 to 0.028 i
nches
0.6 to 0.7 m
m
Fan belt deflection
0.28 to 0.35 i
nch
7 to 9 m
m
Unit ships with 15W-40. Extreme operating
temperatures may require the use of alternative
engine oils. For oil requirements, refer to the
Engine Operator Manual for your engine.
Kohler E ngine Mo dels
Kohler Engine Models
KD350
High idle
3600/3000 r
pm
Oil capacity (including filter)
1.3 quarts
1.2 liters
Unit ships with 15W-40. Extreme operating
temperatures may require the use of alternative
engine oils. For oil requirements, refer to the
Engine Operator Manual for your engine.

September 2016 Maintenance Manual
Engine Specifications
Part No. 1272215 Scissor Lifts 9
GM E ngi ne M od els
GM Engine Models
.998L
Low idle
1100 r
pm
36.6 Hz
High idle
3000 r
pm
100 Hz
Oil capacity (including filter)
3.2 q
uarts
3.0 l
iters
Engine coolant capacity
5 q
uarts
4.7 l
iters
Spark plug gap
0.039 to 0.047 i
nches
1.0 to 1.2 m
m
Unit ships with 15W-40. Extreme operating
temperatures may require the use of alternative
engine oils. For oil requirements, refer to the
Engine Operator Manual for your engine.
