Genie Superlift SL-5 Quick start guide

Parts & Service Manual Part No. 32283
Rev A1
June 2005

Parts and Service Manual - First Edition
Part No. 32283 Genie Superlift v
Table of Contents
Introduction
ImportantInformation ......................................................................................................ii
Section One Safety Rules
GeneralSafetyRules .....................................................................................................iii
Section Two Specifications
Superlift5 ................................................................................................................................. 2 - 1
Superlift10 ................................................................................................................................. 2 - 1
Superlift15 ................................................................................................................................. 2 - 1
Superlift20 ................................................................................................................................. 2 - 1
Superlift25 ................................................................................................................................. 2 - 1
LoadHandlingAttachments ................................................................................................................... 2 - 1
BoltTorque Specification ....................................................................................................................... 2 - 3
Section Three Scheduled Maintenance Inspections
Introduction ............................................................................................................... 3 - 1
TableA ................................................................................................................................. 3 - 2
TableB ................................................................................................................................. 3 - 2
TableC ................................................................................................................................. 3 - 2
MaintenanceInspectionReport .............................................................................................................. 3 - 3
Section Four Scheduled Maintenance Procedures
Introduction ............................................................................................................... 4 - 1
A-1 InspecttheOperator'sManual................................................................................... 4 - 2
A-2 Inspect the Decals and Placards............................................................................... 4 - 2
A-3 Inspect for Damage, Loose or Missing Parts............................................................. 4 - 2
A-4 ChecktheWinchOperation....................................................................................... 4 - 3
A-5 InspecttheColumnsforDamage .............................................................................. 4 - 3
A-6 Inspect the Cable and Cable Pulleys......................................................................... 4 - 3
A-7 Check theMast forProper Sequencing ..................................................................... 4 - 4
A-8 Inspect the Casters and Wheels ............................................................................... 4 - 4
B-1 Inspect the Column Hold Down System .................................................................... 4 - 5

Parts and Service Manual - First Edition
Genie Superlift Part No. 32283
Section Four Scheduled Maintenance Procedures, cont.
B-2 Inspect All Welds ...................................................................................................... 4 - 5
B-3 CleantheColumns.................................................................................................... 4 - 5
B-4 Inspect and Lubricate the Winch ............................................................................... 4 - 6
B-5 InspectandLubricatetheRotatingBarrelHandler..................................................... 4 - 6
C-1 LubricatetheCastersandWheels............................................................................. 4 - 7
C-2 Inspect the Mast Assembly for Wear ........................................................................ 4 - 7
C-3 Replace the Winch Friction Disks.............................................................................. 4 - 8
C-4 Inspect the Safety Brake System ............................................................................. 4 - 8
C-5 Inspect the Painted Surfaces .................................................................................... 4 - 9
Section Five TroubleshootingFlowCharts
Introduction ............................................................................................................... 5 - 1
1 MastWill Not SequenceProperly.............................................................................. 5 - 2
2 CarriageWillNot Raise, But Winch Will Operate ....................................................... 5 - 3
3 WinchWillNot Operate ............................................................................................. 5 - 4
Section Six Repair Procedures
Introduction ............................................................................................................... 6 - 1
BaseAssembly
1-1 How To Remove the Base - Standard Base .............................................................. 6 - 2
1-2 How To Remove the Base - Straddle Base ............................................................... 6 - 3
MastAssembly
2-1 How to Disassemble the Mast Assembly .................................................................. 6 - 4
2-2 Howto Replace the Lifting Cable............................................................................... 6 - 5
2-3 How to Replace a Lifting Pulley - Mast Installed........................................................ 6 - 6
Winches
3-1 How To Disassemble the Winch - Single Speed ........................................................ 6 - 7
3-2 How To Disassemble the Winch - Two Speed ........................................................... 6 - 9
vi
TABLE OF CONTENTS

Parts and Service Manual - First Edition
Part No. 32283 Genie Superlift
Section Seven Service Parts
HowToOrderParts .................................................................................................. 7 - 1
Figure7-A Decals and Paint....................................................................................................... 7 - 2
Figure7-B Number 1 Mast Attached Parts ................................................................................. 7 - 6
Figure7-C StandardBaseComponents...................................................................................... 7 - 8
Figure7-D StraddleBaseComponents..................................................................................... 7 - 12
Figure7-E Mast Components - View 1 (Rev B; June 2005) ...................................................... 7 - 14
Figure7-F Mast Components - View 2 ..................................................................................... 7 - 16
Figure7-G MastComponents - Pulleys andCable ................................................................... 7 - 18
Figure7-H LoadHandling Attachments - Forks ........................................................................ 7 - 20
Figure7-I LoadHandlingAttachments- Boom, Pipe Cradle and Load Platform ...................... 7 - 22
Figure7-J Load Handling Attachments - Vertical Barrel Stacker .............................................. 7 - 24
Figure7-K LoadHandlingAttachments-RotatingBarrelHandler ............................................. 7 - 26
Figure7-L SingleSpeedWinch ................................................................................................ 7 - 30
Figure7-M TwoSpeedWinch ................................................................................................... 7 - 32
NumericIndex ............................................................................................................................... 7 - 36
vii
TABLE OF CONTENTS

Parts and Service Manual - First Edition
Genie Superlift Part No. 32283
This page intentionally left blank.

Part No. 32283 Genie Superlift 2 - 1
Section 2 - Specifications
Part and Service Manual - First Edition
Model SL-5 SL-10 SL-15 SL-20 SL-25
Height-Stowed 781/2in 781/2in 781/2in 781/2in 781/2in
199 cm 199 cm 199 cm 199 cm 199 cm
Width 311/2in 311/2in 311/2in 311/2in 311/2in
Standard Base 80 cm 80 cm 80 cm 80 cm 80 cm
Width - stabilizers lowered 785/8in 785/8in 785/8in 785/8in 785/8in
Standard Base 185 cm 185 cm 185 cm 185 cm 185 cm
Width-Min 311/2in 311/2in 311/2in NA NA
Straddle Base 80 cm 80 cm 80 cm
Width-Max 58 in 58 in 58 in NA NA
Straddle Base 147 cm 147 cm 147 cm
Length-Stowed 29 in 29 in 29 in 29 in 31 in
74 cm 74 cm 74 cm 74 cm 79 cm
Length - Operating 571/2in 571/2in 721/2in 801/2in 801/2in
146 cm 146 cm 184 cm 204 cm 204 cm
Ground 2 in 2 in 2 in 2 in 2 in
Clearance 50.8 mm 50.8 mm 50.8 mm 50.8 mm 50.8 mm
Load Capacity 1000 lbs 1000 lbs 800 lbs 800 lbs 650 lbs
at 18" load center 454 kg 454 kg 363 kg 363 kg 295 kg
Net Weight - Standard Base 215 lbs 260 lbs 317 lbs 405 lbs 450 lbs
(no load handling attachment) 97.5 kg 117.9 kg 143.8 kg 183.7 kg 204.1 kg
Net Weight - Straddle Base 258 lbs 303 lbs 360 lbs NA NA
(no load handling attachment) 117.0 kg 137.4 kg 163.3 kg
Load Handling Attachments Length Width Depth Net Weight
Standard Forks 271/2in 231/2in 21/2 in 38 lbs
70 cm 60 cm 6.5 cm 17.2 kg
Adjustable Forks 271/2in 111/2 in to 30 in 21/2 in 52.5 lbs
70 cm 29 cm to 76 cm 6.5 cm 23.8 kg
Flat Forks 32 in 16 in to 31 in 11/2in 73 lbs
81 cm 41 cm to 79 cm 4 cm 33.1 kg
Boom 18 in to 42 in 11/2in 61/2in 34.5 lbs
46 cm to 107 cm 4 cm 16 cm 15.6 kg
Vertical Barrel Stacker 21 in 29 in NA 50.5 lbs
53 cm 74 cm 22.9 kg
Rotating Barrel Handler 29 in 31 in NA 85 lbs
74 cm 79 cm 38.6 kg
Pipe Cradle 271/2in 24 1/2in 6 in 10 lbs
70 cm 63 cm 11.5 cm 4.5 kg
Load Platform 271/2in 231/2in 21/2in 26.5 lbs
70 cm 60 cm 6.5 cm 12.0 kg
Specifications

2 - 2 GenieSuperlift Part No. 32283
Section 2 - Specifications Part and Service Manual - First Edition
SPECIFICATIONS
Dimensions - Operating SL-5 SL-10 SL-15 SL-20 SL-25
Standard Forks forks down 4 ft 101/2in 9 ft 9 in 14 ft 71/2in 19 ft 6 in 24 ft 4 in
1.5 m 3 m 4.5 m 6 m 7.4 m
forks up 6 ft 7 in 11 ft 51/2in 16 ft 4 in 21 ft 21/2in 26 ft 1/2in
2 m 3.5 m 5 m 6.5 m 7.9 m
Adjustable Forks forks down 4 ft 101/2in 9 ft 9 in 14 ft 71/2in 19 ft 6 in 24 ft 4 in
1.5 m 3 m 4.5 m 6 m 7.4 m
forks up 6 ft 7 in 11 ft 51/2in 16 ft 4 in 21 ft 21/2in 26 ft 1/2in
2 m 3.5 m 5 m 6.5 m 7.9 m
Flat Forks 4 ft 101/2in 9 ft 9 in 14 ft 71/2in NA NA
1.5 m 3 m 4.5 m
Boom 5 ft 101/2in 10 ft 9 in 15 ft 71/2in 20 ft 6 in 25 ft 4 in
1.8 m 3.3 m 4.8 m 6.3 m 7.7 m
Note: measured from ground to bottom of shackle
Vertical Barrel Stacker 30 gallon 4 ft 8 ft 10 in 13 ft 9 in NA NA
(24 Load Center) 1.2 m 2.7 m 4.2 m
55 gallon 3 ft 10 in 8 ft 8 in 13 ft 7 in
1.2 m 2.6 m 4.1 m
Note: measured from ground to bottom of barrel
Rotating Barrel Handler 55 gallon 3 ft 10 in 8 ft 8 in 13 ft 7 in NA NA
(24 inch Load Center) 1.2 m 2.6 m 4.1 m
Note: measured from ground to bottom of barrel
Load Platform forks down 4 ft 101/2in 9 ft 9 in 14 ft 71/2in 19 ft 6 in 24 ft 4 in
1.5 m 3 m 4.5 m 6 m 7.4 m
forks up 6 ft 7 in 11 ft 51/2in 16 ft 4 in 21 ft 21/2in 26 ft 1/2in
2 m 3.5 m 5 m 6.5 m 7.9 m
Note: can be used with standard forks and adjustable forks only
Pipe Cradle:handles round objects up to 30 in (76 cm) in diameter
Note: can be used with standard forks and adjustable forks only (see above for working heights)
Non-marking Fork Option
Note: can be used with standard forks and adjustable forks only (see above for working heights)
Fork Extension Option
Note: can be used with standard forks and adjustable forks only (see above for working heights)

Part No. 32283 Genie Superlift 2 - 3
Section 2 - Specifications
Part and Service Manual - First Edition
13
20
12
18
11
18
10
16
9
14
8
12
24
32
20
28
18
24
16
24
14
20
Torque - Dry
inch-pounds Torque - Dry foot-pounds Torque - Dry Newtonmeters Torque - Dry inch-pounds Torque - Dry foot-pounds Torque - Dry Newtonmeters
43
49
96
120
17
19
30
35
50
55
75
90
110
120
150
170
260
300
430
470
640
700
5
6
11
14
23
28
41
48
68
75
102
122
149
163
204
231
353
407
583
637
868
949
60
68
144
168
25
25
45
50
70
80
110
120
150
170
220
240
380
420
600
660
900
1000
7
8
16
19
34
34
61
68
95
109
149
163
204
231
298
326
515
570
814
895
1221
1356
10
1/4
5/16
3/8
7/16
1/2
9/16
5/8
3/4
7/8
1
Torque specifications for lubricated bolts are 25% less than dry torque specifications for each bolt size.
These bolt torque specifications are for general use only. Specification may vary depending on application of bolt.
Size Threads SAE Grade 5 Bolts SAE Grade 8 Bolts
Bolt Torque Specifications
SPECIFICATIONS

2 - 4 GenieSuperlift Part No. 32283
Section 2 - Specifications Part and Service Manual - First Edition
This page intentionally left blank.

Part No. 32283 Genie Superlift 3 - 1
Section 3 - Scheduled Maintenance InspectionsParts and Service Manual - First Edition
Dealer
service
suggested
New parts
required
Tools are
required
Scheduled Maintenance Inspections
Observe and Obey:
Maintenance inspections shall be completed by
a person trained and qualified on the
maintenance of this machine.
Scheduled maintenance inspections shall be
completed daily, quarterly and annually as
specified on the maintenance inspection report.
Failure to properly complete each
inspection when required may
result in death, serious injury or
substantial machine damage.
Immediately tag and remove from service a
damaged or malfunctioning machine.
Repair any machine damage or malfunction
before operating machine.
Keep records on all inspections for three years.
Machines that have been out of service for a
period longer than 3 months must complete the
quarterly inspection.
About This Section
Schedule
There are three types of maintenance inspections
that must be performed according to a schedule—
daily, quarterly and annually. To account for
repeated procedures, the Maintenance Tables and
the Maintenance Inspection Report have been
divided into three subsections—A, B, C. Use the
following chart to determine which group(s) of
procedures are required to perform a scheduled
inspection.
Inspection Table or Checklist
Daily A
Quarterly (every 150 hours or three months) A + B
Annual A + B + C
Maintenance Tables
The maintenance tables contained in this section
provide summary information on the specific
physical requirements for each inspection.
Complete step-by-step instructions for each
scheduled maintenance procedure are provided in
section 4, Scheduled Maintenance Procedures.
Maintenance Inspection Report
The maintenance inspection report contains
checklists for each type of scheduled inspection.
Make copies of the Maintenance Inspection
Report to use for each inspection. Keep records
on all inspections for three years.

3 - 2 Genie Superlift Part No. 32283
Section 3 - Scheduled Maintenance Inspections Parts and Service Manual - First Edition
Dealer
service
suggested
New parts
required
Tools are
required
Table A
A-1 Inspect the Operator's Manual
A-2 Inspect the Decals and Placards
A-3 Inspect for Damage, Loose or Missing Parts
A-4 Check the Winch Operation
A-5 Inspect the Columns for Damage
A-6 Inspect the Cable and Cable Pulleys
A-7 Check the Mast for Proper Sequencing
A-8 Inspect the Casters and Wheels
Table B
B-1 Inspect the Column Hold Downs
B-2 Inspect All Welds
B-3 Clean the Columns
B-4 Inspect and Lubricate the Winch
B-5 Inspect and Lubricate the
Rotating Barrel Handler
Maintenance Tables

Part No. 32283 Genie Superlift 3 - 3
Section 3 - Scheduled Maintenance InspectionsParts and Service Manual - First Edition
Dealer
service
suggested
New parts
required
Tools are
required
Table C
C-1 Lubricate the Casters and Wheels
C-2 Inspect the Mast Assembly for Wear
C-3 Replace the Winch Friction Disks
C-4 Inspect the Safety Brake System
C-5 Inspect the Painted Surfaces
MAINTENANCE TABLES

3 - 4 Genie Superlift Part No. 32283
Section 3 - Scheduled Maintenance Inspections Parts and Service Manual - First Edition
Dealer
service
suggested
New parts
required
Tools are
required
Maintenance Inspection Report
Checklist A Y N R
A-1 Operator's manual
A-2 Decals and placards
A-3 Damage, loose or
missing parts
A-4 Check winch
A-5 Columns
A-6 Inspect cable and
pulleys
A-7 Check mast for proper
sequencing
A-8 Inspect casters
and wheels
Model
Serial number
Date
Machine owner
Inspected by (print)
Inspector signature
Inspector title
Inspector company
Instructions
· Make copies of this page to use for
each inspection.
·Selecttheappropriatechecklist(s)for
the type of inspection to be performed.
Daily Inspection: A
Quarterly Inspection: A+B
Annual Inspection: A+B+C
·Placea check intheappropriate box
after each inspection procedure is
completed.
·Ifany inspectionreceives an“N”,
remove the machine from use, repair
and re-inspect it. After repair, place a
check in the “R” box.
Legend
Y = yes, acceptable
N = no, unacceptable
R = repaired
Comments
Checklist B Y N R
B-1 Column hold down
B-2 Inspect welds
B-3 Clean columns
B-4 Inspect and lubricate
winch
B-5 Rotating Barrel
Handler
Checklist C Y N R
C-1 Lubricate casters
and wheels
C-2 Mast assembly wear
C-3 Replace winch
friction disks
C-4 Safety brake system
C-5 Inspect painted
surfaces

Part No. 32283 Genie Superlift 4 - 1
Parts and Service Manual - First Edition Section 4 - Scheduled Maintenance Procedures
About This Section
This section contains detailed procedures for each
scheduled maintenance inspection.
Each procedure includes a description, safety
warnings and step-by-step instructions.
Symbols Legend
Indicates the presence of a
hazard that will cause death or
serious injury.
Indicates the presence of a
hazard that may cause death or
serious injury.
Indicates the presence of a
hazard that will or may cause
serious injury or damage to the
machine.
Indicates special operation or
maintenance information.
Indicates that a specific result is expected after
performing a series of steps.
Observe and Obey:
Maintenance procedures shall be completed by
a person trained and qualified on the
maintenance of this machine.
Scheduled maintenance procedures shall be
completed daily, quarterly (every 3 months)
and annually as specified on the maintenance
inspection report.
Failure to properly complete each
inspection when required may
result in death, serious injury or
substantial machine damage.
Immediately tag and remove from service a
damaged or malfunctioning machine.
Repair any machine damage or malfunction
before operating machine.
Keep records on all inspections for three years.
Be sure the capacities of sawhorses or other
supports are sufficient to withstand machine
weight. See Specification section for specific
weight.
Be sure overhead cranes or other lifting
devices are of ample capacity to handle
machine weight. See Specification section for
specific weight.
Unless otherwise specified, perform each
procedure with the machine in the following
configuration:
· machine positioned on a flat level surface
· carriage fully lowered
· casters locked
· load handling attachment installed
Scheduled Maintenance Procedures

4 - 2 Genie Superlift Part No. 32283
Parts and Service Manual - First Edition
Section 4 - Scheduled Maintenance Procedures
A-1
Inspect the Operator's Manual
Maintainingtheoperator'smanualingoodcondition
is essential to safe machine operation. The
operator'smanualisincludedwitheachmachine
and should be stored in the box provided on the
mast. An illegible or missing manual will not provide
safetyandoperational information necessary for a
safeoperatingcondition.
1 Check to make sure the operator's manual is
presentand complete in thestoragecontainer
on the mast.
2 Examine the pages of the manual to be sure
that they are legible and in good condition.
3 Always return the manual to the storage
containerafter use.
ContactyourauthorizedGenie
distributor or Genie Industries if a
replacementmanualisneeded.
A-2
Inspect the Decals and Placards
Maintaining all of the safety and instructional
decals and placards in good condition is essential
forsafemachineoperation. Decalsalertoperators
andpersonnel to the many possiblehazards
associated with using this machine. They also
provideuserswithoperationandmaintenance
information. An illegible decal will fail to alert
personnelofaprocedure orhazard andcouldresult
inunsafeoperatingconditions.
1 Refer to the decals section in the operator's
manual and use the decal list and illustration to
determine that all decals and placards are in
place.
Table A Procedures
2 Inspect all decals for legibility and damage.
Replaceanydamagedorillegibledecal
immediately.
ContactyourauthorizedGenie
distributor or Genie Industries if
replacementdecalsareneeded.
A-3
Inspect for Damage , Loose or
Missing Parts
Daily machine condition inspections are essential
tosafemachineoperation andgoodmachine
performance.Failuretolocateandrepairdamage,
and discover loose or missing parts may result in
anunsafeoperatingcondition.
1 Inspectthe entire machine for damageand
improperlyinstalled or missing partsincluding:
· cableanchor
· cableandpulleys
· mast columns
· exterior plastic shims for safety brake
· nuts, bolts and other fasteners
· loadhandlingattachment
· winchandrelatedcomponents
· legs and casters
· stabilizers, latch plates and casters
· loadingwheelsandsnappin
· dentsordamageto machine
· cracks in welds or structural components
· corrosionto painted surfaces
· corrosion or oxidation to all other surfaces

Part No. 32283 Genie Superlift 4 - 3
Parts and Service Manual - First Edition Section 4 - Scheduled Maintenance Procedures
TABLE A PROCEDURES
A-4
Check the Winch Operation
Detection of damage to the winch is essential to
safemachineoperation.An unsafeworking
condition exists if the winch is damaged or not
operating correctly. A daily check of the winch
operation allows the inspector to identify changes in
the operating condition of the winch that might
indicatedamage.
1 Visually inspect the all winch components for
damage.
2 Raisethe carriage through apartial cycle and
releasethewinchhandles.
Result: The winch should operate smoothly, free
of hesitation or binding. The load should not
lowerwhenthehandlesarereleased.
3 Fullylowerthecarriage.
Result: The winch should operate smoothly, free
ofhesitation or binding.
A-5
Inspect the Columns for
Damage
Detection of damage to columns is essential for
safemachineoperation.An unsafeworking
condition exists if the columns are damaged and do
not operate smoothly, free of hesitation and
binding. A daily check of the columns allows the
inspector to identify changes in the operating
condition of the mast assembly that might indicate
damage.
1 Visually inspect the exterior of each column for
thefollowing:
· dents,gougesorabrasions
· bendsorwarping
· excessivewear
2 Raiseandlower all columns through a complete
cycle.
Result:Columnsshouldraiseandlower
smoothly, free of hesitation and binding.
A-6
Inspect the Cable and
Cable Pulleys
Detection of damage to cable or pulleys is essential
forsafemachineoperation.Anunsafeworking
condition exists if these components are damaged
and do not operate smoothly. A daily check of this
system allows the inspector to identify changes in
theoperating condition thatmightindicatedamage.
1 Visually inspect the cable and components for
thefollowing:
· frayedorbroken wirestrands
· kinks in the cable
· corrosion
· paintorforeignmaterials
· splitor cracked swagged end(s)
· cable is properly secured to the winch
· cable is properly secured to the mast
2 Using proper lifting techniques, lay the machine
back against a sawhorse or other suitable
support and check to be sure of the following:
· cable is on the pulleys
· upperandlowermountingbracketsare
properlysecured
· nobrokenordamagedpulleys
· no unusual or excessive pulley wear

4 - 4 Genie Superlift Part No. 32283
Parts and Service Manual - First Edition
Section 4 - Scheduled Maintenance Procedures
TABLE A PROCEDURES
A-7
Check the Mast for Proper
Sequencing
Detection of damage to the mast is essential for
safemachineoperation.An unsafeworking
condition exists if the mast is damaged and does
notsequenceproperly,freeofhesitation and
binding. A daily check of the sequencing allows the
inspector to identify changes in the operating
condition of the mast assembly that might indicate
damage.
1 Raise all columns to full height.
Result: The carriage should rise to the top of the
front column section, followed in consecutive
orderbyeachcolumn.
2 Lower the columns to the stowed position.
Result: The columns should lower in reverse
order,followedbythecarriage.
A-8
Inspect the Casters and Wheels
Extremely dirty conditions may require that the
castersandwheels be inspected and lubricated
moreoften.
1 Visually inspect each caster and wheel for cuts,
cracksor unusual wear.
2 Move the machine on a flat smooth surface and
check that the casters and wheels roll
smoothly, free of hesitation and binding.
3 Lock the base swivel casters.
Result: The wheels should not turn.
4 Be sure the rotation lock functions properly in
eachposition.

Part No. 32283 Genie Superlift 4 - 5
Parts and Service Manual - First Edition Section 4 - Scheduled Maintenance Procedures
B-1
Inspect the Column Hold Down
System
Detection of damage to the column hold down
system is essential for safe machine operation. An
unsafe working condition exists if the system is
damaged and does not operate properly.
1 Using proper lifting techniques, lay the machine
back against a sawhorse or other suitable
support.
2 Visually inspect the hold down latches for
damage.
3 Move each hold down latch back and forth to
ensure that the latch moves freely.
B-2
Inspect All Welds
Weld inspections are essential to safe machine
operation and good machine performance. Failure
to locate and repair damage may result in an
unsafe operating condition.
1 Visually inspect the welds in the following
locations:
· winch mounting plate
· loading wheels/steer handle
· base
· legs and stabilizers
· load handling attachment(s)
B-3
Clean the Columns
Clean columns are essential to good machine
performance and safe operation. Extremely dirty
conditions may require that the columns be
cleaned more often.
1 Raise all columns to the maximum height.
2 Visually inspect the inner and outer channels of
the columns for debris or foreign material. If
necessary, use a mild cleaning solvent to clean
the columns.
This procedure will require the use
of additional access equipment.
Do not place ladders or scaffold
on or against any part of the
machine. Performing this
procedure without the proper skills
and tools may result in death or
serious injury. Dealer service is
strongly recommended.
Table B Procedures

4 - 6 Genie Superlift Part No. 32283
Parts and Service Manual - First Edition
Section 4 - Scheduled Maintenance Procedures
TABLE B PROCEDURES
B-4
Inspect and Lubricate the Winch
Maintaining the winch is essential to good machine
performance and safe operation. An unsafe
working condition exists if the winch has excessive
wear and/or does not operate smoothly, free of
hesitation and binding.
1 Carefully lubricate the following areas with
automotive grease:
· the cable drum gear
· the teeth on the pinion gear that meshes with
the cable drum gear
· the threads on the pinion shaft, under the
pinion gear
· the teeth on the slow and the fast speed gears
where they mesh together
Do not apply grease to brake
friction disks or rachet gear.
2 Carefully lubricate with 30W oil both pivot
points on each ratchet pawl.
3 Inspect the friction disks for excessive wear.
Replace if pad is less than 1/16 inch (1.5 mm)
thick.
4 Inspect pinion shaft bushings for excessive
wear. Replace if wall thickness of bushing is
less than 1/8inch (3.1 mm).
5 Lubricate the frame drum spacer. Tighten the
drum bolt to 20 ft-lbs (27 Nm). Do not
overtighten.
B-5
Inspect and Lubricate the
Rotating Barrel Handler
Maintaining the barrel handler is essential to good
performance and safe operation. An unsafe
working condition exists if the barrel handler has
excessive wear and/or does not operate smoothly,
free of hesitation and binding.
1 Visually inspect the following components for
damage:
· all bushings
· chain and clamp
· gears
· snap rings
· fasteners
· crank handle
2 Raise the barrel handler to a comfortable
working height (chest height). Do not put a load
on it.
3 Pump grease onto the drive gear. Locate the
gear from the bottom side of the barrel handler.
4 Using the crank handle, rotate the barrel cradle
1/4turn and apply more grease.
5 Rotate the barrel cradle 2 full turns or until the
grease is completely worked into the gears.
Oil Type Multipurpose grease

Part No. 32283 Genie Superlift 4 - 7
Parts and Service Manual - First Edition Section 4 - Scheduled Maintenance Procedures
C-2
Inspect the Mast Assembly
for Wear
Detection of excessive or unusual wear in the
mast assembly is essential for safe machine
operation. An unsafe working condition exists if
the mast assembly has excessive wear and/or
does not operate smoothly, free of hesitation and
binding.
1 Attach an overhead crane or similar lifting
device to the lifting bracket on the mast.
2 Lift the machine slightly and then guide it over
onto the ground, so that the machine is laying
on the loading wheels.
Crushing hazard. The machine
will fall unless it is properly
supported with the overhead
crane.
3 Visually inspect the top of each column for
clearance between the roller wheel and the
adjacent column surface.
Result: There should be a maximum gap of
0.062 inches (1.57 mm) between the roller
wheel and the column.
If mast inspection results in a
measurement that is not within
specification, refer to Repair
procedure 2-1, How to
Disassemble the Mast.
C-1
Lubricate the Casters and Wheels
Extremely dirty conditions may require that the
casters and wheels be inspected and lubricated
more often.
1 Visually inspect each caster and wheel for cuts,
cracks or unusual wear.
2 Move the machine on a flat smooth surface and
check that the casters and wheels roll
smoothly, free of hesitation and binding.
3 Pump grease into the caster or wheel until it
can be seen coming out of the bearing gap.
Grease Type Lithium-based
Table C Procedures
