GeoVision GV-EBD Series User manual

Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
User's Manual
GV-IP Camera
UBN-UM-S
GV-EBD Series
GV-ABL / TBL Series
GV-ADR / TDR Series
GV-AVD / TVD Series

© 2021 GeoVision, Inc. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in part,
without the written consent of GeoVision.
Every effort has been made to ensure that the information in this manual is
accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind
and assumes no responsibility for errors or omissions. No liability is assumed
for incidental or consequential damages arising from the use of the information
or products contained herein. Features and specifications are subject to
change without notice.
Note: No memory card slot or local storage function for Argentina.
GeoVision, Inc.
9F, No. 246, Sec. 1, Neihu Rd.,
Neihu District, Taipei, Taiwan
Tel: [phone]
Fax: [phone]
http://www.geovision.com.tw
Trademarks used in this manual: GeoVision, the GeoVision logo and GV
series products are trademarks of GeoVision, Inc. Windows is the registered
trademark of Microsoft Corporation.
February 2021

Preface
Welcome to the GV-EBD Series IR Eyeball IP Dome, GV-ABL Series Bullet IP Camera,
GV-ADR / TDR Series Mini Fixed Rugged IP Dome and GV-AVD Series Vandal Proof IP
Camera User’s Manual.
The features described in the manual vary among camera models and versions. Some
features may not be available in your camera.
This Manual is designed for the following models:
Model Model Number
GV-EBD2702
GV-EBD4700 / 4701 / 4711 / 4712
IR Eyeball Dome GV-EBD8700 / 8711 / 8800 / 8813
GV-ABL2701 Series / 2702 / 2703 Series
GV-ABL4701 Series / 4703 / 4711 / 4712
GV-ABL8712
GV-TBL2703 Series / 4700 / 4703 / 4710 / 4711
Bullet IP Camera
GV-TBL8710 / 8804 / 8810
GV-ADR2701 / 2702
GV-ADR4701 / 4702
GV-TDR2700 / 2702
Mini Fixed Rugged IP Dome
GV-TDR4700 Series / 4702 Series / 4703 Series
GV-AVD2700
GV-AVD4710
GV-AVD8710
GV-TVD4700 / 4710 / 4711
Vandal Proof IP Dome
GV-TVD8710 / 8810
i

Contents
Naming Definition....................................................................vi
Note for Connecting to GV-VMS / DVR / NVR......................vii
Note for Installing Camera Outdoor .....................................vii
Note for Powering the Camera..............................................vii
Note for Face Detection........................................................viii
Note for People Counting.......................................................ix
Chapter 1 Introduction ..........................................................1
1.1 GV-EBD Series...................................................................................................... 1
1.1.1 Packing List................................................................................................ 2
1.1.2 Optional Accessories ................................................................................. 2
1.1.3 Overview.................................................................................................... 4
1.1.3.1 GV-EBD2702 / 4700 / 4701 / 8700 / 8800............................................... 4
1.1.3.2 GV-EBD4711 / 4712 / 8711 / 8813.......................................................... 5
1.1.4 Installation.................................................................................................. 6
1.1.4.1 GV-EBD2702 / 4700 / 4701 / 8700 / 8800 Standard Installation ... 6
1.1.4.2 GV-EBD4711 / 4712 / 8711 / 8813 Standard Installation.............. 9
1.1.5 Optional Installation...................................................................................12
1.1.5.1 GV-Mount211P............................................................................12
1.1.5.2 GV-Mount212P............................................................................17
1.1.5.3 GV-Mount420 + GV-Mount211P..................................................21
1.1.5.4 GV-Mount212P + GV-Mount107..................................................24
1.2 GV-ABL / TBL Series............................................................................................26
1.2.1 Packing List...............................................................................................27
1.2.2 Optional Accessories ................................................................................27
1.2.3 Overview...................................................................................................29
1.2.3.1 GV-ABL2701 / 2703 / 4701 / 4703 & TBL2703 / 4703..................30
1.2.3.2 GV-ABL2702 / 4711 / 4712 / 8712 & TBL4700 / 4710 / 4711 / 8710 /
8810..........................................................................................................29
1.2.4 Installation.................................................................................................31
1.2.5 Optional Installation...................................................................................34
1.2.5.1 GV-Mount502..............................................................................35
1.2.5.2 GV-Mount503..............................................................................37
ii

1.2.5.3 GV-Mount420 + GV-Mount503....................................................39
1.2.5.4 GV-Mount504..............................................................................41
1.3 GV-ADR / TDR Series ..........................................................................................43
1.3.1 Packing List...............................................................................................45
1.3.2 Optional Accessories ................................................................................45
1.3.3 Overview...................................................................................................47
1.3.4 Installation.................................................................................................48
1.3.5 Optional Installation ...........................................................................................51
1.3.5.1 GV-Mount211P......................................................................................51
1.4 GV-AVD / TVD Series...........................................................................................55
1.4.1 Packing List...............................................................................................56
1.4.1.1 GV-TVD4711...............................................................................56
1.4.1.2 GV-AVD / TVD Series..................................................................57
1.4.2 Optional Accessories ................................................................................58
1.4.3 Overview...................................................................................................60
1.4.3.1 GV-AVD2700 / 4710 / 8710, GV-TVD4700 / 4710 / 8710 / 8810..60
1.4.3.2 GV-TVD4711...............................................................................61
1.4.4 Installation.................................................................................................62
1.4.4.1 GV-AVD2700 / 4710 / 8710, GV-TVD4700 / 4710 / 8710 / 8810..62
1.4.4.2 GV-TVD4711...............................................................................64
1.4.5 Optional Installation...................................................................................66
1.4.5.1 GV-Mount211-2...........................................................................67
1.4.5.2 GV-Mount212-2...........................................................................69
1.4.5.3 GV-Mount420 + GV-Mount211-2.................................................72
1.4.5.4 GV-Mount606..............................................................................73
1.5 System Requirements...........................................................................................75
1.6 Waterproofing the Cable.......................................................................................76
Chapter 2 Accessing the Camera.......................................78
2.1 Installing on a Network..........................................................................................78
2.1.1 Looking up the Dynamic IP Address and Logging In.................................79
2.1.2 Configuring the IP Address .......................................................................80
2.2 Accessing Live View.............................................................................................81
2.2.1 Digital Zoom..............................................................................................83
2.2.2 Start Recording.........................................................................................83
2.3 Playing Back Recorded Videos.............................................................................84
2.3.1 Recording Download.................................................................................85
iii

Chapter 3 Administrator Mode ...........................................86
3.1 Common...............................................................................................................85
3.1.1 Basic Info..................................................................................................85
3.1.2 Local Parameters......................................................................................86
3.2 Network ................................................................................................................88
3.2.1 Network.....................................................................................................88
3.2.2 DNS..........................................................................................................89
3.2.3 Port...........................................................................................................90
3.2.4 DDNS........................................................................................................91
3.2.5 E-mail........................................................................................................93
3.2.6 SNMP .......................................................................................................94
3.2.7 802.1x.......................................................................................................95
3.2.8 QoS ..........................................................................................................96
3.3 Video & Audio.......................................................................................................97
3.3.1 Video.........................................................................................................97
3.3.2 Snapshot...................................................................................................99
3.3.3 Audio.......................................................................................................100
3.3.4 ROI.........................................................................................................101
3.3.5 Media Stream..........................................................................................102
3.4 Image .................................................................................................................104
3.4.1 Image......................................................................................................104
3.4.2 OSD........................................................................................................109
3.4.3 Privacy Mask...........................................................................................111
3.5 Intelligent............................................................................................................112
3.5.1 Smart Settings ........................................................................................112
3.5.1.1 Cross Line.................................................................................113
3.5.1.2 Intrusion ....................................................................................116
3.5.1.3 Object Removed........................................................................118
3.5.1.4 Object Left Behind.....................................................................119
3.5.1.5 Defocus.....................................................................................120
3.5.1.6 Scene Change...........................................................................121
3.5.1.7 Face Detection..........................................................................122
3.5.1.8 People Counting........................................................................123
3.5.1.9 Human Body Detection..............................................................124
3.5.2.0 Enter Area / Leave Area............................................................125
3.5.2 Advanced Settings..................................................................................126
3.6 Events................................................................................................................128
iv

v
3.6.1 Motion Detection.....................................................................................128
3.6.2 Tampering Alarm ....................................................................................130
3.6.3 Audio Detection.......................................................................................131
3.6.4 Alarm Input..............................................................................................132
3.6.5 Alarm Output...........................................................................................133
3.7 Formatting Storage.............................................................................................134
3.7.1 Storage...................................................................................................134
3.7.2 FTP.........................................................................................................136
3.7.3 Backing Up Storage................................................................................137
3.8 Security...............................................................................................................138
3.8.1 User........................................................................................................138
3.8.2 Network Security.....................................................................................139
3.9 System................................................................................................................142
3.9.1 Time........................................................................................................142
3.9.2 Maintenance ...........................................................................................144
Chapter 4 Advanced Applications ...................................145
4.1 Upgrading System Firmware...............................................................................145
4.1.1 Using the Web Interface..........................................................................146
4.1.2 Using GV-IP Device Utility.......................................................................147
4.2 Restoring to Factory Default Settings..................................................................148
Chapter 5 DVR / NVR / VMS ..............................................149
5.1 Setting Up IP Cameras on GV-DVR / NVR.........................................................149
5.2 Setting Up IP Cameras on GV-VMS ...................................................................153
Appendix...............................................................................155
A. RTSP Multicast Protocol Support.........................................................................155
B. RTSP Protocol Support........................................................................................155
C. HTTP Protocol Support........................................................................................155
D. Compatible Versions of GV-VMS / DVR / NVR.....................................................156
E. GV-Mount Dimensions .........................................................................................158
F. GV-Mount300-2 / 310-2........................................................................................161
G. Screw Position Chart............................................................................................163

Naming Definition
GV-DVR / NVR GeoVision Analog and Digital Video Recording Software. The GV-
DVR also refers to GV-Multicam System or GV-Hybrid DVR.
GV-VMS GeoVision Video Management System for IP cameras.
vi

Note for Connecting to GV-VMS / DVR / NVR
The GV-IPCAM in this Manual is designed to work with and record on GV-VMS / DVR / NVR,
a video management system.
Once the camera is connected to the GV-VMS / DVR / NVR, the resolution set on the
GV-VMS / DVR / NVR will override the resolution set on the camera’s Web interface.
You can only change the resolution settings through the Web interface when the
connection to the GV-VMS / DVR / NVR is interrupted.
The login password of the camera cannot contain the character “&” or any whitespace
when connecting to GV-VMS.
The Video Analytic features under Intelligent (see 3.5 Intelligent) cannot be integrated
with GV-VMS / DVR / NVR.
Note for Installing Camera Outdoor
When installing the camera outdoor, be sure that:
1. The camera is set up above the junction box to prevent water from entering the camera
along the cables.
2. Any PoE, power, audio and I/O cables are waterproofed using waterproof silicon rubber
or the like.
3. The screws are tightened and the cover is in place after opening the camera cover.
Note for Powering the Camera
The camera is powered by PoE or a power adapter. If you want to power the camera using
the power connector, an optional power adapter is required.
vii

Note for Face Detection
To use the camera’s built-in face detection feature (see 3.5.1.7 Face Detection), not
supported by GV-ABL2701 series / 2703 series / 4701 series / 4703 / 4711, GV-ADR2701 /
2702 / 4701 / 4702, GV-EBD4701 / 4712 / 8800 / 8813, GV-TBL series, GV-TDR2702 series
/ 4702 series / 4703 series, and GV-TVD series, it is recommended to install the camera
according to the criteria listed below:
Surveillance Condition
The camera shall be installed at a site with uniform, sufficient lighting, where the
face(s) to be detected are fully illuminated.
Example of Recommended Scene Example of Non-recommended Scene
Camera Position
The camera shall be mounted at a recommended height of 2.5 ~ 3 m (8.2 ~ 9.84 ft).
The camera shall be mounted with a recommended depression angle of around 10°.
The camera shall be positioned so that the face(s) to be detected are directly aligned
with the lens of the camera, with a horizontal deviation of no greater than 30°, a
vertical deviation of no greater than 15° and a face size of at least 120 pixels.
viii

ix
Note for People Counting
To use the camera’s built-in people counting feature (see 3.5.1.8 People Counting), not
supported by GV-ABL2701 series / 2703 series / 4701 series / 4703 / 4711, GV-ADR2701 /
2702 / 4701 / 4702, GV-EBD4701 / 4712 / 8800 / 8813, GV-TBL series, GV-TDR2702 series
/ 4702 series / 4703 series, and GV-TVD series, it is recommended to install the camera
according to the criteria listed below:
Surveillance Condition
The camera shall be installed at a site with uniform, sufficient lighting, where the
person(s) to be counted are fully illuminated.
The camera shall be installed at an entrance or exit with an ideal width of 1 ~ 4 m
(3.28 ~ 13.12 ft), where the persons(s) to be counted move toward the lens of the
camera in single file.
Example of Recommended Scene Example of Non-recommended Scene
Camera Position
The camera shall be mounted at a recommended height of 3 ~ 5 m (9.84 ~ 16.4 ft).
The camera shall be mounted with a recommended depression angle of 70 ~ 80°.
The camera shall be positioned so that the person(s) to be counted face toward the
lens of the camera and are displayed on the image with a shoulder size of between
120 ~ 160 pixels.

Introduction
1
Chapter 1 Introduction
1.1 GV-EBD Series
The H.265 Target Eyeball Dome is an outdoor, network camera equipped with an automatic
IR-cut filter and IR LEDs for day and night surveillance. The camera adheres to IP67
standards for dust / water protection and supports H.265 video codec to achieve better
compression ratio while maintaining high quality image at reduced network bandwidths. With
its WDR Pro (WDR for GV-EBD2702), It can process scenes with contrasting intensity of
lights and produce clear image.
For GV-EBD4711 / 4712 / 8711 / 8813, with their motorized lenses, the user can zoom and
focus the camera from the Web interface. The camera also provides built-in micro SD card
slot for local storage.
Model No. Specifications Description
GV-EBD2702 2 MP, H.265, Low
Lux, WDR
GV-EBD4700
Fixed Iris, f: 2.8 mm,
F/1.8, M12 Lens Mount
GV-EBD4701
4 MP, H.265, Super
Low Lux, WDR Pro
GV-EBD8700
GV-EBD8800
Fixed lens
Fixed Iris, f: 2.8 mm,
F/2.0, M12 Lens Mount 8 MP, H.265, Low
Lux, WDR Pro
GV-EBD4711 Fixed Iris, f: 2.7 ~ 12 mm,
F/1.4, Ø12 mm Lens
Mount
GV-EBD4712 Fixed Iris, f: 2.8 ~ 12 mm,
F/1.6, Ø12 mm Lens
Mount
4 MP, H.265, Super
Low Lux, WDR Pro
GV-EBD8711 Fixed Iris, f: 2.8 ~ 12 mm
F/1.5, Ø12 mm Lens
Mount
GV-EBD8813
Motorized
varifocal lens
Fixed Iris, f: 2.8 ~ 12 mm,
F/1.6, Ø12 mm Lens
Mount
8 MP, H.265, Super
Low Lux, WDR Pro
1

1.1.1 Packing List
H.265 Target Eyeball Dome
Screw Kit
Drill Template Paster
Waterproof Rubber Set
Download Guide
Warranty Card
1.1.2 Optional Accessories
Optional accessories can expand the capabilities and versatility of your camera. Contact your
dealer for more information.
Model Number Name Details
GV-Mount107
(must be used with
GV-Mount212P)
Pendant Bracket
Dimensions: Ø 120 x 334 mm (Ø
4.72” x 13.15”)
Weight: 0.74 kg (1.63 lb)
GV-Mount211P Wall Mount and Junction Box
Dimensions: 233 x 126 x 126 mm
(9.2” x 5” x 5”)
Weight: 1 kg (2.2 lb)
GV-Mount212P Wall Box Mount
Dimensions: Ø 126 x 36 mm (Ø
5.0” x 1.4”)
Weight: 0.22 kg (0.48 lb)
2

Introduction
1
GV-Mount300-2 Convex Corner Mount
Dimensions: 137 x 233 x 160 mm
(5.4” x 9.17” x 6.3”)
Weight: 1.65 kg (3.64 lb)
GV-Mount310-2 Concave Corner Mount
Dimensions: 111.2 x 369.9 x 210
mm (2.6” x 11.4” x 6.6”)
Weight: 1.65 kg (3.64 lb)
GV-Mount420
(must be used with
GV-Mount211P)
Pole Mount Bracket
Dimensions: Ø 120 x 120 x 53.4
mm (Ø 4.7” x 4.7” x 2.1”)
Weight: 0.45 kg (0.99 lb)
Steel Strap Diameter: Ø 67 ~ 127
mm (Ø 2.6” ~ 5”)
GV-Mount704
(must be used with
GV-Mount107)
Extension Tube
Dimensions: Ø 3.5 x 10 or 20 or 30
or 50 cm (Ø 1.38 x 3.9 or 7.9 or
11.8 or 19.7”)
Weight: 225 g or 360 g or 500 g or
780 g (0.5 lb or 0.79 lb or 1.1 lb or
1.72 lb)
GV-PA191 Power over Ethernet (PoE)
Adapter
GV-PA191 is a Power over
Ethernet (PoE) adapter designed
to provide power to the IP device
through a single Ethernet cable.
GV-POE Switch GV-POE Switch is designed to provide power along with network
connection for IP devices. GV-POE Switch is available in various
models with different numbers and types of ports.
Power Adapter Contact our sales representatives for the countries and areas
supported.
3

1.1.3 Overview
1.1.3.1 GV-EBD2702 / 4700 / 4701 / 8700 / 8800
Figure 1-1
No. Description
1 Bottom ring
2 Housing
3 Lens
4 Infrared indicator
5 Power connector (DC 12 V)
6 Ethernet connector / PoE
7 Micro SD card slot (GV-EBD4701 / 8800 only)
8 Microphone (GV-EBD4701 / 8800 only)
4

Introduction
1
1.1.3.2 GV-EBD4711 / 4712 / 8711 / 8813
Figure 1-2
No. Description
1 Bottom ring
2 Housing
3 Microphone
4 Lens
5 Power connector (DC 12 V)
6 Ethernet connector / PoE
7 Micro SD card slot and default button compartment
8 Default button
9 Micro SD card slot
Note: If the default button doesn’t respond after pressing for 15 seconds, reboot the
camera and try again within 10 minutes of rebooting.
5

1.1.4 Installation
The Target Eyeball Dome is designed for outdoors. With the standard package, you can
install the camera on the ceiling. Alternatively, you can purchase optional mounting
accessories to mount the dome on a wall.
Below are the instructions for Ceiling Mount. There are two kinds of Ceiling Mount:
Concealed Installation and Open Installation. In concealed installation, the cables are
hidden in the ceiling. In Open Installation, the cables are led out from the open slot on the
bottom ring.
1.1.4.1 GV-EBD2702 / 4700 / 4701 / 8700 / 8800 Standard Installation
For Concealed Installation
1. Stick the drill template paster to the ceiling and drill three holes according to the drill
template.
Figure 1-3
2. Insert the screw anchors.

Figure 1-4
6

Introduction
1
3. Remove the bottom ring by turning it anticlockwise.
Figure 1-5
4. Connect the cables and secure the camera.
Figure 1-6
5. Adjust the monitoring direction.
Figure 1-7
7

6. Mount the bottom ring.
Figure 1-8
For Open Installation
Lead the cables out from the open slot on the bottom ring before screwing the camera to the
ceiling as shown in Figure 1-6.

Figure 1-9
8

Introduction
1
1.1.4.2 GV-EBD4711 / 4712 / 8711 / 8813 Standard Installation
For Concealed Installation
1. Stick the drill template paster to the ceiling and drill three holes according to the drill
template.
Figure 1-10
2. Insert the screw anchors.

Figure 1-11
3. Loosen the fixing screw and remove the housing by turning it to the position as shown.
Figure 1-12
9
